Catenin beta-1
Homo sapiens
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein monomer Monomer Protein × 1 PDB declaration: monomeric（1） Consistent with protein copy count | Chain A； UniProt 138–686 | Not recorded | No other associated polymer | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；pH 7.5；277 K；14% PEG 3350, 0.1M Hepes pH 7.5, 0.2M L-proline, 20% glycerol | Resolution 2.80 Å R-free 0.264 |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 8Z5J | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 1G3J CRYSTAL STRUCTURE OF THE XTCF3-CBD/BETA-CATENIN ARMADILLO REPEAT COMPLEX Deposited 2000-10-24 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
133–664（532 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.2；298 K；2.5% PEG-8000, 44mM Phosphate-Citrate, 2mM DTT, pH 4.2, VAPOR DIFFUSION, HANGING DROP, temperature 298.0K
|
Resolution 2.10 Å R-free 0.255 |
| 1G3J CRYSTAL STRUCTURE OF THE XTCF3-CBD/BETA-CATENIN ARMADILLO REPEAT COMPLEX Deposited 2000-10-24 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
133–664（532 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.2；298 K；2.5% PEG-8000, 44mM Phosphate-Citrate, 2mM DTT, pH 4.2, VAPOR DIFFUSION, HANGING DROP, temperature 298.0K
|
Resolution 2.10 Å R-free 0.255 |
| 1JDH CRYSTAL STRUCTURE OF BETA-CATENIN AND HTCF-4 Deposited 2001-06-13 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
135–663（529 aa）
Fragment：Residues 135-663
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.90 Å R-free 0.231 |
| 1JPW Crystal Structure of a Human Tcf-4 / beta-Catenin Complex Deposited 2001-08-03 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
131–670（540 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；295 K；PEG 400, MES, ammonium sulfate, pH 5.5, VAPOR DIFFUSION, SITTING DROP, temperature 22K
|
Resolution 2.50 Å R-free 0.390 |
| 1JPW Crystal Structure of a Human Tcf-4 / beta-Catenin Complex Deposited 2001-08-03 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
131–670（540 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；295 K；PEG 400, MES, ammonium sulfate, pH 5.5, VAPOR DIFFUSION, SITTING DROP, temperature 22K
|
Resolution 2.50 Å R-free 0.390 |
| 1JPW Crystal Structure of a Human Tcf-4 / beta-Catenin Complex Deposited 2001-08-03 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
131–670（540 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.5；295 K；PEG 400, MES, ammonium sulfate, pH 5.5, VAPOR DIFFUSION, SITTING DROP, temperature 22K
|
Resolution 2.50 Å R-free 0.390 |
| 1LUJ Crystal Structure of the Beta-catenin/ICAT Complex Deposited 2002-05-22 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
150–663（514 aa）
Fragment：residues 150-666
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；PEG800, magnesium chloride, Tris, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.50 Å R-free 0.255 |
| 1P22 Structure of a beta-TrCP1-Skp1-beta-catenin complex: destruction motif binding and lysine specificity on the SCFbeta-TrCP1 ubiquitin ligase Deposited 2003-04-14 | Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
19–44（26 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.8；298 K；PEG4000, sodium citrate, Bis-Tris Propane, pH 6.8, VAPOR DIFFUSION, HANGING DROP, temperature 298.0K
|
Resolution 2.95 Å R-free 0.286 |
| 1QZ7 Beta-catenin binding domain of Axin in complex with beta-catenin Deposited 2003-09-15 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
133–665（533 aa）
Fragment：Armadillo repeat region
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；298 K；PEG 6000, sodium citrate, isopropanol, pH 5.6, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.20 Å R-free 0.256 |
| 1T08 Crystal structure of beta-catenin/ICAT helical domain/unphosphorylated APC R3 Deposited 2004-04-07 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
146–664（519 aa）
Fragment：armadillo repeat (RESIDUES 146-664)
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 6.5；297 K；PEG3400, Potassium phosphate, pH 6.5, EVAPORATION, temperature 297K
|
Resolution 2.10 Å R-free 0.241 |
| 1TH1 Beta-catenin in complex with a phosphorylated APC 20aa repeat fragment Deposited 2004-05-31 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
133–664（532 aa）
Fragment：armadillo repeat
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；Tris, sidium chloride, PEG2000MME, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.50 Å R-free 0.257 |
| 1TH1 Beta-catenin in complex with a phosphorylated APC 20aa repeat fragment Deposited 2004-05-31 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
133–664（532 aa）
Fragment：armadillo repeat
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；Tris, sidium chloride, PEG2000MME, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.50 Å R-free 0.257 |
| 2G57 Structure of the Phosphorylation Motif of the oncogenic Protein beta-Catenin Recognized By a Selective Monoclonal Antibody Deposited 2006-02-22 | Different construct Different mutation/modification Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
19–44（26 aa）
Fragment：Residues 19-44
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | No recorded non-water small molecule |
SOLUTION NMR
NMR measurement conditions
pH 7.4；278 K；Ionic strength (raw mmCIF value) 20mM；Pressure 1
NMR sample composition
1mM P-beta-Cat peptide with 0.01mM antibody; 20mM phosphate buffered saline(pH 7.4);
15mM sodium azide; 90% H2O, 10% D2O | 90% H2O/10% D2O
|
Resolution not provided |
| 2GL7 Crystal Structure of a beta-catenin/BCL9/Tcf4 complex Deposited 2006-04-04 | Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
138–686（549 aa）
Fragment：Residues 138-686
|
Mutation：Y142E | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；13% PEG 3350, 125mM sodium thiocyanate, 5% Glycerol, 10mM DTT, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298.0K
|
Resolution 2.60 Å R-free 0.267 |
| 2GL7 Crystal Structure of a beta-catenin/BCL9/Tcf4 complex Deposited 2006-04-04 | Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
138–686（549 aa）
Fragment：Residues 138-686
|
Mutation：Y142E | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；298 K；13% PEG 3350, 125mM sodium thiocyanate, 5% Glycerol, 10mM DTT, pH 7.0, VAPOR DIFFUSION, HANGING DROP, temperature 298.0K
|
Resolution 2.60 Å R-free 0.267 |
| 2Z6H Crystal Structure of Beta-Catenin Armadillo Repeat Region and Its C-Terminal domain Deposited 2007-08-01 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
138–781（644 aa）
Fragment：Armadillo Repeat Region and C-terminal Domain (UNP residues 138-781)
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；298 K；0.1M Na Citrate, 0.4M NaCl, 7% JEFFAMINE ED-2001, pH 5.60, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.20 Å R-free 0.249 |
| 2Z6H Crystal Structure of Beta-Catenin Armadillo Repeat Region and Its C-Terminal domain Deposited 2007-08-01 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 2 Protein homooligomer Homooligomer；Protein × 4 PDB declaration: tetrameric |
Chain A
138–781（644 aa）
Fragment：Armadillo Repeat Region and C-terminal Domain (UNP residues 138-781)
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；298 K；0.1M Na Citrate, 0.4M NaCl, 7% JEFFAMINE ED-2001, pH 5.60, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.20 Å R-free 0.249 |
| 3DIW c-terminal beta-catenin bound TIP-1 structure Deposited 2008-06-21 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
772–781（10 aa）
Fragment：C-terminal domain, UNP residues 772-781
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.5；293 K；3.0M sodium formate, 0.1M sodium acetate, pH 4.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.10 Å R-free 0.265 |
| 3DIW c-terminal beta-catenin bound TIP-1 structure Deposited 2008-06-21 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain D
772–781（10 aa）
Fragment：C-terminal domain, UNP residues 772-781
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 4.5；293 K；3.0M sodium formate, 0.1M sodium acetate, pH 4.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.10 Å R-free 0.265 |
| 3SL9 X-ray structure of Beta catenin in complex with Bcl9 Deposited 2011-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
141–305（165 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 4 PEG DI(HYDROXYETHYL)ETHER × 2 IMD IMIDAZOLE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；298 K；0.12M ethylene glycol, 1M MES 62% MES, 1M Imidazol 38%, 10% PEG 4K, 20% glycerol, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.20 Å R-free 0.249 |
| 3SL9 X-ray structure of Beta catenin in complex with Bcl9 Deposited 2011-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
141–305（165 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 3 PEG DI(HYDROXYETHYL)ETHER × 2 IMD IMIDAZOLE × 1 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；298 K；0.12M ethylene glycol, 1M MES 62% MES, 1M Imidazol 38%, 10% PEG 4K, 20% glycerol, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.20 Å R-free 0.249 |
| 3SL9 X-ray structure of Beta catenin in complex with Bcl9 Deposited 2011-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain E
141–305（165 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 4 PEG DI(HYDROXYETHYL)ETHER × 1 IMD IMIDAZOLE × 1 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；298 K；0.12M ethylene glycol, 1M MES 62% MES, 1M Imidazol 38%, 10% PEG 4K, 20% glycerol, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.20 Å R-free 0.249 |
| 3SL9 X-ray structure of Beta catenin in complex with Bcl9 Deposited 2011-06-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain G
141–305（165 aa）
|
Not recorded | IMD IMIDAZOLE × 3 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；298 K；0.12M ethylene glycol, 1M MES 62% MES, 1M Imidazol 38%, 10% PEG 4K, 20% glycerol, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.20 Å R-free 0.249 |
| 3SLA X-ray structure of first four repeats of human beta-catenin Deposited 2011-06-24 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
141–306（166 aa）
|
Not recorded | GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；0.98M sodium acetate trihydrate, 30% glycerol, 0.07M sodium cacodylate, 30% w/v galactose
, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.50 Å R-free 0.277 |
| 3SLA X-ray structure of first four repeats of human beta-catenin Deposited 2011-06-24 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
141–306（166 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；0.98M sodium acetate trihydrate, 30% glycerol, 0.07M sodium cacodylate, 30% w/v galactose
, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.50 Å R-free 0.277 |
| 3SLA X-ray structure of first four repeats of human beta-catenin Deposited 2011-06-24 | Different construct Different experimental conditions Different structure-quality metrics | Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain C
141–306（166 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；0.98M sodium acetate trihydrate, 30% glycerol, 0.07M sodium cacodylate, 30% w/v galactose
, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.50 Å R-free 0.277 |
| 3SLA X-ray structure of first four repeats of human beta-catenin Deposited 2011-06-24 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain D
141–306（166 aa）
|
Not recorded | GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；0.98M sodium acetate trihydrate, 30% glycerol, 0.07M sodium cacodylate, 30% w/v galactose
, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.50 Å R-free 0.277 |
| 3SLA X-ray structure of first four repeats of human beta-catenin Deposited 2011-06-24 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 5 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain E
141–306（166 aa）
|
Not recorded | GOL GLYCEROL × 2 NA SODIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；0.98M sodium acetate trihydrate, 30% glycerol, 0.07M sodium cacodylate, 30% w/v galactose
, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.50 Å R-free 0.277 |
| 3TX7 Crystal structure of LRH-1/beta-catenin complex Deposited 2011-09-22 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
138–663（526 aa）
|
Not recorded | P6L (2S)-3-{[{[(2S)-2,3-DIHYDROXYPROPYL]OXY}(HYDROXY)PHOSPHORYL]OXY}-2-[(6E)-HEXADEC-6-ENOYLOXY]PROPYL (8E)-OCTADEC-8-ENOATE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；20 mM Tris-HCl, 40% PEG200, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.76 Å R-free 0.243 |
| 4DJS Structure of beta-catenin in complex with a stapled peptide inhibitor Deposited 2012-02-02 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
148–665（518 aa）
Fragment：armadillo repeats 1-12 (UNP residues 148-665)
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.2；298 K；1.4-2.0 M sodium chloride, 100 mM Bis-Tris, 100 mM potassium phosphate monobasic, pH 6.2, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 3.03 Å R-free 0.291 |
| 6M90 Monophosphorylated pSer33 b-Catenin peptide, b-TrCP/Skp1, NRX-2776 ternary complex Deposited 2018-08-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
17–48（32 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | J91 2-(2-fluorophenoxy)-3-{[2-oxo-6-(trifluoromethyl)-1,2-dihydropyridine-3-carbonyl]amino}benzoic acid × 2 PO4 PHOSPHATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；8% PEG 4000
0.1M BTP pH 5.5
|
Resolution 2.05 Å R-free 0.212 |
| 6M91 Monophosphorylated pSer33 b-Catenin peptide, b-TrCP/Skp1, NRX-103094 ternary complex Deposited 2018-08-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
17–48（32 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | J97 3-({4-[(2,6-dichlorophenyl)sulfanyl]-2-oxo-6-(trifluoromethyl)-1,2-dihydropyridine-3-carbonyl}amino)benzoic acid × 1 PO4 PHOSPHATE ION × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；8% PEG 4000
0.1M BTP pH 5.5
|
Resolution 2.40 Å R-free 0.216 |
| 6M92 Monophosphorylated pSer33 b-Catenin peptide, b-TrCP/Skp1, NRX-2663 ternary complex Deposited 2018-08-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
17–48（32 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | J8V 3-{[2-oxo-4-phenoxy-6-(trifluoromethyl)-1,2-dihydropyridine-3-carbonyl]amino}benzoic acid × 1 PO4 PHOSPHATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；8% PEG 4000
0.1M BTP pH 5.5
|
Resolution 2.35 Å R-free 0.221 |
| 6M93 Monophosphorylated pSer33 b-Catenin peptide, b-TrCP/Skp1, NRX-1933 ternary complex Deposited 2018-08-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
17–48（32 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | J8Y 2-oxo-N-[3-(1H-tetrazol-5-yl)phenyl]-6-(trifluoromethyl)-1,2-dihydropyridine-3-carboxamide × 1 PO4 PHOSPHATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；8% PEG 4000
0.1M BTP pH 5.5
|
Resolution 2.50 Å R-free 0.230 |
| 6M94 Monophosphorylated pSer33 b-Catenin peptide bound to b-TrCP/Skp1 Complex Deposited 2018-08-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
17–48（32 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | PO4 PHOSPHATE ION × 1 DMS DIMETHYL SULFOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；8% PEG 4000
0.1M BTP pH5.5
|
Resolution 2.70 Å R-free 0.238 |
| 6O9B Crystal structure of HLA-A3*01 in complex with a wild-type beta-catenin peptide Deposited 2019-03-13 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
41–49（9 aa）
Fragment：UNP residues 41-49
|
Not recorded | PG4 TETRAETHYLENE GLYCOL × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 3 IMD IMIDAZOLE × 2 PEG DI(HYDROXYETHYL)ETHER × 4 EDO 1,2-ETHANEDIOL × 7 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；292 K；0.1 M MES/imidazole, pH 6.5, 0.03 M diethylene glycol, 0.03 M triethylene glycol, 0.03 M tetraethylene glycol, 0.03 M pentaethylene glycol, 20% PEG500 MME, 10% PEG20000
|
Resolution 2.20 Å R-free 0.227 |
| 6O9C Crystal structure of HLA-A3*01 in complex with a mutant beta-catenin peptide Deposited 2019-03-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
41–49（9 aa）
Fragment：UNP residues 41-49
|
Mutation：S45F | MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 SO4 SULFATE ION × 10 PEG DI(HYDROXYETHYL)ETHER × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；292 K；0.1 M MES, pH 6.5, 0.2 M ammonium sulfate, 30% PEG5000 MME
|
Resolution 2.45 Å R-free 0.259 |
| 6WLX PAK4 kinase domain in complex with beta-catenin Ser675 substrate peptide Deposited 2020-04-20 | Different construct Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
671–677（7 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；295 K；0.1M Tris-HCl, 2M Na acetate, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 295K, 5mM peptide
|
Resolution 2.20 Å R-free 0.229 |
| 6WNX FBXW11-SKP1 in complex with a pSer33/pSer37 Beta-Catenin peptide Deposited 2020-04-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
31–39（9 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | GOL GLYCEROL × 4 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；0.12M Ethylene Glycol,
0.1M Morpheus Buffer 1 pH 6.5, 30.0% GOL_P4K
|
Resolution 2.50 Å R-free 0.251 |
| 6WNX FBXW11-SKP1 in complex with a pSer33/pSer37 Beta-Catenin peptide Deposited 2020-04-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain F
31–39（9 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | GOL GLYCEROL × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；0.12M Ethylene Glycol,
0.1M Morpheus Buffer 1 pH 6.5, 30.0% GOL_P4K
|
Resolution 2.50 Å R-free 0.251 |
| 6WNX FBXW11-SKP1 in complex with a pSer33/pSer37 Beta-Catenin peptide Deposited 2020-04-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain I
31–39（9 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；298 K；0.12M Ethylene Glycol,
0.1M Morpheus Buffer 1 pH 6.5, 30.0% GOL_P4K
|
Resolution 2.50 Å R-free 0.251 |
| 7AFW Beta-Catenin in complex with compound 6 Deposited 2020-09-21 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
141–305（165 aa）
|
Not recorded | R9Q 3-[(2~{R})-4-methyl-5-oxidanylidene-2,3-dihydro-1,4-benzoxazepin-2-yl]benzenecarbonitrile × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；278 K；25% PEG 3350, 100 mM BIS-TRIS buffer pH 5.5 and 0.2 M Magnesium chloride
|
Resolution 1.81 Å R-free 0.281 |
| 7AR4 Crystal structure of beta-catenin in complex with cyclic peptide inhibitor Deposited 2020-10-23 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain AAA
134–665（532 aa）
|
Not recorded | EPE 4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293.15 K；0.1 M HEPES, 4% PEG6000, 20 mM TRIS, 150 mM NaCl, 0.5 % Glycerol, 2 mM DTT
|
Resolution 2.60 Å R-free 0.242 |
| 7UWI Structure of beta-catenin in complex with FP01567, a Helicon Polypeptide Deposited 2022-05-03 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
143–663（521 aa）
|
Not recorded | PO4 PHOSPHATE ION × 1 GOL GLYCEROL × 6 WHL N,N'-(1,4-phenylene)diacetamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；293.15 K；0.1 M Sodium phosphate monobasic monohydrate, 0.1 M Potassium phosphate monobasic, 0.1 M MES monohydrate pH 6.5, 2.0 M Sodium chloride
|
Resolution 2.32 Å R-free 0.278 |
| 7UWO Structure of beta-catenin in complex with FP05874, a Helicon Polypeptide Deposited 2022-05-03 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
134–665（532 aa）
|
Not recorded | WHL N,N'-(1,4-phenylene)diacetamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293.15 K；0.05M MgCl2, 0.1M MES pH6.5, 5% (w/v) PEG 4000
|
Resolution 2.75 Å R-free 0.253 |
| 8EI9 Crystal structure of beta-catenin and the MDM2 p53-binding domain in complex with H332, a Helicon Polypeptide Deposited 2022-09-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
134–665（532 aa）
|
Not recorded | WHL N,N'-(1,4-phenylene)diacetamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；291 K；0.1M MES Sodium Salt pH6.5, 10% v/v 2-Propanol, 25% v/v PEG 400
|
Resolution 3.90 Å R-free 0.315 |
| 8EIA Crystal structure of beta-catenin and the MDM2 p53-binding domain in complex with H333, a Helicon Polypeptide Deposited 2022-09-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
134–665（532 aa）
|
Not recorded | WHL N,N'-(1,4-phenylene)diacetamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；291 K；0.1 M Potassium chloride, 0.1 M HEPES pH 7, 15% w/v PEG 5000 MME
|
Resolution 3.60 Å R-free 0.373 |
| 8EIB Crystal structure of beta-catenin and the MDM2 p53-binding domain in complex with H329, a Helicon Polypeptide Deposited 2022-09-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
134–665（532 aa）
|
Not recorded | WHL N,N'-(1,4-phenylene)diacetamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；291 K；0.2 M Calcium acetate pH 7.5, 20% w/v PEG 3350
|
Resolution 3.76 Å R-free 0.298 |
| 8EIC Crystal structure of beta-catenin and the MDM2 p53-binding domain in complex with H330, a Helicon Polypeptide Deposited 2022-09-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
134–665（532 aa）
|
Not recorded | WHL N,N'-(1,4-phenylene)diacetamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；4M Sodium formate
|
Resolution 2.62 Å R-free 0.269 |
| 8RU3 Crystal structure of beta-catenin in complex with alpha-helical peptide inhibitor Deposited 2024-01-30 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
134–665（532 aa）
|
Not recorded | CL CHLORIDE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；300 K；Crystals grown in 100 mM NaKPO4, 2M NaCl.
|
Resolution 2.00 Å R-free 0.232 |
| 8RU4 Crystal structure of Human Catenin Beta-1 in complex with stitched peptide inhibitor Deposited 2024-01-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
145–665（521 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | GLC alpha-D-glucopyranose × 3 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 2 CL CHLORIDE ION × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；277.15 K；100 mM TRIS pH 8.75, 2%(w/v) PEG-6000, cryoprotected in 30% (w/v) Glucose.
|
Resolution 2.13 Å R-free 0.240 |
| 8RU4 Crystal structure of Human Catenin Beta-1 in complex with stitched peptide inhibitor Deposited 2024-01-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
145–665（521 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | GLC alpha-D-glucopyranose × 4 TRS 2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；277.15 K；100 mM TRIS pH 8.75, 2%(w/v) PEG-6000, cryoprotected in 30% (w/v) Glucose.
|
Resolution 2.13 Å R-free 0.240 |
| 8VME Crystal structure of the GSK-3/Axin complex bound to a phosphorylated beta-catenin T41A peptide Deposited 2024-01-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
35–61（27 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | ADP ADENOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 2 GOL GLYCEROL × 6 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
MICRODIALYSIS；pH 7.5；277 K；10% PEG35000, 20 mM Tris, pH 7.5, 300 mM sodium chloride, 5% glycerol, 10 mM magnesium chloride, 200 uM ATP, 5 mM DTT
|
Resolution 2.30 Å R-free 0.230 |
| 8VMF Crystal structure of a transition-state mimic of the GSK-3/Axin complex bound to a beta-catenin S45D peptide Deposited 2024-01-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
35–61（27 aa）
|
Mutation：S45D | MG MAGNESIUM ION × 2 AF3 ALUMINUM FLUORIDE × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 1 GOL GLYCEROL × 3 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
MICRODIALYSIS；pH 7.5；277 K；10% PEG35000, 20 mM Tris, pH 7.5, 300 mM sodium chloride, 5% glycerol, 10 mM magnesium chloride, 5 mM DTT, 200 uM ADP, 200 uM aluminum nitrate, 1.2 mM sodium fluoride
|
Resolution 2.50 Å R-free 0.251 |
| 8Y0G Human beta-catenin crystal structure Deposited 2024-01-22 | Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
138–686（549 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；277 K；Apo crystals of beta-Catenin were grown from 14% PEG3350, 0.1M Hepes pH 7.5, 0.2M L-proline
Crystal were transferred into soaking solution and incubated at RT for 1 days. Crystals were transferred into cryoprotectant (14% PEG3350, 0.1M Hepes pH 7.5, 0.2M L-proline, 20% glycerol), and then flash frozen in liquid nitrogen.
|
Resolution 2.50 Å R-free 0.287 |
| 8Y0P Beta-Catenin in complex with peptide 301 Deposited 2024-01-22 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
138–686（549 aa）
|
Not recorded | PRO PROLINE × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；14% PEG 3350, 0.1M Hepes pH 7.5, 0.2M L-proline, 20% glycerol
|
Resolution 2.62 Å R-free 0.279 |
| 8Y0P Beta-Catenin in complex with peptide 301 Deposited 2024-01-22 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
138–686（549 aa）
|
Not recorded | PRO PROLINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；14% PEG 3350, 0.1M Hepes pH 7.5, 0.2M L-proline, 20% glycerol
|
Resolution 2.62 Å R-free 0.279 |
| 8Y14 Beta-catenin Crystal Structure Deposited 2024-01-23 | Parsed fields agree | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
138–686（549 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；277 K；14% PEG 3350, 0.1M Hepes pH 7.5, 0.2M L-proline, 20% glycerol
|
Resolution 2.80 Å R-free 0.264 |
| 8Z0U Human beta-catenin crystal structure Deposited 2024-04-10 | Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
138–686（549 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；277 K；Apo crystals of beta-Catenin were grown from 14% PEG3350, 0.1M Hepes pH 7.5, 0.2M L-proline. Crystal were transferred into soaking solution and incubated at RT for 4 days. Crystals were transferred into cryoprotectant (14% PEG3350, 0.1M Hepes pH 7.5, 0.2M L-proline, 20% glycerol), and then flash frozen in liquid nitrogen.
|
Resolution 2.21 Å R-free 0.281 |
| 8Z10 Human beta-catenin crystal structure Deposited 2024-04-10 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
138–686（549 aa）
|
Not recorded | PRO PROLINE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；277 K；Apo crystals of beta-Catenin were grown from 14% PEG3350, 0.1M Hepes pH 7.5, 0.2M L-proline. Crystal was transferred into a soaking solution and incubated at RT for 4 days. Crystals were transferred into cryoprotectant (14% PEG3350, 0.1M Hepes pH 7.5, 0.2M L-proline, 20% glycerol), and then flash frozen in liquid nitrogen.
|
Resolution 2.35 Å R-free 0.275 |
| 8Z61 Human beta-catenin crystal structure Deposited 2024-04-18 | Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
138–686（549 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；277 K；Apo crystals of beta-Catenin were grown from 14% PEG 3350, 0.1M Hepes pH 7.5, 0.2M L-proline (Crystal were transferred into soaking solution and incubated at RT for 1 days. Crystals were transferred into cryoprotectant (14% PEG3350, 0.1M Hepes pH 7.5, 0.2M L-proline, 20% glycerol), and then flash frozen in liquid nitrogen.)
|
Resolution 2.50 Å R-free 0.287 |
| 9I8K Beta-catenin armadillo (150-663) Deposited 2025-02-05 | Different construct Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics | Assembly 1 Protein homooligomer Homooligomer；Protein × 2 PDB declaration: dimeric |
Chain A
150–663（514 aa）
Chain B
150–663（514 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；Buffer system 1 pH 6.5, 0.12 M monosaccharides mix, 50% precipitant mix 4
|
Resolution 2.00 Å R-free 0.239 |
| 9I8W Beta-catenin armadillo with cyclic peptide and Compound 3 Deposited 2025-02-06 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
134–671（538 aa）
|
Not recorded | HHT 2-(4-bromanyl-2-methoxy-phenyl)ethanoic acid × 1 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.1 M ADA pH 6.5, 100 mM ammonium sulfate, 30 % w/v PEG MME 5000
|
Resolution 2.20 Å R-free 0.244 |
| 9I8X Beta-catenin armadillo with cyclic peptide and Compound 2 Deposited 2025-02-06 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
134–671（538 aa）
|
Not recorded | IJX ~{N}-(4-bromophenyl)ethanamide × 1 SO4 SULFATE ION × 6 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.1 M Bis-TRIS pH 6.5, 0.2 M Lithium sulfate monohydrate, 26% PEG 3350
|
Resolution 2.00 Å R-free 0.286 |
46 other PDB entries and 64 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | CTNB1_HUMAN |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 1–549； UniProt 138–686 |
