Heparin-binding growth factor 1
Homo sapiens
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain A； UniProt 24–153 | Fragment：Heparin-binding, UNP residues 24-153 | DBX 2,5-dihydroxybenzenesulfonic acid × 1 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；pH 7.8；295 K；Crystals of thecomplex between FGF-1 and 2,5-DHPS (2,5-dihydroxyphenylsulfonate) were grown using the sitting drop vapour method at 295 K. Equal volumes of protein and inhibitor solutions, 0.75 and 1.5mM, respectively were mixed with drops containing 60% sodium/potassium tartrate buffered with 5mM sodium phosphate [pH 7.8]. The drops were equilibrated against 0.2ml of 1.3M Li2SO4 and typical crystals grew within two weeks with approximate dimensions of 0.7 x 0.5 x 0.2 mm. , VAPOR DIFFUSION, SITTING DROP | Resolution 1.98 Å R-free 0.290 |
| 2 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain B； UniProt 24–153 | Fragment：Heparin-binding, UNP residues 24-153 | DBX 2,5-dihydroxybenzenesulfonic acid × 1 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；pH 7.8；295 K；Crystals of thecomplex between FGF-1 and 2,5-DHPS (2,5-dihydroxyphenylsulfonate) were grown using the sitting drop vapour method at 295 K. Equal volumes of protein and inhibitor solutions, 0.75 and 1.5mM, respectively were mixed with drops containing 60% sodium/potassium tartrate buffered with 5mM sodium phosphate [pH 7.8]. The drops were equilibrated against 0.2ml of 1.3M Li2SO4 and typical crystals grew within two weeks with approximate dimensions of 0.7 x 0.5 x 0.2 mm. , VAPOR DIFFUSION, SITTING DROP | Resolution 1.98 Å R-free 0.290 |
| 3 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain C； UniProt 24–153 | Fragment：Heparin-binding, UNP residues 24-153 | No other associated polymer | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；pH 7.8；295 K；Crystals of thecomplex between FGF-1 and 2,5-DHPS (2,5-dihydroxyphenylsulfonate) were grown using the sitting drop vapour method at 295 K. Equal volumes of protein and inhibitor solutions, 0.75 and 1.5mM, respectively were mixed with drops containing 60% sodium/potassium tartrate buffered with 5mM sodium phosphate [pH 7.8]. The drops were equilibrated against 0.2ml of 1.3M Li2SO4 and typical crystals grew within two weeks with approximate dimensions of 0.7 x 0.5 x 0.2 mm. , VAPOR DIFFUSION, SITTING DROP | Resolution 1.98 Å R-free 0.290 |
| 4 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain D； UniProt 24–153 | Fragment：Heparin-binding, UNP residues 24-153 | No other associated polymer | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；pH 7.8；295 K；Crystals of thecomplex between FGF-1 and 2,5-DHPS (2,5-dihydroxyphenylsulfonate) were grown using the sitting drop vapour method at 295 K. Equal volumes of protein and inhibitor solutions, 0.75 and 1.5mM, respectively were mixed with drops containing 60% sodium/potassium tartrate buffered with 5mM sodium phosphate [pH 7.8]. The drops were equilibrated against 0.2ml of 1.3M Li2SO4 and typical crystals grew within two weeks with approximate dimensions of 0.7 x 0.5 x 0.2 mm. , VAPOR DIFFUSION, SITTING DROP | Resolution 1.98 Å R-free 0.290 |
| 5 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain E； UniProt 24–153 | Fragment：Heparin-binding, UNP residues 24-153 | No other associated polymer | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；pH 7.8；295 K；Crystals of thecomplex between FGF-1 and 2,5-DHPS (2,5-dihydroxyphenylsulfonate) were grown using the sitting drop vapour method at 295 K. Equal volumes of protein and inhibitor solutions, 0.75 and 1.5mM, respectively were mixed with drops containing 60% sodium/potassium tartrate buffered with 5mM sodium phosphate [pH 7.8]. The drops were equilibrated against 0.2ml of 1.3M Li2SO4 and typical crystals grew within two weeks with approximate dimensions of 0.7 x 0.5 x 0.2 mm. , VAPOR DIFFUSION, SITTING DROP | Resolution 1.98 Å R-free 0.290 |
| 6 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain F； UniProt 24–153 | Fragment：Heparin-binding, UNP residues 24-153 | No other associated polymer | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；pH 7.8；295 K；Crystals of thecomplex between FGF-1 and 2,5-DHPS (2,5-dihydroxyphenylsulfonate) were grown using the sitting drop vapour method at 295 K. Equal volumes of protein and inhibitor solutions, 0.75 and 1.5mM, respectively were mixed with drops containing 60% sodium/potassium tartrate buffered with 5mM sodium phosphate [pH 7.8]. The drops were equilibrated against 0.2ml of 1.3M Li2SO4 and typical crystals grew within two weeks with approximate dimensions of 0.7 x 0.5 x 0.2 mm. , VAPOR DIFFUSION, SITTING DROP | Resolution 1.98 Å R-free 0.290 |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 3K1X | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 1AXM HEPARIN-LINKED BIOLOGICALLY-ACTIVE DIMER OF FIBROBLAST GROWTH FACTOR Deposited 1997-10-16 | Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–155（135 aa）
Chain B
21–155（135 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) Non-standard monomer：Yes (specific site not provided by mmCIF) | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7；PROTEIN/HEPARIN COMPLEX WAS CRYSTALLIZED FROM 25% PEG 8000, 200 MM MGSO4, 100 MM HEPES, PH 7.0; CRYSTAL WAS SOAKED IN 22% XYLITOL PRIOR TO DATA COLLECTION.
|
Resolution 3.00 Å R-free 0.304 |
| 1AXM HEPARIN-LINKED BIOLOGICALLY-ACTIVE DIMER OF FIBROBLAST GROWTH FACTOR Deposited 1997-10-16 | Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain D
21–155（135 aa）
Chain F
21–155（135 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) Non-standard monomer：Yes (specific site not provided by mmCIF) | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7；PROTEIN/HEPARIN COMPLEX WAS CRYSTALLIZED FROM 25% PEG 8000, 200 MM MGSO4, 100 MM HEPES, PH 7.0; CRYSTAL WAS SOAKED IN 22% XYLITOL PRIOR TO DATA COLLECTION.
|
Resolution 3.00 Å R-free 0.304 |
| 1AXM HEPARIN-LINKED BIOLOGICALLY-ACTIVE DIMER OF FIBROBLAST GROWTH FACTOR Deposited 1997-10-16 | Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 3 Other combination Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain C
21–155（135 aa）
Chain E
21–155（135 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) Non-standard monomer：Yes (specific site not provided by mmCIF) | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7；PROTEIN/HEPARIN COMPLEX WAS CRYSTALLIZED FROM 25% PEG 8000, 200 MM MGSO4, 100 MM HEPES, PH 7.0; CRYSTAL WAS SOAKED IN 22% XYLITOL PRIOR TO DATA COLLECTION.
|
Resolution 3.00 Å R-free 0.304 |
| 1DJS LIGAND-BINDING PORTION OF FIBROBLAST GROWTH FACTOR RECEPTOR 2 IN COMPLEX WITH FGF1 Deposited 1999-12-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain B
21–155（135 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 18 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；1.6M AMMONIUM SULFATE, 10MM TRIS (PH7.5), pH 7.50
|
Resolution 2.40 Å R-free 0.315 |
| 1DJS LIGAND-BINDING PORTION OF FIBROBLAST GROWTH FACTOR RECEPTOR 2 IN COMPLEX WITH FGF1 Deposited 1999-12-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 8 PDB declaration: octameric |
Chain B
21–155（135 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | SO4 SULFATE ION × 36 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；1.6M AMMONIUM SULFATE, 10MM TRIS (PH7.5), pH 7.50
|
Resolution 2.40 Å R-free 0.315 |
| 1DZC High resolution structure of acidic fibroblast growth factor. Mutant FGF-4-ALA-(24-154), 24 NMR structures Deposited 2000-02-24 | Different construct Different mutation/modification Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
25–155（131 aa）
Fragment：RESIDUES 25-155
|
Mutation：YES | No recorded non-water small molecule |
SOLUTION NMR
NMR measurement conditions
pH 6；298 K；Pressure 1
NMR sample composition
WATER
|
Resolution not provided |
| 1DZD High resolution structure of acidic fibroblast growth factor (27-154), 24 NMR structures Deposited 2000-02-24 | Different construct Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
29–155（127 aa）
Fragment：RESIDUES 27-154
|
Not recorded | No recorded non-water small molecule |
SOLUTION NMR
NMR measurement conditions
pH 6；298 K；Pressure 1
NMR sample composition
WATER
|
Resolution not provided |
| 1E0O CRYSTAL STRUCTURE OF A TERNARY FGF1-FGFR2-HEPARIN COMPLEX Deposited 2000-04-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 4 PDB declaration: pentameric |
Chain A
16–155（140 aa）
Chain C
16–155（140 aa）
|
Not recorded | NI NICKEL (II) ION × 5 SO4 SULFATE ION × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；CRYSTALS WERE GROWN FROM: 1.0M LI2SO4, 0.1M TRISCL PH=8.5, 10MM NISO4, pH 8.50
|
Resolution 2.80 Å R-free 0.309 |
| 1EVT CRYSTAL STRUCTURE OF FGF1 IN COMPLEX WITH THE EXTRACELLULAR LIGAND BINDING DOMAIN OF FGF RECEPTOR 1 (FGFR1) Deposited 2000-04-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
22–155（134 aa）
Fragment：THE B-TREFOIL CORE OF FIBROBLAST GROWTH FACTOR 1 (FGF1)
Chain B
22–155（134 aa）
Fragment：THE B-TREFOIL CORE OF FIBROBLAST GROWTH FACTOR 1 (FGF1)
|
Not recorded | SO4 SULFATE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.5；298 K；PEG 4000, Isopropanol, HEPES-NaOH, pH 7.5, VAPOR DIFFUSION, temperature 298.0K
|
Resolution 2.80 Å R-free 0.300 |
| 1HKN A complex between acidic fibroblast growth factor and 5-amino-2-naphthalenesulfonate Deposited 2003-03-10 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
17–155（139 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.8；CRYSTALS OF THE COMPLEX BETWEEN AFGF AND 5-AMINO-2-NMS WERE GROWN BY MIXING 0.75 MM PROTEIN, 1.5 MM OF THE INHIBITOR AND 60% SODIUM/PO, pH 7.80
|
Resolution 2.00 Å R-free 0.259 |
| 1HKN A complex between acidic fibroblast growth factor and 5-amino-2-naphthalenesulfonate Deposited 2003-03-10 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
17–155（139 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.8；CRYSTALS OF THE COMPLEX BETWEEN AFGF AND 5-AMINO-2-NMS WERE GROWN BY MIXING 0.75 MM PROTEIN, 1.5 MM OF THE INHIBITOR AND 60% SODIUM/PO, pH 7.80
|
Resolution 2.00 Å R-free 0.259 |
| 1HKN A complex between acidic fibroblast growth factor and 5-amino-2-naphthalenesulfonate Deposited 2003-03-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
17–155（139 aa）
|
Not recorded | N2M 5-AMINO-NAPHTALENE-2-MONOSULFONATE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.8；CRYSTALS OF THE COMPLEX BETWEEN AFGF AND 5-AMINO-2-NMS WERE GROWN BY MIXING 0.75 MM PROTEIN, 1.5 MM OF THE INHIBITOR AND 60% SODIUM/PO, pH 7.80
|
Resolution 2.00 Å R-free 0.259 |
| 1HKN A complex between acidic fibroblast growth factor and 5-amino-2-naphthalenesulfonate Deposited 2003-03-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
17–155（139 aa）
|
Not recorded | N2M 5-AMINO-NAPHTALENE-2-MONOSULFONATE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.8；CRYSTALS OF THE COMPLEX BETWEEN AFGF AND 5-AMINO-2-NMS WERE GROWN BY MIXING 0.75 MM PROTEIN, 1.5 MM OF THE INHIBITOR AND 60% SODIUM/PO, pH 7.80
|
Resolution 2.00 Å R-free 0.259 |
| 1HKN A complex between acidic fibroblast growth factor and 5-amino-2-naphthalenesulfonate Deposited 2003-03-10 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 5 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain E
17–155（139 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.8；CRYSTALS OF THE COMPLEX BETWEEN AFGF AND 5-AMINO-2-NMS WERE GROWN BY MIXING 0.75 MM PROTEIN, 1.5 MM OF THE INHIBITOR AND 60% SODIUM/PO, pH 7.80
|
Resolution 2.00 Å R-free 0.259 |
| 1HKN A complex between acidic fibroblast growth factor and 5-amino-2-naphthalenesulfonate Deposited 2003-03-10 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 6 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain F
17–155（139 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.8；CRYSTALS OF THE COMPLEX BETWEEN AFGF AND 5-AMINO-2-NMS WERE GROWN BY MIXING 0.75 MM PROTEIN, 1.5 MM OF THE INHIBITOR AND 60% SODIUM/PO, pH 7.80
|
Resolution 2.00 Å R-free 0.259 |
| 1JQZ Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag. Deposited 2001-08-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Not recorded | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.8；283 K；sodium formate, ammonium sulfate, pH 5.8, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.65 Å |
| 1JQZ Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag. Deposited 2001-08-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Not recorded | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.8；283 K；sodium formate, ammonium sulfate, pH 5.8, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.65 Å |
| 1JT3 Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Histidine Tag AND LEU 73 REPLACED BY VAL (L73V) Deposited 2001-08-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：L73V | SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；283 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.95 Å |
| 1JT3 Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Histidine Tag AND LEU 73 REPLACED BY VAL (L73V) Deposited 2001-08-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：L73V | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；283 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.95 Å |
| 1JT3 Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Histidine Tag AND LEU 73 REPLACED BY VAL (L73V) Deposited 2001-08-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
16–155（140 aa）
Chain B
16–155（140 aa）
|
Mutation：L73V Mutation：L73V | SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；283 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.95 Å |
| 1JT3 Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Histidine Tag AND LEU 73 REPLACED BY VAL (L73V) Deposited 2001-08-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
16–155（140 aa）
Chain B
16–155（140 aa）
|
Mutation：L73V Mutation：L73V | SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；283 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.95 Å |
| 1JT4 Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag AND VAL 109 REPLACED BY LEU (V109L) Deposited 2001-08-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：V109L | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.78 Å |
| 1JT4 Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag AND VAL 109 REPLACED BY LEU (V109L) Deposited 2001-08-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：V109L | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.78 Å |
| 1JT5 Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag AND LEU 73 REPLACED BY VAL AND VAL 109 REPLACED BY LEU (L73V/V109L) Deposited 2001-08-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：L73V,V109L | SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；283 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.85 Å |
| 1JT5 Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag AND LEU 73 REPLACED BY VAL AND VAL 109 REPLACED BY LEU (L73V/V109L) Deposited 2001-08-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：L73V,V109L | SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；283 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.85 Å |
| 1JT5 Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag AND LEU 73 REPLACED BY VAL AND VAL 109 REPLACED BY LEU (L73V/V109L) Deposited 2001-08-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
16–155（140 aa）
Chain B
16–155（140 aa）
|
Mutation：L73V,V109L Mutation：L73V,V109L | SO4 SULFATE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；283 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.85 Å |
| 1JT5 Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag AND LEU 73 REPLACED BY VAL AND VAL 109 REPLACED BY LEU (L73V/V109L) Deposited 2001-08-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
16–155（140 aa）
Chain B
16–155（140 aa）
|
Mutation：L73V,V109L Mutation：L73V,V109L | SO4 SULFATE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；283 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.85 Å |
| 1JT7 Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag AND LEU 44 REPLACED BY PHE AND LEU 73 REPLACED BY VAL AND VAL 109 REPLACED BY LEU (L44F/L73V/V109L) Deposited 2001-08-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：L44F,L73V,V109L | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；283 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.70 Å |
| 1JT7 Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag AND LEU 44 REPLACED BY PHE AND LEU 73 REPLACED BY VAL AND VAL 109 REPLACED BY LEU (L44F/L73V/V109L) Deposited 2001-08-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：L44F,L73V,V109L | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；283 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.70 Å |
| 1JT7 Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag AND LEU 44 REPLACED BY PHE AND LEU 73 REPLACED BY VAL AND VAL 109 REPLACED BY LEU (L44F/L73V/V109L) Deposited 2001-08-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
16–155（140 aa）
|
Mutation：L44F,L73V,V109L | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；283 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.70 Å |
| 1JT7 Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag AND LEU 44 REPLACED BY PHE AND LEU 73 REPLACED BY VAL AND VAL 109 REPLACED BY LEU (L44F/L73V/V109L) Deposited 2001-08-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
16–155（140 aa）
|
Mutation：L44F,L73V,V109L | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；283 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 283K
|
Resolution 1.70 Å |
| 1JTC Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag AND LEU 44 REPLACED BY PHE (L44F) Deposited 2001-08-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：L44F | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.70 Å |
| 1JTC Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag AND LEU 44 REPLACED BY PHE (L44F) Deposited 2001-08-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：L44F | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.70 Å |
| 1JTC Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag AND LEU 44 REPLACED BY PHE (L44F) Deposited 2001-08-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
16–155（140 aa）
|
Mutation：L44F | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.70 Å |
| 1JTC Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag AND LEU 44 REPLACED BY PHE (L44F) Deposited 2001-08-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
16–155（140 aa）
|
Mutation：L44F | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.70 Å |
| 1JY0 Human acidic fibroblast growth factor. 141 amino acid form with amino terminal His tag and Cys 117 replaced with Val (C117V). Deposited 2001-09-10 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：C117V | FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.70 Å |
| 1JY0 Human acidic fibroblast growth factor. 141 amino acid form with amino terminal His tag and Cys 117 replaced with Val (C117V). Deposited 2001-09-10 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：C117V | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.70 Å |
| 1K5U Human acidic fibroblast growth factor. 141 amino acid form with amino terminal His tag with His93 replaced by Gly (H93G). Deposited 2001-10-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–154（139 aa）
|
Mutation：H93G | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；PEG 4,000, 2-propanol, magnesium chloride, hepes., pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.00 Å R-free 0.293 |
| 1K5U Human acidic fibroblast growth factor. 141 amino acid form with amino terminal His tag with His93 replaced by Gly (H93G). Deposited 2001-10-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–154（139 aa）
|
Mutation：H93G | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；PEG 4,000, 2-propanol, magnesium chloride, hepes., pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.00 Å R-free 0.293 |
| 1K5U Human acidic fibroblast growth factor. 141 amino acid form with amino terminal His tag with His93 replaced by Gly (H93G). Deposited 2001-10-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
16–154（139 aa）
|
Mutation：H93G | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；PEG 4,000, 2-propanol, magnesium chloride, hepes., pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.00 Å R-free 0.293 |
| 1K5V Human acidic fibroblast growth factor. 141 amino acid form with amino terminal His tag with Asn106 replaced by Gly (N106G). Deposited 2001-10-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–154（139 aa）
|
Mutation：N106G | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；298.15 K；PEG20,000, MES, pH 6.0, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.10 Å R-free 0.308 |
| 1K5V Human acidic fibroblast growth factor. 141 amino acid form with amino terminal His tag with Asn106 replaced by Gly (N106G). Deposited 2001-10-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–154（139 aa）
|
Mutation：N106G | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；298.15 K；PEG20,000, MES, pH 6.0, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.10 Å R-free 0.308 |
| 1M16 Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag and Leu 44 Replaced with Phe (L44F), Leu 73 Replaced with Val (L73V), Val 109 Replaced with Leu (V109L) and Cys 117 Replaced with Val (C117V). Deposited 2002-06-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：L44F, L73V, V109L, C117V | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.70 Å R-free 0.249 |
| 1M16 Human Acidic Fibroblast Growth Factor. 141 Amino Acid Form with Amino Terminal His Tag and Leu 44 Replaced with Phe (L44F), Leu 73 Replaced with Val (L73V), Val 109 Replaced with Leu (V109L) and Cys 117 Replaced with Val (C117V). Deposited 2002-06-17 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：L44F, L73V, V109L, C117V | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.70 Å R-free 0.249 |
| 1NZK Crystal Structure of a Multiple Mutant (L44F, L73V, V109L, L111I, C117V) of Human Acidic Fibroblast Growth Factor Deposited 2003-02-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–152（137 aa）
|
Mutation：L44F, L73V, V109L, L111I, C117V | SO4 SULFATE ION × 1 FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Sodium Formate, Ammonium Sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.95 Å R-free 0.253 |
| 1NZK Crystal Structure of a Multiple Mutant (L44F, L73V, V109L, L111I, C117V) of Human Acidic Fibroblast Growth Factor Deposited 2003-02-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–152（137 aa）
|
Mutation：L44F, L73V, V109L, L111I, C117V | SO4 SULFATE ION × 1 FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Sodium Formate, Ammonium Sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.95 Å R-free 0.253 |
| 1NZK Crystal Structure of a Multiple Mutant (L44F, L73V, V109L, L111I, C117V) of Human Acidic Fibroblast Growth Factor Deposited 2003-02-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
16–152（137 aa）
|
Mutation：L44F, L73V, V109L, L111I, C117V | SO4 SULFATE ION × 1 FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Sodium Formate, Ammonium Sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.95 Å R-free 0.253 |
| 1NZK Crystal Structure of a Multiple Mutant (L44F, L73V, V109L, L111I, C117V) of Human Acidic Fibroblast Growth Factor Deposited 2003-02-18 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
16–152（137 aa）
|
Mutation：L44F, L73V, V109L, L111I, C117V | SO4 SULFATE ION × 1 FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Sodium Formate, Ammonium Sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.95 Å R-free 0.253 |
| 1P63 Human Acidic Fibroblast Growth Factor. 140 Amino Acid Form with Amino Terminal His Tag and Leu111 Replaced with Ile (L111I) Deposited 2003-04-28 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
Fragment：140 Amino Acid Form with Amino Terminal His Tag
|
Mutation：L111I | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；Sodium Formate, Ammonium Sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.60 Å R-free 0.251 |
| 1P63 Human Acidic Fibroblast Growth Factor. 140 Amino Acid Form with Amino Terminal His Tag and Leu111 Replaced with Ile (L111I) Deposited 2003-04-28 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
Fragment：140 Amino Acid Form with Amino Terminal His Tag
|
Mutation：L111I | FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；Sodium Formate, Ammonium Sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.60 Å R-free 0.251 |
| 1PZZ Crystal structure of FGF-1, V51N mutant Deposited 2003-07-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：V51N | SO4 SULFATE ION × 2 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.00 Å R-free 0.227 |
| 1PZZ Crystal structure of FGF-1, V51N mutant Deposited 2003-07-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：V51N | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.00 Å R-free 0.227 |
| 1Q03 Crystal structure of FGF-1, S50G/V51G mutant Deposited 2003-07-15 | Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：S50G, V51G | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.05 Å R-free 0.227 |
| 1Q03 Crystal structure of FGF-1, S50G/V51G mutant Deposited 2003-07-15 | Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：S50G, V51G | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.05 Å R-free 0.227 |
| 1Q04 Crystal structure of FGF-1, S50E/V51N Deposited 2003-07-15 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：S50E/V51N | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.80 Å R-free 0.214 |
| 1Q04 Crystal structure of FGF-1, S50E/V51N Deposited 2003-07-15 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：S50E/V51N | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.80 Å R-free 0.214 |
| 1QQL THE CRYSTAL STRUCTURE OF FIBROBLAST GROWTH FACTOR 7/1 CHIMERA Deposited 1999-06-07 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
92–155（64 aa）
Fragment：;DUAL-FUNCTION CHIMERA BETWEEN RAT FGF-7 ENCODED BY EXON 1 AND 2 AND HUMAN FGF-1 ENCODED BY EXON 3,DUAL-FUNCTION CHIMERA BETWEEN RAT FGF-7 ENCODED BY EXON 1 AND 2 AND HUMAN FGF-1 ENCODED BY EXON 3
;
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；298 K；SODIUM PHOSPHATE, POTASSIUM PHOSPHATE, SODIUM SULPHATE, pH 7.0, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 2.30 Å R-free 0.328 |
| 1RG8 Human Acidic Fibroblast Growth Factor (haFGF-1) at 1.10 angstrom resolution (140 amino acid form) Deposited 2003-11-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Not recorded | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.8；298 K；sodium phosphate, sodium chloride, ammonium sulfate, DTT, EDTA, sodium formate, pH 5.8, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.10 Å R-free 0.171 |
| 1RG8 Human Acidic Fibroblast Growth Factor (haFGF-1) at 1.10 angstrom resolution (140 amino acid form) Deposited 2003-11-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Not recorded | FMT FORMIC ACID × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.8；298 K；sodium phosphate, sodium chloride, ammonium sulfate, DTT, EDTA, sodium formate, pH 5.8, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.10 Å R-free 0.171 |
| 1RML NMR STUDY OF ACID FIBROBLAST GROWTH FACTOR BOUND TO 1,3,6-NAPHTHALENE TRISULPHONATE, 26 STRUCTURES Deposited 1998-05-21 | Different construct Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–155（155 aa）
Fragment：RESIDUES 23 - 154
|
Not recorded | NTS NAPHTHALENE TRISULFONATE × 1 |
SOLUTION NMR
NMR measurement conditions
pH 6；298 K
NMR sample composition
WATER
|
Resolution not provided |
| 1RY7 Crystal Structure of the 3 Ig form of FGFR3c in complex with FGF1 Deposited 2003-12-19 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–155（155 aa）
Fragment：FGF1
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；Peg 4000, glycerol, MPD, cadmium chloride, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 3.20 Å R-free 0.341 |
| 1YTO Crystal Structure of Gly19 deletion Mutant of Human Acidic Fibroblast Growth Factor Deposited 2005-02-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Not recorded | SO4 SULFATE ION × 2 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.10 Å R-free 0.250 |
| 1YTO Crystal Structure of Gly19 deletion Mutant of Human Acidic Fibroblast Growth Factor Deposited 2005-02-10 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.10 Å R-free 0.250 |
| 1YTO Crystal Structure of Gly19 deletion Mutant of Human Acidic Fibroblast Growth Factor Deposited 2005-02-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
16–155（140 aa）
|
Not recorded | FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.10 Å R-free 0.250 |
| 1YTO Crystal Structure of Gly19 deletion Mutant of Human Acidic Fibroblast Growth Factor Deposited 2005-02-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
16–155（140 aa）
|
Not recorded | SO4 SULFATE ION × 2 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；sodium formate, ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.10 Å R-free 0.250 |
| 1Z2V Crystal Structure of Glu60 deletion Mutant of Human Acidic Fibroblast Growth Factor Deposited 2005-03-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Not recorded | SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；PEG400, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.90 Å R-free 0.221 |
| 1Z2V Crystal Structure of Glu60 deletion Mutant of Human Acidic Fibroblast Growth Factor Deposited 2005-03-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Not recorded | SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；PEG400, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.90 Å R-free 0.221 |
| 1Z4S Crystal Structure of Gly19 and Glu60 deletion mutant of Human Acidic Fibroblast Growth Factor Deposited 2005-03-16 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.60 Å R-free 0.235 |
| 1Z4S Crystal Structure of Gly19 and Glu60 deletion mutant of Human Acidic Fibroblast Growth Factor Deposited 2005-03-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Not recorded | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.60 Å R-free 0.235 |
| 1Z4S Crystal Structure of Gly19 and Glu60 deletion mutant of Human Acidic Fibroblast Growth Factor Deposited 2005-03-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
16–155（140 aa）
|
Not recorded | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.60 Å R-free 0.235 |
| 1Z4S Crystal Structure of Gly19 and Glu60 deletion mutant of Human Acidic Fibroblast Growth Factor Deposited 2005-03-16 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
16–155（140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.60 Å R-free 0.235 |
| 2AFG 2.0 ANGSTROM X-RAY STRUCTURE OF HUMAN ACIDIC FIBROBLAST GROWTH FACTOR Deposited 1995-07-21 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Not recorded | SO4 SULFATE ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å |
| 2AFG 2.0 ANGSTROM X-RAY STRUCTURE OF HUMAN ACIDIC FIBROBLAST GROWTH FACTOR Deposited 1995-07-21 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Not recorded | SO4 SULFATE ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å |
| 2AFG 2.0 ANGSTROM X-RAY STRUCTURE OF HUMAN ACIDIC FIBROBLAST GROWTH FACTOR Deposited 1995-07-21 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
16–155（140 aa）
|
Not recorded | SO4 SULFATE ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å |
| 2AFG 2.0 ANGSTROM X-RAY STRUCTURE OF HUMAN ACIDIC FIBROBLAST GROWTH FACTOR Deposited 1995-07-21 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
16–155（140 aa）
|
Not recorded | SO4 SULFATE ION × 1 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å |
| 2AQZ Crystal structure of FGF-1, S17T/N18T/G19 deletion mutant Deposited 2005-08-18 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.85 Å R-free 0.226 |
| 2AQZ Crystal structure of FGF-1, S17T/N18T/G19 deletion mutant Deposited 2005-08-18 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Not recorded | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.85 Å R-free 0.226 |
| 2AXM HEPARIN-LINKED BIOLOGICALLY-ACTIVE DIMER OF FIBROBLAST GROWTH FACTOR Deposited 1997-10-20 | Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
21–155（135 aa）
Chain B
21–155（135 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7；PROTEIN/HEPARIN COMPLEX WAS CRYSTALLIZED FROM 25% PEG 8000, 200 MM MGSO4, 100 MM HEPES, PH 7.0; CRYSTAL WAS SOAKED IN 22% XYLITOL PRIOR TO DATA COLLECTION.
|
Resolution 3.00 Å R-free 0.307 |
| 2ERM Solution structure of a biologically active human FGF-1 monomer, complexed to a hexasaccharide heparin-analogue Deposited 2005-10-25 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
17–155（139 aa）
|
Not recorded | IPA ISOPROPYL ALCOHOL × 1 |
SOLUTION NMR
NMR measurement conditions
pH 6；298 K；Ionic strength (raw mmCIF value) 150 mM NaCl；Pressure ambient
NMR sample composition
1 mM FGF-1 U-15N; 1 mM heparin-like hexasaccharide; 10mM sodium phosphate; 150 mM sodium chloride; 90% H2O, 10% D2O | 90% H2O/10% D2O
NMR sample composition
1 mM FGF-1 U-15N,13C; 1 mM heparin-like hexasaccharide; 10mM sodium phosphate; 150 mM sodium chloride; 90% H2O, 10% D2O | 90% H2O/10% D2O
|
Resolution not provided |
| 2HW9 Crystal structure of Lys12Cys/Cys117Val mutant of human acidic fibroblast Growth factor at 1.60 angstrom resolution. Deposited 2006-08-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：K12C,C117V | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Ammonium Sulfate, Sodium Formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.60 Å R-free 0.221 |
| 2HW9 Crystal structure of Lys12Cys/Cys117Val mutant of human acidic fibroblast Growth factor at 1.60 angstrom resolution. Deposited 2006-08-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：K12C,C117V | SO4 SULFATE ION × 1 FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Ammonium Sulfate, Sodium Formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.60 Å R-free 0.221 |
| 2HWA Crystal structure of Lys12Thr/Cys117Val mutant of human acidic fibroblast growth factor at 1.65 angstrom resolution. Deposited 2006-08-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：K12T,C117V | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Ammonium Sulfate, Sodium Formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.65 Å R-free 0.258 |
| 2HWA Crystal structure of Lys12Thr/Cys117Val mutant of human acidic fibroblast growth factor at 1.65 angstrom resolution. Deposited 2006-08-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：K12T,C117V | SO4 SULFATE ION × 1 FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Ammonium Sulfate, Sodium Formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.65 Å R-free 0.258 |
| 2HWM Crystal structure of Lys12Val/Cys117Val mutant of human acidic fibroblast growth factor at 1.60 angstrom resolution Deposited 2006-08-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：K12V, C117V | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Ammonium Sulfate, Sodium Formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.60 Å R-free 0.225 |
| 2HWM Crystal structure of Lys12Val/Cys117Val mutant of human acidic fibroblast growth factor at 1.60 angstrom resolution Deposited 2006-08-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：K12V, C117V | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Ammonium Sulfate, Sodium Formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.60 Å R-free 0.225 |
| 2HZ9 Crystal structure of Lys12Val/Asn95Val/Cys117Val mutant of human acidic fibroblast growth factor at 1.70 angstrom resolution. Deposited 2006-08-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：Lys12Val, Asn95Val, Cys117Val | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Ammonium Sulfate, Sodium Formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.70 Å R-free 0.226 |
| 2HZ9 Crystal structure of Lys12Val/Asn95Val/Cys117Val mutant of human acidic fibroblast growth factor at 1.70 angstrom resolution. Deposited 2006-08-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：Lys12Val, Asn95Val, Cys117Val | FMT FORMIC ACID × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；Ammonium Sulfate, Sodium Formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.70 Å R-free 0.226 |
| 2K43 Acidic fibroblast growth factor solution structure in the FGF-1-C2A binary complex: key component in the fibroblast growthfactor non-classical pathway Deposited 2008-05-28 | Different construct Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
23–155（133 aa）
Fragment：UNP residues 23-155
|
Not recorded | No recorded non-water small molecule |
SOLUTION NMR
NMR measurement conditions
pH 6；298 K；Ionic strength (raw mmCIF value) 50mM (NH4)2SO4；Pressure ambient
NMR sample composition
1.0mM FGF-1, 90% H2O, 10% D2O | 90% H2O/10% D2O
|
Resolution not provided |
| 2K4A FGF-1-C2A binary complex structure: a key component in the fibroblast growthfactor non-classical pathway Deposited 2008-06-02 | Different construct Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
23–155（133 aa）
Fragment：UNP residues 23-155
|
Not recorded | No recorded non-water small molecule |
SOLUTION NMR
NMR measurement conditions
pH 6；298 K；Ionic strength (raw mmCIF value) 50mM (NH4)2SO4；Pressure ambient
NMR sample composition
1.2mM FGF-1-C2A; 100% D2O | 100% D2O
|
Resolution not provided |
| 2K8R Solution structure of human acidic fibroblast growth factor in complex with anti-angiogenic drug inositol hexaphosphate (IP6) Deposited 2008-09-22 | Different construct Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
23–155（133 aa）
Fragment：UNP residues 23-155
|
Not recorded | IHP INOSITOL HEXAKISPHOSPHATE × 1 |
SOLUTION NMR
NMR measurement conditions
pH 6.8；298 K；Ionic strength (raw mmCIF value) 0.1；Pressure ambient
NMR sample composition
1.5 mM [U-100% 13C; U-100% 15N] protein, 1.5 mM INOSITOL HEXAKISPHOSPHATE, 100 mM ammonium sulfate, 25 mM sodium phosphate, 90% H2O/10% D2O | 90% H2O/10% D2O
|
Resolution not provided |
| 2KI4 FGF1-S100A13 complex structure: key component in non-classical path way of FGF1 Deposited 2009-04-27 | Different construct Different mutation/modification Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
23–155（133 aa）
Chain D
23–155（133 aa）
|
Not recorded | No recorded non-water small molecule |
SOLUTION NMR
NMR measurement conditions
pH 6；298 K；Ionic strength (raw mmCIF value) 0.1；Pressure ambient
NMR sample composition
1.2 mM [U-100% 13C; U-100% 15N] entity_1-1, 1.2 mM [U-100% 13C; U-100% 15N] entity_2-2, entity_3-3, 90% H2O/10% D2O | 90% H2O/10% D2O
|
Resolution not provided |
| 2KI6 The FGF1-S100A13-C2A hetero-hexameric complex structure: A component in the non-classical pathway for FGF1 secretion Deposited 2009-04-28 | Different construct Different mutation/modification Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain B
23–155（133 aa）
Chain E
23–155（133 aa）
|
Not recorded | No recorded non-water small molecule |
SOLUTION NMR
NMR measurement conditions
pH 6；298 K；Ionic strength (raw mmCIF value) 0.1；Pressure ambient
NMR sample composition
1.0mM [U-100% 13C; U-100% 15N] C2A domain of Syt1-1, 1.0mM FGF1-2, 1.0mM S100A13-3, S100A13-4, 25mM sodium phosphate-5, 100mM sodium chloride-6, 90% H2O/10% D2O | 90% H2O/10% D2O
|
Resolution not provided |
| 2NTD Human fibroblast growth factor-1 (140 amino acid form) with Cys117Val/Pro134Cys mutations Deposited 2006-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：C117V, P134C | FMT FORMIC ACID × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.6M sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.52 Å R-free 0.229 |
| 2NTD Human fibroblast growth factor-1 (140 amino acid form) with Cys117Val/Pro134Cys mutations Deposited 2006-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：C117V, P134C | FMT FORMIC ACID × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.6M sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.52 Å R-free 0.229 |
| 2NTD Human fibroblast growth factor-1 (140 amino acid form) with Cys117Val/Pro134Cys mutations Deposited 2006-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
16–155（140 aa）
|
Mutation：C117V, P134C | FMT FORMIC ACID × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.6M sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.52 Å R-free 0.229 |
| 2NTD Human fibroblast growth factor-1 (140 amino acid form) with Cys117Val/Pro134Cys mutations Deposited 2006-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
16–155（140 aa）
|
Mutation：C117V, P134C | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.6M sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.52 Å R-free 0.229 |
| 2Q9X Crystal structure of highly stable mutant Q40P/S47I/H93G of human fibroblast growth factor-1 Deposited 2007-06-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：Q40P, S47I, H93G | GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；15% PEG 8000, 100mM TrisHCl, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.70 Å R-free 0.245 |
| 2RQ9 Solution structure of human acidic fibroblast growth factor (aFGF) in the presence of a protein stabilizer NDSB-new Deposited 2009-03-12 | Different construct Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–155（134 aa）
Fragment：residues in UNP, 22-155
|
Not recorded | No recorded non-water small molecule |
SOLUTION NMR
NMR measurement conditions
pH 6.6；298 K；Ionic strength (raw mmCIF value) 190；Pressure ambient
NMR sample composition
1.0mM [U-99% 13C; U-99% 15N] aFGF-1, 500mM NDSB-new-2, 25mM sodium phosphate-3, 150mM NaCl-4, 1mM dioxane-5, 90% H2O/10% D2O | 90% H2O/10% D2O
|
Resolution not provided |
| 3B9U Crystal structure of L26N/D28N/H93G mutant of Human acidic fibroblast growth factor Deposited 2007-11-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：L26N, D28N, H93G | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；PEG4000, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.55 Å R-free 0.200 |
| 3BA4 Crystal structure of L26D mutant of Human acidic fibroblast growth factor Deposited 2007-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：L26D | SO4 SULFATE ION × 2 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；2.9M Na-formate, 0.7M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.80 Å R-free 0.219 |
| 3BA4 Crystal structure of L26D mutant of Human acidic fibroblast growth factor Deposited 2007-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：L26D | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；2.9M Na-formate, 0.7M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.80 Å R-free 0.219 |
| 3BA5 Crystal structure of D28A mutant of Human acidic fibroblast growth factor Deposited 2007-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：D28A | SO4 SULFATE ION × 1 FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；4.6M Na-formate, 0.3M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.75 Å R-free 0.232 |
| 3BA5 Crystal structure of D28A mutant of Human acidic fibroblast growth factor Deposited 2007-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：D28A | FMT FORMIC ACID × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；4.6M Na-formate, 0.3M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.75 Å R-free 0.232 |
| 3BA7 Crystal structure of L26N/D28A mutant of Human acidic fibroblast growth factor Deposited 2007-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：L26N, D28A | SO4 SULFATE ION × 1 FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；3.0M Na-formate, 0.5M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.60 Å R-free 0.225 |
| 3BA7 Crystal structure of L26N/D28A mutant of Human acidic fibroblast growth factor Deposited 2007-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：L26N, D28A | SO4 SULFATE ION × 1 FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；3.0M Na-formate, 0.5M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.60 Å R-free 0.225 |
| 3BAD Crystal structure of D70A/H93G mutant of Human acidic fibroblast growth factor Deposited 2007-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：D70A, H93G | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 9.5；298.15 K；25% PEG4000, 0.1M Bicine, pH 9.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.00 Å R-free 0.253 |
| 3BAD Crystal structure of D70A/H93G mutant of Human acidic fibroblast growth factor Deposited 2007-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：D70A, H93G | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 9.5；298.15 K；25% PEG4000, 0.1M Bicine, pH 9.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 2.00 Å R-free 0.253 |
| 3BAG Crystal structure of K112N/N114A mutant of Human acidic fibroblast growth factor Deposited 2007-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：K112N, N114A | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；3.8M Na-formate, 0.2M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.75 Å R-free 0.224 |
| 3BAG Crystal structure of K112N/N114A mutant of Human acidic fibroblast growth factor Deposited 2007-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：K112N, N114A | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；3.8M Na-formate, 0.2M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.75 Å R-free 0.224 |
| 3BAH Crystal structure of K112N mutant of Human acidic fibroblast growth factor Deposited 2007-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：K112N | FMT FORMIC ACID × 6 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；2.9M Na-formate, 1.0M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.65 Å R-free 0.205 |
| 3BAH Crystal structure of K112N mutant of Human acidic fibroblast growth factor Deposited 2007-11-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：K112N | FMT FORMIC ACID × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；2.9M Na-formate, 1.0M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.65 Å R-free 0.205 |
| 3BAO Crystal structure of L26N mutant of Human acidic fibroblast growth factor Deposited 2007-11-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：L26N | SO4 SULFATE ION × 1 FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；3.3M Na-formate, 0.7M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.55 Å R-free 0.211 |
| 3BAO Crystal structure of L26N mutant of Human acidic fibroblast growth factor Deposited 2007-11-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：L26N | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；3.3M Na-formate, 0.7M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.55 Å R-free 0.211 |
| 3BAQ Crystal structure of L26A mutant of Human acidic fibroblast growth factor Deposited 2007-11-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：L26A | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；3.3M Na-formate, 0.4M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.80 Å R-free 0.216 |
| 3BAQ Crystal structure of L26A mutant of Human acidic fibroblast growth factor Deposited 2007-11-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：L26A | FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；3.3M Na-formate, 0.4M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.80 Å R-free 0.216 |
| 3BAU Crystal structure of K12V/L26D/D28A mutant of Human acidic fibroblast growth factor Deposited 2007-11-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：K12V, L26D, D28A | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；2.7M Na-formate, 0.7M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.60 Å R-free 0.233 |
| 3BAU Crystal structure of K12V/L26D/D28A mutant of Human acidic fibroblast growth factor Deposited 2007-11-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：K12V, L26D, D28A | SO4 SULFATE ION × 1 FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；2.7M Na-formate, 0.7M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.60 Å R-free 0.233 |
| 3BAV Crystal structure of L26A/D28N mutant of Human acidic fibroblast growth factor Deposited 2007-11-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：L26A, D28N | SO4 SULFATE ION × 1 FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；3.3M Na-formate, 0.4M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.62 Å R-free 0.218 |
| 3BAV Crystal structure of L26A/D28N mutant of Human acidic fibroblast growth factor Deposited 2007-11-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：L26A, D28N | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；3.3M Na-formate, 0.4M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.62 Å R-free 0.218 |
| 3BB2 Crystal structure of L26D/D28N mutant of Human acidic fibroblast growth factor Deposited 2007-11-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：L26D, D28N | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；2.8M Na-formate, 0.6M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.50 Å R-free 0.228 |
| 3BB2 Crystal structure of L26D/D28N mutant of Human acidic fibroblast growth factor Deposited 2007-11-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：L26D, D28N | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298.15 K；2.8M Na-formate, 0.6M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298.15K
|
Resolution 1.50 Å R-free 0.228 |
| 3CQA Crystal structure of human fibroblast growth factor-1 with mutations Glu81Ala and Lys101Ala Deposited 2008-04-02 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
Fragment：UNP residues 16-152
|
Mutation：E81A and K101A | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.3 M sodium formate and 0.4 M ammonium sulphate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.80 Å R-free 0.212 |
| 3CQA Crystal structure of human fibroblast growth factor-1 with mutations Glu81Ala and Lys101Ala Deposited 2008-04-02 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
Fragment：UNP residues 16-152
|
Mutation：E81A and K101A | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.3 M sodium formate and 0.4 M ammonium sulphate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.80 Å R-free 0.212 |
| 3CQA Crystal structure of human fibroblast growth factor-1 with mutations Glu81Ala and Lys101Ala Deposited 2008-04-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
16–155（140 aa）
Fragment：UNP residues 16-152
Chain B
16–155（140 aa）
Fragment：UNP residues 16-152
|
Mutation：E81A and K101A Mutation：E81A and K101A | SO4 SULFATE ION × 2 FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.3 M sodium formate and 0.4 M ammonium sulphate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.80 Å R-free 0.212 |
| 3CRG Crystal structure of human fibroblast growth factor-1 with mutations Glu81Ala, Glu82Asn and Lys101Ala Deposited 2008-04-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：E81A, E82N and K101A | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.1 M sodium formate and 0.4 M ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.85 Å R-free 0.221 |
| 3CRG Crystal structure of human fibroblast growth factor-1 with mutations Glu81Ala, Glu82Asn and Lys101Ala Deposited 2008-04-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：E81A, E82N and K101A | SO4 SULFATE ION × 1 FMT FORMIC ACID × 2 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.1 M sodium formate and 0.4 M ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.85 Å R-free 0.221 |
| 3CRH Crystal structure of human fibroblast growth factor-1 with mutations Glu81Ser and Lys101Ala Deposited 2008-04-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：E81S and K101A | SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；1.5 M sodium formate and 0.4 M ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.15 Å R-free 0.227 |
| 3CRH Crystal structure of human fibroblast growth factor-1 with mutations Glu81Ser and Lys101Ala Deposited 2008-04-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：E81S and K101A | SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；1.5 M sodium formate and 0.4 M ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.15 Å R-free 0.227 |
| 3CRH Crystal structure of human fibroblast growth factor-1 with mutations Glu81Ser and Lys101Ala Deposited 2008-04-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
16–155（140 aa）
Chain B
16–155（140 aa）
|
Mutation：E81S and K101A Mutation：E81S and K101A | SO4 SULFATE ION × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；1.5 M sodium formate and 0.4 M ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.15 Å R-free 0.227 |
| 3CRI Crystal structure of human fibroblast growth factor-1 with mutations Glu81Ser, Glu82Asn and Lys101Ala Deposited 2008-04-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：E81S, E82N and K101A | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.3 M sodium formate and 0.4 M ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.10 Å R-free 0.228 |
| 3CRI Crystal structure of human fibroblast growth factor-1 with mutations Glu81Ser, Glu82Asn and Lys101Ala Deposited 2008-04-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：E81S, E82N and K101A | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.3 M sodium formate and 0.4 M ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.10 Å R-free 0.228 |
| 3CU1 Crystal Structure of 2:2:2 FGFR2D2:FGF1:SOS complex Deposited 2008-04-15 | Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain B
22–152（131 aa）
Fragment：UNP residues 22-152
Chain D
22–152（131 aa）
Fragment：UNP residues 22-152
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；12% PEG3350, 4% Tacsimate, pH 7.0, vapor diffusion, hanging drop, temperature 298.0K
|
Resolution 2.60 Å R-free 0.277 |
| 3FGM Crystal structure of L44F/C83T/C117V/F132W mutant of Human acidic fibroblast growth factor Deposited 2008-12-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：L44F, C83T, C117V, F132W | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；4.1M Na-formate, 0.1M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.95 Å R-free 0.238 |
| 3FGM Crystal structure of L44F/C83T/C117V/F132W mutant of Human acidic fibroblast growth factor Deposited 2008-12-06 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：L44F, C83T, C117V, F132W | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；4.1M Na-formate, 0.1M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.95 Å R-free 0.238 |
| 3FJ8 Crystal structure of C117I mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：C117I | SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3M Na-formate, 0.7M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.00 Å R-free 0.231 |
| 3FJ8 Crystal structure of C117I mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：C117I | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3M Na-formate, 0.7M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.00 Å R-free 0.231 |
| 3FJ9 Crystal structure of F85W mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：F85W | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3M Na-formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.228 |
| 3FJ9 Crystal structure of F85W mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：F85W | FMT FORMIC ACID × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3M Na-formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.228 |
| 3FJA Crystal structure of F132W mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：F132W | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.4M Na formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.95 Å R-free 0.213 |
| 3FJA Crystal structure of F132W mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：F132W | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.4M Na formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.95 Å R-free 0.213 |
| 3FJB Crystal structure of V31I mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：V31I | SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；2.5M Na formate, 0.7M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.00 Å R-free 0.233 |
| 3FJB Crystal structure of V31I mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：V31I | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；2.5M Na formate, 0.7M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.00 Å R-free 0.233 |
| 3FJC Crystal structure of L44W mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：L44W | SO4 SULFATE ION × 1 FMT FORMIC ACID × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.0M Na-formate, 0.4M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.00 Å R-free 0.243 |
| 3FJC Crystal structure of L44W mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：L44W | FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.0M Na-formate, 0.4M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.00 Å R-free 0.243 |
| 3FJD Crystal structure of L44F/F132W mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：L44F,F132W | SO4 SULFATE ION × 1 FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.0M Na-formate, 0.2M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.221 |
| 3FJD Crystal structure of L44F/F132W mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：L44F,F132W | FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.0M Na-formate, 0.2M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.221 |
| 3FJE Crystal structure of C83S mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：C83S | SO4 SULFATE ION × 1 FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.0M Na formate, 0.4M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.10 Å R-free 0.235 |
| 3FJE Crystal structure of C83S mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：C83S | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.0M Na formate, 0.4M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.10 Å R-free 0.235 |
| 3FJF Crystal structure of C83T mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：C83T | FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.3M Na formate, 0.4M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.224 |
| 3FJF Crystal structure of C83T mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：C83T | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.3M Na formate, 0.4M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.224 |
| 3FJH Crystal structure of C83A mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：C83A | SO4 SULFATE ION × 1 FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；2.7 M Na formate, 0.4M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.218 |
| 3FJH Crystal structure of C83A mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：C83A | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；2.7 M Na formate, 0.4M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.218 |
| 3FJI Crystal structure of K12V/C83I/C117V mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：K12V,C83I,C117V | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.0M Na formate, 0.1M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.55 Å R-free 0.263 |
| 3FJI Crystal structure of K12V/C83I/C117V mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：K12V,C83I,C117V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.0M Na formate, 0.1M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.55 Å R-free 0.263 |
| 3FJI Crystal structure of K12V/C83I/C117V mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
16–155（140 aa）
|
Mutation：K12V,C83I,C117V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.0M Na formate, 0.1M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.55 Å R-free 0.263 |
| 3FJI Crystal structure of K12V/C83I/C117V mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
16–155（140 aa）
|
Mutation：K12V,C83I,C117V | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.0M Na formate, 0.1M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.55 Å R-free 0.263 |
| 3FJJ Crystal structure of C83V mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：C83V | SO4 SULFATE ION × 1 FMT FORMIC ACID × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.3 M Na formate, 0.4M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.233 |
| 3FJJ Crystal structure of C83V mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：C83V | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.3 M Na formate, 0.4M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.233 |
| 3FJK Crystal structure of A66C mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：A66C | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.3 M Na formate, 0.15M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.15 Å R-free 0.267 |
| 3FJK Crystal structure of A66C mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：A66C | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.3 M Na formate, 0.15M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.15 Å R-free 0.267 |
| 3FJK Crystal structure of A66C mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
16–155（140 aa）
|
Mutation：A66C | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.3 M Na formate, 0.15M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.15 Å R-free 0.267 |
| 3FJK Crystal structure of A66C mutant of Human acidic fibroblast growth factor Deposited 2008-12-14 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
16–155（140 aa）
|
Mutation：A66C | FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.3 M Na formate, 0.15M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.15 Å R-free 0.267 |
| 3HOM Crystal structure of oxidized A66C mutant of Human acidic fibroblast growth factor Deposited 2009-06-02 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：A81C | FMT FORMIC ACID × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.2M Na-formate, 0.15M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.30 Å R-free 0.234 |
| 3HOM Crystal structure of oxidized A66C mutant of Human acidic fibroblast growth factor Deposited 2009-06-02 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：A81C | FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.2M Na-formate, 0.15M (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.30 Å R-free 0.234 |
| 3JUT Acidic Fibroblast Growth Factor (FGF-1) complexed with gentisic acid Deposited 2009-09-15 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
24–153（130 aa）
Fragment：Heparin-binding, UNP residues 24-153
|
Not recorded | GTQ 2,5-dihydroxybenzoic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.8；295 K；Equal volumes of protein and inhibitor solutions, 0.75 and 1.5 mM,respectively were mixed with drops containing 60% sodium/potassium tartrate buffered with 5 mM sodium phosphate [pH 7.8]. The drops were
equilibrated against 200 ml of 1.3M Li2SO4 and typical crystals grew within two weeks
, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.25 Å R-free 0.274 |
| 3JUT Acidic Fibroblast Growth Factor (FGF-1) complexed with gentisic acid Deposited 2009-09-15 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
24–153（130 aa）
Fragment：Heparin-binding, UNP residues 24-153
|
Not recorded | GTQ 2,5-dihydroxybenzoic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.8；295 K；Equal volumes of protein and inhibitor solutions, 0.75 and 1.5 mM,respectively were mixed with drops containing 60% sodium/potassium tartrate buffered with 5 mM sodium phosphate [pH 7.8]. The drops were
equilibrated against 200 ml of 1.3M Li2SO4 and typical crystals grew within two weeks
, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.25 Å R-free 0.274 |
| 3JUT Acidic Fibroblast Growth Factor (FGF-1) complexed with gentisic acid Deposited 2009-09-15 | Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
24–153（130 aa）
Fragment：Heparin-binding, UNP residues 24-153
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.8；295 K；Equal volumes of protein and inhibitor solutions, 0.75 and 1.5 mM,respectively were mixed with drops containing 60% sodium/potassium tartrate buffered with 5 mM sodium phosphate [pH 7.8]. The drops were
equilibrated against 200 ml of 1.3M Li2SO4 and typical crystals grew within two weeks
, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.25 Å R-free 0.274 |
| 3JUT Acidic Fibroblast Growth Factor (FGF-1) complexed with gentisic acid Deposited 2009-09-15 | Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
24–153（130 aa）
Fragment：Heparin-binding, UNP residues 24-153
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.8；295 K；Equal volumes of protein and inhibitor solutions, 0.75 and 1.5 mM,respectively were mixed with drops containing 60% sodium/potassium tartrate buffered with 5 mM sodium phosphate [pH 7.8]. The drops were
equilibrated against 200 ml of 1.3M Li2SO4 and typical crystals grew within two weeks
, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.25 Å R-free 0.274 |
| 3JUT Acidic Fibroblast Growth Factor (FGF-1) complexed with gentisic acid Deposited 2009-09-15 | Different experimental conditions Different structure-quality metrics | Assembly 5 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain E
24–153（130 aa）
Fragment：Heparin-binding, UNP residues 24-153
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.8；295 K；Equal volumes of protein and inhibitor solutions, 0.75 and 1.5 mM,respectively were mixed with drops containing 60% sodium/potassium tartrate buffered with 5 mM sodium phosphate [pH 7.8]. The drops were
equilibrated against 200 ml of 1.3M Li2SO4 and typical crystals grew within two weeks
, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.25 Å R-free 0.274 |
| 3JUT Acidic Fibroblast Growth Factor (FGF-1) complexed with gentisic acid Deposited 2009-09-15 | Different experimental conditions Different structure-quality metrics | Assembly 6 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain F
24–153（130 aa）
Fragment：Heparin-binding, UNP residues 24-153
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.8；295 K；Equal volumes of protein and inhibitor solutions, 0.75 and 1.5 mM,respectively were mixed with drops containing 60% sodium/potassium tartrate buffered with 5 mM sodium phosphate [pH 7.8]. The drops were
equilibrated against 200 ml of 1.3M Li2SO4 and typical crystals grew within two weeks
, VAPOR DIFFUSION, SITTING DROP, temperature 295K
|
Resolution 2.25 Å R-free 0.274 |
| 3O3Q Crystal structure of "L44F/M67I/L73V/A103G/deletion 104-106/F108Y/V109L/L111I/C117V/R119G/deletion 120-122" mutant form of Human acidic fibroblast growth factor Deposited 2010-07-25 | Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：L44F, M67I, L73V, A103G, deletion 104-106, F108Y, V109L, L111I, C117V, R119G, deletion 120-122 | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；0.2M magnesium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.60 Å R-free 0.203 |
| 3O3Q Crystal structure of "L44F/M67I/L73V/A103G/deletion 104-106/F108Y/V109L/L111I/C117V/R119G/deletion 120-122" mutant form of Human acidic fibroblast growth factor Deposited 2010-07-25 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：L44F, M67I, L73V, A103G, deletion 104-106, F108Y, V109L, L111I, C117V, R119G, deletion 120-122 | GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；0.2M magnesium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.60 Å R-free 0.203 |
| 3O3Q Crystal structure of "L44F/M67I/L73V/A103G/deletion 104-106/F108Y/V109L/L111I/C117V/R119G/deletion 120-122" mutant form of Human acidic fibroblast growth factor Deposited 2010-07-25 | Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
16–155（140 aa）
|
Mutation：L44F, M67I, L73V, A103G, deletion 104-106, F108Y, V109L, L111I, C117V, R119G, deletion 120-122 | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；0.2M magnesium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.60 Å R-free 0.203 |
| 3O3Q Crystal structure of "L44F/M67I/L73V/A103G/deletion 104-106/F108Y/V109L/L111I/C117V/R119G/deletion 120-122" mutant form of Human acidic fibroblast growth factor Deposited 2010-07-25 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
16–155（140 aa）
|
Mutation：L44F, M67I, L73V, A103G, deletion 104-106, F108Y, V109L, L111I, C117V, R119G, deletion 120-122 | GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；0.2M magnesium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.60 Å R-free 0.203 |
| 3OJ2 Crystal structure of FGF1 complexed with the ectodomain of FGFR2b harboring the A172F Pfeiffer syndrome mutation Deposited 2010-08-20 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–155（155 aa）
|
Not recorded | SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；0.1M Hepes, 20% PEG4000, 0.2M ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.20 Å R-free 0.294 |
| 3OJ2 Crystal structure of FGF1 complexed with the ectodomain of FGFR2b harboring the A172F Pfeiffer syndrome mutation Deposited 2010-08-20 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
1–155（155 aa）
|
Not recorded | SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；0.1M Hepes, 20% PEG4000, 0.2M ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.20 Å R-free 0.294 |
| 3OJM Crystal Structure of FGF1 complexed with the ectodomain of FGFR2b harboring P253R Apert mutation Deposited 2010-08-23 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–155（155 aa）
|
Not recorded | SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；0.1M Hepes, 22% monomethyl ether PEG5000, 0.2M ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.10 Å R-free 0.263 |
| 3OJV Crystal Structure of FGF1 complexed with the ectodomain of FGFR1c exhibiting an ordered ligand specificity-determining betaC'-betaE loop Deposited 2010-08-23 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
21–155（135 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；293 K；0.1M Tris, 15% PEG4000, 0.1M ammonium sulfate, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.60 Å R-free 0.309 |
| 3OJV Crystal Structure of FGF1 complexed with the ectodomain of FGFR1c exhibiting an ordered ligand specificity-determining betaC'-betaE loop Deposited 2010-08-23 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
21–155（135 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；293 K；0.1M Tris, 15% PEG4000, 0.1M ammonium sulfate, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.60 Å R-free 0.309 |
| 3UD7 Crystal Structure Analysis of FGF1-Disaccharide(NI21) complexes Deposited 2011-10-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Not recorded | PO4 PHOSPHATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；2M (NH4)HPO4, 0.1M sodium acetate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.80 Å R-free 0.267 |
| 3UD7 Crystal Structure Analysis of FGF1-Disaccharide(NI21) complexes Deposited 2011-10-27 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Not recorded | PO4 PHOSPHATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；2M (NH4)HPO4, 0.1M sodium acetate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.80 Å R-free 0.267 |
| 3UD7 Crystal Structure Analysis of FGF1-Disaccharide(NI21) complexes Deposited 2011-10-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
16–155（140 aa）
|
Not recorded | PO4 PHOSPHATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；2M (NH4)HPO4, 0.1M sodium acetate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.80 Å R-free 0.267 |
| 3UD8 Crystal Structure Analysis of FGF1-Disaccharide(NI22) complex Deposited 2011-10-27 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；2 M (NH4)HPO4, 0.1 M sodium acetate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.37 Å R-free 0.270 |
| 3UD8 Crystal Structure Analysis of FGF1-Disaccharide(NI22) complex Deposited 2011-10-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Not recorded | PO4 PHOSPHATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；2 M (NH4)HPO4, 0.1 M sodium acetate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.37 Å R-free 0.270 |
| 3UD8 Crystal Structure Analysis of FGF1-Disaccharide(NI22) complex Deposited 2011-10-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
16–155（140 aa）
|
Not recorded | PO4 PHOSPHATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；2 M (NH4)HPO4, 0.1 M sodium acetate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.37 Å R-free 0.270 |
| 3UD9 Crystal Structure Analysis of FGF1-Disaccharide(NI23) complex Deposited 2011-10-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Not recorded | PO4 PHOSPHATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；2M (NH4)HPO4, 0.1M sodium acetate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.34 Å R-free 0.252 |
| 3UD9 Crystal Structure Analysis of FGF1-Disaccharide(NI23) complex Deposited 2011-10-27 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；2M (NH4)HPO4, 0.1M sodium acetate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.34 Å R-free 0.252 |
| 3UD9 Crystal Structure Analysis of FGF1-Disaccharide(NI23) complex Deposited 2011-10-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
16–155（140 aa）
|
Not recorded | PO4 PHOSPHATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；2M (NH4)HPO4, 0.1M sodium acetate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.34 Å R-free 0.252 |
| 3UDA Crystal Structure Analysis of FGF1-Disaccharide(NI24) complex Deposited 2011-10-27 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；2M (NH4)HPO4, 0.1M sodium acetate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.51 Å R-free 0.276 |
| 3UDA Crystal Structure Analysis of FGF1-Disaccharide(NI24) complex Deposited 2011-10-27 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 2 Other combination Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；2M (NH4)HPO4, 0.1M sodium acetate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.51 Å R-free 0.276 |
| 3UDA Crystal Structure Analysis of FGF1-Disaccharide(NI24) complex Deposited 2011-10-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
16–155（140 aa）
|
Not recorded | PO4 PHOSPHATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；2M (NH4)HPO4, 0.1M sodium acetate, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.51 Å R-free 0.276 |
| 4J23 Low resolution crystal structure of the FGFR2D2D3/FGF1/SR128545 complex Deposited 2013-02-04 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
21–155（135 aa）
Fragment：unp residues 21-155
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 3.88 Å R-free 0.384 |
| 4Q91 Crystal structure of C16A/K12V/C117V/P134V mutant of human acidic fibroblast growth factor Deposited 2014-04-28 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：K12V/C16A/C117V/P134V | FMT FORMIC ACID × 2 PO4 PHOSPHATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.4 M sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.80 Å R-free 0.186 |
| 4Q91 Crystal structure of C16A/K12V/C117V/P134V mutant of human acidic fibroblast growth factor Deposited 2014-04-28 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：K12V/C16A/C117V/P134V | FMT FORMIC ACID × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；3.4 M sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.80 Å R-free 0.186 |
| 4Q9G Crystal structure of K12V/C16S/C117V/P134V mutant of human acidic fibroblast growth factor Deposited 2014-05-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：K12V/C16S/C117V/P134V | FMT FORMIC ACID × 2 PO4 PHOSPHATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；1.8 M sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.55 Å R-free 0.199 |
| 4Q9G Crystal structure of K12V/C16S/C117V/P134V mutant of human acidic fibroblast growth factor Deposited 2014-05-01 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：K12V/C16S/C117V/P134V | FMT FORMIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；1.8 M sodium formate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.55 Å R-free 0.199 |
| 4Q9P Crystal structure of C16T/K12V/C117V/P134V mutant of human acidic fibroblast growth factor Deposited 2014-05-01 | Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：K12V/C16T/C117V/P134V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；298 K；1.0 M sodium citrate, 0.1 M imidazole, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.80 Å R-free 0.210 |
| 4Q9P Crystal structure of C16T/K12V/C117V/P134V mutant of human acidic fibroblast growth factor Deposited 2014-05-01 | Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：K12V/C16T/C117V/P134V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；298 K；1.0 M sodium citrate, 0.1 M imidazole, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.80 Å R-free 0.210 |
| 4QAL Crystal structure of C117A mutant of human acidic fibroblast growth factor Deposited 2014-05-05 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：C117A | FLC CITRATE ANION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；298 K；0.7 M sodium citrate, 0.1 M imidazole, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.50 Å R-free 0.190 |
| 4QAL Crystal structure of C117A mutant of human acidic fibroblast growth factor Deposited 2014-05-05 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：C117A | FLC CITRATE ANION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；298 K；0.7 M sodium citrate, 0.1 M imidazole, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.50 Å R-free 0.190 |
| 4QBC Crystal structure of C117T mutant of human acidic fibroblast growth factor in sodium formate buffer Deposited 2014-05-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：C117T | SO4 SULFATE ION × 1 FMT FORMIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；4.0 M sodium formate, 0.45 M ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.52 Å R-free 0.199 |
| 4QBC Crystal structure of C117T mutant of human acidic fibroblast growth factor in sodium formate buffer Deposited 2014-05-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：C117T | FMT FORMIC ACID × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；4.0 M sodium formate, 0.45 M ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.52 Å R-free 0.199 |
| 4QBV Crystal structure of C117T mutant of human acidic fibroblast growth factor in sodium citrate buffer Deposited 2014-05-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：C117T | FLC CITRATE ANION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；298 K；0.9 M sodium citrate, 0.1 M imidazole, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.50 Å R-free 0.168 |
| 4QBV Crystal structure of C117T mutant of human acidic fibroblast growth factor in sodium citrate buffer Deposited 2014-05-08 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：C117T | FLC CITRATE ANION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；298 K；0.9 M sodium citrate, 0.1 M imidazole, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.50 Å R-free 0.168 |
| 4QC4 Crystal structure of C117S mutant of human acidic fibroblast growth factor Deposited 2014-05-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：C117S | FLC CITRATE ANION × 1 NA SODIUM ION × 1 IMD IMIDAZOLE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；295 K；0.9 M sodium citrate, 0.1 M imidazole, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.49 Å R-free 0.182 |
| 4QC4 Crystal structure of C117S mutant of human acidic fibroblast growth factor Deposited 2014-05-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：C117S | FLC CITRATE ANION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；295 K；0.9 M sodium citrate, 0.1 M imidazole, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 295K
|
Resolution 1.49 Å R-free 0.182 |
| 4QO3 Crystal structure of C16S/N18S/K12V/C117V/P134V mutant of human acidic fibroblast growth factor Deposited 2014-06-19 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：C16S/N18S/K12V/C117V/P134V | FLC CITRATE ANION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；298 K；0.9 M sodium citrate, 0.1 M imidazole, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.05 Å R-free 0.187 |
| 4QO3 Crystal structure of C16S/N18S/K12V/C117V/P134V mutant of human acidic fibroblast growth factor Deposited 2014-06-19 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：C16S/N18S/K12V/C117V/P134V | FLC CITRATE ANION × 1 IMD IMIDAZOLE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；298 K；0.9 M sodium citrate, 0.1 M imidazole, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.05 Å R-free 0.187 |
| 4XKI Human Fibroblast Growth Factor - 1 (FGF-1) mutant S116R Deposited 2015-01-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
|
Mutation：S116R | SO4 SULFATE ION × 2 PO4 PHOSPHATE ION × 3 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；2M ammonium sulfate, 2% v/v Polyethylene glycol 400 and 0.1 M sodium HEPES pH 7.5
|
Resolution 2.00 Å R-free 0.215 |
| 4XKI Human Fibroblast Growth Factor - 1 (FGF-1) mutant S116R Deposited 2015-01-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
|
Mutation：S116R | PO4 PHOSPHATE ION × 5 2PE NONAETHYLENE GLYCOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；2M ammonium sulfate, 2% v/v Polyethylene glycol 400 and 0.1 M sodium HEPES pH 7.5
|
Resolution 2.00 Å R-free 0.215 |
| 4YOL Human fibroblast growth factor-1 C16S/A66C/C117A/P134A Deposited 2015-03-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：C16S/A66C/C117A/P134A | FLC CITRATE ANION × 1 IMD IMIDAZOLE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；298 K；0.7 M sodium citrate, 0.1 M imidazole, pH 8.5
|
Resolution 1.97 Å R-free 0.199 |
| 4YOL Human fibroblast growth factor-1 C16S/A66C/C117A/P134A Deposited 2015-03-11 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
16–155（140 aa）
Fragment：UNP residues 16-155
|
Mutation：C16S/A66C/C117A/P134A | FLC CITRATE ANION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；298 K；0.7 M sodium citrate, 0.1 M imidazole, pH 8.5
|
Resolution 1.97 Å R-free 0.199 |
96 other PDB entries and 212 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | FGF1_HUMAN |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 1–130； UniProt 24–153 Author chain B； PDBConstruct 1–130； UniProt 24–153 Author chain C； PDBConstruct 1–130； UniProt 24–153 Author chain D； PDBConstruct 1–130； UniProt 24–153 Author chain E； PDBConstruct 1–130； UniProt 24–153 Author chain F； PDBConstruct 1–130； UniProt 24–153 |
