9gc7

Mineralocorticoid receptor in complex with acylurea antagonists.

Method: X-RAY DIFFRACTION Dmax: 72.8 Å Quality: REASONABLE
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Mineralocorticoid receptor

Homo sapiens

UniProt P08235

State in the Current Structure

Assembly Oligomeric State Construct Mutations and Modifications Ligands, Ions and Associated Components Method and Experimental Conditions Structure Quality
1 Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count Chain A； UniProt 735–984 Mutation：C808S, S810L, C910S MPD (4S)-2-METHYL-2,4-PENTANEDIOL × 1 NHE 2-[N-CYCLOHEXYLAMINO]ETHANE SULFONIC ACID × 1 A1IJ6 (2S)-N-aminocarbonyl-2-[(4-cyano-6-cyclopropyl-cyclohexa-1,2,3,5-tetraen-1-yl)amino]propanamide × 1 X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；293.15 K；0.9 M AMS 0.1 M CHES pH 9.5 +10% Morpheus G8 Resolution 1.46 Å R-free 0.210

Other States of the Same Protein in the Database

Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.

Other PDB Difference from Current Entry 9GC7 Assembly / Oligomeric State Construct Mutations and Modifications Ligands, Ions and Non-polymers Method and Experimental Conditions Structure Quality
1Y9R Crystal structure of the human mineralocorticoid receptor ligand-binding domain bound to deoxycorticosterone and harboring the S810L mutation responsible for a severe form of hypertension Deposited 2004-12-16 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 731–984（254 aa） Fragment：LIGAND-BINDING DOMAIN
Mutation：S810L, C910A 1CA DESOXYCORTICOSTERONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7；297 K；PEG 4000, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 297K
Resolution 1.96 Å R-free 0.267
1Y9R Crystal structure of the human mineralocorticoid receptor ligand-binding domain bound to deoxycorticosterone and harboring the S810L mutation responsible for a severe form of hypertension Deposited 2004-12-16 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 731–984（254 aa） Fragment：LIGAND-BINDING DOMAIN
Mutation：S810L, C910A 1CA DESOXYCORTICOSTERONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7；297 K；PEG 4000, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 297K
Resolution 1.96 Å R-free 0.267
1YA3 Crystal structure of the human mineralocorticoid receptor ligand-binding domain bound to progesterone and harboring the S810L mutation responsible for a severe form of hypertension Deposited 2004-12-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 731–984（254 aa） Fragment：LIGAND-BINDING DOMAIN
Mutation：S810L, C910A STR PROGESTERONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.8；297 K；PEG 4000, pH 6.8, VAPOR DIFFUSION, HANGING DROP, temperature 297K
Resolution 2.34 Å R-free 0.284
1YA3 Crystal structure of the human mineralocorticoid receptor ligand-binding domain bound to progesterone and harboring the S810L mutation responsible for a severe form of hypertension Deposited 2004-12-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 731–984（254 aa） Fragment：LIGAND-BINDING DOMAIN
Mutation：S810L, C910A STR PROGESTERONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.8；297 K；PEG 4000, pH 6.8, VAPOR DIFFUSION, HANGING DROP, temperature 297K
Resolution 2.34 Å R-free 0.284
1YA3 Crystal structure of the human mineralocorticoid receptor ligand-binding domain bound to progesterone and harboring the S810L mutation responsible for a severe form of hypertension Deposited 2004-12-17 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain C 731–984（254 aa） Fragment：LIGAND-BINDING DOMAIN
Mutation：S810L, C910A STR PROGESTERONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.8；297 K；PEG 4000, pH 6.8, VAPOR DIFFUSION, HANGING DROP, temperature 297K
Resolution 2.34 Å R-free 0.284
2A3I Structural and Biochemical Mechanisms for the Specificity of Hormone Binding and Coactivator Assembly by Mineralocorticoid Receptor Deposited 2005-06-24 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain A 732–984（253 aa） Fragment：Mineralocoricoid receptor
Mutation：C808S C0R CORTICOSTERONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 7.9；293 K；PEG mme5K, Sodium Acetate, 1-6 Hexanediol, pH 7.9, VAPOR DIFFUSION, temperature 293K
Resolution 1.95 Å R-free 0.253
2AA2 Mineralocorticoid Receptor with Bound Aldosterone Deposited 2005-07-13 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 712–984（273 aa）
Mutation：C808S BOG octyl beta-D-glucopyranoside × 1 SO4 SULFATE ION × 1 AS4 ALDOSTERONE × 1 GOL GLYCEROL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；0.1M Hepes pH7.5, 0.9M Lithium Sulfate, 2% PEG2KMME, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 1.95 Å R-free 0.235
2AA5 Mineralocorticoid Receptor with Bound Progesterone Deposited 2005-07-13 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 712–984（273 aa） Fragment：Ligand Binding Domain
Mutation：C808S STR PROGESTERONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；0.1m Hepes pH7.5, 0.9M Li2SO4, 2% PEG 2KMME, vapor diffusion, hanging drop, temperature 298K
Resolution 2.20 Å R-free 0.264
2AA5 Mineralocorticoid Receptor with Bound Progesterone Deposited 2005-07-13 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 712–984（273 aa） Fragment：Ligand Binding Domain
Mutation：C808S STR PROGESTERONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；0.1m Hepes pH7.5, 0.9M Li2SO4, 2% PEG 2KMME, vapor diffusion, hanging drop, temperature 298K
Resolution 2.20 Å R-free 0.264
2AA6 Mineralocorticoid Receptor S810L Mutant with Bound Progesterone Deposited 2005-07-13 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 712–984（273 aa） Fragment：Ligand Binding Domain
Mutation：C808S, S810L STR PROGESTERONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；0.1m Hepes pH7.5, 0.9M Li2SO4, 2% PEG 2KMME, vapor diffusion, hanging drop, temperature 298K
Resolution 1.95 Å R-free 0.225
2AA6 Mineralocorticoid Receptor S810L Mutant with Bound Progesterone Deposited 2005-07-13 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 712–984（273 aa） Fragment：Ligand Binding Domain
Mutation：C808S, S810L STR PROGESTERONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；0.1m Hepes pH7.5, 0.9M Li2SO4, 2% PEG 2KMME, vapor diffusion, hanging drop, temperature 298K
Resolution 1.95 Å R-free 0.225
2AA7 Mineralocorticoid Receptor with Bound Deoxycorticosterone Deposited 2005-07-13 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 712–984（273 aa） Fragment：Ligand Binding Domain
Mutation：C808S SO4 SULFATE ION × 1 1CA DESOXYCORTICOSTERONE × 1 GOL GLYCEROL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；0.1m Hepes pH7.5, 0.9M Li2SO4, 2% PEG 2KMME, vapor diffusion, hanging drop, temperature 298K
Resolution 2.20 Å R-free 0.264
2AAX Mineralocorticoid Receptor Double Mutant with Bound Cortisone Deposited 2005-07-14 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 712–984（273 aa） Fragment：Ligand Binding Domain
Chain B 712–984（273 aa） Fragment：Ligand Binding Domain
Mutation：C808S, S810L Mutation：C808S, S810L SO4 SULFATE ION × 1 PDN 17,21-DIHYDROXYPREGNA-1,4-DIENE-3,11,20-TRIONE × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；0.1m Hepes pH7.5, 0.9M Li2SO4, 2% PEG 2KMME, vapor diffusion, hanging drop, temperature 298K
Resolution 1.75 Å R-free 0.212
2AB2 Mineralocorticoid Receptor Double Mutant with Bound Spironolactone Deposited 2005-07-14 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 712–984（273 aa） Fragment：MR Ligand Binding Domain
Chain B 712–984（273 aa） Fragment：MR Ligand Binding Domain
Mutation：C808S, S810L Mutation：C808S, S810L SNL SPIRONOLACTONE × 2 SO4 SULFATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；0.1m Hepes pH7.5, 0.9M Li2SO4, 2% PEG 2KMME, vapor diffusion, hanging drop, temperature 298K
Resolution 1.85 Å R-free 0.218
2ABI Crystal structure of the human mineralocorticoid receptor ligand-binding domain bound to deoxycorticosterone Deposited 2005-07-15 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 731–984（254 aa） Fragment：LIGAND-BINDING DOMAIN
Mutation：C910A 1CA DESOXYCORTICOSTERONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.1；297 K；PEG4000, HEPES, pH 7.1, VAPOR DIFFUSION, HANGING DROP, temperature 297K
Resolution 2.33 Å R-free 0.264
2ABI Crystal structure of the human mineralocorticoid receptor ligand-binding domain bound to deoxycorticosterone Deposited 2005-07-15 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 731–984（254 aa） Fragment：LIGAND-BINDING DOMAIN
Mutation：C910A 1CA DESOXYCORTICOSTERONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.1；297 K；PEG4000, HEPES, pH 7.1, VAPOR DIFFUSION, HANGING DROP, temperature 297K
Resolution 2.33 Å R-free 0.264
2ABI Crystal structure of the human mineralocorticoid receptor ligand-binding domain bound to deoxycorticosterone Deposited 2005-07-15 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain C 731–984（254 aa） Fragment：LIGAND-BINDING DOMAIN
Mutation：C910A 1CA DESOXYCORTICOSTERONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.1；297 K；PEG4000, HEPES, pH 7.1, VAPOR DIFFUSION, HANGING DROP, temperature 297K
Resolution 2.33 Å R-free 0.264
2OAX Crystal structure of the S810L mutant mineralocorticoid receptor associated with SC9420 Deposited 2006-12-18 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 731–984（254 aa） Fragment：LIGAND-BINDING DOMAIN
Mutation：S810L,C910A SNL SPIRONOLACTONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.8；297 K；HEPES 100 mM, pH 6.8, 230 mM NaCl, 25% PEG4000, VAPOR DIFFUSION, HANGING DROP, temperature 297K
Resolution 2.29 Å R-free 0.263
2OAX Crystal structure of the S810L mutant mineralocorticoid receptor associated with SC9420 Deposited 2006-12-18 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 731–984（254 aa） Fragment：LIGAND-BINDING DOMAIN
Mutation：S810L,C910A SNL SPIRONOLACTONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.8；297 K；HEPES 100 mM, pH 6.8, 230 mM NaCl, 25% PEG4000, VAPOR DIFFUSION, HANGING DROP, temperature 297K
Resolution 2.29 Å R-free 0.263
2OAX Crystal structure of the S810L mutant mineralocorticoid receptor associated with SC9420 Deposited 2006-12-18 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain C 731–984（254 aa） Fragment：LIGAND-BINDING DOMAIN
Mutation：S810L,C910A SNL SPIRONOLACTONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.8；297 K；HEPES 100 mM, pH 6.8, 230 mM NaCl, 25% PEG4000, VAPOR DIFFUSION, HANGING DROP, temperature 297K
Resolution 2.29 Å R-free 0.263
2OAX Crystal structure of the S810L mutant mineralocorticoid receptor associated with SC9420 Deposited 2006-12-18 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain D 731–984（254 aa） Fragment：LIGAND-BINDING DOMAIN
Mutation：S810L,C910A SNL SPIRONOLACTONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.8；297 K；HEPES 100 mM, pH 6.8, 230 mM NaCl, 25% PEG4000, VAPOR DIFFUSION, HANGING DROP, temperature 297K
Resolution 2.29 Å R-free 0.263
2OAX Crystal structure of the S810L mutant mineralocorticoid receptor associated with SC9420 Deposited 2006-12-18 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 5 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain E 731–984（254 aa） Fragment：LIGAND-BINDING DOMAIN
Mutation：S810L,C910A SNL SPIRONOLACTONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.8；297 K；HEPES 100 mM, pH 6.8, 230 mM NaCl, 25% PEG4000, VAPOR DIFFUSION, HANGING DROP, temperature 297K
Resolution 2.29 Å R-free 0.263
2OAX Crystal structure of the S810L mutant mineralocorticoid receptor associated with SC9420 Deposited 2006-12-18 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 6 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain F 731–984（254 aa） Fragment：LIGAND-BINDING DOMAIN
Mutation：S810L,C910A SNL SPIRONOLACTONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.8；297 K；HEPES 100 mM, pH 6.8, 230 mM NaCl, 25% PEG4000, VAPOR DIFFUSION, HANGING DROP, temperature 297K
Resolution 2.29 Å R-free 0.263
3VHU Mineralocorticoid receptor ligand-binding domain with spironolactone Deposited 2011-09-07 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 712–984（273 aa） Fragment：LIGAND-BINDING DOMAIN, UNP residues 712-984
Mutation：C808S, S810L SNL SPIRONOLACTONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；293 K；0.1M HEPES pH 7.0, 1.26M Lithium sulfate, 6% PEG MME 2000, VAPOR DIFFUSION, SITTING DROP, temperature 293K
Resolution 2.11 Å R-free 0.246
3VHV Mineralocorticoid receptor ligand-binding domain with non-steroidal antagonist Deposited 2011-09-07 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 727–984（258 aa） Fragment：LIGAND-BINDING DOMAIN, UNP residues 727-984
Mutation：C808S, S810L, A976V LD1 6-[(7S)-7-phenyl-7H-[1,2,4]triazolo[3,4-b][1,3,4]thiadiazin-6-yl]-2H-1,4-benzoxazin-3(4H)-one × 1 LD2 6-[(1E)-2-phenyl-N-(3-sulfanyl-4H-1,2,4-triazol-4-yl)ethanimidoyl]-2H-1,4-benzoxazin-3(4H)-one × 1 EDO 1,2-ETHANEDIOL × 2 K POTASSIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.4；293 K；0.1M HEPES pH 7.4, 0.88M potassium/sodium tartrate, 5% ethylene glycol, VAPOR DIFFUSION, SITTING DROP, temperature 293K
Resolution 1.35 Å R-free 0.167
3WFF Mineralocorticoid receptor ligand-binding domain with compound 2b Deposited 2013-07-19 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 712–984（273 aa） Fragment：LIGAND-BINDING DOMAIN, UNP residues 712-984
Mutation：C808S, S810L, A976V WFF 6-[4-(2,4-difluorophenyl)-5-oxo-2,5-dihydrofuran-3-yl]-2H-1,4-benzoxazin-3(4H)-one × 1 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.2；293 K；0.04M potassium dihydrogen phosphate, 16% PEG 8000, 20% glycerol, pH 7.2, VAPOR DIFFUSION, SITTING DROP, temperature 293K
Resolution 2.05 Å R-free 0.216
3WFG Mineralocorticoid receptor ligand-binding domain with compuond 2e Deposited 2013-07-19 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 712–984（273 aa） Fragment：LIGAND-BINDING DOMAIN, UNP residues 712-984
Mutation：C808S, S810L, A976V WFG 6-[(2S)-4-(4-fluorophenyl)-2-methyl-5-oxo-2,5-dihydrofuran-3-yl]-2H-1,4-benzoxazin-3(4H)-one × 1 EDO 1,2-ETHANEDIOL × 13 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.8；293 K；0.1M Tris, 23% ethanol, pH 7.8, VAPOR DIFFUSION, SITTING DROP, temperature 293K
Resolution 1.40 Å R-free 0.179
4PF3 Mineralocorticoid receptor ligand-binding domain with compuond 37a Deposited 2014-04-28 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 716–988（273 aa） Fragment：UNP residues 716-988
Mutation：C808S, S810L, A976V HFN 6-[1-(2,2-difluoro-3-hydroxypropyl)-5-(4-fluorophenyl)-3-methyl-1H-pyrazol-4-yl]-2H-1,4-benzoxazin-3(4H)-one × 1 EDO 1,2-ETHANEDIOL × 8 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；0.1M Tris pH 8.0, 23% ethanol
Resolution 1.10 Å R-free 0.177
4TNT Structure of the human mineralocorticoid receptor in complex with DNA Deposited 2014-06-04 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–DNA Homooligomer；Protein × 2 PDB declaration: tetrameric
Chain A 593–671（79 aa）
Chain B 593–671（79 aa）
Not recorded ZN ZINC ION × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；298 K；0.2 M sodium malonate, 12 % PEG 3350
Resolution 2.39 Å R-free 0.258
4UDA MR in complex with dexamethasone Deposited 2014-12-09 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain A 735–984（250 aa） Fragment：LIGAND BINDING DOMAIN, RESIDUES 735-984
Mutation：YES GOL GLYCEROL × 1 DEX DEXAMETHASONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.5；30% PEG4000, 0.1M NACL, 0.2M PIPES PH 7.5
Resolution 2.03 Å R-free 0.240
4UDB MR in complex with desisobutyrylciclesonide Deposited 2014-12-09 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain A 735–984（250 aa） Fragment：LIGAND BINDING DOMAIN, RESIDUES 735-984
Mutation：YES DMS DIMETHYL SULFOXIDE × 1 GOL GLYCEROL × 1 SO4 SULFATE ION × 1 CV7 DESISOBUYTYRYL CICLESONIDE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions pH 8.5；18% PEG4K, 0.14M LISO4, 85MM TRIS PH 8.5, 15% GLYCEROL
Resolution 2.36 Å R-free 0.218
5HCV Identification of Spirooxindole and Dibenzoxazepine Motifs as Potent Mineralocorticoid Receptor Antagonists Deposited 2016-01-04 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 732–984（253 aa） Fragment：ligand-binding domain (UNP residues 732-984)
Mutation：C808S 60R 6-[(~{E})-(3-fluoranyl-6~{H}-benzo[c][1]benzoxepin-11-ylidene)methyl]-4~{H}-1,4-benzoxazin-3-one × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；294 K；1uL of protein complex at 8-10mg protein/ml is mixed with an equal volume of reservoir solution composed of 100mM Tris-HCl pH=8.0, 200mM NaCl, 5% (v/v) glycerol, 16%(w/v) PEG3350
Resolution 2.50 Å R-free 0.256
5HCV Identification of Spirooxindole and Dibenzoxazepine Motifs as Potent Mineralocorticoid Receptor Antagonists Deposited 2016-01-04 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 732–984（253 aa） Fragment：ligand-binding domain (UNP residues 732-984)
Mutation：C808S 60R 6-[(~{E})-(3-fluoranyl-6~{H}-benzo[c][1]benzoxepin-11-ylidene)methyl]-4~{H}-1,4-benzoxazin-3-one × 1 CL CHLORIDE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；294 K；1uL of protein complex at 8-10mg protein/ml is mixed with an equal volume of reservoir solution composed of 100mM Tris-HCl pH=8.0, 200mM NaCl, 5% (v/v) glycerol, 16%(w/v) PEG3350
Resolution 2.50 Å R-free 0.256
5HCV Identification of Spirooxindole and Dibenzoxazepine Motifs as Potent Mineralocorticoid Receptor Antagonists Deposited 2016-01-04 Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain C 732–984（253 aa） Fragment：ligand-binding domain (UNP residues 732-984)
Mutation：C808S 60R 6-[(~{E})-(3-fluoranyl-6~{H}-benzo[c][1]benzoxepin-11-ylidene)methyl]-4~{H}-1,4-benzoxazin-3-one × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；294 K；1uL of protein complex at 8-10mg protein/ml is mixed with an equal volume of reservoir solution composed of 100mM Tris-HCl pH=8.0, 200mM NaCl, 5% (v/v) glycerol, 16%(w/v) PEG3350
Resolution 2.50 Å R-free 0.256
5L7E MCR IN COMPLEX WITH ligand Deposited 2016-06-03 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain A 735–984（250 aa）
Not recorded NHE 2-[N-CYCLOHEXYLAMINO]ETHANE SULFONIC ACID × 1 MPD (4S)-2-METHYL-2,4-PENTANEDIOL × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 2 6Q0 ~{N}-[[4-(3,5-dimethyl-1,2-oxazol-4-yl)phenyl]methyl]benzenesulfonamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions EVAPORATION；293 K；1.6 M AMS 0.1 M CHES pH 9.5 15% EG 10% Morpheus F12
Resolution 1.86 Å R-free 0.197
5L7G MCR IN COMPLEX WITH ligand Deposited 2016-06-03 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain A 739–988（250 aa）
Not recorded EDO 1,2-ETHANEDIOL × 1 6QE ~{N}-[[4-[5-[[2,3-bis(fluoranyl)phenoxy]methyl]-3-methyl-1,2-oxazol-4-yl]phenyl]methyl]-1-methyl-cyclopropane-1-sulfonamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions EVAPORATION；293 K；0.9 M AMS 0.1 M CHES pH 9.5 +10% Morpheus C9
Resolution 2.01 Å R-free 0.243
5L7H MCR IN COMPLEX WITH ligand Deposited 2016-06-03 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain A 735–984（250 aa）
Not recorded 6QG 3-methyl-5,8-dioxa-17lambda-thia-4,18-diazatetracyclo[18.2.2.1,.0]pentacosa-1(22),2(6),3,9,11,13(25),20,23-octaene-17,17-dione × 1 NHE 2-[N-CYCLOHEXYLAMINO]ETHANE SULFONIC ACID × 1 X-RAY DIFFRACTION
X-ray crystallization conditions EVAPORATION；293 K；0.9 M AMS 0.1 M CHES pH 9.5 +10% Morpheus G5
Resolution 1.84 Å R-free 0.224
5MWP The structure of MR in complex with AZD9977. Deposited 2017-01-19 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 735–984（250 aa）
Mutation：C808S, C910S ECV 2-[(3~{S})-7-fluoranyl-4-[(3-oxidanylidene-4~{H}-1,4-benzoxazin-6-yl)carbonyl]-2,3-dihydro-1,4-benzoxazin-3-yl]-~{N}-methyl-ethanamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M (NH4)2SO4, 0.1 M CHES pH 9.5, and 10% (v/v) of conditions E5 from the Morpheus Screen (Molecular Dimensions).
Resolution 1.82 Å R-free 0.242
5MWY The structure of MR in complex with eplerenone. Deposited 2017-01-20 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 735–984（250 aa）
Not recorded YNU eplerenone × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M (NH4)2SO4, 0.1 M CHES pH 9.5, and 10% (v/v) of conditions G6 from the Morpheus Screen (Molecular Dimensions)
Resolution 1.75 Å R-free 0.245
6GEV Mineralocorticoid receptor in complex with (s)-13 Deposited 2018-04-27 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain A 735–984（250 aa）
Not recorded GOL GLYCEROL × 3 EWN 6-[[(3~{S})-7-fluoranyl-3-(2-methylpropyl)-2,3-dihydro-1,4-benzoxazin-4-yl]carbonyl]-4~{H}-1,4-benzoxazin-3-one × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M (NH4)2SO4, 3.5% 1,4-butanediol, 0.1 M CHES pH 9.5
Resolution 1.54 Å R-free 0.190
6GG8 Mineralocorticoid receptor in complex with (s)-13 Deposited 2018-05-03 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain A 735–984（250 aa）
Not recorded MPD (4S)-2-METHYL-2,4-PENTANEDIOL × 1 EY8 [(3~{R})-7-fluoranyl-4-[(3-oxidanylidene-4~{H}-1,4-benzoxazin-6-yl)carbonyl]-2,3-dihydro-1,4-benzoxazin-3-yl]methanesulfonamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；293 K；0.9M (NH4)2SO4, 0.1 M CHES pH9.5, 10% (v/v) of condition C8 of the Morpheus Screen (Molecular Dimension)
Resolution 1.80 Å R-free 0.228
6GGG Mineralocorticoid receptor in complex with (s)-13 Deposited 2018-05-03 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain A 735–984（250 aa）
Not recorded CL CHLORIDE ION × 1 EYN 2-[(3~{S})-7-fluoranyl-6-(2-methylpropyl)-4-[(3-oxidanylidene-4~{H}-1,4-benzoxazin-6-yl)carbonyl]-2,3-dihydro-1,4-benzoxazin-3-yl]-~{N}-methyl-ethanamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；293 K；Condition C2 of the morpheus screen (Molecular Dimension).
Resolution 1.71 Å R-free 0.192
6L88 Crystal structure of mineralocorticoid receptor ligand binding domain in complex with esaxerenone Deposited 2019-11-05 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 735–984（250 aa）
Chain D 735–984（250 aa）
Mutation：C808S,C910S Mutation：C808S,C910S E6R 1-(2-hydroxyethyl)-4-methyl-N-(4-methylsulfonylphenyl)-5-[2-(trifluoromethyl)phenyl]pyrrole-3-carboxamide × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；2.0-2.5 M sodium nitrate, 0.1 M Tris-HCl pH 8.0
Resolution 3.00 Å R-free 0.307
6L88 Crystal structure of mineralocorticoid receptor ligand binding domain in complex with esaxerenone Deposited 2019-11-05 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric
Chain B 735–984（250 aa）
Chain C 735–984（250 aa）
Mutation：C808S,C910S Mutation：C808S,C910S E6R 1-(2-hydroxyethyl)-4-methyl-N-(4-methylsulfonylphenyl)-5-[2-(trifluoromethyl)phenyl]pyrrole-3-carboxamide × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；2.0-2.5 M sodium nitrate, 0.1 M Tris-HCl pH 8.0
Resolution 3.00 Å R-free 0.307

29 other PDB entries and 44 assemblies. Open the comparison page and filter oligomeric states

View Construct and Data Evidence
UniProt name MCR_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 23–272； UniProt 735–984

Nuclear receptor coactivator 1

Homo sapiens

UniProt Q15788

State in the Current Structure

Assembly Oligomeric State Construct Mutations and Modifications Ligands, Ions and Associated Components Method and Experimental Conditions Structure Quality
2 Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count Chain B； UniProt 1430–1441 Not recorded No other associated polymer X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；293.15 K；0.9 M AMS 0.1 M CHES pH 9.5 +10% Morpheus G8 Resolution 1.46 Å R-free 0.210

Other States of the Same Protein in the Database

Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.

Other PDB Difference from Current Entry 9GC7 Assembly / Oligomeric State Construct Mutations and Modifications Ligands, Ions and Non-polymers Method and Experimental Conditions Structure Quality
1TFC CRYSTAL STRUCTURE OF THE LIGAND-BINDING DOMAIN OF THE ESTROGEN-RELATED RECEPTOR GAMMA IN COMPLEX WITH A STEROID RECEPTOR COACTIVATOR-1 PEPTIDE Deposited 2004-05-27 Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 686–700（15 aa） Fragment：SECOND NR-BOX
Chain D 686–700（15 aa） Fragment：SECOND NR-BOX
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；TRIS.HCL, AMMONIUM SULFATE, GLYCEROL, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 2.40 Å R-free 0.258
1XIU Crystal structure of the agonist-bound ligand-binding domain of Biomphalaria glabrata RXR Deposited 2004-09-22 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 8 PDB declaration: octameric
Chain E 686–700（15 aa）
Chain F 686–700（15 aa）
Not recorded 9CR (9cis)-retinoic acid × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；HEPES, sodium formate, sodium chloride, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
Resolution 2.50 Å R-free 0.243
1ZAF Crystal structure of estrogen receptor beta complexed with 3-Bromo-6-hydroxy-2-(4-hydroxy-phenyl)-inden-1-one Deposited 2005-04-06 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 630–640（11 aa）
Chain D 630–640（11 aa）
Not recorded 789 3-BROMO-6-HYDROXY-2-(4-HYDROXYPHENYL)-1H-INDEN-1-ONE × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 7.5；291 K；15% PEG3350, 0.2M Mg Acetate, pH 7.5, VAPOR DIFFUSION, temperature 291K
Resolution 2.20 Å R-free 0.286
2A3I Structural and Biochemical Mechanisms for the Specificity of Hormone Binding and Coactivator Assembly by Mineralocorticoid Receptor Deposited 2005-06-24 Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 1430–1441（12 aa）
Not recorded C0R CORTICOSTERONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 7.9；293 K；PEG mme5K, Sodium Acetate, 1-6 Hexanediol, pH 7.9, VAPOR DIFFUSION, temperature 293K
Resolution 1.95 Å R-free 0.253
2C52 Structural diversity in CBP p160 complexes Deposited 2005-10-25 Different construct Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 920–970（51 aa） Fragment：AD1, RESIDUES 920-970
Not recorded No recorded non-water small molecule SOLUTION NMR
NMR measurement conditions pH 7；298 K；Ionic strength (raw mmCIF value) 100
NMR measurement conditions pH 7；298 K；Ionic strength (raw mmCIF value) 100
NMR measurement conditions pH 7；298 K；Ionic strength (raw mmCIF value) 100
NMR measurement conditions pH 7；298 K；Ionic strength (raw mmCIF value) 100
NMR sample composition 90% WATER/10% D2O
NMR sample composition 90% WATER/10% D2O
NMR sample composition 100% D2O
NMR sample composition 100% D2O
Resolution not provided
2FVJ A novel anti-adipogenic partial agonist of peroxisome proliferator-activated receptor-gamma (PPARG) recruits pparg-coactivator-1 alpha (PGC1A) but potentiates insulin signaling in vitro Deposited 2006-01-31 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 628–640（13 aa） Fragment：COACTIVATOR FRAGMENT SRC-1, 13-mer peptide from Nuclear receptor coactivator 1
Not recorded RO0 1-(3,4-DIMETHOXYBENZYL)-6,7-DIMETHOXY-4-{[4-(2-METHOXYPHENYL)PIPERIDIN-1-YL]METHYL}ISOQUINOLINE × 1 GOL GLYCEROL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8.5；293 K；20% PEG3350, 0.2M magnesium chloride, 0.1M Tris, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
Resolution 1.99 Å R-free 0.246
2GTK Structure-based Design of Indole Propionic Acids as Novel PPARag CO-Agonists Deposited 2006-04-28 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 631–640（10 aa） Fragment：residues 631-640
Not recorded 208 (2S)-3-(1-{[2-(2-CHLOROPHENYL)-5-METHYL-1,3-OXAZOL-4-YL]METHYL}-1H-INDOL-5-YL)-2-ETHOXYPROPANOIC ACID × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8.5；293 K；0.1M TRIS, PEG 3350, 0.2M MGSO4, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
Resolution 2.10 Å R-free 0.261
2HBH Crystal structure of Vitamin D nuclear receptor ligand binding domain bound to a locked side-chain analog of calcitriol and SRC-1 peptide Deposited 2006-06-14 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa）
Not recorded XE4 1,3-CYCLOHEXANEDIOL, 4-METHYLENE-5-[(2E)-[(1S,3AS,7AS)-OCTAHYDRO-1-(5-HYDROXY-5-METHYL-1,3-HEXADIYNYL)-7A-METHYL-4H-INDEN-4-YLIDENE]ETHYLIDENE]-, (1R,3S,5Z) × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；Li sulfate 1.6M, Mg sulfate 50mM, Bis Tris 0.1M, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 2.65 Å R-free 0.261
2HC4 Crystal structure of the LBD of VDR of Danio rerio in complex with calcitriol Deposited 2006-06-15 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa）
Not recorded VDX 5-{2-[1-(5-HYDROXY-1,5-DIMETHYL-HEXYL)-7A-METHYL-OCTAHYDRO-INDEN-4-YLIDENE]-ETHYLIDENE}-4-METHYLENE-CYCLOHEXANE-1,3-DIOL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；Li sulfate 1.6M, Mg sulfate 50mM, Bis Tris 0.1M, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 2.20 Å R-free 0.250
2HCD Crystal structure of the ligand binding domain of the Vitamin D nuclear receptor in complex with Gemini and a coactivator peptide Deposited 2006-06-16 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa）
Not recorded BIV 21-NOR-9,10-SECOCHOLESTA-5,7,10(19)-TRIENE-1,3,25-TRIOL, 20-(4-HYDROXY-4-METHYLPENTYL)-, (1A,3B,5Z,7E) × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；Li sulfate 1.6M, Mgsulfate 50mM, Bis tris 0.1M, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 2.60 Å R-free 0.260
2NV7 Crystal Structure of Estrogen Receptor Beta Complexed with WAY-555 Deposited 2006-11-10 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 631–640（10 aa）
Chain D 631–640（10 aa）
Not recorded 555 4-(4-HYDROXYPHENYL)-1-NAPHTHALDEHYDE OXIME × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；291 K；precipitant: PEG3350, Mg formate, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 2.10 Å R-free 0.265
2P54 a crystal structure of PPAR alpha bound with SRC1 peptide and GW735 Deposited 2007-03-14 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 686–696（11 aa） Fragment：SRC1 peptide
Not recorded 735 2-METHYL-2-(4-{[({4-METHYL-2-[4-(TRIFLUOROMETHYL)PHENYL]-1,3-THIAZOL-5-YL}CARBONYL)AMINO]METHYL}PHENOXY)PROPANOIC ACID × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7；295 K；7% PEG 3350, 200 mM NaF, 12% 2,5-hexanediol, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 295K
Resolution 1.79 Å R-free 0.227
3BEJ Structure of human FXR in complex with MFA-1 and co-activator peptide Deposited 2007-11-19 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain E 676–700（25 aa） Fragment：residues 676-700
Not recorded YT3 YTTRIUM (III) ION × 1 MUF (8alpha,10alpha,13alpha,17beta)-17-[(4-hydroxyphenyl)carbonyl]androsta-3,5-diene-3-carboxylic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；16-22% PEG3350, 0.1M Bis-Tris, 4 mM YCl(3), 0.2M Ammonium acetate, 1 mM DTT. Protein was carboxymethylated with iodoacetic acid, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
Resolution 1.90 Å R-free 0.254
3BEJ Structure of human FXR in complex with MFA-1 and co-activator peptide Deposited 2007-11-19 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain F 676–700（25 aa） Fragment：residues 676-700
Not recorded YT3 YTTRIUM (III) ION × 1 MUF (8alpha,10alpha,13alpha,17beta)-17-[(4-hydroxyphenyl)carbonyl]androsta-3,5-diene-3-carboxylic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；16-22% PEG3350, 0.1M Bis-Tris, 4 mM YCl(3), 0.2M Ammonium acetate, 1 mM DTT. Protein was carboxymethylated with iodoacetic acid, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
Resolution 1.90 Å R-free 0.254
3BQD Doubling the Size of the Glucocorticoid Receptor Ligand Binding Pocket by Deacylcortivazol Deposited 2007-12-20 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 1429–1441（13 aa） Fragment：nuclear receptor coactivator 1 isoform 1 coactivator motif (residues 739-751)
Not recorded DAY 1-[(1R,2R,3aS,3bS,10aR,10bS,11S,12aS)-1,11-dihydroxy-2,5,10a,12a-tetramethyl-7-phenyl-1,2,3,3a,3b,7,10,10a,10b,11,12,12a-dodecahydrocyclopenta[5,6]naphtho[1,2-f]indazol-1-yl]-2-hydroxyethanone × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8.5；298 K；1.3 M ammonium sulfate, 100 mM Tris, 8% glycerol, 3 mM n-hexadecyl-beta-maltoside, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.0K
Resolution 2.50 Å R-free 0.261
3CTB Tethered PXR-LBD/SRC-1p apoprotein Deposited 2008-04-11 Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain A 678–700（23 aa） Fragment：PXR, residues 130-434, linker, SRC-1, residues 678-700
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 7；277 K；10-30% MPD or isopropanol, 100 mM imidazole, pH 7, VAPOR DIFFUSION, temperature 277K
Resolution 2.00 Å R-free 0.244
3CTB Tethered PXR-LBD/SRC-1p apoprotein Deposited 2008-04-11 Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 2 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain B 678–700（23 aa） Fragment：PXR, residues 130-434, linker, SRC-1, residues 678-700
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 7；277 K；10-30% MPD or isopropanol, 100 mM imidazole, pH 7, VAPOR DIFFUSION, temperature 277K
Resolution 2.00 Å R-free 0.244
3CTB Tethered PXR-LBD/SRC-1p apoprotein Deposited 2008-04-11 Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 3 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 678–700（23 aa） Fragment：PXR, residues 130-434, linker, SRC-1, residues 678-700
Chain B 678–700（23 aa） Fragment：PXR, residues 130-434, linker, SRC-1, residues 678-700
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 7；277 K；10-30% MPD or isopropanol, 100 mM imidazole, pH 7, VAPOR DIFFUSION, temperature 277K
Resolution 2.00 Å R-free 0.244
3CWD Molecular recognition of nitro-fatty acids by PPAR gamma Deposited 2008-04-21 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain C 685–700（16 aa） Fragment：LXXLL motif of SRC1-2
Not recorded LNA (9E,12Z)-10-nitrooctadeca-9,12-dienoic acid × 1 LNB (9Z,12E)-12-nitrooctadeca-9,12-dienoic acid × 1 X-RAY DIFFRACTION mmCIF provides none of the parsed conditions Resolution 2.40 Å R-free 0.290
3CWD Molecular recognition of nitro-fatty acids by PPAR gamma Deposited 2008-04-21 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 685–700（16 aa） Fragment：LXXLL motif of SRC1-2
Not recorded LNA (9E,12Z)-10-nitrooctadeca-9,12-dienoic acid × 1 LNB (9Z,12E)-12-nitrooctadeca-9,12-dienoic acid × 1 X-RAY DIFFRACTION mmCIF provides none of the parsed conditions Resolution 2.40 Å R-free 0.290
3DCT FXR with SRC1 and GW4064 Deposited 2008-06-04 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 741–761（21 aa） Fragment：UNP residues 741-761
Not recorded 064 3-[(E)-2-(2-chloro-4-{[3-(2,6-dichlorophenyl)-5-(1-methylethyl)isoxazol-4-yl]methoxy}phenyl)ethenyl]benzoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions hanging drop；pH 6.5；298 K；0.2M Li2SO4, 0.1M Bis-Tris pH6.5, 25% PEG3350, hanging drop, temperature 298K
Resolution 2.50 Å R-free 0.240
3DCU FXR with SRC1 and GSK8062 Deposited 2008-06-04 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 741–761（21 aa） Fragment：UNP residues 741-761
Not recorded O62 6-(4-{[3-(2,6-dichlorophenyl)-5-(1-methylethyl)isoxazol-4-yl]methoxy}phenyl)naphthalene-1-carboxylic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；0.2M Li2SO4, 0.1M Bis-Tris pH6.5, 25% PEG3350, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 2.95 Å R-free 0.228
3DR1 Side-chain fluorine atoms of non-steroidal vitamin D3 analogs stabilize helix 12 of vitamin D receptor Deposited 2008-07-10 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa）
Not recorded MG MAGNESIUM ION × 2 C5D (1R,3R)-5-[(2E)-3-{(1S,3R)-2,2,3-trimethyl-3-[6,6,6-trifluoro-5-hydroxy-5-(trifluoromethyl)hex-3-yn-1-yl]cyclopentyl}prop-2-en-1-ylidene]cyclohexane-1,3-diol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；Li sulfate 1.6M, Mg sulfate 50mM, Bis Tris 0.1M , pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 2.70 Å R-free 0.286
3ET1 Structure of PPARalpha with 3-[5-Methoxy-1-(4-methoxy-benzenesulfonyl)-1H-indol-3-yl]-propionic acid Deposited 2008-10-06 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain P 681–696（16 aa） Fragment：residues 681-696
Not recorded ET1 3-{5-methoxy-1-[(4-methoxyphenyl)sulfonyl]-1H-indol-3-yl}propanoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions pH 8；277 K；The purified PPARa LBD protein was diluted to 10 mg/ml and 1mM of indeglitazar and 2x molar excess of SRC-1 peptide were added prior to crystallization by mixing equal volumes of protein/compound sample with reservoir solution containing 16% PEG 8000, 0.1 M Tris buffer at pH 8.0, 0.02 M lithium sulfate, and 5% glycerol, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 2.50 Å R-free 0.258
3ET1 Structure of PPARalpha with 3-[5-Methoxy-1-(4-methoxy-benzenesulfonyl)-1H-indol-3-yl]-propionic acid Deposited 2008-10-06 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain Q 681–696（16 aa） Fragment：residues 681-696
Not recorded ET1 3-{5-methoxy-1-[(4-methoxyphenyl)sulfonyl]-1H-indol-3-yl}propanoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions pH 8；277 K；The purified PPARa LBD protein was diluted to 10 mg/ml and 1mM of indeglitazar and 2x molar excess of SRC-1 peptide were added prior to crystallization by mixing equal volumes of protein/compound sample with reservoir solution containing 16% PEG 8000, 0.1 M Tris buffer at pH 8.0, 0.02 M lithium sulfate, and 5% glycerol, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 2.50 Å R-free 0.258
3ET3 Structure of PPARgamma with 3-[5-Methoxy-1-(4-methoxy-benzenesulfonyl)-1H-indol-3-yl]-propionic acid Deposited 2008-10-06 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain P 680–695（16 aa） Fragment：residues 681-696
Not recorded ET1 3-{5-methoxy-1-[(4-methoxyphenyl)sulfonyl]-1H-indol-3-yl}propanoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions pH 6.5；277 K；The purified PPARg LBD protein was diluted to 12 mg/ml and 1mM of indeglitazar and 2x molar excess of SRC-1 peptide were added prior to crystallization by mixing equal volumes of protein/compound sample with reservoir solution containing 27% polyethylene glycol (PEG) 4000, 0.1 M 2-(bis-(2-hydroxy-ethyl)-amino)-2-hydroxymethyl- propane-1,3-diol (BisTris) buffer at pH 6.5, 0.2 M ammonium acetate, and 5% glycerol, VAPOR DIFFUSION, SITTING DROP, temperature 277K
Resolution 1.95 Å R-free 0.236
3FEI Design and biological evaluation of novel, balanced dual PPARa/g agonists Deposited 2008-11-30 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain Z 744–756（13 aa）
Not recorded CTM (2S)-3-(4-{[2-(4-chlorophenyl)-1,3-thiazol-4-yl]methoxy}-2-methylphenyl)-2-ethoxypropanoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8.5；293 K；0.1M Tris, 0.2M MgCl2, 25% PEG3350, 15% Glycerol, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
Resolution 2.40 Å R-free 0.260
3FEJ Design and biological evaluation of novel, balanced dual PPARa/g agonists Deposited 2008-11-30 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 628–640（13 aa）
Not recorded CTM (2S)-3-(4-{[2-(4-chlorophenyl)-1,3-thiazol-4-yl]methoxy}-2-methylphenyl)-2-ethoxypropanoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8.5；293 K；0.1M Tris, 15-20% PEG3350, 10% Glycerol, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
Resolution 2.01 Å R-free 0.250
3FUR Crystal Structure of PPARg in complex with INT131 Deposited 2009-01-14 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain H 629–640（12 aa） Fragment：FRAGMENT CONTAINING HD1, UNP residues 629-640
Not recorded Z12 2,4-dichloro-N-[3,5-dichloro-4-(quinolin-3-yloxy)phenyl]benzenesulfonamide × 1 CL CHLORIDE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8.5；298 K；30% PEG 4000, 0.2M MgCl2, Tris-HCl 8.5, vapor diffusion, hanging drop, temperature 298K
Resolution 2.30 Å R-free 0.242
3FXV Identification of an N-oxide pyridine GW4064 analogue as a potent FXR agonist Deposited 2009-01-21 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 744–756（13 aa） Fragment：residues 744-756
Not recorded 643 6-(4-{[3-(3,5-dichloropyridin-4-yl)-5-(1-methylethyl)isoxazol-4-yl]methoxy}-2-methylphenyl)-1-methyl-1H-indole-3-carbox ylic acid × 1 X-RAY DIFFRACTION mmCIF provides none of the parsed conditions Resolution 2.26 Å R-free 0.242
3G8I Aleglitazar, a new, potent, and balanced PPAR alpha/gamma agonist for the treatment of type II diabetes Deposited 2009-02-12 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain Z 744–756（13 aa） Fragment：motif 5
Not recorded RO7 (2S)-2-methoxy-3-{4-[2-(5-methyl-2-phenyl-1,3-oxazol-4-yl)ethoxy]-1-benzothiophen-7-yl}propanoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 8.5；293 K；20-22% PEG 2000, 0.2M NACL, 5% GLYCEROL, 0.1M TRIS-CL, pH 8.5, VAPOR DIFFUSION, temperature 293K
Resolution 2.20 Å R-free 0.261
3G9E Aleglitaar. a new. potent, and balanced dual ppara/g agonist for the treatment of type II diabetes Deposited 2009-02-13 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 628–640（13 aa） Fragment：CO-ACTIVATOR MOTIF 3
Not recorded RO7 (2S)-2-methoxy-3-{4-[2-(5-methyl-2-phenyl-1,3-oxazol-4-yl)ethoxy]-1-benzothiophen-7-yl}propanoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8.5；293 K；0.2M NaK TARTRATE, 25% PEG 3350, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
Resolution 2.30 Å R-free 0.262
3H0A Crystal Structure of Peroxisome Proliferator-Activated Receptor Gamma (PPARg) and Retinoic Acid Receptor Alpha (RXRa) in Complex with 9-cis Retinoic Acid, Co-activator Peptide, and a Partial Agonist Deposited 2009-04-08 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 629–640（12 aa） Fragment：UNP RESIDUES 629-640
Chain E 629–640（12 aa） Fragment：UNP RESIDUES 629-640
Not recorded 9RA 4-[1-(3,5,5,8,8-pentamethyl-5,6,7,8-tetrahydronaphthalen-2-yl)ethenyl]benzoic acid × 1 D30 [(4-{[2-(pent-2-yn-1-yloxy)-4-{[4-(trifluoromethyl)phenoxy]methyl}phenyl]sulfanyl}-5,6,7,8-tetrahydronaphthalen-1-yl)oxy]acetic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 7.5；289 K；25% PEG 2000 monomethyl ether, 0.3 M sodium acetate, 0.1 M Hepes 7.5, vapor diffusion, temperature 289K
Resolution 2.10 Å R-free 0.342
3HC5 FXR with SRC1 and GSK826 Deposited 2009-05-05 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 741–761（21 aa） Fragment：SRC1
Not recorded 82X 3-(6-{[3-(2,6-dichlorophenyl)-5-(1-methylethyl)isoxazol-4-yl]methoxy}-1-benzothiophen-2-yl)benzoic acid × 1 SO4 SULFATE ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；0.2M Li2SO4, 0.1M Bis-Tris, 25% PEG3350, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 2.60 Å R-free 0.269
3HC6 FXR with SRC1 and GSK088 Deposited 2009-05-05 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 741–761（21 aa） Fragment：LXXLL Motif
Not recorded 088 3-[(5-{[3-(2,6-dichlorophenyl)-5-(1-methylethyl)isoxazol-4-yl]methoxy}-1H-indol-1-yl)methyl]benzoic acid × 1 SO4 SULFATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；0.2M Li2SO4, 0.1M Bis-Tris, 25% PEG3350, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 3.20 Å R-free 0.287
3HVL Tethered PXR-LBD/SRC-1p complexed with SR-12813 Deposited 2009-06-16 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain A 678–700（23 aa） Fragment：PXR, residues 130-434, linker, SRC-1, residues 678-700
Not recorded SRL [2-(3,5-DI-TERT-BUTYL-4-HYDROXY-PHENYL)-1-(DIETHOXY-PHOSPHORYL)-VINYL]-PHOSPHONIC ACID DIETHLYL ESTER × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 7；277 K；10-30% MPD OR ISOPROPANOL, 100 mM IMIDAZOLE, 1 mM SR12813, pH 7, VAPOR DIFFUSION, temperature 277K
Resolution 2.10 Å R-free 0.265
3HVL Tethered PXR-LBD/SRC-1p complexed with SR-12813 Deposited 2009-06-16 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain B 678–700（23 aa） Fragment：PXR, residues 130-434, linker, SRC-1, residues 678-700
Not recorded SRL [2-(3,5-DI-TERT-BUTYL-4-HYDROXY-PHENYL)-1-(DIETHOXY-PHOSPHORYL)-VINYL]-PHOSPHONIC ACID DIETHLYL ESTER × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 7；277 K；10-30% MPD OR ISOPROPANOL, 100 mM IMIDAZOLE, 1 mM SR12813, pH 7, VAPOR DIFFUSION, temperature 277K
Resolution 2.10 Å R-free 0.265
3HVL Tethered PXR-LBD/SRC-1p complexed with SR-12813 Deposited 2009-06-16 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 678–700（23 aa） Fragment：PXR, residues 130-434, linker, SRC-1, residues 678-700
Chain B 678–700（23 aa） Fragment：PXR, residues 130-434, linker, SRC-1, residues 678-700
Not recorded SRL [2-(3,5-DI-TERT-BUTYL-4-HYDROXY-PHENYL)-1-(DIETHOXY-PHOSPHORYL)-VINYL]-PHOSPHONIC ACID DIETHLYL ESTER × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 7；277 K；10-30% MPD OR ISOPROPANOL, 100 mM IMIDAZOLE, 1 mM SR12813, pH 7, VAPOR DIFFUSION, temperature 277K
Resolution 2.10 Å R-free 0.265
3IPQ X-ray structure of GW3965 synthetic agonist bound to the LXR-alpha Deposited 2009-08-18 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 676–700（25 aa） Fragment：Steroid receptor co-activator 1: UNP residues 676-700
Not recorded 965 [3-(3-{[2-chloro-3-(trifluoromethyl)benzyl](2,2-diphenylethyl)amino}propoxy)phenyl]acetic acid × 2 SO4 SULFATE ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；298 K；100mM (NH4)2SO4, 40mM Tris-HCl pH 7.8, 60mM Imidazole pH 6.2, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 2.00 Å R-free 0.234
3IPS X-ray structure of benzisoxazole synthetic agonist bound to the LXR-alpha Deposited 2009-08-18 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 676–700（25 aa） Fragment：Steroid receptor co-activator 1: UNP residues 676-700
Chain D 676–700（25 aa） Fragment：Steroid receptor co-activator 1: UNP residues 676-700
Not recorded SO4 SULFATE ION × 2 O90 {3-chloro-4-[(3-{[7-propyl-3-(trifluoromethyl)-1,2-benzisoxazol-6-yl]oxy}propyl)sulfanyl]phenyl}acetic acid × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；298 K；18% PEG MME 2000, 100mM (NH4)2SO4, 35mM Tris-HCl pH 7.8, 65mM Imidazole, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 2.26 Å R-free 0.315
3IPU X-ray structure of benzisoxazole urea synthetic agonist bound to the LXR-alpha Deposited 2009-08-18 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 676–700（25 aa） Fragment：Steroid receptor co-activator 1: UNP residues 676-700
Chain D 676–700（25 aa） Fragment：Steroid receptor co-activator 1: UNP residues 676-700
Not recorded O40 4-{[methyl(3-{[7-propyl-3-(trifluoromethyl)-1,2-benzisoxazol-6-yl]oxy}propyl)carbamoyl]amino}benzoic acid × 2 SO4 SULFATE ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；277 K；10% PEG MME 2000, 100mM (NH4)2SO4, 40mM Tris-HCl pH 7.8, 60mM Imidazole pH 6.2, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 2.40 Å R-free 0.291
3KMR Crystal structure of RARalpha ligand binding domain in complex with an agonist ligand (Am580) and a coactivator fragment Deposited 2009-11-11 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain C 686–698（13 aa） Fragment：NR interaction motif 2 (UNP RESIDUE 686-698)
Not recorded EQN 4-{[(5,5,8,8-tetramethyl-5,6,7,8-tetrahydronaphthalen-2-yl)carbonyl]amino}benzoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；293 K；15% (w/v) PEG 6000, 5% (w/v) glycerol, pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 293K
Resolution 1.80 Å R-free 0.237
3LMP Crystal structure of the PPARgamma-LBD complexed with a cercosporamide derivative modulator Deposited 2010-01-31 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain C 686–700（15 aa） Fragment：UNP residues 686-700
Not recorded CEK (9aS)-8-acetyl-1,7-dihydroxy-3-methoxy-9a-methyl-N-(1-naphthylmethyl)-9-oxo-9,9a-dihydrodibenzo[b,d]furan-4-carboxamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8.5；295 K；PEG 4000, NaSCN, vapor diffusion, temperature 295K, VAPOR DIFFUSION, HANGING DROP, pH 8.5
Resolution 1.90 Å R-free 0.242
3OKH Crystal structure of human FXR in complex with 2-(4-chlorophenyl)-1-[(1S)-1-cyclohexyl-2-(cyclohexylamino)-2-oxoethyl]-1H-benzimidazole-6-carboxylic acid Deposited 2010-08-25 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 744–757（14 aa） Fragment：UNP RESIDUES 744-757
Not recorded OKH 2-(4-chlorophenyl)-1-[(1S)-1-cyclohexyl-2-(cyclohexylamino)-2-oxoethyl]-1H-benzimidazole-6-carboxylic acid × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；298 K；0.1M NaCl, 0.1M BisTris pH6.5, 1.5M AmmSulfate, VAPOR DIFFUSION, SITTING DROP, temperature 298K
Resolution 2.50 Å R-free 0.273
3OKI Crystal structure of human FXR in complex with (2S)-2-[2-(4-chlorophenyl)-1H-benzimidazol-1-yl]-N,2-dicyclohexylethanamide Deposited 2010-08-25 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 744–757（14 aa） Fragment：UNP RESIDUES 744-757
Not recorded OKI (2S)-2-[2-(4-chlorophenyl)-1H-benzimidazol-1-yl]-N,2-dicyclohexylethanamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；298 K；0.1M Bis-Tris pH 6.5, 28% PEG 2000, VAPOR DIFFUSION, SITTING DROP, temperature 298K
Resolution 2.00 Å R-free 0.280
3OKI Crystal structure of human FXR in complex with (2S)-2-[2-(4-chlorophenyl)-1H-benzimidazol-1-yl]-N,2-dicyclohexylethanamide Deposited 2010-08-25 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 744–757（14 aa） Fragment：UNP RESIDUES 744-757
Not recorded OKI (2S)-2-[2-(4-chlorophenyl)-1H-benzimidazol-1-yl]-N,2-dicyclohexylethanamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；298 K；0.1M Bis-Tris pH 6.5, 28% PEG 2000, VAPOR DIFFUSION, SITTING DROP, temperature 298K
Resolution 2.00 Å R-free 0.280
3OLF Crystal structure of human FXR in complex with 4-({(2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexylacetyl}amino)-3-methylbenzoic acid Deposited 2010-08-26 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 744–757（14 aa） Fragment：UNP RESIDUES 744-757
Not recorded OLF 4-({(2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexylacetyl}amino)-3-methylbenzoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；298 K；0.1M HEPES pH 7.5, 1.4M tri-sodium citrate dihydrate, VAPOR DIFFUSION, SITTING DROP, temperature 298K
Resolution 1.90 Å R-free 0.238
3OLF Crystal structure of human FXR in complex with 4-({(2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexylacetyl}amino)-3-methylbenzoic acid Deposited 2010-08-26 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 744–757（14 aa） Fragment：UNP RESIDUES 744-757
Not recorded OLF 4-({(2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexylacetyl}amino)-3-methylbenzoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；298 K；0.1M HEPES pH 7.5, 1.4M tri-sodium citrate dihydrate, VAPOR DIFFUSION, SITTING DROP, temperature 298K
Resolution 1.90 Å R-free 0.238
3OLL Crystal structure of phosphorylated estrogen receptor beta ligand binding domain Deposited 2010-08-26 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain C 683–701（19 aa） Fragment：UNP residues 683-701
Not recorded EST ESTRADIOL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；277.15 K；0.2 M Ammonium Acetate, 0.1 M BIS-TRIS pH 5.5, 17% PEG10000 (v/v), VAPOR DIFFUSION, HANGING DROP, temperature 277.15K
Resolution 1.50 Å R-free 0.208
3OLL Crystal structure of phosphorylated estrogen receptor beta ligand binding domain Deposited 2010-08-26 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 683–701（19 aa） Fragment：UNP residues 683-701
Not recorded EST ESTRADIOL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；277.15 K；0.2 M Ammonium Acetate, 0.1 M BIS-TRIS pH 5.5, 17% PEG10000 (v/v), VAPOR DIFFUSION, HANGING DROP, temperature 277.15K
Resolution 1.50 Å R-free 0.208
3OLL Crystal structure of phosphorylated estrogen receptor beta ligand binding domain Deposited 2010-08-26 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 683–701（19 aa） Fragment：UNP residues 683-701
Chain D 683–701（19 aa） Fragment：UNP residues 683-701
Not recorded EST ESTRADIOL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；277.15 K；0.2 M Ammonium Acetate, 0.1 M BIS-TRIS pH 5.5, 17% PEG10000 (v/v), VAPOR DIFFUSION, HANGING DROP, temperature 277.15K
Resolution 1.50 Å R-free 0.208
3OLS Crystal structure of estrogen receptor beta ligand binding domain Deposited 2010-08-26 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain C 683–701（19 aa） Fragment：Box 2 (UNP residues 683-701)
Not recorded EST ESTRADIOL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；277.15 K；0.2 M Ammonium Acetate, 0.1 M BIS-TRIS pH 5.5, 17% PEG10000 (v/v), VAPOR DIFFUSION, HANGING DROP, temperature 277.15K
Resolution 2.20 Å R-free 0.266
3OLS Crystal structure of estrogen receptor beta ligand binding domain Deposited 2010-08-26 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 683–701（19 aa） Fragment：Box 2 (UNP residues 683-701)
Not recorded EST ESTRADIOL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；277.15 K；0.2 M Ammonium Acetate, 0.1 M BIS-TRIS pH 5.5, 17% PEG10000 (v/v), VAPOR DIFFUSION, HANGING DROP, temperature 277.15K
Resolution 2.20 Å R-free 0.266
3OLS Crystal structure of estrogen receptor beta ligand binding domain Deposited 2010-08-26 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 683–701（19 aa） Fragment：Box 2 (UNP residues 683-701)
Chain D 683–701（19 aa） Fragment：Box 2 (UNP residues 683-701)
Not recorded EST ESTRADIOL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；277.15 K；0.2 M Ammonium Acetate, 0.1 M BIS-TRIS pH 5.5, 17% PEG10000 (v/v), VAPOR DIFFUSION, HANGING DROP, temperature 277.15K
Resolution 2.20 Å R-free 0.266
3OMK Crystal structure of human FXR in complex with (2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexyl-N-(2-methylphenyl)ethanamide Deposited 2010-08-27 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 744–757（14 aa） Fragment：UNP RESIDUES 744-757
Not recorded OMK (2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexyl-N-(2-methylphenyl)ethanamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；298 K；0.1M Bis-Tris pH 6.5, 25% PEG 3350, VAPOR DIFFUSION, SITTING DROP, temperature 298K
Resolution 1.90 Å R-free 0.245
3OMK Crystal structure of human FXR in complex with (2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexyl-N-(2-methylphenyl)ethanamide Deposited 2010-08-27 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 744–757（14 aa） Fragment：UNP RESIDUES 744-757
Not recorded OMK (2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexyl-N-(2-methylphenyl)ethanamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；298 K；0.1M Bis-Tris pH 6.5, 25% PEG 3350, VAPOR DIFFUSION, SITTING DROP, temperature 298K
Resolution 1.90 Å R-free 0.245
3OMM Crystal structure of human FXR in complex with 4-({(2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexylacetyl}amino)-3-fluorobenzoic acid Deposited 2010-08-27 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 744–757（14 aa） Fragment：UNP RESIDUES 744-757
Not recorded OMM 4-({(2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexylacetyl}amino)-3-fluorobenzoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；298 K；0.1M 2,2-Bis(hydroxymethyl)-2,2',2''-nitrilotriethanol pH 6.5, 20% PEG 5000 MME, VAPOR DIFFUSION, SITTING DROP, temperature 298K
Resolution 2.10 Å R-free 0.256
3OMM Crystal structure of human FXR in complex with 4-({(2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexylacetyl}amino)-3-fluorobenzoic acid Deposited 2010-08-27 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 744–757（14 aa） Fragment：UNP RESIDUES 744-757
Not recorded OMM 4-({(2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexylacetyl}amino)-3-fluorobenzoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；298 K；0.1M 2,2-Bis(hydroxymethyl)-2,2',2''-nitrilotriethanol pH 6.5, 20% PEG 5000 MME, VAPOR DIFFUSION, SITTING DROP, temperature 298K
Resolution 2.10 Å R-free 0.256
3OMO Fragment-Based Design of novel Estrogen Receptor Ligands Deposited 2010-08-27 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain C 683–701（19 aa） Fragment：Box 2 (UNP residues 683-701)
Not recorded WV7 2-(trifluoroacetyl)-1,2,3,4-tetrahydroisoquinolin-6-ol × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；277.15 K；0.2 M Ammonium Acetate, 0.1 M BIS-TRIS pH 5.5, 17% PEG10000 (v/v), VAPOR DIFFUSION, HANGING DROP, temperature 277.15K
Resolution 2.21 Å R-free 0.264
3OMO Fragment-Based Design of novel Estrogen Receptor Ligands Deposited 2010-08-27 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 683–701（19 aa） Fragment：Box 2 (UNP residues 683-701)
Not recorded WV7 2-(trifluoroacetyl)-1,2,3,4-tetrahydroisoquinolin-6-ol × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；277.15 K；0.2 M Ammonium Acetate, 0.1 M BIS-TRIS pH 5.5, 17% PEG10000 (v/v), VAPOR DIFFUSION, HANGING DROP, temperature 277.15K
Resolution 2.21 Å R-free 0.264
3OMO Fragment-Based Design of novel Estrogen Receptor Ligands Deposited 2010-08-27 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 683–701（19 aa） Fragment：Box 2 (UNP residues 683-701)
Chain D 683–701（19 aa） Fragment：Box 2 (UNP residues 683-701)
Not recorded WV7 2-(trifluoroacetyl)-1,2,3,4-tetrahydroisoquinolin-6-ol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；277.15 K；0.2 M Ammonium Acetate, 0.1 M BIS-TRIS pH 5.5, 17% PEG10000 (v/v), VAPOR DIFFUSION, HANGING DROP, temperature 277.15K
Resolution 2.21 Å R-free 0.264
3OMP Fragment-Based Design of novel Estrogen Receptor Ligands Deposited 2010-08-27 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain C 683–701（19 aa） Fragment：Box 2 (UNP residues 683-701)
Not recorded W14 2-(trifluoroacetyl)-1,2,3,4-tetrahydroisoquinolin-7-ol × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；277.15 K；0.2 M Ammonium Acetate, 0.1 M BIS-TRIS pH 5.5, 17% PEG10000 (v/v), VAPOR DIFFUSION, HANGING DROP, temperature 277.15K
Resolution 2.05 Å R-free 0.255
3OMP Fragment-Based Design of novel Estrogen Receptor Ligands Deposited 2010-08-27 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 683–701（19 aa） Fragment：Box 2 (UNP residues 683-701)
Not recorded W14 2-(trifluoroacetyl)-1,2,3,4-tetrahydroisoquinolin-7-ol × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；277.15 K；0.2 M Ammonium Acetate, 0.1 M BIS-TRIS pH 5.5, 17% PEG10000 (v/v), VAPOR DIFFUSION, HANGING DROP, temperature 277.15K
Resolution 2.05 Å R-free 0.255
3OMP Fragment-Based Design of novel Estrogen Receptor Ligands Deposited 2010-08-27 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 683–701（19 aa） Fragment：Box 2 (UNP residues 683-701)
Chain D 683–701（19 aa） Fragment：Box 2 (UNP residues 683-701)
Not recorded W14 2-(trifluoroacetyl)-1,2,3,4-tetrahydroisoquinolin-7-ol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；277.15 K；0.2 M Ammonium Acetate, 0.1 M BIS-TRIS pH 5.5, 17% PEG10000 (v/v), VAPOR DIFFUSION, HANGING DROP, temperature 277.15K
Resolution 2.05 Å R-free 0.255
3OMQ Fragment-Based Design of novel Estrogen Receptor Ligands Deposited 2010-08-27 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain C 683–701（19 aa） Fragment：Box 2 (UNP residues 683-701)
Not recorded W23 2-[(trifluoromethyl)sulfonyl]-1,2,3,4-tetrahydroisoquinolin-6-ol × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；277.15 K；0.2 M Ammonium Acetate, 0.1 M BIS-TRIS pH 5.5, 17% PEG10000 (v/v), VAPOR DIFFUSION, HANGING DROP, temperature 277.15K
Resolution 1.97 Å R-free 0.260
3OMQ Fragment-Based Design of novel Estrogen Receptor Ligands Deposited 2010-08-27 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 683–701（19 aa） Fragment：Box 2 (UNP residues 683-701)
Not recorded W23 2-[(trifluoromethyl)sulfonyl]-1,2,3,4-tetrahydroisoquinolin-6-ol × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；277.15 K；0.2 M Ammonium Acetate, 0.1 M BIS-TRIS pH 5.5, 17% PEG10000 (v/v), VAPOR DIFFUSION, HANGING DROP, temperature 277.15K
Resolution 1.97 Å R-free 0.260
3OMQ Fragment-Based Design of novel Estrogen Receptor Ligands Deposited 2010-08-27 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 683–701（19 aa） Fragment：Box 2 (UNP residues 683-701)
Chain D 683–701（19 aa） Fragment：Box 2 (UNP residues 683-701)
Not recorded W23 2-[(trifluoromethyl)sulfonyl]-1,2,3,4-tetrahydroisoquinolin-6-ol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.5；277.15 K；0.2 M Ammonium Acetate, 0.1 M BIS-TRIS pH 5.5, 17% PEG10000 (v/v), VAPOR DIFFUSION, HANGING DROP, temperature 277.15K
Resolution 1.97 Å R-free 0.260
3OOF Crystal structure of human FXR in complex with 4-({(2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexylacetyl}amino)benzoic acid Deposited 2010-08-31 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 744–757（14 aa） Fragment：UNP RESIDUES 744-757
Not recorded OOF 4-({(2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexylacetyl}amino)benzoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 5.5；298 K；0.1M Bis-Tris pH 5.5, 25% PEG 3350, VAPOR DIFFUSION, SITTING DROP, temperature 298K
Resolution 2.29 Å R-free 0.255
3OOF Crystal structure of human FXR in complex with 4-({(2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexylacetyl}amino)benzoic acid Deposited 2010-08-31 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 744–757（14 aa） Fragment：UNP RESIDUES 744-757
Not recorded OOF 4-({(2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexylacetyl}amino)benzoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 5.5；298 K；0.1M Bis-Tris pH 5.5, 25% PEG 3350, VAPOR DIFFUSION, SITTING DROP, temperature 298K
Resolution 2.29 Å R-free 0.255
3OOK Crystal structure of human FXR in complex with 4-({(2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexylacetyl}amino)-3,5-difluorobenzoic acid Deposited 2010-08-31 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 744–757（14 aa） Fragment：UNP RESIDUES 744-757
Not recorded OOK 4-({(2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexylacetyl}amino)-3,5-difluorobenzoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；298 K；0.1M Bis-Tris pH 6.5, 20% PEG 5000, VAPOR DIFFUSION, SITTING DROP, temperature 298K
Resolution 2.29 Å R-free 0.271
3OOK Crystal structure of human FXR in complex with 4-({(2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexylacetyl}amino)-3,5-difluorobenzoic acid Deposited 2010-08-31 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 744–757（14 aa） Fragment：UNP RESIDUES 744-757
Not recorded OOK 4-({(2S)-2-[2-(4-chlorophenyl)-5,6-difluoro-1H-benzimidazol-1-yl]-2-cyclohexylacetyl}amino)-3,5-difluorobenzoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；298 K；0.1M Bis-Tris pH 6.5, 20% PEG 5000, VAPOR DIFFUSION, SITTING DROP, temperature 298K
Resolution 2.29 Å R-free 0.271
3QT0 Revealing a steroid receptor ligand as a unique PPARgamma agonist Deposited 2011-02-22 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain C 685–700（16 aa） Fragment：UNP residies 685-700
Not recorded 486 11-(4-DIMETHYLAMINO-PHENYL)-17-HYDROXY-13-METHYL-17-PROP-1-YNYL-1,2,6,7,8,11,12,13,14,15,16,17-DODEC AHYDRO-CYCLOPENTA[A]PHENANTHREN-3-ONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；PEG, Tris-HCl, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
Resolution 2.50 Å R-free 0.277
3RUT FXR with SRC1 and GSK359 Deposited 2011-05-05 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 745–755（11 aa） Fragment：UNP residues 745-755
Not recorded SO4 SULFATE ION × 2 59G 6-(4-{[3-(2,6-dichlorophenyl)-5-(propan-2-yl)-1,2-oxazol-4-yl]methoxy}phenyl)-1-benzothiophene-3-carboxylic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions HANGING DROP；pH 6.5；298 K；25% PEG3350, 0.2 M lithium sulfate, 0.1 M Bis-Tris, pH 6.5, HANGING DROP, temperature 298K
Resolution 3.00 Å R-free 0.266
3RUU FXR with SRC1 and GSK237 Deposited 2011-05-05 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 745–755（11 aa） Fragment：UNP residues 745-755
Not recorded SO4 SULFATE ION × 2 37G 6-(4-{[3-(2,6-dichlorophenyl)-5-(propan-2-yl)-1,2-oxazol-4-yl]methoxy}phenyl)-1H-indole-3-carboxylic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions HANGING DROP；pH 6.5；298 K；25% PEG3350, 0.2 M lithium sulfate, 0.1 M Bis-Tris, pH 6.5, HANGING DROP, temperature 298K
Resolution 2.50 Å R-free 0.253
3RVF FXR with SRC1 and GSK2034 Deposited 2011-05-06 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 741–761（21 aa） Fragment：UNP residues 741-761
Not recorded SO4 SULFATE ION × 1 034 5-(4-{[3-(2,6-dichlorophenyl)-5-(propan-2-yl)-1,2-oxazol-4-yl]methoxy}phenyl)-1H-indole-2-carboxylic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions HANGING DROP；pH 6.5；298 K；25% PEG3350, 0.2 M lithium sulfate, 0.1 M Bis-Tris, pH 6.5, HANGING DROP, temperature 298K
Resolution 3.10 Å R-free 0.290
3S9S Ligand binding domain of PPARgamma complexed with a benzimidazole partial agonist Deposited 2011-06-02 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–697（13 aa） Fragment：LXXLL MOTIF 4 (RESIDUES 685-697)
Not recorded M0T 1-(3,4-dichlorobenzyl)-2-methyl-N-[(1R)-1-phenylpropyl]-1H-benzimidazole-5-carboxamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；100MM HEPES, 1.4M SODIUM CITRATE, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 2.55 Å R-free 0.284
3T03 Crystal structure of PPAR gamma ligand binding domain in complex with a novel partial agonist GQ-16 Deposited 2011-07-19 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: monomeric
Chain C 683–700（18 aa） Fragment：UNP residues 683-700
Not recorded 3T0 (5Z)-5-(5-bromo-2-methoxybenzylidene)-3-(4-methylbenzyl)-1,3-thiazolidine-2,4-dione × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；0.2 M Ammonium acetate, 0.1 M Sodium citrate, pH 5.6, 30%(w/v) PEG 4000, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 2.10 Å R-free 0.247
3T03 Crystal structure of PPAR gamma ligand binding domain in complex with a novel partial agonist GQ-16 Deposited 2011-07-19 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: monomeric
Chain D 683–700（18 aa） Fragment：UNP residues 683-700
Not recorded 3T0 (5Z)-5-(5-bromo-2-methoxybenzylidene)-3-(4-methylbenzyl)-1,3-thiazolidine-2,4-dione × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；0.2 M Ammonium acetate, 0.1 M Sodium citrate, pH 5.6, 30%(w/v) PEG 4000, VAPOR DIFFUSION, HANGING DROP, temperature 298K
Resolution 2.10 Å R-free 0.247
3UU7 Crystal structure of hERa-LBD (Y537S) in complex with bisphenol-A Deposited 2011-11-28 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain F 686–698（13 aa） Fragment：Coactivator peptide SRC-1
Chain G 686–698（13 aa） Fragment：Coactivator peptide SRC-1
Not recorded 2OH 4,4'-PROPANE-2,2-DIYLDIPHENOL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；300 mM NaCl, 100 mM NaHepes pH 7.75, 30% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 2.20 Å R-free 0.246
3UU7 Crystal structure of hERa-LBD (Y537S) in complex with bisphenol-A Deposited 2011-11-28 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain F 686–698（13 aa） Fragment：Coactivator peptide SRC-1
Not recorded 2OH 4,4'-PROPANE-2,2-DIYLDIPHENOL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；300 mM NaCl, 100 mM NaHepes pH 7.75, 30% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 2.20 Å R-free 0.246
3UU7 Crystal structure of hERa-LBD (Y537S) in complex with bisphenol-A Deposited 2011-11-28 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain G 686–698（13 aa） Fragment：Coactivator peptide SRC-1
Not recorded 2OH 4,4'-PROPANE-2,2-DIYLDIPHENOL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；300 mM NaCl, 100 mM NaHepes pH 7.75, 30% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 2.20 Å R-free 0.246
3UUA Crystal structure of hERa-LBD (Y537S) in complex with bisphenol-AF Deposited 2011-11-28 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain F 686–698（13 aa） Fragment：Coactivator peptide SRC-1
Chain G 686–698（13 aa） Fragment：Coactivator peptide SRC-1
Not recorded 0CZ 4,4'-(1,1,1,3,3,3-hexafluoropropane-2,2-diyl)diphenol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；300 mM NaCl, 100 mM Hepes pH 7.75, 32% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 2.05 Å R-free 0.231
3UUA Crystal structure of hERa-LBD (Y537S) in complex with bisphenol-AF Deposited 2011-11-28 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain F 686–698（13 aa） Fragment：Coactivator peptide SRC-1
Not recorded 0CZ 4,4'-(1,1,1,3,3,3-hexafluoropropane-2,2-diyl)diphenol × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；300 mM NaCl, 100 mM Hepes pH 7.75, 32% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 2.05 Å R-free 0.231
3UUA Crystal structure of hERa-LBD (Y537S) in complex with bisphenol-AF Deposited 2011-11-28 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain G 686–698（13 aa） Fragment：Coactivator peptide SRC-1
Not recorded 0CZ 4,4'-(1,1,1,3,3,3-hexafluoropropane-2,2-diyl)diphenol × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；300 mM NaCl, 100 mM Hepes pH 7.75, 32% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 2.05 Å R-free 0.231
3UUD Crystal structure of hERa-LBD (Y537S) in complex with estradiol Deposited 2011-11-28 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 686–698（13 aa） Fragment：Coactivator peptide SRC-1
Chain D 686–698（13 aa） Fragment：Coactivator peptide SRC-1
Not recorded EST ESTRADIOL × 2 GOL GLYCEROL × 3 EDO 1,2-ETHANEDIOL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8.5；291 K；200 mM Li2SO4, 100 mM Tris pH 8.5, 30% PEG 4000, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 1.60 Å R-free 0.195
3UUD Crystal structure of hERa-LBD (Y537S) in complex with estradiol Deposited 2011-11-28 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain C 686–698（13 aa） Fragment：Coactivator peptide SRC-1
Not recorded EST ESTRADIOL × 1 GOL GLYCEROL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8.5；291 K；200 mM Li2SO4, 100 mM Tris pH 8.5, 30% PEG 4000, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 1.60 Å R-free 0.195
3UUD Crystal structure of hERa-LBD (Y537S) in complex with estradiol Deposited 2011-11-28 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 686–698（13 aa） Fragment：Coactivator peptide SRC-1
Not recorded EST ESTRADIOL × 1 GOL GLYCEROL × 2 EDO 1,2-ETHANEDIOL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8.5；291 K；200 mM Li2SO4, 100 mM Tris pH 8.5, 30% PEG 4000, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 1.60 Å R-free 0.195
3V9Y Crystal structure of the PPARgamma-LBD complexed with a cercosporamide derivative modulator Deposited 2011-12-28 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 686–700（15 aa）
Not recorded 24L 4-{4-[({[(9aS)-8-acetyl-1,7-dihydroxy-3-methoxy-9a-methyl-9-oxo-9,9a-dihydrodibenzo[b,d]furan-4-yl]carbonyl}amino)methyl]naphthalen-2-yl}butanoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8.5；295 K；PEG 4000, sodium thiocyanate, Tris-hydrochloride, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 295K
Resolution 2.10 Å R-free 0.252
3VN2 Crystal Structure of PPARgamma complexed with Telmisartan Deposited 2011-12-21 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain C 685–700（16 aa） Fragment：Coactivator fragment SRC-1, UNP residues 685-700
Not recorded TLS 4'-[(1,7'-dimethyl-2'-propyl-1H,3'H-2,5'-bibenzimidazol-3'-yl)methyl]biphenyl-2-carboxylic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.5；293 K；0.1M TRIS-HCL, 0.8M SODIUM CITRATE TRIBASIC DIHYDRATE, pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 293.0K
Resolution 2.18 Å R-free 0.309
4DK7 Crystal structure of LXR ligand binding domain in complex with full agonist 1 Deposited 2012-02-03 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 745–756（12 aa） Fragment：UNp residues 745-756
Chain D 745–756（12 aa） Fragment：UNp residues 745-756
Not recorded 0KS N-[4-(1,1,1,3,3,3-hexafluoro-2-hydroxypropan-2-yl)phenyl]-N-methylbenzenesulfonamide × 2 ACT ACETATE ION × 1 CA CALCIUM ION × 7 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 8；293 K；0.1 M Tris pH 8, 12% PEG 10000, 0.2 M calcium acetate, 0.005 M DTT, vapor diffusion, temperature 293K
Resolution 2.45 Å R-free 0.270
4DK8 Crystal structure of LXR ligand binding domain in complex with partial agonist 5 Deposited 2012-02-03 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 745–756（12 aa） Fragment：UNP residues 745-756
Chain D 745–756（12 aa） Fragment：UNP residues 745-756
Not recorded 0KT N-methyl-N-(4-{(1S)-2,2,2-trifluoro-1-hydroxy-1-[1-(2-methoxyethyl)-1H-pyrrol-2-yl]ethyl}phenyl)benzenesulfonamide × 2 ACT ACETATE ION × 1 CA CALCIUM ION × 6 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 8；293 K；0.1 M Tris, 12% PEG 10000, 0.2 M calcium acetate, 0.005 M DTT, pH 8, vapor diffusion, temperature 293K
Resolution 2.75 Å R-free 0.278
4DM6 Crystal structure of RARb LBD homodimer in complex with TTNPB Deposited 2012-02-07 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain E 676–700（25 aa） Fragment：unp residues 676-700
Not recorded TTB 4-[(1E)-2-(5,5,8,8-TETRAMETHYL-5,6,7,8-TETRAHYDRONAPHTHALEN-2-YL)PROP-1-ENYL]BENZOIC ACID × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.6；290 K；5% polyethylene glycol 8000, 0.2 M KCl, 0.01 M MgCl2 and 0.05 M MES, VAPOR DIFFUSION, HANGING DROP, temperature 290K, pH 5.6
Resolution 1.90 Å R-free 0.239
4DM6 Crystal structure of RARb LBD homodimer in complex with TTNPB Deposited 2012-02-07 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain F 676–700（25 aa） Fragment：unp residues 676-700
Not recorded TTB 4-[(1E)-2-(5,5,8,8-TETRAMETHYL-5,6,7,8-TETRAHYDRONAPHTHALEN-2-YL)PROP-1-ENYL]BENZOIC ACID × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.6；290 K；5% polyethylene glycol 8000, 0.2 M KCl, 0.01 M MgCl2 and 0.05 M MES, VAPOR DIFFUSION, HANGING DROP, temperature 290K, pH 5.6
Resolution 1.90 Å R-free 0.239
4DM8 Crystal structure of RARb LBD in complex with 9cis retinoic acid Deposited 2012-02-07 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain C 676–700（25 aa） Fragment：unp residues 676-700
Not recorded REA RETINOIC ACID × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.6；290 K；5% polyethylene glycol 8000, 0.2 M KCl, 0.01 M MgCl2 and 0.05 M MES pH 5.6, VAPOR DIFFUSION, HANGING DROP, temperature 290K
Resolution 2.30 Å R-free 0.277
4DM8 Crystal structure of RARb LBD in complex with 9cis retinoic acid Deposited 2012-02-07 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 676–700（25 aa） Fragment：unp residues 676-700
Not recorded REA RETINOIC ACID × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 5.6；290 K；5% polyethylene glycol 8000, 0.2 M KCl, 0.01 M MgCl2 and 0.05 M MES pH 5.6, VAPOR DIFFUSION, HANGING DROP, temperature 290K
Resolution 2.30 Å R-free 0.277
4DQM Revealing a marine natural product as a novel agonist for retinoic acid receptors with a unique binding mode and antitumor activity Deposited 2012-02-16 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 1432–1441（10 aa） Fragment：LXXLL motif 7, UNP RESIDUES 1432-1441
Not recorded LUF (5S)-4-[(3E,7E)-4,8-dimethyl-10-(2,6,6-trimethylcyclohex-1-en-1-yl)deca-3,7-dien-1-yl]-5-hydroxyfuran-2(5H)-one × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；2% v/v Tacsimate pH7.0, 5% 2-propanol, 0.1M imadazole , 8% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 293K
Resolution 2.75 Å R-free 0.259
4DQM Revealing a marine natural product as a novel agonist for retinoic acid receptors with a unique binding mode and antitumor activity Deposited 2012-02-16 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 1432–1441（10 aa） Fragment：LXXLL motif 7, UNP RESIDUES 1432-1441
Not recorded LUF (5S)-4-[(3E,7E)-4,8-dimethyl-10-(2,6,6-trimethylcyclohex-1-en-1-yl)deca-3,7-dien-1-yl]-5-hydroxyfuran-2(5H)-one × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；2% v/v Tacsimate pH7.0, 5% 2-propanol, 0.1M imadazole , 8% PEG 3350, VAPOR DIFFUSION, HANGING DROP, temperature 293K
Resolution 2.75 Å R-free 0.259
4F9M Crystal structure of the PPARgamma-LBD complexed with a cercosporamide derivative modulator Deposited 2012-05-19 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain C 686–700（15 aa） Fragment：LXXLL box, UNP residues 686-700
Not recorded FCM (9aS)-8-acetyl-N-[(2-ethyl-4-fluoronaphthalen-1-yl)methyl]-1,7-dihydroxy-3-methoxy-9a-methyl-9-oxo-9,9a-dihydrodibenzo[b,d]furan-4-carboxamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8.5；295 K；PEG 4000, Sodium thiocyanate, Tris-HCl, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 295K
Resolution 1.90 Å R-free 0.254
4FGY Identification of a unique PPAR ligand with an unexpected binding mode and antibetic activity Deposited 2012-06-05 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 686–696（11 aa） Fragment：UNP RESIDUES 686-696
Not recorded 0W3 (4R,6S,8S,12R,14R,16Z,18R,19R,20S,21S)-19,21-dihydroxy-22-{(2S,2'R,5S,5'S)-5'-[(1R)-1-hydroxyethyl]-2,5'-dimethyloctahydro-2,2'-bifuran-5-yl}-4,6,8,12,14,18,20-heptamethyl-9,11-dioxodocos-16-enoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7；0.2 M sodium acetate, 5% ethylene glycol, 20% PEG 3350, pH 7.0, VAPOR DIFFUSION, HANGING DROP
Resolution 2.84 Å R-free 0.285
4G1D Structural basis for the accommodation of bis- and tris-aromatic derivatives in Vitamin D Nuclear Receptor Deposited 2012-07-10 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa） Fragment：unp residues 686-700
Not recorded 0VK 3-(5'-{[3,4-bis(hydroxymethyl)benzyl]oxy}-2'-methyl-2-propylbiphenyl-4-yl)pentan-3-ol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；Bis-Tris 0.1 M, lithium sulfate 1.6 M and magnesium sulfate 50 mM, VAPOR DIFFUSION, HANGING DROP, temperature 295K, pH 6.5
Resolution 2.90 Å R-free 0.291
4G1Y Structural basis for the accommodation of bis- and tris-aromatic derivatives in Vitamin D Nuclear Receptor Deposited 2012-07-11 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa） Fragment：unp residues 686-700
Not recorded 0VO (4E,6Z)-7-(3-{[3,4-bis(hydroxymethyl)benzyl]oxy}phenyl)-3-ethylnona-4,6-dien-3-ol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；Bis-Tris 0.1 M, lithium sulfate 1.6 M and magnesium sulfate 50 mM, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 295K
Resolution 2.85 Å R-free 0.270
4G1Z Structural basis for the accommodation of bis- and tris-aromatic derivatives in Vitamin D Nuclear Receptor Deposited 2012-07-11 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa） Fragment：unp residues 686-692
Not recorded 0VP 3-(5'-{[3,4-bis(hydroxymethyl)benzyl]oxy}-2'-ethyl-2-propylbiphenyl-4-yl)pentan-3-ol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；Bis-Tris 0.1 M, lithium sulfate 1.6 M and magnesium sulfate 50 mM, VAPOR DIFFUSION, HANGING DROP, temperature 295K, pH 6.5
Resolution 2.50 Å R-free 0.274
4G20 Structural basis for the accommodation of bis- and tris-aromatic derivatives in Vitamin D Nuclear Receptor Deposited 2012-07-11 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa） Fragment：unp residues 686-700
Not recorded 484 3-(5'-{2-[3,4-bis(hydroxymethyl)phenyl]ethyl}-2'-methyl-2-propylbiphenyl-4-yl)pentan-3-ol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；Bis-Tris 0.1 M, lithium sulfate 1.6 M and magnesium sulfate 50 mM, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
Resolution 2.90 Å R-free 0.287
4G21 Structural basis for the accommodation of bis- and tris-aromatic derivatives in Vitamin D Nuclear Receptor Deposited 2012-07-11 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa） Fragment：unp residues 686-700
Not recorded 0VP 3-(5'-{[3,4-bis(hydroxymethyl)benzyl]oxy}-2'-ethyl-2-propylbiphenyl-4-yl)pentan-3-ol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；Bis-Tris 0.1 M, lithium sulfate 1.6 M and magnesium sulfate 50 mM , pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 295K
Resolution 2.90 Å R-free 0.291
4G2H Structural basis for the accommodation of bis- and tris-aromatic derivatives in Vitamin D Nuclear Receptor Deposited 2012-07-12 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa） Fragment：unp residues 686-692
Not recorded 0VQ (3E,5E)-6-(3-{2-[3,4-bis(hydroxymethyl)phenyl]ethyl}phenyl)-1,1,1-trifluoro-2-(trifluoromethyl)octa-3,5-dien-2-ol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；Bis-Tris 0.1 M, lithium sulfate 1.6 M and magnesium sulfate 50 mM, VAPOR DIFFUSION, HANGING DROP, temperature 293K, pH 6.5
Resolution 2.50 Å R-free 0.285
4HEE Crystal structure of PPARgamma in complex with compound 13 Deposited 2012-10-03 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain Y 676–700（25 aa） Fragment：UNP Residues 676-700
Not recorded 14R 5-benzyl-2-ethyl-3-{(1S)-5-[2-(1H-tetrazol-5-yl)phenyl]-2,3-dihydro-1H-inden-1-yl}-3,5-dihydro-4H-imidazo[4,5-c]pyridin-4-one × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；100mM PIPES, 200mM Sodium Thiocyanate, 16% PEG4000, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
Resolution 2.50 Å R-free 0.258
4J5W Crystal Structure of the apo-PXR/RXRalpha LBD Heterotetramer Complex Deposited 2013-02-10 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Heteromer；Protein × 4 PDB declaration: tetrameric
Chain A 678–700（23 aa）
Chain B 678–700（23 aa）
Chain C 678–700（23 aa）
Chain D 678–700（23 aa）
Not recorded MG MAGNESIUM ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7；277.15 K；16-20% PEG 8000, 0.1-0.2 M MgCl, 0.1 M bis-tris proprane, 0.02% sodium azide, pH 7.0, vapor diffusion, hanging drop, temperature 277.15K
Resolution 2.80 Å R-free 0.298
4J5X Crystal Structure of the SR12813-bound PXR/RXRalpha LBD Heterotetramer Complex Deposited 2013-02-10 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Heteromer；Protein × 4 PDB declaration: tetrameric
Chain A 678–700（23 aa）
Chain B 678–700（23 aa）
Chain C 678–700（23 aa）
Chain D 678–700（23 aa）
Not recorded SRL [2-(3,5-DI-TERT-BUTYL-4-HYDROXY-PHENYL)-1-(DIETHOXY-PHOSPHORYL)-VINYL]-PHOSPHONIC ACID DIETHLYL ESTER × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7；277.15 K；16-20% PEG 8000, 0.1-0.2 M MgCl, 0.1 M bis-tris proprane, 0.02% sodium azide, pH 7.0, vapor diffusion, hanging drop, temperature 277.15K
Resolution 2.80 Å R-free 0.298
4JYG Crystal structure of RARbeta LBD in complex with agonist BMS411 [4-{[(5,5-dimethyl-8-phenyl-5,6-dihydronaphthalen-2-yl)carbonyl]amino}benzoic acid] Deposited 2013-03-29 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain F 686–698（13 aa） Fragment：UNP residues 686-698
Chain G 686–698（13 aa） Fragment：UNP residues 686-698
Not recorded 1NY 4-{[(5,5-dimethyl-8-phenyl-5,6-dihydronaphthalen-2-yl)carbonyl]amino}benzoic acid × 2 PE4 2-{2-[2-(2-{2-[2-(2-ETHOXY-ETHOXY)-ETHOXY]-ETHOXY}-ETHOXY)-ETHOXY]-ETHOXY}-ETHANOL × 1 FLC CITRATE ANION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 5.5；291 K；200 mM Tri Sodium Citrate pH 5.5, 25 % PEG 4000, VAPOR DIFFUSION, temperature 291K
Resolution 2.35 Å R-free 0.257
4JYH Crystal structure of RARbeta LBD in complex with selective agonist BMS948 [4-{[(8-phenylnaphthalen-2-yl)carbonyl]amino}benzoic acid] Deposited 2013-03-29 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 686–698（13 aa） Fragment：UNP residues 686-698
Chain G 686–698（13 aa） Fragment：UNP residues 686-698
Not recorded JYH 4-{[(8-phenylnaphthalen-2-yl)carbonyl]amino}benzoic acid × 2 FLC CITRATE ANION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 5.5；291 K；200 mM Tri Sodium Citrate pH 5.5, 25% PEG 4000, VAPOR DIFFUSION, temperature 291K
Resolution 2.60 Å R-free 0.267
4JYI Crystal structure of RARbeta LBD in complex with selective partial agonist BMS641 [3-chloro-4-[(E)-2-(5,5-dimethyl-8-phenyl-5,6-dihydronaphthalen-2-yl)ethenyl]benzoic acid] Deposited 2013-03-29 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain F 686–698（13 aa） Fragment：UNP residues 686-698
Chain G 686–698（13 aa） Fragment：UNP residues 686-698
Not recorded JYI 3-chloro-4-[(E)-2-(5,5-dimethyl-8-phenyl-5,6-dihydronaphthalen-2-yl)ethenyl]benzoic acid × 2 FLC CITRATE ANION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；pH 5.5；291 K；200 mM Tri Sodium Citrate pH 5.5, 25% PEG 4000, VAPOR DIFFUSION, temperature 291K
Resolution 1.90 Å R-free 0.227
4MG5 Crystal structure of hERa-LBD (Y537S) in complex with chlordecone Deposited 2013-08-28 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Chain D 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Not recorded GOL GLYCEROL × 3 A1AQV chlordecone × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；340 mM sodium chloride, 100 mM HEPES, 32% PEG3350, pH 7.75, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 2.05 Å R-free 0.228
4MG6 Crystal structure of hERa-LBD (Y537S) in complex with benzylbutylphtalate Deposited 2013-08-28 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Chain D 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Not recorded 27G benzyl butyl benzene-1,2-dicarboxylate × 2 GOL GLYCEROL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；320 mM sodium chloride, 100 mM HEPES, 26% PEG3350, pH 7.75, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 2.10 Å R-free 0.230
4MG7 Crystal structure of hERa-LBD (Y537S) in complex with ferutinine Deposited 2013-08-28 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Chain D 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Not recorded 27H ferutinine × 2 EDO 1,2-ETHANEDIOL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；320 mM sodium chloride, 100 mM HEPES, 24% PEG3350, pH 7.75, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 2.15 Å R-free 0.230
4MG8 Crystal structure of hERa-LBD (Y537S) in complex with alpha-zearalanol Deposited 2013-08-28 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Chain D 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Not recorded 27J alpha-zearalanol × 2 GOL GLYCEROL × 1 EDO 1,2-ETHANEDIOL × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；300 mM sodium chloride, 100 mM HEPES, 24% PEG3350, pH 7.75, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 1.85 Å R-free 0.213
4MG9 Crystal structure of hERa-LBD (Y537S) in complex with butylparaben Deposited 2013-08-28 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain F 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Chain G 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Not recorded 27K butyl 4-hydroxybenzoate × 2 GOL GLYCEROL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；300 mM sodium chloride, 100 mM HEPES, 28% PEG3350, pH 7.75, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 2.00 Å R-free 0.237
4MGA Crystal structure of hERa-LBD (Y537S) in complex with 4-tert-octylphenol Deposited 2013-08-28 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Chain D 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Not recorded 27L 4-(2,4,4-trimethylpentan-2-yl)phenol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；320 mM sodium chloride, 100 mM HEPES, 28% PEG3350, pH 7.75, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 1.80 Å R-free 0.222
4MGB Crystal structure of hERa-LBD (Y537S) in complex with TCBPA Deposited 2013-08-28 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Chain D 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Not recorded XDH 4,4'-propane-2,2-diylbis(2,6-dichlorophenol) × 2 GOL GLYCEROL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；320 mM sodium chloride, 100 mM HEPES, 30% PEG3350, pH 7.75, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 1.85 Å R-free 0.250
4MGC Crystal structure of hERa-LBD (Y537S) in complex with benzophenone-2 Deposited 2013-08-28 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain F 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Chain G 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Not recorded 27M bis(2,4-dihydroxyphenyl)methanone × 2 GOL GLYCEROL × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；300 mM sodium chloride, 100 mM HEPES, 28% PEG3350, pH 7.75, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 2.15 Å R-free 0.240
4MGD Crystal structure of hERa-LBD (Y537S) in complex with HPTE Deposited 2013-08-28 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain F 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Chain G 686–698（13 aa） Fragment：coactivator peptide SRC-1 (UNP residues 686-698)
Not recorded 27N 4,4'-(2,2,2-trichloroethane-1,1-diyl)diphenol × 2 GOL GLYCEROL × 1 EDO 1,2-ETHANEDIOL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；340 mM sodium chloride, 100 mM HEPES, 24% PEG3350, pH 7.75, VAPOR DIFFUSION, HANGING DROP, temperature 291K
Resolution 1.90 Å R-free 0.234
4RUJ Crystal structure of zVDR L337H mutant-VD complex Deposited 2014-11-20 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa） Fragment：UNP residues 686-700
Not recorded VDX 5-{2-[1-(5-HYDROXY-1,5-DIMETHYL-HEXYL)-7A-METHYL-OCTAHYDRO-INDEN-4-YLIDENE]-ETHYLIDENE}-4-METHYLENE-CYCLOHEXANE-1,3-DIOL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；297 K；50 mM BIS-TRIS pH6.5, 1.6 M lithium sulfate, 50 mM magnesium sulfate, VAPOR DIFFUSION, HANGING DROP, temperature 297K
Resolution 2.35 Å R-free 0.255
4RUP Crystal structure of zVDR L337H mutant-Gemini72 complex Deposited 2014-11-21 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa） Fragment：UNP residues 686-700
Not recorded H97 (1R,3R,7E,17beta)-17-[(1R)-6,6,6-trifluoro-5-hydroxy-1-(4-hydroxy-4-methylpentyl)-5-(trifluoromethyl)hex-3-yn-1-yl]-9,1 0-secoestra-5,7-diene-1,3-diol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；Bis-Tris 0.1 M, lithium sulfate 1.6 M and magnesium sulfate 50 mM, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 295K
Resolution 2.75 Å R-free 0.253
4UDA MR in complex with dexamethasone Deposited 2014-12-09 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 1427–1441（15 aa） Fragment：RESIDUES 1427-1441
Not recorded GOL GLYCEROL × 1 DEX DEXAMETHASONE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions pH 7.5；30% PEG4000, 0.1M NACL, 0.2M PIPES PH 7.5
Resolution 2.03 Å R-free 0.240
4UDB MR in complex with desisobutyrylciclesonide Deposited 2014-12-09 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 1427–1441（15 aa） Fragment：RESIDUES 1427-1441
Not recorded DMS DIMETHYL SULFOXIDE × 1 GOL GLYCEROL × 1 SO4 SULFATE ION × 1 CV7 DESISOBUYTYRYL CICLESONIDE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions pH 8.5；18% PEG4K, 0.14M LISO4, 85MM TRIS PH 8.5, 15% GLYCEROL
Resolution 2.36 Å R-free 0.218
4Y29 Identification of a novel PPARg ligand that regulates metabolism Deposited 2015-02-09 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 1432–1441（10 aa）
Not recorded CTI 1,2-dimethoxy-12-methyl[1,3]benzodioxolo[5,6-c]phenanthridin-12-ium × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293.15 K；0.2 M Sodium thiocyanate, 20% w/v PEG 3350
Resolution 1.98 Å R-free 0.219
5A86 Structure of pregnane X receptor in complex with a Sphingosine 1- Phosphate Receptor 1 Antagonist Deposited 2015-07-13 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 682–698（17 aa）
Chain D 682–698（17 aa）
Not recorded D7E 4-chloro-N-[(1R)-1-[1-ethyl-6-(trifluoromethyl)benzimidazol-2-yl]ethyl]benzenesulfonamide × 2 X-RAY DIFFRACTION mmCIF provides none of the parsed conditions Resolution 2.25 Å R-free 0.256
5AVI Crystal structure of LXRalpha in complex with tert-butyl benzoate analog, compound 4 Deposited 2015-06-16 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 676–700（25 aa） Fragment：UNP residues 676-700
Chain D 676–700（25 aa） Fragment：UNP residues 676-700
Not recorded 4KM tert-butyl 2-[[4-[ethanoyl(methyl)amino]phenoxy]methyl]-5-(trifluoromethyl)benzoate × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.5；295 K；PEG2000MME, ammonium sulfate, Tris-HCl
Resolution 2.70 Å R-free 0.274
5AVL Crystal structure of LXRalpha in complex with tert-butyl benzoate analog, compound 32b Deposited 2015-06-17 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 676–700（25 aa） Fragment：UNP residues 676-700
Not recorded 4KQ 2-[4-[4-[[2-[(2-methylpropan-2-yl)oxycarbonyl]-3-oxidanyl-4-(trifluoromethyl)phenyl]methoxy]phenyl]phenyl]ethanoic acid × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.5；295 K；PEG2000MME, ammonium sulfate, Tris-HCl
Resolution 2.80 Å R-free 0.243
5AZT Ternary complex of hPPARalpha ligand binding domain, 17-oxoDHA and a SRC1 peptide Deposited 2015-10-23 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain C 683–697（15 aa）
Not recorded 4M5 (4~{Z},7~{Z},10~{Z},13~{Z},19~{Z})-17-oxidanylidenedocosa-4,7,10,13,19-pentaenoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.9；293 K；0.1M HEPES, 35% PEG3350
Resolution 3.45 Å R-free 0.308
5DV3 Human PPARgamma ligand binding dmain complexed with SB1405 in a covalent bonded form Deposited 2015-09-21 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa） Fragment：UNP RESIDUES 685-700
Not recorded B05 N-[2-(benzyloxy)phenyl]-3-nitrobenzamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；297 K；2.2M sodium malonate pH 7.0
Resolution 2.75 Å R-free 0.230
5DV6 Human PPARgamma ligand binding dmain complexed with SB1404 in a covalent bonded form Deposited 2015-09-21 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa） Fragment：UNP RESIDUES 685-700
Not recorded B4H N-methylidene-3-nitrobenzamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；297 K；2.2M sodium malonate pH 7.0
Resolution 2.80 Å R-free 0.244
5DV8 Human PPARgamma ligand binding dmain complexed with SB1451 in a covalent bonded form Deposited 2015-09-21 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa） Fragment：UNP RESIDUES 685-700
Not recorded T51 N-[2-({2-[({4-[(4-methylpiperazin-1-yl)methyl]benzoyl}amino)methyl]benzyl}oxy)phenyl]-3-nitrobenzamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；297 K；0.19M sodium acetate trihydrate, 0.1M sodium cacodylate pH 6.5, 26% PEG 8000
Resolution 2.75 Å R-free 0.243
5DVC Human PPARgamma ligand binding dmain complexed with SB1453 in a covalent bonded form Deposited 2015-09-21 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa） Fragment：UNP RESIDUES 685-700
Not recorded T53 N-[2-({3-[({4-[(4-methylpiperazin-1-yl)methyl]benzoyl}amino)methyl]benzyl}oxy)phenyl]-3-nitrobenzamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；297 K；2.2 M sodium malonate pH 7.0
Resolution 2.30 Å R-free 0.241
5DWL Human PPARgamma ligand binding dmain in complex with SR1664 Deposited 2015-09-22 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa） Fragment：UNP RESIDUES 685-700
Not recorded 3JX 4'-[(2,3-dimethyl-5-{[(1S)-1-(4-nitrophenyl)ethyl]carbamoyl}-1H-indol-1-yl)methyl]biphenyl-2-carboxylic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；297 K；2.2 M sodium malonate pH7.0
Resolution 2.20 Å R-free 0.238
5HJS Identification of LXRbeta selective agonists for the treatment of Alzheimer's Disease Deposited 2016-01-13 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 676–700（25 aa）
Chain D 676–700（25 aa）
Not recorded 668 2-chloro-4-{1'-[(2R)-2-hydroxy-3-methyl-2-(trifluoromethyl)butanoyl]-4,4'-bipiperidin-1-yl}-N,N-dimethylbenzamide × 2 SO4 SULFATE ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；12% PEG MME 2000, 0.1M Ammonium Sulfate, 0.1M Tris buffer pH 7.8
Resolution 1.72 Å R-free 0.238
5JI0 PPARgamma-RXRalpha(S427F) heterodimer in complex with SRC-1, rosiglitazone, and 9-cis-retanoic acid Deposited 2016-04-21 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain E 676–700（25 aa）
Chain F 676–700（25 aa）
Non-standard monomer：Yes (specific site not provided by mmCIF) Non-standard monomer：Yes (specific site not provided by mmCIF) 9CR (9cis)-retinoic acid × 1 BRL 2,4-THIAZOLIDIINEDIONE, 5-[[4-[2-(METHYL-2-PYRIDINYLAMINO)ETHOXY]PHENYL]METHYL]-(9CL) × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；296 K；Crystals grew in the dark at room temperature from 0.5 + 0.5 uL sitting drops equilibrated over a reservoir containing 20-24% PEG3350 and 0.02M Na Citrate
Resolution 1.98 Å R-free 0.246
5JI0 PPARgamma-RXRalpha(S427F) heterodimer in complex with SRC-1, rosiglitazone, and 9-cis-retanoic acid Deposited 2016-04-21 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain F 676–700（25 aa）
Non-standard monomer：Yes (specific site not provided by mmCIF) 9CR (9cis)-retinoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；296 K；Crystals grew in the dark at room temperature from 0.5 + 0.5 uL sitting drops equilibrated over a reservoir containing 20-24% PEG3350 and 0.02M Na Citrate
Resolution 1.98 Å R-free 0.246
5JI0 PPARgamma-RXRalpha(S427F) heterodimer in complex with SRC-1, rosiglitazone, and 9-cis-retanoic acid Deposited 2016-04-21 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain E 676–700（25 aa）
Non-standard monomer：Yes (specific site not provided by mmCIF) BRL 2,4-THIAZOLIDIINEDIONE, 5-[[4-[2-(METHYL-2-PYRIDINYLAMINO)ETHOXY]PHENYL]METHYL]-(9CL) × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；296 K；Crystals grew in the dark at room temperature from 0.5 + 0.5 uL sitting drops equilibrated over a reservoir containing 20-24% PEG3350 and 0.02M Na Citrate
Resolution 1.98 Å R-free 0.246
5JMM Crystal structure of hERa-LBD (Y537S) in complex with biochanin A Deposited 2016-04-29 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain F 686–698（13 aa） Fragment：UNP residues 686-698
Chain G 686–698（13 aa） Fragment：UNP residues 686-698
Not recorded QSO 5,7-dihydroxy-3-(4-methoxyphenyl)-4H-chromen-4-one × 2 GOL GLYCEROL × 2 EDO 1,2-ETHANEDIOL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；250 mM NaCl 100 mM Hepes 16% PEG3350 5% DMSO 10 mM b-mercaptoethanol
Resolution 2.10 Å R-free 0.216
5MX7 1a,20S-dihydroxyvitamin D3 VDR complex Deposited 2017-01-21 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B1 686–700（15 aa） Fragment：UNP residues 686-700
Not recorded D3V 1a,20S-dihydroxyvitamin D3 × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；295 K；BisTris pH 6.5, 1.6 M lithium sulfate and 50 mM magnesium sulfate
Resolution 1.98 Å R-free 0.225
5NMA Structure-activity relationship study of vitamin D analogs with oxolane group in their side chain Deposited 2017-04-05 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa） Fragment：UNP residues 686-700
Not recorded 9CW (1~{R},3~{S},5~{Z})-5-[(2~{E})-2-[(1~{R},3~{a}~{S},7~{a}~{R})-7~{a}-methyl-1-[(1~{S})-1-[(2~{S},5~{S})-5-(2-oxidanylpropan-2-yl)oxolan-2-yl]ethyl]-2,3,3~{a},5,6,7-hexahydro-1~{H}-inden-4-ylidene]ethylidene]-4-methylidene-cyclohexane-1,3-diol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；290 K；0.1 M BTP pH 7.0, 3 M NaOAc
Resolution 2.80 Å R-free 0.272
5NMB Structure-activity relationship study of vitamin D analogs with oxolane group in their side chain Deposited 2017-04-05 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B2 686–700（15 aa） Fragment：UNP residues 686-700
Not recorded 9CZ (1~{R},3~{S},5~{Z})-5-[(2~{E})-2-[(1~{R},3~{a}~{S},7~{a}~{R})-7~{a}-methyl-1-[(1~{S})-1-[(2~{S},5~{R})-5-(2-oxidanylpropan-2-yl)oxolan-2-yl]ethyl]-2,3,3~{a},5,6,7-hexahydro-1~{H}-inden-4-ylidene]ethylidene]-4-methylidene-cyclohexane-1,3-diol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；290 K；0.1 M BTP pH 7.0, 3 M NaOAc
Resolution 2.50 Å R-free 0.260
5NWM Insight into the molecular recognition mechanism of the coactivator NCoA1 by STAT6 Deposited 2017-05-06 Different construct Different mutation/modification Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain A 257–385（129 aa） Fragment：UNP residues 257-385
Mutation：K343R No recorded non-water small molecule SOLUTION NMR
NMR measurement conditions pH 7；309 K；Ionic strength (raw mmCIF value) 150；Pressure 1
NMR sample composition 50 mM HEPES, 150 mM sodium chloride, 10 % D2O, 1 mM [U-99% 13C; U-99% 15N] STAT6, 90% H2O/10% D2O | 90% H2O/10% D2O
NMR sample composition 1 mM [U-99% 13C; U-99% 15N] STAT6, 0.7 mM NCoA1, 50 mM HEPES, 150 mM sodium chloride, 10 % D2O, 90% H2O/10% D2O | 90% H2O/10% D2O
NMR sample composition 0.7 mM [U-99% 13C; U-99% 15N] NCoA1, 1 mM STAT6, 50 mM HEPES, 150 mM sodium chloride, 10 % D2O, 90% H2O/10% D2O | 90% H2O/10% D2O
NMR sample composition 1 mM [U-99% 15N] STAT6, 0.7 mM NCoA1, 50 mM HEPES, 150 mM sodium chloride, 10 % D2O, 90% H2O/10% D2O | 90% H2O/10% D2O
NMR sample composition 0.7 mM [U-99% 15N] NCoA1, 1 mM STAT6, 50 mM HEPES, 150 mM sodium chloride, 10 % D2O, 90% H2O/10% D2O | 90% H2O/10% D2O
NMR sample composition 1 mM [U-99% 15N] STAT6, 50 mM HEPES, 150 mM sodium chloride, 10 % D2O, 90% H2O/10% D2O | 90% H2O/10% D2O
NMR sample composition 1 mM [U-99% 13C; U-99% 15N] STAT6, 0.7 mM NCoA1, 50 mM HEPES, 150 mM sodium chloride, 100 % D2O, 100% D2O | 100% D2O
NMR sample composition 0.7 mM [U-99% 13C; U-99% 15N] NCoA1, 1 mM STAT6, 50 mM HEPES, 150 mM sodium chloride, 100 % D2O, 100% D2O | 100% D2O
Resolution not provided
5OW7 VDR complex Deposited 2017-08-31 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa） Fragment：UNP residues 686-700
Not recorded AYK (3~{S})-3-[(1~{S},3~{a}~{S},4~{E},7~{a}~{S})-7~{a}-methyl-4-[(2~{Z})-2-[(5~{S})-2-methylidene-5-oxidanyl-cyclohexylidene]ethylidene]-2,3,3~{a},5,6,7-hexahydro-1~{H}-inden-1-yl]-3-oxidanyl-~{N}-propan-2-yl-butanamide × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；298 K；50 mM Bis-Tris pH 6.5, 1.6 M lithium sulfate and 50 mM magnesium sulfate
Resolution 2.10 Å R-free 0.227
5OW9 Vitamin D receptor complex Deposited 2017-08-31 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa） Fragment：UNP residues 686-700
Not recorded AYT (1~{S},3~{Z})-3-[(2~{E})-2-[(1~{S},3~{a}~{S},7~{a}~{S})-7~{a}-methyl-1-[(2~{S})-6-methyl-2-oxidanyl-heptan-2-yl]-2,3,3~{a},5,6,7-hexahydro-1~{H}-inden-4-ylidene]ethylidene]-4-methylidene-cyclohexan-1-ol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；298 K；50 mM Bis-Tris pH 6.5, 1.6 M lithium sulfate and 50 mM magnesium sulfate
Resolution 2.40 Å R-free 0.246
5OWD Vitamin D receptor complex Deposited 2017-08-31 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa） Fragment：UNP residues 686-700
Not recorded B0B (1~{S},3~{Z})-3-[(2~{E})-2-[(1~{S},3~{a}~{S},7~{a}~{S})-7~{a}-methyl-1-[(2~{S})-6-methyl-2-oxidanyl-hept-5-en-2-yl]-2,3,3~{a},5,6,7-hexahydro-1~{H}-inden-4-ylidene]ethylidene]-4-methylidene-cyclohexan-1-ol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；298 K；50 mM Bis-Tris pH 6.5, 1.6 M lithium sulfate and 50 mM magnesium sulfate
Resolution 2.15 Å R-free 0.219
5X0R Crystal Structure of PXR LBD Complexed with SJB7 Deposited 2017-01-23 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 676–700（25 aa）
Chain D 676–700（25 aa）
Not recorded 4WH 4-[(4-tert-butylphenyl)sulfonyl]-1-(2,4-dimethoxy-5-methylphenyl)-5-methyl-1H-1,2,3-triazole × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7.8；291 K；Tris-HCl, imidazole, isopropanol,sodium chloride, glycerol, EDTA, pH 7.2-7.8, VAPOR DIFFUSION, HANGING DROP, temperature 291.0K
Resolution 2.67 Å R-free 0.252
5X8U Crystal Structure of the wild Human ROR gamma Ligand Binding Domain. Deposited 2017-03-03 Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 686–700（15 aa） Fragment：UNP residues 686-700
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；277 K；0.1M Sodium acetate pH8.0, 4M ammonium acetate
Resolution 2.00 Å R-free 0.247
5X8W Crystal Structure of the mutant Human ROR gamma Ligand Binding Domain. Deposited 2017-03-03 Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 686–700（15 aa）
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；277 K；0.1M Sodium acetate pH8.0, 4M ammonium acetate
Resolution 2.30 Å R-free 0.230
5Y44 A novel moderator XD4 for bile acid receptor Deposited 2017-08-01 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 745–755（11 aa）
Not recorded XD4 [(1R,2R,4R)-1,7,7-trimethyl-2-bicyclo[2.2.1]heptanyl] 4-azanyl-3-methyl-benzoate × 1 SO4 SULFATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293.15 K；0.1M Magnesium sulfate, 25% w/v polyethylene glycol 8000
Resolution 2.35 Å R-free 0.271
5YCN Human PPARgamma ligand binding domain complexed with Lobeglitazone Deposited 2017-09-07 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa） Fragment：UNP RESIDUES 685-700
Not recorded 8LX (5S)-5-[[4-[2-[[6-(4-methoxyphenoxy)pyrimidin-4-yl]-methyl-amino]ethoxy]phenyl]methyl]-1,3-thiazolidine-2,4-dione × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；296 K；1.6 M sodium citrate tribasic dihydrate (pH 6.5)
Resolution 2.15 Å R-free 0.228
5YCP Human PPARgamma ligand binding domain complexed with Rosiglitazone Deposited 2017-09-07 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa） Fragment：UNP RESIDUES 685-700
Not recorded BRL 2,4-THIAZOLIDIINEDIONE, 5-[[4-[2-(METHYL-2-PYRIDINYLAMINO)ETHOXY]PHENYL]METHYL]-(9CL) × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；296 K；2.2 M sodium malonate (pH 7.0)
Resolution 2.00 Å R-free 0.233
6BNS STRUCTURE OF HUMAN PREGNANE X RECEPTOR LIGAND BINDING DOMAIN BOUND TETHERED WITH SRC co-activator peptide and Compound 25a AKA BICYCLIC HEXAFLUOROISOPROPYL 2 ALCOHOL SULFONAMIDES Deposited 2017-11-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 678–710（33 aa）
Chain B 678–710（33 aa）
Not recorded XGH 2-[(2S)-4-[(4-fluorophenyl)sulfonyl]-7-(1,1,1,3,3,3-hexafluoro-2-hydroxypropan-2-yl)-3,4-dihydro-2H-1,4-benzothiazin-2-yl]-N-(2-hydroxy-2-methylpropyl)acetamide × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；296 K；0.1M Hepes pH 7.5, 150mM NaCl, 10-15%(V/V)PEG10K.Crystals were cryoprotected by supplementing the mother liquor with 15% (v/v) ethylene glycol and harvested by flash-cooling in liquid nitrogen
Resolution 2.56 Å R-free 0.246
6FO7 Vitamin D nuclear receptor complex 3 Deposited 2018-02-06 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa）
Not recorded LX3 (1~{R},3~{S},5~{Z})-4-methylidene-5-[(~{E})-3-[3-(6-methyl-6-oxidanyl-heptyl)phenyl]hept-2-enylidene]cyclohexane-1,3-diol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；295 K；BisTris pH 6.5, 1.6 M lithium sulfate and 50 mM magnesium sulfate
Resolution 2.59 Å R-free 0.230
6GEV Mineralocorticoid receptor in complex with (s)-13 Deposited 2018-04-27 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 1427–1441（15 aa）
Not recorded GOL GLYCEROL × 3 EWN 6-[[(3~{S})-7-fluoranyl-3-(2-methylpropyl)-2,3-dihydro-1,4-benzoxazin-4-yl]carbonyl]-4~{H}-1,4-benzoxazin-3-one × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M (NH4)2SO4, 3.5% 1,4-butanediol, 0.1 M CHES pH 9.5
Resolution 1.54 Å R-free 0.190
6GG8 Mineralocorticoid receptor in complex with (s)-13 Deposited 2018-05-03 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 1427–1441（15 aa）
Not recorded MPD (4S)-2-METHYL-2,4-PENTANEDIOL × 1 EY8 [(3~{R})-7-fluoranyl-4-[(3-oxidanylidene-4~{H}-1,4-benzoxazin-6-yl)carbonyl]-2,3-dihydro-1,4-benzoxazin-3-yl]methanesulfonamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；293 K；0.9M (NH4)2SO4, 0.1 M CHES pH9.5, 10% (v/v) of condition C8 of the Morpheus Screen (Molecular Dimension)
Resolution 1.80 Å R-free 0.228
6HTY PXR in complex with P2X4 inhibitor compound 25 Deposited 2018-10-05 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain A 678–700（23 aa）
Mutation：K129G,K129G GOL GLYCEROL × 1 DMS DIMETHYL SULFOXIDE × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；1 microliter protein at 12.1 mg/ml (in 20 millimolar Tris pH 7.8, 250 millimolar NaCl, 2.5 millimolar EDTA, 5% (v/v) glycerol, 5 mM DTT), preincubated with 10 millimolar compound 15 (from 200 millimolar stock in DMSO), mixed with 1 microliter of reservoir (100 mM imidazole pH 8.0, 17 % (v/v) MPD). Crystals additionally soaked in 20 millimolar compound 15 prior to data collection. cryo buffer 34% (v/v) MPD supplemented with 20 millimolar compound 15
Resolution 2.22 Å R-free 0.226
6HTY PXR in complex with P2X4 inhibitor compound 25 Deposited 2018-10-05 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain B 678–700（23 aa）
Mutation：K129G,K129G DMS DIMETHYL SULFOXIDE × 2 GRH (2~{R})-~{N}-[4-(3-chloranylphenoxy)-3-sulfamoyl-phenyl]-2-phenyl-propanamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；1 microliter protein at 12.1 mg/ml (in 20 millimolar Tris pH 7.8, 250 millimolar NaCl, 2.5 millimolar EDTA, 5% (v/v) glycerol, 5 mM DTT), preincubated with 10 millimolar compound 15 (from 200 millimolar stock in DMSO), mixed with 1 microliter of reservoir (100 mM imidazole pH 8.0, 17 % (v/v) MPD). Crystals additionally soaked in 20 millimolar compound 15 prior to data collection. cryo buffer 34% (v/v) MPD supplemented with 20 millimolar compound 15
Resolution 2.22 Å R-free 0.226
6ICJ Crystal structure of PPARgamma with compound BR102375K Deposited 2018-09-06 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 676–700（25 aa）
Not recorded GOL GLYCEROL × 2 A0L 2-butyl-5-[(3-tert-butyl-1,2,4-oxadiazol-5-yl)methyl]-6-methyl-3-{[2'-(5-oxo-4,5-dihydro-1,2,4-oxadiazol-3-yl)[1,1'-biphenyl]-4-yl]methyl}pyrimidin-4(3H)-one × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；291 K；0.2 M NH4 Acetate, 0.1 M HEPES 7.5 pH, 25 %w/v PEG 3350
Resolution 2.48 Å R-free 0.282
6IJR Human PPARgamma ligand binding domain complexed with SB1495 Deposited 2018-10-11 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa）
Not recorded A9C N-{[3-({[(1S,2R)-2-{[(2E)-2-cyano-4,4-dimethylpent-2-enoyl]amino}cyclopentyl]oxy}methyl)phenyl]methyl}-4-[(4-methylpiperazin-1-yl)methyl]benzamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；295 K；60% (v/v) Tacsimate
Resolution 2.85 Å R-free 0.266
6IJR Human PPARgamma ligand binding domain complexed with SB1495 Deposited 2018-10-11 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 685–700（16 aa）
Not recorded A9C N-{[3-({[(1S,2R)-2-{[(2E)-2-cyano-4,4-dimethylpent-2-enoyl]amino}cyclopentyl]oxy}methyl)phenyl]methyl}-4-[(4-methylpiperazin-1-yl)methyl]benzamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；295 K；60% (v/v) Tacsimate
Resolution 2.85 Å R-free 0.266
6IJS Human PPARgamma ligand binding domain complexed with SB1494 Deposited 2018-10-11 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa）
Not recorded A9F N-{[3-({[(1R,2S)-2-{[(2E)-2-cyano-4,4-dimethylpent-2-enoyl]amino}cyclopentyl]oxy}methyl)phenyl]methyl}-4-[(4-methylpiperazin-1-yl)methyl]benzamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；295 K；2.2 M sodium malonate
Resolution 2.15 Å R-free 0.241
6ILQ Crystal structure of PPARgamma with compound BR101549 Deposited 2018-10-19 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 676–700（25 aa）
Not recorded AE0 ethyl [2-butyl-6-oxo-1-{[2'-(5-oxo-4,5-dihydro-1,2,4-oxadiazol-3-yl)[1,1'-biphenyl]-4-yl]methyl}-4-(propan-2-yl)-1,6-dihydropyrimidin-5-yl]acetate × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；291 K；0.2 M MgCl2, 0.1 M TRIS 8.5 pH, 27 %w/v PEG 3350
Resolution 2.41 Å R-free 0.303
6ITM Crystal structure of FXR in complex with agonist XJ034 Deposited 2018-11-23 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 744–757（14 aa）
Not recorded AWL 1-adamantyl-[4-(5-chloranyl-2-methyl-phenyl)piperazin-1-yl]methanone × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；0.2M Ammonium acetate, 0.1M Bis-Tris pH 6.5, 25% w/v Polyethylene glycol 3350
Resolution 2.50 Å R-free 0.242
6ITM Crystal structure of FXR in complex with agonist XJ034 Deposited 2018-11-23 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 744–757（14 aa）
Not recorded AWL 1-adamantyl-[4-(5-chloranyl-2-methyl-phenyl)piperazin-1-yl]methanone × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；0.2M Ammonium acetate, 0.1M Bis-Tris pH 6.5, 25% w/v Polyethylene glycol 3350
Resolution 2.50 Å R-free 0.242
6JQ7 The ligand-free structure of human PPARgamma LBD in the presence of the SRC-1 coactivator peptide Deposited 2019-03-29 Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa）
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；296 K；60% (v/v) Tacsimate (pH 7.0)
Resolution 2.55 Å R-free 0.257
6KTM The ligand-free structure of human PPARgamma ligand-binding domain R288A mutant in the presence of the SRC-1 coactivator peptide Deposited 2019-08-28 Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa）
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；296 K；2.2 M sodium malonate (pH 7.0)
Resolution 2.70 Å R-free 0.258
6KTN Human PPARgamma ligand-binding domain R288A mutant in complex with imatinib Deposited 2019-08-28 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa）
Not recorded STI 4-(4-METHYL-PIPERAZIN-1-YLMETHYL)-N-[4-METHYL-3-(4-PYRIDIN-3-YL-PYRIMIDIN-2-YLAMINO)-PHENYL]-BENZAMIDE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；296 K；2.2 M sodium malonate (pH 7.0)
Resolution 2.75 Å R-free 0.256
6NX1 STRUCTURE OF HUMAN PREGNANE X RECEPTOR LIGAND BINDING DOMAIN BOUND TETHERED WITH SRC CO-ACTIVATOR PEPTIDE AND COMPOUND-3 AKA 1,1,1,3,3,3-HEXAFLUORO-2-{4-[1-(4- LUOROBENZENESULFONYL)CYCLOPENTYL]PHENYL}PROPAN-2-OL Deposited 2019-02-07 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 678–710（33 aa） Fragment：LIGAND BINDING DOMAIN
Chain B 678–710（33 aa） Fragment：LIGAND BINDING DOMAIN
Not recorded L7D 1,1,1,3,3,3-hexafluoro-2-(4-{1-[(4-fluorophenyl)sulfonyl]cyclopentyl}phenyl)propan-2-ol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；296 K；0.1M Hepes pH 7.5, 150mM NaCl, 10-15%(V/V)PEG10K, Crystals were cryoprotected by supplementing the mother liquor with 15% (v/v) ethylene glycol and harvested by flash-cooling in liquid nitrogen
Resolution 2.27 Å R-free 0.240
6NX1 STRUCTURE OF HUMAN PREGNANE X RECEPTOR LIGAND BINDING DOMAIN BOUND TETHERED WITH SRC CO-ACTIVATOR PEPTIDE AND COMPOUND-3 AKA 1,1,1,3,3,3-HEXAFLUORO-2-{4-[1-(4- LUOROBENZENESULFONYL)CYCLOPENTYL]PHENYL}PROPAN-2-OL Deposited 2019-02-07 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 678–710（33 aa） Fragment：LIGAND BINDING DOMAIN
Chain B 678–710（33 aa） Fragment：LIGAND BINDING DOMAIN
Not recorded L7D 1,1,1,3,3,3-hexafluoro-2-(4-{1-[(4-fluorophenyl)sulfonyl]cyclopentyl}phenyl)propan-2-ol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；296 K；0.1M Hepes pH 7.5, 150mM NaCl, 10-15%(V/V)PEG10K, Crystals were cryoprotected by supplementing the mother liquor with 15% (v/v) ethylene glycol and harvested by flash-cooling in liquid nitrogen
Resolution 2.27 Å R-free 0.240
6P9F Crystal structure of RAR-related orphan receptor C (NHIS-RORGT(244-487)-L6-SRC1(678-692)) in complex with a phenyl (3-phenylpyrrolidin-3-yl)sulfone inhibitor Deposited 2019-06-10 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain A 683–696（14 aa） Fragment：ligand-binding domain (UNP residues 265-508) fused to SRC peptide (UNP residues 683-696)
Not recorded O5A trans-4-{(3R)-3-[(4-fluorophenyl)sulfonyl]-3-[4-(1,1,1,2,3,3,3-heptafluoropropan-2-yl)phenyl]pyrrolidine-1-carbonyl}cyclohexane-1-carboxylic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；298 K；20-26% PEG3350, 0.2 M magnesium chloride, 0.1 M Bis-Tris pH 5.5-6.5
Resolution 2.80 Å R-free 0.223
6P9F Crystal structure of RAR-related orphan receptor C (NHIS-RORGT(244-487)-L6-SRC1(678-692)) in complex with a phenyl (3-phenylpyrrolidin-3-yl)sulfone inhibitor Deposited 2019-06-10 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain B 683–696（14 aa） Fragment：ligand-binding domain (UNP residues 265-508) fused to SRC peptide (UNP residues 683-696)
Not recorded O5A trans-4-{(3R)-3-[(4-fluorophenyl)sulfonyl]-3-[4-(1,1,1,2,3,3,3-heptafluoropropan-2-yl)phenyl]pyrrolidine-1-carbonyl}cyclohexane-1-carboxylic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；298 K；20-26% PEG3350, 0.2 M magnesium chloride, 0.1 M Bis-Tris pH 5.5-6.5
Resolution 2.80 Å R-free 0.223
6SSQ Crystal structure of RARbeta LBD in complex with LG 100754 Deposited 2019-09-09 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain F 686–698（13 aa）
Chain G 686–698（13 aa）
Not recorded 754 (2E,4E,6Z)-3-methyl-7-(5,5,8,8-tetramethyl-3-propoxy-5,6,7,8-tetrahydronaphthalen-2-yl)octa-2,4,6-trienoic acid × 2 FLC CITRATE ANION × 1 GOL GLYCEROL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；291 K；200 mM Tri Sodium Citrate pH 5.5, 25 % PEG 4000
Resolution 2.30 Å R-free 0.208
6T2M VDR-ZK168281 complex Deposited 2019-10-09 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa）
Not recorded M9Q ethyl (~{Z})-3-[1-[(~{E},1~{R},4~{R})-4-[(1~{R},3~{a}~{S},4~{E},7~{a}~{R})-7~{a}-methyl-4-[(2~{Z})-2-[(3~{S},5~{R})-2-methylidene-3,5-bis(oxidanyl)cyclohexylidene]ethylidene]-2,3,3~{a},5,6,7-hexahydro-1~{H}-inden-1-yl]-1-oxidanyl-pent-2-enyl]cyclopropyl]prop-2-enoate × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；50 mM Bis-Tris pH 6.5, 1.6 M lithium sulfate and 50 mM magnesium sulfate
Resolution 3.00 Å R-free 0.259
6TFI PXR IN COMPLEX WITH THROMBIN INHIBITOR COMPOUND 17 Deposited 2019-11-14 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain A 681–700（20 aa）
Mutation：K129G GOL GLYCEROL × 2 MPD (4S)-2-METHYL-2,4-PENTANEDIOL × 1 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；1 MICROLITER PROTEIN AT 12.1 MG/ML (IN 20 MILLIMOLAR TRIS PH 7.8, 250 MILLIMOLAR NACL, 2.5 MILLIMOLAR EDTA, 5% (V/V) GLYCEROL, 5 MM DTT), PREINCUBATED WITH 25 MILLIMOLAR COMPOUND 17 (FROM 500 MILLIMOLAR STOCK IN DMSO) for 24 hours at 277 K, MIXED WITH 1 MICROLITER OF RESERVOIR (100 MILLIMOLAR IMIDAZOLE PH 8.0, 20 % (V/V) MPD). CRYO BUFFER 100 MILLIMOLAR IMIDAZOLE PH 8.0, 30 % (V/V) MPD
Resolution 1.85 Å R-free 0.199
6TFI PXR IN COMPLEX WITH THROMBIN INHIBITOR COMPOUND 17 Deposited 2019-11-14 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain B 681–700（20 aa）
Mutation：K129G GOL GLYCEROL × 3 MPD (4S)-2-METHYL-2,4-PENTANEDIOL × 1 DMS DIMETHYL SULFOXIDE × 2 N6H [2-[(3-chlorophenyl)methylamino]-7-methoxy-1,3-benzoxazol-5-yl]-(2,2-dimethylmorpholin-4-yl)methanone × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；1 MICROLITER PROTEIN AT 12.1 MG/ML (IN 20 MILLIMOLAR TRIS PH 7.8, 250 MILLIMOLAR NACL, 2.5 MILLIMOLAR EDTA, 5% (V/V) GLYCEROL, 5 MM DTT), PREINCUBATED WITH 25 MILLIMOLAR COMPOUND 17 (FROM 500 MILLIMOLAR STOCK IN DMSO) for 24 hours at 277 K, MIXED WITH 1 MICROLITER OF RESERVOIR (100 MILLIMOLAR IMIDAZOLE PH 8.0, 20 % (V/V) MPD). CRYO BUFFER 100 MILLIMOLAR IMIDAZOLE PH 8.0, 30 % (V/V) MPD
Resolution 1.85 Å R-free 0.199
6U25 CRYSTAL STRUCTURE OF RAR-RELATED ORPHAN RECEPTOR C (NHIS- RORGT(244-487)-L6-SRC1(678-692)) IN COMPLEX WITH A TRICYCLIC INVERSE AGONIST Deposited 2019-08-19 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain A 683–696（14 aa） Fragment：LIGAND-BINDING DOMAIN (UNP RESIDUES 265-508) FUSED TO SRC PEPTIDE (UNP RESIDUES 683-696)
Not recorded O5B trans-4-[(3aR,9bR)-9b-[(4-fluorophenyl)sulfonyl]-7-(1,1,1,2,3,3,3-heptafluoropropan-2-yl)-1,2,3a,4,5,9b-hexahydro-3H-benzo[e]indole-3-carbonyl]cyclohexane-1-carboxylic acid × 1 GOL GLYCEROL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；298 K；20-26% PEG3350, 0.2 M MAGNESIUM CHLORIDE, 0.1 M BIS-TRIS PH 5.5-6.5
Resolution 2.61 Å R-free 0.247
6W9H SUBSTITUTED BENZYLOXYTRICYCLIC COMPOUNDS AS RETINOIC ACID-RELATED ORPHAN RECEPTOR GAMMA T AGONISTS Deposited 2020-03-23 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain A 683–696（14 aa）
Not recorded TKJ 4-{(3R)-3-[4-(benzyloxy)phenyl]-3-[(4-fluorophenyl)sulfonyl]pyrrolidine-1-carbonyl}-1lambda~6~-thiane-1,1-dione × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；295 K；protein at 8-10mg/ml, with 0.2M MgCl2, 22% PEG3350, 0.1M Bis-Tris pH 5.5
Resolution 2.00 Å R-free 0.258
6W9I SUBSTITUTED BENZYLOXYTRICYCLIC COMPOUNDS AS RETINOIC ACID-RELATED ORPHAN RECEPTOR GAMMA T AGONISTS Deposited 2020-03-23 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain A 683–696（14 aa）
Not recorded Z7D 1-(benzyloxy)-4-{1-[(4-fluorophenyl)sulfonyl]cyclopentyl}benzene × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；295 K；protein at 8-10mg/ml, with 0.2M MgCl2, 22% PEG3350, 0.1M Bis-Tris pH 5.5
Resolution 1.61 Å R-free 0.235
6XP9 STRUCTURE OF HUMAN PREGNANE X RECEPTOR LIGAND BINDING DOMAIN BOUND TETHERED WITH SRC co-activator peptide IN COMPLEX WITH (S,S)-1 Deposited 2020-07-08 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain A 678–710（33 aa） Fragment：Ligand Binding Domain tethered with SRC co-activator peptide
Not recorded QCG (2S)-tert-butoxy[7-(8-fluoro-5-methyl-3,4-dihydro-2H-1-benzopyran-6-yl)-5-methyl-2-phenylpyrazolo[1,5-a]pyrimidin-6-yl]acetic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；296 K；0.1 M Ammonium acetate, 0.1 M Sodium HEPES pH 7.5, 18-20 % w/v PEG 4000.Crystals were cryoprotected by supplementing the mother liquor with 20% (v/v) Glycerol and harvested by flash-cooling in liquid nitrogen
Resolution 2.27 Å R-free 0.220
6XP9 STRUCTURE OF HUMAN PREGNANE X RECEPTOR LIGAND BINDING DOMAIN BOUND TETHERED WITH SRC co-activator peptide IN COMPLEX WITH (S,S)-1 Deposited 2020-07-08 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain B 678–710（33 aa） Fragment：Ligand Binding Domain tethered with SRC co-activator peptide
Not recorded QCG (2S)-tert-butoxy[7-(8-fluoro-5-methyl-3,4-dihydro-2H-1-benzopyran-6-yl)-5-methyl-2-phenylpyrazolo[1,5-a]pyrimidin-6-yl]acetic acid × 1 GOL GLYCEROL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；296 K；0.1 M Ammonium acetate, 0.1 M Sodium HEPES pH 7.5, 18-20 % w/v PEG 4000.Crystals were cryoprotected by supplementing the mother liquor with 20% (v/v) Glycerol and harvested by flash-cooling in liquid nitrogen
Resolution 2.27 Å R-free 0.220
7AOS crystal structure of the RARalpha/RXRalpha ligand binding domain heterodimer in complex with a fragment of SRC1 coactivator Deposited 2020-10-15 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 686–712（27 aa）
Chain D 686–712（27 aa）
Not recorded LG2 6-[1-(3,5,5,8,8-PENTAMETHYL-5,6,7,8-TETRAHYDRONAPHTHALEN-2-YL)CYCLOPROPYL]PYRIDINE-3-CARBOXYLIC ACID × 1 GOL GLYCEROL × 1 EQN 4-{[(5,5,8,8-tetramethyl-5,6,7,8-tetrahydronaphthalen-2-yl)carbonyl]amino}benzoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；293 K；24% PEG 3350, 0.2M Na acetate, 0.1M Bis Tris Propane pH 7.0
Resolution 2.55 Å R-free 0.262
7B39 Allene-Based Design of a Noncalcemic Vitamin D Receptor Agonist Deposited 2020-11-29 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa）
Not recorded T0H (1R,3S,Z)-5-(2-((3aS,7aS,E)-1-(6-hydroxy-6-methylhept-1-en-1-ylidene)-7a-methyloctahydro-4H-inden-4-ylidene)ethylidene)-4-methylenecyclohexane-1,3-diol × 2 ACT ACETATE ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；293 K；50 mM BisTris pH 6.5, 1.6 M lithium sulfate and 50 mM magnesium sulfate
Resolution 2.13 Å R-free 0.247
7BNS VDR complex with BXL-62 Deposited 2021-01-22 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B2 686–700（15 aa）
Not recorded U5W 1,25-Dihydroxy-16-ene-20-cyclopropyl-vitamin D3 × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；273 K；50 mM Bis-Tris pH 6.5, 1.6 M lithium sulfate and 50 mM magnesium sulfate
Resolution 2.70 Å R-free 0.260
7BNU VDR complex with BXL-62 Deposited 2021-01-22 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B2 686–700（15 aa）
Not recorded U5W 1,25-Dihydroxy-16-ene-20-cyclopropyl-vitamin D3 × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；273 K；50 mM Bis-Tris pH 6.5, 1.6 M lithium sulfate and 50 mM magnesium sulfate
Resolution 2.40 Å R-free 0.261
7BO6 VDR complex with LCA derivative Deposited 2021-01-24 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa）
Not recorded FKC (4R)-4-[(3R,5R,8R,9S,10S,13R,14S,17R)-10,13-dimethyl-3-(2-methyl-2-oxidanyl-propyl)-2,3,4,5,6,7,8,9,11,12,14,15,16,17-tetradecahydro-1H-cyclopenta[a]phenanthren-17-yl]pentanoic acid × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；293 K；50 mM Bis-Tris pH 6.5, 1.6 M lithium sulfate and 50 mM magnesium sulfate
Resolution 2.86 Å R-free 0.263
7BPY X-ray structure of human PPARalpha ligand binding domain-clofibric acid-SRC1 coactivator peptide co-crystals obtained by delipidation and co-crystallization Deposited 2020-03-23 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 683–697（15 aa）
Not recorded E0O 2-(4-chloranylphenoxy)-2-methyl-propanoic acid × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；277 K；0.1 M Tris (pH 8.5), 30 %(w/v) PEG3350
Resolution 2.09 Å R-free 0.215
7BPY X-ray structure of human PPARalpha ligand binding domain-clofibric acid-SRC1 coactivator peptide co-crystals obtained by delipidation and co-crystallization Deposited 2020-03-23 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 683–697（15 aa）
Not recorded E0O 2-(4-chloranylphenoxy)-2-methyl-propanoic acid × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；277 K；0.1 M Tris (pH 8.5), 30 %(w/v) PEG3350
Resolution 2.09 Å R-free 0.215
7BPZ X-ray structure of human PPARalpha ligand binding domain-bezafibrate-SRC1 coactivator peptide co-crystals obtained by soaking Deposited 2020-03-23 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 683–697（15 aa）
Not recorded PEM 2-[P-[2-P-CHLOROBENZAMIDO)ETHYL]PHENOXY]-2-METHYLPROPIONIC ACID × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；277 K；0.1 M Tris (pH 8.5), 25 %(w/v) PEG3350
Resolution 2.43 Å R-free 0.242
7BPZ X-ray structure of human PPARalpha ligand binding domain-bezafibrate-SRC1 coactivator peptide co-crystals obtained by soaking Deposited 2020-03-23 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 683–697（15 aa）
Not recorded PEM 2-[P-[2-P-CHLOROBENZAMIDO)ETHYL]PHENOXY]-2-METHYLPROPIONIC ACID × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；277 K；0.1 M Tris (pH 8.5), 25 %(w/v) PEG3350
Resolution 2.43 Å R-free 0.242
7BQ0 X-ray structure of human PPARalpha ligand binding domain-fenofibric acid-SRC1 coactivator peptide co-crystals obtained by delipidation and co-crystallization Deposited 2020-03-23 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 683–697（15 aa）
Not recorded F5A 2-[4-(4-chlorobenzene-1-carbonyl)phenoxy]-2-methylpropanoic acid × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；277 K；0.1M Tris (pH 8.5), 25 %(w/v) PEG3350
Resolution 1.77 Å R-free 0.217
7BQ0 X-ray structure of human PPARalpha ligand binding domain-fenofibric acid-SRC1 coactivator peptide co-crystals obtained by delipidation and co-crystallization Deposited 2020-03-23 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain D 683–697（15 aa）
Not recorded F5A 2-[4-(4-chlorobenzene-1-carbonyl)phenoxy]-2-methylpropanoic acid × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；277 K；0.1M Tris (pH 8.5), 25 %(w/v) PEG3350
Resolution 1.77 Å R-free 0.217
7BQ1 X-ray structure of human PPARalpha ligand binding domain-intrinsic fatty acid (E. coli origin)-SRC1 coactivator peptide co-crystals obtained by co-crystallization Deposited 2020-03-23 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 683–697（15 aa）
Not recorded PLM PALMITIC ACID × 1 GOL GLYCEROL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；277 K；0.1 M Tris (pH 8.0), 25 %(w/v) PEG3350
Resolution 1.52 Å R-free 0.213
7BQ2 X-ray structure of human PPARalpha ligand binding domain-pemafibrate-SRC1 coactivator peptide co-crystals obtained by soaking Deposited 2020-03-23 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 683–697（15 aa）
Not recorded P7F (2~{R})-2-[3-[[1,3-benzoxazol-2-yl-[3-(4-methoxyphenoxy)propyl]amino]methyl]phenoxy]butanoic acid × 1 GOL GLYCEROL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；277 K；0.1M Tris (pH 8.0), 25%(w/v) PEG3350
Resolution 1.52 Å R-free 0.206
7BQ3 X-ray structure of human PPARalpha ligand binding domain-GW7647-SRC1 coactivator peptide co-crystals obtained by delipidation and co-crystallization Deposited 2020-03-23 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 683–697（15 aa）
Not recorded 2VN 2-[(4-{2-[(4-cyclohexylbutyl)(cyclohexylcarbamoyl)amino]ethyl}phenyl)sulfanyl]-2-methylpropanoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；277 K；0.1M Tris (pH 8.5), 25%(w/v) PEG3350
Resolution 1.98 Å R-free 0.237
7BQ4 X-ray structure of human PPARalpha ligand binding domain-eicosapentaenoic acid (EPA)-SRC1 coactivator peptide co-crystals obtained by delipidation and co-crystallization Deposited 2020-03-23 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 683–697（15 aa）
Not recorded EPA 5,8,11,14,17-EICOSAPENTAENOIC ACID × 1 GOL GLYCEROL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；277 K；0.1 M Tris (pH 8.0), 30 %(w/v) PEG3350
Resolution 1.62 Å R-free 0.214
7CXF The ligand-free structure of human PPARgamma LBD C285Y mutant in the presence of the SRC-1 coactivator peptide Deposited 2020-09-01 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa）
Not recorded MLA MALONIC ACID × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；295 K；2.2 M sodium malonate (pH 7.0)
Resolution 2.35 Å R-free 0.269
7CXH The ligand-free structure of human PPARgamma LBD Q286E mutant in the presence of the SRC-1 coactivator peptide Deposited 2020-09-01 Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa）
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；295 K；2.2 M sodium malonate (pH 7.0)
Resolution 2.30 Å R-free 0.257
7CXI The ligand-free structure of human PPARgamma LBD F287Y mutant in the presence of the SRC-1 coactivator peptide Deposited 2020-09-01 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa）
Not recorded MLI MALONATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；295 K；2.2 M sodium malonate (pH 7.0)
Resolution 2.30 Å R-free 0.276
7CXJ The ligand-free structure of human PPARgamma LBD R288C mutant in the presence of the SRC-1 coactivator peptide Deposited 2020-09-01 Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa）
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；295 K；2.2 M sodium malonate (pH 7.0)
Resolution 2.65 Å R-free 0.275
7CXK The ligand-free structure of human PPARgamma LBD R288H mutant in the presence of the SRC-1 coactivator peptide Deposited 2020-09-01 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa）
Not recorded MLI MALONATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；295 K；2.2 M sodium malonate (pH 7.0)
Resolution 2.20 Å R-free 0.264
7CXL The ligand-free structure of human PPARgamma LBD S289C mutant in the presence of the SRC-1 coactivator peptide Deposited 2020-09-01 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 685–700（16 aa）
Not recorded MLA MALONIC ACID × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；295 K；2.2 M sodium malonate (pH 7.0)
Resolution 2.70 Å R-free 0.255
7JYM CRYSTAL STRUCTURE OF RAR-RELATED ORPHAN RECEPTOR C (NHIS-RORGT(244-487)-L6-SRC1(678-692)) IN COMPLEX WITH A TRICYCLIC SULFONE INVERSE AGONIST Deposited 2020-08-31 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain A 683–696（14 aa） Fragment：;LIGAND-BINDING DOMAIN (UNP RESIDUES 265-508) FUSED TO SRC PEPTIDE (UNP RESIDUES 683-696),LIGAND-BINDING DOMAIN (UNP RESIDUES 265-508) FUSED TO SRC PEPTIDE (UNP RESIDUES 683-696) ;
Not recorded Z8I (3R,5S)-3-fluoro-5-[(3aR,9bR)-9b-[(4-fluorophenyl)sulfonyl]-7-(1,1,1,2,3,3,3-heptafluoropropan-2-yl)-1,2,3a,4,5,9b-hexahydro-3H-benzo[e]indole-3-carbonyl]-1-(2-hydroxy-2-methylpropyl)pyrrolidin-2-one × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；298 K；20-26% PEG3350, 0.2 M MAGNESIUM CHLORIDE, 0.1 M BIS-TRIS PH 5.5-6.5, VAPOR DIFFUSION, HANGING DROP, TEMPERATURE 298K
Resolution 3.05 Å R-free 0.264
7KXD CRYSTAL STRUCTURE OF RAR-RELATED ORPHAN RECEPTOR C (NHIS-RORGT(244-487)-L6-SRC1(678-692)) IN COMPLEX WITH {3,5-DICHLORO-4-[4-METHOXY-3-(PROPAN-2-YL)PHENOXY]PHENYL}METHANOL Deposited 2020-12-03 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain A 683–696（14 aa）
Not recorded Z7G {3,5-dichloro-4-[4-methoxy-3-(propan-2-yl)phenoxy]phenyl}methanol × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；298 K；22% PEG3350, 0.2 M MAGNESIUM CHLORIDE, 0.1 M BIS-TRIS PH 5.5, VAPOR DIFFUSION, HANGING DROP, TEMPERATURE 298K
Resolution 1.62 Å R-free 0.239
7KXE CRYSTAL STRUCTURE OF RAR-RELATED ORPHAN RECEPTOR C (NHIS-RORGT(244-487)-L6-SRC1(678-692)) IN COMPLEX WITH {3,5-DICHLORO-4-[4-METHOXY-3-(PROPAN-2-YL)PHENOXY]PHENYL}METHANOL Deposited 2020-12-03 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain A 683–696（14 aa）
Not recorded Z7H N-{3,5-dichloro-4-[4-methoxy-3-(propan-2-yl)phenoxy]phenyl}-2-(pyridin-3-yl)acetamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；295 K；22% PEG3350, 0.2 M MAGNESIUM CHLORIDE, 0.1 M BIS-TRIS PH 5.5, VAPOR DIFFUSION, HANGING DROP, TEMPERATURE 298K
Resolution 2.42 Å R-free 0.241
7KXF CRYSTAL STRUCTURE OF RAR-RELATED ORPHAN RECEPTOR C (NHIS-RORGT(244-487)-L6-SRC1(678-692)) IN COMPLEX WITH {3,5-DICHLORO-4-[4-METHOXY-3-(PROPAN-2-YL)PHENOXY]PHENYL}METHANOL Deposited 2020-12-03 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain A 683–696（14 aa）
Not recorded Z7I N-(3,5-dichloro-4-{[6-methoxy-5-(propan-2-yl)pyridin-3-yl]oxy}phenyl)-2-[1-(methylsulfonyl)piperidin-4-yl]acetamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；298 K；22% PEG3350, 0.2 M MAGNESIUM CHLORIDE, 0.1 M BIS-TRIS PH 5.5, VAPOR DIFFUSION, HANGING DROP, TEMPERATURE 298K
Resolution 2.14 Å R-free 0.234
7OXZ VDR complex with a side-chain hydroxylated derivative of lithocholic acid Deposited 2021-06-23 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa）
Not recorded 2UI (3R,6R)-6-[(3R,5R,8R,9S,10S,13R,14S,17R)-10,13-dimethyl-3-(2-methyl-2-oxidanyl-propyl)-2,3,4,5,6,7,8,9,11,12,14,15,16,17-tetradecahydro-1H-cyclopenta[a]phenanthren-17-yl]heptane-1,3-diol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；293 K；50 mM Bis-Tris pH 6.5, 1.6 M lithium sulfate and 50 mM magnesium sulfate
Resolution 2.20 Å R-free 0.254
7OY4 VDR complex of a side-chain hydroxylated derivatives of lithocholic acid Deposited 2021-06-23 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa）
Not recorded 2WV (3S,6R)-6-[(3R,5R,8R,9S,10S,13R,14S,17R)-10,13-dimethyl-3-(2-methyl-2-oxidanyl-propyl)-2,3,4,5,6,7,8,9,11,12,14,15,16,17-tetradecahydro-1H-cyclopenta[a]phenanthren-17-yl]heptane-1,3-diol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；290 K；50 mM Bis-Tris pH 6.5, 1.6 M lithium sulfate and 50 mM magnesium sulfate
Resolution 2.00 Å R-free 0.238
7QPI Structure of lamprey VDR in complex with 1,25D3 Deposited 2022-01-04 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain U 686–698（13 aa）
Not recorded VDX 5-{2-[1-(5-HYDROXY-1,5-DIMETHYL-HEXYL)-7A-METHYL-OCTAHYDRO-INDEN-4-YLIDENE]-ETHYLIDENE}-4-METHYLENE-CYCLOHEXANE-1,3-DIOL × 1 MG MAGNESIUM ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；PEG 3350 25%, Tris 0.1M pH 8.5, magnesium chloride 0.2M
Resolution 2.50 Å R-free 0.256
7WGO X-ray structure of human PPAR gamma ligand binding domain-bezafibrate co-rystals obtained by co-crystallization Deposited 2021-12-28 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 683–697（15 aa）
Not recorded PEM 2-[P-[2-P-CHLOROBENZAMIDO)ETHYL]PHENOXY]-2-METHYLPROPIONIC ACID × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；293 K；0.1 M Tris (pH 8.0), 1.1 M trisodium citrate
Resolution 2.36 Å R-free 0.225
7WGP X-ray structure of human PPAR gamma ligand binding domain-fenofibric acid co-crystals obtained by co-crystallization Deposited 2021-12-28 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 683–697（15 aa）
Not recorded F5A 2-[4-(4-chlorobenzene-1-carbonyl)phenoxy]-2-methylpropanoic acid × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；293 K；0.1 M Tris (pH 8.0), 1.1 M trisodium citrate
Resolution 2.53 Å R-free 0.269
7WGQ X-ray structure of human PPAR gamma ligand binding domain-pemafibrate co-crystals obtained by co-crystallization Deposited 2021-12-28 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 683–697（15 aa）
Not recorded P7F (2~{R})-2-[3-[[1,3-benzoxazol-2-yl-[3-(4-methoxyphenoxy)propyl]amino]methyl]phenoxy]butanoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；293 K；0.1 M HEPES (pH 7.5), 1.1 M trisodium citrate
Resolution 2.43 Å R-free 0.252
7WQQ Retinoic acid receptor alpha mutant - N299H Deposited 2022-01-25 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain C 686–698（13 aa）
Not recorded 5Z6 4-[(E)-3-(3,5-ditert-butylphenyl)-3-oxidanylidene-prop-1-enyl]benzoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；277 K；0.05M Bis-Tris Propane pH 5.0, 0.05M Citric acid, 18% PEG 3350
Resolution 1.90 Å R-free 0.206
7XVY Human Estrogen Receptor beta Ligand-binding Domain in Complex with S-DPN Deposited 2022-05-25 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 628–640（13 aa）
Chain D 628–640（13 aa）
Not recorded I0K (2~{S})-2,3-bis(4-hydroxyphenyl)propanenitrile × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；293 K；16-20% PEG3350, 100 mM BisTris pH6.5, 200 mM Magnesium Acetate
Resolution 1.54 Å R-free 0.237
7YFK The structure of human pregnane X receptor in complex with an SRC-1 coactivator peptide and a limonoid compound, nomilin Deposited 2022-07-08 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 676–700（25 aa）
Chain B 676–700（25 aa）
Not recorded G3L Nomilin × 2 X-RAY DIFFRACTION
X-ray crystallization conditions EVAPORATION；pH 8；277.15 K；10% (v/v) 2-propanol, 100 mM Imidazole/ Hydrochloric acid, pH 8.0
Resolution 2.10 Å
7ZFG VDR complex with aromatic D-ring analog Deposited 2022-04-01 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 686–700（15 aa）
Not recorded ACT ACETATE ION × 1 IV5 (1R,3S,5Z)-4-methylidene-5-[(E)-9-methyl-3-[3-(6-methyl-6-oxidanyl-heptyl)phenyl]-9-oxidanyl-dec-2-enylidene]cyclohexane-1,3-diol × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；293 K；NaAcetate 2.5M, BisTris 0.1M
Resolution 2.62 Å R-free 0.261
7ZFX VDR complex with Aromatic-D-Ring Analog Deposited 2022-04-01 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 686–700（15 aa）
Not recorded ACT ACETATE ION × 1 IV1 (1R,3S,5Z)-5-[(E)-3-[3,5-bis(6-methyl-6-oxidanyl-heptyl)phenyl]prop-2-enylidene]-4-methylidene-cyclohexane-1,3-diol × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 8；293 K；NaActetae 2.5M, Tris 0.1M
Resolution 2.60 Å R-free 0.254
8CK5 VDR LBD complex with 25-nitro derivative of 1,25D3 Deposited 2023-02-14 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 686–700（15 aa）
Not recorded ACT ACETATE ION × 1 UYO (1S,3R,5Z,7E,13xi)-25-nitro-9,10-secocholesta-5,7,10-triene-1,3-diol × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；293 K；50 mM Bis-Tris pH 6.5, 1.6 M lithium sulfate and 50 mM magnesium sulfate
Resolution 2.10 Å R-free 0.243
8CKC Vitamin D receptor complex with 25-amine derivative of 1,25D3 Deposited 2023-02-15 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa）
Not recorded ACT ACETATE ION × 2 UYU (1R,3S,5Z)-5-[(2E)-2-[(1R,3aS,7aR)-1-[(2R)-6-azanyl-6-methyl-heptan-2-yl]-7a-methyl-2,3,3a,5,6,7-hexahydro-1H-inden-4-ylidene]ethylidene]-4-methylidene-cyclohexane-1,3-diol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 6.5；293 K；50 mM Bis-Tris pH 6.5, 1.6 M lithium sulfate and 50 mM magnesium sulfate
Resolution 2.10 Å R-free 0.232
8F5Y Crystal structure of pregnane X receptor ligand binding domain complexed with JQ1 Deposited 2022-11-15 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain C 676–700（25 aa）
Chain D 676–700（25 aa）
Not recorded JQ1 (6S)-6-(2-tert-butoxy-2-oxoethyl)-4-(4-chlorophenyl)-2,3,9-trimethyl-6,7-dihydrothieno[3,2-f][1,2,4]triazolo[4,3-a][1,4]diazepin-10-ium × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；50 mM imidazole pH 7.0, 8% isopropanol
Resolution 2.15 Å R-free 0.215
8HUK X-ray structure of human PPAR alpha ligand binding domain-lanifibranor-SRC1 coactivator peptide co-crystals obtained by soaking Deposited 2022-12-24 Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 683–697（15 aa）
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；277 K；0.1 M Tris (pH 8.5), 25%(w/v) PEG3350
Resolution 2.98 Å R-free 0.254
8HUM X-ray structure of human PPAR gamma ligand binding domain-lanifibranor-SRC1 coactivator peptide co-crystals obtained by co-crystallization Deposited 2022-12-24 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 683–697（15 aa）
Not recorded BJB 4-[1-(1,3-benzothiazol-6-ylsulfonyl)-5-chloro-indol-2-yl]butanoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；293 K；0.1 M HEPES (pH 7.5), 1.0 M trisodium citrate
Resolution 2.29 Å R-free 0.250
8HUP X-ray structure of human PPAR gamma ligand binding domain-seladelpar-SRC1 coactivator peptide co-crystals obtained by co-crystallization Deposited 2022-12-24 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 683–697（15 aa）
Not recorded KKB Seladelpar × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；293 K；0.1 M Tris (pH 8.0), 1.1 M trisodium citrate
Resolution 2.36 Å R-free 0.234
8HUQ X-ray structure of human PPAR alpha ligand binding domain-elafibranor-SRC1 coactivator peptide co-crystals obtained by soaking Deposited 2022-12-24 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 683–697（15 aa）
Not recorded GOL GLYCEROL × 1 MUO 2-[2,6-dimethyl-4-[(~{E})-3-(4-methylsulfanylphenyl)-3-oxidanylidene-prop-1-enyl]phenoxy]-2-methyl-propanoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；277 K；0.1 M Tris (pH 8.5), 25%(w/v) PEG3350
Resolution 1.65 Å R-free 0.213
8P9W vitamin D receptor complex with Xe4MeCF3 analog Deposited 2023-06-06 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa）
Not recorded XDO (1~{R},3~{S},5~{Z})-5-[(2~{E})-2-[(1~{S},3~{a}~{S},7~{a}~{S})-1,7~{a}-dimethyl-1-[6,6,6-tris(fluoranyl)-5-oxidanyl-5-(trifluoromethyl)hexa-1,3-diynyl]-2,3,3~{a},5,6,7-hexahydroinden-4-ylidene]ethylidene]-4-methylidene-cyclohexane-1,3-diol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；293 K；0.1 M BTP pH 7.0, 3 M NaOAc
Resolution 2.90 Å R-free 0.234
8SVN Crystal structure of the apo form of pregnane X receptor ligand binding domain Deposited 2023-05-17 Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 678–710（33 aa）
Chain B 678–710（33 aa）
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 7；277 K；in 0.1 M HEPES pH 7.0, and 14% Isopropanol
Resolution 2.20 Å R-free 0.235
8SVO Crystal structure of pregnane X receptor ligand binding domain in complex with SJPYT-310 Deposited 2023-05-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 678–710（33 aa）
Chain B 678–710（33 aa）
Not recorded WSO (1P)-N-(5-tert-butyl-2-{[(2S)-pentan-2-yl]oxy}phenyl)-1-(2-methoxy-5-methylphenyl)-5-methyl-1H-1,2,3-triazole-4-carboxamide × 2 DMS DIMETHYL SULFOXIDE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；50 mM Bis-Tris pH 6.0-7.0, 9-16% (v/v) 2-Methyl-2,4-pentanediol
Resolution 2.35 Å R-free 0.238
8SVP Crystal structure of pregnane X receptor ligand binding domain in complex with SJPYT-278 Deposited 2023-05-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 678–710（33 aa）
Chain B 678–710（33 aa）
Not recorded WSX (1P)-N-(5-tert-butyl-2-{[(3S)-hexan-3-yl]oxy}phenyl)-1-(2,5-dimethoxyphenyl)-5-methyl-1H-1,2,3-triazole-4-carboxamide × 2 YGO (1P)-N-(5-tert-butyl-2-{[(3R)-hexan-3-yl]oxy}phenyl)-1-(2,5-dimethoxyphenyl)-5-methyl-1H-1,2,3-triazole-4-carboxamide × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；50 mM Bis-Tris pH 6.0-7.0, 9-16% (v/v) 2-Methyl-2,4-pentanediol
Resolution 3.32 Å R-free 0.252
8SVQ Crystal structure of pregnane X receptor ligand binding domain in complex with SJPYT-312 Deposited 2023-05-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 678–710（33 aa）
Chain B 678–710（33 aa）
Not recorded WSX (1P)-N-(5-tert-butyl-2-{[(3S)-hexan-3-yl]oxy}phenyl)-1-(2,5-dimethoxyphenyl)-5-methyl-1H-1,2,3-triazole-4-carboxamide × 2 DMS DIMETHYL SULFOXIDE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；50 mM Bis-Tris pH 6.0-7.0, 9-16% (v/v) 2-Methyl-2,4-pentanediol
Resolution 2.75 Å R-free 0.262
8SVR Crystal structure of pregnane X receptor ligand binding domain in complex with SJPYT-326 Deposited 2023-05-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 678–710（33 aa）
Chain B 678–710（33 aa）
Not recorded DMS DIMETHYL SULFOXIDE × 1 WT1 (1P)-N-(5-tert-butyl-2-{[(3S)-hexan-3-yl]oxy}phenyl)-5-methyl-1-(2,4,5-trimethoxyphenyl)-1H-1,2,3-triazole-4-carboxamide × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；50 mM Bis-Tris pH 6.0-7.0, 9-16% (v/v) 2-Methyl-2,4-pentanediol
Resolution 2.92 Å R-free 0.258
8SVS Crystal structure of pregnane X receptor ligand binding domain in complex with SJPYT-328 Deposited 2023-05-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 678–710（33 aa）
Chain B 678–710（33 aa）
Not recorded WU2 (1P)-N-(5-tert-butyl-2-{[(3S)-hexan-3-yl]oxy}phenyl)-1-(2,4-dimethoxy-5-methylphenyl)-5-methyl-1H-1,2,3-triazole-4-carboxamide × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；50 mM Bis-Tris pH 6.0-7.0, 9-16% (v/v) 2-Methyl-2,4-pentanediol
Resolution 2.68 Å R-free 0.250
8SVT Crystal structure of pregnane X receptor ligand binding domain in complex with SJPYT-331 Deposited 2023-05-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 678–710（33 aa）
Chain B 678–710（33 aa）
Not recorded WU6 methyl 3-{[(1P)-1-(2,5-dimethoxyphenyl)-5-methyl-1H-1,2,3-triazole-4-carbonyl]amino}-4-{[(3S)-hexan-3-yl]oxy}benzoate × 2 DMS DIMETHYL SULFOXIDE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；50 mM Bis-Tris pH 6.0-7.0, 9-16% (v/v) 2-Methyl-2,4-pentanediol
Resolution 2.39 Å R-free 0.237
8SVU Crystal structure of the L428V mutant of pregnane X receptor ligand binding domain in apo form Deposited 2023-05-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 678–710（33 aa）
Chain B 678–710（33 aa）
Mutation：L428V Mutation：L428V GOL GLYCEROL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；50 mM Bis-Tris pH 6.0-7.0, 9-16% (v/v) 2-Methyl-2,4-pentanediol
Resolution 2.89 Å R-free 0.244
8SVX Crystal structure of the L428V mutant of pregnane X receptor ligand binding domain in complex with SJPYT-331 Deposited 2023-05-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 678–710（33 aa）
Chain B 678–710（33 aa）
Mutation：L428V Mutation：L428V WU6 methyl 3-{[(1P)-1-(2,5-dimethoxyphenyl)-5-methyl-1H-1,2,3-triazole-4-carbonyl]amino}-4-{[(3S)-hexan-3-yl]oxy}benzoate × 2 DMS DIMETHYL SULFOXIDE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；50 mM Bis-Tris pH 6.0-7.0, 9-16% (v/v) 2-Methyl-2,4-pentanediol
Resolution 2.14 Å R-free 0.235
9EYR VDR complex with gemini analog UG-480 Deposited 2024-04-09 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa）
Not recorded A1H75 (1~{R},3~{S},5~{Z})-5-[(2~{E})-2-[(1~{R},3~{a}~{S},7~{a}~{R})-7~{a}-methyl-1-[(1~{R})-5-methyl-1-[(1~{S},2~{S})-2-(3-methyl-3-oxidanyl-butyl)cyclopropyl]-5-oxidanyl-hexyl]-2,3,3~{a},5,6,7-hexahydro-1~{H}-inden-4-ylidene]ethylidene]-4-methylidene-cyclohexane-1,3-diol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；293 K；Li2SO4 1.8M
Resolution 2.56 Å R-free 0.259
9FBF VDR complex with UG-481 Deposited 2024-05-13 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric
Chain B 686–700（15 aa）
Not recorded A1IBM (1~{R},3~{S},5~{Z})-5-[(2~{E})-2-[(1~{R},3~{a}~{S},7~{a}~{R})-7~{a}-methyl-1-[(1~{S})-5-methyl-1-[(1~{R},2~{R})-2-(3-methyl-3-oxidanyl-butyl)cyclopropyl]-5-oxidanyl-hexyl]-2,3,3~{a},5,6,7-hexahydro-1~{H}-inden-4-ylidene]ethylidene]-4-methylidene-cyclohexane-1,3-diol × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；Li2SO4 1.8M
Resolution 3.01 Å R-free 0.258
9FZI A new crystal structure of the hPXR-LBD in fusion with an SRC1 co-activator peptide and in complex with SR12813 (P212121 form) Deposited 2024-07-05 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain A 678–700（23 aa）
Not recorded SRL [2-(3,5-DI-TERT-BUTYL-4-HYDROXY-PHENYL)-1-(DIETHOXY-PHOSPHORYL)-VINYL]-PHOSPHONIC ACID DIETHLYL ESTER × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；277 K；100 mM Imidazole 25 - 30% MPD
Resolution 2.70 Å R-free 0.237
9FZI A new crystal structure of the hPXR-LBD in fusion with an SRC1 co-activator peptide and in complex with SR12813 (P212121 form) Deposited 2024-07-05 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain B 678–700（23 aa）
Not recorded SRL [2-(3,5-DI-TERT-BUTYL-4-HYDROXY-PHENYL)-1-(DIETHOXY-PHOSPHORYL)-VINYL]-PHOSPHONIC ACID DIETHLYL ESTER × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；277 K；100 mM Imidazole 25 - 30% MPD
Resolution 2.70 Å R-free 0.237
9O41 Crystal structure of the L411A mutant of pregnane X receptor ligand binding domain (apo form) Deposited 2025-04-08 Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 682–710（29 aa）
Chain B 682–710（29 aa）
Mutation：L411A Mutation：L411A No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；50 mM Bis-Tris (pH 6-7), 9-16% (v/v) 2-methyl-2,4-pentanediol
Resolution 2.05 Å R-free 0.222
9O42 Crystal structure of the L411A mutant of pregnane X receptor ligand binding domain in complex with SJPYT-328 Deposited 2025-04-08 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 682–710（29 aa）
Chain B 682–710（29 aa）
Mutation：L411A Mutation：L411A WU2 (1P)-N-(5-tert-butyl-2-{[(3S)-hexan-3-yl]oxy}phenyl)-1-(2,4-dimethoxy-5-methylphenyl)-5-methyl-1H-1,2,3-triazole-4-carboxamide × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；50 mM Bis-Tris (pH 6-7), 9-16% (v/v) 2-methyl-2,4-pentanediol
Resolution 2.51 Å R-free 0.219
9O43 Crystal structure of the L411A mutant of pregnane X receptor ligand binding domain in complex with SJPYT-331 Deposited 2025-04-08 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 682–710（29 aa）
Chain B 682–710（29 aa）
Mutation：L411A Mutation：L411A WU6 methyl 3-{[(1P)-1-(2,5-dimethoxyphenyl)-5-methyl-1H-1,2,3-triazole-4-carbonyl]amino}-4-{[(3S)-hexan-3-yl]oxy}benzoate × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；50 mM Bis-Tris (pH 6-7), 9-16% (v/v) 2-methyl-2,4-pentanediol
Resolution 2.76 Å R-free 0.239
9O44 Crystal structure of the L411W mutant of pregnane X receptor ligand binding domain (apo form) Deposited 2025-04-08 Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 682–710（29 aa）
Chain B 682–710（29 aa）
Mutation：L411W Mutation：L411W No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；50 mM Bis-Tris (pH 6-7), 9-16% (v/v) 2-methyl-2,4-pentanediol
Resolution 2.30 Å R-free 0.228
9O45 Crystal structure of the L411W mutant of pregnane X receptor ligand binding domain in complex with SJPYT-328 Deposited 2025-04-08 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 682–710（29 aa）
Chain B 682–710（29 aa）
Mutation：L411W Mutation：L411W WU2 (1P)-N-(5-tert-butyl-2-{[(3S)-hexan-3-yl]oxy}phenyl)-1-(2,4-dimethoxy-5-methylphenyl)-5-methyl-1H-1,2,3-triazole-4-carboxamide × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；50 mM Bis-Tris (pH 6-7), 9-16% (v/v) 2-methyl-2,4-pentanediol
Resolution 2.56 Å R-free 0.241
9O46 Crystal structure of the L411W mutant of pregnane X receptor ligand binding domain in complex with SJPYT-331 Deposited 2025-04-08 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Homooligomer；Protein × 2 PDB declaration: dimeric
Chain A 682–710（29 aa）
Chain B 682–710（29 aa）
Mutation：L411W Mutation：L411W WU6 methyl 3-{[(1P)-1-(2,5-dimethoxyphenyl)-5-methyl-1H-1,2,3-triazole-4-carbonyl]amino}-4-{[(3S)-hexan-3-yl]oxy}benzoate × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；50 mM Bis-Tris (pH 6-7), 9-16% (v/v) 2-methyl-2,4-pentanediol
Resolution 3.02 Å R-free 0.232
9S70 Crystal structure of RXR alpha LBD bound to a partial agonist 21 and a coactivator fragment SRC1 Deposited 2025-08-01 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 680–700（21 aa）
Not recorded A1JL7 3-[[4-cyclobutyl-6-(3,4-dihydro-2~{H}-quinolin-1-yl)pyrimidin-2-yl]amino]propanoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；277 K；20% PEG2000, 0.1M Mes pH 6.5
Resolution 1.95 Å R-free 0.221
9S71 Crystal structure of RXR alpha LBD bound to a partial agonist 35 and a coactivator fragment SRC1 Deposited 2025-08-01 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 680–700（21 aa）
Not recorded A1JL8 3-[[4-(4,4-dimethyl-2,3-dihydroquinolin-1-yl)-6-(trifluoromethyl)pyrimidin-2-yl]amino]propanoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；277 K；18% PEG 4000 0.1 M MES pH 6.5
Resolution 2.00 Å R-free 0.222
9VBQ Crystal structure of FXR in complex with agonist XJ02862-S2 Deposited 2025-06-04 Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 744–757（14 aa） Fragment：HD3 Peptide
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION mmCIF provides none of the parsed conditions Resolution 2.30 Å R-free 0.244
9VBR Farnesoid X Receptor Agonists_FXR fused with a HD3 peptide Deposited 2025-06-04 Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain A 745–756（12 aa）
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION mmCIF provides none of the parsed conditions Resolution 2.50 Å R-free 0.251
9VBR Farnesoid X Receptor Agonists_FXR fused with a HD3 peptide Deposited 2025-06-04 Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 2 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric
Chain B 745–756（12 aa）
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION mmCIF provides none of the parsed conditions Resolution 2.50 Å R-free 0.251
9VNX Crystal Structure of the mutant ROR gamma LBD With Compound 28 Deposited 2025-07-01 Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 686–700（15 aa）
Not recorded A1MAM (2~{R})-~{N}-[5-(5-cyano-6-propan-2-yloxy-pyridin-3-yl)-1-(trifluoromethyl)pyrazol-3-yl]-1-ethanoyl-4-propan-2-ylsulfonyl-piperazine-2-carboxamide × 1 EDO 1,2-ETHANEDIOL × 3 ACT ACETATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；297 K；0.1M sodium acetate (pH 7.0), 3.5M ammonium acetate
Resolution 1.93 Å R-free 0.218
9VZQ Crystal structure of RORgamma in complex with novel inverse agonist Deposited 2025-07-23 Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric
Chain B 1429–1441（13 aa）
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION mmCIF provides none of the parsed conditions Resolution 2.18 Å R-free 0.251

204 other PDB entries and 251 assemblies. Open the comparison page and filter oligomeric states

View Construct and Data Evidence
UniProt name NCOA1_HUMAN
Isoform —
PDB entities 2
Chains and sequence ranges Author chain B； PDBConstruct 1–12； UniProt 1430–1441

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

SAXS scattering curve SAXS Profile

SAXS profile for 9gc7

P(r) Distance Distribution P(r) Distribution

P(r) distribution for 9gc7
Download Download
▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id9gc7
Deposition date deposition_date2024-08-01
Structure title titleMineralocorticoid receptor in complex with acylurea antagonists.
Keywords keywordsMINERALOCORTICOID R, Nuclear hormone receptor, steroid receptor, TRANSCRIPTION; TRANSCRIPTION
Experimental Method methodX-RAY DIFFRACTION
▼

3. SAXS Parameters (CRYSOL theoretical calculation) 3. SAXS Parameters (CRYSOL)

Radius of gyration Rg (Guinier) rg_guinier19.21 Å
Radius of gyration Rg (electron density) rg_electron18.14 Å
Forward intensity I(0) i029184300.00
Molecular weight molecular_weight28448.0 kDa
Excluded volume excluded_volume27877 ų
Envelope volume envelope_volume43545 ų
Hydration-shell volume shell_volume19785 ų
Envelope diameter envelope_diameter64.8 Å
Shell Rg shell_rg24.75 Å
Envelope Rg envelope_rg18.45 Å
Shape Rg shape_rg18.12 Å
Total Rg total_rg18.89 Å
Total atoms total_atoms2156
Residues n_residues258
Spherical-harmonic order n_harmonics20
q range q_range— – 0.5000 Å−1
Data points n_points101
Shell type shell_typedirectional
Solvent electron density solvent_density0.3340 e/ų
Shell contrast contrast_shell0.0300 e/ų
CRYSOL version crysol_version4.1.3
▼

4. P(r) Distance Distribution (GNOM inversion) 4. P(r) Analysis (GNOM)

Maximum dimension Dmax dmax72.8 Å
Rg (real space) rg_real19.10 Å
Rg uncertainty (real space) rg_real_error0.51 Å
I(0) (real space) i0_real2.9180e+07
I(0) uncertainty (real space) i0_real_error3.6940e+05
Rg (reciprocal space) rg_reciprocal19.11 Å
I(0) (reciprocal space) i0_reciprocal29180000.0000
Solution quality estimate total_estimate0.7348
Solution quality rating solution_quality REASONABLE a REASONABLE solution
P(r) peaks n_peaks3
Primary peak position r_peak_primary24.3 Å
Skewness Skewness skewness0.212
Kurtosis Kurtosis kurtosis-0.340
Angular range angular_range— – 0.4150 Å−1
Current regularization parameter α current_alpha0.0000
Highest regularization parameter α highest_alpha6920000.0000
Real-space data points n_real_points73
GNOM version gnom_version4.1.3
Quality Criteria quality_criteria AN1: 0.000; Oscil: 0.539; Stabil: 1.000; Sysdev: 1.000; Positv: 1.000; Valcen: 0.932; Smooth: 0.000
▶

5. Crystallography and Experiment 5. Crystallography & Experiment

▶

6. Entities and Polymers Entities & Polymers (6)

▶

8. Citations (1)

▶

9. Files and Curves (10)
