1ms7

X-ray structure of the GluR2 ligand-binding core (S1S2J) in complex with (S)-Des-Me-AMPA at 1.97 A resolution, Crystallization in the presence of zinc acetate

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Glutamate receptor subunit 2

Rattus norvegicus

UniProt P19491

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein homooligomer Homooligomer Protein 2 ZINC ION × 2 (S)-2-AMINO-3-(3-HYDROXY-ISOXAZOL-4-YL)PROPIONIC ACID × 2 water × 2 Consistent with protein count
2 Protein homooligomer Homooligomer Protein 2 ZINC ION × 8 (S)-2-AMINO-3-(3-HYDROXY-ISOXAZOL-4-YL)PROPIONIC ACID × 2 water × 2 Consistent with protein count
3 Protein homooligomer Homooligomer Protein 3 ZINC ION × 6 (S)-2-AMINO-3-(3-HYDROXY-ISOXAZOL-4-YL)PROPIONIC ACID × 3 water × 3 Consistent with protein count

Other States of the Same Protein in the Database

Monomer
1ftj 1ftj 1ftj 1ftk 1ftm 1ftm 1ftm 1fto 1fto 1fw0 1gr2 1lb8

57 assemblies; showing the first 12

Homodimer
1ftj 1ftl 1ftm 1m5b 1m5b 1m5c 1m5d 1m5e 1m5e 1m5f 1m5f 1mm6

242 assemblies; showing the first 12

Homotetramer
2i3v 4u1w 4u1x 4u1y 4u2p 4u2q 4u2r 4uq6 4uqj 4uqk 5jei 5kbv

48 assemblies; showing the first 12

Other homooligomers
1ftj 1ftm 1m5b 1m5e 1m5f 1ms7 1mxu 1mxv 1mxw 1mxx 1mxy 1mxz

21 assemblies; showing the first 12

Heteromeric or nucleic-acid complex
3h5v 3hsy 3kg2 4u4f 4u4g 4u5b 4u5c 4u5d 4u5e 4u5f 5fwx 5fwx

115 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name GRIA2_RAT
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 3–117； UniProt 413–527 Author chain A； PDBConstruct 120–263； UniProt 653–796 Author chain B； PDBConstruct 3–117； UniProt 413–527 Author chain B； PDBConstruct 120–263； UniProt 653–796 Author chain C； PDBConstruct 3–117； UniProt 413–527 Author chain C； PDBConstruct 120–263； UniProt 653–796

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id1ms7
Deposition date deposition_date2002-09-19
Structure title titleX-ray structure of the GluR2 ligand-binding core (S1S2J) in complex with (S)-Des-Me-AMPA at 1.97 A resolution, Crystallization in the presence of zinc acetate
Keywords keywordsIonotropic glutamate receptor GluR2, ligand-binding core, agonist complex, Membrane protein; MEMBRANE PROTEIN
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

1ms7__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

1ms7__assembly_1__model_1 | I(q)

10-2 10-1 106 107 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

1ms7__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）24.92 Å
Rg (electron density)23.75 Å
Total Rg24.79 Å
Atom count4060
Residues516
Excluded volume73092 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 1ms7__assembly_1__model_1 dimeric （2） Success 4.1.3-1-20251215 (887e7ef) View Download
2 1 1ms7__assembly_2__model_1 dimeric （2） Success 4.1.3-1-20251215 (887e7ef) View Download
3 1 1ms7__assembly_3__model_1 trimeric （3） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (4)

▼

6. Fold Classification (SCOP + CATH) 9 domains

SCOP 2.08 (3 domains)

Domain ID domain_idd1ms7a_
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.94 — Periplasmic binding protein-like II
Superfamily Superfamily superfamilyc.94.1 — Periplasmic binding protein-like II
Family Family familyc.94.1.1 — Phosphate binding protein-like
Domain ID domain_idd1ms7b_
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.94 — Periplasmic binding protein-like II
Superfamily Superfamily superfamilyc.94.1 — Periplasmic binding protein-like II
Family Family familyc.94.1.1 — Phosphate binding protein-like
Domain ID domain_idd1ms7c_
Class classc — Alpha and beta proteins (a/b)
Fold Fold foldc.94 — Periplasmic binding protein-like II
Superfamily Superfamily superfamilyc.94.1 — Periplasmic binding protein-like II
Family Family familyc.94.1.1 — Phosphate binding protein-like

CATH v4.4 (6 domains)

Domain ID domain_id1ms7A01
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology190 — D-Maltodextrin-Binding Protein; domain 2
Homologous superfamily homologous superfamily10 — Periplasmic binding protein-like II
Domain ID domain_id1ms7A02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology190 — D-Maltodextrin-Binding Protein; domain 2
Homologous superfamily homologous superfamily10 — Periplasmic binding protein-like II
Domain ID domain_id1ms7B01
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology190 — D-Maltodextrin-Binding Protein; domain 2
Homologous superfamily homologous superfamily10 — Periplasmic binding protein-like II
Domain ID domain_id1ms7B02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology190 — D-Maltodextrin-Binding Protein; domain 2
Homologous superfamily homologous superfamily10 — Periplasmic binding protein-like II
Domain ID domain_id1ms7C01
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology190 — D-Maltodextrin-Binding Protein; domain 2
Homologous superfamily homologous superfamily10 — Periplasmic binding protein-like II
Domain ID domain_id1ms7C02
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology190 — D-Maltodextrin-Binding Protein; domain 2
Homologous superfamily homologous superfamily10 — Periplasmic binding protein-like II
▶

7. Citations (5)
