1zr5

Crystal structure of the macro-domain of human core histone variant macroH2A1.2

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

H2AFY protein

Homo sapiens

UniProt O75367

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein monomer Monomer Protein 1 water × 1 Consistent with protein count
2 Protein monomer Monomer Protein 1 water × 1 Consistent with protein count

Other States of the Same Protein in the Database

Monomer
1zr5 1zr5

2 assemblies

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
1u35 2f8n 3hsv 3ivb 5iit 5iit 5iit 5iit 5lnc 5lnc

10 assemblies

View Construct and Data Evidence
UniProt name H2AY_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 3–214； UniProt 161–372 Author chain B； PDBConstruct 3–214； UniProt 161–372

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id1zr5
Deposition date deposition_date2005-05-19
Structure title titleCrystal structure of the macro-domain of human core histone variant macroH2A1.2
Keywords keywordschromatin, histone, a1pp, macro-domain, p-loop, splicing, Gene Regulation; GENE REGULATION
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1zr5__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1zr5__assembly_1__model_1 | I(q)

10-2 10-1 105 106 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

1zr5__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）16.96 Å
Rg (electron density)15.64 Å
Total Rg16.90 Å
Atom count1430
Residues189
Excluded volume25847 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 1zr5__assembly_1__model_1 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
2 1 1zr5__assembly_2__model_1 monomeric （1） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (2)

▼

6. Fold Classification (SCOP + CATH) 4 domains

SCOP 2.08 (2 domains)

Domain ID domain_idd1zr5a1
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.50 — Macro domain-like
Superfamily Superfamily superfamilyc.50.1 — Macro domain-like
Family Family familyc.50.1.2 — Macro domain
Domain ID domain_idd1zr5b_
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.50 — Macro domain-like
Superfamily Superfamily superfamilyc.50.1 — Macro domain-like
Family Family familyc.50.1.2 — Macro domain

CATH v4.4 (2 domains)

Domain ID domain_id1zr5A00
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology220 — Leucine Aminopeptidase, subunit E; domain 1
Homologous superfamily homologous superfamily10 — Leucine Aminopeptidase, subunit E, domain 1
Domain ID domain_id1zr5B00
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology220 — Leucine Aminopeptidase, subunit E; domain 1
Homologous superfamily homologous superfamily10 — Leucine Aminopeptidase, subunit E, domain 1
▶

7. Citations (1)
