3oee

Structure of four mutant forms of yeast F1 ATPase: alpha-F405S

Method: X-RAY DIFFRACTION Dmax: 262.1 Å Quality: GOOD
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

ATP synthase subunit alpha

Saccharomyces cerevisiae

UniProt P07251

State in the Current Structure

Assembly Oligomeric State Construct Mutations and Modifications Ligands, Ions and Associated Components Method and Experimental Conditions Structure Quality
1 Protein heterocomplex Heteromer Protein × 9 PDB declaration: nonameric（9） Consistent with protein copy count Chain A； UniProt 36–545 Chain B； UniProt 36–545 Chain C； UniProt 36–545 Fragment：UNP RESIDUES 36-545 Mutation：F405S ATP synthase subunit beta × 3 （P00830） ATP synthase subunit gamma × 1 （P38077） ATP synthase subunit delta × 1 （Q12165） ATP synthase subunit epsilon × 1 （P21306） ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION X-ray crystallization conditions：pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K Resolution 2.74 Å R-free 0.259
2 Protein heterocomplex Heteromer Protein × 9 PDB declaration: nonameric（9） Consistent with protein copy count Chain J； UniProt 36–545 Chain K； UniProt 36–545 Chain L； UniProt 36–545 Fragment：UNP RESIDUES 36-545 Mutation：F405S ATP synthase subunit beta × 3 （P00830） ATP synthase subunit gamma × 1 （P38077） ATP synthase subunit delta × 1 （Q12165） ATP synthase subunit epsilon × 1 （P21306） ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION X-ray crystallization conditions：pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K Resolution 2.74 Å R-free 0.259
3 Protein heterocomplex Heteromer Protein × 9 PDB declaration: nonameric（9） Consistent with protein copy count Chain S； UniProt 36–545 Chain T； UniProt 36–545 Chain U； UniProt 36–545 Fragment：UNP RESIDUES 36-545 Mutation：F405S ATP synthase subunit beta × 3 （P00830） ATP synthase subunit gamma × 1 （P38077） ATP synthase subunit delta × 1 （Q12165） ATP synthase subunit epsilon × 1 （P21306） ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION X-ray crystallization conditions：pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K Resolution 2.74 Å R-free 0.259

Other States of the Same Protein in the Database

Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.

Other PDB Difference from Current Entry 3OEE Assembly / Oligomeric State Construct Mutations and Modifications Ligands, Ions and Non-polymers Method and Experimental Conditions Structure Quality
2HLD Crystal structure of yeast mitochondrial F1-ATPase Deposited 2006-07-06 Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded MG MAGNESIUM ION × 5 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% glycerol, 4% methanol, 0.05M sodium acetate, 0.5mM nickel sulphate, 0.5mM AMP/PNP, 0.025 mM ADP, 2mM magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 2.80 Å R-free 0.244
2HLD Crystal structure of yeast mitochondrial F1-ATPase Deposited 2006-07-06 Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain J 36–545（510 aa）
Chain K 36–545（510 aa）
Chain L 36–545（510 aa）
Not recorded MG MAGNESIUM ION × 5 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% glycerol, 4% methanol, 0.05M sodium acetate, 0.5mM nickel sulphate, 0.5mM AMP/PNP, 0.025 mM ADP, 2mM magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 2.80 Å R-free 0.244
2HLD Crystal structure of yeast mitochondrial F1-ATPase Deposited 2006-07-06 Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain S 36–545（510 aa）
Chain T 36–545（510 aa）
Chain U 36–545（510 aa）
Not recorded MG MAGNESIUM ION × 5 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% glycerol, 4% methanol, 0.05M sodium acetate, 0.5mM nickel sulphate, 0.5mM AMP/PNP, 0.025 mM ADP, 2mM magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 2.80 Å R-free 0.244
2WPD The Mg.ADP inhibited state of the yeast F1c10 ATP synthase Deposited 2009-08-05 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 19 PDB declaration: nonadecameric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 2 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.5；0.1 M HEPES/HCL PH 7.5, 12% PEG MME 5000, 100 MM SODIUM CHLORIDE MIXED 1:1 WITH PROTEIN SOLUTION CONTAINING 0.64 MM DDM, 25 MM TRIS/HCL PH 8.0, 100 MM SODIUM CHLORIDE, 25 MM TREHALOSE, 0.5 MM EDTA, 0.02% SODIUM AZIDE, 2 MM MAGNESIUM CHLORIDE, 0.66 MM ADP, 0.1 MM DCCD, 2.5 MM DTT, 0.5 MM PMSF
Resolution 3.43 Å R-free 0.297
2XOK Refined structure of yeast F1c10 ATPase complex to 3 A resolution Deposited 2010-08-18 Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 19 PDB declaration: nonadecameric
Chain A 1–545（545 aa）
Chain B 1–545（545 aa）
Chain C 1–545（545 aa）
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions MICROBATCH；pH 8；0.1 M TRIS/CL PH8.0, 12% PEG 6000, 150 MM NACL, 1 MM AMP-PNP, 40 MICROM ADP, 1 MM DTT, 0.02% NAN3. MIXED 1:1 WITH PROTEIN SOLUTION UNDER PARAFFIN OIL IN MICROBATCH PLATE.
Resolution 3.01 Å R-free 0.253
3FKS Yeast F1 ATPase in the absence of bound nucleotides Deposited 2008-12-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain A 36–545（510 aa） Fragment：UNP residues 36-545
Chain B 36–545（510 aa） Fragment：UNP residues 36-545
Chain C 36–545（510 aa） Fragment：UNP residues 36-545
Not recorded PO4 PHOSPHATE ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；6.25% PEG 6000, 10% Glycerol, 4% Methanol, 0.05M Sodium acetate, 0.5mM Nickel sulfate, 2 mM Sodium pyrophosphate, 2mM Magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277.0K
Resolution 3.59 Å R-free 0.306
3FKS Yeast F1 ATPase in the absence of bound nucleotides Deposited 2008-12-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain J 36–545（510 aa） Fragment：UNP residues 36-545
Chain K 36–545（510 aa） Fragment：UNP residues 36-545
Chain L 36–545（510 aa） Fragment：UNP residues 36-545
Not recorded PO4 PHOSPHATE ION × 6 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；6.25% PEG 6000, 10% Glycerol, 4% Methanol, 0.05M Sodium acetate, 0.5mM Nickel sulfate, 2 mM Sodium pyrophosphate, 2mM Magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277.0K
Resolution 3.59 Å R-free 0.306
3FKS Yeast F1 ATPase in the absence of bound nucleotides Deposited 2008-12-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain S 36–545（510 aa） Fragment：UNP residues 36-545
Chain T 36–545（510 aa） Fragment：UNP residues 36-545
Chain U 36–545（510 aa） Fragment：UNP residues 36-545
Not recorded PO4 PHOSPHATE ION × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；6.25% PEG 6000, 10% Glycerol, 4% Methanol, 0.05M Sodium acetate, 0.5mM Nickel sulfate, 2 mM Sodium pyrophosphate, 2mM Magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277.0K
Resolution 3.59 Å R-free 0.306
3OE7 Structure of four mutant forms of yeast f1 ATPase: gamma-I270T Deposited 2010-08-12 Different mutation/modification Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain A 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain B 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain C 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, PH 7.3, VAPOR DIFFUSION SITTING DROP, TEMPERATURE 277K
Resolution 3.19 Å R-free 0.245
3OE7 Structure of four mutant forms of yeast f1 ATPase: gamma-I270T Deposited 2010-08-12 Different mutation/modification Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain J 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain K 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain L 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, PH 7.3, VAPOR DIFFUSION SITTING DROP, TEMPERATURE 277K
Resolution 3.19 Å R-free 0.245
3OE7 Structure of four mutant forms of yeast f1 ATPase: gamma-I270T Deposited 2010-08-12 Different mutation/modification Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain S 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain T 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain U 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, PH 7.3, VAPOR DIFFUSION SITTING DROP, TEMPERATURE 277K
Resolution 3.19 Å R-free 0.245
3OEH Structure of four mutant forms of yeast F1 ATPase: beta-V279F Deposited 2010-08-12 Different mutation/modification Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain A 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain B 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain C 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.00 Å R-free 0.270
3OEH Structure of four mutant forms of yeast F1 ATPase: beta-V279F Deposited 2010-08-12 Different mutation/modification Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain J 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain K 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain L 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.00 Å R-free 0.270
3OEH Structure of four mutant forms of yeast F1 ATPase: beta-V279F Deposited 2010-08-12 Different mutation/modification Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain S 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain T 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain U 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.00 Å R-free 0.270
3OFN Structure of four mutant forms of yeast F1 ATPase: alpha-N67I Deposited 2010-08-15 Different mutation/modification Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain A 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain B 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain C 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Mutation：N67I Mutation：N67I Mutation：N67I ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.20 Å R-free 0.276
3OFN Structure of four mutant forms of yeast F1 ATPase: alpha-N67I Deposited 2010-08-15 Different mutation/modification Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain J 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain K 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain L 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Mutation：N67I Mutation：N67I Mutation：N67I ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.20 Å R-free 0.276
3OFN Structure of four mutant forms of yeast F1 ATPase: alpha-N67I Deposited 2010-08-15 Different mutation/modification Different oligomeric state Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain S 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain T 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Chain U 36–545（510 aa） Fragment：UNP RESIDUES 36-545
Mutation：N67I Mutation：N67I Mutation：N67I ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.20 Å R-free 0.276
3ZIA The structure of F1-ATPase from Saccharomyces cerevisiae inhibited by its regulatory protein IF1 Deposited 2013-01-07 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric
Chain K 36–545（510 aa）
Chain L 36–545（510 aa）
Chain M 36–545（510 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 5 EDO 1,2-ETHANEDIOL × 5 X-RAY DIFFRACTION
X-ray crystallization conditions MICROBATCH；pH 7.5；296 K；ACTIVE F1-ATPASE (12 MG/ML) WAS EXCHANGED ON A DESALTING COLUMN INTO CRYSTALLISATION BUFFER, PREPARED IN D2O CONSISTING OF 100 MM BIS-TRIS PROPANE, PH 7.5, 100 MM SUCROSE, 1 MM ADP AND 10 MM MAGNESIUM SULPHATE. THEN THE ENZYME WAS INHIBITED AT 23C WITH A 4-FOLD MOLAR EXCESS OF YI1-53 (MUTATION E21A) IN THE PRESENCE OF 1 MM ATP AND 2 MM MAGNESIUM SULPHATE. FURTHER PORTIONS (5 UL OF A NEUTRALISED STOCK SOLUTION CONTAINING 200 MM ATP AND 400 MM MAGNESIUM SULPHATE/ML PROTEIN SOLUTION) WERE ADDED AFTER 5 AND 10 MIN. MORE THAN 95% OF THE ATP HYDROLYSIS ACTIVITY OF THE ENZYME WAS INHIBITED. SODIUM-POTASSIUM TARTRATE WAS ADDED TO 100 MM, AND THE CONCENTRATION OF THE PROTEIN SOLUTION WAS ADJUSTED TO 10 MG/ML WITH CRYSTALLISATION BUFFER. CRYSTALS WERE GROWN AT 23C IN 72 WELL MICRO-BATCH PLATES UNDER FILTERED PARAFFIN OIL. THE CRYSTALLISATION DROPS (4 UL) CONTAINED A 1:1 MIXTURE OF PROTEIN SOLUTION AND PRECIPITANT SOLUTION (20%-26% POLYETHYLENE GLYCOL 3000 AND 600 MM NACL PREPARED IN D2O).
Resolution 2.50 Å R-free 0.262
3ZIA The structure of F1-ATPase from Saccharomyces cerevisiae inhibited by its regulatory protein IF1 Deposited 2013-01-07 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 5 EDO 1,2-ETHANEDIOL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions MICROBATCH；pH 7.5；296 K；ACTIVE F1-ATPASE (12 MG/ML) WAS EXCHANGED ON A DESALTING COLUMN INTO CRYSTALLISATION BUFFER, PREPARED IN D2O CONSISTING OF 100 MM BIS-TRIS PROPANE, PH 7.5, 100 MM SUCROSE, 1 MM ADP AND 10 MM MAGNESIUM SULPHATE. THEN THE ENZYME WAS INHIBITED AT 23C WITH A 4-FOLD MOLAR EXCESS OF YI1-53 (MUTATION E21A) IN THE PRESENCE OF 1 MM ATP AND 2 MM MAGNESIUM SULPHATE. FURTHER PORTIONS (5 UL OF A NEUTRALISED STOCK SOLUTION CONTAINING 200 MM ATP AND 400 MM MAGNESIUM SULPHATE/ML PROTEIN SOLUTION) WERE ADDED AFTER 5 AND 10 MIN. MORE THAN 95% OF THE ATP HYDROLYSIS ACTIVITY OF THE ENZYME WAS INHIBITED. SODIUM-POTASSIUM TARTRATE WAS ADDED TO 100 MM, AND THE CONCENTRATION OF THE PROTEIN SOLUTION WAS ADJUSTED TO 10 MG/ML WITH CRYSTALLISATION BUFFER. CRYSTALS WERE GROWN AT 23C IN 72 WELL MICRO-BATCH PLATES UNDER FILTERED PARAFFIN OIL. THE CRYSTALLISATION DROPS (4 UL) CONTAINED A 1:1 MIXTURE OF PROTEIN SOLUTION AND PRECIPITANT SOLUTION (20%-26% POLYETHYLENE GLYCOL 3000 AND 600 MM NACL PREPARED IN D2O).
Resolution 2.50 Å R-free 0.262
3ZRY Rotor architecture in the F(1)-c(10)-ring complex of the yeast F-ATP synthase Deposited 2011-06-21 Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 6.5；10% PEG 4000, 100 MM SODIUM CHLORIDE, 100 MM HEPES PH 6.5 MIXED 1:1 WITH PROTEIN SOLUTION (10 MG/ML) CONTAINING 0.64 MM DDM, 25 MM TRIS PH 8.0, 100 MM SODIUM CHLORIDE, 25 MM TREHALOSE, 0.5 MM EDTA, 3 MM SODIUM AZIDE, 2 MM MAGNESIUM CHLORIDE, 0.04 MM ADP, 1 MM AMP-PNP, 0.1 MM DCCD, 2.5 MM DTT, 0.5 MM PMSF.
Resolution 6.50 Å R-free 0.339
4B2Q Model of the yeast F1Fo-ATP synthase dimer based on subtomogram average Deposited 2012-07-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 46 PDB declaration: 46-meric
Chain A 61–545（485 aa） Fragment：RESIDUES 61-545
Chain B 60–545（486 aa） Fragment：RESIDUES 60-545
Chain C 61–545（485 aa） Fragment：RESIDUES 61-545
Chain a 61–545（485 aa） Fragment：RESIDUES 61-545
Chain b 60–545（486 aa） Fragment：RESIDUES 60-545
Chain c 61–545（485 aa） Fragment：RESIDUES 61-545
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 10 ADP ADENOSINE-5'-DIPHOSPHATE × 4 ELECTRON MICROSCOPY
cryo-EM buffer 250MM TREHALOSE 10NM TRIS- HCL PH7.4；pH 7.4；250MM TREHALOSE 10NM TRIS- HCL PH7.4
cryo-EM vitrification conditions Cryogen ETHANE；VITRIFICATION 1 -- CRYOGEN- ETHANE, TEMPERATURE- 100, INSTRUMENT- HOMEMADE PLUNGER, METHOD- SINGLE SIDE MANUAL BLOTTING FOR 5 SECONDS.,
Resolution 37.00 Å
6B8H Mosaic model of yeast mitochondrial ATP synthase monomer Deposited 2017-10-07 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 60 PDB declaration: 60-meric
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Chain K 36–545（510 aa）
Chain W 36–545（510 aa）
Chain X 36–545（510 aa）
Chain n 36–545（510 aa）
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 10 MG MAGNESIUM ION × 10 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen NITROGEN
Resolution 3.60 Å
6CP3 Monomer yeast ATP synthase (F1Fo) reconstituted in nanodisc with inhibitor of oligomycin bound. Deposited 2018-03-13 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 ADP ADENOSINE-5'-DIPHOSPHATE × 2 ELECTRON MICROSCOPY
cryo-EM buffer pH 8；20 mM Tris-HCl, 150 mM NaCl, pH 8.0
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.80 Å
6CP6 Monomer yeast ATP synthase (F1Fo) reconstituted in nanodisc. Deposited 2018-03-13 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 ADP ADENOSINE-5'-DIPHOSPHATE × 2 ELECTRON MICROSCOPY
cryo-EM buffer pH 8；20 mM Tris-HCl, 150 mM NaCl, pH 8.0
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.60 Å
7TJT Yeast ATP synthase F1 region State 1-3catalytic beta_tight open without exogenous ATP Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 3 PO4 PHOSPHATE ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 3.20 Å
7TJU Yeast ATP synthase F1 region State 1-3binding beta_tight open without exogenous ATP Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 3 PO4 PHOSPHATE ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 3.30 Å
7TJV Yeast ATP synthase F1 region State 1catalytic(a) with 10 mM ATP Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 4 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 3.60 Å
7TJW Yeast ATP synthase F1 region State 1catalytic(e-h) with 10 mM ATP Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 5 MG MAGNESIUM ION × 5 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.00 Å
7TJX Yeast ATP synthase F1 region State 1binding(a-d) with 10 mM ATP Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 4 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 1 PO4 PHOSPHATE ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.00 Å
7TJY Yeast ATP synthase State 1catalytic(a) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 3.80 Å
7TJZ Yeast ATP synthase State 1catalytic(b) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.40 Å
7TK0 Yeast ATP synthase State 1catalytic(c) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.40 Å
7TK1 Yeast ATP synthase State 1catalytic(d) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TK2 Yeast ATP synthase State 1binding(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.50 Å
7TK3 Yeast ATP synthase State 1binding(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.30 Å
7TK4 Yeast ATP synthase State 1binding(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.00 Å
7TK5 Yeast ATP synthase State 1binding(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.80 Å
7TK6 Yeast ATP synthase State 1catalytic(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.50 Å
7TK7 Yeast ATP synthase State 1catalytic(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.70 Å
7TK8 Yeast ATP synthase State 1catalytic(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.70 Å
7TK9 Yeast ATP synthase State 1catalytic(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.00 Å
7TKA Yeast ATP synthase State 1catalytic(e) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKB Yeast ATP synthase State 1catalytic(f) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.30 Å
7TKC Yeast ATP synthase State 1catalytic(g) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 5.80 Å
7TKD Yeast ATP synthase State 1catalytic(h) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.70 Å
7TKE Yeast ATP synthase State 2binding(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKF Yeast ATP synthase State 2binding(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKG Yeast ATP synthase State 2catalytic(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.50 Å
7TKH Yeast ATP synthase State 2catalytic(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.40 Å
7TKI Yeast ATP synthase State 2catalytic(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKJ Yeast ATP synthase State 2catalytic(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.50 Å
7TKK Yeast ATP synthase State 2catalytic(e) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.30 Å
7TKL Yeast ATP synthase State 3binding(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.40 Å
7TKM Yeast ATP synthase State 3binding(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.50 Å
7TKN Yeast ATP synthase State 3binding(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKO Yeast ATP synthase State 3catalytic(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.80 Å
7TKP Yeast ATP synthase State 3catalytic(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.60 Å
7TKQ Yeast ATP synthase State 3catalytic(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.50 Å
7TKR Yeast ATP synthase State 3catalytic(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.50 Å
7TKS Yeast ATP synthase State 3catalytic(e) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 36–545（510 aa）
Chain B 36–545（510 aa）
Chain C 36–545（510 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.50 Å
8F29 Yeast ATP synthase in conformation-1 at pH 6 Deposited 2022-11-07 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 39–545（507 aa）
Chain B 39–545（507 aa）
Chain C 39–545（507 aa）
Not recorded ADP ADENOSINE-5'-DIPHOSPHATE × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 6
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 4.00 Å
8F39 Yeast ATP synthase in conformation-2, at pH 6 Deposited 2022-11-09 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain A 39–545（507 aa）
Chain B 39–545（507 aa）
Chain C 39–545（507 aa）
Not recorded ADP ADENOSINE-5'-DIPHOSPHATE × 5 MG MAGNESIUM ION × 4 ELECTRON MICROSCOPY
cryo-EM buffer pH 6
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.50 Å

51 other PDB entries and 62 assemblies. Open the comparison page and filter oligomeric states

View Construct and Data Evidence
UniProt name ATPA_YEAST
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 1–510； UniProt 36–545 Author chain B； PDBConstruct 1–510； UniProt 36–545 Author chain C； PDBConstruct 1–510； UniProt 36–545 Author chain J； PDBConstruct 1–510； UniProt 36–545 Author chain K； PDBConstruct 1–510； UniProt 36–545 Author chain L； PDBConstruct 1–510； UniProt 36–545 Author chain S； PDBConstruct 1–510； UniProt 36–545 Author chain T； PDBConstruct 1–510； UniProt 36–545 Author chain U； PDBConstruct 1–510； UniProt 36–545

ATP synthase subunit beta

Saccharomyces cerevisiae

UniProt P00830

State in the Current Structure

Assembly Oligomeric State Construct Mutations and Modifications Ligands, Ions and Associated Components Method and Experimental Conditions Structure Quality
1 Protein heterocomplex Heteromer Protein × 9 PDB declaration: nonameric（9） Consistent with protein copy count Chain D； UniProt 36–511 Chain E； UniProt 36–511 Chain F； UniProt 36–511 Fragment：UNP RESIDUES 34-511 ATP synthase subunit alpha × 3 （P07251） ATP synthase subunit gamma × 1 （P38077） ATP synthase subunit delta × 1 （Q12165） ATP synthase subunit epsilon × 1 （P21306） ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION X-ray crystallization conditions：pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K Resolution 2.74 Å R-free 0.259
2 Protein heterocomplex Heteromer Protein × 9 PDB declaration: nonameric（9） Consistent with protein copy count Chain M； UniProt 36–511 Chain N； UniProt 36–511 Chain O； UniProt 36–511 Fragment：UNP RESIDUES 34-511 ATP synthase subunit alpha × 3 （P07251） ATP synthase subunit gamma × 1 （P38077） ATP synthase subunit delta × 1 （Q12165） ATP synthase subunit epsilon × 1 （P21306） ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION X-ray crystallization conditions：pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K Resolution 2.74 Å R-free 0.259
3 Protein heterocomplex Heteromer Protein × 9 PDB declaration: nonameric（9） Consistent with protein copy count Chain V； UniProt 36–511 Chain W； UniProt 36–511 Chain X； UniProt 36–511 Fragment：UNP RESIDUES 34-511 ATP synthase subunit alpha × 3 （P07251） ATP synthase subunit gamma × 1 （P38077） ATP synthase subunit delta × 1 （Q12165） ATP synthase subunit epsilon × 1 （P21306） ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION X-ray crystallization conditions：pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K Resolution 2.74 Å R-free 0.259

Other States of the Same Protein in the Database

Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.

Other PDB Difference from Current Entry 3OEE Assembly / Oligomeric State Construct Mutations and Modifications Ligands, Ions and Non-polymers Method and Experimental Conditions Structure Quality
2HLD Crystal structure of yeast mitochondrial F1-ATPase Deposited 2006-07-06 Different construct Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded MG MAGNESIUM ION × 5 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% glycerol, 4% methanol, 0.05M sodium acetate, 0.5mM nickel sulphate, 0.5mM AMP/PNP, 0.025 mM ADP, 2mM magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 2.80 Å R-free 0.244
2HLD Crystal structure of yeast mitochondrial F1-ATPase Deposited 2006-07-06 Different construct Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain M 34–511（478 aa）
Chain N 34–511（478 aa）
Chain O 34–511（478 aa）
Not recorded MG MAGNESIUM ION × 5 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% glycerol, 4% methanol, 0.05M sodium acetate, 0.5mM nickel sulphate, 0.5mM AMP/PNP, 0.025 mM ADP, 2mM magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 2.80 Å R-free 0.244
2HLD Crystal structure of yeast mitochondrial F1-ATPase Deposited 2006-07-06 Different construct Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain V 34–511（478 aa）
Chain W 34–511（478 aa）
Chain X 34–511（478 aa）
Not recorded MG MAGNESIUM ION × 5 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% glycerol, 4% methanol, 0.05M sodium acetate, 0.5mM nickel sulphate, 0.5mM AMP/PNP, 0.025 mM ADP, 2mM magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 2.80 Å R-free 0.244
2WPD The Mg.ADP inhibited state of the yeast F1c10 ATP synthase Deposited 2009-08-05 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 19 PDB declaration: nonadecameric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 2 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.5；0.1 M HEPES/HCL PH 7.5, 12% PEG MME 5000, 100 MM SODIUM CHLORIDE MIXED 1:1 WITH PROTEIN SOLUTION CONTAINING 0.64 MM DDM, 25 MM TRIS/HCL PH 8.0, 100 MM SODIUM CHLORIDE, 25 MM TREHALOSE, 0.5 MM EDTA, 0.02% SODIUM AZIDE, 2 MM MAGNESIUM CHLORIDE, 0.66 MM ADP, 0.1 MM DCCD, 2.5 MM DTT, 0.5 MM PMSF
Resolution 3.43 Å R-free 0.297
2XOK Refined structure of yeast F1c10 ATPase complex to 3 A resolution Deposited 2010-08-18 Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 19 PDB declaration: nonadecameric
Chain D 1–507（507 aa）
Chain E 1–507（507 aa）
Chain F 1–507（507 aa）
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions MICROBATCH；pH 8；0.1 M TRIS/CL PH8.0, 12% PEG 6000, 150 MM NACL, 1 MM AMP-PNP, 40 MICROM ADP, 1 MM DTT, 0.02% NAN3. MIXED 1:1 WITH PROTEIN SOLUTION UNDER PARAFFIN OIL IN MICROBATCH PLATE.
Resolution 3.01 Å R-free 0.253
3FKS Yeast F1 ATPase in the absence of bound nucleotides Deposited 2008-12-17 Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain D 34–511（478 aa） Fragment：UNP residues 34-511
Chain E 34–511（478 aa） Fragment：UNP residues 34-511
Chain F 34–511（478 aa） Fragment：UNP residues 34-511
Not recorded PO4 PHOSPHATE ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；6.25% PEG 6000, 10% Glycerol, 4% Methanol, 0.05M Sodium acetate, 0.5mM Nickel sulfate, 2 mM Sodium pyrophosphate, 2mM Magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277.0K
Resolution 3.59 Å R-free 0.306
3FKS Yeast F1 ATPase in the absence of bound nucleotides Deposited 2008-12-17 Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain M 34–511（478 aa） Fragment：UNP residues 34-511
Chain N 34–511（478 aa） Fragment：UNP residues 34-511
Chain O 34–511（478 aa） Fragment：UNP residues 34-511
Not recorded PO4 PHOSPHATE ION × 6 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；6.25% PEG 6000, 10% Glycerol, 4% Methanol, 0.05M Sodium acetate, 0.5mM Nickel sulfate, 2 mM Sodium pyrophosphate, 2mM Magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277.0K
Resolution 3.59 Å R-free 0.306
3FKS Yeast F1 ATPase in the absence of bound nucleotides Deposited 2008-12-17 Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain V 34–511（478 aa） Fragment：UNP residues 34-511
Chain W 34–511（478 aa） Fragment：UNP residues 34-511
Chain X 34–511（478 aa） Fragment：UNP residues 34-511
Not recorded PO4 PHOSPHATE ION × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；6.25% PEG 6000, 10% Glycerol, 4% Methanol, 0.05M Sodium acetate, 0.5mM Nickel sulfate, 2 mM Sodium pyrophosphate, 2mM Magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277.0K
Resolution 3.59 Å R-free 0.306
3OE7 Structure of four mutant forms of yeast f1 ATPase: gamma-I270T Deposited 2010-08-12 Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain D 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain E 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain F 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, PH 7.3, VAPOR DIFFUSION SITTING DROP, TEMPERATURE 277K
Resolution 3.19 Å R-free 0.245
3OE7 Structure of four mutant forms of yeast f1 ATPase: gamma-I270T Deposited 2010-08-12 Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain M 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain N 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain O 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, PH 7.3, VAPOR DIFFUSION SITTING DROP, TEMPERATURE 277K
Resolution 3.19 Å R-free 0.245
3OE7 Structure of four mutant forms of yeast f1 ATPase: gamma-I270T Deposited 2010-08-12 Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain V 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain W 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain X 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, PH 7.3, VAPOR DIFFUSION SITTING DROP, TEMPERATURE 277K
Resolution 3.19 Å R-free 0.245
3OEH Structure of four mutant forms of yeast F1 ATPase: beta-V279F Deposited 2010-08-12 Different mutation/modification Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain D 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain E 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain F 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Mutation：V279F Mutation：V279F Mutation：V279F ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.00 Å R-free 0.270
3OEH Structure of four mutant forms of yeast F1 ATPase: beta-V279F Deposited 2010-08-12 Different mutation/modification Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain M 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain N 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain O 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Mutation：V279F Mutation：V279F Mutation：V279F ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.00 Å R-free 0.270
3OEH Structure of four mutant forms of yeast F1 ATPase: beta-V279F Deposited 2010-08-12 Different mutation/modification Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain V 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain W 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain X 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Mutation：V279F Mutation：V279F Mutation：V279F ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.00 Å R-free 0.270
3OFN Structure of four mutant forms of yeast F1 ATPase: alpha-N67I Deposited 2010-08-15 Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain D 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain E 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain F 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.20 Å R-free 0.276
3OFN Structure of four mutant forms of yeast F1 ATPase: alpha-N67I Deposited 2010-08-15 Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain M 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain N 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain O 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.20 Å R-free 0.276
3OFN Structure of four mutant forms of yeast F1 ATPase: alpha-N67I Deposited 2010-08-15 Different oligomeric state Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain V 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain W 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Chain X 36–511（476 aa） Fragment：UNP RESIDUES 34-511
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.20 Å R-free 0.276
3ZIA The structure of F1-ATPase from Saccharomyces cerevisiae inhibited by its regulatory protein IF1 Deposited 2013-01-07 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric
Chain N 34–511（478 aa）
Chain O 34–511（478 aa）
Chain P 34–511（478 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 5 EDO 1,2-ETHANEDIOL × 5 X-RAY DIFFRACTION
X-ray crystallization conditions MICROBATCH；pH 7.5；296 K；ACTIVE F1-ATPASE (12 MG/ML) WAS EXCHANGED ON A DESALTING COLUMN INTO CRYSTALLISATION BUFFER, PREPARED IN D2O CONSISTING OF 100 MM BIS-TRIS PROPANE, PH 7.5, 100 MM SUCROSE, 1 MM ADP AND 10 MM MAGNESIUM SULPHATE. THEN THE ENZYME WAS INHIBITED AT 23C WITH A 4-FOLD MOLAR EXCESS OF YI1-53 (MUTATION E21A) IN THE PRESENCE OF 1 MM ATP AND 2 MM MAGNESIUM SULPHATE. FURTHER PORTIONS (5 UL OF A NEUTRALISED STOCK SOLUTION CONTAINING 200 MM ATP AND 400 MM MAGNESIUM SULPHATE/ML PROTEIN SOLUTION) WERE ADDED AFTER 5 AND 10 MIN. MORE THAN 95% OF THE ATP HYDROLYSIS ACTIVITY OF THE ENZYME WAS INHIBITED. SODIUM-POTASSIUM TARTRATE WAS ADDED TO 100 MM, AND THE CONCENTRATION OF THE PROTEIN SOLUTION WAS ADJUSTED TO 10 MG/ML WITH CRYSTALLISATION BUFFER. CRYSTALS WERE GROWN AT 23C IN 72 WELL MICRO-BATCH PLATES UNDER FILTERED PARAFFIN OIL. THE CRYSTALLISATION DROPS (4 UL) CONTAINED A 1:1 MIXTURE OF PROTEIN SOLUTION AND PRECIPITANT SOLUTION (20%-26% POLYETHYLENE GLYCOL 3000 AND 600 MM NACL PREPARED IN D2O).
Resolution 2.50 Å R-free 0.262
3ZIA The structure of F1-ATPase from Saccharomyces cerevisiae inhibited by its regulatory protein IF1 Deposited 2013-01-07 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 5 EDO 1,2-ETHANEDIOL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions MICROBATCH；pH 7.5；296 K；ACTIVE F1-ATPASE (12 MG/ML) WAS EXCHANGED ON A DESALTING COLUMN INTO CRYSTALLISATION BUFFER, PREPARED IN D2O CONSISTING OF 100 MM BIS-TRIS PROPANE, PH 7.5, 100 MM SUCROSE, 1 MM ADP AND 10 MM MAGNESIUM SULPHATE. THEN THE ENZYME WAS INHIBITED AT 23C WITH A 4-FOLD MOLAR EXCESS OF YI1-53 (MUTATION E21A) IN THE PRESENCE OF 1 MM ATP AND 2 MM MAGNESIUM SULPHATE. FURTHER PORTIONS (5 UL OF A NEUTRALISED STOCK SOLUTION CONTAINING 200 MM ATP AND 400 MM MAGNESIUM SULPHATE/ML PROTEIN SOLUTION) WERE ADDED AFTER 5 AND 10 MIN. MORE THAN 95% OF THE ATP HYDROLYSIS ACTIVITY OF THE ENZYME WAS INHIBITED. SODIUM-POTASSIUM TARTRATE WAS ADDED TO 100 MM, AND THE CONCENTRATION OF THE PROTEIN SOLUTION WAS ADJUSTED TO 10 MG/ML WITH CRYSTALLISATION BUFFER. CRYSTALS WERE GROWN AT 23C IN 72 WELL MICRO-BATCH PLATES UNDER FILTERED PARAFFIN OIL. THE CRYSTALLISATION DROPS (4 UL) CONTAINED A 1:1 MIXTURE OF PROTEIN SOLUTION AND PRECIPITANT SOLUTION (20%-26% POLYETHYLENE GLYCOL 3000 AND 600 MM NACL PREPARED IN D2O).
Resolution 2.50 Å R-free 0.262
3ZRY Rotor architecture in the F(1)-c(10)-ring complex of the yeast F-ATP synthase Deposited 2011-06-21 Different construct Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 6.5；10% PEG 4000, 100 MM SODIUM CHLORIDE, 100 MM HEPES PH 6.5 MIXED 1:1 WITH PROTEIN SOLUTION (10 MG/ML) CONTAINING 0.64 MM DDM, 25 MM TRIS PH 8.0, 100 MM SODIUM CHLORIDE, 25 MM TREHALOSE, 0.5 MM EDTA, 3 MM SODIUM AZIDE, 2 MM MAGNESIUM CHLORIDE, 0.04 MM ADP, 1 MM AMP-PNP, 0.1 MM DCCD, 2.5 MM DTT, 0.5 MM PMSF.
Resolution 6.50 Å R-free 0.339
4B2Q Model of the yeast F1Fo-ATP synthase dimer based on subtomogram average Deposited 2012-07-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 46 PDB declaration: 46-meric
Chain D 39–508（470 aa） Fragment：RESIDUES 39-508
Chain E 39–511（473 aa） Fragment：RESIDUES 39-511
Chain F 39–511（473 aa） Fragment：RESIDUES 39-511
Chain d 39–508（470 aa） Fragment：RESIDUES 39-508
Chain e 39–511（473 aa） Fragment：RESIDUES 39-511
Chain f 39–511（473 aa） Fragment：RESIDUES 39-511
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 10 ADP ADENOSINE-5'-DIPHOSPHATE × 4 ELECTRON MICROSCOPY
cryo-EM buffer 250MM TREHALOSE 10NM TRIS- HCL PH7.4；pH 7.4；250MM TREHALOSE 10NM TRIS- HCL PH7.4
cryo-EM vitrification conditions Cryogen ETHANE；VITRIFICATION 1 -- CRYOGEN- ETHANE, TEMPERATURE- 100, INSTRUMENT- HOMEMADE PLUNGER, METHOD- SINGLE SIDE MANUAL BLOTTING FOR 5 SECONDS.,
Resolution 37.00 Å
6B8H Mosaic model of yeast mitochondrial ATP synthase monomer Deposited 2017-10-07 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 60 PDB declaration: 60-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Chain Y 34–511（478 aa）
Chain Z 34–511（478 aa）
Chain c 34–511（478 aa）
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 10 MG MAGNESIUM ION × 10 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen NITROGEN
Resolution 3.60 Å
6CP3 Monomer yeast ATP synthase (F1Fo) reconstituted in nanodisc with inhibitor of oligomycin bound. Deposited 2018-03-13 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 ADP ADENOSINE-5'-DIPHOSPHATE × 2 ELECTRON MICROSCOPY
cryo-EM buffer pH 8；20 mM Tris-HCl, 150 mM NaCl, pH 8.0
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.80 Å
6CP6 Monomer yeast ATP synthase (F1Fo) reconstituted in nanodisc. Deposited 2018-03-13 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 ADP ADENOSINE-5'-DIPHOSPHATE × 2 ELECTRON MICROSCOPY
cryo-EM buffer pH 8；20 mM Tris-HCl, 150 mM NaCl, pH 8.0
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.60 Å
7TJT Yeast ATP synthase F1 region State 1-3catalytic beta_tight open without exogenous ATP Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 3 PO4 PHOSPHATE ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 3.20 Å
7TJU Yeast ATP synthase F1 region State 1-3binding beta_tight open without exogenous ATP Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 3 PO4 PHOSPHATE ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 3.30 Å
7TJV Yeast ATP synthase F1 region State 1catalytic(a) with 10 mM ATP Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 4 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 3.60 Å
7TJW Yeast ATP synthase F1 region State 1catalytic(e-h) with 10 mM ATP Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 5 MG MAGNESIUM ION × 5 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.00 Å
7TJX Yeast ATP synthase F1 region State 1binding(a-d) with 10 mM ATP Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 4 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 1 PO4 PHOSPHATE ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.00 Å
7TJY Yeast ATP synthase State 1catalytic(a) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 3.80 Å
7TJZ Yeast ATP synthase State 1catalytic(b) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.40 Å
7TK0 Yeast ATP synthase State 1catalytic(c) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.40 Å
7TK1 Yeast ATP synthase State 1catalytic(d) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TK2 Yeast ATP synthase State 1binding(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.50 Å
7TK3 Yeast ATP synthase State 1binding(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.30 Å
7TK4 Yeast ATP synthase State 1binding(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.00 Å
7TK5 Yeast ATP synthase State 1binding(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.80 Å
7TK6 Yeast ATP synthase State 1catalytic(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.50 Å
7TK7 Yeast ATP synthase State 1catalytic(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.70 Å
7TK8 Yeast ATP synthase State 1catalytic(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.70 Å
7TK9 Yeast ATP synthase State 1catalytic(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.00 Å
7TKA Yeast ATP synthase State 1catalytic(e) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKB Yeast ATP synthase State 1catalytic(f) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.30 Å
7TKC Yeast ATP synthase State 1catalytic(g) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 5.80 Å
7TKD Yeast ATP synthase State 1catalytic(h) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.70 Å
7TKE Yeast ATP synthase State 2binding(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKF Yeast ATP synthase State 2binding(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKG Yeast ATP synthase State 2catalytic(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.50 Å
7TKH Yeast ATP synthase State 2catalytic(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.40 Å
7TKI Yeast ATP synthase State 2catalytic(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKJ Yeast ATP synthase State 2catalytic(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.50 Å
7TKK Yeast ATP synthase State 2catalytic(e) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.30 Å
7TKL Yeast ATP synthase State 3binding(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.40 Å
7TKM Yeast ATP synthase State 3binding(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.50 Å
7TKN Yeast ATP synthase State 3binding(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKO Yeast ATP synthase State 3catalytic(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.80 Å
7TKP Yeast ATP synthase State 3catalytic(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.60 Å
7TKQ Yeast ATP synthase State 3catalytic(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.50 Å
7TKR Yeast ATP synthase State 3catalytic(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.50 Å
7TKS Yeast ATP synthase State 3catalytic(e) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 34–511（478 aa）
Chain E 34–511（478 aa）
Chain F 34–511（478 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.50 Å
8F29 Yeast ATP synthase in conformation-1 at pH 6 Deposited 2022-11-07 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 39–511（473 aa）
Chain E 39–511（473 aa）
Chain F 39–511（473 aa）
Not recorded ADP ADENOSINE-5'-DIPHOSPHATE × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 6
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 4.00 Å
8F39 Yeast ATP synthase in conformation-2, at pH 6 Deposited 2022-11-09 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain D 39–511（473 aa）
Chain E 39–511（473 aa）
Chain F 39–511（473 aa）
Not recorded ADP ADENOSINE-5'-DIPHOSPHATE × 5 MG MAGNESIUM ION × 4 ELECTRON MICROSCOPY
cryo-EM buffer pH 6
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.50 Å

51 other PDB entries and 62 assemblies. Open the comparison page and filter oligomeric states

View Construct and Data Evidence
UniProt name ATPB_YEAST
Isoform —
PDB entities 2
Chains and sequence ranges Author chain D； PDBConstruct 9–484； UniProt 36–511 Author chain E； PDBConstruct 9–484； UniProt 36–511 Author chain F； PDBConstruct 9–484； UniProt 36–511 Author chain M； PDBConstruct 9–484； UniProt 36–511 Author chain N； PDBConstruct 9–484； UniProt 36–511 Author chain O； PDBConstruct 9–484； UniProt 36–511 Author chain V； PDBConstruct 9–484； UniProt 36–511 Author chain W； PDBConstruct 9–484； UniProt 36–511 Author chain X； PDBConstruct 9–484； UniProt 36–511

ATP synthase subunit gamma

Saccharomyces cerevisiae

UniProt P38077

State in the Current Structure

Assembly Oligomeric State Construct Mutations and Modifications Ligands, Ions and Associated Components Method and Experimental Conditions Structure Quality
1 Protein heterocomplex Heteromer Protein × 9 PDB declaration: nonameric（9） Consistent with protein copy count Chain G； UniProt 34–311 Fragment：UNP RESIDUES 34-311 ATP synthase subunit alpha × 3 （P07251） ATP synthase subunit beta × 3 （P00830） ATP synthase subunit delta × 1 （Q12165） ATP synthase subunit epsilon × 1 （P21306） ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION X-ray crystallization conditions：pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K Resolution 2.74 Å R-free 0.259
2 Protein heterocomplex Heteromer Protein × 9 PDB declaration: nonameric（9） Consistent with protein copy count Chain P； UniProt 34–311 Fragment：UNP RESIDUES 34-311 ATP synthase subunit alpha × 3 （P07251） ATP synthase subunit beta × 3 （P00830） ATP synthase subunit delta × 1 （Q12165） ATP synthase subunit epsilon × 1 （P21306） ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION X-ray crystallization conditions：pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K Resolution 2.74 Å R-free 0.259
3 Protein heterocomplex Heteromer Protein × 9 PDB declaration: nonameric（9） Consistent with protein copy count Chain Y； UniProt 34–311 Fragment：UNP RESIDUES 34-311 ATP synthase subunit alpha × 3 （P07251） ATP synthase subunit beta × 3 （P00830） ATP synthase subunit delta × 1 （Q12165） ATP synthase subunit epsilon × 1 （P21306） ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION X-ray crystallization conditions：pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K Resolution 2.74 Å R-free 0.259

Other States of the Same Protein in the Database

Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.

Other PDB Difference from Current Entry 3OEE Assembly / Oligomeric State Construct Mutations and Modifications Ligands, Ions and Non-polymers Method and Experimental Conditions Structure Quality
2HLD Crystal structure of yeast mitochondrial F1-ATPase Deposited 2006-07-06 Different construct Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain G 34–311（278 aa）
Not recorded MG MAGNESIUM ION × 5 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% glycerol, 4% methanol, 0.05M sodium acetate, 0.5mM nickel sulphate, 0.5mM AMP/PNP, 0.025 mM ADP, 2mM magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 2.80 Å R-free 0.244
2HLD Crystal structure of yeast mitochondrial F1-ATPase Deposited 2006-07-06 Different construct Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain P 34–311（278 aa）
Not recorded MG MAGNESIUM ION × 5 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% glycerol, 4% methanol, 0.05M sodium acetate, 0.5mM nickel sulphate, 0.5mM AMP/PNP, 0.025 mM ADP, 2mM magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 2.80 Å R-free 0.244
2HLD Crystal structure of yeast mitochondrial F1-ATPase Deposited 2006-07-06 Different construct Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain Y 34–311（278 aa）
Not recorded MG MAGNESIUM ION × 5 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% glycerol, 4% methanol, 0.05M sodium acetate, 0.5mM nickel sulphate, 0.5mM AMP/PNP, 0.025 mM ADP, 2mM magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 2.80 Å R-free 0.244
2WPD The Mg.ADP inhibited state of the yeast F1c10 ATP synthase Deposited 2009-08-05 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 19 PDB declaration: nonadecameric
Chain G 34–311（278 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 2 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.5；0.1 M HEPES/HCL PH 7.5, 12% PEG MME 5000, 100 MM SODIUM CHLORIDE MIXED 1:1 WITH PROTEIN SOLUTION CONTAINING 0.64 MM DDM, 25 MM TRIS/HCL PH 8.0, 100 MM SODIUM CHLORIDE, 25 MM TREHALOSE, 0.5 MM EDTA, 0.02% SODIUM AZIDE, 2 MM MAGNESIUM CHLORIDE, 0.66 MM ADP, 0.1 MM DCCD, 2.5 MM DTT, 0.5 MM PMSF
Resolution 3.43 Å R-free 0.297
2XOK Refined structure of yeast F1c10 ATPase complex to 3 A resolution Deposited 2010-08-18 Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 19 PDB declaration: nonadecameric
Chain G 1–311（311 aa）
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions MICROBATCH；pH 8；0.1 M TRIS/CL PH8.0, 12% PEG 6000, 150 MM NACL, 1 MM AMP-PNP, 40 MICROM ADP, 1 MM DTT, 0.02% NAN3. MIXED 1:1 WITH PROTEIN SOLUTION UNDER PARAFFIN OIL IN MICROBATCH PLATE.
Resolution 3.01 Å R-free 0.253
3FKS Yeast F1 ATPase in the absence of bound nucleotides Deposited 2008-12-17 Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain G 34–311（278 aa） Fragment：UNP residues 34-311
Not recorded PO4 PHOSPHATE ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；6.25% PEG 6000, 10% Glycerol, 4% Methanol, 0.05M Sodium acetate, 0.5mM Nickel sulfate, 2 mM Sodium pyrophosphate, 2mM Magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277.0K
Resolution 3.59 Å R-free 0.306
3FKS Yeast F1 ATPase in the absence of bound nucleotides Deposited 2008-12-17 Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain P 34–311（278 aa） Fragment：UNP residues 34-311
Not recorded PO4 PHOSPHATE ION × 6 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；6.25% PEG 6000, 10% Glycerol, 4% Methanol, 0.05M Sodium acetate, 0.5mM Nickel sulfate, 2 mM Sodium pyrophosphate, 2mM Magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277.0K
Resolution 3.59 Å R-free 0.306
3FKS Yeast F1 ATPase in the absence of bound nucleotides Deposited 2008-12-17 Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain Y 34–311（278 aa） Fragment：UNP residues 34-311
Not recorded PO4 PHOSPHATE ION × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；6.25% PEG 6000, 10% Glycerol, 4% Methanol, 0.05M Sodium acetate, 0.5mM Nickel sulfate, 2 mM Sodium pyrophosphate, 2mM Magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277.0K
Resolution 3.59 Å R-free 0.306
3OE7 Structure of four mutant forms of yeast f1 ATPase: gamma-I270T Deposited 2010-08-12 Different mutation/modification Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain G 34–311（278 aa） Fragment：UNP RESIDUES 34-311
Mutation：I270T ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, PH 7.3, VAPOR DIFFUSION SITTING DROP, TEMPERATURE 277K
Resolution 3.19 Å R-free 0.245
3OE7 Structure of four mutant forms of yeast f1 ATPase: gamma-I270T Deposited 2010-08-12 Different mutation/modification Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain P 34–311（278 aa） Fragment：UNP RESIDUES 34-311
Mutation：I270T ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, PH 7.3, VAPOR DIFFUSION SITTING DROP, TEMPERATURE 277K
Resolution 3.19 Å R-free 0.245
3OE7 Structure of four mutant forms of yeast f1 ATPase: gamma-I270T Deposited 2010-08-12 Different mutation/modification Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain Y 34–311（278 aa） Fragment：UNP RESIDUES 34-311
Mutation：I270T ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, PH 7.3, VAPOR DIFFUSION SITTING DROP, TEMPERATURE 277K
Resolution 3.19 Å R-free 0.245
3OEH Structure of four mutant forms of yeast F1 ATPase: beta-V279F Deposited 2010-08-12 Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain G 34–311（278 aa） Fragment：UNP RESIDUES 34-311
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.00 Å R-free 0.270
3OEH Structure of four mutant forms of yeast F1 ATPase: beta-V279F Deposited 2010-08-12 Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain P 34–311（278 aa） Fragment：UNP RESIDUES 34-311
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.00 Å R-free 0.270
3OEH Structure of four mutant forms of yeast F1 ATPase: beta-V279F Deposited 2010-08-12 Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain Y 34–311（278 aa） Fragment：UNP RESIDUES 34-311
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.00 Å R-free 0.270
3OFN Structure of four mutant forms of yeast F1 ATPase: alpha-N67I Deposited 2010-08-15 Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain G 34–311（278 aa） Fragment：UNP RESIDUES 34-311
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.20 Å R-free 0.276
3OFN Structure of four mutant forms of yeast F1 ATPase: alpha-N67I Deposited 2010-08-15 Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain P 34–311（278 aa） Fragment：UNP RESIDUES 34-311
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.20 Å R-free 0.276
3OFN Structure of four mutant forms of yeast F1 ATPase: alpha-N67I Deposited 2010-08-15 Different oligomeric state Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain Y 34–311（278 aa） Fragment：UNP RESIDUES 34-311
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.20 Å R-free 0.276
3ZIA The structure of F1-ATPase from Saccharomyces cerevisiae inhibited by its regulatory protein IF1 Deposited 2013-01-07 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric
Chain Q 34–311（278 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 5 EDO 1,2-ETHANEDIOL × 5 X-RAY DIFFRACTION
X-ray crystallization conditions MICROBATCH；pH 7.5；296 K；ACTIVE F1-ATPASE (12 MG/ML) WAS EXCHANGED ON A DESALTING COLUMN INTO CRYSTALLISATION BUFFER, PREPARED IN D2O CONSISTING OF 100 MM BIS-TRIS PROPANE, PH 7.5, 100 MM SUCROSE, 1 MM ADP AND 10 MM MAGNESIUM SULPHATE. THEN THE ENZYME WAS INHIBITED AT 23C WITH A 4-FOLD MOLAR EXCESS OF YI1-53 (MUTATION E21A) IN THE PRESENCE OF 1 MM ATP AND 2 MM MAGNESIUM SULPHATE. FURTHER PORTIONS (5 UL OF A NEUTRALISED STOCK SOLUTION CONTAINING 200 MM ATP AND 400 MM MAGNESIUM SULPHATE/ML PROTEIN SOLUTION) WERE ADDED AFTER 5 AND 10 MIN. MORE THAN 95% OF THE ATP HYDROLYSIS ACTIVITY OF THE ENZYME WAS INHIBITED. SODIUM-POTASSIUM TARTRATE WAS ADDED TO 100 MM, AND THE CONCENTRATION OF THE PROTEIN SOLUTION WAS ADJUSTED TO 10 MG/ML WITH CRYSTALLISATION BUFFER. CRYSTALS WERE GROWN AT 23C IN 72 WELL MICRO-BATCH PLATES UNDER FILTERED PARAFFIN OIL. THE CRYSTALLISATION DROPS (4 UL) CONTAINED A 1:1 MIXTURE OF PROTEIN SOLUTION AND PRECIPITANT SOLUTION (20%-26% POLYETHYLENE GLYCOL 3000 AND 600 MM NACL PREPARED IN D2O).
Resolution 2.50 Å R-free 0.262
3ZIA The structure of F1-ATPase from Saccharomyces cerevisiae inhibited by its regulatory protein IF1 Deposited 2013-01-07 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric
Chain G 34–311（278 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 5 EDO 1,2-ETHANEDIOL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions MICROBATCH；pH 7.5；296 K；ACTIVE F1-ATPASE (12 MG/ML) WAS EXCHANGED ON A DESALTING COLUMN INTO CRYSTALLISATION BUFFER, PREPARED IN D2O CONSISTING OF 100 MM BIS-TRIS PROPANE, PH 7.5, 100 MM SUCROSE, 1 MM ADP AND 10 MM MAGNESIUM SULPHATE. THEN THE ENZYME WAS INHIBITED AT 23C WITH A 4-FOLD MOLAR EXCESS OF YI1-53 (MUTATION E21A) IN THE PRESENCE OF 1 MM ATP AND 2 MM MAGNESIUM SULPHATE. FURTHER PORTIONS (5 UL OF A NEUTRALISED STOCK SOLUTION CONTAINING 200 MM ATP AND 400 MM MAGNESIUM SULPHATE/ML PROTEIN SOLUTION) WERE ADDED AFTER 5 AND 10 MIN. MORE THAN 95% OF THE ATP HYDROLYSIS ACTIVITY OF THE ENZYME WAS INHIBITED. SODIUM-POTASSIUM TARTRATE WAS ADDED TO 100 MM, AND THE CONCENTRATION OF THE PROTEIN SOLUTION WAS ADJUSTED TO 10 MG/ML WITH CRYSTALLISATION BUFFER. CRYSTALS WERE GROWN AT 23C IN 72 WELL MICRO-BATCH PLATES UNDER FILTERED PARAFFIN OIL. THE CRYSTALLISATION DROPS (4 UL) CONTAINED A 1:1 MIXTURE OF PROTEIN SOLUTION AND PRECIPITANT SOLUTION (20%-26% POLYETHYLENE GLYCOL 3000 AND 600 MM NACL PREPARED IN D2O).
Resolution 2.50 Å R-free 0.262
3ZRY Rotor architecture in the F(1)-c(10)-ring complex of the yeast F-ATP synthase Deposited 2011-06-21 Different construct Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain G 34–311（278 aa）
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 6.5；10% PEG 4000, 100 MM SODIUM CHLORIDE, 100 MM HEPES PH 6.5 MIXED 1:1 WITH PROTEIN SOLUTION (10 MG/ML) CONTAINING 0.64 MM DDM, 25 MM TRIS PH 8.0, 100 MM SODIUM CHLORIDE, 25 MM TREHALOSE, 0.5 MM EDTA, 3 MM SODIUM AZIDE, 2 MM MAGNESIUM CHLORIDE, 0.04 MM ADP, 1 MM AMP-PNP, 0.1 MM DCCD, 2.5 MM DTT, 0.5 MM PMSF.
Resolution 6.50 Å R-free 0.339
4B2Q Model of the yeast F1Fo-ATP synthase dimer based on subtomogram average Deposited 2012-07-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 46 PDB declaration: 46-meric
Chain G 34–311（278 aa） Fragment：RESIDUES 34-311
Chain g 34–311（278 aa） Fragment：RESIDUES 34-311
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 10 ADP ADENOSINE-5'-DIPHOSPHATE × 4 ELECTRON MICROSCOPY
cryo-EM buffer 250MM TREHALOSE 10NM TRIS- HCL PH7.4；pH 7.4；250MM TREHALOSE 10NM TRIS- HCL PH7.4
cryo-EM vitrification conditions Cryogen ETHANE；VITRIFICATION 1 -- CRYOGEN- ETHANE, TEMPERATURE- 100, INSTRUMENT- HOMEMADE PLUNGER, METHOD- SINGLE SIDE MANUAL BLOTTING FOR 5 SECONDS.,
Resolution 37.00 Å
6B8H Mosaic model of yeast mitochondrial ATP synthase monomer Deposited 2017-10-07 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 60 PDB declaration: 60-meric
Chain G 34–311（278 aa）
Chain j 34–311（278 aa）
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 10 MG MAGNESIUM ION × 10 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen NITROGEN
Resolution 3.60 Å
6CP3 Monomer yeast ATP synthase (F1Fo) reconstituted in nanodisc with inhibitor of oligomycin bound. Deposited 2018-03-13 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 ADP ADENOSINE-5'-DIPHOSPHATE × 2 ELECTRON MICROSCOPY
cryo-EM buffer pH 8；20 mM Tris-HCl, 150 mM NaCl, pH 8.0
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.80 Å
6CP6 Monomer yeast ATP synthase (F1Fo) reconstituted in nanodisc. Deposited 2018-03-13 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 ADP ADENOSINE-5'-DIPHOSPHATE × 2 ELECTRON MICROSCOPY
cryo-EM buffer pH 8；20 mM Tris-HCl, 150 mM NaCl, pH 8.0
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.60 Å
7TJT Yeast ATP synthase F1 region State 1-3catalytic beta_tight open without exogenous ATP Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain G 34–311（278 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 3 PO4 PHOSPHATE ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 3.20 Å
7TJU Yeast ATP synthase F1 region State 1-3binding beta_tight open without exogenous ATP Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain G 34–311（278 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 3 PO4 PHOSPHATE ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 3.30 Å
7TJV Yeast ATP synthase F1 region State 1catalytic(a) with 10 mM ATP Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain G 34–311（278 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 4 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 3.60 Å
7TJW Yeast ATP synthase F1 region State 1catalytic(e-h) with 10 mM ATP Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain G 34–311（278 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 5 MG MAGNESIUM ION × 5 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.00 Å
7TJX Yeast ATP synthase F1 region State 1binding(a-d) with 10 mM ATP Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric
Chain G 34–311（278 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 4 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 1 PO4 PHOSPHATE ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.00 Å
7TJY Yeast ATP synthase State 1catalytic(a) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 3.80 Å
7TJZ Yeast ATP synthase State 1catalytic(b) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.40 Å
7TK0 Yeast ATP synthase State 1catalytic(c) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.40 Å
7TK1 Yeast ATP synthase State 1catalytic(d) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TK2 Yeast ATP synthase State 1binding(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.50 Å
7TK3 Yeast ATP synthase State 1binding(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.30 Å
7TK4 Yeast ATP synthase State 1binding(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.00 Å
7TK5 Yeast ATP synthase State 1binding(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.80 Å
7TK6 Yeast ATP synthase State 1catalytic(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.50 Å
7TK7 Yeast ATP synthase State 1catalytic(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.70 Å
7TK8 Yeast ATP synthase State 1catalytic(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.70 Å
7TK9 Yeast ATP synthase State 1catalytic(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.00 Å
7TKA Yeast ATP synthase State 1catalytic(e) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKB Yeast ATP synthase State 1catalytic(f) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.30 Å
7TKC Yeast ATP synthase State 1catalytic(g) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 5.80 Å
7TKD Yeast ATP synthase State 1catalytic(h) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.70 Å
7TKE Yeast ATP synthase State 2binding(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKF Yeast ATP synthase State 2binding(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKG Yeast ATP synthase State 2catalytic(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.50 Å
7TKH Yeast ATP synthase State 2catalytic(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.40 Å
7TKI Yeast ATP synthase State 2catalytic(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKJ Yeast ATP synthase State 2catalytic(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.50 Å
7TKK Yeast ATP synthase State 2catalytic(e) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.30 Å
7TKL Yeast ATP synthase State 3binding(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.40 Å
7TKM Yeast ATP synthase State 3binding(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.50 Å
7TKN Yeast ATP synthase State 3binding(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKO Yeast ATP synthase State 3catalytic(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.80 Å
7TKP Yeast ATP synthase State 3catalytic(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.60 Å
7TKQ Yeast ATP synthase State 3catalytic(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.50 Å
7TKR Yeast ATP synthase State 3catalytic(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.50 Å
7TKS Yeast ATP synthase State 3catalytic(e) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 34–311（278 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.50 Å
8F29 Yeast ATP synthase in conformation-1 at pH 6 Deposited 2022-11-07 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 38–307（270 aa）
Not recorded ADP ADENOSINE-5'-DIPHOSPHATE × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 6
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 4.00 Å
8F39 Yeast ATP synthase in conformation-2, at pH 6 Deposited 2022-11-09 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 38–307（270 aa）
Not recorded ADP ADENOSINE-5'-DIPHOSPHATE × 5 MG MAGNESIUM ION × 4 ELECTRON MICROSCOPY
cryo-EM buffer pH 6
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.50 Å
8FL8 Yeast ATP Synthase structure in presence of MgATP Deposited 2022-12-21 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain G 38–307（270 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 4 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 8
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 4.20 Å

52 other PDB entries and 63 assemblies. Open the comparison page and filter oligomeric states

View Construct and Data Evidence
UniProt name ATPG_YEAST
Isoform —
PDB entities 3
Chains and sequence ranges Author chain G； PDBConstruct 1–278； UniProt 34–311 Author chain P； PDBConstruct 1–278； UniProt 34–311 Author chain Y； PDBConstruct 1–278； UniProt 34–311

ATP synthase subunit delta

Saccharomyces cerevisiae

UniProt Q12165

State in the Current Structure

Assembly Oligomeric State Construct Mutations and Modifications Ligands, Ions and Associated Components Method and Experimental Conditions Structure Quality
1 Protein heterocomplex Heteromer Protein × 9 PDB declaration: nonameric（9） Consistent with protein copy count Chain H； UniProt 23–160 Fragment：UNP RESIDUES 23-160 ATP synthase subunit alpha × 3 （P07251） ATP synthase subunit beta × 3 （P00830） ATP synthase subunit gamma × 1 （P38077） ATP synthase subunit epsilon × 1 （P21306） ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION X-ray crystallization conditions：pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K Resolution 2.74 Å R-free 0.259
2 Protein heterocomplex Heteromer Protein × 9 PDB declaration: nonameric（9） Consistent with protein copy count Chain Q； UniProt 23–160 Fragment：UNP RESIDUES 23-160 ATP synthase subunit alpha × 3 （P07251） ATP synthase subunit beta × 3 （P00830） ATP synthase subunit gamma × 1 （P38077） ATP synthase subunit epsilon × 1 （P21306） ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION X-ray crystallization conditions：pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K Resolution 2.74 Å R-free 0.259
3 Protein heterocomplex Heteromer Protein × 9 PDB declaration: nonameric（9） Consistent with protein copy count Chain Z； UniProt 23–160 Fragment：UNP RESIDUES 23-160 ATP synthase subunit alpha × 3 （P07251） ATP synthase subunit beta × 3 （P00830） ATP synthase subunit gamma × 1 （P38077） ATP synthase subunit epsilon × 1 （P21306） ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION X-ray crystallization conditions：pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K Resolution 2.74 Å R-free 0.259

Other States of the Same Protein in the Database

Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.

Other PDB Difference from Current Entry 3OEE Assembly / Oligomeric State Construct Mutations and Modifications Ligands, Ions and Non-polymers Method and Experimental Conditions Structure Quality
2HLD Crystal structure of yeast mitochondrial F1-ATPase Deposited 2006-07-06 Different construct Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain H 23–160（138 aa）
Not recorded MG MAGNESIUM ION × 5 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% glycerol, 4% methanol, 0.05M sodium acetate, 0.5mM nickel sulphate, 0.5mM AMP/PNP, 0.025 mM ADP, 2mM magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 2.80 Å R-free 0.244
2HLD Crystal structure of yeast mitochondrial F1-ATPase Deposited 2006-07-06 Different construct Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain Q 23–160（138 aa）
Not recorded MG MAGNESIUM ION × 5 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% glycerol, 4% methanol, 0.05M sodium acetate, 0.5mM nickel sulphate, 0.5mM AMP/PNP, 0.025 mM ADP, 2mM magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 2.80 Å R-free 0.244
2HLD Crystal structure of yeast mitochondrial F1-ATPase Deposited 2006-07-06 Different construct Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain Z 23–160（138 aa）
Not recorded MG MAGNESIUM ION × 5 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% glycerol, 4% methanol, 0.05M sodium acetate, 0.5mM nickel sulphate, 0.5mM AMP/PNP, 0.025 mM ADP, 2mM magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 2.80 Å R-free 0.244
2WPD The Mg.ADP inhibited state of the yeast F1c10 ATP synthase Deposited 2009-08-05 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 19 PDB declaration: nonadecameric
Chain H 23–160（138 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 2 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.5；0.1 M HEPES/HCL PH 7.5, 12% PEG MME 5000, 100 MM SODIUM CHLORIDE MIXED 1:1 WITH PROTEIN SOLUTION CONTAINING 0.64 MM DDM, 25 MM TRIS/HCL PH 8.0, 100 MM SODIUM CHLORIDE, 25 MM TREHALOSE, 0.5 MM EDTA, 0.02% SODIUM AZIDE, 2 MM MAGNESIUM CHLORIDE, 0.66 MM ADP, 0.1 MM DCCD, 2.5 MM DTT, 0.5 MM PMSF
Resolution 3.43 Å R-free 0.297
2XOK Refined structure of yeast F1c10 ATPase complex to 3 A resolution Deposited 2010-08-18 Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 19 PDB declaration: nonadecameric
Chain H 1–160（160 aa）
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions MICROBATCH；pH 8；0.1 M TRIS/CL PH8.0, 12% PEG 6000, 150 MM NACL, 1 MM AMP-PNP, 40 MICROM ADP, 1 MM DTT, 0.02% NAN3. MIXED 1:1 WITH PROTEIN SOLUTION UNDER PARAFFIN OIL IN MICROBATCH PLATE.
Resolution 3.01 Å R-free 0.253
3FKS Yeast F1 ATPase in the absence of bound nucleotides Deposited 2008-12-17 Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain H 23–160（138 aa） Fragment：UNP residues 23-160
Not recorded PO4 PHOSPHATE ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；6.25% PEG 6000, 10% Glycerol, 4% Methanol, 0.05M Sodium acetate, 0.5mM Nickel sulfate, 2 mM Sodium pyrophosphate, 2mM Magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277.0K
Resolution 3.59 Å R-free 0.306
3FKS Yeast F1 ATPase in the absence of bound nucleotides Deposited 2008-12-17 Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain Q 23–160（138 aa） Fragment：UNP residues 23-160
Not recorded PO4 PHOSPHATE ION × 6 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；6.25% PEG 6000, 10% Glycerol, 4% Methanol, 0.05M Sodium acetate, 0.5mM Nickel sulfate, 2 mM Sodium pyrophosphate, 2mM Magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277.0K
Resolution 3.59 Å R-free 0.306
3FKS Yeast F1 ATPase in the absence of bound nucleotides Deposited 2008-12-17 Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain Z 23–160（138 aa） Fragment：UNP residues 23-160
Not recorded PO4 PHOSPHATE ION × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；6.25% PEG 6000, 10% Glycerol, 4% Methanol, 0.05M Sodium acetate, 0.5mM Nickel sulfate, 2 mM Sodium pyrophosphate, 2mM Magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277.0K
Resolution 3.59 Å R-free 0.306
3OE7 Structure of four mutant forms of yeast f1 ATPase: gamma-I270T Deposited 2010-08-12 Different construct Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain H 24–160（137 aa） Fragment：UNP RESIDUES 23-160
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, PH 7.3, VAPOR DIFFUSION SITTING DROP, TEMPERATURE 277K
Resolution 3.19 Å R-free 0.245
3OE7 Structure of four mutant forms of yeast f1 ATPase: gamma-I270T Deposited 2010-08-12 Different construct Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain Q 24–160（137 aa） Fragment：UNP RESIDUES 23-160
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, PH 7.3, VAPOR DIFFUSION SITTING DROP, TEMPERATURE 277K
Resolution 3.19 Å R-free 0.245
3OE7 Structure of four mutant forms of yeast f1 ATPase: gamma-I270T Deposited 2010-08-12 Different construct Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain Z 24–160（137 aa） Fragment：UNP RESIDUES 23-160
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, PH 7.3, VAPOR DIFFUSION SITTING DROP, TEMPERATURE 277K
Resolution 3.19 Å R-free 0.245
3OEH Structure of four mutant forms of yeast F1 ATPase: beta-V279F Deposited 2010-08-12 Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain H 23–160（138 aa） Fragment：UNP RESIDUES 23-160
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.00 Å R-free 0.270
3OEH Structure of four mutant forms of yeast F1 ATPase: beta-V279F Deposited 2010-08-12 Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain Q 23–160（138 aa） Fragment：UNP RESIDUES 23-160
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.00 Å R-free 0.270
3OEH Structure of four mutant forms of yeast F1 ATPase: beta-V279F Deposited 2010-08-12 Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain Z 23–160（138 aa） Fragment：UNP RESIDUES 23-160
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.00 Å R-free 0.270
3OFN Structure of four mutant forms of yeast F1 ATPase: alpha-N67I Deposited 2010-08-15 Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain H 23–160（138 aa） Fragment：UNP RESIDUES 23-160
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.20 Å R-free 0.276
3OFN Structure of four mutant forms of yeast F1 ATPase: alpha-N67I Deposited 2010-08-15 Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain Q 23–160（138 aa） Fragment：UNP RESIDUES 23-160
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.20 Å R-free 0.276
3ZIA The structure of F1-ATPase from Saccharomyces cerevisiae inhibited by its regulatory protein IF1 Deposited 2013-01-07 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric
Chain R 23–160（138 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 5 EDO 1,2-ETHANEDIOL × 5 X-RAY DIFFRACTION
X-ray crystallization conditions MICROBATCH；pH 7.5；296 K；ACTIVE F1-ATPASE (12 MG/ML) WAS EXCHANGED ON A DESALTING COLUMN INTO CRYSTALLISATION BUFFER, PREPARED IN D2O CONSISTING OF 100 MM BIS-TRIS PROPANE, PH 7.5, 100 MM SUCROSE, 1 MM ADP AND 10 MM MAGNESIUM SULPHATE. THEN THE ENZYME WAS INHIBITED AT 23C WITH A 4-FOLD MOLAR EXCESS OF YI1-53 (MUTATION E21A) IN THE PRESENCE OF 1 MM ATP AND 2 MM MAGNESIUM SULPHATE. FURTHER PORTIONS (5 UL OF A NEUTRALISED STOCK SOLUTION CONTAINING 200 MM ATP AND 400 MM MAGNESIUM SULPHATE/ML PROTEIN SOLUTION) WERE ADDED AFTER 5 AND 10 MIN. MORE THAN 95% OF THE ATP HYDROLYSIS ACTIVITY OF THE ENZYME WAS INHIBITED. SODIUM-POTASSIUM TARTRATE WAS ADDED TO 100 MM, AND THE CONCENTRATION OF THE PROTEIN SOLUTION WAS ADJUSTED TO 10 MG/ML WITH CRYSTALLISATION BUFFER. CRYSTALS WERE GROWN AT 23C IN 72 WELL MICRO-BATCH PLATES UNDER FILTERED PARAFFIN OIL. THE CRYSTALLISATION DROPS (4 UL) CONTAINED A 1:1 MIXTURE OF PROTEIN SOLUTION AND PRECIPITANT SOLUTION (20%-26% POLYETHYLENE GLYCOL 3000 AND 600 MM NACL PREPARED IN D2O).
Resolution 2.50 Å R-free 0.262
3ZIA The structure of F1-ATPase from Saccharomyces cerevisiae inhibited by its regulatory protein IF1 Deposited 2013-01-07 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric
Chain H 23–160（138 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 5 EDO 1,2-ETHANEDIOL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions MICROBATCH；pH 7.5；296 K；ACTIVE F1-ATPASE (12 MG/ML) WAS EXCHANGED ON A DESALTING COLUMN INTO CRYSTALLISATION BUFFER, PREPARED IN D2O CONSISTING OF 100 MM BIS-TRIS PROPANE, PH 7.5, 100 MM SUCROSE, 1 MM ADP AND 10 MM MAGNESIUM SULPHATE. THEN THE ENZYME WAS INHIBITED AT 23C WITH A 4-FOLD MOLAR EXCESS OF YI1-53 (MUTATION E21A) IN THE PRESENCE OF 1 MM ATP AND 2 MM MAGNESIUM SULPHATE. FURTHER PORTIONS (5 UL OF A NEUTRALISED STOCK SOLUTION CONTAINING 200 MM ATP AND 400 MM MAGNESIUM SULPHATE/ML PROTEIN SOLUTION) WERE ADDED AFTER 5 AND 10 MIN. MORE THAN 95% OF THE ATP HYDROLYSIS ACTIVITY OF THE ENZYME WAS INHIBITED. SODIUM-POTASSIUM TARTRATE WAS ADDED TO 100 MM, AND THE CONCENTRATION OF THE PROTEIN SOLUTION WAS ADJUSTED TO 10 MG/ML WITH CRYSTALLISATION BUFFER. CRYSTALS WERE GROWN AT 23C IN 72 WELL MICRO-BATCH PLATES UNDER FILTERED PARAFFIN OIL. THE CRYSTALLISATION DROPS (4 UL) CONTAINED A 1:1 MIXTURE OF PROTEIN SOLUTION AND PRECIPITANT SOLUTION (20%-26% POLYETHYLENE GLYCOL 3000 AND 600 MM NACL PREPARED IN D2O).
Resolution 2.50 Å R-free 0.262
3ZRY Rotor architecture in the F(1)-c(10)-ring complex of the yeast F-ATP synthase Deposited 2011-06-21 Different construct Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain H 23–160（138 aa）
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 6.5；10% PEG 4000, 100 MM SODIUM CHLORIDE, 100 MM HEPES PH 6.5 MIXED 1:1 WITH PROTEIN SOLUTION (10 MG/ML) CONTAINING 0.64 MM DDM, 25 MM TRIS PH 8.0, 100 MM SODIUM CHLORIDE, 25 MM TREHALOSE, 0.5 MM EDTA, 3 MM SODIUM AZIDE, 2 MM MAGNESIUM CHLORIDE, 0.04 MM ADP, 1 MM AMP-PNP, 0.1 MM DCCD, 2.5 MM DTT, 0.5 MM PMSF.
Resolution 6.50 Å R-free 0.339
4B2Q Model of the yeast F1Fo-ATP synthase dimer based on subtomogram average Deposited 2012-07-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 46 PDB declaration: 46-meric
Chain H 29–160（132 aa） Fragment：RESIDUES 29-160
Chain h 29–160（132 aa） Fragment：RESIDUES 29-160
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 10 ADP ADENOSINE-5'-DIPHOSPHATE × 4 ELECTRON MICROSCOPY
cryo-EM buffer 250MM TREHALOSE 10NM TRIS- HCL PH7.4；pH 7.4；250MM TREHALOSE 10NM TRIS- HCL PH7.4
cryo-EM vitrification conditions Cryogen ETHANE；VITRIFICATION 1 -- CRYOGEN- ETHANE, TEMPERATURE- 100, INSTRUMENT- HOMEMADE PLUNGER, METHOD- SINGLE SIDE MANUAL BLOTTING FOR 5 SECONDS.,
Resolution 37.00 Å
6B8H Mosaic model of yeast mitochondrial ATP synthase monomer Deposited 2017-10-07 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 60 PDB declaration: 60-meric
Chain H 23–160（138 aa）
Chain l 23–160（138 aa）
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 10 MG MAGNESIUM ION × 10 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen NITROGEN
Resolution 3.60 Å
6CP3 Monomer yeast ATP synthase (F1Fo) reconstituted in nanodisc with inhibitor of oligomycin bound. Deposited 2018-03-13 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 ADP ADENOSINE-5'-DIPHOSPHATE × 2 ELECTRON MICROSCOPY
cryo-EM buffer pH 8；20 mM Tris-HCl, 150 mM NaCl, pH 8.0
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.80 Å
6CP6 Monomer yeast ATP synthase (F1Fo) reconstituted in nanodisc. Deposited 2018-03-13 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 ADP ADENOSINE-5'-DIPHOSPHATE × 2 ELECTRON MICROSCOPY
cryo-EM buffer pH 8；20 mM Tris-HCl, 150 mM NaCl, pH 8.0
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.60 Å
7TJY Yeast ATP synthase State 1catalytic(a) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 3.80 Å
7TJZ Yeast ATP synthase State 1catalytic(b) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.40 Å
7TK0 Yeast ATP synthase State 1catalytic(c) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.40 Å
7TK1 Yeast ATP synthase State 1catalytic(d) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TK2 Yeast ATP synthase State 1binding(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.50 Å
7TK3 Yeast ATP synthase State 1binding(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.30 Å
7TK4 Yeast ATP synthase State 1binding(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.00 Å
7TK5 Yeast ATP synthase State 1binding(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.80 Å
7TK6 Yeast ATP synthase State 1catalytic(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.50 Å
7TK7 Yeast ATP synthase State 1catalytic(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.70 Å
7TK8 Yeast ATP synthase State 1catalytic(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.70 Å
7TK9 Yeast ATP synthase State 1catalytic(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.00 Å
7TKA Yeast ATP synthase State 1catalytic(e) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKB Yeast ATP synthase State 1catalytic(f) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.30 Å
7TKC Yeast ATP synthase State 1catalytic(g) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 5.80 Å
7TKD Yeast ATP synthase State 1catalytic(h) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.70 Å
7TKE Yeast ATP synthase State 2binding(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKF Yeast ATP synthase State 2binding(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKG Yeast ATP synthase State 2catalytic(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.50 Å
7TKH Yeast ATP synthase State 2catalytic(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.40 Å
7TKI Yeast ATP synthase State 2catalytic(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKJ Yeast ATP synthase State 2catalytic(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.50 Å
7TKK Yeast ATP synthase State 2catalytic(e) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.30 Å
7TKL Yeast ATP synthase State 3binding(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.40 Å
7TKM Yeast ATP synthase State 3binding(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.50 Å
7TKN Yeast ATP synthase State 3binding(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKO Yeast ATP synthase State 3catalytic(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.80 Å
7TKP Yeast ATP synthase State 3catalytic(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.60 Å
7TKQ Yeast ATP synthase State 3catalytic(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.50 Å
7TKR Yeast ATP synthase State 3catalytic(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.50 Å
7TKS Yeast ATP synthase State 3catalytic(e) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 23–160（138 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.50 Å
8F29 Yeast ATP synthase in conformation-1 at pH 6 Deposited 2022-11-07 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 29–160（132 aa）
Not recorded ADP ADENOSINE-5'-DIPHOSPHATE × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 6
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 4.00 Å
8F39 Yeast ATP synthase in conformation-2, at pH 6 Deposited 2022-11-09 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 29–160（132 aa）
Not recorded ADP ADENOSINE-5'-DIPHOSPHATE × 5 MG MAGNESIUM ION × 4 ELECTRON MICROSCOPY
cryo-EM buffer pH 6
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.50 Å
8FKJ Yeast ATP Synthase in conformation-3, at pH 6 Deposited 2022-12-21 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 29–160（132 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 6
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 4.20 Å
8FL8 Yeast ATP Synthase structure in presence of MgATP Deposited 2022-12-21 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain H 29–160（132 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 4 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 8
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 4.20 Å

48 other PDB entries and 58 assemblies. Open the comparison page and filter oligomeric states

View Construct and Data Evidence
UniProt name ATPD_YEAST
Isoform —
PDB entities 4
Chains and sequence ranges Author chain H； PDBConstruct 1–138； UniProt 23–160 Author chain Q； PDBConstruct 1–138； UniProt 23–160 Author chain Z； PDBConstruct 1–138； UniProt 23–160

ATP synthase subunit epsilon

Saccharomyces cerevisiae

UniProt P21306

State in the Current Structure

Assembly Oligomeric State Construct Mutations and Modifications Ligands, Ions and Associated Components Method and Experimental Conditions Structure Quality
1 Protein heterocomplex Heteromer Protein × 9 PDB declaration: nonameric（9） Consistent with protein copy count Chain I； UniProt 2–62 Fragment：UNP RESIDUES 2-62 ATP synthase subunit alpha × 3 （P07251） ATP synthase subunit beta × 3 （P00830） ATP synthase subunit gamma × 1 （P38077） ATP synthase subunit delta × 1 （Q12165） ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION X-ray crystallization conditions：pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K Resolution 2.74 Å R-free 0.259
2 Protein heterocomplex Heteromer Protein × 9 PDB declaration: nonameric（9） Consistent with protein copy count Chain R； UniProt 2–62 Fragment：UNP RESIDUES 2-62 ATP synthase subunit alpha × 3 （P07251） ATP synthase subunit beta × 3 （P00830） ATP synthase subunit gamma × 1 （P38077） ATP synthase subunit delta × 1 （Q12165） ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION X-ray crystallization conditions：pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K Resolution 2.74 Å R-free 0.259
3 Protein heterocomplex Heteromer Protein × 9 PDB declaration: nonameric（9） Consistent with protein copy count Chain 1； UniProt 2–62 Fragment：UNP RESIDUES 2-62 ATP synthase subunit alpha × 3 （P07251） ATP synthase subunit beta × 3 （P00830） ATP synthase subunit gamma × 1 （P38077） ATP synthase subunit delta × 1 （Q12165） ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION X-ray crystallization conditions：pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K Resolution 2.74 Å R-free 0.259

Other States of the Same Protein in the Database

Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.

Other PDB Difference from Current Entry 3OEE Assembly / Oligomeric State Construct Mutations and Modifications Ligands, Ions and Non-polymers Method and Experimental Conditions Structure Quality
2HLD Crystal structure of yeast mitochondrial F1-ATPase Deposited 2006-07-06 Different construct Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain I 1–61（61 aa）
Not recorded MG MAGNESIUM ION × 5 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% glycerol, 4% methanol, 0.05M sodium acetate, 0.5mM nickel sulphate, 0.5mM AMP/PNP, 0.025 mM ADP, 2mM magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 2.80 Å R-free 0.244
2HLD Crystal structure of yeast mitochondrial F1-ATPase Deposited 2006-07-06 Different construct Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain R 1–61（61 aa）
Not recorded MG MAGNESIUM ION × 5 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% glycerol, 4% methanol, 0.05M sodium acetate, 0.5mM nickel sulphate, 0.5mM AMP/PNP, 0.025 mM ADP, 2mM magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 2.80 Å R-free 0.244
2HLD Crystal structure of yeast mitochondrial F1-ATPase Deposited 2006-07-06 Different construct Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain 1 1–61（61 aa）
Not recorded MG MAGNESIUM ION × 5 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% glycerol, 4% methanol, 0.05M sodium acetate, 0.5mM nickel sulphate, 0.5mM AMP/PNP, 0.025 mM ADP, 2mM magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 2.80 Å R-free 0.244
2WPD The Mg.ADP inhibited state of the yeast F1c10 ATP synthase Deposited 2009-08-05 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 19 PDB declaration: nonadecameric
Chain I 2–62（61 aa） Fragment：RESIDUES 2-62
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 2 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.5；0.1 M HEPES/HCL PH 7.5, 12% PEG MME 5000, 100 MM SODIUM CHLORIDE MIXED 1:1 WITH PROTEIN SOLUTION CONTAINING 0.64 MM DDM, 25 MM TRIS/HCL PH 8.0, 100 MM SODIUM CHLORIDE, 25 MM TREHALOSE, 0.5 MM EDTA, 0.02% SODIUM AZIDE, 2 MM MAGNESIUM CHLORIDE, 0.66 MM ADP, 0.1 MM DCCD, 2.5 MM DTT, 0.5 MM PMSF
Resolution 3.43 Å R-free 0.297
3FKS Yeast F1 ATPase in the absence of bound nucleotides Deposited 2008-12-17 Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain I 2–62（61 aa） Fragment：UNP residues 2-62
Not recorded PO4 PHOSPHATE ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；6.25% PEG 6000, 10% Glycerol, 4% Methanol, 0.05M Sodium acetate, 0.5mM Nickel sulfate, 2 mM Sodium pyrophosphate, 2mM Magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277.0K
Resolution 3.59 Å R-free 0.306
3FKS Yeast F1 ATPase in the absence of bound nucleotides Deposited 2008-12-17 Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain R 2–62（61 aa） Fragment：UNP residues 2-62
Not recorded PO4 PHOSPHATE ION × 6 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；6.25% PEG 6000, 10% Glycerol, 4% Methanol, 0.05M Sodium acetate, 0.5mM Nickel sulfate, 2 mM Sodium pyrophosphate, 2mM Magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277.0K
Resolution 3.59 Å R-free 0.306
3FKS Yeast F1 ATPase in the absence of bound nucleotides Deposited 2008-12-17 Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain 1 2–62（61 aa） Fragment：UNP residues 2-62
Not recorded PO4 PHOSPHATE ION × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；6.25% PEG 6000, 10% Glycerol, 4% Methanol, 0.05M Sodium acetate, 0.5mM Nickel sulfate, 2 mM Sodium pyrophosphate, 2mM Magnesium chloride, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277.0K
Resolution 3.59 Å R-free 0.306
3OE7 Structure of four mutant forms of yeast f1 ATPase: gamma-I270T Deposited 2010-08-12 Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain I 2–62（61 aa） Fragment：UNP RESIDUES 2-62
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, PH 7.3, VAPOR DIFFUSION SITTING DROP, TEMPERATURE 277K
Resolution 3.19 Å R-free 0.245
3OE7 Structure of four mutant forms of yeast f1 ATPase: gamma-I270T Deposited 2010-08-12 Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain R 2–62（61 aa） Fragment：UNP RESIDUES 2-62
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, PH 7.3, VAPOR DIFFUSION SITTING DROP, TEMPERATURE 277K
Resolution 3.19 Å R-free 0.245
3OE7 Structure of four mutant forms of yeast f1 ATPase: gamma-I270T Deposited 2010-08-12 Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain 1 2–62（61 aa） Fragment：UNP RESIDUES 2-62
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, PH 7.3, VAPOR DIFFUSION SITTING DROP, TEMPERATURE 277K
Resolution 3.19 Å R-free 0.245
3OEH Structure of four mutant forms of yeast F1 ATPase: beta-V279F Deposited 2010-08-12 Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain I 2–62（61 aa） Fragment：UNP RESIDUES 2-62
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.00 Å R-free 0.270
3OEH Structure of four mutant forms of yeast F1 ATPase: beta-V279F Deposited 2010-08-12 Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain R 2–62（61 aa） Fragment：UNP RESIDUES 2-62
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.00 Å R-free 0.270
3OEH Structure of four mutant forms of yeast F1 ATPase: beta-V279F Deposited 2010-08-12 Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain 1 2–62（61 aa） Fragment：UNP RESIDUES 2-62
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.00 Å R-free 0.270
3OFN Structure of four mutant forms of yeast F1 ATPase: alpha-N67I Deposited 2010-08-15 Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain I 2–62（61 aa） Fragment：UNP RESIDUES 2-62
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.20 Å R-free 0.276
3OFN Structure of four mutant forms of yeast F1 ATPase: alpha-N67I Deposited 2010-08-15 Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric
Chain R 2–62（61 aa） Fragment：UNP RESIDUES 2-62
Not recorded ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 5 MG MAGNESIUM ION × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.3；277 K；5.5% PEG 6000, 10% GLYCEROL, 4% METHANOL, 0.05M SODIUM ACETATE, 0.5MM NICKEL SULPHATE, 0.5MM AMP/PNP, 0.025 MM ADP, 2MM MAGNESIUM CHLORIDE, pH 7.3, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 3.20 Å R-free 0.276
3ZIA The structure of F1-ATPase from Saccharomyces cerevisiae inhibited by its regulatory protein IF1 Deposited 2013-01-07 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric
Chain S 2–62（61 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 5 EDO 1,2-ETHANEDIOL × 5 X-RAY DIFFRACTION
X-ray crystallization conditions MICROBATCH；pH 7.5；296 K；ACTIVE F1-ATPASE (12 MG/ML) WAS EXCHANGED ON A DESALTING COLUMN INTO CRYSTALLISATION BUFFER, PREPARED IN D2O CONSISTING OF 100 MM BIS-TRIS PROPANE, PH 7.5, 100 MM SUCROSE, 1 MM ADP AND 10 MM MAGNESIUM SULPHATE. THEN THE ENZYME WAS INHIBITED AT 23C WITH A 4-FOLD MOLAR EXCESS OF YI1-53 (MUTATION E21A) IN THE PRESENCE OF 1 MM ATP AND 2 MM MAGNESIUM SULPHATE. FURTHER PORTIONS (5 UL OF A NEUTRALISED STOCK SOLUTION CONTAINING 200 MM ATP AND 400 MM MAGNESIUM SULPHATE/ML PROTEIN SOLUTION) WERE ADDED AFTER 5 AND 10 MIN. MORE THAN 95% OF THE ATP HYDROLYSIS ACTIVITY OF THE ENZYME WAS INHIBITED. SODIUM-POTASSIUM TARTRATE WAS ADDED TO 100 MM, AND THE CONCENTRATION OF THE PROTEIN SOLUTION WAS ADJUSTED TO 10 MG/ML WITH CRYSTALLISATION BUFFER. CRYSTALS WERE GROWN AT 23C IN 72 WELL MICRO-BATCH PLATES UNDER FILTERED PARAFFIN OIL. THE CRYSTALLISATION DROPS (4 UL) CONTAINED A 1:1 MIXTURE OF PROTEIN SOLUTION AND PRECIPITANT SOLUTION (20%-26% POLYETHYLENE GLYCOL 3000 AND 600 MM NACL PREPARED IN D2O).
Resolution 2.50 Å R-free 0.262
3ZIA The structure of F1-ATPase from Saccharomyces cerevisiae inhibited by its regulatory protein IF1 Deposited 2013-01-07 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric
Chain I 2–62（61 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 5 EDO 1,2-ETHANEDIOL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions MICROBATCH；pH 7.5；296 K；ACTIVE F1-ATPASE (12 MG/ML) WAS EXCHANGED ON A DESALTING COLUMN INTO CRYSTALLISATION BUFFER, PREPARED IN D2O CONSISTING OF 100 MM BIS-TRIS PROPANE, PH 7.5, 100 MM SUCROSE, 1 MM ADP AND 10 MM MAGNESIUM SULPHATE. THEN THE ENZYME WAS INHIBITED AT 23C WITH A 4-FOLD MOLAR EXCESS OF YI1-53 (MUTATION E21A) IN THE PRESENCE OF 1 MM ATP AND 2 MM MAGNESIUM SULPHATE. FURTHER PORTIONS (5 UL OF A NEUTRALISED STOCK SOLUTION CONTAINING 200 MM ATP AND 400 MM MAGNESIUM SULPHATE/ML PROTEIN SOLUTION) WERE ADDED AFTER 5 AND 10 MIN. MORE THAN 95% OF THE ATP HYDROLYSIS ACTIVITY OF THE ENZYME WAS INHIBITED. SODIUM-POTASSIUM TARTRATE WAS ADDED TO 100 MM, AND THE CONCENTRATION OF THE PROTEIN SOLUTION WAS ADJUSTED TO 10 MG/ML WITH CRYSTALLISATION BUFFER. CRYSTALS WERE GROWN AT 23C IN 72 WELL MICRO-BATCH PLATES UNDER FILTERED PARAFFIN OIL. THE CRYSTALLISATION DROPS (4 UL) CONTAINED A 1:1 MIXTURE OF PROTEIN SOLUTION AND PRECIPITANT SOLUTION (20%-26% POLYETHYLENE GLYCOL 3000 AND 600 MM NACL PREPARED IN D2O).
Resolution 2.50 Å R-free 0.262
4B2Q Model of the yeast F1Fo-ATP synthase dimer based on subtomogram average Deposited 2012-07-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 46 PDB declaration: 46-meric
Chain I 2–60（59 aa） Fragment：RESIDUES 2-60
Chain i 2–60（59 aa） Fragment：RESIDUES 2-60
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 10 ADP ADENOSINE-5'-DIPHOSPHATE × 4 ELECTRON MICROSCOPY
cryo-EM buffer 250MM TREHALOSE 10NM TRIS- HCL PH7.4；pH 7.4；250MM TREHALOSE 10NM TRIS- HCL PH7.4
cryo-EM vitrification conditions Cryogen ETHANE；VITRIFICATION 1 -- CRYOGEN- ETHANE, TEMPERATURE- 100, INSTRUMENT- HOMEMADE PLUNGER, METHOD- SINGLE SIDE MANUAL BLOTTING FOR 5 SECONDS.,
Resolution 37.00 Å
6CP3 Monomer yeast ATP synthase (F1Fo) reconstituted in nanodisc with inhibitor of oligomycin bound. Deposited 2018-03-13 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 ADP ADENOSINE-5'-DIPHOSPHATE × 2 ELECTRON MICROSCOPY
cryo-EM buffer pH 8；20 mM Tris-HCl, 150 mM NaCl, pH 8.0
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.80 Å
6CP6 Monomer yeast ATP synthase (F1Fo) reconstituted in nanodisc. Deposited 2018-03-13 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 ADP ADENOSINE-5'-DIPHOSPHATE × 2 ELECTRON MICROSCOPY
cryo-EM buffer pH 8；20 mM Tris-HCl, 150 mM NaCl, pH 8.0
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.60 Å
7MD2 The F1 region of ammocidin-bound Saccharomyces cerevisiae ATP synthase Deposited 2021-04-03 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 8 PDB declaration: octameric
Chain H 2–62（61 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 3 PO4 PHOSPHATE ION × 1 ZHD (3~{E},5~{Z},7~{E},9~{R},10~{S},11~{E},13~{E},15~{E},17~{R},18~{S},20~{S})-20-[(1~{R})-1-[(2~{S},3~{R},4~{R},5~{S},6~{R})-5-[(2~{S},4~{S},5~{S},6~{R})-5-[(2~{S},4~{R},5~{R},6~{R})-4,6-dimethyl-4,5-bis(oxidanyl)oxan-2-yl]oxy-6-methyl-4-oxidanyl-oxan-2-yl]oxy-3-methoxy-6-(3-methoxypropyl)-5-methyl-2,4-bis(oxidanyl)oxan-2-yl]ethyl]-5,18-dimethoxy-3,7,9,11,13,15-hexamethyl-10-[(2~{R},3~{S},4~{R},5~{R},6~{S})-6-methyl-3,4,5-tris(oxidanyl)oxan-2-yl]oxy-17-oxidanyl-1-oxacycloicosa-3,5,7,11,13,15-hexaen-2-one × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 3.10 Å
7MD3 The F1 region of apoptolidin-bound Saccharomyces cerevisiae ATP synthase Deposited 2021-04-03 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 8 PDB declaration: octameric
Chain H 2–62（61 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 3 PO4 PHOSPHATE ION × 1 ZH7 (3~{E},5~{E},7~{E},9~{R},10~{R},11~{E},13~{E},17~{S},18~{S},20~{S})-18-methoxy-20-[(~{R})-[(2~{R},3~{R},4~{S},5~{R},6~{R})-6-[(2~{R})-3-methoxy-2-[(2~{R},4~{S},5~{S},6~{S})-5-[(2~{S},4~{R},5~{R},6~{R})-4-methoxy-6-methyl-5-oxidanyl-oxan-2-yl]oxy-4,6-dimethyl-4-oxidanyl-oxan-2-yl]oxy-propyl]-3,5-dimethyl-2,4-bis(oxidanyl)oxan-2-yl]-oxidanyl-methyl]-10-[(2~{R},3~{S},4~{S},5~{R},6~{S})-5-methoxy-6-methyl-3,4-bis(oxidanyl)oxan-2-yl]oxy-3,5,7,9,13-pentamethyl-17-oxidanyl-1-oxacycloicosa-3,5,7,11,13-pentaen-2-one × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 3.30 Å
7TJY Yeast ATP synthase State 1catalytic(a) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 3.80 Å
7TJZ Yeast ATP synthase State 1catalytic(b) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.40 Å
7TK0 Yeast ATP synthase State 1catalytic(c) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.40 Å
7TK1 Yeast ATP synthase State 1catalytic(d) without exogenous ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TK2 Yeast ATP synthase State 1binding(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.50 Å
7TK3 Yeast ATP synthase State 1binding(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.30 Å
7TK4 Yeast ATP synthase State 1binding(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.00 Å
7TK5 Yeast ATP synthase State 1binding(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.80 Å
7TK6 Yeast ATP synthase State 1catalytic(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.50 Å
7TK7 Yeast ATP synthase State 1catalytic(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.70 Å
7TK8 Yeast ATP synthase State 1catalytic(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.70 Å
7TK9 Yeast ATP synthase State 1catalytic(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.00 Å
7TKA Yeast ATP synthase State 1catalytic(e) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKB Yeast ATP synthase State 1catalytic(f) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.30 Å
7TKC Yeast ATP synthase State 1catalytic(g) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 5.80 Å
7TKD Yeast ATP synthase State 1catalytic(h) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.70 Å
7TKE Yeast ATP synthase State 2binding(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKF Yeast ATP synthase State 2binding(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKG Yeast ATP synthase State 2catalytic(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.50 Å
7TKH Yeast ATP synthase State 2catalytic(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.40 Å
7TKI Yeast ATP synthase State 2catalytic(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKJ Yeast ATP synthase State 2catalytic(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.50 Å
7TKK Yeast ATP synthase State 2catalytic(e) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.30 Å
7TKL Yeast ATP synthase State 3binding(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.40 Å
7TKM Yeast ATP synthase State 3binding(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.50 Å
7TKN Yeast ATP synthase State 3binding(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.10 Å
7TKO Yeast ATP synthase State 3catalytic(a) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.80 Å
7TKP Yeast ATP synthase State 3catalytic(b) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.60 Å
7TKQ Yeast ATP synthase State 3catalytic(c) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 4.50 Å
7TKR Yeast ATP synthase State 3catalytic(d) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 6.50 Å
7TKS Yeast ATP synthase State 3catalytic(e) with 10 mM ATP backbone model Deposited 2022-01-17 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–62（61 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 7.4
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 7.50 Å
8F29 Yeast ATP synthase in conformation-1 at pH 6 Deposited 2022-11-07 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–60（59 aa）
Not recorded ADP ADENOSINE-5'-DIPHOSPHATE × 5 MG MAGNESIUM ION × 5 PO4 PHOSPHATE ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 6
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 4.00 Å
8F39 Yeast ATP synthase in conformation-2, at pH 6 Deposited 2022-11-09 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–60（59 aa）
Not recorded ADP ADENOSINE-5'-DIPHOSPHATE × 5 MG MAGNESIUM ION × 4 ELECTRON MICROSCOPY
cryo-EM buffer pH 6
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.50 Å
8FKJ Yeast ATP Synthase in conformation-3, at pH 6 Deposited 2022-12-21 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–60（59 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 6
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 4.20 Å
8FL8 Yeast ATP Synthase structure in presence of MgATP Deposited 2022-12-21 Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric
Chain I 2–60（59 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 4 MG MAGNESIUM ION × 5 ADP ADENOSINE-5'-DIPHOSPHATE × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 8
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 4.20 Å

47 other PDB entries and 57 assemblies. Open the comparison page and filter oligomeric states

View Construct and Data Evidence
UniProt name ATP5E_YEAST
Isoform —
PDB entities 5
Chains and sequence ranges Author chain 1； PDBConstruct 1–61； UniProt 2–62 Author chain I； PDBConstruct 1–61； UniProt 2–62 Author chain R； PDBConstruct 1–61； UniProt 2–62

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

SAXS scattering curve SAXS Profile

SAXS profile for 3oee

P(r) Distance Distribution P(r) Distribution

P(r) distribution for 3oee
Download Download
▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id3oee
Deposition date deposition_date2010-08-12
Structure title titleStructure of four mutant forms of yeast F1 ATPase: alpha-F405S
Keywords keywordsATP SYNTHASE, ATP PHOSPHATASE, F1F0 ATPASE, ATP SYNTHESIS, HYDROLASE, ADP, PO4, MITOCHONDRIA; HYDROLASE
Experimental Method methodX-RAY DIFFRACTION
▼

3. SAXS Parameters (CRYSOL theoretical calculation) 3. SAXS Parameters (CRYSOL)

Radius of gyration Rg (Guinier) rg_guinier75.19 Å
Radius of gyration Rg (electron density) rg_electron74.86 Å
Forward intensity I(0) i014499600000.00
Molecular weight molecular_weight1030900.0 kDa
Excluded volume excluded_volume1295000 ų
Envelope volume envelope_volume1916400 ų
Hydration-shell volume shell_volume203960 ų
Envelope diameter envelope_diameter251.0 Å
Shell Rg shell_rg79.03 Å
Envelope Rg envelope_rg73.93 Å
Shape Rg shape_rg74.88 Å
Total Rg total_rg74.82 Å
Total atoms total_atoms72591
Residues n_residues9597
Spherical-harmonic order n_harmonics20
q range q_range— – 0.5000 Å−1
Data points n_points101
Shell type shell_typedirectional
Solvent electron density solvent_density0.3340 e/ų
Shell contrast contrast_shell0.0300 e/ų
CRYSOL version crysol_version4.1.3
▼

4. P(r) Distance Distribution (GNOM inversion) 4. P(r) Analysis (GNOM)

Maximum dimension Dmax dmax262.1 Å
Rg (real space) rg_real78.27 Å
Rg uncertainty (real space) rg_real_error1.55 Å
I(0) (real space) i0_real1.4500e+10
I(0) uncertainty (real space) i0_real_error3.1070e+08
Rg (reciprocal space) rg_reciprocal75.50 Å
I(0) (reciprocal space) i0_reciprocal14510000000.0000
Solution quality estimate total_estimate0.8988
Solution quality rating solution_quality GOOD a GOOD solution
P(r) peaks n_peaks1
Primary peak position r_peak_primary74.9 Å
Skewness Skewness skewness0.375
Kurtosis Kurtosis kurtosis-0.235
Angular range angular_range— – 0.1050 Å−1
Current regularization parameter α current_alpha1.1550
Highest regularization parameter α highest_alpha4376000000.0000
Real-space data points n_real_points22
GNOM version gnom_version4.1.3
Quality Criteria quality_criteria AN1: 0.000; Oscil: 0.845; Stabil: 0.875; Sysdev: 1.000; Positv: 1.000; Valcen: 0.979; Smooth: 0.575
▶

5. Crystallography and Experiment 5. Crystallography & Experiment

▶

6. Entities and Polymers Entities & Polymers (9)

▼

7. Fold Classification (SCOP + CATH) 95 domains

SCOP 2.08 (34 domains)

Domain ID domain_idd3oeed1
Class classb — All beta proteins
Fold Fold foldb.49 — Domain of alpha and beta subunits of F1 ATP synthase-like
Superfamily Superfamily superfamilyb.49.1 — N-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familyb.49.1.1 — N-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeed2
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.37 — P-loop containing nucleoside triphosphate hydrolases
Superfamily Superfamily superfamilyc.37.1 — P-loop containing nucleoside triphosphate hydrolases
Family Family familyc.37.1.11 — RecA protein-like (ATPase-domain)
Domain ID domain_idd3oeed3
Class classa — All alpha proteins
Fold Fold folda.69 — Left-handed superhelix
Superfamily Superfamily superfamilya.69.1 — C-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familya.69.1.1 — C-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeee1
Class classb — All beta proteins
Fold Fold foldb.49 — Domain of alpha and beta subunits of F1 ATP synthase-like
Superfamily Superfamily superfamilyb.49.1 — N-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familyb.49.1.1 — N-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeee2
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.37 — P-loop containing nucleoside triphosphate hydrolases
Superfamily Superfamily superfamilyc.37.1 — P-loop containing nucleoside triphosphate hydrolases
Family Family familyc.37.1.11 — RecA protein-like (ATPase-domain)
Domain ID domain_idd3oeee3
Class classa — All alpha proteins
Fold Fold folda.69 — Left-handed superhelix
Superfamily Superfamily superfamilya.69.1 — C-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familya.69.1.1 — C-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeef1
Class classb — All beta proteins
Fold Fold foldb.49 — Domain of alpha and beta subunits of F1 ATP synthase-like
Superfamily Superfamily superfamilyb.49.1 — N-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familyb.49.1.1 — N-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeef2
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.37 — P-loop containing nucleoside triphosphate hydrolases
Superfamily Superfamily superfamilyc.37.1 — P-loop containing nucleoside triphosphate hydrolases
Family Family familyc.37.1.11 — RecA protein-like (ATPase-domain)
Domain ID domain_idd3oeef3
Class classa — All alpha proteins
Fold Fold folda.69 — Left-handed superhelix
Superfamily Superfamily superfamilya.69.1 — C-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familya.69.1.1 — C-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeeg_
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.49 — Pyruvate kinase C-terminal domain-like
Superfamily Superfamily superfamilyc.49.2 — ATP synthase (F1-ATPase), gamma subunit
Family Family familyc.49.2.1 — ATP synthase (F1-ATPase), gamma subunit
Domain ID domain_idd3oeeh1
Class classb — All beta proteins
Fold Fold foldb.93 — Epsilon subunit of F1F0-ATP synthase N-terminal domain
Superfamily Superfamily superfamilyb.93.1 — Epsilon subunit of F1F0-ATP synthase N-terminal domain
Family Family familyb.93.1.1 — Epsilon subunit of F1F0-ATP synthase N-terminal domain
Domain ID domain_idd3oeeh2
Class classa — All alpha proteins
Fold Fold folda.2 — Long alpha-hairpin
Superfamily Superfamily superfamilya.2.10 — Epsilon subunit of F1F0-ATP synthase C-terminal domain
Family Family familya.2.10.1 — Epsilon subunit of F1F0-ATP synthase C-terminal domain
Domain ID domain_idd3oeei_
Class classa — All alpha proteins
Fold Fold folda.137 — Non-globular all-alpha subunits of globular proteins
Superfamily Superfamily superfamilya.137.8 — Epsilon subunit of mitochondrial F1F0-ATP synthase
Family Family familya.137.8.1 — Epsilon subunit of mitochondrial F1F0-ATP synthase
Domain ID domain_idd3oeem1
Class classb — All beta proteins
Fold Fold foldb.49 — Domain of alpha and beta subunits of F1 ATP synthase-like
Superfamily Superfamily superfamilyb.49.1 — N-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familyb.49.1.1 — N-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeem2
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.37 — P-loop containing nucleoside triphosphate hydrolases
Superfamily Superfamily superfamilyc.37.1 — P-loop containing nucleoside triphosphate hydrolases
Family Family familyc.37.1.11 — RecA protein-like (ATPase-domain)
Domain ID domain_idd3oeem3
Class classa — All alpha proteins
Fold Fold folda.69 — Left-handed superhelix
Superfamily Superfamily superfamilya.69.1 — C-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familya.69.1.1 — C-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeen1
Class classb — All beta proteins
Fold Fold foldb.49 — Domain of alpha and beta subunits of F1 ATP synthase-like
Superfamily Superfamily superfamilyb.49.1 — N-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familyb.49.1.1 — N-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeen2
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.37 — P-loop containing nucleoside triphosphate hydrolases
Superfamily Superfamily superfamilyc.37.1 — P-loop containing nucleoside triphosphate hydrolases
Family Family familyc.37.1.11 — RecA protein-like (ATPase-domain)
Domain ID domain_idd3oeen3
Class classa — All alpha proteins
Fold Fold folda.69 — Left-handed superhelix
Superfamily Superfamily superfamilya.69.1 — C-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familya.69.1.1 — C-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeeo1
Class classb — All beta proteins
Fold Fold foldb.49 — Domain of alpha and beta subunits of F1 ATP synthase-like
Superfamily Superfamily superfamilyb.49.1 — N-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familyb.49.1.1 — N-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeeo2
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.37 — P-loop containing nucleoside triphosphate hydrolases
Superfamily Superfamily superfamilyc.37.1 — P-loop containing nucleoside triphosphate hydrolases
Family Family familyc.37.1.11 — RecA protein-like (ATPase-domain)
Domain ID domain_idd3oeeo3
Class classa — All alpha proteins
Fold Fold folda.69 — Left-handed superhelix
Superfamily Superfamily superfamilya.69.1 — C-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familya.69.1.1 — C-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeep_
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.49 — Pyruvate kinase C-terminal domain-like
Superfamily Superfamily superfamilyc.49.2 — ATP synthase (F1-ATPase), gamma subunit
Family Family familyc.49.2.1 — ATP synthase (F1-ATPase), gamma subunit
Domain ID domain_idd3oeer_
Class classa — All alpha proteins
Fold Fold folda.137 — Non-globular all-alpha subunits of globular proteins
Superfamily Superfamily superfamilya.137.8 — Epsilon subunit of mitochondrial F1F0-ATP synthase
Family Family familya.137.8.1 — Epsilon subunit of mitochondrial F1F0-ATP synthase
Domain ID domain_idd3oeev1
Class classb — All beta proteins
Fold Fold foldb.49 — Domain of alpha and beta subunits of F1 ATP synthase-like
Superfamily Superfamily superfamilyb.49.1 — N-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familyb.49.1.1 — N-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeev2
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.37 — P-loop containing nucleoside triphosphate hydrolases
Superfamily Superfamily superfamilyc.37.1 — P-loop containing nucleoside triphosphate hydrolases
Family Family familyc.37.1.11 — RecA protein-like (ATPase-domain)
Domain ID domain_idd3oeev3
Class classa — All alpha proteins
Fold Fold folda.69 — Left-handed superhelix
Superfamily Superfamily superfamilya.69.1 — C-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familya.69.1.1 — C-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeew1
Class classb — All beta proteins
Fold Fold foldb.49 — Domain of alpha and beta subunits of F1 ATP synthase-like
Superfamily Superfamily superfamilyb.49.1 — N-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familyb.49.1.1 — N-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeew2
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.37 — P-loop containing nucleoside triphosphate hydrolases
Superfamily Superfamily superfamilyc.37.1 — P-loop containing nucleoside triphosphate hydrolases
Family Family familyc.37.1.11 — RecA protein-like (ATPase-domain)
Domain ID domain_idd3oeew3
Class classa — All alpha proteins
Fold Fold folda.69 — Left-handed superhelix
Superfamily Superfamily superfamilya.69.1 — C-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familya.69.1.1 — C-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeex1
Class classb — All beta proteins
Fold Fold foldb.49 — Domain of alpha and beta subunits of F1 ATP synthase-like
Superfamily Superfamily superfamilyb.49.1 — N-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familyb.49.1.1 — N-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeex2
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.37 — P-loop containing nucleoside triphosphate hydrolases
Superfamily Superfamily superfamilyc.37.1 — P-loop containing nucleoside triphosphate hydrolases
Family Family familyc.37.1.11 — RecA protein-like (ATPase-domain)
Domain ID domain_idd3oeex3
Class classa — All alpha proteins
Fold Fold folda.69 — Left-handed superhelix
Superfamily Superfamily superfamilya.69.1 — C-terminal domain of alpha and beta (or A/B) subunits of rotary ATPases
Family Family familya.69.1.1 — C-terminal domain of alpha and beta subunits of F1 ATP synthase
Domain ID domain_idd3oeey_
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.49 — Pyruvate kinase C-terminal domain-like
Superfamily Superfamily superfamilyc.49.2 — ATP synthase (F1-ATPase), gamma subunit
Family Family familyc.49.2.1 — ATP synthase (F1-ATPase), gamma subunit

CATH v4.4 (61 domains)

Domain ID domain_id3oeeA01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology30 — Elongation Factor Tu (Ef-tu); domain 3
Homologous superfamily homologous superfamily20 —
Domain ID domain_id3oeeA02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeA03
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology150 — Lysin
Homologous superfamily homologous superfamily20 — ATP synthase alpha/beta chain, C-terminal domain
Domain ID domain_id3oeeB01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology30 — Elongation Factor Tu (Ef-tu); domain 3
Homologous superfamily homologous superfamily20 —
Domain ID domain_id3oeeB02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeB03
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology150 — Lysin
Homologous superfamily homologous superfamily20 — ATP synthase alpha/beta chain, C-terminal domain
Domain ID domain_id3oeeC01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology30 — Elongation Factor Tu (Ef-tu); domain 3
Homologous superfamily homologous superfamily20 —
Domain ID domain_id3oeeC02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeC03
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology150 — Lysin
Homologous superfamily homologous superfamily20 — ATP synthase alpha/beta chain, C-terminal domain
Domain ID domain_id3oeeD01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology10 — Thrombin, subunit H
Homologous superfamily homologous superfamily170 —
Domain ID domain_id3oeeD02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeD03
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology1140 — Bovine Mitochondrial F1-ATPase, ATP Synthase Beta Chain; Chain D, domain3
Homologous superfamily homologous superfamily10 — Bovine Mitochondrial F1-atpase; Atp Synthase Beta Chain; Chain D, domain 3
Domain ID domain_id3oeeE01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology10 — Thrombin, subunit H
Homologous superfamily homologous superfamily170 —
Domain ID domain_id3oeeE02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeE03
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology1140 — Bovine Mitochondrial F1-ATPase, ATP Synthase Beta Chain; Chain D, domain3
Homologous superfamily homologous superfamily10 — Bovine Mitochondrial F1-atpase; Atp Synthase Beta Chain; Chain D, domain 3
Domain ID domain_id3oeeF01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology10 — Thrombin, subunit H
Homologous superfamily homologous superfamily170 —
Domain ID domain_id3oeeF02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeF03
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology1140 — Bovine Mitochondrial F1-ATPase, ATP Synthase Beta Chain; Chain D, domain3
Homologous superfamily homologous superfamily10 — Bovine Mitochondrial F1-atpase; Atp Synthase Beta Chain; Chain D, domain 3
Domain ID domain_id3oeeG01
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology287 — Helix Hairpins
Homologous superfamily homologous superfamily80 — ATP synthase, gamma subunit, helix hairpin domain
Domain ID domain_id3oeeG02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology1380 — Pyruvate Kinase; Chain: A, domain 1
Homologous superfamily homologous superfamily10 — ATP synthase, F1 complex, gamma subunit
Domain ID domain_id3oeeI00
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology1620 — Atp Synthase Epsilon Chain; Chain: I;
Homologous superfamily homologous superfamily20 — ATP synthase, F1 complex, epsilon subunit superfamily, mitochondrial
Domain ID domain_id3oeeJ01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology30 — Elongation Factor Tu (Ef-tu); domain 3
Homologous superfamily homologous superfamily20 —
Domain ID domain_id3oeeJ02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeJ03
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology150 — Lysin
Homologous superfamily homologous superfamily20 — ATP synthase alpha/beta chain, C-terminal domain
Domain ID domain_id3oeeK01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology30 — Elongation Factor Tu (Ef-tu); domain 3
Homologous superfamily homologous superfamily20 —
Domain ID domain_id3oeeK02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeK03
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology150 — Lysin
Homologous superfamily homologous superfamily20 — ATP synthase alpha/beta chain, C-terminal domain
Domain ID domain_id3oeeL01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology30 — Elongation Factor Tu (Ef-tu); domain 3
Homologous superfamily homologous superfamily20 —
Domain ID domain_id3oeeL02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeL03
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology150 — Lysin
Homologous superfamily homologous superfamily20 — ATP synthase alpha/beta chain, C-terminal domain
Domain ID domain_id3oeeM01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology10 — Thrombin, subunit H
Homologous superfamily homologous superfamily170 —
Domain ID domain_id3oeeM02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeM03
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology1140 — Bovine Mitochondrial F1-ATPase, ATP Synthase Beta Chain; Chain D, domain3
Homologous superfamily homologous superfamily10 — Bovine Mitochondrial F1-atpase; Atp Synthase Beta Chain; Chain D, domain 3
Domain ID domain_id3oeeN01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology10 — Thrombin, subunit H
Homologous superfamily homologous superfamily170 —
Domain ID domain_id3oeeN02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeN03
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology1140 — Bovine Mitochondrial F1-ATPase, ATP Synthase Beta Chain; Chain D, domain3
Homologous superfamily homologous superfamily10 — Bovine Mitochondrial F1-atpase; Atp Synthase Beta Chain; Chain D, domain 3
Domain ID domain_id3oeeO01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology10 — Thrombin, subunit H
Homologous superfamily homologous superfamily170 —
Domain ID domain_id3oeeO02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeO03
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology1140 — Bovine Mitochondrial F1-ATPase, ATP Synthase Beta Chain; Chain D, domain3
Homologous superfamily homologous superfamily10 — Bovine Mitochondrial F1-atpase; Atp Synthase Beta Chain; Chain D, domain 3
Domain ID domain_id3oeeP01
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology287 — Helix Hairpins
Homologous superfamily homologous superfamily80 — ATP synthase, gamma subunit, helix hairpin domain
Domain ID domain_id3oeeP02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology1380 — Pyruvate Kinase; Chain: A, domain 1
Homologous superfamily homologous superfamily10 — ATP synthase, F1 complex, gamma subunit
Domain ID domain_id3oeeS01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology30 — Elongation Factor Tu (Ef-tu); domain 3
Homologous superfamily homologous superfamily20 —
Domain ID domain_id3oeeS02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeS03
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology150 — Lysin
Homologous superfamily homologous superfamily20 — ATP synthase alpha/beta chain, C-terminal domain
Domain ID domain_id3oeeT01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology30 — Elongation Factor Tu (Ef-tu); domain 3
Homologous superfamily homologous superfamily20 —
Domain ID domain_id3oeeT02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeT03
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology150 — Lysin
Homologous superfamily homologous superfamily20 — ATP synthase alpha/beta chain, C-terminal domain
Domain ID domain_id3oeeU01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology30 — Elongation Factor Tu (Ef-tu); domain 3
Homologous superfamily homologous superfamily20 —
Domain ID domain_id3oeeU02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeU03
Class class1 — Mainly Alpha
Architecture architecture20 — Up-down Bundle
Topology topology150 — Lysin
Homologous superfamily homologous superfamily20 — ATP synthase alpha/beta chain, C-terminal domain
Domain ID domain_id3oeeV01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology10 — Thrombin, subunit H
Homologous superfamily homologous superfamily170 —
Domain ID domain_id3oeeV02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeV03
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology1140 — Bovine Mitochondrial F1-ATPase, ATP Synthase Beta Chain; Chain D, domain3
Homologous superfamily homologous superfamily10 — Bovine Mitochondrial F1-atpase; Atp Synthase Beta Chain; Chain D, domain 3
Domain ID domain_id3oeeW01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology10 — Thrombin, subunit H
Homologous superfamily homologous superfamily170 —
Domain ID domain_id3oeeW02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeW03
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology1140 — Bovine Mitochondrial F1-ATPase, ATP Synthase Beta Chain; Chain D, domain3
Homologous superfamily homologous superfamily10 — Bovine Mitochondrial F1-atpase; Atp Synthase Beta Chain; Chain D, domain 3
Domain ID domain_id3oeeX01
Class class2 — Mainly Beta
Architecture architecture40 — Beta Barrel
Topology topology10 — Thrombin, subunit H
Homologous superfamily homologous superfamily170 —
Domain ID domain_id3oeeX02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily300 — P-loop containing nucleotide triphosphate hydrolases
Domain ID domain_id3oeeX03
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology1140 — Bovine Mitochondrial F1-ATPase, ATP Synthase Beta Chain; Chain D, domain3
Homologous superfamily homologous superfamily10 — Bovine Mitochondrial F1-atpase; Atp Synthase Beta Chain; Chain D, domain 3
Domain ID domain_id3oeeY01
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology287 — Helix Hairpins
Homologous superfamily homologous superfamily80 — ATP synthase, gamma subunit, helix hairpin domain
Domain ID domain_id3oeeY02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology1380 — Pyruvate Kinase; Chain: A, domain 1
Homologous superfamily homologous superfamily10 — ATP synthase, F1 complex, gamma subunit
▶

8. Citations (1)

▶

9. Files and Curves (10)
