1r5d

X-ray structure of bovine seminal ribonuclease swapping dimer from a new crystal form

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Ribonuclease, seminal

OrganismNot specified

UniProt P00669

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein homooligomer Homooligomer Protein 2 water × 2 Consistent with protein count

Other States of the Same Protein in the Database

Monomer
1n1x 1n3z 1qwq 1r3m 1r3m 2lfj

6 assemblies

Homodimer
11ba 1bsr 1r5c 1r5d 1tq9 1y92 1y94 3bcm 3bcm 3bco 3bcp 3bcp

18 assemblies; showing the first 12

Homotetramer
1bsr 3bcp

2 assemblies

Other homooligomers

None

Heteromeric or nucleic-acid complex

None

View Construct and Data Evidence
UniProt name RNS_BOVIN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 1–124； UniProt 27–150 Author chain B； PDBConstruct 1–124； UniProt 27–150

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id1r5d
Deposition date deposition_date2003-10-10
Structure title titleX-ray structure of bovine seminal ribonuclease swapping dimer from a new crystal form
Keywords keywordsribonucleases, protein dynamics, protein structure-function, ligand binding, population shift, 3D domain swapping, HYDROLASE; HYDROLASE
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1r5d__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1r5d__assembly_1__model_1 | I(q)

10-2 10-1 105 106 107 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

1r5d__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）21.32 Å
Rg (electron density)21.23 Å
Total Rg21.95 Å
Atom count1882
Residues248
Excluded volume33201 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 1r5d__assembly_1__model_1 dimeric （2） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (2)

▼

6. Fold Classification (SCOP + CATH) 4 domains

SCOP 2.08 (2 domains)

Domain ID domain_idd1r5da_
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.5 — RNase A-like
Superfamily Superfamily superfamilyd.5.1 — RNase A-like
Family Family familyd.5.1.1 — Ribonuclease A-like
Domain ID domain_idd1r5db_
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.5 — RNase A-like
Superfamily Superfamily superfamilyd.5.1 — RNase A-like
Family Family familyd.5.1.1 — Ribonuclease A-like

CATH v4.4 (2 domains)

Domain ID domain_id1r5dA00
Class class3 — Alpha Beta
Architecture architecture10 — Roll
Topology topology130 — P-30 Protein
Homologous superfamily homologous superfamily10 — Ribonuclease A-like domain
Domain ID domain_id1r5dB00
Class class3 — Alpha Beta
Architecture architecture10 — Roll
Topology topology130 — P-30 Protein
Homologous superfamily homologous superfamily10 — Ribonuclease A-like domain
▶

7. Citations (6)
