8vlf

Crystal structure of Ash1L PHD finger in complex with histone H3K4me3

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Histone-lysine N-methyltransferase ASH1L

Homo sapiens

UniProt Q9NR48

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 4 Histone H3.3C × 2 (Q6NXT2) ZINC ION × 4 water × 4 Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence
UniProt name ASH1L_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A; PDBConstruct 4–56; UniProt 2584–2636 Author chain B; PDBConstruct 4–56; UniProt 2584–2636

Histone H3.3C

OrganismNot specified

UniProt Q6NXT2

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 4 Histone-lysine N-methyltransferase ASH1L × 2 (Q9NR48) ZINC ION × 4 water × 4 Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence
UniProt name H3C_HUMAN
Isoform —
PDB entities 2
Chains and sequence ranges Author chain P; PDBConstruct 1–12; UniProt 2–13 Author chain T; PDBConstruct 1–12; UniProt 2–13

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id8vlf
Deposition date deposition_date2024-01-11
Structure title titleCrystal structure of Ash1L PHD finger in complex with histone H3K4me3
Keywords keywordsAsh1L, H3K4me2, zinc finger, transcriptional regulation, TRANSFERASE; TRANSFERASE
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

8vlf__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

8vlf__assembly_1__model_1 | I(q)

10-2 10-1 105 106 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

8vlf__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg(Guinier)16.96 Å
Rg (electron density)16.18 Å
Total Rg16.86 Å
Atom count1018
Residues128
Excluded volume18119 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 8vlf__assembly_1__model_1 tetrameric (4) Success 4.1.3-1-20251215 (887e7ef) View Download
▶
