9lq1

Structure of human DNMT3A-TCL1A complex

Method: ELECTRON MICROSCOPY
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Isoform 1 of DNA (cytosine-5)-methyltransferase 3A

Homo sapiens

UniProt Q9Y6K1

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 6 T-cell leukemia/lymphoma protein 1A × 4 (P56279) ZINC ION × 6 Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence
UniProt name DNM3A_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A; PDBConstruct 1–912; UniProt 1–912 Author chain F; PDBConstruct 1–912; UniProt 1–912

T-cell leukemia/lymphoma protein 1A

Homo sapiens

UniProt P56279

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 6 Isoform 1 of DNA (cytosine-5)-methyltransferase 3A × 2 (Q9Y6K1) ZINC ION × 6 Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence
UniProt name TCL1A_HUMAN
Isoform —
PDB entities 2
Chains and sequence ranges Author chain B; PDBConstruct 1–114; UniProt 1–114 Author chain C; PDBConstruct 1–114; UniProt 1–114 Author chain D; PDBConstruct 1–114; UniProt 1–114 Author chain E; PDBConstruct 1–114; UniProt 1–114

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id9lq1
Deposition date deposition_date2025-01-27
Structure title titleStructure of human DNMT3A-TCL1A complex
Keywords keywordscomplex, TRANSFERASE; TRANSFERASE
Experimental Method methodELECTRON MICROSCOPY
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

9lq1__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

9lq1__assembly_1__model_1 | I(q)

10-2 10-1 106 107 108 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

9lq1__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg(Guinier)47.40 Å
Rg (electron density)48.24 Å
Total Rg48.08 Å
Atom count10649
Residues1307
Excluded volume189640 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 9lq1__assembly_1__model_1 hexameric (6) Success 4.1.3-1-20251215 (887e7ef) View Download
▶
