Coagulation factor XI
Homo sapiens
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein heterocomplex Heteromer Protein × 4 PDB declaration: tetrameric（4） Consistent with protein copy count | Chain A； UniProt 388–625 Chain B； UniProt 388–625 | Fragment：Catalytic Domain Mutation：S75A, T115A | Ecotin × 2 （P23827） | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, HANGING DROP；pH 6.3；293 K；PEG-MME 2000, Ammonium Sulfate, Sodium Cacodylate, pH 6.3, VAPOR DIFFUSION, HANGING DROP, temperature 293K | Resolution 2.91 Å R-free 0.282 |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 1XXD | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 1XX9 Crystal Structure of the FXIa Catalytic Domain in Complex with EcotinM84R Deposited 2004-11-04 | Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
388–625（238 aa）
Fragment：Catalytic Domain
Chain B
388–625（238 aa）
Fragment：Catalytic Domain
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.2；293 K；PEG 1000, NaCl, Na/K phosphate, pH 6.2, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.20 Å R-free 0.285 |
| 1XXF Crystal Structure of the FXIa Catalytic Domain in Complex with Ecotin Mutant (EcotinP) Deposited 2004-11-04 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
388–625（238 aa）
Fragment：Catalytic Domain
Chain B
388–625（238 aa）
Fragment：Catalytic Domain
|
Mutation：S75A, T115A Mutation：S75A, T115A | NA SODIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.2；293 K；PEG-MME 2000, Ammonium Sulfate, Sodium Cacodylate, methanol, pH 6.2, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.60 Å R-free 0.284 |
| 1ZHM Crystal Structure of the Catalytic Domain of the Coagulation Factor XIa in Complex with Benzamidine (S434A-T475A-K437 Mutant) Deposited 2005-04-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：catalytic domain
|
Mutation：S434A, T475A, K437A | BEN BENZAMIDINE × 1 GSH Glutathione × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；283 K；Ammonium Sulfate, Tris-HCl, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.96 Å R-free 0.191 |
| 1ZHP Crystal Structure of the Catalytic Domain of Coagulation Factor XI in Complex with Benzamidine (S434A-T475A-K505 Mutant) Deposited 2005-04-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：catalytic domain
|
Mutation：S434A, T475A, K505A | BEN BENZAMIDINE × 1 GSH Glutathione × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；283 K；Ammonium Sulfate, Tris-HCl, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 2.70 Å R-free 0.257 |
| 1ZHR Crystal Structure of the Catalytic Domain of Coagulation Factor XI in Complex with Benzamidine (S434A-T475A-C482S-K437A Mutant) Deposited 2005-04-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：catalytic domain
|
Mutation：S434A, T475A, C482S, K437A | BEN BENZAMIDINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；283 K；Ammonium Sulfate, Tris-HCl, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.73 Å R-free 0.202 |
| 1ZJD Crystal Structure of the Catalytic Domain of Coagulation Factor XI in Complex with Kunitz Protease Inhibitor Domain of Protease Nexin II Deposited 2005-04-28 | Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
388–624（237 aa）
Fragment：Catalytic Domain
|
Mutation：S434A, T475A, C482S | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；283 K；Sodium Formate, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 2.60 Å R-free 0.255 |
| 1ZLR Factor XI catalytic domain complexed with 2-guanidino-1-(4-(4,4,5,5-tetramethyl-1,3,2-dioxaborolan-2-yl)phenyl)ethyl nicotinate Deposited 2005-05-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–624（237 aa）
Fragment：catalytic domain
|
Mutation：S434A,T475A,C482S,K437A | SO4 SULFATE ION × 3 368 (1R)-2-{[AMINO(IMINO)METHYL]AMINO}-1-{4-[(4R)-4-(HYDROXYMETHYL)-1,3,2-DIOXABOROLAN-2-YL]PHENYL}ETHYL NICOTINATE × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；283 K；2 M ammonium sulfate, 0.1 M tris, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 2.50 Å R-free 0.224 |
| 1ZMJ Crystal Structure of the Catalytic Domain of Factor XI in complex with 4-(guanidinomethyl)-phenylboronic acid Deposited 2005-05-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：Catalytic Domain
|
Mutation：S452A, T493A, K455A, C500S | SO4 SULFATE ION × 2 HDB (R)-1-(4-(4-(HYDROXYMETHYL)-1,3,2-DIOXABOROLAN-2-YL)BENZYL)GUANIDINE × 1 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；283 K；Ammonium Sulfate, Tris-HCl, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 2.00 Å R-free 0.223 |
| 1ZML Crystal Structure of the Catalytic Domain of Factor XI in complex with (R)-1-(4-(4-(hydroxymethyl)-1,3,2-dioxaborolan-2-yl)phenethyl)guanidine Deposited 2005-05-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：Catalytic Domain
|
Mutation：S452A, T493A, K455A, C500S | SO4 SULFATE ION × 6 BCT BICARBONATE ION × 1 412 (R)-1-(4-(4-(HYDROXYMETHYL)-1,3,2-DIOXABOROLAN-2-YL)PHENETHYL)GUANIDINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；283 K；Ammonium Sulfate, Tris-HCl, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 2.25 Å R-free 0.229 |
| 1ZMN Crystal Structure of the Catalytic Domain of Coagulation Factor XI in Complex with (R)-1-(4-(4-(hydroxymethyl)-1,3,2-dioxaborolan-2-yl)phenyl)guanidine Deposited 2005-05-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：Catalytic Domain
|
Mutation：S452A, T493A, K455A, C500S | SO4 SULFATE ION × 3 427 (R)-1-(4-(4-(HYDROXYMETHYL)-1,3,2-DIOXABOROLAN-2-YL)PHENYL)GUANIDINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；283 K；Ammonium Sulfate, Tris-HCl, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 2.05 Å R-free 0.221 |
| 1ZOM Crystal Structure of the Catalytic Domain of Coagulation Factor XI in complex with a peptidomimetic Inhibitor Deposited 2005-05-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：Catalytic Domain
|
Mutation：S452A, T493A, K455A, C500S | SO4 SULFATE ION × 1 339 (S)-2-(3-((R)-1-(4-BROMOPHENYL)ETHYL)UREIDO)-N-((S)-1-((S)-5-GUANIDINO-1-OXO-1-(THIAZOL-2-YL)PENTAN-2-YLAMINO)-3-METHYL-1-OXOBUTAN-2-YL)-5-UREIDOPENTANAMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；283 K；Ammonium Sulfate, Tris-HCl, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 2.25 Å R-free 0.226 |
| 1ZPB Crystal Structure of the Catalytic Domain of Coagulation Factor XI in Complex with 4-Methyl-pentanoic acid {1-[4-guanidino-1-(thiazole-2-carbonyl)-butylcarbamoyl]-2-methyl-propyl}-amide Deposited 2005-05-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：Catalytic Domain
|
Mutation：S452A, T493A, K455A, C500S | SO4 SULFATE ION × 1 995 4-METHYL-PENTANOIC ACID {1-[4-GUANIDINO-1-(THIAZOLE-2-CARBONYL)-BUTYLCARBAMOYL]-2-METHYL-PROPYL}-AMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；283 K；Ammonium Sulfate, Tris-HCl, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 2.10 Å R-free 0.216 |
| 1ZPC Crystal Structure of the Catalytic Domain of Coagulation Factor XI in Complex with 2-[2-(3-Chloro-phenyl)-2-hydroxy-acetylamino]-N-[4-guanidino-1-(thiazole-2-carbonyl)-butyl]-3-methyl-butyramide Deposited 2005-05-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：Catalytic Domain
|
Mutation：S452A, T493A, K455A, C500S | SO4 SULFATE ION × 3 716 2-[2-(3-CHLORO-PHENYL)-2-HYDROXY-ACETYLAMINO]-N-[4-GUANIDINO-1-(THIAZOLE-2-CARBONYL)-BUTYL]-3-METHYL-BUTYRAMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；283 K；Ammonium Sulfate, Tris-HCl, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 2.60 Å R-free 0.229 |
| 1ZPZ Factor XI catalytic domain complexed with N-((R)-1-(4-bromophenyl)ethyl)urea-Asn-Val-Arg-alpha-ketothiazole Deposited 2005-05-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：catalytic domain
|
Mutation：K78A,C123S | SO4 SULFATE ION × 1 BUK N~2~-({[(1R)-1-(4-BROMOPHENYL)ETHYL]AMINO}CARBONYL)ASPARAGINYL-N~1~-{4-{[AMINO(IMINO)METHYL]AMINO}-1-[2,3-DIHYDRO-1,3-THIAZOL-2-YL(HYDROXY)METHYL]BUTYL}VALINAMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 8.5；283 K；2 M ammonium sulfate, 0.1 M tris, pH 8.5, VAPOR DIFFUSION, temperature 283K
|
Resolution 2.50 Å R-free 0.272 |
| 1ZRK Factor XI complexed with 3-hydroxypropyl 3-(7-amidinonaphthalene-1-carboxamido)benzenesulfonate Deposited 2005-05-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：catalytic domain
|
Mutation：S434A,T475A,C482S,K437A | SO4 SULFATE ION × 3 367 3-HYDROXYPROPYL 3-[({7-[AMINO(IMINO)METHYL]-1-NAPHTHYL}AMINO)CARBONYL]BENZENESULFONATE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 8.5；283 K；2 M ammonium sulfate, 0.1 M tris, pH 8.5, VAPOR DIFFUSION, temperature 283K
|
Resolution 2.30 Å R-free 0.235 |
| 1ZSJ Crystal Structure of the Catalytic Domain of Coagulation Factor XI in complex with N-(7-Carbamimidoyl-naphthalen-1-yl)-3-hydroxy-2-methyl-benzamide Deposited 2005-05-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：Coagulation factor XIa light chain, Catalytic Domain
|
Mutation：S452A, T493A, K455A, C500S | SO4 SULFATE ION × 1 BCT BICARBONATE ION × 1 709 N-(7-CARBAMIMIDOYL-NAPHTHALEN-1-YL)-3-HYDROXY-2-METHYL-BENZAMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；283 K；ammonium sulfate, Tris-HCl, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.90 Å R-free 0.207 |
| 1ZSK Crystal Structure of the Catalytic Domain of Coagulation Factor XI in Complex with 6-Carbamimidoyl-4-(3-hydroxy-2-methyl-benzoylamino)-naphthalene-2-carboxylic acid methyl ester Deposited 2005-05-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：Coagulation factor XIa light chain, Catalytic Domain
|
Mutation：S452A, T493A, K455A, C500S | SO4 SULFATE ION × 2 BCT BICARBONATE ION × 1 421 6-CARBAMIMIDOYL-4-(3-HYDROXY-2-METHYL-BENZOYLAMINO)-NAPHTHALENE-2-CARBOXYLIC ACID METHYL ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；283 K；ammonium sulfate, Tris-HCl, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.90 Å R-free 0.217 |
| 1ZSL Factor XI complexed with a pyrimidinone inhibitor Deposited 2005-05-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：Coagulation Factor XIa Light Chain
|
Mutation：K455A/C500S | 624 2-(2-(3,4-DICHLOROPHENYL)-5-(ISOPROPYLAMINO)-6-OXOPYRIMIDIN-1(6H)-YL)-N-((S)-1-OXO-1-(THIAZOL-2-YL)-5-GUANIDINOPENTAN-2-YL)ACETAMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.6；283 K；20% PEGMME 5000, 0.2 M ammonium sulfate, 0.1 M tris, pH 7.6, VAPOR DIFFUSION, temperature 283K
|
Resolution 2.05 Å R-free 0.254 |
| 1ZTJ Crystal Structure of the Catalytic Domain of Coagulation Factor XI in Complex with 2-(5-Benzylamino-2-methylsulfanyl-6-oxo-6H-pyrimidin-1-yl)-N-[4-guanidino-1-(thiazole-2-carbonyl)-butyl]-acetamide Deposited 2005-05-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：Catalytic Domain
|
Mutation：S452A, T493A, K455A, C500S | SO4 SULFATE ION × 2 BCT BICARBONATE ION × 1 632 2-(5-BENZYLAMINO-2-METHYLSULFANYL-6-OXO-6H-PYRIMIDIN-1-YL)-N-[4-GUANIDINO-1-(THIAZOLE-2-CARBONYL)-BUTYL]-ACETAMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；283 K；ammonium sulfate, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 2.05 Å R-free 0.220 |
| 1ZTK Crystal Structure of the Catalytic Domain of Coagulation Factor XI in Complex with 2-(5-Amino-6-oxo-2-m-tolyl-6H-pyrimidin-1-yl)-N-[4-guanidino-1-(thiazole-2-carbonyl)-butyl]-acetamide Deposited 2005-05-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：Catalytic Domain
|
Mutation：S452A, T493A, K455A, C500S | SO4 SULFATE ION × 2 62A 2-(5-AMINO-6-OXO-2-M-TOLYL-6H-PYRIMIDIN-1-YL)-N-[4-GUANIDINO-1-(THIAZOLE-2-CARBONYL)-BUTYL]-ACETAMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；283 K；ammonium sulfate, Tris-HCl, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 2.50 Å R-free 0.240 |
| 1ZTL Crystal Structure of the Catalytic Domain of Coagulation Factor XI in Complex with N-[4-Guanidino-1-(thiazole-2-carbonyl)-butyl]-2-{6-oxo-5-[(quinolin-8-ylmethyl)-amino]-2-m-tolyl-6H-pyrimidin-1-yl}-acetamide Deposited 2005-05-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：Catalytic Domain
|
Mutation：S452A, T493A, K455A, C500S | SO4 SULFATE ION × 2 737 N-[4-GUANIDINO-1-(THIAZOLE-2-CARBONYL)-BUTYL]-2-{6-OXO-5-[(QUINOLIN-8-YLMETHYL)-AMINO]-2-M-TOLYL-6H-PYRIMIDIN-1-YL}-ACETAMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；283 K；ammonium sulfate, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 2.60 Å R-free 0.237 |
| 2FDA Crystal Structure of the Catalytic Domain of Human Coagulation Factor XIa in Complex with alpha-Ketothiazole Arginine Derived Ligand Deposited 2005-12-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：light chain, catalytic domain, residues 388-625
|
Mutation：S75A, K78A, T115A, C123S | BCT BICARBONATE ION × 2 SO4 SULFATE ION × 1 682 N~2~-(AMINOCARBONYL)-N~1~-{4-{[AMINO(IMINO)METHYL]AMINO}-1-[HYDROXY(1,3-THIAZOL-2-YL)METHYL]BUTYL}VALINAMIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；283 K；2.0 M AMMONIUM SULFATE, 0.1 M TRIS-HCL, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 2.00 Å R-free 0.213 |
| 2J8J Solution Structure of the A4 Domain of Blood Coagulation Factor XI Deposited 2006-10-25 | Different construct Different mutation/modification Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
290–379（90 aa）
Fragment：APPLE 4 DOMAIN, RESIDUES 290-379
Chain B
290–379（90 aa）
Fragment：APPLE 4 DOMAIN, RESIDUES 290-379
|
Not recorded | No recorded non-water small molecule |
SOLUTION NMR
NMR measurement conditions
pH 6.2；310 K
NMR sample composition
90% WATER/10% D2O
|
Resolution not provided |
| 2J8L FXI Apple 4 domain loop-out conformation Deposited 2006-10-25 | Different construct Different mutation/modification Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
290–379（90 aa）
Fragment：APPLE 4 DOMAIN, RESIDUES 290-379
Chain B
290–379（90 aa）
Fragment：APPLE 4 DOMAIN, RESIDUES 290-379
|
Not recorded | No recorded non-water small molecule |
SOLUTION NMR
NMR measurement conditions
pH 6.2；310 K
NMR sample composition
90% WATER/10% D2O
|
Resolution not provided |
| 3BG8 Crystal structure of Factor XIa in complex with Clavatadine A Deposited 2007-11-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Not recorded | G0R N-(4-carbamimidamidobutyl)ethanamide × 1 BEN BENZAMIDINE × 1 SO4 SULFATE ION × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.4；298 K；20mM Tris pH 7.4, 200mM NaCl, VAPOR DIFFUSION, temperature 298K
|
Resolution 1.60 Å R-free 0.200 |
| 3BG8 Crystal structure of Factor XIa in complex with Clavatadine A Deposited 2007-11-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 3 PDB declaration: trimeric |
Chain A
388–625（238 aa）
|
Not recorded | G0R N-(4-carbamimidamidobutyl)ethanamide × 3 BEN BENZAMIDINE × 3 SO4 SULFATE ION × 15 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.4；298 K；20mM Tris pH 7.4, 200mM NaCl, VAPOR DIFFUSION, temperature 298K
|
Resolution 1.60 Å R-free 0.200 |
| 3SOR Factor XIa in complex with a clorophenyl-tetrazole inhibitor Deposited 2011-06-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：C500S | CIT CITRIC ACID × 1 O58 {4-[(N-{3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]propanoyl}-L-phenylalanyl)amino]phenyl}acetic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；Co-crystallization by adding seeds to the crystal drops using a Hampton seed hair. Incubation @ 20 C. crystal. solution: 0.1 M citrate pH 4.5-5.25, 22-24 % PEG4000. cryoprotectant: 75 % mother liquor + 25 % Glycerol, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.80 Å R-free 0.296 |
| 3SOS Benzothiazinone inhibitor in complex with FXIa Deposited 2011-06-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：C500S | CIT CITRIC ACID × 1 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 O61 N-[(2S)-1-({2-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]ethyl}amino)-1-oxo-3-phenylpropan-2-yl]-3-oxo-3,4-dihydro-2H-1,4-benzothiazine-7-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
293 K；Co-crystallization by adding seeds to the crystal drops using a Hampton seed hair. crystal. solutin: 0.1 M citrate pH 4.5 - 5.25, 22 - 24 % PEG4000. cryoprotectant: 75 % mother liquor + 25 % Glycerol, temperature 293K
|
Resolution 2.58 Å R-free 0.278 |
| 4CR5 Creating novel F1 inhibitors through fragment based lead generation and structure aided drug design Deposited 2014-02-25 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
388–625（238 aa）
Fragment：CATALYTIC DOMAIN, RESIDUES 388-625
|
Mutation：YES | 0TU 6-chloroquinolin-2(1H)-one × 2 SO4 SULFATE ION × 14 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；2M AMMONIUM SULFATE 0.1M TRIS-CL PH 8.5 0.2M NACL
|
Resolution 2.00 Å R-free 0.247 |
| 4CR9 Creating novel F1 inhibitors through fragment based lead generation and structure aided drug design Deposited 2014-02-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
388–625（238 aa）
Fragment：CATALYTIC DOMAIN, RESIDUES 388-625
|
Mutation：YES | OTW 4-methylquinoline-2,6-diamine × 2 SO4 SULFATE ION × 12 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；2M AMMONIUM SULFATE 0.1M TRIS-CL PH 8.5 0.2M NACL
|
Resolution 1.70 Å R-free 0.208 |
| 4CRA Creating novel F1 inhibitors through fragment based lead generation and structure aided drug design Deposited 2014-02-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：CATALYTIC DOMAIN, RESIDUES 388-625
|
Mutation：YES | GOL GLYCEROL × 2 XJ8 N-[(1S)-2-[(2-amino-5-quinolyl)methylamino]-1-benzyl-2-oxo-ethyl]-4-hydroxy-2-oxo-1H-quinoline-6-carboxamide × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；2M AMMONIUM SULFATE, 0.1M TRIS-CL PH 8.5, 0.2M NACL
|
Resolution 1.80 Å R-free 0.209 |
| 4CRA Creating novel F1 inhibitors through fragment based lead generation and structure aided drug design Deposited 2014-02-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 3 PDB declaration: trimeric |
Chain A
388–625（238 aa）
Fragment：CATALYTIC DOMAIN, RESIDUES 388-625
|
Mutation：YES | GOL GLYCEROL × 6 XJ8 N-[(1S)-2-[(2-amino-5-quinolyl)methylamino]-1-benzyl-2-oxo-ethyl]-4-hydroxy-2-oxo-1H-quinoline-6-carboxamide × 3 SO4 SULFATE ION × 9 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；2M AMMONIUM SULFATE, 0.1M TRIS-CL PH 8.5, 0.2M NACL
|
Resolution 1.80 Å R-free 0.209 |
| 4CRB Creating novel F1 inhibitors through fragment based lead generation and structure aided drug design Deposited 2014-02-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：CATALYTIC DOMAIN, RESIDUES 388-625
|
Mutation：YES | GOL GLYCEROL × 2 7P0 N-[(1S)-1-benzyl-2-[2-[5-chloro-2-(tetrazol-1-yl)phenyl]ethylamino]-2-oxo-ethyl]-4-hydroxy-2-oxo-1H-quinoline-6-carboxamide × 1 SO4 SULFATE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；2M AMMONIUM SULFATE 0.1M TRIS-CL PH 8.5 0.2M NACL
|
Resolution 1.85 Å R-free 0.213 |
| 4CRC Creating novel F1 inhibitors through fragment based lead generation and structure aided drug design Deposited 2014-02-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：CATALYTIC DOMAIN, RESIDUES 388-625
|
Mutation：YES | OTM (2S)-2-[[(E)-3-[5-chloranyl-2-(1,2,3,4-tetrazol-1-yl)phenyl]prop-2-enoyl]amino]-3-phenyl-N-[4-(1H-1,2,3,4-tetrazol-5-yl)phenyl]propanamide × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；2M AMMONIUM SULFATE, 0.1M TRIS-CL PH 8.5, 0.2M NACL
|
Resolution 1.60 Å R-free 0.213 |
| 4CRD Creating novel F1 inhibitors through fragment based lead generation and structure aided drug design Deposited 2014-02-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 3 PDB declaration: trimeric |
Chain A
388–625（238 aa）
Fragment：CATALYTIC DOMAIN, RESIDUES 388-625
|
Mutation：YES | OTJ Methyl N-[4-[5-chloro-2-[[3-[5-chloro-2-(tetrazol-1-yl)phenyl]propanoylamino]methyl]-1H-imidazol-4-yl]phenyl]carbamate × 3 SO4 SULFATE ION × 9 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；2M AMMONIUM SULFATE, 0.1M TRIS-CL PH 8.5, 0.2M NACL
|
Resolution 2.10 Å R-free 0.220 |
| 4CRE Creating novel F1 inhibitors through fragment based lead generation and structure aided drug design Deposited 2014-02-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 3 PDB declaration: trimeric |
Chain A
388–625（238 aa）
Fragment：CATALYTIC DOMAIN, RESIDUES 388-625
|
Mutation：YES | MVN 6-chloro-4-methyl-1H-quinolin-2-one × 3 SO4 SULFATE ION × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；2M AMMONIUM SULFATE, 0.1M TRIS-CL PH 8.5, 0.2M NACL
|
Resolution 1.73 Å R-free 0.197 |
| 4CRF Creating novel F1 inhibitors through fragment based lead generation and structure aided drug design Deposited 2014-02-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：CATALYTIC DOMAIN, RESIDUES 388-625
|
Mutation：YES | GOL GLYCEROL × 3 R9B N-[(1S)-1-benzyl-2-[(6-chloro-2-oxo-1H-quinolin-4-yl)methylamino]-2-oxo-ethyl]-4-hydroxy-2-oxo-1H-quinoline-6-carbo × 1 SO4 SULFATE ION × 4 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；2M AMMONIUM SULFATE, 0.1M TRIS-CL PH 8.5, 0.2M NACL
|
Resolution 2.30 Å R-free 0.244 |
| 4CRG Creating novel F1 inhibitors through fragment based lead generation and structure aided drug design Deposited 2014-02-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 3 PDB declaration: trimeric |
Chain A
388–625（238 aa）
Fragment：CATALYTIC DOMAIN, RESIDUES 388-625
|
Mutation：YES | GOL GLYCEROL × 12 J4X 6-carbamimidoyl-N-phenyl-4-(pyrimidin-2-ylamino)naphthalene-2-carboxamide × 3 SO4 SULFATE ION × 12 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；2M AMMONIUM SULFATE, 0.1M TRIS-CL PH 8.5, 0.2M NACL
|
Resolution 1.25 Å R-free 0.195 |
| 4D76 Human FXIa in complex with small molecule inhibitors. Deposited 2014-11-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：CATALYTIC DOMAIN, RESIDUES 388-625
|
Mutation：YES | GOL GLYCEROL × 3 J1J N-[(2S)-1-({5-[(diaminomethylidene)amino]pentyl}amino)-1-oxo-3-phenylpropan-2-yl]-4-hydroxy-2-oxo-1,2-dihydroquinoline-6-carboxamide × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；2M AMMONIUM SULFATE, 0.1M TRIS-CL PH 8.5, 0.2M NACL
|
Resolution 1.77 Å R-free 0.210 |
| 4D7F Human FXIa in complex with small molecule inhibitors. Deposited 2014-11-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：CATALYTIC DOMAIN, RESIDUES 388-625
|
Mutation：YES | GOL GLYCEROL × 1 IXA N-[(2S)-1-({4-[(diaminomethylidene)amino]butyl}amino)-1-oxo-3-phenylpropan-2-yl]-4-hydroxy-2-oxo-1,2-dihydroquinoline-6-carboxamide × 1 SO4 SULFATE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；2M AMMONIUM SULFATE, 0.1M TRIS-CL PH 8.5, 0.2M NACL
|
Resolution 1.62 Å R-free 0.211 |
| 4D7G Human FXIa in complex with small molecule inhibitors. Deposited 2014-11-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：CATALYTIC DOMAIN, RESIDUES 388-625
|
Mutation：YES | GOL GLYCEROL × 6 E6U N-[(1S)-1-benzyl-2-(3-guanidinopropylamino)-2-oxo-ethyl]-4-hydroxy-2-oxo-1H-quinoline-6-carboxamide × 1 SO4 SULFATE ION × 5 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；2M AMMONIUM SULFATE, 0.1M TRIS-CL PH 8.5, 0.2M NACL
|
Resolution 2.33 Å R-free 0.249 |
| 4NA7 Factor XIA in complex with the inhibitor 3'-[(2S,4R)-6-carbamimidoyl-4-methyl-4-phenyl-1,2,3,4-tetrahydroquinolin-2-yl]-4-carbamoyl-5'-[(3-methylbutanoyl)amino]biphenyl-2-carboxylic acid Deposited 2013-10-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Not recorded | 1T5 3'-[(2S,4R)-6-carbamimidoyl-4-methyl-4-phenyl-1,2,3,4-tetrahydroquinolin-2-yl]-4-carbamoyl-5'-[(3-methylbutanoyl)amino]biphenyl-2-carboxylic acid × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.5；277 K；100 mM Sodium Acetate, pH 4.5, 25%(W/V) PEG 8000, 100 mM ammonium sulfate, vapor diffusion, hanging drop, temperature 277K
|
Resolution 2.80 Å R-free 0.269 |
| 4NA8 Factor XIa in complex with the inhibitor 5-aminocarbonyl-2-[3-[(2s,4r)-6-carbamimidoyl-4-methyl-4-phenyl-2,3-dihydro-1h-quinolin-2-yl]phenyl]benzoic acid Deposited 2013-10-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Not recorded | 1T6 5-aminocarbonyl-2-[3-[(2S,4R)-6-carbamimidoyl-4-methyl-4-phenyl-2,3-dihydro-1H-quinolin-2-yl]phenyl]benzoic acid × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；277 K；100 mM sodium acetate, pH 4.6, 26% (w/v) MEPEG2000, 200 mM ammonium sulfate, vapor diffusion, hanging drop, temperature 277K
|
Resolution 2.30 Å R-free 0.271 |
| 4TY6 Factor XIa in complex with the inhibitor 4-{2-[(1S)-1-({[trans-4-(aminomethyl)cyclohexyl]carbonyl}amino)-2-phenylethyl]-1H-imidazol-4-yl}benzamide Deposited 2014-07-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
388–625（238 aa）
Fragment：Light chain (UNP Residues 388-625)
Chain H
375–387（13 aa）
Fragment：Heavy chain (UNP Residues 357-369)
|
Mutation：T113G, N115G | 39D 4-{2-[(1S)-1-({[trans-4-(aminomethyl)cyclohexyl]carbonyl}amino)-2-phenylethyl]-1H-imidazol-4-yl}benzamide × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 8 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；277 K；100 MM SODIUM ACETATE, PH 4.6, 26%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE
|
Resolution 1.85 Å R-free 0.201 |
| 4TY7 Factor XIa in complex with the inhibitor (2S)-6-amino-N-{(1S)-1-[4-(3-amino-2H-indazol-6-yl)-5-chloro-1H-imidazol-2-yl]-2-phenylethyl}-2-ethylhexanamide Deposited 2014-07-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：Light chain (UNP Residues 388-625)
|
Mutation：N491G,T493G | 39F trans-N-{(1S)-1-[4-(3-amino-2H-indazol-6-yl)-5-chloro-1H-imidazol-2-yl]-2-phenylethyl}-4-(aminomethyl)cyclohexane-1-carboxamide × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 7 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；277 K；100 MM SODIUM ACETATE, PH 4.6, 26%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE
|
Resolution 2.09 Å R-free 0.206 |
| 4WXI FACTOR XIA IN COMPLEX WITH THE INHIBITOR trans-N-{(1S)-1-[4-(3-amino-2H-indazol-6-yl)pyridin-2-yl]-2-phenylethyl}-4-(aminomethyl)cyclohexanecarboxamide Deposited 2014-11-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：unp residues 388-625
|
Mutation：N491G, T493G | 3VM trans-N-{(1S)-1-[4-(3-amino-2H-indazol-6-yl)pyridin-2-yl]-2-phenylethyl}-4-(aminomethyl)cyclohexanecarboxamide × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；277 K；100 MM SODIUM ACETATE, PH 4.6, 26%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE
|
Resolution 2.60 Å R-free 0.226 |
| 4X6M FACTOR XIA IN COMPLEX WITH THE INHIBITOR 1-{(1S)-1-[4-(3-amino-1H-indazol-6-yl)-5-chloro-1H-imidazol-2-yl]-2-phenylethyl}-3-[2-(aminomethyl)-5-chlorobenzyl]urea Deposited 2014-12-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：N113G, T115G | 3Y3 1-{(1S)-1-[4-(3-amino-1H-indazol-6-yl)-5-chloro-1H-imidazol-2-yl]-2-phenylethyl}-3-[2-(aminomethyl)-5-chlorobenzyl]urea × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 9 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；277 K；100 MM SODIUM ACETATE, PH 4.6, 26%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE
|
Resolution 2.40 Å R-free 0.230 |
| 4X6N FACTOR XIA IN COMPLEX WITH THE INHIBITOR 1-{(1S)-1-[4-(3-amino-1H-indazol-6-yl)-5-chloro-1H-imidazol-2-yl]-2-phenylethyl}-3-[5-chloro-2-(1H-tetrazol-1-yl)benzyl]urea Deposited 2014-12-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
388–625（238 aa）
|
Mutation：N113G, T115G | 3Y5 1-{(1S)-1-[4-(3-amino-1H-indazol-6-yl)-5-chloro-1H-imidazol-2-yl]-2-phenylethyl}-3-[5-chloro-2-(1H-tetrazol-1-yl)benzyl]urea × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 11 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；277 K；100 MM SODIUM ACETATE, PH 4.6, 26%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE
|
Resolution 2.10 Å R-free 0.210 |
| 4X6O FACTOR XIA IN COMPLEX WITH THE INHIBITOR methyl (4-{4-chloro-2-[(1S)-1-({3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]propanoyl}amino)-2-phenylethyl]-1H-imidazol-5-yl}phenyl)carbamate Deposited 2014-12-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：N113G, T115G | 3Y4 methyl (4-{4-chloro-2-[(1S)-1-({3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]propanoyl}amino)-2-phenylethyl]-1H-imidazol-5-yl}phenyl)carbamate × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 9 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；277 K；100 MM SODIUM ACETATE, PH 4.6, 26%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE
|
Resolution 2.10 Å R-free 0.228 |
| 4X6P FACTOR XIA (PICHIA PASTORIS; C500S [C122S]) IN COMPLEX WITH THE INHIBITOR (2E)-N-{(1S)-1-[4-(3-amino-1H-indazol-6-yl)-1H-imidazol-2-yl]-2-phenylethyl}-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enamide Deposited 2014-12-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：C500S | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 3YU (2E)-N-{(1S)-1-[4-(3-amino-1H-indazol-6-yl)-1H-imidazol-2-yl]-2-phenylethyl}-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enamide × 1 CIT CITRIC ACID × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；277 K；100 MM SODIUM CITRATE, PH 5.0, 36%(w/v) PEG4000
|
Resolution 1.93 Å R-free 0.197 |
| 4X6P FACTOR XIA (PICHIA PASTORIS; C500S [C122S]) IN COMPLEX WITH THE INHIBITOR (2E)-N-{(1S)-1-[4-(3-amino-1H-indazol-6-yl)-1H-imidazol-2-yl]-2-phenylethyl}-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enamide Deposited 2014-12-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
388–625（238 aa）
|
Mutation：C500S | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 3YU (2E)-N-{(1S)-1-[4-(3-amino-1H-indazol-6-yl)-1H-imidazol-2-yl]-2-phenylethyl}-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enamide × 1 GOL GLYCEROL × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；277 K；100 MM SODIUM CITRATE, PH 5.0, 36%(w/v) PEG4000
|
Resolution 1.93 Å R-free 0.197 |
| 4Y8X Factor XIa in complex with the inhibitor methyl (4-{4-chloro-2-[(1S)-1-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-2-phenylethyl]-1H-imidazol-5-yl}phenyl)carbamate Deposited 2015-02-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：light chain (UNP residues 388-625)
|
Not recorded | 4GR methyl (4-{4-chloro-2-[(1S)-1-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-2-phenylethyl]-1H-imidazol-5-yl}phenyl)carbamate × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 9 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 26% w/v MEPEG2000, 200 mM ammonium sulfate (crystals were grown at pH4.6 and transferred to pH 7 prior to soaking with compound)
|
Resolution 1.90 Å R-free 0.164 |
| 4Y8Y Factor XIa in complex with the inhibitor methyl (4-{4-chloro-2-[(1S)-1-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-3-(morpholin-4-yl)-3-oxopropyl]-1H-imidazol-5-yl}phenyl)carbamate Deposited 2015-02-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：light chain (UNP residues 388-625)
|
Not recorded | 4D5 methyl (4-{4-chloro-2-[(1S)-1-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-3-(morpholin-4-yl)-3-oxopropyl]-1H-imidazol-5-yl}phenyl)carbamate × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 7 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；277 K；100 mM sodium acetate, pH 4.6, 26% w/v MEPEG2000, 200 mM ammonium sulfate
|
Resolution 2.60 Å R-free 0.241 |
| 4Y8Z Factor XIa in complex with the inhibitor (2E)-N-[(1S)-1-[5-chloro-4-(4-hydroxy-2-oxo-1,2-dihydroquinolin-6-yl)-1H-imidazol-2-yl]-3-(4-methylpiperazin-1-yl)-3-oxopropyl]-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enamide Deposited 2015-02-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：light chain (UNP residues 388-625)
|
Not recorded | 4CE (2E)-N-[(1S)-1-[5-chloro-4-(4-hydroxy-2-oxo-1,2-dihydroquinolin-6-yl)-1H-imidazol-2-yl]-3-(4-methylpiperazin-1-yl)-3-oxopropyl]-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enamide × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；277 K；100 mM sodium acetate, pH 4.6, 26% w/v MEPEG2000, 200 mM ammonium sulfate (crystals were grown at pH4.6 and transferred to pH 7 prior to soaking with compound)
|
Resolution 2.20 Å R-free 0.261 |
| 5E2O FACTOR XIA IN COMPLEX WITH THE INHIBITOR 4-[(N-{(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}-L-phenylalanyl)amino]benzoic acid Deposited 2015-10-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：N491G, N493G | 5JM 4-[(N-{(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}-L-phenylalanyl)amino]benzoic acid × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 9 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；277 K；100 MM SODIUM ACETATE, PH 4.6, 26%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE
|
Resolution 2.08 Å R-free 0.214 |
| 5E2P FACTOR XIA IN COMPLEX WITH THE INHIBITOR N-[(1S)-1-benzyl-2-[2-[5-chloro-2-(tetrazol-1-yl)phenyl]ethylamino]-2-oxo-ethyl]-4-hydroxy-2-oxo-1H-quinoline-6-carboxamide Deposited 2015-10-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：N491G, N493G | 7P0 N-[(1S)-1-benzyl-2-[2-[5-chloro-2-(tetrazol-1-yl)phenyl]ethylamino]-2-oxo-ethyl]-4-hydroxy-2-oxo-1H-quinoline-6-carboxamide × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 10 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；277 K；100 MM SODIUM ACETATE, PH 4.6, 26%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE
|
Resolution 2.11 Å R-free 0.259 |
| 5EOD Human Plasma Coagulation FXI with peptide LP2 Deposited 2015-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
20–625（606 aa）
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；293.15 K；0.1M HEPES pH7.5, 20% PEG1500,
|
Resolution 3.10 Å R-free 0.274 |
| 5EOK Human Plasma Coagulation Factor XI in complex with peptide P39 Deposited 2015-11-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
20–625（606 aa）
Fragment：UNP residues 20-265
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；293.15 K；0.1M HEPES pH7.5, 20% PEG1500
|
Resolution 2.80 Å R-free 0.264 |
| 5EXL FACTOR XIA IN COMPLEX WITH THE INHIBITOR 4-(aminomethyl)-~{N}-[(1~{S})-1-[4-(3-oxidanyl-1~{H}-indazol-5-yl)pyridin-2-yl]-2-phenyl-ethyl]cyclohexane-1-carboxamide Deposited 2015-11-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：N113G,T115G | 5SS 4-(aminomethyl)-~{N}-[(1~{S})-1-[4-(3-oxidanyl-1~{H}-indazol-5-yl)pyridin-2-yl]-2-phenyl-ethyl]cyclohexane-1-carboxamide × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 7 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；277 K；100 MM SODIUM ACETATE, PH 4.6, 26%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE
|
Resolution 2.30 Å R-free 0.238 |
| 5EXM FACTOR XIA IN COMPLEX WITH THE INHIBITOR methyl ~{N}-[4-[2-[(1~{S})-1-[[4-(aminomethyl)cyclohexyl]carbonylamino]-2-phenyl-ethyl]pyridin-4-yl]phenyl]carbamate Deposited 2015-11-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：COAGULATION FACTOR XI, HEAVY CHAIN
|
Mutation：N113G,T115G | 5ST methyl ~{N}-[4-[2-[(1~{S})-1-[[4-(aminomethyl)cyclohexyl]carbonylamino]-2-phenyl-ethyl]pyridin-4-yl]phenyl]carbamate × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；277 K；100 MM SODIUM ACETATE, PH 4.6, 26%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE
|
Resolution 2.09 Å R-free 0.226 |
| 5EXN FACTOR XIA (C500S [C122S]) IN COMPLEX WITH THE INHIBITOR methyl ~{N}-[4-[2-[(1~{S})-1-[[(~{E})-3-[5-chloranyl-2-(1,2,3,4-tetrazol-1-yl)phenyl]prop-2-enoyl]amino]-2-phenyl-ethyl]pyridin-4-yl]phenyl]carbamate Deposited 2015-11-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：C122S | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 5SU methyl ~{N}-[4-[2-[(1~{S})-1-[[(~{E})-3-[5-chloranyl-2-(1,2,3,4-tetrazol-1-yl)phenyl]prop-2-enoyl]amino]-2-phenyl-ethyl]pyridin-4-yl]phenyl]carbamate × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；100 MM SODIUM CITRATE, PH 5.0, 36%(w/v) PEG4000
|
Resolution 1.49 Å R-free 0.195 |
| 5I25 human recombinant coagulation FXI in complex with a peptide derived from human high molecular weight kininogen (HKP) Deposited 2016-02-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
19–625（607 aa）
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.4；293.15 K；PEG1500, HEPES pH 7.4., 0.2M NaCl
|
Resolution 2.85 Å R-free 0.288 |
| 5Q0D FACTOR XIA IN COMPLEX WITH THE INHIBITOR methyl [(7S)-7-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-2-oxo-1,2,3,4,5,6,7,9-octahydro-11,8-(azeno)-1,9-benzodiazacyclotridecin-14-yl]carbamate Deposited 2017-05-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：HEAVY CHAIN (UNP residues 388-625)
|
Not recorded | 9EY methyl [(7S)-7-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-2-oxo-1,2,3,4,5,6,7,9-octahydro-11,8-(azeno)-1,9-benzodiazacyclotridecin-14-yl]carbamate × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 13 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 2.12 Å R-free 0.192 |
| 5Q0E FACTOR XIA IN COMPLEX WITH THE INHIBITOR methyl [(4S,8S)-8-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-4-methyl-2-oxo-1,3,4,5,6,7,8,10-octahydro-2H-12,9-(azeno)-1,10-benzodiazacyclotetradecin-15-yl]carbamate Deposited 2017-05-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：HEAVY CHAIN (UNP residues 388-625)
|
Not recorded | 9FD methyl [(4S,8S)-8-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-4-methyl-2-oxo-1,3,4,5,6,7,8,10-octahydro-2H-12,9-(azeno)-1,10-benzodiazacyclotetradecin-15-yl]carbamate × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 15 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 2.12 Å R-free 0.196 |
| 5Q0F FACTOR XIA IN COMPLEX WITH THE INHIBITOR methyl [(4R,5E,8S)-8-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-4-methyl-2-oxo-1,3,4,7,8,10-hexahydro-2H-12,9-(azeno)-1,10-benzodiazacyclotetradecin-15-yl]carbamate Deposited 2017-05-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
388–625（238 aa）
Fragment：HEAVY CHAIN (UNP residues 388-625)
|
Not recorded | 9FA methyl [(4R,5E,8S)-8-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-4-methyl-2-oxo-1,3,4,7,8,10-hexahydro-2H-12,9-(azeno)-1,10-benzodiazacyclotetradecin-15-yl]carbamate × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 12 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 2.12 Å R-free 0.197 |
| 5Q0G FACTOR XIA IN COMPLEX WITH THE INHIBITOR methyl [(3R,7S)-7-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-3-ethyl-2-oxo-1,2,3,4,5,6,7,9-octahydro-11,8-(azeno)-1,9-benzodiazacyclotridecin-14-yl]carbamate Deposited 2017-05-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：HEAVY CHAIN (UNP residues 388-625)
|
Not recorded | 9F7 methyl [(3R,7S)-7-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-3-ethyl-2-oxo-1,2,3,4,5,6,7,9-octahydro-11,8-(azeno)-1,9-benzodiazacyclotridecin-14-yl]carbamate × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 2.60 Å R-free 0.229 |
| 5Q0H FACTOR XIA IN COMPLEX WITH THE INHIBITOR methyl [(4R,5E,8S)-11-chloro-8-[(2,6-difluoro-4-methylbenzene-1-carbonyl)amino]-4-methyl-2-oxo-1,3,4,7,8,10-hexahydro-2H-12,9-(azeno)-1,10-benzodiazacyclotetradecin-15-yl]carbamate Deposited 2017-05-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：HEAVY CHAIN (UNP residues 388-625)
|
Not recorded | 9F1 methyl [(4R,5E,8S)-11-chloro-8-[(2,6-difluoro-4-methylbenzene-1-carbonyl)amino]-4-methyl-2-oxo-1,3,4,7,8,10-hexahydro-2H-12,9-(azeno)-1,10-benzodiazacyclotetradecin-15-yl]carbamate × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 8 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 2.50 Å R-free 0.210 |
| 5QCK FACTOR XIA IN COMPLEX WITH THE INHIBITOR 4-[[(2~{S},3~{R})-1-[(~{E})-3-[5-chloranyl-2-(1,2,3,4-tetrazol-1-yl)phenyl]prop-2-enoyl]-3-phenyl-pyrrolidin-2-yl]carbonylamino]benzoic acid Deposited 2017-08-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：HEAVY CHAIN (UNP residues 388-625)
|
Not recorded | BUV 4-[[(2~{S},3~{R})-1-[(~{E})-3-[5-chloranyl-2-(1,2,3,4-tetrazol-1-yl)phenyl]prop-2-enoyl]-3-phenyl-pyrrolidin-2-yl]carbonylamino]benzoic acid × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 2.64 Å R-free 0.209 |
| 5QCL FACTOR XIA IN COMPLEX WITH THE INHIBITOR 4-[[(1~{S})-2-[(~{E})-3-[5-chloranyl-2-(1,2,3,4-tetrazol-1-yl)phenyl]prop-2-enoyl]-3,4-dihydro-1~{H}-isoquinolin-1-yl]carbonylamino]benzoic acid Deposited 2017-08-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：HEAVY CHAIN (UNP residues 388-625)
|
Not recorded | BUY 4-[[(1~{S})-2-[(~{E})-3-[5-chloranyl-2-(1,2,3,4-tetrazol-1-yl)phenyl]prop-2-enoyl]-3,4-dihydro-1~{H}-isoquinolin-1-yl]carbonylamino]benzoic acid × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 10 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 2.11 Å R-free 0.235 |
| 5QCM FACTOR XIA IN COMPLEX WITH THE INHIBITOR methyl ~{N}-[4-[[(1~{S})-2-[(~{E})-3-[3-chloranyl-2-fluoranyl-6-(1,2,3,4-tetrazol-1-yl)phenyl]prop-2-enoyl]-3,4-dihydro-1~{H}-isoquinolin-1-yl]carbonylamino]phenyl]carbamate Deposited 2017-08-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：HEAVY CHAIN (UNP residues 388-625)
|
Not recorded | BVJ methyl ~{N}-[4-[[(1~{S})-2-[(~{E})-3-[3-chloranyl-2-fluoranyl-6-(1,2,3,4-tetrazol-1-yl)phenyl]prop-2-enoyl]-3,4-dihydro-1~{H}-isoquinolin-1-yl]carbonylamino]phenyl]carbamate × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 15 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 2.20 Å R-free 0.244 |
| 5QCN FACTOR XIA IN COMPLEX WITH THE INHIBITOR 4-[[(1~{S})-2-[(~{E})-3-[5-chloranyl-2-(1,2,3,4-tetrazol-1-yl)phenyl]prop-2-enoyl]-5-[(3~{S})-3-ethoxycarbonylpiperidin-1-yl]carbonyl-3,4-dihydro-1~{H}-isoquinolin-1-yl]carbonylamino]benzoic acid Deposited 2017-08-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：HEAVY CHAIN (UNP residues 388-625)
|
Not recorded | BVM 4-[[(1~{S})-2-[(~{E})-3-[5-chloranyl-2-(1,2,3,4-tetrazol-1-yl)phenyl]prop-2-enoyl]-5-[(3~{S})-3-ethoxycarbonylpiperidin-1-yl]carbonyl-3,4-dihydro-1~{H}-isoquinolin-1-yl]carbonylamino]benzoic acid × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 15 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 2.30 Å R-free 0.243 |
| 5QQO FACTOR XIA IN COMPLEX WITH THE INHIBITOR methyl [(5E,8S)-8-[(6R)-6-(3-chlorophenyl)-2-oxo-1,3-oxazinan-3-yl]-2-oxo-1,3,4,7,8,10-hexahydro-2H-12,9-(azeno)-1,10-benzodiazacyclotetradecin-15-yl]carbamate Deposited 2019-05-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
388–625（238 aa）
Fragment：COAGULATION FACTOR XI, HEAVY CHAIN
|
Not recorded | NRJ methyl [(5E,8S)-8-[(6R)-6-(3-chlorophenyl)-2-oxo-1,3-oxazinan-3-yl]-2-oxo-1,3,4,7,8,10-hexahydro-2H-12,9-(azeno)-1,10-benzodiazacyclotetradecin-15-yl]carbamate × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 12 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 2.00 Å R-free 0.184 |
| 5QQP FACTOR XIA IN COMPLEX WITH THE INHIBITOR methyl [(5E,8S)-8-[(4S)-4-(3-chlorophenyl)-2-oxopiperidin-1-yl]-2-oxo-1,3,4,7,8,10-hexahydro-2H-12,9-(azeno)-1,10-benzodiazacyclotetradecin-15-yl]carbamate Deposited 2019-05-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：COAGULATION FACTOR XI, HEAVY CHAIN
|
Not recorded | NR7 methyl [(5E,8S)-8-[(4S)-4-(3-chlorophenyl)-2-oxopiperidin-1-yl]-2-oxo-1,3,4,7,8,10-hexahydro-2H-12,9-(azeno)-1,10-benzodiazacyclotetradecin-15-yl]carbamate × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 8 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 2.08 Å R-free 0.190 |
| 5QTT FACTOR XIA IN COMPLEX WITH THE INHIBITOR methyl [(3R,7S)-7-{[5-amino-1-(3-chloro-2-fluorophenyl)-1H-pyrazole-4-carbonyl]amino}-3-methyl-2-oxo-2,3,4,5,6,7-hexahydro-1H-12,8-(metheno)-1,9-benzodiazacyclotetradecin-15-yl]carbamate Deposited 2019-10-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：COAGULATION FACTOR XI, HEAVY CHAIN
|
Not recorded | QEY methyl [(3R,7S)-7-{[5-amino-1-(3-chloro-2-fluorophenyl)-1H-pyrazole-4-carbonyl]amino}-3-methyl-2-oxo-2,3,4,5,6,7-hexahydro-1H-12,8-(metheno)-1,9-benzodiazacyclotetradecin-15-yl]carbamate × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 11 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 2.23 Å R-free 0.226 |
| 5QTU FACTOR XIA IN COMPLEX WITH THE INHIBITOR methyl [(3R,7S)-7-{[1-(3-chloro-2-fluorophenyl)-5-methyl-1H-imidazole-4-carbonyl]amino}-3-methyl-2-oxo-2,3,4,5,6,7-hexahydro-1H-12,8-(metheno)-1,9-benzodiazacyclotetradecin-15-yl]carbamate Deposited 2019-10-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
388–625（238 aa）
Fragment：COAGULATION FACTOR XI, HEAVY CHAIN
Chain H
375–387（13 aa）
|
Not recorded | QEV methyl [(3R,7S)-7-{[1-(3-chloro-2-fluorophenyl)-5-methyl-1H-imidazole-4-carbonyl]amino}-3-methyl-2-oxo-2,3,4,5,6,7-hexahydro-1H-12,8-(metheno)-1,9-benzodiazacyclotetradecin-15-yl]carbamate × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 9 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 2.53 Å R-free 0.236 |
| 5QTV FACTOR XIA IN COMPLEX WITH THE INHIBITOR methyl [(2R,7S)-7-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-2-(trifluoromethyl)-2,3,4,5,6,7-hexahydro-1H-8,11-epimino-1,9-benzodiazacyclotridecin-14-yl]carbamate Deposited 2019-11-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：COAGULATION FACTOR XI, HEAVY CHAIN
|
Not recorded | QLS methyl [(2R,7S)-7-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-2-(trifluoromethyl)-2,3,4,5,6,7-hexahydro-1H-8,11-epimino-1,9-benzodiazacyclotridecin-14-yl]carbamate × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 13 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 2.20 Å R-free 0.202 |
| 5QTW FACTOR XIA IN COMPLEX WITH THE INHIBITOR methyl (2R,7S)-7-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-14-[(methoxycarbonyl)amino]-2,3,4,5,6,7-hexahydro-1H-8,11-epimino-1,9-benzodiazacyclotridecine-2-carboxylate Deposited 2019-11-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：COAGULATION FACTOR XI, HEAVY CHAIN
|
Not recorded | QLM methyl (2R,7S)-7-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-14-[(methoxycarbonyl)amino]-2,3,4,5,6,7-hexahydro-1H-8,11-epimino-1,9-benzodiazacyclotridecine-2-carboxylate × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 14 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 2.12 Å R-free 0.248 |
| 5QTX FACTOR XIA IN COMPLEX WITH THE INHIBITOR ethyl (2R,7S)-7-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-14-[(methoxycarbonyl)amino]-1,2,3,4,5,6,7,9-octahydro-11,8-(azeno)-1,9-benzodiazacyclotridecine-2-carboxylate Deposited 2019-11-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
388–625（238 aa）
Fragment：COAGULATION FACTOR XI, HEAVY CHAIN
Chain H
375–387（13 aa）
Fragment：N-ter fragment
|
Not recorded | QLD ethyl (2R,7S)-7-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-14-[(methoxycarbonyl)amino]-1,2,3,4,5,6,7,9-octahydro-11,8-(azeno)-1,9-benzodiazacyclotridecine-2-carboxylate × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 13 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 2.07 Å R-free 0.178 |
| 5QTY FACTOR XIA IN COMPLEX WITH THE INHIBITOR ethyl (2R,7S)-7-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-15-[(methoxycarbonyl)amino]-2,3,4,5,6,7-hexahydro-1H-12,8-(metheno)-1,9-benzodiazacyclotetradecine-2-carboxylate Deposited 2019-11-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：COAGULATION FACTOR XI, HEAVY CHAIN
|
Not recorded | QLJ ethyl (2R,7S)-7-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-15-[(methoxycarbonyl)amino]-2,3,4,5,6,7-hexahydro-1H-12,8-(metheno)-1,9-benzodiazacyclotetradecine-2-carboxylate × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 13 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 1.89 Å R-free 0.171 |
| 5TKS FACTOR XIA IN COMPLEX WITH THE INHIBITOR ((15S)-18-CHLORO- 15-(((2E)-3-(5-CHLORO-2-(1H-TETRAZOL-1-YL)PHENYL)-2- PROPENOYL)AMINO)-17,19-DIAZATRICYCLO[14.2.1.0~2,7~]NONADECA-1(18),2,4,6,16(19)-PENTAEN-5-YL)CARBAMATE Deposited 2016-10-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：N113G,T115G | 7DL ((15S)-18-CHLORO- 15-(((2E)-3-(5-CHLORO-2-(1H-TETRAZOL-1-YL)PHENYL)-2- PROPENOYL)AMINO)-17,19-DIAZATRICYCLO[14.2.1.0~2,7~]NONADECA-1(18),2,4,6,16(19)-PENTAEN-5-YL)CARBAMATE × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 15 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 MM SODIUM ACETATE, PH 4.6, 25%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE, then transferred to 100 MM TRIS-HCL, pH 7.0, 25%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE
|
Resolution 1.55 Å R-free 0.176 |
| 5TKT FACTOR XIA IN COMPLEX WITH THE INHIBITOR METHYL ((12E,15S)-15-(((2E)-3-(5-CHLORO-2-(1H-TETRAZOL-1-YL)PHENYL)-2-PROPENOYL)AMINO)-9-OXO-8,17,19-TRIAZATRICYCLO[14.2.1.0~2,7~]NONADECA-1(18),2,4,6,12,16(19)-HEXAEN-5-YL)CARBAMATE Deposited 2016-10-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：N113G,T115G | 7DS METHYL ((12E,15S)-15-(((2E)-3-(5-CHLORO-2-(1H-TETRAZOL-1-YL)PHENYL)-2-PROPENOYL)AMINO)-9-OXO-8,17,19-TRIAZATRICYCLO[14.2.1.0~2, 7~]NONADECA-1(18),2,4,6,12,16(19)-HEXAEN-5-YL)CARBAMATE × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 11 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 MM SODIUM ACETATE, PH 4.6, 25%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE, then transferred to 100 MM TRIS-HCL, pH 7.0, 25%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE
|
Resolution 2.12 Å R-free 0.189 |
| 5TKU FACTOR XIA IN COMPLEX WITH THE INHIBITOR METHYL ((15S)-15-(((2E)-3-(5-CHLORO-2-(1H-TETRAZOL-1-YL)PHENYL)-2-PROPENOYL)AMINO)-9-OXO-8,17,19-TRIAZATRICYCLO[14.2.1.0~2,7~]NONADECA-1(18),2,4,6,16(19)-PENTAEN-5-YL)CARBAMATE Deposited 2016-10-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：N113G,T115G | 7DK METHYL ((15S)-15-(((2E)-3-(5-CHLORO-2-(1H-TETRAZOL-1-YL)PHENYL)-2-PROPENOYL)AMINO)-9-OXO-8,17,19-TRIAZATRICYCLO[14.2.1.0~2,7~]N ONADECA-1(18),2,4,6,16(19)-PENTAEN-5-YL)CARBAMATE × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 10 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 MM SODIUM ACETATE, PH 4.6, 25%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE, then transferred to 100 MM TRIS-HCL, pH 7.0, 25%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE
|
Resolution 2.12 Å R-free 0.185 |
| 5WB6 FACTOR XIA IN COMPLEX WITH THE INHIBITOR methyl [(11S)-11-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-6-fluoro-2-oxo-1,3,4,10,11,13-hexahydro-2H-5,9:15,12-di(azeno)-1,13-benzodiazacycloheptadecin-18-yl]carbamate Deposited 2017-06-28 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：Light chain (UNP residues 388-625)
|
Mutation：N113G,T115G | 9ZM methyl [(11S)-11-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)-6-fluoro-2-oxo-1,3,4,10,11,13-hexahydro-2H-5,9:15,12-di(azeno)-1,13-benzodiazacycloheptadecin-18-yl]carbamate × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 14 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 MM SODIUM ACETATE, PH 4.6, 25%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE, then transferred to 100 MM TRIS-HCL, pH 7.0, 25%(w/v) MEPEG2000, 200 MM AMMONIUM SULFATE
|
Resolution 2.35 Å R-free 0.236 |
| 6AOD FXIa antibody complex Deposited 2017-08-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
388–624（237 aa）
Fragment：UNP residues 388-624
|
Mutation：N63Q, N104Q, C113S, S188A | SO4 SULFATE ION × 4 GOL GLYCEROL × 9 CO COBALT (II) ION × 3 PO4 PHOSPHATE ION × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；277 K；1.86 M ammonium sulfate, 8 mM CoCl2, 30 mM K/Na phosphate, pH 6.5
|
Resolution 1.80 Å R-free 0.207 |
| 6C0S Factor XIA in complex with the inhibitor methyl (4-{6-[(1S)-2-[(3R)-1-acetylpiperidin-3-yl]-1-({(2E)-3-[5-chloro-2- (1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)ethyl]-3-chloropyridazin-4-yl}phenyl) carbamate Deposited 2018-01-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：Light Chain (UNP residues 388-625)
|
Mutation：N113G,T115G | EEJ methyl (4-{6-[(1S)-2-[(3R)-1-acetylpiperidin-3-yl]-1-({(2E)-3-[5-chloro-2-(1H-tetrazol-1-yl)phenyl]prop-2-enoyl}amino)ethyl]-3-chloropyridazin-4-yl}phenyl)carbamate × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 12 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% w/v MEPEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% w/v MEPEG2000, 200 mM ammonium sulfate
|
Resolution 2.35 Å R-free 0.226 |
| 6HHC Allosteric Inhibition as a new mode of Action for BAY 1213790, a Neutralizing Antibody Targeting the Activated form of Coagulation Factor XI Deposited 2018-08-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
388–625（238 aa）
|
Mutation：C500S | SO4 SULFATE ION × 3 DMS DIMETHYL SULFOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 7.5；293 K；20 mM Tris-HCl pH 7.5,75 mM NaCl
|
Resolution 2.70 Å R-free 0.314 |
| 6I58 Allosteric activation of human prekallikrein by apple domain disc rotation Deposited 2018-11-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
19–625（607 aa）
|
Not recorded | CL CHLORIDE ION × 10 PEG DI(HYDROXYETHYL)ETHER × 2 NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 7.5；293 K；0.1 M SODIUM HEPES AND 22% (V/V) PEG
1000, PH 7.5, EVAPORATION, TEMPERATURE 293K
|
Resolution 2.60 Å R-free 0.280 |
| 6R8X COAGULATION FACTOR XI CATALYTIC DOMAIN IN COMPLEX WITH FAB-PORTION OF MAA868 Deposited 2019-04-02 | Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
388–625（238 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；277 K；20% PEG 3350
9MG/ML
SEEDING (ORIGINAL CRYSTAL FROM WHICH SEEDS WERE PREPARED GREW AFTER 3 WEEKS)
|
Resolution 2.04 Å R-free 0.282 |
| 6TS4 Coagulation factor XI protease domain in complex with active site inhibitor Deposited 2019-12-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：SER A 123 SWS P03951 CYS 500 ENGINEERED MUTATION, ALA A 195 SWS P03951 SER 575 ACTIVE SITE MUTATION | SO4 SULFATE ION × 3 DMS DIMETHYL SULFOXIDE × 5 NA SODIUM ION × 1 J7B 2-[2-[[3-[3-(aminomethyl)phenyl]phenyl]carbonylamino]phenyl]ethanoic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；277 K；0.2 M Ammonium sulfate, 0.1 M BIS-TRIS pH5.5, 25% w/v Polyethylene glycol 3350
|
Resolution 1.17 Å R-free 0.203 |
| 6TS5 Coagulation factor XI protease domain in complex with active site inhibitor Deposited 2019-12-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：SER A 123 SWS P03951 CYS 500 ENGINEERED MUTATION, ALA A 195 SWS P03951 SER 575 ACTIVE SITE MUTATION | NW2 2-[2-[3-[(3~{S})-3-azanyl-2,3-dihydro-1-benzofuran-5-yl]-5-propan-2-yl-phenyl]ethoxy]-3-methoxy-benzoic acid × 1 SO4 SULFATE ION × 3 DMS DIMETHYL SULFOXIDE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；277 K；0.2 M Ammonium sulfate, 0.1 M BIS-TRIS pH5.5, 25% w/v Polyethylene glycol 3350
Protein at 18mg/ml in 50mM Tris/HCl pH7.4 100mM NaCl
|
Resolution 1.29 Å R-free 0.207 |
| 6TS6 Coagulation factor XI protease domain in complex with active site inhibitor Deposited 2019-12-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：SER A 123 SWS P03951 CYS 500 ENGINEERED MUTATION | SO4 SULFATE ION × 3 DMS DIMETHYL SULFOXIDE × 3 NW5 2-[2-[[3-[(3~{S})-3-azanyl-2,3-dihydro-1-benzofuran-5-yl]-5-(2-cyanopropan-2-yl)phenyl]methoxy]phenyl]ethanoic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；277 K；0.2 M Ammonium sulfate, 0.1 M BIS-TRIS pH5.5, 25% w/v Polyethylene glycol 3350
|
Resolution 1.33 Å R-free 0.210 |
| 6TS7 Coagulation factor XI protease domain in complex with active site inhibitor Deposited 2019-12-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：SER A 123 SWS P03951 CYS 500 ENGINEERED MUTATION | NWE 2-[2-[[3-(1,2,3,4-tetrahydroisoquinolin-7-yl)phenyl]methoxy]phenyl]ethanoic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；277 K；25% w/v PEG 3350, Sodium acetate trihydrate pH 4.5
|
Resolution 2.63 Å R-free 0.276 |
| 6TWB Crystal Structure of the Catalytic Domain of Coagulation Factor XIa in Complex with Double Bridged Peptide F19 Deposited 2020-01-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
321–571（251 aa）
Chain H
321–571（251 aa）
|
Not recorded | NH4 AMMONIUM ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；200 mM (NH4)2SO4, 25% PEG4000, and 100 mM NaOAc, pH 4.6
|
Resolution 2.91 Å R-free 0.241 |
| 6TWC Crystal Structure of the Catalytic Domain of the Coagulation Factor XIa in Complex with Double Bridged Peptide F21 Deposited 2020-01-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
388–625（238 aa）
Chain H
375–387（13 aa）
|
Not recorded | ACN ACETONE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；200 mM (NH4)2SO4, 25% PEG4000, and 100 mM NaOAc, pH 4.6
|
Resolution 2.86 Å R-free 0.259 |
| 6USY COAGULATION FACTOR XI CATALYTIC DOMAIN (C123S) IN COMPLEX WITH NVP-XIV936 Deposited 2019-10-28 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：C123S | QGS 1-[(2S)-2-{3-[(3S)-3-amino-2,3-dihydro-1-benzofuran-5-yl]-5-(propan-2-yl)phenyl}-2-hydroxyethyl]-1H-indole-7-carboxylic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1 M Bit-Tris pH 7.0, 0.6 M NaCl, 25 % (w/v) PEG3,350
|
Resolution 1.26 Å R-free 0.188 |
| 6VLU Factor XIa in complex with compound 7 Deposited 2020-01-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Not recorded | CIT CITRIC ACID × 1 R2Y N-cyclohexyl-D-leucyl-N-[(1-aminoisoquinolin-6-yl)methyl]-4,4-difluoro-L-prolinamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；0.1 M citrate pH 5, 23% PEG4000, seeded.
|
Resolution 1.60 Å R-free 0.246 |
| 6VLV Factor XIa in complex with compound 11 Deposited 2020-01-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：C500S | FLC CITRATE ANION × 2 R3A 1-carbamimidamido-4-chloro-N-[(2R)-3-methyl-1-(morpholin-4-yl)-1-oxobutan-2-yl]isoquinoline-7-sulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 5；293 K；0.1 M CITRATE pH 5.0
32.0 w/v polyethylene glycol 4000
|
Resolution 1.72 Å R-free 0.198 |
| 6W50 FACTOR XIA IN COMPLEX WITH THE INHIBITOR METHYL ((10R,14S)- 14-(4-(3-CHLORO-2,6-DIFLUOROPHENYL)-6-OXO-3,6-DIHYDRO- 1(2H)-PYRIDINYL)-10-METHYL-9-OXO-8,16- DIAZATRICYCLO[13.3.1.0~2,7~]NONADECA-1(19),2,4,6,15,17- HEXAEN-5-YL)CARBAMATE Deposited 2020-03-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
Fragment：COAGULATION FACTOR XI, HEAVY CHAIN
|
Not recorded | SWP methyl ((10R,14S)-14-(4-(3-chloro-2,6-difluorophenyl)-6-oxo-3,6-dihydro- 1(2h)-pyridinyl)-10-methyl-9-oxo-8,16-diazatricyclo[13.3.1.0~2,7~]nonadeca- 1(19),2,4,6,15,17-hexaen-5-yl)carbamate × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 12 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；100 mM sodium acetate, pH 4.6, 25% (w/v) MePEG2000, 200 mM ammonium sulfate, then transferred to 100 mM Tris-HCl, pH 7.0, 25% (w/v) MePEG2000, 200 MM ammonium sulfate
|
Resolution 1.95 Å R-free 0.172 |
| 7CJ1 The crystal structure of FXIa serine protease domain in complex with benzamidine Deposited 2020-07-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–623（236 aa）
|
Not recorded | BEN BENZAMIDINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；25% PEG2000 MME, 0.1 M Tris-Hcl pH8.5
|
Resolution 3.00 Å R-free 0.267 |
| 7CJ1 The crystal structure of FXIa serine protease domain in complex with benzamidine Deposited 2020-07-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
388–623（236 aa）
|
Not recorded | BEN BENZAMIDINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；25% PEG2000 MME, 0.1 M Tris-Hcl pH8.5
|
Resolution 3.00 Å R-free 0.267 |
| 7CJ1 The crystal structure of FXIa serine protease domain in complex with benzamidine Deposited 2020-07-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
388–623（236 aa）
|
Not recorded | BEN BENZAMIDINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；25% PEG2000 MME, 0.1 M Tris-Hcl pH8.5
|
Resolution 3.00 Å R-free 0.267 |
| 7CJ1 The crystal structure of FXIa serine protease domain in complex with benzamidine Deposited 2020-07-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
388–623（236 aa）
|
Not recorded | BEN BENZAMIDINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；25% PEG2000 MME, 0.1 M Tris-Hcl pH8.5
|
Resolution 3.00 Å R-free 0.267 |
| 7MBO FACTOR XIA (PICHIA PASTORIS; C500S [C122S]) IN COMPLEX WITH THE INHIBITOR Milvexian (BMS-986177), IUPAC NAME:(6R,10S)-10-{4-[5-chloro-2-(4-chloro-1H-1,2,3-triazol-1-yl)phenyl]-6- oxopyrimidin-1(6H)-yl}-1-(difluoromethyl)-6-methyl-1,4,7,8,9,10-hexahydro-15,11- (metheno)pyrazolo[4,3-b][1,7]diazacyclotetradecin-5(6H)-one Deposited 2021-04-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：C500S | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 YXG Milvexian × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；100 MM MES, pH 6.5, 20% (W/V) PEG 6000, 10 MM CALCIUM ACETATE
|
Resolution 0.92 Å R-free 0.168 |
| 7QOT Factor XI and Plasma Kallikrein apple domain structures reveals different kininogen bound complexes Deposited 2021-12-28 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
19–376（358 aa）
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 2 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；288 K；0.1M Tris pH8, 1.5M AMMONIUM SULFATE
|
Resolution 3.24 Å R-free 0.284 |
| 7QOT Factor XI and Plasma Kallikrein apple domain structures reveals different kininogen bound complexes Deposited 2021-12-28 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
19–376（358 aa）
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；288 K；0.1M Tris pH8, 1.5M AMMONIUM SULFATE
|
Resolution 3.24 Å R-free 0.284 |
| 7V0Z Factor XIa in Complex with Compound 2a Deposited 2022-05-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：C500S | OQ6 methyl ~{N}-[4-[1-[(1~{R})-1-[5-[5-chloranyl-2-(1,2,3,4-tetrazol-1-yl)phenyl]-1-oxidanyl-pyridin-2-yl]-2-cyclopropyl-ethyl]pyrazol-4-yl]phenyl]carbamate × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；293 K；24% PEG 4000, 100mM Na Citrate pH 5.0
|
Resolution 1.80 Å R-free 0.202 |
| 7V10 Factor XIa in Complex with Compound 2d Deposited 2022-05-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：C500S | OQI methyl ~{N}-[4-[1-[(1~{R})-1-[5-[3-chloranyl-2-fluoranyl-6-(1,2,3,4-tetrazol-1-yl)phenyl]-1-oxidanyl-pyridin-2-yl]-2-cyclopropyl-ethyl]pyrazol-4-yl]phenyl]carbamate × 1 CIT CITRIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；293 K；24% PEG 4000, 100mM Na Citrate pH 5.0
|
Resolution 1.80 Å R-free 0.230 |
| 7V11 Factor XIa in Complex with Compound 2e Deposited 2022-05-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：C500S | OQO 5-[1-[(1~{R})-1-[5-[3-chloranyl-2-fluoranyl-6-(1,2,3,4-tetrazol-1-yl)phenyl]-1-oxidanyl-pyridin-2-yl]-2-cyclopropyl-ethyl]pyrazol-4-yl]-6-methyl-pyridin-2-amine × 1 CIT CITRIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；293 K；24% PEG 4000, 100mM Na Citrate pH 5.0
|
Resolution 1.47 Å R-free 0.175 |
| 7V12 Factor XIa in Complex with Compound 2f Deposited 2022-05-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：C500S | OR0 5-[1-[(1~{R})-1-[5-[3-chloranyl-2-fluoranyl-6-(1,2,3,4-tetrazol-1-yl)phenyl]-1-oxidanyl-pyridin-2-yl]-2-cyclopropyl-ethyl]pyrazol-4-yl]-6-fluoranyl-pyridin-2-amine × 1 CIT CITRIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；293 K；24% PEG 4000, 100mM Na Citrate pH 5.0
|
Resolution 1.63 Å R-free 0.224 |
| 7V13 Factor XIa in Complex with Compound 2g Deposited 2022-05-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：C500S | CIT CITRIC ACID × 1 ORF 3-chloranyl-4-[1-[(1~{R})-1-[5-[3-chloranyl-2-fluoranyl-6-(1,2,3,4-tetrazol-1-yl)phenyl]-1-oxidanyl-pyridin-2-yl]-2-cyclopropyl-ethyl]pyrazol-4-yl]-5-fluoranyl-pyridine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；293 K；24% PEG 4000, 100mM Na Citrate pH 5.0
|
Resolution 1.59 Å R-free 0.189 |
| 7V14 Factor XIa in Complex with Compound 2h Deposited 2022-05-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：C500S | CIT CITRIC ACID × 1 ORU 5-[1-[(1~{R})-1-[5-[3-chloranyl-2-fluoranyl-6-(1,2,3,4-tetrazol-1-yl)phenyl]-1-oxidanyl-pyridin-2-yl]-2-cyclopropyl-ethyl]pyrazol-4-yl]-1,3-thiazole × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；293 K；24% PEG 4000, 100mM Na Citrate pH 5.0
|
Resolution 1.70 Å R-free 0.193 |
| 7V15 Factor XIa in Complex with Compound 2i Deposited 2022-05-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：C500S | CIT CITRIC ACID × 1 OSX 5-[1-[(1~{R})-1-[5-[3-chloranyl-2-fluoranyl-6-(1,2,3,4-tetrazol-1-yl)phenyl]-1-oxidanyl-pyridin-2-yl]-2-cyclopropyl-ethyl]pyrazol-4-yl]-4-methyl-1,3-thiazole × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；293 K；24% PEG 4000, 100mM Na Citrate pH 5.0
|
Resolution 1.68 Å R-free 0.190 |
| 7V16 Factor XIa in Complex with Compound 2j Deposited 2022-05-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：C500S | CIT CITRIC ACID × 1 OT7 5-[3-chloranyl-2-fluoranyl-6-(1,2,3,4-tetrazol-1-yl)phenyl]-2-[(1~{R})-2-cyclopropyl-1-[4-(2-methylpyrazol-3-yl)pyrazol-1-yl]ethyl]-1-oxidanyl-pyridine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；293 K；24% PEG 4000, 100mM Na Citrate pH 5.0
|
Resolution 1.50 Å R-free 0.194 |
| 7V17 Factor XIa in Complex with Compound 2k Deposited 2022-05-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：C500S | CIT CITRIC ACID × 1 OTL 5-[3-chloranyl-2-fluoranyl-6-(1,2,3,4-tetrazol-1-yl)phenyl]-2-[(1~{R})-2-cyclopropyl-1-[4-(3-methylimidazol-4-yl)pyrazol-1-yl]ethyl]-1-oxidanyl-pyridine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 5；293 K；24% PEG 4000, 100mM Na Citrate pH 5.0
|
Resolution 1.52 Å R-free 0.187 |
| 7V18 Factor XIa in Complex with Compound 3f Deposited 2022-05-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
388–625（238 aa）
|
Mutation：C500S | CIT CITRIC ACID × 1 OTX 2-[(1~{R})-3-[bis(fluoranyl)methoxy]-1-[4-(3-methyl-1,2,3-triazol-4-yl)pyrazol-1-yl]propyl]-5-[3-chloranyl-6-(4-chloranyl-1,2,3-triazol-1-yl)-2-fluoranyl-phenyl]-1-oxidanyl-pyridine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；293 K；24% PEG 4000, 100mM Na Citrate pH 5.0
|
Resolution 1.73 Å R-free 0.207 |
| 8BO3 COAGULATION FACTOR XI PROTEASE DOMAIN IN COMPLEX WITH ACTIVE SITE INHIBITOR Asundexian Deposited 2022-11-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain AAA
388–625（238 aa）
|
Mutation：C500S | QV3 4-[[(2~{S})-2-[4-[5-chloranyl-2-[4-(trifluoromethyl)-1,2,3-triazol-1-yl]phenyl]-5-methoxy-2-oxidanylidene-pyridin-1-yl]butanoyl]amino]-2-fluoranyl-benzamide × 1 CIT CITRIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.1M Citrate pH 4.5, 20-30% PEG4000
|
Resolution 1.84 Å R-free 0.208 |
| 8BO4 COAGULATION FACTOR XI PROTEASE DOMAIN IN COMPLEX WITH ACTIVE SITE INHIBITOR 1 Deposited 2022-11-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain AAA
388–625（238 aa）
|
Mutation：C500S | GOL GLYCEROL × 1 QVI 4-(aminomethyl)-~{N}-[(2~{S})-1-oxidanylidene-3-phenyl-1-[[4-(1~{H}-1,2,3,4-tetrazol-5-yl)phenyl]amino]propan-2-yl]cyclohexane-1-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.1M citrate buffer pH 4.5 and 20-30% PEG4000
|
Resolution 1.75 Å R-free 0.189 |
| 8BO5 COAGULATION FACTOR XI PROTEASE DOMAIN IN COMPLEX WITH ACTIVE SITE INHIBITOR 3 Deposited 2022-11-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain AAA
388–625（238 aa）
|
Mutation：C500S | QVO 2-[4-(3-chlorophenyl)-2,5-bis(oxidanylidene)pyrrolo[3,4-b]pyridin-1-yl]-~{N}-[4-(1~{H}-1,2,3,4-tetrazol-5-yl)phenyl]ethanamide × 1 CIT CITRIC ACID × 1 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.1M citrate buffer pH 4.5 and 20-30% PEG4000
|
Resolution 1.70 Å R-free 0.174 |
| 8BO6 COAGULATION FACTOR XI PROTEASE DOMAIN IN COMPLEX WITH ACTIVE SITE INHIBITOR 2 Deposited 2022-11-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain AAA
388–625（238 aa）
|
Mutation：C500S | QW0 (~{E})-~{N}-[[5-(3-azanyl-1~{H}-indazol-6-yl)-4-chloranyl-1~{H}-imidazol-2-yl]methyl]-3-[5-chloranyl-2-(1,2,3,4-tetrazol-1-yl)phenyl]prop-2-enamide × 1 CIT CITRIC ACID × 1 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.1M citrate buffer pH 4.5 and 20-30% PEG4000
|
Resolution 1.25 Å R-free 0.141 |
| 8BO7 COAGULATION FACTOR XI PROTEASE DOMAIN IN COMPLEX WITH ACTIVE SITE INHIBITOR 34 Deposited 2022-11-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain AAA
388–625（238 aa）
|
Mutation：C500S | QW6 4-[[(2~{S})-2-[4-(5-chloranyl-2-cyano-phenyl)-3-methoxy-6-oxidanylidene-2,5-dihydropyridin-1-yl]-3-[(2~{S})-oxan-2-yl]propanoyl]amino]benzoic acid × 1 CIT CITRIC ACID × 1 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.1M citrate buffer pH 4.5 and 20-30% PEG4000
|
Resolution 1.25 Å R-free 0.157 |
113 other PDB entries and 120 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | FA11_HUMAN |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 1–238； UniProt 388–625 Author chain B； PDBConstruct 1–238； UniProt 388–625 |
