Fibrinogen alpha/alpha-E chain
Homo sapiens
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Other combination Heteromer Protein × 5 其他Polymer 1 PDB declaration: pentameric（5） Consistent with protein copy count | Chain A； UniProt 145–210 | Fragment：Fibrinogen alpha/alpha-E Chain | Fibrinogen beta chain × 1 （P02675） Fibrinogen gamma chain × 1 （P02679） GHRP peptide × 2 2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-[alpha-L-fucopyranose-(1-6)]2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 2 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；9-10% PEG 3350, 12.5 mM calcium chloride, 2 mM sodium azide, 50 mM Tris pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K | Resolution 2.53 Å R-free 0.281 |
| 2 | Other combination Heteromer Protein × 5 其他Polymer 1 PDB declaration: pentameric（5） Consistent with protein copy count | Chain D； UniProt 145–210 | Fragment：Fibrinogen alpha/alpha-E Chain | Fibrinogen beta chain × 1 （P02675） Fibrinogen gamma chain × 1 （P02679） GHRP peptide × 2 2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-[alpha-L-fucopyranose-(1-6)]2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 2 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；9-10% PEG 3350, 12.5 mM calcium chloride, 2 mM sodium azide, 50 mM Tris pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K | Resolution 2.53 Å R-free 0.281 |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 1RF1 | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 1BBR THE STRUCTURE OF RESIDUES 7-16 OF THE A ALPHA CHAIN OF HUMAN FIBRINOGEN BOUND TO BOVINE THROMBIN AT 2.3 ANGSTROMS RESOLUTION Deposited 1992-04-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain F
26–35（10 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1BBR THE STRUCTURE OF RESIDUES 7-16 OF THE A ALPHA CHAIN OF HUMAN FIBRINOGEN BOUND TO BOVINE THROMBIN AT 2.3 ANGSTROMS RESOLUTION Deposited 1992-04-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
26–35（10 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1BBR THE STRUCTURE OF RESIDUES 7-16 OF THE A ALPHA CHAIN OF HUMAN FIBRINOGEN BOUND TO BOVINE THROMBIN AT 2.3 ANGSTROMS RESOLUTION Deposited 1992-04-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain I
26–35（10 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1BBR THE STRUCTURE OF RESIDUES 7-16 OF THE A ALPHA CHAIN OF HUMAN FIBRINOGEN BOUND TO BOVINE THROMBIN AT 2.3 ANGSTROMS RESOLUTION Deposited 1992-04-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain G
26–35（10 aa）
Chain I
26–35（10 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) Non-standard monomer：Yes (specific site not provided by mmCIF) | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å |
| 1FZA CRYSTAL STRUCTURE OF FIBRINOGEN FRAGMENT D Deposited 1997-08-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
130–216（87 aa）
Fragment：FRAGMENT D
Chain D
130–216（87 aa）
Fragment：FRAGMENT D
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 2 CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
SYMMETRY OPERATIONS FOR NON-STANDARD SETTING: X, Y, Z -X, Y+1/2, -Z
|
Resolution 2.90 Å R-free 0.363 |
| 1FZB CRYSTAL STRUCTURE OF CROSSLINKED FRAGMENT D Deposited 1997-08-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 8 PDB declaration: octameric |
Chain A
130–216（87 aa）
Fragment：DOUBLE FRAGMENT D
Chain D
130–216（87 aa）
Fragment：DOUBLE FRAGMENT D
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 2 CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7；13-14% PEG 3350, 50 MM TRIS PH 7.0, 10 MM CALCIUM CHLORIDE 1MM SODIUM AZIDE 5MM GLY-PRO-ARG-PRO-AMIDE
|
Resolution 2.90 Å R-free 0.318 |
| 1FZC CRYSTAL STRUCTURE OF FRAGMENT DOUBLE-D FROM HUMAN FIBRIN WITH TWO DIFFERENT BOUND LIGANDS Deposited 1998-05-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 10 PDB declaration: decameric |
Chain A
130–216（87 aa）
Fragment：DOUBLE-D
Chain D
130–216（87 aa）
Fragment：DOUBLE-D
|
Not recorded | MAN alpha-D-mannopyranose × 1 CA CALCIUM ION × 4 NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7；12% PEG 3350, 50 MM TRIS PH 7.0, 5 MM CALCIUM CHLORIDE, 1MM SODIUM AZIDE, 5MM GLY-PRO-ARG-PRO-AMIDE, 5MM GLY-HIS-ARG-PRO-AMIDE
|
Resolution 2.30 Å R-free 0.290 |
| 1FZD STRUCTURE OF RECOMBINANT ALPHAEC DOMAIN FROM HUMAN FIBRINOGEN-420 Deposited 1998-06-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain A
666–866（201 aa）
Fragment：ALPHA-EC DOMAIN
Chain B
666–866（201 aa）
Fragment：ALPHA-EC DOMAIN
Chain C
666–866（201 aa）
Fragment：ALPHA-EC DOMAIN
Chain D
666–866（201 aa）
Fragment：ALPHA-EC DOMAIN
|
Not recorded | CA CALCIUM ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；PROTEIN WAS CRYSTALLIZED BY SITTING DROP VAPOUR DIFFUSION FROM 20% PEG 3350, 0.15 M CACL2, 0.1M IMIDAZOLE- ACETATE PH 5.5 0.002 M SODIUM AZIDE, vapor diffusion - sitting drop
|
Resolution 2.10 Å R-free 0.255 |
| 1FZD STRUCTURE OF RECOMBINANT ALPHAEC DOMAIN FROM HUMAN FIBRINOGEN-420 Deposited 1998-06-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain E
666–866（201 aa）
Fragment：ALPHA-EC DOMAIN
Chain F
666–866（201 aa）
Fragment：ALPHA-EC DOMAIN
Chain G
666–866（201 aa）
Fragment：ALPHA-EC DOMAIN
Chain H
666–866（201 aa）
Fragment：ALPHA-EC DOMAIN
|
Not recorded | CA CALCIUM ION × 4 NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；PROTEIN WAS CRYSTALLIZED BY SITTING DROP VAPOUR DIFFUSION FROM 20% PEG 3350, 0.15 M CACL2, 0.1M IMIDAZOLE- ACETATE PH 5.5 0.002 M SODIUM AZIDE, vapor diffusion - sitting drop
|
Resolution 2.10 Å R-free 0.255 |
| 1FZE CRYSTAL STRUCTURE OF FRAGMENT DOUBLE-D FROM HUMAN FIBRIN Deposited 1998-12-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
130–216（87 aa）
Fragment：FRAGMENT D
Chain D
130–216（87 aa）
Fragment：FRAGMENT D
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 4 CA CALCIUM ION × 6 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8；pH 8.0
|
Resolution 3.00 Å R-free 0.318 |
| 1FZE CRYSTAL STRUCTURE OF FRAGMENT DOUBLE-D FROM HUMAN FIBRIN Deposited 1998-12-23 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
130–216（87 aa）
Fragment：FRAGMENT D
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 2 CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8；pH 8.0
|
Resolution 3.00 Å R-free 0.318 |
| 1FZE CRYSTAL STRUCTURE OF FRAGMENT DOUBLE-D FROM HUMAN FIBRIN Deposited 1998-12-23 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
130–216（87 aa）
Fragment：FRAGMENT D
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 2 CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8；pH 8.0
|
Resolution 3.00 Å R-free 0.318 |
| 1FZF CRYSTAL STRUCTURE OF FRAGMENT DOUBLE-D FROM HUMAN FIBRIN WITH THE PEPTIDE LIGAND GLY-HIS-ARG-PRO-AMIDE Deposited 1998-12-28 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric |
Chain A
130–216（87 aa）
Fragment：FRAGMENT DOUBLE-D
Chain D
130–216（87 aa）
Fragment：FRAGMENT DOUBLE-D
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 2 CA CALCIUM ION × 6 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.8；pH 7.8
|
Resolution 2.70 Å R-free 0.302 |
| 1FZG CRYSTAL STRUCTURE OF FRAGMENT D FROM HUMAN FIBRINOGEN WITH THE PEPTIDE LIGAND GLY-HIS-ARG-PRO-AMIDE Deposited 1999-01-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 10 PDB declaration: decameric |
Chain A
130–216（87 aa）
Fragment：FRAGMENT DOUBLE-D
Chain D
130–216（87 aa）
Fragment：FRAGMENT DOUBLE-D
|
Not recorded | CA CALCIUM ION × 8 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.8；pH 7.8
|
Resolution 2.50 Å R-free 0.302 |
| 1LT9 Crystal Structure of Recombinant Human Fibrinogen Fragment D Deposited 2002-05-20 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
145–210（66 aa）
Fragment：Fragment D (residues 126-191)
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；9% PEG 3350, 70mM Calcium Chloride, 2mM Sodium Azide, 50mM Tris pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.80 Å R-free 0.271 |
| 1LT9 Crystal Structure of Recombinant Human Fibrinogen Fragment D Deposited 2002-05-20 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
145–210（66 aa）
Fragment：Fragment D (residues 126-191)
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；9% PEG 3350, 70mM Calcium Chloride, 2mM Sodium Azide, 50mM Tris pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.80 Å R-free 0.271 |
| 1LTJ Crystal Structure of Recombinant Human Fibrinogen Fragment D with the Peptide Ligands Gly-Pro-Arg-Pro-Amide and Gly-His-Arg-Pro-Amide Deposited 2002-05-20 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
145–210（66 aa）
Fragment：Fragment D (residues 126-191)
|
Not recorded | CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；7% PEG 3350, 12.5mM Calcium Chloride, 2mM Sodium Azide, 50mM Tris pH 8.5, 2mM GHRP-amide, 2mM GPRP-amide, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.80 Å R-free 0.270 |
| 1LTJ Crystal Structure of Recombinant Human Fibrinogen Fragment D with the Peptide Ligands Gly-Pro-Arg-Pro-Amide and Gly-His-Arg-Pro-Amide Deposited 2002-05-20 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Heteromer；Protein × 5 PDB declaration: pentameric |
Chain D
145–210（66 aa）
Fragment：Fragment D (residues 126-191)
|
Not recorded | CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；7% PEG 3350, 12.5mM Calcium Chloride, 2mM Sodium Azide, 50mM Tris pH 8.5, 2mM GHRP-amide, 2mM GPRP-amide, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.80 Å R-free 0.270 |
| 1N86 Crystal structure of human D-dimer from cross-linked fibrin complexed with GPR and GHRPLDK peptide ligands. Deposited 2002-11-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric |
Chain A
130–216（87 aa）
Fragment：DOUBLE-D ALPHA CHAIN
Chain D
130–216（87 aa）
Fragment：DOUBLE-D ALPHA CHAIN
Chain G
36–38（3 aa）
Fragment：sequence database residues 36-38
Chain H
36–38（3 aa）
Fragment：sequence database residues 36-38
|
Not recorded | NDG 2-acetamido-2-deoxy-alpha-D-glucopyranose × 4 MAN alpha-D-mannopyranose × 1 CA CALCIUM ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；PEG 3350, Tris buffer. 10 mM CaCl2, pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 3.20 Å R-free 0.289 |
| 1N8E Fragment Double-D from Human Fibrin Deposited 2002-11-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
130–218（89 aa）
Fragment：double-D alpha chain
Chain D
130–218（89 aa）
Fragment：double-D alpha chain
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；PEG-3350, 50 mM Tris, 7.5 mM CaCl2, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 4.50 Å R-free 0.416 |
| 1RE3 Crystal Structure of Fragment D of BbetaD398A Fibrinogen with the Peptide Ligand Gly-His-Arg-Pro-Amide Deposited 2003-11-06 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
145–210（66 aa）
Fragment：Fragment D of fibrinogen alpha chain
|
Not recorded | CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；9% PEG 3350, 12.5 mM calcium chloride, 2 mM sodium azide, 50 mM Tris pH 8.5, , VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.45 Å R-free 0.263 |
| 1RE3 Crystal Structure of Fragment D of BbetaD398A Fibrinogen with the Peptide Ligand Gly-His-Arg-Pro-Amide Deposited 2003-11-06 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain D
145–210（66 aa）
Fragment：Fragment D of fibrinogen alpha chain
|
Not recorded | CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；9% PEG 3350, 12.5 mM calcium chloride, 2 mM sodium azide, 50 mM Tris pH 8.5, , VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.45 Å R-free 0.263 |
| 1RE4 Crystal Structure of Fragment D of BbetaD398A Fibrinogen Deposited 2003-11-06 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
145–210（66 aa）
Fragment：Fragment D of fibrinogen alpha chain
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；14-15% PEG 3350, 70 mM calcium chloride, 2 mM sodium azide, 50 mM Tris pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.70 Å R-free 0.271 |
| 1RE4 Crystal Structure of Fragment D of BbetaD398A Fibrinogen Deposited 2003-11-06 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
145–210（66 aa）
Fragment：Fragment D of fibrinogen alpha chain
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；14-15% PEG 3350, 70 mM calcium chloride, 2 mM sodium azide, 50 mM Tris pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.70 Å R-free 0.271 |
| 1RF0 Crystal Structure of Fragment D of gammaE132A Fibrinogen Deposited 2003-11-07 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
145–210（66 aa）
Fragment：Fibrinogen alpha/alpha-E Chain
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；14-15% PEG 3350, 70 mM calcium chloride, 2 mM sodium azide, 50 mM Tris pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.81 Å R-free 0.286 |
| 1RF0 Crystal Structure of Fragment D of gammaE132A Fibrinogen Deposited 2003-11-07 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
145–210（66 aa）
Fragment：Fibrinogen alpha/alpha-E Chain
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；14-15% PEG 3350, 70 mM calcium chloride, 2 mM sodium azide, 50 mM Tris pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.81 Å R-free 0.286 |
| 1YCP THE CRYSTAL STRUCTURE OF FIBRINOGEN-AA PEPTIDE 1-23 (F8Y) BOUND TO BOVINE THROMBIN EXPLAINS WHY THE MUTATION OF PHE-8 TO TYROSINE STRONGLY INHIBITS NORMAL CLEAVAGE AT ARGININE-16 Deposited 1997-05-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain F
20–42（23 aa）
Fragment：RESIDUES 1 - 23
|
Mutation：F308Y | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；2.0M AMMONIUM SULFATE 0.1M HEPES, PH 7.5 2.0% POLYETHYLENE GLYCOL 400
|
Resolution 2.50 Å R-free 0.245 |
| 1YCP THE CRYSTAL STRUCTURE OF FIBRINOGEN-AA PEPTIDE 1-23 (F8Y) BOUND TO BOVINE THROMBIN EXPLAINS WHY THE MUTATION OF PHE-8 TO TYROSINE STRONGLY INHIBITS NORMAL CLEAVAGE AT ARGININE-16 Deposited 1997-05-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain N
20–42（23 aa）
Fragment：RESIDUES 1 - 23
|
Mutation：F308Y | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；2.0M AMMONIUM SULFATE 0.1M HEPES, PH 7.5 2.0% POLYETHYLENE GLYCOL 400
|
Resolution 2.50 Å R-free 0.245 |
| 2A45 Crystal structure of the complex between thrombin and the central "E" region of fibrin Deposited 2005-06-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric |
Chain G
36–92（57 aa）
Fragment：UNP P02671, residues 36-92
Chain J
36–92（57 aa）
Fragment：UNP P02671, residues 36-92
|
Not recorded | 0G6 D-phenylalanyl-N-[(2S,3S)-6-{[amino(iminio)methyl]amino}-1-chloro-2-hydroxyhexan-3-yl]-L-prolinamide × 2 PO4 PHOSPHATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
MICRODIALYSIS；pH 7.9；298 K；PEG 3500, AMMONIUM PHOSPHATE, TRIS, pH 7.90, MICRODIALYSIS, temperature 298K
|
Resolution 3.65 Å R-free 0.290 |
| 2FFD Fibrinogen Fragment D with "A" knob peptide mimic GPRVVE Deposited 2005-12-19 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
145–210（66 aa）
Fragment：residues 145-210
|
Not recorded | CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；10% PEG3350, 12.5 mM CaCl2, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.89 Å R-free 0.268 |
| 2FFD Fibrinogen Fragment D with "A" knob peptide mimic GPRVVE Deposited 2005-12-19 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Heteromer；Protein × 5 PDB declaration: pentameric |
Chain D
145–210（66 aa）
Fragment：residues 145-210
|
Not recorded | CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；10% PEG3350, 12.5 mM CaCl2, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.89 Å R-free 0.268 |
| 2H43 Crystal Structure of Human Fragment D Complexed with Ala-His-Arg-Pro-amide Deposited 2006-05-23 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
130–216（87 aa）
|
Not recorded | CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；fragment D, 5 mg/mil, 4mM AHRPam, 50mM Tris, pH 7.5, 7.5% PEG, 7.5mM CaCl2, 1mM sodium azide, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.70 Å R-free 0.307 |
| 2H43 Crystal Structure of Human Fragment D Complexed with Ala-His-Arg-Pro-amide Deposited 2006-05-23 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain D
130–216（87 aa）
|
Not recorded | CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；fragment D, 5 mg/mil, 4mM AHRPam, 50mM Tris, pH 7.5, 7.5% PEG, 7.5mM CaCl2, 1mM sodium azide, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.70 Å R-free 0.307 |
| 2HLO Crystal Structure of Fragment D-dimer from Human Fibrin Complexed with Gly-hydroxyPro-Arg-Pro-amide Deposited 2006-07-08 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
130–216（87 aa）
|
Not recorded | CA CALCIUM ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；295 K；10mg/ml fibrinogen, 2mM Gly-hydroxyPro-Arg-Pro-amide, 7.5mM CaCl2, 10% PEG, 50mM Tris, 2mM sodium azide, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.60 Å R-free 0.268 |
| 2HLO Crystal Structure of Fragment D-dimer from Human Fibrin Complexed with Gly-hydroxyPro-Arg-Pro-amide Deposited 2006-07-08 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain D
130–216（87 aa）
|
Not recorded | CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；295 K；10mg/ml fibrinogen, 2mM Gly-hydroxyPro-Arg-Pro-amide, 7.5mM CaCl2, 10% PEG, 50mM Tris, 2mM sodium azide, pH 8.0, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.60 Å R-free 0.268 |
| 2HOD Crystal Structure of Fragment D from Human Fibrinogen Complexed with Gly-hydroxyPro-Arg-Pro-amide Deposited 2006-07-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
130–216（87 aa）
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；equal volumes of 10 mg/ml fragment D, 5 mM Gly-hydroxyPro-Arg-Pro-amide, 50 mM Tris, pH 7.0 and 16% PEG 3350, 50 mM Tris pH 8.0 mM 20 mM CaCl2, 2 mM sodium azide., pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.90 Å R-free 0.347 |
| 2HOD Crystal Structure of Fragment D from Human Fibrinogen Complexed with Gly-hydroxyPro-Arg-Pro-amide Deposited 2006-07-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain D
130–216（87 aa）
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；equal volumes of 10 mg/ml fragment D, 5 mM Gly-hydroxyPro-Arg-Pro-amide, 50 mM Tris, pH 7.0 and 16% PEG 3350, 50 mM Tris pH 8.0 mM 20 mM CaCl2, 2 mM sodium azide., pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.90 Å R-free 0.347 |
| 2HOD Crystal Structure of Fragment D from Human Fibrinogen Complexed with Gly-hydroxyPro-Arg-Pro-amide Deposited 2006-07-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain G
130–216（87 aa）
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；equal volumes of 10 mg/ml fragment D, 5 mM Gly-hydroxyPro-Arg-Pro-amide, 50 mM Tris, pH 7.0 and 16% PEG 3350, 50 mM Tris pH 8.0 mM 20 mM CaCl2, 2 mM sodium azide., pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.90 Å R-free 0.347 |
| 2HOD Crystal Structure of Fragment D from Human Fibrinogen Complexed with Gly-hydroxyPro-Arg-Pro-amide Deposited 2006-07-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain J
130–216（87 aa）
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；equal volumes of 10 mg/ml fragment D, 5 mM Gly-hydroxyPro-Arg-Pro-amide, 50 mM Tris, pH 7.0 and 16% PEG 3350, 50 mM Tris pH 8.0 mM 20 mM CaCl2, 2 mM sodium azide., pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.90 Å R-free 0.347 |
| 2HPC Crystal structure of fragment D from Human Fibrinogen Complexed with Gly-Pro-Arg-Pro-amide. Deposited 2006-07-17 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
130–216（87 aa）
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；equal volumes of 10 mg/ml fragment D, 5 mM Gly-Pro-Arg-Pro-amide, 50 mM Tris, pH 7.0 and 16% PEG 3350, 50 mM Tris pH 8.0, 20 mM CaCl2, 2 mM sodium azide., pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.90 Å R-free 0.360 |
| 2HPC Crystal structure of fragment D from Human Fibrinogen Complexed with Gly-Pro-Arg-Pro-amide. Deposited 2006-07-17 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain D
130–216（87 aa）
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；equal volumes of 10 mg/ml fragment D, 5 mM Gly-Pro-Arg-Pro-amide, 50 mM Tris, pH 7.0 and 16% PEG 3350, 50 mM Tris pH 8.0, 20 mM CaCl2, 2 mM sodium azide., pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.90 Å R-free 0.360 |
| 2HPC Crystal structure of fragment D from Human Fibrinogen Complexed with Gly-Pro-Arg-Pro-amide. Deposited 2006-07-17 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain G
130–216（87 aa）
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；equal volumes of 10 mg/ml fragment D, 5 mM Gly-Pro-Arg-Pro-amide, 50 mM Tris, pH 7.0 and 16% PEG 3350, 50 mM Tris pH 8.0, 20 mM CaCl2, 2 mM sodium azide., pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.90 Å R-free 0.360 |
| 2HPC Crystal structure of fragment D from Human Fibrinogen Complexed with Gly-Pro-Arg-Pro-amide. Deposited 2006-07-17 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain J
130–216（87 aa）
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；equal volumes of 10 mg/ml fragment D, 5 mM Gly-Pro-Arg-Pro-amide, 50 mM Tris, pH 7.0 and 16% PEG 3350, 50 mM Tris pH 8.0, 20 mM CaCl2, 2 mM sodium azide., pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.90 Å R-free 0.360 |
| 2OYH Crystal Structure of Fragment D of gammaD298,301A Fibrinogen with the Peptide Ligand Gly-His-Arg-Pro-Amide Deposited 2007-02-22 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
145–210（66 aa）
Fragment：Residues 145-210
|
Not recorded | CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；5 microL of 10 mg/mL protein in HBS with 3 mM GHRP were mixed with an identical volume of well solution containing 50 mM Tris, pH 8.5, 2 mM NaN3, 12.5 mM CaCl2, and 11% PEG 3350, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.40 Å R-free 0.259 |
| 2OYH Crystal Structure of Fragment D of gammaD298,301A Fibrinogen with the Peptide Ligand Gly-His-Arg-Pro-Amide Deposited 2007-02-22 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Heteromer；Protein × 5 PDB declaration: pentameric |
Chain D
145–210（66 aa）
Fragment：Residues 145-210
|
Not recorded | CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；5 microL of 10 mg/mL protein in HBS with 3 mM GHRP were mixed with an identical volume of well solution containing 50 mM Tris, pH 8.5, 2 mM NaN3, 12.5 mM CaCl2, and 11% PEG 3350, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.40 Å R-free 0.259 |
| 2OYI Crystal Structure of Fragment D of gammaD298,301A Fibrinogen with the Peptide Ligand Gly-Pro-Arg-Pro-Amide Deposited 2007-02-22 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
145–210（66 aa）
Fragment：Residues 126-191
|
Not recorded | CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；5 microL of 10 mg/mL protein in HBS with 3 mM GPRP were mixed with an identical volume of well solution containing 50 mM Tris, pH 8.5, 2 mM NaN3, 12.5 mM CaCl2, and 11% PEG 3350, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.70 Å R-free 0.256 |
| 2OYI Crystal Structure of Fragment D of gammaD298,301A Fibrinogen with the Peptide Ligand Gly-Pro-Arg-Pro-Amide Deposited 2007-02-22 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Heteromer；Protein × 5 PDB declaration: pentameric |
Chain D
145–210（66 aa）
Fragment：Residues 126-191
|
Not recorded | CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；5 microL of 10 mg/mL protein in HBS with 3 mM GPRP were mixed with an identical volume of well solution containing 50 mM Tris, pH 8.5, 2 mM NaN3, 12.5 mM CaCl2, and 11% PEG 3350, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.70 Å R-free 0.256 |
| 2Q9I Crystal Structure of D-Dimer from Human Fibrin Complexed with Met-His-Arg-Pro-Tyr-amide. Deposited 2007-06-12 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
130–216（87 aa）
Fragment：UNP residues 130-216
|
Not recorded | CA CALCIUM ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；equal volumes of (a) 9 mg/ml D-dimer, 2 mM Gly-His-Arg-Pro-amide, 0.05 M Tris, pH 7.0,
5 mM CaCl2 and (b) 10% PEG, 5 mM CaCl2, 0.05M Tris, pH 8.0, 2 mM sodium azide.
Crystals were subsequently soaked in same solution containing 0.6 mM Met-His-Arg-Pro-Tyr-amide., pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 295.0K
|
Resolution 2.80 Å R-free 0.276 |
| 2Q9I Crystal Structure of D-Dimer from Human Fibrin Complexed with Met-His-Arg-Pro-Tyr-amide. Deposited 2007-06-12 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Heteromer；Protein × 5 PDB declaration: pentameric |
Chain D
130–216（87 aa）
Fragment：UNP residues 130-216
|
Not recorded | CA CALCIUM ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；equal volumes of (a) 9 mg/ml D-dimer, 2 mM Gly-His-Arg-Pro-amide, 0.05 M Tris, pH 7.0,
5 mM CaCl2 and (b) 10% PEG, 5 mM CaCl2, 0.05M Tris, pH 8.0, 2 mM sodium azide.
Crystals were subsequently soaked in same solution containing 0.6 mM Met-His-Arg-Pro-Tyr-amide., pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 295.0K
|
Resolution 2.80 Å R-free 0.276 |
| 2XNX BC1 fragment of streptococcal M1 protein in complex with human fibrinogen Deposited 2010-08-06 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 14 PDB declaration: tetradecameric |
Chain A
130–216（87 aa）
Fragment：FRAGMENT D, RESIDUES 130-216
Chain D
130–216（87 aa）
Fragment：FRAGMENT D, RESIDUES 130-216
Chain G
130–216（87 aa）
Fragment：FRAGMENT D, RESIDUES 130-216
Chain J
130–216（87 aa）
Fragment：FRAGMENT D, RESIDUES 130-216
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
16% PEG 3350, 0.2 M SODIUM TARTRATE WITH SEEDS GROWN IN 0.6 M K2/NA2 PO4, 0.12 M (NH4)2SO4, 0.1 M HEPES, PH 7.5
|
Resolution 3.30 Å R-free 0.325 |
| 2XNY A fragment of streptococcal M1 protein in complex with human fibrinogen Deposited 2010-08-06 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
130–216（87 aa）
Fragment：FRAGMENT D, RESIDUES 130-216
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
1.3 M AMMONIUM TARTRATE, 0.1 M MES, PH 6.25.
|
Resolution 7.50 Å R-free 0.408 |
| 2XNY A fragment of streptococcal M1 protein in complex with human fibrinogen Deposited 2010-08-06 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
130–216（87 aa）
Fragment：FRAGMENT D, RESIDUES 130-216
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
1.3 M AMMONIUM TARTRATE, 0.1 M MES, PH 6.25.
|
Resolution 7.50 Å R-free 0.408 |
| 2Z4E Crystal Structure of D-Dimer from Human Fibrin Complexed with Gly-His-Arg-Pro-Tyr-amide Deposited 2007-06-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 10 PDB declaration: decameric |
Chain A
130–216（87 aa）
Fragment：residues in database 130-218
Chain D
130–216（87 aa）
Fragment：residues in database 130-218
|
Not recorded | CA CALCIUM ION × 8 NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；equal volumes of (a) 9 mg/ml D-dimer, 2mM Gly-His-Arg-Pro-amide, 0.05M Tris, pH 7.0, 5mM CaCl2; (b) 10% PEG, 5mM CaCl2, 0.05M Tris, pH 8.0, 2mM sodium azide; The crystal was subsequently soaked in 0.5mM Gly-His-Arg-Pro-Tyr-amide in solution of came constitution., pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 295.0K
|
Resolution 2.70 Å R-free 0.275 |
| 2Z4E Crystal Structure of D-Dimer from Human Fibrin Complexed with Gly-His-Arg-Pro-Tyr-amide Deposited 2007-06-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
130–216（87 aa）
Fragment：residues in database 130-218
|
Not recorded | CA CALCIUM ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；equal volumes of (a) 9 mg/ml D-dimer, 2mM Gly-His-Arg-Pro-amide, 0.05M Tris, pH 7.0, 5mM CaCl2; (b) 10% PEG, 5mM CaCl2, 0.05M Tris, pH 8.0, 2mM sodium azide; The crystal was subsequently soaked in 0.5mM Gly-His-Arg-Pro-Tyr-amide in solution of came constitution., pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 295.0K
|
Resolution 2.70 Å R-free 0.275 |
| 2Z4E Crystal Structure of D-Dimer from Human Fibrin Complexed with Gly-His-Arg-Pro-Tyr-amide Deposited 2007-06-16 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain D
130–216（87 aa）
Fragment：residues in database 130-218
|
Not recorded | CA CALCIUM ION × 4 NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；equal volumes of (a) 9 mg/ml D-dimer, 2mM Gly-His-Arg-Pro-amide, 0.05M Tris, pH 7.0, 5mM CaCl2; (b) 10% PEG, 5mM CaCl2, 0.05M Tris, pH 8.0, 2mM sodium azide; The crystal was subsequently soaked in 0.5mM Gly-His-Arg-Pro-Tyr-amide in solution of came constitution., pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 295.0K
|
Resolution 2.70 Å R-free 0.275 |
| 3AT0 Structural and biochemical characterization of ClfB:ligand interactions Deposited 2010-12-23 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
332–347（16 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 8；298 K；0.9M sodium citrate, 90mM imidazole pH 8.0, VAPOR DIFFUSION, temperature 298K
|
Resolution 2.50 Å R-free 0.207 |
| 3BVH Crystal Structure of Recombinant gammaD364A Fibrinogen Fragment D with the Peptide Ligand Gly-Pro-Arg-Pro-Amide Deposited 2008-01-07 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
148–209（62 aa）
Fragment：residues 148-209
|
Not recorded | CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；9 % PEG 3350, 50 mM Tris-HCl pH 8.5, 2 mM sodium azide, 12.5 mM sodium chloride, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.60 Å R-free 0.260 |
| 3BVH Crystal Structure of Recombinant gammaD364A Fibrinogen Fragment D with the Peptide Ligand Gly-Pro-Arg-Pro-Amide Deposited 2008-01-07 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Heteromer；Protein × 5 PDB declaration: pentameric |
Chain D
148–209（62 aa）
Fragment：residues 148-209
|
Not recorded | CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；9 % PEG 3350, 50 mM Tris-HCl pH 8.5, 2 mM sodium azide, 12.5 mM sodium chloride, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.60 Å R-free 0.260 |
| 3E1I Crystal Structure of BbetaD432A Variant Fibrinogen Fragment D with the Peptide Ligand Gly-His-Arg-Pro-amide Deposited 2008-08-04 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
130–216（87 aa）
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；50 mM Tris, 12.5 mM calcium chloride, 12% PEG 3350, 2 mM sodium azide, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.30 Å R-free 0.242 |
| 3E1I Crystal Structure of BbetaD432A Variant Fibrinogen Fragment D with the Peptide Ligand Gly-His-Arg-Pro-amide Deposited 2008-08-04 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain D
130–216（87 aa）
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 CA CALCIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；50 mM Tris, 12.5 mM calcium chloride, 12% PEG 3350, 2 mM sodium azide, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.30 Å R-free 0.242 |
| 3GHG Crystal Structure of Human Fibrinogen Deposited 2009-03-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 10 PDB declaration: decameric |
Chain A
20–581（562 aa）
Fragment：mature chain
Chain D
20–581（562 aa）
Fragment：mature chain
|
Not recorded | CA CALCIUM ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；295 K；2% PEG 3350, 0.2 M TMAO, 75 mM NaCl, 50 mM Tris, 1 mM CaCl2, 1 mM HPRPam, 1 mM GHRPam, 1 mM sodium azide, pH 7.0, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.90 Å R-free 0.309 |
| 3GHG Crystal Structure of Human Fibrinogen Deposited 2009-03-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Heteromer；Protein × 10 PDB declaration: decameric |
Chain G
20–581（562 aa）
Fragment：mature chain
Chain J
20–581（562 aa）
Fragment：mature chain
|
Not recorded | CA CALCIUM ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；295 K；2% PEG 3350, 0.2 M TMAO, 75 mM NaCl, 50 mM Tris, 1 mM CaCl2, 1 mM HPRPam, 1 mM GHRPam, 1 mM sodium azide, pH 7.0, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.90 Å R-free 0.309 |
| 3H32 Crystal structure of D-dimer from human fibrin complexed with Gly-His-Arg-Pro-Tyr-amide Deposited 2009-04-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 8 PDB declaration: octameric |
Chain A
20–216（197 aa）
Fragment：UNP residues 20-216
Chain D
20–216（197 aa）
Fragment：UNP residues 20-216
|
Not recorded | CA CALCIUM ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；295 K；Equal volumes of (a) 5 mg/mL D-dimer, 0.5 mM GHRPYam, 0.3 mM GPRPam, 0.05 M Tris-HCl pH 8.0 and (b) 1% PEG 3350, 1 mM Iodoacetamide, 1 mM CaCl2, 2mM Sodium azide, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 3.60 Å R-free 0.320 |
| 3HUS Crystal structure of recombinant gamma N308K fibrinogen fragment D with the peptide ligand Gly-Pro-Arg-Pro-amide Deposited 2009-06-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
145–210（66 aa）
Fragment：Fragment D: UNP residues 145-210
|
Not recorded | CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；9% PEG 3350, 50 mM Tris-HCl pH 8.5, 2 mM Sodium azide, 12.5 mM Calcium chloride, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 3.04 Å R-free 0.288 |
| 3HUS Crystal structure of recombinant gamma N308K fibrinogen fragment D with the peptide ligand Gly-Pro-Arg-Pro-amide Deposited 2009-06-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Heteromer；Protein × 5 PDB declaration: pentameric |
Chain D
145–210（66 aa）
Fragment：Fragment D: UNP residues 145-210
|
Not recorded | CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277 K；9% PEG 3350, 50 mM Tris-HCl pH 8.5, 2 mM Sodium azide, 12.5 mM Calcium chloride, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 3.04 Å R-free 0.288 |
| 4F27 Crystal structures reveal the multi-ligand binding mechanism of the Staphylococcus aureus ClfB Deposited 2012-05-07 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain Q
336–347（12 aa）
|
Not recorded | MG MAGNESIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；291 K；0.1M sodium citrate tribasic dehydrate, 20% 2-propanol, 20% PEG 4000, pH 5.6, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.92 Å R-free 0.226 |
| 5CFA Crystal structures of Bbp from Staphylococcus aureus with peptide ligand Deposited 2015-07-08 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
580–594（15 aa）
|
Not recorded | MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291.15 K；peptide was added into the concentrated protein samples at 10:1 ratio and the protein-peptide complex crystals are grown in 0.2 M lithium sulfate, 0.1M Tris-HCl pH8.2, 30% PEG4000
protein concentration was 30mg/ml
|
Resolution 1.45 Å R-free 0.212 |
| 5CFA Crystal structures of Bbp from Staphylococcus aureus with peptide ligand Deposited 2015-07-08 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain D
580–594（15 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291.15 K；peptide was added into the concentrated protein samples at 10:1 ratio and the protein-peptide complex crystals are grown in 0.2 M lithium sulfate, 0.1M Tris-HCl pH8.2, 30% PEG4000
protein concentration was 30mg/ml
|
Resolution 1.45 Å R-free 0.212 |
36 other PDB entries and 68 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | FIBA_HUMAN |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 1–66； UniProt 145–210 Author chain D； PDBConstruct 1–66； UniProt 145–210 |
