WD repeat-containing protein 5
Homo sapiens
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein heterocomplex Heteromer Protein × 2 PDB declaration: dimeric（2） Consistent with protein copy count | Chain A； UniProt 21–334 | Fragment：UNP residues 21-334 | Histone-lysine N-methyltransferase SETD1A × 1 （O15047） | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, HANGING DROP；pH 4.5；298 K；25% PEG3350, 0.1 M sodium acetate, pH 4.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K | Resolution 1.79 Å R-free 0.230 |
| 2 | Protein heterocomplex Heteromer Protein × 2 PDB declaration: dimeric（2） Consistent with protein copy count | Chain C； UniProt 21–334 | Fragment：UNP residues 21-334 | Histone-lysine N-methyltransferase SETD1A × 1 （O15047） | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, HANGING DROP；pH 4.5；298 K；25% PEG3350, 0.1 M sodium acetate, pH 4.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K | Resolution 1.79 Å R-free 0.230 |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 3UVN | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 10TC Structure of WDR5 bound to RbBP5 (D376N) Deposited 2026-02-07 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
31–334（304 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；0.15 M Ammonium citrate, 18% PEG3350
|
Resolution 2.20 Å R-free 0.243 |
| 10TC Structure of WDR5 bound to RbBP5 (D376N) Deposited 2026-02-07 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
31–334（304 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；0.15 M Ammonium citrate, 18% PEG3350
|
Resolution 2.20 Å R-free 0.243 |
| 10TC Structure of WDR5 bound to RbBP5 (D376N) Deposited 2026-02-07 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain E
31–334（304 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；0.15 M Ammonium citrate, 18% PEG3350
|
Resolution 2.20 Å R-free 0.243 |
| 10TC Structure of WDR5 bound to RbBP5 (D376N) Deposited 2026-02-07 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain G
31–334（304 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；0.15 M Ammonium citrate, 18% PEG3350
|
Resolution 2.20 Å R-free 0.243 |
| 24XN Structure of WDR5 F263A variant in complex with MBD3C Deposited 2026-03-23 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；289 K；0.15 ammonium sulfate, 0.1 M sodium HEPES, pH7.0, 20% w/v PEG 4000
|
Resolution 1.57 Å R-free 0.212 |
| 24XN Structure of WDR5 F263A variant in complex with MBD3C Deposited 2026-03-23 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；289 K；0.15 ammonium sulfate, 0.1 M sodium HEPES, pH7.0, 20% w/v PEG 4000
|
Resolution 1.57 Å R-free 0.212 |
| 24XP Crystal structure of WDR5 F133A variant in complex with MBD3C Deposited 2026-03-23 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；289 K；0.1 M sodium acetate (pH 5.0), 20% (w/v) PEG 4000
|
Resolution 1.30 Å R-free 0.180 |
| 24XP Crystal structure of WDR5 F133A variant in complex with MBD3C Deposited 2026-03-23 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；289 K；0.1 M sodium acetate (pH 5.0), 20% (w/v) PEG 4000
|
Resolution 1.30 Å R-free 0.180 |
| 2CNX WDR5 and Histone H3 Lysine 4 dimethyl complex at 2.1 angstrom Deposited 2006-05-25 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
20–334（315 aa）
Fragment：RESIDUES 20-334
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.10 Å R-free 0.223 |
| 2CO0 WDR5 and unmodified Histone H3 complex at 2.25 Angstrom Deposited 2006-05-25 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
20–334（315 aa）
Fragment：RESIDUES 20-334
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.25 Å R-free 0.226 |
| 2CO0 WDR5 and unmodified Histone H3 complex at 2.25 Angstrom Deposited 2006-05-25 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
20–334（315 aa）
Fragment：RESIDUES 20-334
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.25 Å R-free 0.226 |
| 2G99 Structural basis for the specific recognition of methylated histone H3 lysine 4 by the WD-40 protein WDR5 Deposited 2006-03-06 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
27–334（308 aa）
Fragment：residues 27-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；20% PEG 4000, 10% isopropanol, 0.1M HEPES, pH7.5 , VAPOR DIFFUSION, HANGING DROP, temperature 298.0K
|
Resolution 1.90 Å R-free 0.243 |
| 2G99 Structural basis for the specific recognition of methylated histone H3 lysine 4 by the WD-40 protein WDR5 Deposited 2006-03-06 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
27–334（308 aa）
Fragment：residues 27-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；20% PEG 4000, 10% isopropanol, 0.1M HEPES, pH7.5 , VAPOR DIFFUSION, HANGING DROP, temperature 298.0K
|
Resolution 1.90 Å R-free 0.243 |
| 2G9A Structural basis for the specific recognition of methylated histone H3 lysine 4 by the WD-40 protein WDR5 Deposited 2006-03-06 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
29–334（306 aa）
Fragment：;'residues 24-334
;
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；20% PEG, 0.2M ammonium acetate, 100mM HEPES, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.70 Å R-free 0.286 |
| 2GNQ Structure of wdr5 Deposited 2006-04-10 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–334（334 aa）
|
Not recorded | CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；300 K；20%peg5k mme, bis-tris 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 300K
|
Resolution 1.80 Å R-free 0.192 |
| 2H13 Crystal structure of WDR5/histone H3 complex Deposited 2006-05-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
22–334（313 aa）
Fragment：Residues 22-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；20-30% PEG3350, 0.1 M HEPES, pH 7.5, 0.05 M ammonium sulfate, VAPOR DIFFUSION, HANGING DROP
|
Resolution 1.58 Å R-free 0.200 |
| 2H14 Crystal of WDR5 (apo-form) Deposited 2006-05-15 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
Fragment：Residues 22-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；20-30% PEG 3350
0.1M Hepes
0.05M ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP
|
Resolution 1.48 Å R-free 0.197 |
| 2H68 Histone H3 recognition and presentation by the WDR5 module of the MLL1 complex Deposited 2006-05-30 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
23–334（312 aa）
Fragment：residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
Crystals were grown by hanging drop vapour equilibration in Nextal plates as follows: 1 ul of 10 15 mg ml-1 protein solution (10 mM Tris HCl (pH 7.4), 50 mM NaCl, and 10 mM 2-mercaptoethanol) were mixed with 1 ul of well solution composed of 50 mM HEPES (pH 7.5), 100 mM potassium formate, and 10-20% (w/v) polyethylene glycol 3350 and equilibrated at room temperature overnight against 1 ml of well solution.
|
Resolution 1.79 Å R-free 0.192 |
| 2H68 Histone H3 recognition and presentation by the WDR5 module of the MLL1 complex Deposited 2006-05-30 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
23–334（312 aa）
Fragment：residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
Crystals were grown by hanging drop vapour equilibration in Nextal plates as follows: 1 ul of 10 15 mg ml-1 protein solution (10 mM Tris HCl (pH 7.4), 50 mM NaCl, and 10 mM 2-mercaptoethanol) were mixed with 1 ul of well solution composed of 50 mM HEPES (pH 7.5), 100 mM potassium formate, and 10-20% (w/v) polyethylene glycol 3350 and equilibrated at room temperature overnight against 1 ml of well solution.
|
Resolution 1.79 Å R-free 0.192 |
| 2H6K Histone H3 recognition and presentation by the WDR5 module of the MLL1 complex Deposited 2006-05-31 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
23–334（312 aa）
Fragment：residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
Crystals were grown by hanging drop vapour equilibration in Nextal plates as follows: 1 ul of 10 15 mg ml-1 protein solution (10 mM Tris, HCl (pH 7.4), 50 mM NaCl, and 10 mM 2-mercaptoethanol) were mixed with 1 ul of well solution composed of 50 mM HEPES (pH 7.5), 100 mM potassium formate, and 10-20% (w/v) polyethylene glycol 3350 and equilibrated at room temperature overnight against 1 ml of well solution.
|
Resolution 1.89 Å R-free 0.190 |
| 2H6K Histone H3 recognition and presentation by the WDR5 module of the MLL1 complex Deposited 2006-05-31 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
23–334（312 aa）
Fragment：residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
Crystals were grown by hanging drop vapour equilibration in Nextal plates as follows: 1 ul of 10 15 mg ml-1 protein solution (10 mM Tris, HCl (pH 7.4), 50 mM NaCl, and 10 mM 2-mercaptoethanol) were mixed with 1 ul of well solution composed of 50 mM HEPES (pH 7.5), 100 mM potassium formate, and 10-20% (w/v) polyethylene glycol 3350 and equilibrated at room temperature overnight against 1 ml of well solution.
|
Resolution 1.89 Å R-free 0.190 |
| 2H6N Histone H3 recognition and presentation by the WDR5 module of the MLL1 complex Deposited 2006-05-31 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
23–334（312 aa）
Fragment：residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
Crystals were grown by hanging drop vapour equilibration in Nextal plates as follows: 1 ul of 10 15 mg ml-1 protein solution (10 mM Tris HCl (pH 7.4), 50 mM NaCl, and 10 mM 2-mercaptoethanol) were mixed with 1 ul of well solution composed of 50 mM HEPES (pH 7.5), 100 mM potassium formate, and 10-20% (w/v) polyethylene glycol 3350 and equilibrated at room temperature overnight against 1 ml of well solution.
|
Resolution 1.50 Å R-free 0.198 |
| 2H6N Histone H3 recognition and presentation by the WDR5 module of the MLL1 complex Deposited 2006-05-31 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
23–334（312 aa）
Fragment：residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
Crystals were grown by hanging drop vapour equilibration in Nextal plates as follows: 1 ul of 10 15 mg ml-1 protein solution (10 mM Tris HCl (pH 7.4), 50 mM NaCl, and 10 mM 2-mercaptoethanol) were mixed with 1 ul of well solution composed of 50 mM HEPES (pH 7.5), 100 mM potassium formate, and 10-20% (w/v) polyethylene glycol 3350 and equilibrated at room temperature overnight against 1 ml of well solution.
|
Resolution 1.50 Å R-free 0.198 |
| 2H6Q Histone H3 recognition and presentation by the WDR5 module of the MLL1 complex Deposited 2006-06-01 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
23–334（312 aa）
Fragment：residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
Crystals were grown by hanging drop vapour equilibration in Nextal plates as follows: 1 ul of 10 15 mg ml-1 protein solution (10 mM Tris HCl (pH 7.4), 50 mM NaCl, and 10 mM 2-mercaptoethanol) were mixed with 1 ul of well solution composed of 50 mM HEPES (pH 7.5), 100 mM potassium formate, and 10-20% (w/v) polyethylene glycol 3350 and equilibrated at room temperature overnight against 1 ml of well solution.
|
Resolution 1.87 Å R-free 0.185 |
| 2H6Q Histone H3 recognition and presentation by the WDR5 module of the MLL1 complex Deposited 2006-06-01 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
23–334（312 aa）
Fragment：residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
Crystals were grown by hanging drop vapour equilibration in Nextal plates as follows: 1 ul of 10 15 mg ml-1 protein solution (10 mM Tris HCl (pH 7.4), 50 mM NaCl, and 10 mM 2-mercaptoethanol) were mixed with 1 ul of well solution composed of 50 mM HEPES (pH 7.5), 100 mM potassium formate, and 10-20% (w/v) polyethylene glycol 3350 and equilibrated at room temperature overnight against 1 ml of well solution.
|
Resolution 1.87 Å R-free 0.185 |
| 2H9L WDR5delta23 Deposited 2006-06-10 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
24–334（311 aa）
|
Not recorded | SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；300 K；20% PEG 5000 MME, 0.1M Bis-Tris 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 300K
|
Resolution 1.75 Å R-free 0.201 |
| 2H9M WDR5 in complex with unmodified H3K4 peptide Deposited 2006-06-10 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；300 K；20% PEG 3350, 0.2M di-Na Tartrate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 300K
|
Resolution 1.90 Å R-free 0.257 |
| 2H9M WDR5 in complex with unmodified H3K4 peptide Deposited 2006-06-10 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；300 K；20% PEG 3350, 0.2M di-Na Tartrate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 300K
|
Resolution 1.90 Å R-free 0.257 |
| 2H9N WDR5 in complex with monomethylated H3K4 peptide Deposited 2006-06-10 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；20% PEG3350, pH 6.5, VAPOR DIFFUSION, HANGING DROP
|
Resolution 2.00 Å R-free 0.279 |
| 2H9N WDR5 in complex with monomethylated H3K4 peptide Deposited 2006-06-10 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；20% PEG3350, pH 6.5, VAPOR DIFFUSION, HANGING DROP
|
Resolution 2.00 Å R-free 0.279 |
| 2H9P WDR5 in complex with trimethylated H3K4 peptide Deposited 2006-06-10 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；300 K；30% PEG4000, 0.2M Ammonium Acetate and 0.1M Na Citrate, pH 5.6, VAPOR DIFFUSION, HANGING DROP, temperature 300K
|
Resolution 1.91 Å R-free 0.203 |
| 2O9K WDR5 in Complex with Dimethylated H3K4 Peptide Deposited 2006-12-13 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；300 K；20% PEG 5000 MME, 0.1M BIS-TRIS, VAPOR DIFFUSION, HANGING DROP, TEMPERATURE 300K, pH 6.50
|
Resolution 1.90 Å R-free 0.226 |
| 2O9K WDR5 in Complex with Dimethylated H3K4 Peptide Deposited 2006-12-13 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；300 K；20% PEG 5000 MME, 0.1M BIS-TRIS, VAPOR DIFFUSION, HANGING DROP, TEMPERATURE 300K, pH 6.50
|
Resolution 1.90 Å R-free 0.226 |
| 3EG6 Structure of WDR5 bound to MLL1 peptide Deposited 2008-09-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
23–334（312 aa）
Fragment：WD-repeat domain (UNP residues 23-334)
|
Not recorded | SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；298 K；30% PEG 3350, 30 mM (NH4)2SO4, 100 mM HEPES, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.72 Å R-free 0.240 |
| 3EMH Structural basis of WDR5-MLL interaction Deposited 2008-09-24 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
25–334（310 aa）
Fragment：UNP residues 25-334
|
Not recorded | SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；20 mM HEPES, 15-20% PEG 3350, 60mM Ammonium sulfate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.37 Å R-free 0.200 |
| 3MXX Crystal structure of WDR5 mutant (S62A) Deposited 2010-05-08 | Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
31–334（304 aa）
Fragment：RESIDUES 31-334
|
Mutation：S62A | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；18% PEG 3350, 0.1M Hepes, 18mM (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.05 Å R-free 0.239 |
| 3N0D Crystal structure of WDR5 mutant (W330F) Deposited 2010-05-13 | Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
31–334（304 aa）
Fragment：RESIDUES 31-334
|
Mutation：W330F | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；18% PEG 3350, 0.1M Hepes, 14mM (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.30 Å R-free 0.233 |
| 3N0E Crystal structure of WDR5 mutant (W330Y) Deposited 2010-05-13 | Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
31–334（304 aa）
Fragment：RESIDUES 31-334
|
Mutation：W330Y | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；18% PEG 3350, 0.1M Hepes, 14mM (NH4)2SO4, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.50 Å R-free 0.323 |
| 3P4F Structural and biochemical insights into MLL1 core complex assembly and regulation. Deposited 2010-10-06 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
22–334（313 aa）
Fragment：unp residues 1-308
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；0.2 M ammonium citrate (buffered with hydrochloric acid/sodium hydroxide to pH 7.0) and 18% PEG3350, VAPOR DIFFUSION, HANGING DROP
|
Resolution 2.35 Å R-free 0.249 |
| 3PSL Fine-tuning the stimulation of MLL1 methyltransferase activity by a histone H3 based peptide mimetic Deposited 2010-12-01 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
21–334（314 aa）
Fragment：WDR5 (unp residues 21-334)
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；293 K；50 mM NaAcetate, 100 mM NH4 SO4 , and 20% PEG4000, pH 4.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.70 Å R-free 0.205 |
| 3PSL Fine-tuning the stimulation of MLL1 methyltransferase activity by a histone H3 based peptide mimetic Deposited 2010-12-01 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
21–334（314 aa）
Fragment：WDR5 (unp residues 21-334)
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；293 K；50 mM NaAcetate, 100 mM NH4 SO4 , and 20% PEG4000, pH 4.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.70 Å R-free 0.205 |
| 3SMR Crystal structure of human WD repeat domain 5 with compound Deposited 2011-06-28 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
24–334（311 aa）
|
Not recorded | NP7 2-chloro-N-[2-(4-methylpiperazin-1-yl)-5-nitrophenyl]benzamide × 1 EDO 1,2-ETHANEDIOL × 8 UNX UNKNOWN LIGAND × 7 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；297 K；24% PEG3350,9.2M NH4 Acetate, 0.1 Bis Tris pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 297K
|
Resolution 1.82 Å R-free 0.206 |
| 3SMR Crystal structure of human WD repeat domain 5 with compound Deposited 2011-06-28 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
24–334（311 aa）
|
Not recorded | NP7 2-chloro-N-[2-(4-methylpiperazin-1-yl)-5-nitrophenyl]benzamide × 1 EDO 1,2-ETHANEDIOL × 6 UNX UNKNOWN LIGAND × 10 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；297 K；24% PEG3350,9.2M NH4 Acetate, 0.1 Bis Tris pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 297K
|
Resolution 1.82 Å R-free 0.206 |
| 3SMR Crystal structure of human WD repeat domain 5 with compound Deposited 2011-06-28 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
24–334（311 aa）
|
Not recorded | NP7 2-chloro-N-[2-(4-methylpiperazin-1-yl)-5-nitrophenyl]benzamide × 1 EDO 1,2-ETHANEDIOL × 5 UNX UNKNOWN LIGAND × 6 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；297 K；24% PEG3350,9.2M NH4 Acetate, 0.1 Bis Tris pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 297K
|
Resolution 1.82 Å R-free 0.206 |
| 3SMR Crystal structure of human WD repeat domain 5 with compound Deposited 2011-06-28 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
24–334（311 aa）
|
Not recorded | NP7 2-chloro-N-[2-(4-methylpiperazin-1-yl)-5-nitrophenyl]benzamide × 1 EDO 1,2-ETHANEDIOL × 4 UNX UNKNOWN LIGAND × 9 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；297 K；24% PEG3350,9.2M NH4 Acetate, 0.1 Bis Tris pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 297K
|
Resolution 1.82 Å R-free 0.206 |
| 3UR4 Crystal structure of human WD repeat domain 5 with compound Deposited 2011-11-21 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
24–334（311 aa）
|
Not recorded | 0BW methyl 3-[(3-methoxybenzoyl)amino]-4-(4-methylpiperazin-1-yl)benzoate × 1 EDO 1,2-ETHANEDIOL × 2 CL CHLORIDE ION × 4 SO4 SULFATE ION × 2 UNX UNKNOWN LIGAND × 17 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；297 K；22% PEG 3350,0.1M A.S. ,0.1M Bis Tris pH 6.0
, VAPOR DIFFUSION, SITTING DROP, temperature 297K
|
Resolution 1.80 Å R-free 0.213 |
| 3UR4 Crystal structure of human WD repeat domain 5 with compound Deposited 2011-11-21 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
24–334（311 aa）
|
Not recorded | 0BW methyl 3-[(3-methoxybenzoyl)amino]-4-(4-methylpiperazin-1-yl)benzoate × 1 EDO 1,2-ETHANEDIOL × 6 CL CHLORIDE ION × 2 SO4 SULFATE ION × 1 UNX UNKNOWN LIGAND × 12 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；297 K；22% PEG 3350,0.1M A.S. ,0.1M Bis Tris pH 6.0
, VAPOR DIFFUSION, SITTING DROP, temperature 297K
|
Resolution 1.80 Å R-free 0.213 |
| 3UVK Crystal structure of WDR5 in complex with the WDR5-interacting motif of MLL2 Deposited 2011-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
21–334（314 aa）
Fragment：UNP residues 21-334
|
Not recorded | BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.5；323 K；0.1 M ammonium sulfate, 24% PEG3350, 0.1 M Bis-Tris, pH 5.5, VAPOR DIFFUSION, HANGING DROP, temperature 323K
|
Resolution 1.40 Å R-free 0.192 |
| 3UVL Crystal structure of WDR5 in complex with the WDR5-interacting motif of MLL3 Deposited 2011-11-30 | Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
21–334（314 aa）
Fragment：UNP residues 21-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；323 K；0.1 M ammonium acetate, 25% PEG3350, 0.1 M Bis-Tris, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 323K
|
Resolution 2.20 Å R-free 0.220 |
| 3UVM Crystal structure of WDR5 in complex with the WDR5-interacting motif of MLL4 Deposited 2011-11-30 | Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
21–334（314 aa）
Fragment：UNP residues 21-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；298 K；0.1 M ammonium sulfate, 25% PEG3350, 0.1 M Tris, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.57 Å R-free 0.198 |
| 3UVO Crystal structure of WDR5 in complex with the WDR5-interacting motif of SET1B Deposited 2011-11-30 | Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
21–334（314 aa）
Fragment：UNP residues 21-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；298 K；0.1 M ammonium sulfate, 25% PEG3350, 0.1 M Tris, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.20 Å R-free 0.219 |
| 4A7J Symmetric Dimethylation of H3 Arginine 2 is a Novel Histone Mark that Supports Euchromatin Maintenance Deposited 2011-11-14 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
21–334（314 aa）
Fragment：RESIDUES 21-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；0.1 M HEPES PH 7.5; 60 MM AMMONIUM SULPHATE; 30% PEG 3350
|
Resolution 1.90 Å R-free 0.222 |
| 4CY1 Crystal structure of the KANSL1-WDR5 complex. Deposited 2014-04-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
23–334（312 aa）
Fragment：RESIDUES 23-334
|
Not recorded | GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；26% (W/V) PEG 3350, 0.2 M AMMONIUM SULPHATE, 0.1 M BIS-TRIS, PH 6.5.
|
Resolution 1.50 Å R-free 0.183 |
| 4CY1 Crystal structure of the KANSL1-WDR5 complex. Deposited 2014-04-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
23–334（312 aa）
Fragment：RESIDUES 23-334
|
Not recorded | GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；26% (W/V) PEG 3350, 0.2 M AMMONIUM SULPHATE, 0.1 M BIS-TRIS, PH 6.5.
|
Resolution 1.50 Å R-free 0.183 |
| 4CY2 Crystal structure of the KANSL1-WDR5-KANSL2 complex. Deposited 2014-04-09 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
23–334（312 aa）
Fragment：RESIDUES 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.9；20% (W/V) PEG 3350, 0.2 M POTASSIUM NITRATE, PH 6.9.
|
Resolution 2.00 Å R-free 0.222 |
| 4ERQ X-ray structure of WDR5-MLL2 Win motif peptide binary complex Deposited 2012-04-20 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
23–334（312 aa）
Fragment：UNP residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
hanging drop；pH 7.3；294 K；PEG3350, Ammonium Sulfate, HEPES, pH 7.3, hanging drop, temperature 294K
|
Resolution 1.91 Å R-free 0.200 |
| 4ERQ X-ray structure of WDR5-MLL2 Win motif peptide binary complex Deposited 2012-04-20 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
23–334（312 aa）
Fragment：UNP residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
hanging drop；pH 7.3；294 K；PEG3350, Ammonium Sulfate, HEPES, pH 7.3, hanging drop, temperature 294K
|
Resolution 1.91 Å R-free 0.200 |
| 4ERQ X-ray structure of WDR5-MLL2 Win motif peptide binary complex Deposited 2012-04-20 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
23–334（312 aa）
Fragment：UNP residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
hanging drop；pH 7.3；294 K；PEG3350, Ammonium Sulfate, HEPES, pH 7.3, hanging drop, temperature 294K
|
Resolution 1.91 Å R-free 0.200 |
| 4ERY X-ray structure of WDR5-MLL3 Win motif peptide binary complex Deposited 2012-04-21 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
23–334（312 aa）
Fragment：UNP residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
hanging drop；pH 7.5；294 K；PEG3350, Ammonium Sulfate, HEPES, pH 7.5, hanging drop, temperature 294K
|
Resolution 1.30 Å R-free 0.209 |
| 4ERZ X-ray structure of WDR5-MLL4 Win motif peptide binary complex Deposited 2012-04-21 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
23–334（312 aa）
Fragment：UNP residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
hanging drop；pH 7.6；294 K；PEG3350, Ammonium Sulfate, HEPES, pH 7.6, hanging drop, temperature 294K
|
Resolution 1.75 Å R-free 0.216 |
| 4ERZ X-ray structure of WDR5-MLL4 Win motif peptide binary complex Deposited 2012-04-21 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
23–334（312 aa）
Fragment：UNP residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
hanging drop；pH 7.6；294 K；PEG3350, Ammonium Sulfate, HEPES, pH 7.6, hanging drop, temperature 294K
|
Resolution 1.75 Å R-free 0.216 |
| 4ERZ X-ray structure of WDR5-MLL4 Win motif peptide binary complex Deposited 2012-04-21 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
23–334（312 aa）
Fragment：UNP residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
hanging drop；pH 7.6；294 K；PEG3350, Ammonium Sulfate, HEPES, pH 7.6, hanging drop, temperature 294K
|
Resolution 1.75 Å R-free 0.216 |
| 4ES0 X-ray structure of WDR5-SETd1b Win motif peptide binary complex Deposited 2012-04-21 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
23–334（312 aa）
Fragment：UNP residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
hanging drop；pH 7.6；294 K；PEG3350, Ammonium Sulfate, HEPES, pH 7.6, hanging drop, temperature 294K
|
Resolution 1.82 Å R-free 0.242 |
| 4ESG X-ray structure of WDR5-MLL1 Win motif peptide binary complex Deposited 2012-04-23 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
23–334（312 aa）
Fragment：UNP residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
hanging drop；pH 7.2；294 K；PEG3350, Ammonium Sulfate, HEPES, pH 7.2, hanging drop, temperature 294K
|
Resolution 1.70 Å R-free 0.193 |
| 4ESG X-ray structure of WDR5-MLL1 Win motif peptide binary complex Deposited 2012-04-23 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
23–334（312 aa）
Fragment：UNP residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
hanging drop；pH 7.2；294 K；PEG3350, Ammonium Sulfate, HEPES, pH 7.2, hanging drop, temperature 294K
|
Resolution 1.70 Å R-free 0.193 |
| 4EWR X-ray structure of WDR5-SETd1a Win motif peptide binary complex Deposited 2012-04-27 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
23–334（312 aa）
Fragment：UNP residues 23-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
hanging drop；pH 7.6；294 K；PEG3350, Ammonium Sulfate, HEPES, pH 7.6, hanging drop, temperature 294K
|
Resolution 1.50 Å R-free 0.198 |
| 4GM3 Crystal structure of human WD repeat domain 5 with compound MM-101 Deposited 2012-08-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
22–334（313 aa）
Fragment：UNP residues 22-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；293 K；25% PEG4000, 0.2 M ammonium sulfate, 0.1 M sodium acetate, pH 4.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 3.39 Å R-free 0.226 |
| 4GM3 Crystal structure of human WD repeat domain 5 with compound MM-101 Deposited 2012-08-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
22–334（313 aa）
Fragment：UNP residues 22-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；293 K；25% PEG4000, 0.2 M ammonium sulfate, 0.1 M sodium acetate, pH 4.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 3.39 Å R-free 0.226 |
| 4GM3 Crystal structure of human WD repeat domain 5 with compound MM-101 Deposited 2012-08-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
22–334（313 aa）
Fragment：UNP residues 22-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；293 K；25% PEG4000, 0.2 M ammonium sulfate, 0.1 M sodium acetate, pH 4.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 3.39 Å R-free 0.226 |
| 4GM3 Crystal structure of human WD repeat domain 5 with compound MM-101 Deposited 2012-08-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain D
22–334（313 aa）
Fragment：UNP residues 22-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；293 K；25% PEG4000, 0.2 M ammonium sulfate, 0.1 M sodium acetate, pH 4.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 3.39 Å R-free 0.226 |
| 4GM3 Crystal structure of human WD repeat domain 5 with compound MM-101 Deposited 2012-08-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 5 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain E
22–334（313 aa）
Fragment：UNP residues 22-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；293 K；25% PEG4000, 0.2 M ammonium sulfate, 0.1 M sodium acetate, pH 4.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 3.39 Å R-free 0.226 |
| 4GM3 Crystal structure of human WD repeat domain 5 with compound MM-101 Deposited 2012-08-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 6 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain F
22–334（313 aa）
Fragment：UNP residues 22-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；293 K；25% PEG4000, 0.2 M ammonium sulfate, 0.1 M sodium acetate, pH 4.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 3.39 Å R-free 0.226 |
| 4GM3 Crystal structure of human WD repeat domain 5 with compound MM-101 Deposited 2012-08-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 7 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain G
22–334（313 aa）
Fragment：UNP residues 22-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；293 K；25% PEG4000, 0.2 M ammonium sulfate, 0.1 M sodium acetate, pH 4.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 3.39 Å R-free 0.226 |
| 4GM3 Crystal structure of human WD repeat domain 5 with compound MM-101 Deposited 2012-08-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 8 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain H
22–334（313 aa）
Fragment：UNP residues 22-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.6；293 K；25% PEG4000, 0.2 M ammonium sulfate, 0.1 M sodium acetate, pH 4.6, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 3.39 Å R-free 0.226 |
| 4GM8 Crystal structure of human WD repeat domain 5 with compound MM-102 Deposited 2012-08-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
22–334（313 aa）
Fragment：UNP residues 22-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；30% PEG8000, 0.2 M ammonium sulfate, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.60 Å R-free 0.249 |
| 4GM8 Crystal structure of human WD repeat domain 5 with compound MM-102 Deposited 2012-08-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
22–334（313 aa）
Fragment：UNP residues 22-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；30% PEG8000, 0.2 M ammonium sulfate, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.60 Å R-free 0.249 |
| 4GM8 Crystal structure of human WD repeat domain 5 with compound MM-102 Deposited 2012-08-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
22–334（313 aa）
Fragment：UNP residues 22-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；30% PEG8000, 0.2 M ammonium sulfate, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.60 Å R-free 0.249 |
| 4GM8 Crystal structure of human WD repeat domain 5 with compound MM-102 Deposited 2012-08-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain D
22–334（313 aa）
Fragment：UNP residues 22-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；30% PEG8000, 0.2 M ammonium sulfate, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.60 Å R-free 0.249 |
| 4GM9 Crystal structure of human WD repeat domain 5 with compound MM-401 Deposited 2012-08-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
22–334（313 aa）
Fragment：UNP residues 22-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；293 K；30% PEG4000, 0.2 M magnesium chloride, 0.1 M Tris-HCl, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 293.00K
|
Resolution 2.10 Å R-free 0.208 |
| 4GM9 Crystal structure of human WD repeat domain 5 with compound MM-401 Deposited 2012-08-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
22–334（313 aa）
Fragment：UNP residues 22-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；293 K；30% PEG4000, 0.2 M magnesium chloride, 0.1 M Tris-HCl, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 293.00K
|
Resolution 2.10 Å R-free 0.208 |
| 4GMB Crystal structure of human WD repeat domain 5 with compound MM-402 Deposited 2012-08-15 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
22–334（313 aa）
Fragment：UNP residues 22-334
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；25% tert-butanol, 0.1 M Tris, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.78 Å R-free 0.247 |
| 4IA9 Crystal structure of human WD REPEAT DOMAIN 5 in complex with 2-chloro-4-fluoro-3-methyl-N-[2-(4-methylpiperazin-1-yl)-5-nitrophenyl]benzamide Deposited 2012-12-06 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
24–334（311 aa）
|
Not recorded | IA9 2-chloro-4-fluoro-3-methyl-N-[2-(4-methylpiperazin-1-yl)-5-nitrophenyl]benzamide × 1 EDO 1,2-ETHANEDIOL × 2 UNX UNKNOWN LIGAND × 24 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.5；291 K；25% PEH 3500, 0.1 M Ammonium sulfate, 0.1 M BisTris pH5.5, vapor diffusion hanging drop, temperature 291K
|
Resolution 1.66 Å R-free 0.210 |
| 4O45 WDR5 in complex with influenza NS1 C-terminal tail Deposited 2013-12-18 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
Fragment：UNP residues 24-334
|
Not recorded | UNX UNKNOWN LIGAND × 17 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；291 K；25% PEG3350, 0.1 M ammonium sulfate, 0.1 M bis-tris, pH 6.5, temperature 291K
|
Resolution 1.87 Å R-free 0.212 |
| 4QL1 Crystal structure of human WDR5 in complex with compound OICR-9429 Deposited 2014-06-10 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
24–334（311 aa）
|
Not recorded | 35Q N-(4-(4-methylpiperazin-1-yl)-3'-(morpholinomethyl)-[1,1'-biphenyl]-3-yl)-6-oxo-4-(trifluoromethyl)-1,6-dihydropyridine-3-carboxamide × 1 UNX UNKNOWN LIGAND × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；25% PEG 3350, 0.2 M NH4oAC, 0.1 M BisTris pH6.5, vapor diffusion hanging drop, temperature 291K
|
Resolution 1.50 Å R-free 0.227 |
| 4QL1 Crystal structure of human WDR5 in complex with compound OICR-9429 Deposited 2014-06-10 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
24–334（311 aa）
|
Not recorded | 35Q N-(4-(4-methylpiperazin-1-yl)-3'-(morpholinomethyl)-[1,1'-biphenyl]-3-yl)-6-oxo-4-(trifluoromethyl)-1,6-dihydropyridine-3-carboxamide × 1 UNX UNKNOWN LIGAND × 1 EDO 1,2-ETHANEDIOL × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；25% PEG 3350, 0.2 M NH4oAC, 0.1 M BisTris pH6.5, vapor diffusion hanging drop, temperature 291K
|
Resolution 1.50 Å R-free 0.227 |
| 4QQE Crystal structure of WDR5, WD repeat domain 5 in complex with compound SGC-DS-MT-0345 Deposited 2014-06-27 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
24–334（311 aa）
Fragment：UNP residues 24-334
|
Not recorded | 37F N-[2-(4-methylpiperazin-1-yl)-5-(quinolin-3-yl)phenyl]-6-oxo-4-(trifluoromethyl)-1,6-dihydropyridine-3-carboxamide × 1 CL CHLORIDE ION × 1 EDO 1,2-ETHANEDIOL × 3 UNX UNKNOWN LIGAND × 7 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；22% PEG3350, 0.2 M ammonium acetate, 0.1 M Bis-Tris, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.80 Å R-free 0.218 |
| 4Y7R Crystal structure of WDR5 in complex with MYC MbIIIb peptide Deposited 2015-02-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
22–334（313 aa）
|
Not recorded | TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；291 K；0.1 M Tris 7.0, 25% PEG 8K
|
Resolution 1.90 Å R-free 0.188 |
| 5EAL Crystal structure of human WDR5 in complex with compound 9h Deposited 2015-10-16 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
24–334（311 aa）
Fragment：UNP residues 23-334
|
Not recorded | 5ML 3-methyl-~{N}-[2-(4-methylpiperazin-1-yl)-5-quinolin-3-yl-phenyl]benzamide × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 1 EDO 1,2-ETHANEDIOL × 8 UNX UNKNOWN LIGAND × 13 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；20% PEG 5K MME, 0.1 M BisTris pH6.5
|
Resolution 1.80 Å R-free 0.211 |
| 5EAL Crystal structure of human WDR5 in complex with compound 9h Deposited 2015-10-16 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
24–334（311 aa）
Fragment：UNP residues 23-334
|
Not recorded | 5ML 3-methyl-~{N}-[2-(4-methylpiperazin-1-yl)-5-quinolin-3-yl-phenyl]benzamide × 1 EDO 1,2-ETHANEDIOL × 9 UNX UNKNOWN LIGAND × 11 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；20% PEG 5K MME, 0.1 M BisTris pH6.5
|
Resolution 1.80 Å R-free 0.211 |
| 5EAM Crystal structure of human WDR5 in complex with compound 9o Deposited 2015-10-16 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
24–334（311 aa）
Fragment：UNP residues 23-334
|
Not recorded | 5MN ~{N}-[5-(1~{H}-indol-5-yl)-2-(4-methylpiperazin-1-yl)phenyl]-3-methyl-benzamide × 1 EDO 1,2-ETHANEDIOL × 1 UNX UNKNOWN LIGAND × 11 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；25% PEG3350, 0.1M NH4SO4, 0.1 M BisTris pH6.5
|
Resolution 1.80 Å R-free 0.228 |
| 5EAM Crystal structure of human WDR5 in complex with compound 9o Deposited 2015-10-16 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
24–334（311 aa）
Fragment：UNP residues 23-334
|
Not recorded | 5MN ~{N}-[5-(1~{H}-indol-5-yl)-2-(4-methylpiperazin-1-yl)phenyl]-3-methyl-benzamide × 1 EDO 1,2-ETHANEDIOL × 4 UNX UNKNOWN LIGAND × 14 SO4 SULFATE ION × 1 BTB 2-[BIS-(2-HYDROXY-ETHYL)-AMINO]-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；25% PEG3350, 0.1M NH4SO4, 0.1 M BisTris pH6.5
|
Resolution 1.80 Å R-free 0.228 |
| 5EAP Crystal structure of human WDR5 in complex with compound 9e Deposited 2015-10-16 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
24–334（311 aa）
Fragment：UNP residues 23-334
|
Not recorded | 5MO N-[5-(2,3-dihydro-1-benzofuran-5-yl)-2-(4-methylpiperazin-1-yl)phenyl]-3-methylbenzamide × 1 GOL GLYCEROL × 1 CL CHLORIDE ION × 1 EDO 1,2-ETHANEDIOL × 5 UNX UNKNOWN LIGAND × 14 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；28% PEG 2K MME, 0.1 M BisTris pH6.5
|
Resolution 1.73 Å R-free 0.241 |
| 5EAR Crystal structure of human WDR5 in complex with compound 9d Deposited 2015-10-16 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
24–334（311 aa）
Fragment：UNP residues 23-334
|
Not recorded | 5MQ N-[5-(2,3-dihydro-1-benzofuran-7-yl)-2-(4-methylpiperazin-1-yl)phenyl]-3-methylbenzamide × 1 EDO 1,2-ETHANEDIOL × 9 UNX UNKNOWN LIGAND × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.5；291 K；22% PEG 3350, 0.1M NH4SO4, 0.1 M BisTris pH5.5
|
Resolution 1.80 Å R-free 0.185 |
| 5EAR Crystal structure of human WDR5 in complex with compound 9d Deposited 2015-10-16 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
24–334（311 aa）
Fragment：UNP residues 23-334
|
Not recorded | 5MQ N-[5-(2,3-dihydro-1-benzofuran-7-yl)-2-(4-methylpiperazin-1-yl)phenyl]-3-methylbenzamide × 1 EDO 1,2-ETHANEDIOL × 10 UNX UNKNOWN LIGAND × 2 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.5；291 K；22% PEG 3350, 0.1M NH4SO4, 0.1 M BisTris pH5.5
|
Resolution 1.80 Å R-free 0.185 |
| 5M23 Modulation of MLL1 Methyltransferase Activity Deposited 2016-10-11 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | 7DC 4-[(~{E})-[4-[[[(2~{S})-2-[[(2~{S})-2-[[(2~{S})-2-[[(2~{S})-2-azanyl-3-oxidanyl-propanoyl]amino]propanoyl]amino]-5-carbamimidamido-pentanoyl]amino]propanoyl]amino]methyl]phenyl]diazenyl]-~{N}-[(2~{S})-3-methyl-1-oxidanylidene-butan-2-yl]benzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；12.5% w/v PEG 1000, 12.5% w/v PEG 3350, 12.5% v/v MPD 0.02 M carboxylic acid 0.1 M bicine/Trizma base pH 8.5
|
Resolution 1.97 Å R-free 0.214 |
| 5M25 Modulation of MLL1 Methyltransferase Activity Deposited 2016-10-11 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | 7DU (2~{S})-2-[[(2~{S})-2-[[(2~{S})-2-azanyl-3-oxidanyl-propanoyl]amino]propanoyl]amino]-5-carbamimidamido-~{N}-[(2~{S})-1-[[4-[(~{E})-[4-(hydroxymethyl)phenyl]diazenyl]phenyl]methylamino]-1-oxidanylidene-propan-2-yl]pentanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；12.5% w/v PEG 1000, 12.5% w/v PEG 3350, 12.5% v/v MPD 0.02 M carboxylic acid 0.1 M bicine/Trizma base pH 8.5
|
Resolution 2.43 Å R-free 0.248 |
| 5SXM WDR5 in complex with MLL Win motif peptidomimetic Deposited 2016-08-09 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
23–334（312 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；293 K；0.1M sodium citrate pH 5.6, 15% 2-propanol, and 17% PEG 4000, and 10mM ATP
|
Resolution 2.00 Å R-free 0.243 |
| 5SXM WDR5 in complex with MLL Win motif peptidomimetic Deposited 2016-08-09 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
23–334（312 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；293 K；0.1M sodium citrate pH 5.6, 15% 2-propanol, and 17% PEG 4000, and 10mM ATP
|
Resolution 2.00 Å R-free 0.243 |
| 5VFC WDR5 bound to inhibitor MM-589 Deposited 2017-04-07 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
24–334（311 aa）
|
Not recorded | 9BA N-{(3R,6S,9S,12R)-6-ethyl-12-methyl-9-[3-(N'-methylcarbamimidamido)propyl]-2,5,8,11-tetraoxo-3-phenyl-1,4,7,10-tetraazacyclotetradecan-12-yl}-2-methylpropanamide × 1 SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 7 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.1 M Na Bis-Tris pH 6.5, 26% PEG 8000 and 0.1 M ammonium sulfate
|
Resolution 1.64 Å R-free 0.174 |
| 6BYN Crystal structure of WDR5-Mb(S4) monobody complex Deposited 2017-12-21 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain W
31–334（304 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.5；293 K；28% PEG3350, 0.1 M BisTris pH 5.5
|
Resolution 2.69 Å R-free 0.248 |
| 6D9X Discovery of Potent 2-Aryl-6,7-Dihydro-5HPyrrolo[ 1,2-a]imidazoles as WDR5 WIN-site Inhibitors Using Fragment-Based Methods and Structure-Based Design Deposited 2018-04-30 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | NA SODIUM ION × 1 FZM 2-phenyl-6,7-dihydro-5H-pyrrolo[1,2-a]imidazole × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；293 K；0.1 M Bis-Tris pH 6.0, 0.2 M ammonium acetate, 28% to 32% PEG3350
|
Resolution 1.83 Å R-free 0.241 |
| 6DAI Discovery of Potent 2-Aryl-6,7-Dihydro-5HPyrrolo[ 1,2-a]imidazoles as WDR5 WIN-site Inhibitors Using Fragment-Based Methods and Structure-Based Design Deposited 2018-05-01 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | DMS DIMETHYL SULFOXIDE × 2 G2V 6-(6,7-dihydro-5H-pyrrolo[1,2-a]imidazol-2-yl)-1-methylindoline × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；293 K；0.1 M Bis-Tris pH 6.0, 0.2 M ammonium acetate, 28% to 32% PEG3350
|
Resolution 1.63 Å R-free 0.186 |
| 6DAK Discovery of Potent 2-Aryl-6,7-Dihydro-5HPyrrolo[ 1,2-a]imidazoles as WDR5 WIN-site Inhibitors Using Fragment-Based Methods and Structure-Based Design Deposited 2018-05-01 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | G1Y N-{[3-(6,7-dihydro-5H-pyrrolo[1,2-a]imidazol-2-yl)phenyl]methyl}benzamide × 1 DMS DIMETHYL SULFOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；293 K；0.1 M Bis-Tris pH 6.0, 0.2 M ammonium acetate, 28% to 32% PEG3350
|
Resolution 1.60 Å R-free 0.188 |
| 6DAR Discovery of Potent 2-Aryl-6,7-Dihydro-5HPyrrolo[ 1,2-a]imidazoles as WDR5 WIN-site Inhibitors Using Fragment-Based Methods and Structure-Based Design Deposited 2018-05-01 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | G2J N-(cyclopropylmethyl)-N-{[3-(6,7-dihydro-5H-pyrrolo[1,2-a]imidazol-2-yl)phenyl]methyl}-3-methoxybenzamide × 1 SO4 SULFATE ION × 2 DMS DIMETHYL SULFOXIDE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；293 K；0.1 M Bis-Tris pH 6.0, 0.2 M ammonium acetate, 28% to 32% PEG3350
|
Resolution 1.88 Å R-free 0.195 |
| 6DAS Discovery of Potent 2-Aryl-6,7-Dihydro-5HPyrrolo[ 1,2-a]imidazoles as WDR5 WIN-site Inhibitors Using Fragment-Based Methods and Structure-Based Design Deposited 2018-05-01 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | G2D N-[(1R)-6-(6,7-dihydro-5H-pyrrolo[1,2-a]imidazol-2-yl)-2,3-dihydro-1H-inden-1-yl]-3-methoxy-4-methylbenzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；293 K；0.1 M Bis-Tris pH 6.0, 0.2 M ammonium acetate, 28% to 32% PEG3350
|
Resolution 1.80 Å R-free 0.222 |
| 6DAS Discovery of Potent 2-Aryl-6,7-Dihydro-5HPyrrolo[ 1,2-a]imidazoles as WDR5 WIN-site Inhibitors Using Fragment-Based Methods and Structure-Based Design Deposited 2018-05-01 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–334（313 aa）
|
Not recorded | G2D N-[(1R)-6-(6,7-dihydro-5H-pyrrolo[1,2-a]imidazol-2-yl)-2,3-dihydro-1H-inden-1-yl]-3-methoxy-4-methylbenzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；293 K；0.1 M Bis-Tris pH 6.0, 0.2 M ammonium acetate, 28% to 32% PEG3350
|
Resolution 1.80 Å R-free 0.222 |
| 6DY7 WDR5 in complex with a WIN site inhibitor Deposited 2018-07-01 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
31–334（304 aa）
|
Not recorded | HH7 N-[3-(2,4-dichlorophenoxy)propyl]-1H-imidazol-2-amine × 1 DMS DIMETHYL SULFOXIDE × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.1 M Bis-Tris pH 6.0, 0.2 M ammonium acetate, 28% to 32% PEG3350
|
Resolution 1.90 Å R-free 0.199 |
| 6DYA WDR5 in complex with a WIN site inhibitor Deposited 2018-07-01 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
30–334（305 aa）
|
Not recorded | HHM N-[(3,5-dichlorophenyl)methyl]-3-[(1H-imidazol-1-yl)methyl]benzamide × 1 SO4 SULFATE ION × 1 DMS DIMETHYL SULFOXIDE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.1 M Bis-Tris pH 6.0, 0.2 M ammonium acetate, 28% to 32% PEG3350
|
Resolution 2.56 Å R-free 0.230 |
| 6E1Y Discovery of Potent 2-Aryl-6,7-Dihydro-5HPyrrolo[ 1,2-a]imidazoles as WDR5 WIN-site Inhibitors Using Fragment-Based Methods and Structure-Based Design Deposited 2018-07-10 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | HLM N-[(1S)-1-(3-chlorophenyl)ethyl]-3-{[(4,5-dihydro-1H-imidazol-2-yl)amino]methyl}benzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；0.1 M Bis-Tris pH 6.0 or Hepes pH 7.5, 0.2 M ammonium acetate, 28% to 32% PEG3350
|
Resolution 1.22 Å R-free 0.182 |
| 6E1Y Discovery of Potent 2-Aryl-6,7-Dihydro-5HPyrrolo[ 1,2-a]imidazoles as WDR5 WIN-site Inhibitors Using Fragment-Based Methods and Structure-Based Design Deposited 2018-07-10 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–334（313 aa）
|
Not recorded | HLM N-[(1S)-1-(3-chlorophenyl)ethyl]-3-{[(4,5-dihydro-1H-imidazol-2-yl)amino]methyl}benzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；0.1 M Bis-Tris pH 6.0 or Hepes pH 7.5, 0.2 M ammonium acetate, 28% to 32% PEG3350
|
Resolution 1.22 Å R-free 0.182 |
| 6E1Z Displacement of WDR5 from chromatin by a pharmacological WIN site inhibitor with picomolar affinity Deposited 2018-07-10 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | HLP 5-[(1H-imidazol-1-yl)methyl]furan-2-carboxylic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；0.1 M Hepes pH 7.5, 0.2 M ammonium acetate, 28% to 32% PEG3350
|
Resolution 1.10 Å R-free 0.163 |
| 6E1Z Displacement of WDR5 from chromatin by a pharmacological WIN site inhibitor with picomolar affinity Deposited 2018-07-10 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–334（313 aa）
|
Not recorded | HLP 5-[(1H-imidazol-1-yl)methyl]furan-2-carboxylic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；0.1 M Hepes pH 7.5, 0.2 M ammonium acetate, 28% to 32% PEG3350
|
Resolution 1.10 Å R-free 0.163 |
| 6E22 Displacement of WDR5 from chromatin by a pharmacological WIN site inhibitor with picomolar affinity Deposited 2018-07-10 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | HLS 3-{[(4,5-dihydro-1H-imidazol-2-yl)amino]methyl}-N-[(3,5-dimethoxyphenyl)methyl]-4-fluorobenzamide × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.1 M Bis-Tris pH 6.0 or Hepes pH 7.5, 0.2 M ammonium acetate, 28% to 32% PEG3350
|
Resolution 1.60 Å R-free 0.180 |
| 6E22 Displacement of WDR5 from chromatin by a pharmacological WIN site inhibitor with picomolar affinity Deposited 2018-07-10 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–334（313 aa）
|
Not recorded | HLS 3-{[(4,5-dihydro-1H-imidazol-2-yl)amino]methyl}-N-[(3,5-dimethoxyphenyl)methyl]-4-fluorobenzamide × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.1 M Bis-Tris pH 6.0 or Hepes pH 7.5, 0.2 M ammonium acetate, 28% to 32% PEG3350
|
Resolution 1.60 Å R-free 0.180 |
| 6E23 Displacement of WDR5 from chromatin by a pharmacological WIN site inhibitor with picomolar affinity Deposited 2018-07-10 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | HLJ N-[(3,4-dichlorophenyl)methyl]-3-(6-fluoro-2-methylpyridin-3-yl)-5-{[(2E)-2-imino-3-methyl-2,3-dihydro-1H-imidazol-1-yl]methyl}benzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.1 M Bis-Tris pH 6.0 or Hepes pH 7.5, 0.2 M ammonium acetate, 28% to 32% PEG3350
|
Resolution 1.66 Å R-free 0.209 |
| 6E23 Displacement of WDR5 from chromatin by a pharmacological WIN site inhibitor with picomolar affinity Deposited 2018-07-10 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–334（313 aa）
|
Not recorded | HLJ N-[(3,4-dichlorophenyl)methyl]-3-(6-fluoro-2-methylpyridin-3-yl)-5-{[(2E)-2-imino-3-methyl-2,3-dihydro-1H-imidazol-1-yl]methyl}benzamide × 1 EPE 4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.1 M Bis-Tris pH 6.0 or Hepes pH 7.5, 0.2 M ammonium acetate, 28% to 32% PEG3350
|
Resolution 1.66 Å R-free 0.209 |
| 6IAM Modulating Protein-Protein Interactions with Visible Light Peptide Backbone Switches Deposited 2018-11-27 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
29–334（306 aa）
|
Not recorded | K POTASSIUM ION × 3 NA SODIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277.15 K；10% (w/v) PEG20000, 20% (v/v) PEG550 MME, 0.02 M sodium formate, 0.02 M ammonium acetate, 0.02 M trisodium citrate, 0.02 M sodium potassium L-tartrate, 0.02 M sodium oxamate
|
Resolution 1.51 Å R-free 0.170 |
| 6KIU Cryo-EM structure of human MLL1-ubNCP complex (3.2 angstrom) Deposited 2019-07-20 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 13 PDB declaration: pentadecameric |
Chain R
1–334（334 aa）
|
Not recorded | SAH S-ADENOSYL-L-HOMOCYSTEINE × 1 ZN ZINC ION × 1 LYS LYSINE × 1 GLN GLUTAMINE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.20 Å |
| 6KIV Cryo-EM structure of human MLL1-ubNCP complex (4.0 angstrom) Deposited 2019-07-20 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 13 PDB declaration: pentadecameric |
Chain R
1–334（334 aa）
|
Not recorded | SAH S-ADENOSYL-L-HOMOCYSTEINE × 1 ZN ZINC ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.00 Å |
| 6KIW Cryo-EM structure of human MLL3-ubNCP complex (4.0 angstrom) Deposited 2019-07-20 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 13 PDB declaration: pentadecameric |
Chain R
1–334（334 aa）
|
Not recorded | ZN ZINC ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.00 Å |
| 6KIX Cryo-EM structure of human MLL1-NCP complex, binding mode1 Deposited 2019-07-20 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 12 PDB declaration: tetradecameric |
Chain R
1–334（334 aa）
|
Not recorded | SAH S-ADENOSYL-L-HOMOCYSTEINE × 1 ZN ZINC ION × 1 LYS LYSINE × 1 GLN GLUTAMINE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.10 Å |
| 6KIZ Cryo-EM structure of human MLL1-NCP complex, binding mode2 Deposited 2019-07-20 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 12 PDB declaration: tetradecameric |
Chain R
1–334（334 aa）
|
Not recorded | SAH S-ADENOSYL-L-HOMOCYSTEINE × 1 ZN ZINC ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.50 Å |
| 6OFZ Crystal structure of human WDR5 Deposited 2019-04-01 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.9；295 K；100 mM Bis-Tris pH5.9, 32% PEG3350,
54.6 mM Ammonium Sulfate
|
Resolution 1.85 Å R-free 0.250 |
| 6OI0 Crystal structure of human WDR5 in complex with L-arginine Deposited 2019-04-08 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | ARG ARGININE × 1 SO4 SULFATE ION × 2 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.9；295 K；100 mM Bis-Tris pH 5.9; 32% PEG3350, 54.6 mM Ammonium Sulfate, 0.66 mM L-arginine
|
Resolution 1.92 Å R-free 0.201 |
| 6OI1 Crystal structure of human WDR5 in complex with monomethyl L-arginine Deposited 2019-04-08 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | SO4 SULFATE ION × 1 GOL GLYCEROL × 2 NMM (2S)-2-amino-5-[(N-methylcarbamimidoyl)amino]pentanoic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.9；295 K；100mM Bis-Tris pH 5.9, 32% PEG3350,
54.6 mM Ammonium Sulfate, 0.66 mM monomethyl L-arginine
|
Resolution 1.68 Å R-free 0.236 |
| 6OI2 Crystal structure of human WDR5 in complex with symmetric dimethyl-L-arginine Deposited 2019-04-08 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | SO4 SULFATE ION × 3 GOL GLYCEROL × 3 2MR N3, N4-DIMETHYLARGININE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.9；295 K；100 mM Bis-Tris pH5.9, 32% PEG3350,
54.6 mM Ammonium Sulfate, 0.66 mM symmetric dimethyl-L-arginine
|
Resolution 1.68 Å R-free 0.223 |
| 6OI3 Crystal structure of human WDR5 in complex with monomethyl H3R2 peptide Deposited 2019-04-08 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
22–334（313 aa）
|
Not recorded | GOL GLYCEROL × 3 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.9；295 K；100 mM Bis-Tris pH 5.9, 32% PEG3350, 54.6 mM Ammonium Sulfate, 1.67 mM monomethyl H3R2 peptide
|
Resolution 1.66 Å R-free 0.202 |
| 6PG3 WDR5delta23 bound to (2-butyl-1H-imidazol-4-yl)methanol Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | OHJ (2-butyl-1H-imidazol-4-yl)methanol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.182 M ammonium fluoride, 0.1 M sodium cacodylate (pH 5.79), 22.1 %w/v PEG8000
|
Resolution 2.04 Å R-free 0.206 |
| 6PG3 WDR5delta23 bound to (2-butyl-1H-imidazol-4-yl)methanol Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–334（313 aa）
|
Not recorded | OHJ (2-butyl-1H-imidazol-4-yl)methanol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.182 M ammonium fluoride, 0.1 M sodium cacodylate (pH 5.79), 22.1 %w/v PEG8000
|
Resolution 2.04 Å R-free 0.206 |
| 6PG4 WDR5delta32 bound to (2-methyl-1H-imidazol-4-yl)methanol Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
32–334（303 aa）
|
Not recorded | OHG (2-methyl-1H-imidazol-4-yl)methanol × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.114 M ammonium sulfate, 0.1 M bis-tris chloride (pH 6.11), 25.8 %w/v PEG8000
|
Resolution 1.60 Å R-free 0.176 |
| 6PG5 WDR5delta32 bound to benzyl (4-(5-(hydroxymethyl)-1H-imidazol-2-yl)butyl)carbamate Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
32–334（303 aa）
|
Not recorded | OHV benzyl {4-[5-(hydroxymethyl)-1H-imidazol-2-yl]butyl}carbamate × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.215 M ammonium sulfate, 0.1 M sodium cacodylate (pH 7.06), 25.6 %w/v PEG8000
|
Resolution 1.99 Å R-free 0.202 |
| 6PG6 WDR5delta23 bound to N-(4-(5-(hydroxymethyl)-1H-imidazol-2-yl)butyl)acetamide Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | SO4 SULFATE ION × 1 OH7 N-{4-[4-(hydroxymethyl)-1H-imidazol-2-yl]butyl}acetamide × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.215 M ammonium sulfate, 0.1 M sodium cacodylate (pH 7.06), 25.6 %w/v PEG8000
|
Resolution 1.68 Å R-free 0.193 |
| 6PG6 WDR5delta23 bound to N-(4-(5-(hydroxymethyl)-1H-imidazol-2-yl)butyl)acetamide Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–334（313 aa）
|
Not recorded | SO4 SULFATE ION × 1 OH7 N-{4-[4-(hydroxymethyl)-1H-imidazol-2-yl]butyl}acetamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.215 M ammonium sulfate, 0.1 M sodium cacodylate (pH 7.06), 25.6 %w/v PEG8000
|
Resolution 1.68 Å R-free 0.193 |
| 6PG7 WDR5delta32 bound to (2-(3-methoxy-3-phenylpropyl)-1H-imidazol-4-yl)methanol Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
32–334（303 aa）
|
Not recorded | OH4 {2-[(3S)-3-methoxy-3-phenylpropyl]-1H-imidazol-4-yl}methanol × 1 PEG DI(HYDROXYETHYL)ETHER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.17 M ammonium sulfate, 0.1 bis-tris chloride (pH 6.3), 30.5 %w/v PEG4000
|
Resolution 2.45 Å R-free 0.243 |
| 6PG8 WDR5delta23 bound to (2-(3-phenylpropyl)-1H-imidazol-4-yl)methanol Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | OGY [2-(3-phenylpropyl)-1H-imidazol-4-yl]methanol × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.179 M ammonium sulfate, 0.1 M bis-tris chloride (pH 5.62), 28.6 %w/v PEG3350
|
Resolution 1.67 Å R-free 0.207 |
| 6PG8 WDR5delta23 bound to (2-(3-phenylpropyl)-1H-imidazol-4-yl)methanol Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–334（313 aa）
|
Not recorded | OGY [2-(3-phenylpropyl)-1H-imidazol-4-yl]methanol × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.179 M ammonium sulfate, 0.1 M bis-tris chloride (pH 5.62), 28.6 %w/v PEG3350
|
Resolution 1.67 Å R-free 0.207 |
| 6PG8 WDR5delta23 bound to (2-(3-phenylpropyl)-1H-imidazol-4-yl)methanol Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
22–334（313 aa）
|
Not recorded | OGY [2-(3-phenylpropyl)-1H-imidazol-4-yl]methanol × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.179 M ammonium sulfate, 0.1 M bis-tris chloride (pH 5.62), 28.6 %w/v PEG3350
|
Resolution 1.67 Å R-free 0.207 |
| 6PG8 WDR5delta23 bound to (2-(3-phenylpropyl)-1H-imidazol-4-yl)methanol Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
22–334（313 aa）
|
Not recorded | OGY [2-(3-phenylpropyl)-1H-imidazol-4-yl]methanol × 1 CL CHLORIDE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.179 M ammonium sulfate, 0.1 M bis-tris chloride (pH 5.62), 28.6 %w/v PEG3350
|
Resolution 1.67 Å R-free 0.207 |
| 6PG9 WDR5delta23 bound to N-(4-(5-(hydroxymethyl)-1H-imidazol-2-yl)butyl)benzamide Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | OH1 N-{4-[4-(hydroxymethyl)-1H-imidazol-2-yl]butyl}benzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.182 M ammonium fluoride, 0.1 soidum cacodylate (pH 5.79), 22.1 %w/v PEG8000
|
Resolution 1.75 Å R-free 0.269 |
| 6PG9 WDR5delta23 bound to N-(4-(5-(hydroxymethyl)-1H-imidazol-2-yl)butyl)benzamide Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–334（313 aa）
|
Not recorded | OH1 N-{4-[4-(hydroxymethyl)-1H-imidazol-2-yl]butyl}benzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.182 M ammonium fluoride, 0.1 soidum cacodylate (pH 5.79), 22.1 %w/v PEG8000
|
Resolution 1.75 Å R-free 0.269 |
| 6PGA WDR5delta32 bound to methyl (4-(4-(hydroxymethyl)-1H-imidazol-2-yl)butyl)carbamate Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
32–334（303 aa）
|
Not recorded | OGM methyl {4-[5-(hydroxymethyl)-1H-imidazol-2-yl]butyl}carbamate × 1 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.237 M ammonium sulfate, 0.1 M bis-tris chloride, 25.7 %w/v MPEG5000
|
Resolution 2.45 Å R-free 0.250 |
| 6PGB WDR5delta32 bound to N-(4-(5-(hydroxymethyl)-1H-imidazol-2-yl)butyl)-2-phenylacetamide Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
32–334（303 aa）
Fragment：UNP residues 32-334
|
Not recorded | OJG N-{4-[5-(hydroxymethyl)-1H-imidazol-2-yl]butyl}-2-phenylacetamide × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.101 M ammonium sulfate, 0.1 M Bis-Tris chloride, pH 5.63, 25.8% w/v PEG4000
|
Resolution 1.73 Å R-free 0.217 |
| 6PGC WDR5delta32 bound to methyl benzyl(4-(4-(hydroxymethyl)-1H-imidazol-2-yl)butyl)carbamate Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
32–334（303 aa）
Fragment：UNP residues 32-334
|
Not recorded | SO4 SULFATE ION × 2 OJJ methyl benzyl{4-[4-(hydroxymethyl)-1H-imidazol-2-yl]butyl}carbamate × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.237 M ammonium sulfate, 0.1 M Bis-Tris chloride, pH 6.92, 25.7% w/v MPEG5000
|
Resolution 1.81 Å R-free 0.248 |
| 6PGD WDR5delta32 bound to peptidomimetic Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
32–334（303 aa）
Fragment：UNP residues 32-334
|
Not recorded | OK4 N-acetyl-L-alanyl-5-[5-(hydroxymethyl)-1H-imidazol-2-yl]-L-norvalyl-L-valinamide × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.233 M ammonium sulfate, 0.1 M Bis-Tris chloride, pH 6.02, 26% w/v PEG8000
|
Resolution 1.50 Å R-free 0.167 |
| 6PGE WDR5delta32 bound to ethyl 3-(4-(hydroxymethyl)-1H-imidazol-2-yl)propanoate Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
32–334（303 aa）
Fragment：UNP residues 32-334
|
Not recorded | OJM ethyl 3-[4-(hydroxymethyl)-1H-imidazol-2-yl]propanoate × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.024 M ammonium sulfate, 0.1 M Bis-Tris chloride, pH 5.64, 26.3% w/v PEG4000
|
Resolution 1.76 Å R-free 0.213 |
| 6PGF WDR5delta32 bound to N-(4-(4-(hydroxymethyl)-1H-imidazol-2-yl)butyl)acrylamide Deposited 2019-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
32–334（303 aa）
Fragment：UNP residues 32-334
|
Not recorded | OJP N-{4-[4-(hydroxymethyl)-1H-imidazol-2-yl]butyl}prop-2-enamide × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；281 K；0.16 M ammonium sulfate, 0.1 M Bis-Tris chloride, pH 6.1, 30.1% w/v PEG8000
|
Resolution 1.54 Å R-free 0.170 |
| 6PWV Cryo-EM structure of MLL1 core complex bound to the nucleosome Deposited 2019-07-23 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 14 PDB declaration: hexadecameric |
Chain B
22–334（313 aa）
|
Not recorded | SAH S-ADENOSYL-L-HOMOCYSTEINE × 2 ZN ZINC ION × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 6.20 Å |
| 6PWW Cryo-EM structure of MLL1 in complex with RbBP5 and WDR5 bound to the nucleosome Deposited 2019-07-23 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 11 PDB declaration: tridecameric |
Chain B
22–334（313 aa）
|
Not recorded | SAH S-ADENOSYL-L-HOMOCYSTEINE × 1 ZN ZINC ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.40 Å |
| 6U5M Discovery and optimization of salicyclic acid-derived sulfonamide inhibitors of the WDR5:MYC protein-protein interaction Deposited 2019-08-28 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
31–334（304 aa）
|
Not recorded | Q0S 5-bromo-2-hydroxy-N-[3-(methylsulfonyl)-5-(pentafluoro-lambda~6~-sulfanyl)phenyl]benzene-1-sulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris, ammonium acetate, PEG 3350
|
Resolution 1.80 Å R-free 0.186 |
| 6U5M Discovery and optimization of salicyclic acid-derived sulfonamide inhibitors of the WDR5:MYC protein-protein interaction Deposited 2019-08-28 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
31–334（304 aa）
|
Not recorded | Q0S 5-bromo-2-hydroxy-N-[3-(methylsulfonyl)-5-(pentafluoro-lambda~6~-sulfanyl)phenyl]benzene-1-sulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris, ammonium acetate, PEG 3350
|
Resolution 1.80 Å R-free 0.186 |
| 6U5Y Discovery and optimization of salicyclic acid-derived sulfonamide inhibitors of the WDR5:MYC protein-protein interaction Deposited 2019-08-28 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
31–334（304 aa）
|
Not recorded | Q0M 3-{[(5-bromo-3-chloro-2-hydroxyphenyl)sulfonyl]amino}-5-(1-cyanocyclobutyl)-2-hydroxy-N-methylbenzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris pH 6.5, 0.2 M ammonium acetate, 28% PEG 3350
|
Resolution 1.53 Å R-free 0.177 |
| 6U5Y Discovery and optimization of salicyclic acid-derived sulfonamide inhibitors of the WDR5:MYC protein-protein interaction Deposited 2019-08-28 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
31–334（304 aa）
|
Not recorded | Q0M 3-{[(5-bromo-3-chloro-2-hydroxyphenyl)sulfonyl]amino}-5-(1-cyanocyclobutyl)-2-hydroxy-N-methylbenzamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris pH 6.5, 0.2 M ammonium acetate, 28% PEG 3350
|
Resolution 1.53 Å R-free 0.177 |
| 6U6W Discovery and optimization of salicyclic acid-derived sulfonamide inhibitors of the WDR5:MYC protein-protein interaction Deposited 2019-08-30 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
24–334（311 aa）
|
Not recorded | Q0Y 5-bromo-N-(5-chloro-2-hydroxyphenyl)-2-methoxybenzene-1-sulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris pH 6.5, 0.2M ammonium acetate, PEG3350
|
Resolution 1.20 Å R-free 0.179 |
| 6U6W Discovery and optimization of salicyclic acid-derived sulfonamide inhibitors of the WDR5:MYC protein-protein interaction Deposited 2019-08-30 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
24–334（311 aa）
|
Not recorded | Q0Y 5-bromo-N-(5-chloro-2-hydroxyphenyl)-2-methoxybenzene-1-sulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris pH 6.5, 0.2M ammonium acetate, PEG3350
|
Resolution 1.20 Å R-free 0.179 |
| 6U80 Discovery and optimization of salicyclic acid-derived sulfonamide inhibitors of the WDR5:MYC protein-protein interaction Deposited 2019-09-04 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
24–334（311 aa）
|
Not recorded | Q1J 5-bromo-N-(4-hydroxy[1,1'-biphenyl]-3-yl)-2-methoxybenzene-1-sulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris, Ammonium Acetate, PEG 3350
|
Resolution 1.55 Å R-free 0.203 |
| 6U80 Discovery and optimization of salicyclic acid-derived sulfonamide inhibitors of the WDR5:MYC protein-protein interaction Deposited 2019-09-04 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
24–334（311 aa）
|
Not recorded | Q1J 5-bromo-N-(4-hydroxy[1,1'-biphenyl]-3-yl)-2-methoxybenzene-1-sulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris, Ammonium Acetate, PEG 3350
|
Resolution 1.55 Å R-free 0.203 |
| 6U8B Discovery and optimization of salicyclic acid-derived sulfonamide inhibitors of the WDR5:MYC protein-protein interaction Deposited 2019-09-04 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
24–334（311 aa）
|
Not recorded | Q1M 3-{[(5-bromo-2-methoxyphenyl)sulfonyl]amino}-5-chloro-2-hydroxybenzoic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris, ammonium acetate, PEG 3350
|
Resolution 1.26 Å R-free 0.159 |
| 6U8B Discovery and optimization of salicyclic acid-derived sulfonamide inhibitors of the WDR5:MYC protein-protein interaction Deposited 2019-09-04 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
24–334（311 aa）
|
Not recorded | Q1M 3-{[(5-bromo-2-methoxyphenyl)sulfonyl]amino}-5-chloro-2-hydroxybenzoic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris, ammonium acetate, PEG 3350
|
Resolution 1.26 Å R-free 0.159 |
| 6U8L Discovery and optimization of salicyclic acid-derived sulfonamide inhibitors of the WDR5:MYC protein-protein interaction Deposited 2019-09-05 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
31–334（304 aa）
|
Not recorded | Q1P 3-{[(5-bromo-2-hydroxyphenyl)sulfonyl]amino}-5-cyclopropyl-6-fluoro-2-hydroxybenzoic acid × 1 Q1S N-[2-(4-methylpiperazin-1-yl)-5-nitrophenyl]isoquinolin-1-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris, Ammonium acetate, PEG 3350
|
Resolution 1.57 Å R-free 0.176 |
| 6U8L Discovery and optimization of salicyclic acid-derived sulfonamide inhibitors of the WDR5:MYC protein-protein interaction Deposited 2019-09-05 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
31–334（304 aa）
|
Not recorded | Q1P 3-{[(5-bromo-2-hydroxyphenyl)sulfonyl]amino}-5-cyclopropyl-6-fluoro-2-hydroxybenzoic acid × 1 Q1S N-[2-(4-methylpiperazin-1-yl)-5-nitrophenyl]isoquinolin-1-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris, Ammonium acetate, PEG 3350
|
Resolution 1.57 Å R-free 0.176 |
| 6U8O Discovery and optimization of salicyclic acid-derived sulfonamide inhibitors of the WDR5:MYC protein-protein interaction Deposited 2019-09-05 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
31–334（304 aa）
|
Not recorded | Q1G 5-bromo-N-[5-(1-cyanocyclobutyl)-2-hydroxyphenyl]-2-hydroxybenzene-1-sulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris, ammonium acetate, PEG 3350
|
Resolution 1.60 Å R-free 0.184 |
| 6UCS Discovery and Structure-Based optimization of potent and selective WDR5 inhibitors containing a dihydroisoquinolinone bicyclic core Deposited 2019-09-17 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | Q41 2-amino-3-{[(5P)-2-[(3,5-dimethoxyphenyl)methyl]-5-(4-fluoro-2-methylphenyl)-1-oxo-1,2,3,4-tetrahydroisoquinolin-7-yl]methyl}-1-methyl-1H-imidazol-3-ium × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris, Ammonium Acetate, PEG 3350
|
Resolution 1.85 Å R-free 0.194 |
| 6UCS Discovery and Structure-Based optimization of potent and selective WDR5 inhibitors containing a dihydroisoquinolinone bicyclic core Deposited 2019-09-17 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–334（313 aa）
|
Not recorded | Q41 2-amino-3-{[(5P)-2-[(3,5-dimethoxyphenyl)methyl]-5-(4-fluoro-2-methylphenyl)-1-oxo-1,2,3,4-tetrahydroisoquinolin-7-yl]methyl}-1-methyl-1H-imidazol-3-ium × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris, Ammonium Acetate, PEG 3350
|
Resolution 1.85 Å R-free 0.194 |
| 6UFX WD repeat-containing protein 5 complexed with N-[(3,5-dimethoxyphenyl)methyl]-4'-fluoro-5-{[(2E)-2-imino-3-methyl-2,3-dihydro-1H-imidazol-1-yl]methyl}-2'-methyl[1,1'-biphenyl]-3-carboxamide (compound 13) Deposited 2019-09-25 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
32–334（303 aa）
Fragment：UNP residues 32-334
|
Not recorded | Q6S N-[(3,5-dimethoxyphenyl)methyl]-4'-fluoro-5-{[(2E)-2-imino-3-methyl-2,3-dihydro-1H-imidazol-1-yl]methyl}-2'-methyl[1,1'-biphenyl]-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M Bis-Tris or HEPES or Tris-HCl, pH 6.0-8.0, 0.2 M ammonium acetate, 20-30% PEG3350
|
Resolution 2.02 Å R-free 0.208 |
| 6UHY WDR5 in complex with Myc site fragment inhibitor Deposited 2019-09-29 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
31–334（304 aa）
|
Not recorded | Q8G 1-cyclohexyl-1H-benzimidazole-5-carboxylic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；0.1 M Bis-Tris pH 6.0, 0.2 M ammonium
acetate, 28% to 32% PEG3350.
|
Resolution 1.26 Å R-free 0.181 |
| 6UHY WDR5 in complex with Myc site fragment inhibitor Deposited 2019-09-29 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
31–334（304 aa）
|
Not recorded | Q8G 1-cyclohexyl-1H-benzimidazole-5-carboxylic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；0.1 M Bis-Tris pH 6.0, 0.2 M ammonium
acetate, 28% to 32% PEG3350.
|
Resolution 1.26 Å R-free 0.181 |
| 6UHZ WDR5 in complex with Myc site fragment inhibitor Deposited 2019-09-29 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
31–334（304 aa）
|
Not recorded | Q8D 1-cyclohexyl-1H-benzotriazole-5-carboxylic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；0.1 M Bis-Tris pH 6.0, 0.2 M ammonium acetate, 28% PEG3350
|
Resolution 1.26 Å R-free 0.176 |
| 6UHZ WDR5 in complex with Myc site fragment inhibitor Deposited 2019-09-29 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
31–334（304 aa）
|
Not recorded | Q8D 1-cyclohexyl-1H-benzotriazole-5-carboxylic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；0.1 M Bis-Tris pH 6.0, 0.2 M ammonium acetate, 28% PEG3350
|
Resolution 1.26 Å R-free 0.176 |
| 6UIF Discovery of fragment-inspired heterocyclic benzenesulfonmides as inhibitors of the WDR5-MYC interaction Deposited 2019-09-30 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
31–334（304 aa）
|
Not recorded | Q8P 4-{[(5-bromo-3-chloro-2-hydroxyphenyl)sulfonyl]amino}-1-cyclopentyl-N-methyl-1H-imidazole-2-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris, Ammonium acetate, PEG 3350
|
Resolution 1.60 Å R-free 0.194 |
| 6UIF Discovery of fragment-inspired heterocyclic benzenesulfonmides as inhibitors of the WDR5-MYC interaction Deposited 2019-09-30 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
31–334（304 aa）
|
Not recorded | Q8P 4-{[(5-bromo-3-chloro-2-hydroxyphenyl)sulfonyl]amino}-1-cyclopentyl-N-methyl-1H-imidazole-2-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris, Ammonium acetate, PEG 3350
|
Resolution 1.60 Å R-free 0.194 |
| 6UIK Discovery of fragment-inspired heterocyclic benzenesulfonmides as inhibitors of the WDR5-MYC interaction Deposited 2019-10-01 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
31–334（304 aa）
|
Not recorded | Q8M 5-bromo-3-chloro-N-(1-cyclopentyl-1H-imidazol-4-yl)-2-hydroxybenzene-1-sulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris 6.5, 0.2 M Ammonium Acetate, 28% PEG 3350
|
Resolution 1.60 Å R-free 0.182 |
| 6UIK Discovery of fragment-inspired heterocyclic benzenesulfonmides as inhibitors of the WDR5-MYC interaction Deposited 2019-10-01 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
31–334（304 aa）
|
Not recorded | Q8M 5-bromo-3-chloro-N-(1-cyclopentyl-1H-imidazol-4-yl)-2-hydroxybenzene-1-sulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris 6.5, 0.2 M Ammonium Acetate, 28% PEG 3350
|
Resolution 1.60 Å R-free 0.182 |
| 6UJ4 Discovery of fragment-inspired heterocyclic benzenesulfonmides as inhibitors of the WDR5-MYC interaction Deposited 2019-10-02 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
31–334（304 aa）
|
Not recorded | Q8S 5-bromo-3-chloro-N-(1-cyclopentyl-2-methyl-1H-imidazol-4-yl)-2-hydroxybenzene-1-sulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris 6.5, 0.2 M Ammonium acetate, 28% PEG 3350
|
Resolution 1.53 Å R-free 0.177 |
| 6UJ4 Discovery of fragment-inspired heterocyclic benzenesulfonmides as inhibitors of the WDR5-MYC interaction Deposited 2019-10-02 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
31–334（304 aa）
|
Not recorded | Q8S 5-bromo-3-chloro-N-(1-cyclopentyl-2-methyl-1H-imidazol-4-yl)-2-hydroxybenzene-1-sulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris 6.5, 0.2 M Ammonium acetate, 28% PEG 3350
|
Resolution 1.53 Å R-free 0.177 |
| 6UJH Discovery of fragment-inspired heterocyclic benzenesulfonamides as inhibitors of the WDR5-MYC interaction Deposited 2019-10-03 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | QBS (2R)-2-(4-chlorophenyl)-3-oxobutanenitrile × 1 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；0.1 M Hepes, 0.2 M ammonium acetate, 32% PEG3350
|
Resolution 1.49 Å R-free 0.169 |
| 6UJH Discovery of fragment-inspired heterocyclic benzenesulfonamides as inhibitors of the WDR5-MYC interaction Deposited 2019-10-03 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–334（313 aa）
|
Not recorded | QBS (2R)-2-(4-chlorophenyl)-3-oxobutanenitrile × 1 SO4 SULFATE ION × 1 DMS DIMETHYL SULFOXIDE × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；0.1 M Hepes, 0.2 M ammonium acetate, 32% PEG3350
|
Resolution 1.49 Å R-free 0.169 |
| 6UJJ Discovery of fragment-inspired heterocyclic benzenesulfonamides as inhibitors of the WDR5-MYC interaction Deposited 2019-10-03 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | QBP 5-[4-(trifluoromethyl)phenyl]-1H-tetrazole × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.1 M Hepes, 0.2 M ammonium acetate, 32% PEG3350
|
Resolution 1.73 Å R-free 0.190 |
| 6UJL Discovery of fragment-inspired heterocyclic benzenesulfonamides as inhibitors of the WDR5-MYC interaction Deposited 2019-10-03 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | QBM 6-methyl-3-(propylsulfanyl)-1,2,4-triazin-5-ol × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.1 M Hepes, 0.2 M ammonium acetate, 32% PEG3350
|
Resolution 1.60 Å R-free 0.183 |
| 6UOZ Discovery of fragment-inspired heterocyclic benzenesulfonmides as inhibitors of the WDR5-MYC interaction Deposited 2019-10-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
31–334（304 aa）
Chain B
31–334（304 aa）
|
Not recorded | QF1 5-bromo-3-chloro-N-[1-cyclopentyl-2-(methylsulfonyl)-1H-imidazol-4-yl]-2-hydroxybenzene-1-sulfonamide × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris, ammonium acetate, PEG 3350
|
Resolution 1.53 Å R-free 0.169 |
| 6W5I Cryo-EM structure of MLL1 in complex with RbBP5, WDR5, SET1, and ASH2L bound to the nucleosome (Class01) Deposited 2020-03-13 | Different construct Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 12 PDB declaration: tetradecameric |
Chain B
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 6.90 Å |
| 6W5M Cryo-EM structure of MLL1 in complex with RbBP5, WDR5, SET1, and ASH2L bound to the nucleosome (Class02) Deposited 2020-03-13 | Different construct Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 12 PDB declaration: tetradecameric |
Chain B
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.60 Å |
| 6W5N Cryo-EM structure of MLL1 in complex with RbBP5, WDR5, SET1, and ASH2L bound to the nucleosome (Class05) Deposited 2020-03-13 | Different construct Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 12 PDB declaration: tetradecameric |
Chain B
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 6.00 Å |
| 6WJQ Crystal structure of WDR5 in complex with the WIN peptide of PDPK1 Deposited 2020-04-14 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；291 K；PEG 3350, Ammonium Acetate, Bis-tris
|
Resolution 2.71 Å R-free 0.252 |
| 6WJQ Crystal structure of WDR5 in complex with the WIN peptide of PDPK1 Deposited 2020-04-14 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；291 K；PEG 3350, Ammonium Acetate, Bis-tris
|
Resolution 2.71 Å R-free 0.252 |
| 7AXP Structural characterisation of WDR5:CS-VIP8 interaction in cis state 2 Deposited 2020-11-10 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–334（334 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277.15 K；10% (w/v) PEG20000, 20% (v/v) PEG550 MME, 0.02 M sodium formate, 0.02 M ammonium acetate, 0.02 M trisodium citrate, 0.02 M sodium potassium L-tartrate, 0.02 M sodium oxamate
|
Resolution 2.43 Å R-free 0.331 |
| 7AXQ Structure of the cryo-trapped WDR5:CS-VIP8 cocrystal after illumination at 405 nm and 180 K Deposited 2020-11-10 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–334（334 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277.15 K；10% (w/v) PEG20000, 20% (v/v) PEG550 MME, 0.02 M sodium formate, 0.02 M ammonium acetate, 0.02 M trisodium citrate, 0.02 M sodium potassium L-tartrate, 0.02 M sodium oxamate
|
Resolution 1.56 Å R-free 0.200 |
| 7AXS Structural characterisation of WDR5:CS-VIP8 interaction in cis state 1 Deposited 2020-11-10 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–334（334 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277.15 K；10% (w/v) PEG20000, 20% (v/v) PEG550 MME, 0.02 M sodium formate, 0.02 M ammonium acetate, 0.02 M trisodium citrate, 0.02 M sodium potassium L-tartrate, 0.02 M sodium oxamate
|
Resolution 1.88 Å R-free 0.235 |
| 7AXU Structure of WDR5:CS-VIP8 cocrystal after illumination in situ Deposited 2020-11-10 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–334（334 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277.15 K；10% (w/v) PEG20000, 20% (v/v) PEG550 MME, 0.02 M sodium formate, 0.02 M ammonium acetate, 0.02 M trisodium citrate, 0.02 M sodium potassium L-tartrate, 0.02 M sodium oxamate
|
Resolution 1.68 Å R-free 0.193 |
| 7AXX Structure of WDR5:CS-VIP8 crystal after illumination at 405 nm and room temperature Deposited 2020-11-10 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–334（334 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；277.15 K；10% (w/v) PEG20000, 20% (v/v) PEG550 MME, 0.02 M sodium formate, 0.02 M ammonium acetate, 0.02 M trisodium citrate, 0.02 M sodium potassium L-tartrate, 0.02 M sodium oxamate
|
Resolution 1.79 Å R-free 0.214 |
| 7BCY X-ray structure of WDR5delta24 bound to the Kaposi's sarcoma herpesvirus LANA win motif peptide Deposited 2020-12-21 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
25–334（310 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；294 K；100 mM Bis-Tris pH 5.5, 50 mM (NH4)2SO4, 25% PEG3350
|
Resolution 1.50 Å R-free 0.227 |
| 7BCY X-ray structure of WDR5delta24 bound to the Kaposi's sarcoma herpesvirus LANA win motif peptide Deposited 2020-12-21 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
25–334（310 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；294 K；100 mM Bis-Tris pH 5.5, 50 mM (NH4)2SO4, 25% PEG3350
|
Resolution 1.50 Å R-free 0.227 |
| 7BED X-ray structure of WDR5 bound to the WDR5 win motif peptide Deposited 2020-12-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
1–334（334 aa）
Chain B
1–334（334 aa）
|
Not recorded | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.5；294 K；26% PEG 3350, 100mM Bis-Tris pH 5.5, 50mM (NH4)2SO4,WDR5 at 14,65 mg/ml with 2:1 (protein:well) drop ratio.
|
Resolution 1.26 Å R-free 0.171 |
| 7CFP Crystal structure of WDR5 in complex with a H3Q5ser peptide Deposited 2020-06-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–334（334 aa）
|
Not recorded | SRO SEROTONIN × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；295 K；0.1% Octylglucoside, 0.1M Sodium citrate tribasic dihydrate pH 5.5, 22% PEG 3350
|
Resolution 1.60 Å R-free 0.199 |
| 7CFQ Crystal structure of WDR5 in complex with H3K4me3Q5ser peptide Deposited 2020-06-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–334（334 aa）
|
Not recorded | GOL GLYCEROL × 1 EDO 1,2-ETHANEDIOL × 1 SRO SEROTONIN × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；295 K；0.15M ammonium sulfate, 0.1M MES pH 5.5, 25% PEG 4000, 2% PEG 3350
|
Resolution 1.60 Å R-free 0.190 |
| 7DNO Characterization of Peptide Ligands Against WDR5 Isolated Using Phage Display Technique Deposited 2020-12-10 | Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
24–334（311 aa）
Chain B
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；291 K；0.1 M BisTris pH 6.0, 0.2M ammonium acetate, 20-30% PEG3350
|
Resolution 2.03 Å R-free 0.227 |
| 7JTO Crystal structure of Protac MS33 in complex with the WD repeat-containing protein 5 and pVHL:ElonginC:ElonginB Deposited 2020-08-18 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain B
31–334（304 aa）
|
Not recorded | SCN THIOCYANATE ION × 4 EDO 1,2-ETHANEDIOL × 5 VKA 3-methyl-N-(11-{[2-(4-{[4'-(4-methylpiperazin-1-yl)-3'-{[6-oxo-4-(trifluoromethyl)-5,6-dihydropyridine-3-carbonyl]amino}[1,1'-biphenyl]-3-yl]methyl}piperazin-1-yl)ethyl]amino}-11-oxoundecanoyl)-L-valyl-(4R)-4-hydroxy-N-{[4-(4-methyl-1,3-thiazol-5-yl)phenyl]methyl}-L-prolinamide × 1 GOL GLYCEROL × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293.15 K；0.1 M HEPES sodium, pH 7.5-8.0, 1.3-1.6 M sodium thiocyanate, 15-20% PEG3350
|
Resolution 1.70 Å R-free 0.225 |
| 7JTP Crystal structure of Protac MS67 in complex with the WD repeat-containing protein 5 and pVHL:ElonginC:ElonginB Deposited 2020-08-18 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
31–334（304 aa）
|
Not recorded | GOL GLYCEROL × 1 X6M N-(6-fluoro-3'-{[6-oxo-4-(trifluoromethyl)-1,6-dihydropyridine-3-carbonyl]amino}-4'-[(3R,5S)-3,4,5-trimethylpiperazin-1-yl][1,1'-biphenyl]-3-carbonyl)glycyl-3-methyl-L-valyl-(4R)-4-hydroxy-N-{(1S)-1-[4-(4-methyl-1,3-thiazol-5-yl)phenyl]ethyl}-L-prolinamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；293.15 K；0.1 M Tris, pH 8.5, 30% PEG300
|
Resolution 2.12 Å R-free 0.224 |
| 7MBM Cryo-EM structure of MLL1-NCP (H3K4M) complex, mode01 Deposited 2021-04-01 | Different construct Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 12 PDB declaration: tetradecameric |
Chain B
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.76 Å |
| 7MBN Cryo-EM structure of MLL1-NCP (H3K4M) complex, mode02 Deposited 2021-04-01 | Different construct Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 12 PDB declaration: tetradecameric |
Chain B
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.02 Å |
| 7Q2J Quaternary Complex of human WDR5 and pVHL:ElonginC:ElonginB bound to PROTAC Homer Deposited 2021-10-25 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain D
24–334（311 aa）
|
Not recorded | 8KH N-[5-[4-[[5-[[(2S)-3,3-dimethyl-1-[(2S,4R)-2-[[4-(4-methyl-1,3-thiazol-5-yl)phenyl]methylcarbamoyl]-4-oxidanyl-pyrrolidin-1-yl]-1-oxidanylidene-butan-2-yl]amino]-5-oxidanylidene-pentyl]carbamoyl]phenyl]-2-(4-methylpiperazin-1-yl)phenyl]-6-oxidanylidene-4-(trifluoromethyl)-1H-pyridine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.8；293 K；21% PEG 3350
0.4 M KSCN
0.1 M HEPES 6.8
|
Resolution 2.50 Å R-free 0.293 |
| 7U9Y WDR5 bound to 2-(3,5-dimethoxybenzyl)-7-((2-methyl-1H-imidazol-1-yl)methyl)-5-(1-methyl-3-(trifluoromethyl)-1H-pyrazol-4-yl)-3,4-dihydroisoquinolin-1(2H)-one Deposited 2022-03-11 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
30–334（305 aa）
|
Not recorded | BEN BENZAMIDINE × 1 M4U (5P)-2-[(3,5-dimethoxyphenyl)methyl]-7-[(2-methyl-1H-imidazol-1-yl)methyl]-5-[1-methyl-3-(trifluoromethyl)-1H-pyrazol-4-yl]-3,4-dihydroisoquinolin-1(2H)-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；BIS-Tris, ammonium acetate, PEG 3350, benzamidine
|
Resolution 1.90 Å R-free 0.189 |
| 7UAS Discovery of Potent Orally Bioavailable WD Repeat Domain 5 (WDR5) Inhibitors Using a Pharmacophore-Based Optimization Deposited 2022-03-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | MBU (5P)-2-[(S)-cyclopropyl(4-methylpyridin-2-yl)methyl]-5-[1-ethyl-3-(trifluoromethyl)-1H-pyrazol-4-yl]-7-[(2-methyl-1H-imidazol-1-yl)methyl]-3,4-dihydroisoquinolin-1(2H)-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris, Ammonium Acetate, PEG 3350
|
Resolution 1.81 Å R-free 0.175 |
| 7UAS Discovery of Potent Orally Bioavailable WD Repeat Domain 5 (WDR5) Inhibitors Using a Pharmacophore-Based Optimization Deposited 2022-03-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–334（313 aa）
|
Not recorded | MBU (5P)-2-[(S)-cyclopropyl(4-methylpyridin-2-yl)methyl]-5-[1-ethyl-3-(trifluoromethyl)-1H-pyrazol-4-yl]-7-[(2-methyl-1H-imidazol-1-yl)methyl]-3,4-dihydroisoquinolin-1(2H)-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；Bis-Tris, Ammonium Acetate, PEG 3350
|
Resolution 1.81 Å R-free 0.175 |
| 7UD5 Complex between MLL1-WRAD and an H2B-ubiquitinated nucleosome Deposited 2022-03-18 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 15 PDB declaration: heptadecameric |
Chain L
2–334（333 aa）
|
Not recorded | SAH S-ADENOSYL-L-HOMOCYSTEINE × 1 ZN ZINC ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.25 Å |
| 7WVK Crystal structure of human WDR5 in complex with compound 19 Deposited 2022-02-10 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | 6IQ 1-[2,5-bis(chloranyl)phenyl]sulfonylbenzimidazole × 1 GOL GLYCEROL × 4 EDO 1,2-ETHANEDIOL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；291 K；0.1M Bis-Tris, 0.2 M NH4OAC, 30% PEG3350
|
Resolution 1.42 Å R-free 0.182 |
| 8BB2 Structure of human WDR5 and pVHL:ElonginC:ElonginB bound to PROTAC with PEG linker (conformation #2) Deposited 2022-10-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain B
33–334（302 aa）
|
Not recorded | SCN THIOCYANATE ION × 5 Q3X ~{N}-[5-[4-[2-[2-[2-[2-[3-[[3,3-dimethyl-1-[(2~{S},4~{R})-2-[[4-(4-methyl-1,3-thiazol-5-yl)phenyl]methylcarbamoyl]-4-oxidanyl-pyrrolidin-1-yl]-1-oxidanylidene-butan-2-yl]amino]-3-oxidanylidene-propoxy]ethoxy]ethoxy]ethoxy]ethylcarbamoyl]phenyl]-2-(4-methylpiperazin-1-yl)phenyl]-6-oxidanylidene-4-(trifluoromethyl)-3~{H}-pyridine-3-carboxamide × 1 EDO 1,2-ETHANEDIOL × 7 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.8；293 K；21-28% PEG 3350 0.4-1 M KSCN 0.1 M HEPES 6.8
|
Resolution 2.05 Å R-free 0.237 |
| 8BB3 Structure of human WDR5 and pVHL:ElonginC:ElonginB bound to PROTAC with PEG linker (conformation #1) Deposited 2022-10-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain B
33–334（302 aa）
|
Not recorded | SCN THIOCYANATE ION × 15 EDO 1,2-ETHANEDIOL × 13 P6G HEXAETHYLENE GLYCOL × 1 Q3X ~{N}-[5-[4-[2-[2-[2-[2-[3-[[3,3-dimethyl-1-[(2~{S},4~{R})-2-[[4-(4-methyl-1,3-thiazol-5-yl)phenyl]methylcarbamoyl]-4-oxidanyl-pyrrolidin-1-yl]-1-oxidanylidene-butan-2-yl]amino]-3-oxidanylidene-propoxy]ethoxy]ethoxy]ethoxy]ethylcarbamoyl]phenyl]-2-(4-methylpiperazin-1-yl)phenyl]-6-oxidanylidene-4-(trifluoromethyl)-3~{H}-pyridine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.8；293 K；21-26% PEG 3350 0.4-1 M KSCN 0.1 M HEPES
|
Resolution 1.80 Å R-free 0.227 |
| 8BB4 Structure of human WDR5 and pVHL:ElonginC:ElonginB bound to PROTAC with C3 linker Deposited 2022-10-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain Q
33–334（302 aa）
|
Not recorded | Q3R ~{N}-[5-[4-[[4-[[(2~{S})-3,3-dimethyl-1-[(2~{S},4~{R})-2-[[4-(4-methyl-1,3-thiazol-5-yl)phenyl]methylcarbamoyl]-4-oxidanyl-pyrrolidin-1-yl]-1-oxidanylidene-butan-2-yl]amino]-4-oxidanylidene-butyl]carbamoyl]phenyl]-2-(4-methylpiperazin-1-yl)phenyl]-6-oxidanyl-4-(trifluoromethyl)pyridine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.8；293 K；21-28% PEG 3350 0.4 M KSCN 0.1 M HEPES pH 6.8
|
Resolution 2.80 Å R-free 0.279 |
| 8BB5 Structure of human WDR5 and pVHL:ElonginC:ElonginB bound to PROTAC with Aryl linker Deposited 2022-10-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain D
33–334（302 aa）
|
Not recorded | SCN THIOCYANATE ION × 10 Q43 ~{N}-[5-[4-[[4-[2-[[(2~{S})-3,3-dimethyl-1-[(2~{S},4~{R})-2-[[4-(4-methyl-1,3-thiazol-5-yl)phenyl]methylcarbamoyl]-4-oxidanyl-pyrrolidin-1-yl]-1-oxidanylidene-butan-2-yl]amino]-2-oxidanylidene-ethyl]phenyl]methylcarbamoyl]phenyl]-2-(4-methylpiperazin-1-yl)phenyl]-6-oxidanyl-4-(trifluoromethyl)pyridine-3-carboxamide × 1 EDO 1,2-ETHANEDIOL × 4 K POTASSIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；21% PEG 3350, 0.4-1 M KSCN 0.1 M HEPES pH 6.8
|
Resolution 2.20 Å R-free 0.248 |
| 8DU4 Complex between RbBP5-WDR5 and an H2B-ubiquitinated nucleosome Deposited 2022-07-26 | Different construct Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 11 PDB declaration: tridecameric |
Chain L
2–334（333 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.55 Å |
| 8E9F WD repeat-containing protein 5 complexed with 4-(7-((1H-imidazol-1-yl)methyl)-5-(1-methyl-3-(trifluoromethyl)-1H-pyrazol-4-yl)-1-oxo-3,4-dihydroisoquinolin-2(1H)-yl)-6-ethyl-N-methylquinoline-8-carboxamide (compound 10) Deposited 2022-08-26 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
30–334（305 aa）
|
Not recorded | BEN BENZAMIDINE × 1 UY9 6-ethyl-4-[(5P)-7-[(1H-imidazol-1-yl)methyl]-5-[1-methyl-3-(trifluoromethyl)-1H-pyrazol-4-yl]-1-oxo-3,4-dihydroisoquinolin-2(1H)-yl]-N-methylquinoline-8-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；BIS-Tris, ammonium acetate, PEG 3350, benzamidine
|
Resolution 1.55 Å R-free 0.184 |
| 8F1G Crystal structure of human WDR5 in complex with compound WM662 Deposited 2022-11-05 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | X8N (2S)-2-({(2S)-3-(3'-chloro[1,1'-biphenyl]-4-yl)-1-oxo-1-[(1H-tetrazol-5-yl)amino]propan-2-yl}oxy)propanoic acid × 1 GOL GLYCEROL × 4 SO4 SULFATE ION × 1 PGE TRIETHYLENE GLYCOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.1 M HEPES pH=7.4, 25 mM ammonium sulfate, 24% w/v Polyethylene glycol 3350
|
Resolution 2.14 Å R-free 0.249 |
| 8F1G Crystal structure of human WDR5 in complex with compound WM662 Deposited 2022-11-05 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–334（313 aa）
|
Not recorded | X8N (2S)-2-({(2S)-3-(3'-chloro[1,1'-biphenyl]-4-yl)-1-oxo-1-[(1H-tetrazol-5-yl)amino]propan-2-yl}oxy)propanoic acid × 1 GOL GLYCEROL × 3 SO4 SULFATE ION × 1 PGE TRIETHYLENE GLYCOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.1 M HEPES pH=7.4, 25 mM ammonium sulfate, 24% w/v Polyethylene glycol 3350
|
Resolution 2.14 Å R-free 0.249 |
| 8F93 WDR5 covalently modified at Y228 by (R)-2-SF Deposited 2022-11-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: monomeric |
Chain A
22–334（313 aa）
Chain B
22–334（313 aa）
|
Not recorded | XKN 3-ethynyl-5-{[(3R)-4-{1-[(2-methoxyphenyl)methyl]-1H-benzimidazole-5-carbonyl}-3-methylpiperazin-1-yl]methyl}benzene-1-sulfonyl fluoride × 2 GOL GLYCEROL × 4 SO4 SULFATE ION × 2 CL CHLORIDE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；0.2 M Ammonium sulfate, 0.1 M MES pH 6.5, 20% w/v PEG 8000
|
Resolution 2.30 Å R-free 0.253 |
| 8F93 WDR5 covalently modified at Y228 by (R)-2-SF Deposited 2022-11-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: monomeric |
Chain A
22–334（313 aa）
Chain B
22–334（313 aa）
|
Not recorded | XKN 3-ethynyl-5-{[(3R)-4-{1-[(2-methoxyphenyl)methyl]-1H-benzimidazole-5-carbonyl}-3-methylpiperazin-1-yl]methyl}benzene-1-sulfonyl fluoride × 2 GOL GLYCEROL × 4 SO4 SULFATE ION × 2 CL CHLORIDE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；0.2 M Ammonium sulfate, 0.1 M MES pH 6.5, 20% w/v PEG 8000
|
Resolution 2.30 Å R-free 0.253 |
| 8G3C Crystal structure of human WDR5 in complex with N-[(2'-cyano[1,1'-biphenyl]-4-yl)methyl]-3-hydroxy-6-methyl-4-oxo-4H-pyran-2-carboxamide (compound 1, WDR5-MYC PPI inhibitor) Deposited 2023-02-07 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | YJN N-[(2'-cyano[1,1'-biphenyl]-4-yl)methyl]-3-hydroxy-6-methyl-4-oxo-4H-pyran-2-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；294 K；20% PEG3350, 0.2 M potassium acetate
|
Resolution 1.80 Å R-free 0.224 |
| 8G3E Crystal structure of human WDR5 in complex with (1M)-N-[(3,5-difluoro[1,1'-biphenyl]-4-yl)methyl]-6-methyl-4-oxo-1-(pyridin-3-yl)-1,4-dihydropyridazine-3-carboxamide (compound 2, WDR5-MYC inhibitor) Deposited 2023-02-07 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | YJR (1M)-N-[(3,5-difluoro[1,1'-biphenyl]-4-yl)methyl]-6-methyl-4-oxo-1-(pyridin-3-yl)-1,4-dihydropyridazine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；294 K；23.5% PEG3350, 0.21 M ammonium sulfate, 0.1 M HEPES, pH 7.5
|
Resolution 1.33 Å R-free 0.170 |
| 8G3E Crystal structure of human WDR5 in complex with (1M)-N-[(3,5-difluoro[1,1'-biphenyl]-4-yl)methyl]-6-methyl-4-oxo-1-(pyridin-3-yl)-1,4-dihydropyridazine-3-carboxamide (compound 2, WDR5-MYC inhibitor) Deposited 2023-02-07 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–334（313 aa）
|
Not recorded | YJR (1M)-N-[(3,5-difluoro[1,1'-biphenyl]-4-yl)methyl]-6-methyl-4-oxo-1-(pyridin-3-yl)-1,4-dihydropyridazine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；294 K；23.5% PEG3350, 0.21 M ammonium sulfate, 0.1 M HEPES, pH 7.5
|
Resolution 1.33 Å R-free 0.170 |
| 8HMX WDR5 in complex with histone H3Q5his peptide Deposited 2022-12-06 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
31–334（304 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M sodium citrate tribasic dihydrate (pH 5.5), 22% polyethylene glycol (PEG) 3350, and 0.1% n-Octyl-beta-D-glucoside
|
Resolution 1.70 Å R-free 0.193 |
| 8Q1N Cyclic peptide binder of the WBM-site of WDR5 Deposited 2023-08-01 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；0.2M Li3-Citrate, 20 w/v% PEG3350
|
Resolution 1.84 Å R-free 0.243 |
| 8Q1N Cyclic peptide binder of the WBM-site of WDR5 Deposited 2023-08-01 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；0.2M Li3-Citrate, 20 w/v% PEG3350
|
Resolution 1.84 Å R-free 0.243 |
| 8T5I Crystal structure of human WDR5 in complex with MR4397 Deposited 2023-06-13 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
24–334（311 aa）
Fragment：UNP residues 23-334
|
Not recorded | ZHF N-[(2S)-1-(6,7-dihydrothieno[3,2-c]pyridin-5(4H)-yl)-1-oxopentan-2-yl]-3-[(1H-imidazol-1-yl)methyl]benzamide × 1 EDO 1,2-ETHANEDIOL × 3 UNX UNKNOWN LIGAND × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；291 K；25% PEG3350, 0.2 M (NH4)2SO4, 0.1M BTP pH 7.0
|
Resolution 1.70 Å R-free 0.232 |
| 8T5I Crystal structure of human WDR5 in complex with MR4397 Deposited 2023-06-13 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
24–334（311 aa）
Fragment：UNP residues 23-334
|
Not recorded | ZHF N-[(2S)-1-(6,7-dihydrothieno[3,2-c]pyridin-5(4H)-yl)-1-oxopentan-2-yl]-3-[(1H-imidazol-1-yl)methyl]benzamide × 1 EDO 1,2-ETHANEDIOL × 5 UNX UNKNOWN LIGAND × 1 PEG DI(HYDROXYETHYL)ETHER × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；291 K；25% PEG3350, 0.2 M (NH4)2SO4, 0.1M BTP pH 7.0
|
Resolution 1.70 Å R-free 0.232 |
| 8UJY Crystal structure of human WD repeat-containing protein 5 in complex with 4-(3,5-dimethoxybenzyl)-9-(4-fluoro-2-methylphenyl)-7-((2-imino-3-methyl-2,3-dihydro-1H-imidazol-1-yl)methyl)-3,4-dihydrobenzo[f][1,4]oxazepin-5(2H)-one (compound 8) Deposited 2023-10-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
Fragment：UNP residues 23-334
Chain B
24–334（311 aa）
Fragment：UNP residues 23-334
|
Not recorded | VV3 (9P)-4-[(3,5-dimethoxyphenyl)methyl]-9-(4-fluoro-2-methylphenyl)-7-{[(2E)-2-imino-3-methyl-2,3-dihydro-1H-imidazol-1-yl]methyl}-3,4-dihydro-1,4-benzoxazepin-5(2H)-one × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；291 K；0.1 M Bis-Tris pH 7.0, 0.2 M ammonium acetate, 25% PEG3350
|
Resolution 2.01 Å R-free 0.232 |
| 8WXQ Structure of WDR5 in complex with WIN motif containing MBD3C Deposited 2023-10-30 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；291 K；0.1 M HEPES (pH 7.5), 18% PEG 600
|
Resolution 1.90 Å R-free 0.209 |
| 8WXQ Structure of WDR5 in complex with WIN motif containing MBD3C Deposited 2023-10-30 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；291 K；0.1 M HEPES (pH 7.5), 18% PEG 600
|
Resolution 1.90 Å R-free 0.209 |
| 8WXR Structure of WDR5 in complex with WIN motif containing MBD3C F47A Deposited 2023-10-30 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2 M potassium dihydrogen phosphate, 20% PEG 3350
|
Resolution 2.08 Å R-free 0.199 |
| 8WXR Structure of WDR5 in complex with WIN motif containing MBD3C F47A Deposited 2023-10-30 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2 M potassium dihydrogen phosphate, 20% PEG 3350
|
Resolution 2.08 Å R-free 0.199 |
| 8WXT Structure of WDR5 in complex with WIN motif containing MBD3C R45E/V46G Deposited 2023-10-30 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；291 K；0.2 M imidazole malate, pH 5.5, 33% PEG 600
|
Resolution 1.83 Å R-free 0.179 |
| 8WXU Structure of WDR5 in complex with WIN motif containing MBD3C C44S/R45E/V46G Deposited 2023-10-30 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2 M lithium chloride, 20% PEG 3350
|
Resolution 2.37 Å R-free 0.233 |
| 8WXV Structure of WDR5 in complex with WIN motif containing SET1B Deposited 2023-10-30 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；291 K；0.1 M Bis-Tris, pH 5.5, 25% PEG 3350
|
Resolution 2.40 Å R-free 0.205 |
| 8WXV Structure of WDR5 in complex with WIN motif containing SET1B Deposited 2023-10-30 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；291 K；0.1 M Bis-Tris, pH 5.5, 25% PEG 3350
|
Resolution 2.40 Å R-free 0.205 |
| 8WXX Structure of WDR5 in complex with WIN motif containing SET1B E1750R/G1751V Deposited 2023-10-30 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；291 K；0.1 M sodium citrate, pH 5.5, 16% PEG 4000, 10% 2-propanol
|
Resolution 2.10 Å R-free 0.212 |
| 8WXX Structure of WDR5 in complex with WIN motif containing SET1B E1750R/G1751V Deposited 2023-10-30 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；291 K；0.1 M sodium citrate, pH 5.5, 16% PEG 4000, 10% 2-propanol
|
Resolution 2.10 Å R-free 0.212 |
| 8X3R Crystal structure of human WDR5 in complex with WDR5 Deposited 2023-11-14 | Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
1–334（334 aa）
Chain B
1–334（334 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；289 K；0.1 M magnesium formate dihydrate, 15% w/v polyethylene glycol 3350
|
Resolution 1.76 Å R-free 0.205 |
| 8X3S Crystal structure of human WDR5 in complex with PTEN Deposited 2023-11-14 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
21–334（314 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；289 K；0.2 M lithium sulfate monohydrate, 0.1 M HEPES at pH 7.5, 25% w/v polyethylene glycol 3350
|
Resolution 1.87 Å R-free 0.259 |
| 9B9H Crystal structure of the ternary complex of DCAF1 and WDR5 with PROTAC, OICR-40333 Deposited 2024-04-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | A1AM2 N-{(1P)-5'-({(17E)-18-[(3P)-4-{[(1S)-3-amino-1-(3-chloro-4-fluorophenyl)-3-oxopropyl]carbamoyl}-3-(4-chloro-2-fluorophenyl)-1H-pyrrol-2-yl]-16-oxo-3,6,9,12-tetraoxa-15-azaoctadec-17-en-1-yl}carbamoyl)-2'-fluoro-4-[(3R,5S)-3,4,5-trimethylpiperazin-1-yl][1,1'-biphenyl]-3-yl}-6-oxo-4-(trifluoromethyl)-1,6-dihydropyridine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；294 K；5% w/v 1-ethyl-3-methylimidazolium ethyl sulfate, 15% w/v polyethylene glycol 20,000, pH 7.9
|
Resolution 2.06 Å R-free 0.229 |
| 9B9T Crystal structure of the ternary complex of DCAF1 and WDR5 with PROTAC, OICR-40407 Deposited 2024-04-03 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | A1ANM N-{(1P)-5'-[(17-{(4P)-4-[(2P)-4-{[(1R)-3-amino-1-(3-chloro-4-fluorophenyl)-3-oxopropyl]carbamoyl}-3-(4-chloro-2-fluorophenyl)-1H-pyrrol-2-yl]-1H-pyrazol-1-yl}-16-oxo-3,6,9,12-tetraoxa-15-azaheptadecan-1-yl)carbamoyl]-2'-fluoro-4-[(3R,5S)-3,4,5-trimethylpiperazin-1-yl][1,1'-biphenyl]-3-yl}-6-oxo-4-(trifluoromethyl)-1,6-dihydropyridine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；294 K；0.1 M sodium acetate trihydrate, pH 4.6, 2.0 M sodium formate
|
Resolution 2.05 Å R-free 0.196 |
| 9B9W Crystal structure of the ternary complex of DCAF1 and WDR5 with PROTAC, OICR-40792 Deposited 2024-04-03 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | A1ANN (4P)-N-[(1R)-3-amino-1-(3-chloro-4-fluorophenyl)-3-oxopropyl]-4-(4-chloro-2-fluorophenyl)-5-[(25E)-1-{(1P)-6-fluoro-3'-[4-fluoro-2-(trifluoromethyl)benzamido]-4'-[(3R,5S)-3,4,5-trimethylpiperazin-1-yl][1,1'-biphenyl]-3-yl}-1,24-dioxo-5,8,11,14,17,20-hexaoxa-2,23-diazahexacos-25-en-26-yl]-1H-pyrrole-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；294 K；35% v/v tacsimate, pH 7.0
|
Resolution 1.92 Å R-free 0.183 |
| 9BA2 Crystal structure of the binary complex of DCAF1 and WDR5 Deposited 2024-04-03 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
24–334（311 aa）
|
Not recorded | IMD IMIDAZOLE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；294 K；0.2 M imidazole, pH 7.4, 20% w/v polyethylene glycol 4,000
|
Resolution 2.97 Å R-free 0.266 |
| 9D5Z Crystal structure of the human WDR5 in complex with LH168 compound Deposited 2024-08-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
24–334（311 aa）
Fragment：UNP residues 23-334
|
Not recorded | A1A16 (3P)-N-[(2S)-1-(6,7-dihydrothieno[3,2-c]pyridin-5(4H)-yl)-1-oxopentan-2-yl]-3-[1-ethyl-3-(trifluoromethyl)-1H-pyrazol-4-yl]-5-[(1H-imidazol-1-yl)methyl]benzamide × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；20% PEG3350, 0.2 M Ammonium formate
|
Resolution 1.70 Å R-free 0.189 |
| 9D5Z Crystal structure of the human WDR5 in complex with LH168 compound Deposited 2024-08-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
24–334（311 aa）
Fragment：UNP residues 23-334
|
Not recorded | A1A16 (3P)-N-[(2S)-1-(6,7-dihydrothieno[3,2-c]pyridin-5(4H)-yl)-1-oxopentan-2-yl]-3-[1-ethyl-3-(trifluoromethyl)-1H-pyrazol-4-yl]-5-[(1H-imidazol-1-yl)methyl]benzamide × 1 EDO 1,2-ETHANEDIOL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；20% PEG3350, 0.2 M Ammonium formate
|
Resolution 1.70 Å R-free 0.189 |
| 9DLW Crystal structure of the ternary complex of DCAF1 and WDR5 with PROTAC, OICR-41114 Deposited 2024-09-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | A1BAF N-{(1P)-5'-({(32E)-33-[(3P)-4-{[(1S)-3-amino-1-(3-chloro-4-fluorophenyl)-3-oxopropyl]carbamoyl}-3-(4-chloro-2-fluorophenyl)-1H-pyrrol-2-yl]-31-oxo-3,6,9,12,15,18,21,24,27-nonaoxa-30-azatritriacont-32-en-1-yl}carbamoyl)-2'-fluoro-4-[(3R,5S)-3,4,5-trimethylpiperazin-1-yl][1,1'-biphenyl]-3-yl}-6-oxo-4-(trifluoromethyl)-1,6-dihydropyridine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.9；294 K；1.8 M Sodium phosphate monobasic monohydrate, potassium phosphate dibasic / pH 6.9
|
Resolution 2.07 Å R-free 0.242 |
| 9IY5 WDR5 inhibitor complex Deposited 2024-07-30 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–334（334 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.5；289 K；Bis-tris pH 5.5 25% PEG 4000
|
Resolution 1.80 Å R-free 0.255 |
| 9IY5 WDR5 inhibitor complex Deposited 2024-07-30 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
1–334（334 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.5；289 K；Bis-tris pH 5.5 25% PEG 4000
|
Resolution 1.80 Å R-free 0.255 |
| 9J20 Structure of WDR5 in complex with KIF2A Deposited 2024-08-06 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
24–334（311 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；0.1 M HEPES (pH 7.5) and 18% PEG 600
|
Resolution 1.85 Å R-free 0.206 |
| 9J20 Structure of WDR5 in complex with KIF2A Deposited 2024-08-06 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；0.1 M HEPES (pH 7.5) and 18% PEG 600
|
Resolution 1.85 Å R-free 0.206 |
| 9JWV Structure of WDR5 Y191F in complex with WIN motif containing Kif2A Deposited 2024-10-10 | Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Mutation：Y191F | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；291 K；0.1 M HEPES (pH 7.5), 18% PEG 600
|
Resolution 1.80 Å R-free 0.211 |
| 9JWV Structure of WDR5 Y191F in complex with WIN motif containing Kif2A Deposited 2024-10-10 | Different construct Different mutation/modification Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
24–334（311 aa）
|
Mutation：Y191F | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；291 K；0.1 M HEPES (pH 7.5), 18% PEG 600
|
Resolution 1.80 Å R-free 0.211 |
| 9KD4 Structure of WDR5 in complex with WIN motif containing Kif2A 114-120 Deposited 2024-11-03 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2 M Ammonium acetate, 0.1 M Sodium acetate pH=4, 15% PEG 4000
|
Resolution 1.64 Å R-free 0.204 |
| 9KD4 Structure of WDR5 in complex with WIN motif containing Kif2A 114-120 Deposited 2024-11-03 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2 M Ammonium acetate, 0.1 M Sodium acetate pH=4, 15% PEG 4000
|
Resolution 1.64 Å R-free 0.204 |
| 9KD5 Structure of WDR5 in complex with WIN motif containing Kif2A S121G Deposited 2024-11-03 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2 M imidazole malate, pH=5.5, 24% PEG 600
|
Resolution 1.80 Å R-free 0.216 |
| 9KD5 Structure of WDR5 in complex with WIN motif containing Kif2A S121G Deposited 2024-11-03 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2 M imidazole malate, pH=5.5, 24% PEG 600
|
Resolution 1.80 Å R-free 0.216 |
| 9KFM Structure of WDR5 in complex with WIN motif containing EMBOW Deposited 2024-11-06 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M sodium cacodylate, pH 5.5, 25% (w/v) PEG 4000
|
Resolution 1.80 Å R-free 0.201 |
| 9KFM Structure of WDR5 in complex with WIN motif containing EMBOW Deposited 2024-11-06 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M sodium cacodylate, pH 5.5, 25% (w/v) PEG 4000
|
Resolution 1.80 Å R-free 0.201 |
| 9KFN Structure of WDR5 in complex with mutated EMBOW T3V Deposited 2024-11-06 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2 M imidazole malate, pH 8.5, 12.5 % (w/v) PEG 10000.
|
Resolution 2.80 Å R-free 0.241 |
| 9KFO Structure of WDR5 in complex with mutated EMBOW Deposited 2024-11-06 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.1 M sodium HEPES, pH 7.0, 15 % (w/v) PEG 4000.
|
Resolution 2.20 Å R-free 0.190 |
| 9KQS Crystal structure of WDR5 in complex with peptide MRTEPRPPAP of EMBOW Deposited 2024-11-26 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；291.15 K；0.2 M Ammonium acetate, 0.1 M BIS-TRIS pH 5.5, 25% w/v Polyethylene glycol 3,350
|
Resolution 1.72 Å R-free 0.210 |
| 9L0T Structure of WDR5 in complex with WIN motif containing RBM15 Deposited 2024-12-12 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2 M imidazole malate, pH 6.0, and 15 % (w/v) PEG 4000
|
Resolution 2.05 Å R-free 0.245 |
| 9L0T Structure of WDR5 in complex with WIN motif containing RBM15 Deposited 2024-12-12 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2 M imidazole malate, pH 6.0, and 15 % (w/v) PEG 4000
|
Resolution 2.05 Å R-free 0.245 |
| 9L0V Structure of WDR5 in complex with WIN motif containing ZSCAN10 Deposited 2024-12-13 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M sodium citrate, pH 4.5, and 20 % (w/v) PEG 4000
|
Resolution 2.00 Å R-free 0.220 |
| 9LWY Crystal structure of human WDR5 in complex with compound 4 Deposited 2025-02-17 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | GOL GLYCEROL × 1 A1EMB 4-[[2-(6-fluoranyl-2-methyl-pyridin-3-yl)-6-(5-methyl-1,3-thiazol-2-yl)pyridin-4-yl]methyl]-1-methyl-imidazol-2-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；PEG3350, Bis-Tris, ammonium acetate
|
Resolution 1.55 Å R-free 0.191 |
| 9NCT Crystal Structure of WDR5 in complex with Triazole-Based Inhibitors Deposited 2025-02-17 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | A1BW7 4-({6-cyclopropyl-8-[(2-methyl-1H-imidazol-1-yl)methyl]-4,5-dihydro-3H-naphtho[1,2-d][1,2,3]triazol-3-yl}methyl)-2-methoxybenzonitrile × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；289.15 K；Ammonium Acetate, PEG 3350, Bis-TRS, TRIS, or HEPES
|
Resolution 2.11 Å R-free 0.228 |
| 9NCT Crystal Structure of WDR5 in complex with Triazole-Based Inhibitors Deposited 2025-02-17 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–334（313 aa）
|
Not recorded | A1BW7 4-({6-cyclopropyl-8-[(2-methyl-1H-imidazol-1-yl)methyl]-4,5-dihydro-3H-naphtho[1,2-d][1,2,3]triazol-3-yl}methyl)-2-methoxybenzonitrile × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；289.15 K；Ammonium Acetate, PEG 3350, Bis-TRS, TRIS, or HEPES
|
Resolution 2.11 Å R-free 0.228 |
| 9NCV Crystal Structure of WDR5 in complex with Triazole-Based Inhibitors Deposited 2025-02-17 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | A1BW8 (6P)-6-[1-ethyl-3-(trifluoromethyl)-1H-pyrazol-4-yl]-3-[(4-fluoro-3-methylphenyl)methyl]-8-[(2-methyl-1H-imidazol-1-yl)methyl]-4,5-dihydro-3H-naphtho[1,2-d][1,2,3]triazole × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；289.15 K；ammonium acetate, PEG3350, Bis-TRIS, TRIS, HEPES
|
Resolution 1.58 Å R-free 0.287 |
| 9NCV Crystal Structure of WDR5 in complex with Triazole-Based Inhibitors Deposited 2025-02-17 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–334（313 aa）
|
Not recorded | A1BW8 (6P)-6-[1-ethyl-3-(trifluoromethyl)-1H-pyrazol-4-yl]-3-[(4-fluoro-3-methylphenyl)methyl]-8-[(2-methyl-1H-imidazol-1-yl)methyl]-4,5-dihydro-3H-naphtho[1,2-d][1,2,3]triazole × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；289.15 K；ammonium acetate, PEG3350, Bis-TRIS, TRIS, HEPES
|
Resolution 1.58 Å R-free 0.287 |
| 9NCV Crystal Structure of WDR5 in complex with Triazole-Based Inhibitors Deposited 2025-02-17 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
22–334（313 aa）
|
Not recorded | A1BW8 (6P)-6-[1-ethyl-3-(trifluoromethyl)-1H-pyrazol-4-yl]-3-[(4-fluoro-3-methylphenyl)methyl]-8-[(2-methyl-1H-imidazol-1-yl)methyl]-4,5-dihydro-3H-naphtho[1,2-d][1,2,3]triazole × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；289.15 K；ammonium acetate, PEG3350, Bis-TRIS, TRIS, HEPES
|
Resolution 1.58 Å R-free 0.287 |
| 9NCV Crystal Structure of WDR5 in complex with Triazole-Based Inhibitors Deposited 2025-02-17 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
22–334（313 aa）
|
Not recorded | A1BW8 (6P)-6-[1-ethyl-3-(trifluoromethyl)-1H-pyrazol-4-yl]-3-[(4-fluoro-3-methylphenyl)methyl]-8-[(2-methyl-1H-imidazol-1-yl)methyl]-4,5-dihydro-3H-naphtho[1,2-d][1,2,3]triazole × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；289.15 K；ammonium acetate, PEG3350, Bis-TRIS, TRIS, HEPES
|
Resolution 1.58 Å R-free 0.287 |
| 9NCW Crystal Structure of WDR5 in complex with Triazole-Based Inhibitors Deposited 2025-02-17 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
22–334（313 aa）
|
Not recorded | A1BW9 1-{[(6P)-3-[(3,5-dimethoxyphenyl)methyl]-6-(4-fluoro-2-methylphenyl)-4,5-dihydro-3H-naphtho[1,2-d][1,2,3]triazol-8-yl]methyl}-3-methyl-1,3-dihydro-2H-imidazol-2-imine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；289.15 K；ammonium acetate, PEG 3350, Bis-TRIS, HEPES, TRIS
|
Resolution 1.58 Å R-free 0.275 |
| 9NCW Crystal Structure of WDR5 in complex with Triazole-Based Inhibitors Deposited 2025-02-17 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
22–334（313 aa）
|
Not recorded | A1BW9 1-{[(6P)-3-[(3,5-dimethoxyphenyl)methyl]-6-(4-fluoro-2-methylphenyl)-4,5-dihydro-3H-naphtho[1,2-d][1,2,3]triazol-8-yl]methyl}-3-methyl-1,3-dihydro-2H-imidazol-2-imine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；289.15 K；ammonium acetate, PEG 3350, Bis-TRIS, HEPES, TRIS
|
Resolution 1.58 Å R-free 0.275 |
| 9NCW Crystal Structure of WDR5 in complex with Triazole-Based Inhibitors Deposited 2025-02-17 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；289.15 K；ammonium acetate, PEG 3350, Bis-TRIS, HEPES, TRIS
|
Resolution 1.58 Å R-free 0.275 |
| 9NCW Crystal Structure of WDR5 in complex with Triazole-Based Inhibitors Deposited 2025-02-17 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；289.15 K；ammonium acetate, PEG 3350, Bis-TRIS, HEPES, TRIS
|
Resolution 1.58 Å R-free 0.275 |
| 9NSN Crystal structure of the ternary complex of DCAF1 and WDR5 with PROTAC, OICR-41059 Deposited 2025-03-17 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | A1B0X N-{(1P)-5'-({(26E)-27-[(3P)-4-{[(1S)-3-amino-1-(3-chloro-4-fluorophenyl)-3-oxopropyl]carbamoyl}-3-(4-chloro-2-fluorophenyl)-1H-pyrrol-2-yl]-25-oxo-3,6,9,12,15,18,21-heptaoxa-24-azaheptacos-26-en-1-yl}carbamoyl)-2'-fluoro-4-[(3R,5S)-3,4,5-trimethylpiperazin-1-yl][1,1'-biphenyl]-3-yl}-6-oxo-4-(trifluoromethyl)-5,6-dihydropyridine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；294 K；0.15 M cesium chloride, 15% PEG3350
|
Resolution 1.85 Å R-free 0.234 |
| 9NSO Crystal structure of the ternary complex of DCAF1 and WDR5 with PROTAC, OICR-41060 Deposited 2025-03-17 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | A1B0Y (4P)-N-[(1S)-3-amino-1-(3-chloro-4-fluorophenyl)-3-oxopropyl]-4-(4-chloro-2-fluorophenyl)-5-[(34E)-1-{(1P)-6-fluoro-3'-[4-fluoro-2-(trifluoromethyl)benzamido]-4'-[(3R,5S)-3,4,5-trimethylpiperazin-1-yl][1,1'-biphenyl]-3-yl}-1,33-dioxo-5,8,11,14,17,20,23,26,29-nonaoxa-2,32-diazapentatriacont-34-en-35-yl]-1H-pyrrole-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；294 K；0.1 M sodium citrate tribasic dihydrate, pH 4.2, 0.4 M potassium phosphate dibasic, 1.6 M sodium phosphate monobasic monohydrate
|
Resolution 1.85 Å R-free 0.218 |
| 9UJR Crystal structure of WDR5 in complex with peptide Ac-MRT-NH2 Deposited 2025-04-17 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291.15 K；0.1 M HEPES pH 7.0, 30% v/v Jeffamine ED-2001 pH 7.0
|
Resolution 2.25 Å R-free 0.235 |
| 9UJZ Crystal structure of WDR5 in complex with peptide Ac-MRTEPRP-NH2 Deposited 2025-04-17 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291.15 K；0.1 M HEPES pH 7.0, 30% v/v Jeffamine ED-2001 pH 7.0
|
Resolution 2.46 Å R-free 0.229 |
| 9UK1 Crystal structure of WDR5 in complex with EMBOW Deposited 2025-04-17 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291.15 K；0.2 M Sodium tartrate dibasic dihydrate, 20% w/v Polyethylene glycol 3,350, pH7.3
|
Resolution 2.02 Å R-free 0.226 |
| 9UK3 Crystal structure of WDR5 in complex with peptide Ac-MRTEPRPPAP-NH2 Deposited 2025-04-17 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291.15 K；0.1 M BIS-TRIS pH 5.5, 25% w/v Polyethylene glycol 3,350
|
Resolution 1.69 Å R-free 0.200 |
| 9UK4 Crystal structure of WDR5 in complex with peptide Ac-ARA-NH2 Deposited 2025-04-17 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291.15 K；0.1 M HEPES pH 7.0, 30% v/v Jeffamine ED-2001 pH 7.0
|
Resolution 2.12 Å R-free 0.242 |
| 9UK7 Crystal structure of WDR5 in complex with peptide Ac-MRTEP-NH2 Deposited 2025-04-17 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291.15 K；0.2 M Ammonium acetate, 0.1 M Sodium citrate tribasic dihydrate pH 5.6, 30% w/v Polyethylene glycol 4,000
|
Resolution 1.95 Å R-free 0.237 |
| 9UK7 Crystal structure of WDR5 in complex with peptide Ac-MRTEP-NH2 Deposited 2025-04-17 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291.15 K；0.2 M Ammonium acetate, 0.1 M Sodium citrate tribasic dihydrate pH 5.6, 30% w/v Polyethylene glycol 4,000
|
Resolution 1.95 Å R-free 0.237 |
| 9UK7 Crystal structure of WDR5 in complex with peptide Ac-MRTEP-NH2 Deposited 2025-04-17 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
22–334（313 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291.15 K；0.2 M Ammonium acetate, 0.1 M Sodium citrate tribasic dihydrate pH 5.6, 30% w/v Polyethylene glycol 4,000
|
Resolution 1.95 Å R-free 0.237 |
| 9UOJ WDR5 bound with P3 Deposited 2025-04-25 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
21–334（314 aa）
|
Not recorded | A1L9J ~{N}-[5-[2-fluoranyl-5-[4-[[4-[oxidanyl(oxidanylidene)-$l^{4}-azanyl]-2,1,3-benzoxadiazol-7-yl]amino]butylcarbamoyl]phenyl]-2-[(3~{R},5~{S})-3,4,5-trimethylpiperazin-1-yl]phenyl]-6-oxidanylidene-4-(trifluoromethyl)-1~{H}-pyridine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；300 K；30% (w/v) polyethylene glycol 5000, 0.2 M ammonium sulfate, and 0.1 M MES monohydrate (pH 6.5)
|
Resolution 1.82 Å R-free 0.254 |
| 9UXG Structure of WDR5 in complex with Peptide 2 Deposited 2025-05-14 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2M Sodium iodide, 0.1M Bis-tris propane pH 7.5, 20% w/v PEG 3350
|
Resolution 1.70 Å R-free 0.243 |
| 9UXJ Structure of WDR5 in complex with Peptide 2_R4A Deposited 2025-05-14 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2 M imidazole malate (pH 7.0), and 25 % w/v PEG 4000
|
Resolution 1.76 Å R-free 0.225 |
| 9UXM Structure of WDR5 in complex with Peptide 1 Deposited 2025-05-14 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2 M sodium fluoride, 0.1 M Bis-Tris propane, pH 8.5, 20% w/v PEG3350
|
Resolution 1.48 Å R-free 0.193 |
| 9VN5 Structure of WDR5 in complex with MBD3C R43K Deposited 2025-06-30 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2 M imidazole malate (pH 8.5) and 7.5% w/v PEG 10,000
|
Resolution 1.90 Å R-free 0.231 |
| 9VN5 Structure of WDR5 in complex with MBD3C R43K Deposited 2025-06-30 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
24–334（311 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2 M imidazole malate (pH 8.5) and 7.5% w/v PEG 10,000
|
Resolution 1.90 Å R-free 0.231 |
| 9YL3 State 1 MLL4FC bound to a nucleosome premodified with H2BK120ub and H4K16ac Deposited 2025-10-08 | Different construct Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 15 PDB declaration: 17-meric |
Chain R
1–334（334 aa）
|
Not recorded | No recorded non-water small molecule | ELECTRON MICROSCOPY mmCIF provides none of the parsed conditions | Resolution 3.50 Å |
| 9YLE State 3 MLL4FC bound to a nucleosome premodified with H2BK120ub and H4K16ac Deposited 2025-10-08 | Different construct Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 15 PDB declaration: 17-meric |
Chain R
1–334（334 aa）
|
Not recorded | No recorded non-water small molecule | ELECTRON MICROSCOPY mmCIF provides none of the parsed conditions | Resolution 3.63 Å |
| 9YLY MLL4FC bound to a nucleosome with p53 RE Deposited 2025-10-09 | Different construct Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 14 PDB declaration: 16-meric |
Chain R
1–334（334 aa）
|
Not recorded | No recorded non-water small molecule | ELECTRON MICROSCOPY mmCIF provides none of the parsed conditions | Resolution 3.77 Å |
| 9YM8 State 2 focused on PHD FYR of MLL4FC bound to a nucleosome premodified with H2BK120ub and H4K16ac Deposited 2025-10-09 | Different construct Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 16 PDB declaration: 18-meric |
Chain R
1–334（334 aa）
|
Not recorded | No recorded non-water small molecule | ELECTRON MICROSCOPY mmCIF provides none of the parsed conditions | Resolution 3.43 Å |
| 9YMF State 2 focused on H3 N terminal tail of MLL4FC bound to a nucleosome premodified with H2BK120ub and H4K16ac Deposited 2025-10-09 | Different construct Different oligomeric state Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 16 PDB declaration: 18-meric |
Chain R
1–334（334 aa）
|
Not recorded | No recorded non-water small molecule | ELECTRON MICROSCOPY mmCIF provides none of the parsed conditions | Resolution 3.45 Å |
198 other PDB entries and 293 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | WDR5_HUMAN |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 5–318； UniProt 21–334 Author chain C； PDBConstruct 5–318； UniProt 21–334 |
