1srs

SERUM RESPONSE FACTOR (SRF) CORE COMPLEXED WITH SPECIFIC SRE DNA

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

PROTEIN (SERUM RESPONSE FACTOR (SRF))

Homo sapiens

UniProt P11831

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein–DNA Homooligomer Protein 2 DNA 2 ;DNA (5'-D(*CP*CP*(5IU)P*TP*CP*CP*TP*AP*AP*TP*TP*AP*GP*GP*CP*CP*AP*TP*G)-3') ; × 1 ;DNA (5'-D(*CP*CP*AP*TP*GP*GP*CP*CP*TP*AP*AP*TP*TP*AP*GP*GP*A P*AP*G)-3') ; × 1 Consistent with all polymers

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
1hbx 1hbx 1k6o 1srs

4 assemblies

View Construct and Data Evidence
UniProt name SRF_HUMAN
Isoform —
PDB entities 3
Chains and sequence ranges Author chain A； PDBConstruct 1–92； UniProt 87–178 Author chain B； PDBConstruct 1–92； UniProt 87–178

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id1srs
Deposition date deposition_date1995-07-28
Structure title titleSERUM RESPONSE FACTOR (SRF) CORE COMPLEXED WITH SPECIFIC SRE DNA
Keywords keywordsTRANSCRIPTION REGULATION, MADS-DOMAIN, COMPLEX (DNA BINDING PROTEIN-DNA), TRANSCRIPTION-DNA COMPLEX; TRANSCRIPTION/DNA
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1srs__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1srs__assembly_1__model_1 | I(q)

10-2 10-1 105 106 107 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

1srs__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）20.44 Å
Rg (electron density)19.35 Å
Total Rg20.15 Å
Atom count2074
Residues201
Excluded volume35023 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 1srs__assembly_1__model_1 tetrameric （4） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (3)

▼

6. Fold Classification (SCOP + CATH) 4 domains

SCOP 2.08 (2 domains)

Domain ID domain_idd1srsa_
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.88 — SRF-like
Superfamily Superfamily superfamilyd.88.1 — SRF-like
Family Family familyd.88.1.1 — SRF-like
Domain ID domain_idd1srsb_
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.88 — SRF-like
Superfamily Superfamily superfamilyd.88.1 — SRF-like
Family Family familyd.88.1.1 — SRF-like

CATH v4.4 (2 domains)

Domain ID domain_id1srsA01
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology1810 — SRF-like
Homologous superfamily homologous superfamily10 — Transcription factor, MADS-box
Domain ID domain_id1srsB01
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology1810 — SRF-like
Homologous superfamily homologous superfamily10 — Transcription factor, MADS-box
▶

7. Citations (1)
