9mxd

Human E104A calmodulin:MLCK RM20 complex

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Calmodulin-1

Homo sapiens

UniProt P0DP23

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 2 Myosin light chain kinase, smooth muscle, deglutamylated form × 1 (Q15746) CALCIUM ION × 4 water × 2 Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence
UniProt name CALM1_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A; PDBConstruct 1–149; UniProt 1–149

Myosin light chain kinase, smooth muscle, deglutamylated form

OrganismNot specified

UniProt Q15746

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 2 Calmodulin-1 × 1 (P0DP23) CALCIUM ION × 4 water × 2 Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence
UniProt name MYLK_HUMAN
Isoform —
PDB entities 2
Chains and sequence ranges Author chain B; PDBConstruct 1–20; UniProt 1742–1761

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id9mxd
Deposition date deposition_date2025-01-19
Last revision last_revision2026-02-11
Structure title titleHuman E104A calmodulin:MLCK RM20 complex
Keywords keywordsE101A calmodulin, calcium signal transduction, protein kinase, myosin light chain kinase, TRANSFERASE; TRANSFERASE
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

9mxd__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

9mxd__assembly_1__model_1 | I(q)

10-2 10-1 105 106 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

9mxd__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg(Guinier)17.05 Å
Rg (electron density)15.74 Å
Total Rg16.67 Å
Atom count2473
Residues163
Excluded volume22471 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 9mxd__assembly_1__model_1 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (4)

▶

7. Citations (1)
