1hcq

THE CRYSTAL STRUCTURE OF THE ESTROGEN RECEPTOR DNA-BINDING DOMAIN BOUND TO DNA: HOW RECEPTORS DISCRIMINATE BETWEEN THEIR RESPONSE ELEMENTS

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

PROTEIN (ESTROGEN RECEPTOR)

Homo sapiens

UniProt P03372

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein–DNA Homooligomer Protein 2 DNA 2 ;DNA (5'-D(*CP*CP*AP*GP*GP*TP*CP*AP*CP*AP*GP*TP*GP*AP*CP*CP*T P*G)-3') ; × 1 ;DNA (5'-D(*CP*CP*AP*GP*GP*TP*CP*AP*CP*TP*GP*TP*GP*AP*CP*CP*T P*G)-3') ; × 1 ZINC ION × 4 water × 4 Consistent with all polymers
2 Protein–DNA Homooligomer Protein 2 DNA 2 ;DNA (5'-D(*CP*CP*AP*GP*GP*TP*CP*AP*CP*AP*GP*TP*GP*AP*CP*CP*T P*G)-3') ; × 1 ;DNA (5'-D(*CP*CP*AP*GP*GP*TP*CP*AP*CP*TP*GP*TP*GP*AP*CP*CP*T P*G)-3') ; × 1 ZINC ION × 4 water × 4 Consistent with all polymers

Other States of the Same Protein in the Database

Monomer
1hcp 7qvj 7qvj 7qvl 7qvl

5 assemblies

Homodimer
1a52 1a52 1ere 1ere 1ere 1err 1g50 1g50 1qkt 1qku 1qku 1r5k

196 assemblies; showing the first 12

Homotetramer
1a52 1a52

2 assemblies

Other homooligomers
4q50

1 assemblies

Heteromeric or nucleic-acid complex
1gwq 1gwr 1gwr 1hcq 1hcq 1l2i 1l2i 1pcg 1x7e 1x7r 1zky 2b1v

319 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name ESR1_HUMAN
Isoform —
PDB entities 3
Chains and sequence ranges Author chain A； PDBConstruct 2–84； UniProt 180–262 Author chain B； PDBConstruct 2–84； UniProt 180–262 Author chain E； PDBConstruct 2–84； UniProt 180–262 Author chain F； PDBConstruct 2–84； UniProt 180–262

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id1hcq
Deposition date deposition_date1995-01-04
Structure title titleTHE CRYSTAL STRUCTURE OF THE ESTROGEN RECEPTOR DNA-BINDING DOMAIN BOUND TO DNA: HOW RECEPTORS DISCRIMINATE BETWEEN THEIR RESPONSE ELEMENTS
Keywords keywordsPROTEIN-DNA COMPLEX, COMPLEXED WITH DRUG, TRANSCRIPTION-DNA COMPLEX; TRANSCRIPTION/DNA
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1hcq__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1hcq__assembly_1__model_1 | I(q)

10-2 10-1 105 106 107 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

1hcq__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）20.15 Å
Rg (electron density)19.77 Å
Total Rg20.25 Å
Atom count1867
Residues181
Excluded volume30567 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 1hcq__assembly_1__model_1 tetrameric （4） Success 4.1.3-1-20251215 (887e7ef) View Download
2 1 1hcq__assembly_2__model_1 tetrameric （4） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (5)

▼

6. Fold Classification (SCOP + CATH) 8 domains

SCOP 2.08 (4 domains)

Domain ID domain_idd1hcqa_
Class classg — Small proteins
Fold Fold foldg.39 — Glucocorticoid receptor-like (DNA-binding domain)
Superfamily Superfamily superfamilyg.39.1 — Glucocorticoid receptor-like (DNA-binding domain)
Family Family familyg.39.1.2 — Nuclear receptor
Domain ID domain_idd1hcqb_
Class classg — Small proteins
Fold Fold foldg.39 — Glucocorticoid receptor-like (DNA-binding domain)
Superfamily Superfamily superfamilyg.39.1 — Glucocorticoid receptor-like (DNA-binding domain)
Family Family familyg.39.1.2 — Nuclear receptor
Domain ID domain_idd1hcqe_
Class classg — Small proteins
Fold Fold foldg.39 — Glucocorticoid receptor-like (DNA-binding domain)
Superfamily Superfamily superfamilyg.39.1 — Glucocorticoid receptor-like (DNA-binding domain)
Family Family familyg.39.1.2 — Nuclear receptor
Domain ID domain_idd1hcqf_
Class classg — Small proteins
Fold Fold foldg.39 — Glucocorticoid receptor-like (DNA-binding domain)
Superfamily Superfamily superfamilyg.39.1 — Glucocorticoid receptor-like (DNA-binding domain)
Family Family familyg.39.1.2 — Nuclear receptor

CATH v4.4 (4 domains)

Domain ID domain_id1hcqA00
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology50 — Erythroid Transcription Factor GATA-1; Chain A
Homologous superfamily homologous superfamily10 — Erythroid Transcription Factor GATA-1, subunit A
Domain ID domain_id1hcqB00
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology50 — Erythroid Transcription Factor GATA-1; Chain A
Homologous superfamily homologous superfamily10 — Erythroid Transcription Factor GATA-1, subunit A
Domain ID domain_id1hcqE00
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology50 — Erythroid Transcription Factor GATA-1; Chain A
Homologous superfamily homologous superfamily10 — Erythroid Transcription Factor GATA-1, subunit A
Domain ID domain_id1hcqF00
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology50 — Erythroid Transcription Factor GATA-1; Chain A
Homologous superfamily homologous superfamily10 — Erythroid Transcription Factor GATA-1, subunit A
▶

7. Citations (2)
