1axc

HUMAN PCNA

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

PCNA

OrganismNot specified

UniProt P12004

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 6 P21/WAF1 × 3 （P38936） water × 6 Consistent with protein count

Other States of the Same Protein in the Database

Monomer
8e84 8e84 8e84

3 assemblies

Homodimer

None

Homotetramer

None

Other homooligomers
1vym 1w60 1w60 3ja9 3vkx 3wgw 3wgw 5e0t 5e0t 5mlo 5mlw 5mom

21 assemblies; showing the first 12

Heteromeric or nucleic-acid complex
1axc 1u76 1u7b 1ul1 1vyj 1vyj 2zvk 2zvl 2zvl 2zvm 3p87 3p87

103 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name PCNA_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 1–261； UniProt 1–261 Author chain C； PDBConstruct 1–261； UniProt 1–261 Author chain E； PDBConstruct 1–261； UniProt 1–261

P21/WAF1

OrganismNot specified

UniProt P38936

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 6 PCNA × 3 （P12004） water × 6 Consistent with protein count

Other States of the Same Protein in the Database

Monomer
6cej

1 assemblies

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
1axc 2zvv 2zvv 2zvw 2zvw 2zvw 2zvw 4rjf 4rjf 4rjf 5e0u 5e0u

14 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name CDN1A_HUMAN
Isoform —
PDB entities 2
Chains and sequence ranges Author chain B； PDBConstruct 1–22； UniProt 139–160 Author chain D； PDBConstruct 1–22； UniProt 139–160 Author chain F； PDBConstruct 1–22； UniProt 139–160

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id1axc
Deposition date deposition_date1997-10-14
Structure title titleHUMAN PCNA
Keywords keywordsDNA, REPLICATION, PROCESSIVITY, ONCOGENE, WAF1, CIP1, COMPLEX (DNA-BINDING PROTEIN-DNA), COMPLEX (DNA-BINDING PROTEIN-DNA) complex; COMPLEX (DNA-BINDING PROTEIN/DNA)
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1axc__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1axc__assembly_1__model_1 | I(q)

10-2 10-1 106 107 108 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

1axc__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）33.73 Å
Rg (electron density)32.47 Å
Total Rg33.18 Å
Atom count7508
Residues804
Excluded volume110310 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 1axc__assembly_1__model_1 hexameric （6） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (3)

▼

6. Fold Classification (SCOP + CATH) 9 domains

SCOP 2.08 (6 domains)

Domain ID domain_idd1axca1
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.131 — DNA clamp
Superfamily Superfamily superfamilyd.131.1 — DNA clamp
Family Family familyd.131.1.2 — DNA polymerase processivity factor
Domain ID domain_idd1axca2
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.131 — DNA clamp
Superfamily Superfamily superfamilyd.131.1 — DNA clamp
Family Family familyd.131.1.2 — DNA polymerase processivity factor
Domain ID domain_idd1axcc1
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.131 — DNA clamp
Superfamily Superfamily superfamilyd.131.1 — DNA clamp
Family Family familyd.131.1.2 — DNA polymerase processivity factor
Domain ID domain_idd1axcc2
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.131 — DNA clamp
Superfamily Superfamily superfamilyd.131.1 — DNA clamp
Family Family familyd.131.1.2 — DNA polymerase processivity factor
Domain ID domain_idd1axce1
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.131 — DNA clamp
Superfamily Superfamily superfamilyd.131.1 — DNA clamp
Family Family familyd.131.1.2 — DNA polymerase processivity factor
Domain ID domain_idd1axce2
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.131 — DNA clamp
Superfamily Superfamily superfamilyd.131.1 — DNA clamp
Family Family familyd.131.1.2 — DNA polymerase processivity factor

CATH v4.4 (3 domains)

Domain ID domain_id1axcA00
Class class3 — Alpha Beta
Architecture architecture70 — Box
Topology topology10 — Proliferating Cell Nuclear Antigen
Homologous superfamily homologous superfamily10 —
Domain ID domain_id1axcC00
Class class3 — Alpha Beta
Architecture architecture70 — Box
Topology topology10 — Proliferating Cell Nuclear Antigen
Homologous superfamily homologous superfamily10 —
Domain ID domain_id1axcE00
Class class3 — Alpha Beta
Architecture architecture70 — Box
Topology topology10 — Proliferating Cell Nuclear Antigen
Homologous superfamily homologous superfamily10 —
▶

7. Citations (1)
