6tyg

Crystal structure of MTB sigma L transcription initiation complex with 9 nt long RNA primer

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

RNA polymerase sigma factor

Mycobacterium tuberculosis

UniProt A0A045IR27

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Other combination Heteromer Protein 6 DNA 2 RNA 1 ;DNA (5'-D(*GP*CP*AP*TP*CP*CP*GP*TP*GP*AP*AP*TP*CP*GP*AP*GP*GP*GP*TP*G)-3') ; × 1 ;DNA (5'-D(P*GP*TP*GP*TP*CP*AP*GP*TP*AP*GP*CP*TP*GP*TP*CP*AP*CP*GP*GP*AP*TP*GP*C)-3') ; × 1 ;RNA (5'-R(P*CP*AP*CP*CP*CP*UP*CP*GP*A)-3') ; × 1 DNA-directed RNA polymerase subunit alpha × 2 （A5U8D3） DNA-directed RNA polymerase subunit beta × 1 （P9WGY8） ;DNA-directed RNA polymerase subunit beta' ; × 1 （A0A045J9E2） DNA-directed RNA polymerase subunit omega × 1 （A0A045H2R3） Consistent with all polymers

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
6tye 6tyf 6tyg 7rwi

4 assemblies

View Construct and Data Evidence
UniProt name A0A045IR27_MYCTX
Isoform —
PDB entities 1
Chains and sequence ranges Author chain F； PDBConstruct 1–177； UniProt 1–177

DNA-directed RNA polymerase subunit alpha

Mycobacterium tuberculosis

UniProt A5U8D3

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Other combination Heteromer Protein 6 DNA 2 RNA 1 RNA polymerase sigma factor × 1 （A0A045IR27） ;DNA (5'-D(*GP*CP*AP*TP*CP*CP*GP*TP*GP*AP*AP*TP*CP*GP*AP*GP*GP*GP*TP*G)-3') ; × 1 ;DNA (5'-D(P*GP*TP*GP*TP*CP*AP*GP*TP*AP*GP*CP*TP*GP*TP*CP*AP*CP*GP*GP*AP*TP*GP*C)-3') ; × 1 ;RNA (5'-R(P*CP*AP*CP*CP*CP*UP*CP*GP*A)-3') ; × 1 DNA-directed RNA polymerase subunit beta × 1 （P9WGY8） ;DNA-directed RNA polymerase subunit beta' ; × 1 （A0A045J9E2） DNA-directed RNA polymerase subunit omega × 1 （A0A045H2R3） Consistent with all polymers

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
6edt 6ee8 6eec 6m7j 6tye 6tyf 6tyg 6vvx 6vvy 6vvz 6vw0 7kif

27 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name RPOA_MYCTA
Isoform —
PDB entities 5
Chains and sequence ranges Author chain A； PDBConstruct 1–347； UniProt 1–347 Author chain B； PDBConstruct 1–347； UniProt 1–347

DNA-directed RNA polymerase subunit beta

Mycobacterium tuberculosis

UniProt P9WGY8

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Other combination Heteromer Protein 6 DNA 2 RNA 1 RNA polymerase sigma factor × 1 （A0A045IR27） ;DNA (5'-D(*GP*CP*AP*TP*CP*CP*GP*TP*GP*AP*AP*TP*CP*GP*AP*GP*GP*GP*TP*G)-3') ; × 1 ;DNA (5'-D(P*GP*TP*GP*TP*CP*AP*GP*TP*AP*GP*CP*TP*GP*TP*CP*AP*CP*GP*GP*AP*TP*GP*C)-3') ; × 1 ;RNA (5'-R(P*CP*AP*CP*CP*CP*UP*CP*GP*A)-3') ; × 1 DNA-directed RNA polymerase subunit alpha × 2 （A5U8D3） ;DNA-directed RNA polymerase subunit beta' ; × 1 （A0A045J9E2） DNA-directed RNA polymerase subunit omega × 1 （A0A045H2R3） Consistent with all polymers

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
6tye 6tyf 6tyg 7rwi 7u22 7zf2 9e84

7 assemblies

View Construct and Data Evidence
UniProt name RPOB_MYCTO
Isoform —
PDB entities 6
Chains and sequence ranges Author chain C； PDBConstruct 1–1178； UniProt 1–1178

;DNA-directed RNA polymerase subunit beta' ;

Mycobacterium tuberculosis

UniProt A0A045J9E2

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Other combination Heteromer Protein 6 DNA 2 RNA 1 RNA polymerase sigma factor × 1 （A0A045IR27） ;DNA (5'-D(*GP*CP*AP*TP*CP*CP*GP*TP*GP*AP*AP*TP*CP*GP*AP*GP*GP*GP*TP*G)-3') ; × 1 ;DNA (5'-D(P*GP*TP*GP*TP*CP*AP*GP*TP*AP*GP*CP*TP*GP*TP*CP*AP*CP*GP*GP*AP*TP*GP*C)-3') ; × 1 ;RNA (5'-R(P*CP*AP*CP*CP*CP*UP*CP*GP*A)-3') ; × 1 DNA-directed RNA polymerase subunit alpha × 2 （A5U8D3） DNA-directed RNA polymerase subunit beta × 1 （P9WGY8） DNA-directed RNA polymerase subunit omega × 1 （A0A045H2R3） Consistent with all polymers

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
6bzo 6c04 6c05 6c06 6tyf 6tyg 7kif 7kim 7kin 7rwi 7u22 8e74

16 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name A0A045J9E2_MYCTX
Isoform —
PDB entities 7
Chains and sequence ranges Author chain D； PDBConstruct 1–1316； UniProt 1–1316

DNA-directed RNA polymerase subunit omega

Mycobacterium tuberculosis

UniProt A0A045H2R3

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Other combination Heteromer Protein 6 DNA 2 RNA 1 RNA polymerase sigma factor × 1 （A0A045IR27） ;DNA (5'-D(*GP*CP*AP*TP*CP*CP*GP*TP*GP*AP*AP*TP*CP*GP*AP*GP*GP*GP*TP*G)-3') ; × 1 ;DNA (5'-D(P*GP*TP*GP*TP*CP*AP*GP*TP*AP*GP*CP*TP*GP*TP*CP*AP*CP*GP*GP*AP*TP*GP*C)-3') ; × 1 ;RNA (5'-R(P*CP*AP*CP*CP*CP*UP*CP*GP*A)-3') ; × 1 DNA-directed RNA polymerase subunit alpha × 2 （A5U8D3） DNA-directed RNA polymerase subunit beta × 1 （P9WGY8） ;DNA-directed RNA polymerase subunit beta' ; × 1 （A0A045J9E2） Consistent with all polymers

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
6tye 6tyf 6tyg 7rwi 7u22 9e7v 9e7y 9e84 9e85 9e86 9e87 9e88

16 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name A0A045H2R3_MYCTX
Isoform —
PDB entities 8
Chains and sequence ranges Author chain E； PDBConstruct 1–110； UniProt 1–110

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id6tyg
Deposition date deposition_date2019-08-08
Structure title titleCrystal structure of MTB sigma L transcription initiation complex with 9 nt long RNA primer
Keywords keywordstranscription, tuberculosis, initiation, sigma finger displacement; TRANSCRIPTION
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

6tyg__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

6tyg__assembly_1__model_1 | I(q)

10-2 10-1 106 107 108 109 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

6tyg__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）46.48 Å
Rg (electron density)46.26 Å
Total Rg46.46 Å
Atom count49186
Residues3113
Excluded volume436990 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 6tyg__assembly_1__model_1 nonameric （9） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (8)

▼

6. Fold Classification (SCOP + CATH) 6 domains

CATH v4.4 (6 domains)

Domain ID domain_id6tygA01
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology1360 — Gyrase A; domain 2
Homologous superfamily homologous superfamily10 — RNA polymerase, RBP11-like subunit
Domain ID domain_id6tygA02
Class class2 — Mainly Beta
Architecture architecture170 — Beta Complex
Topology topology120 — RNA Polymerase Alpha Subunit; Chain A, domain 2
Homologous superfamily homologous superfamily12 — DNA-directed RNA polymerase, insert domain
Domain ID domain_id6tygB01
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology1360 — Gyrase A; domain 2
Homologous superfamily homologous superfamily10 — RNA polymerase, RBP11-like subunit
Domain ID domain_id6tygB02
Class class2 — Mainly Beta
Architecture architecture170 — Beta Complex
Topology topology120 — RNA Polymerase Alpha Subunit; Chain A, domain 2
Homologous superfamily homologous superfamily12 — DNA-directed RNA polymerase, insert domain
Domain ID domain_id6tygD01
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology274 — Enzyme I; Chain A, domain 2
Homologous superfamily homologous superfamily100 — RNA polymerase Rpb1, domain 3
Domain ID domain_id6tygD02
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology132 — Topoisomerase I; Chain A, domain 4
Homologous superfamily homologous superfamily30 — RNA polymerase Rpb1 funnel domain
▶
