8wma

Fzd4/DEP complex (local refined)

Method: ELECTRON MICROSCOPY
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Frizzled-4

Homo sapiens

UniProt Q9ULV1

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 2 Segment polarity protein dishevelled homolog DVL-2 × 1 (O14641) Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence
UniProt name FZD4_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A; PDBConstruct 1–537; UniProt 1–537

Segment polarity protein dishevelled homolog DVL-2

Homo sapiens

UniProt O14641

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 2 Frizzled-4 × 1 (Q9ULV1) Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence
UniProt name DVL2_HUMAN
Isoform —
PDB entities 2
Chains and sequence ranges Author chain C; PDBConstruct 1–736; UniProt 1–736

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id8wma
Deposition date deposition_date2023-10-03
Structure title titleFzd4/DEP complex (local refined)
Keywords keywordsGPCR complex, MEMBRANE PROTEIN; MEMBRANE PROTEIN
Experimental Method methodELECTRON MICROSCOPY
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

8wma__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

8wma__assembly_1__model_1 | I(q)

10-2 10-1 105 106 107 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

8wma__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg(Guinier)29.02 Å
Rg (electron density)27.86 Å
Total Rg28.37 Å
Atom count3172
Residues413
Excluded volume57430 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 8wma__assembly_1__model_1 dimeric (2) Success 4.1.3-1-20251215 (887e7ef) View Download
▶
