6mfn

Human Argonaute2-miR-27a bound to HSUR1 target RNA

Method: X-RAY DIFFRACTION Dmax: 100.6 Å Quality: GOOD
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Protein argonaute-2

Homo sapiens

UniProt Q9UKV8

State in the Current Structure

Assembly Oligomeric State Construct Mutations and Modifications Ligands, Ions and Associated Components Method and Experimental Conditions Structure Quality
1 Protein–RNA Monomer Protein × 1 RNA 2 PDB declaration: trimeric（3） Consistent with all polymer counts Chain A； UniProt 1–859 Mutation：D669A, S387D, S824A, S828D, S831D, S834A ;RNA (5'-R(P*UP*UP*CP*AP*CP*AP*GP*UP*G)-3') ; × 1 ;RNA (5'-R(P*UP*CP*UP*GP*UP*GP*AP*UP*AP*A)-3') ; × 1 IPH PHENOL × 1 X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；10% PEG3350, 50 mM Tris, pH 8.0, 20 mM magnesium chloride, 75 mM phenol Resolution 2.50 Å R-free 0.247

Other States of the Same Protein in the Database

Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.

Other PDB Difference from Current Entry 6MFN Assembly / Oligomeric State Construct Mutations and Modifications Ligands, Ions and Non-polymers Method and Experimental Conditions Structure Quality
10BE Human AGO2 bound to a miR-20a guide and a position 10-11 mismatched target Deposited 2026-01-09 Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY mmCIF provides none of the parsed conditions Resolution 3.02 Å
11GI Human Argonaute2 WT - guide(3 prime-amino) RNA in complex with a fully complementary target Deposited 2026-02-23 Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：S387D, S824A, S828D, S831D, S834A MG MAGNESIUM ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 8
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.00 Å
11GJ Human Argonaute2 R315V/H316A - guide10U RNA in complex with a complementary target to position 19 Deposited 2026-02-23 Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：R315V, H316A, S387D, S824A, S828D, S831D, S834A MG MAGNESIUM ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 8
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.30 Å
11GK Human Argonaute2 R315V/H316A - guide RNA in complex with a fully complementary target (conformation 2) Deposited 2026-02-23 Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：R315V, H316A, S387D, S824A, S828D, S831D, S834A MG MAGNESIUM ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 8
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.00 Å
3LUC Crystal structure of MID domain from hAGO2 Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 439–575（137 aa） Fragment：MID domain
Not recorded PO4 PHOSPHATE ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 1.69 Å R-free 0.209
3LUC Crystal structure of MID domain from hAGO2 Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 439–575（137 aa） Fragment：MID domain
Not recorded PO4 PHOSPHATE ION × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 1.69 Å R-free 0.209
3LUC Crystal structure of MID domain from hAGO2 Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain C 439–575（137 aa） Fragment：MID domain
Not recorded PO4 PHOSPHATE ION × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 1.69 Å R-free 0.209
3LUD Crystal structure of MID domain from hAGO2 in complex with AMP Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 439–575（137 aa） Fragment：MID domain
Not recorded AMP ADENOSINE MONOPHOSPHATE × 1 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. Protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 2.10 Å R-free 0.223
3LUD Crystal structure of MID domain from hAGO2 in complex with AMP Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 439–575（137 aa） Fragment：MID domain
Not recorded AMP ADENOSINE MONOPHOSPHATE × 1 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. Protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 2.10 Å R-free 0.223
3LUD Crystal structure of MID domain from hAGO2 in complex with AMP Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain C 439–575（137 aa） Fragment：MID domain
Not recorded AMP ADENOSINE MONOPHOSPHATE × 1 PO4 PHOSPHATE ION × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. Protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 2.10 Å R-free 0.223
3LUG Crystal structure of MID domain from hAGO2 in complex with CMP Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 439–575（137 aa） Fragment：MID domain
Not recorded PO4 PHOSPHATE ION × 1 C5P CYTIDINE-5'-MONOPHOSPHATE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. Protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP
Resolution 1.85 Å R-free 0.225
3LUG Crystal structure of MID domain from hAGO2 in complex with CMP Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 439–575（137 aa） Fragment：MID domain
Not recorded PO4 PHOSPHATE ION × 2 C5P CYTIDINE-5'-MONOPHOSPHATE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. Protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP
Resolution 1.85 Å R-free 0.225
3LUG Crystal structure of MID domain from hAGO2 in complex with CMP Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain C 439–575（137 aa） Fragment：MID domain
Not recorded PO4 PHOSPHATE ION × 2 C5P CYTIDINE-5'-MONOPHOSPHATE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. Protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP
Resolution 1.85 Å R-free 0.225
3LUH Crystal structure of MID domain from hAGO2 in complex with GMP Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 439–575（137 aa） Fragment：MID domain
Not recorded 5GP GUANOSINE-5'-MONOPHOSPHATE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. Protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 2.00 Å R-free 0.233
3LUH Crystal structure of MID domain from hAGO2 in complex with GMP Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 439–575（137 aa） Fragment：MID domain
Not recorded 5GP GUANOSINE-5'-MONOPHOSPHATE × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. Protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 2.00 Å R-free 0.233
3LUH Crystal structure of MID domain from hAGO2 in complex with GMP Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain C 439–575（137 aa） Fragment：MID domain
Not recorded PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. Protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 2.00 Å R-free 0.233
3LUJ Crystal structure of MID domain from hAGO2 in complex with UMP Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 439–575（137 aa） Fragment：MID domain
Not recorded U5P URIDINE-5'-MONOPHOSPHATE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. Protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 1.80 Å R-free 0.234
3LUJ Crystal structure of MID domain from hAGO2 in complex with UMP Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 439–575（137 aa） Fragment：MID domain
Not recorded U5P URIDINE-5'-MONOPHOSPHATE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. Protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 1.80 Å R-free 0.234
3LUJ Crystal structure of MID domain from hAGO2 in complex with UMP Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain C 439–575（137 aa） Fragment：MID domain
Not recorded U5P URIDINE-5'-MONOPHOSPHATE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. Protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 1.80 Å R-free 0.234
3LUK Crystal structure of MID domain from hAGO2 Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 439–575（137 aa） Fragment：MID domain
Non-standard monomer：Yes (specific site not provided by mmCIF) PO4 PHOSPHATE ION × 2 GOL GLYCEROL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. Protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 1.70 Å R-free 0.232
3LUK Crystal structure of MID domain from hAGO2 Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 439–575（137 aa） Fragment：MID domain
Non-standard monomer：Yes (specific site not provided by mmCIF) PO4 PHOSPHATE ION × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. Protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 1.70 Å R-free 0.232
3LUK Crystal structure of MID domain from hAGO2 Deposited 2010-02-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain C 439–575（137 aa） Fragment：MID domain
Non-standard monomer：Yes (specific site not provided by mmCIF) PO4 PHOSPHATE ION × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4. Protein: 15 mg/mL, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 1.70 Å R-free 0.232
3QX8 Crystal structure of MID domain from hAGO2 in complex with m7GpppG Deposited 2011-03-01 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 439–575（137 aa） Fragment：unp residues 439-575
Not recorded GTG 7-METHYL-GUANOSINE-5'-TRIPHOSPHATE-5'-GUANOSINE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 2.30 Å R-free 0.279
3QX8 Crystal structure of MID domain from hAGO2 in complex with m7GpppG Deposited 2011-03-01 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 439–575（137 aa） Fragment：unp residues 439-575
Not recorded GTG 7-METHYL-GUANOSINE-5'-TRIPHOSPHATE-5'-GUANOSINE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 2.30 Å R-free 0.279
3QX8 Crystal structure of MID domain from hAGO2 in complex with m7GpppG Deposited 2011-03-01 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain C 439–575（137 aa） Fragment：unp residues 439-575
Not recorded GTG 7-METHYL-GUANOSINE-5'-TRIPHOSPHATE-5'-GUANOSINE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 2.30 Å R-free 0.279
3QX9 Crystal structure of MID domain from hAGO2 in complex with ATP Deposited 2011-03-01 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 439–575（137 aa） Fragment：unp residues 439-575
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 2.00 Å R-free 0.250
3QX9 Crystal structure of MID domain from hAGO2 in complex with ATP Deposited 2011-03-01 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 439–575（137 aa） Fragment：unp residues 439-575
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 2.00 Å R-free 0.250
3QX9 Crystal structure of MID domain from hAGO2 in complex with ATP Deposited 2011-03-01 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain C 439–575（137 aa） Fragment：unp residues 439-575
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；0.1 M imidazole, 0.2 M NaCl, 0.46 M NaH2PO4, 1.84 M K2HPO4, VAPOR DIFFUSION, HANGING DROP, temperature 277K
Resolution 2.00 Å R-free 0.250
4F3T Human Argonaute-2 - miR-20a complex Deposited 2012-05-09 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: dimeric
Chain A 1–859（859 aa）
Not recorded IPH PHENOL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 9；290 K；microseeding in 100 mM Tris pH=9.0, 10% PEG 3350 (w/v), 8% 2-propanol (v/v), 0.12 M phenol, VAPOR DIFFUSION, HANGING DROP, temperature 290K
Resolution 2.25 Å R-free 0.254
4OLA Crystal Structure of Human Argonaute2 Deposited 2014-01-23 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: dimeric
Chain A 1–859（859 aa）
Mutation：S387D IPH PHENOL × 1 IPA ISOPROPYL ALCOHOL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 9；293 K；16% PEG3350, 12% isopropanol, 0.1 M phenol, 0.1 M Tris, pH 9.0, VAPOR DIFFUSION, HANGING DROP, temperature 293.0K
Resolution 2.30 Å R-free 0.253
4OLB Crystal Structure of Human Argonaute2 Bound to Tryptophan Deposited 2014-01-23 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: dimeric
Chain A 1–859（859 aa）
Mutation：S387D TRP TRYPTOPHAN × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 9；293 K；16% PEG3350, 12% isopropanol, saturated L-tryptophan, 0.1 M Tris, pH 9.0, VAPOR DIFFUSION, HANGING DROP, temperature 293K
Resolution 2.90 Å R-free 0.249
4W5N The Crystal Structure of Human Argonaute2 Bound to a Defined Guide RNA Deposited 2014-08-18 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: dimeric
Chain A 1–859（859 aa）
Mutation：S387D IPH PHENOL × 3 MG MAGNESIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；293 K；PEG, Tris, Isopropanol, Phenol, Magnesium
Resolution 2.90 Å R-free 0.253
4W5O The Crystal Structure of Human Argonaute2 Bound to a Guide and Target RNA Containing Seed Pairing from 2-9 Deposited 2014-08-18 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Not recorded MG MAGNESIUM ION × 3 IPA ISOPROPYL ALCOHOL × 2 IPH PHENOL × 4 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；293 K；PEG 3350, Tris, Isopropanol, Phenol, Magnesium
Resolution 1.80 Å R-free 0.197
4W5Q The Crystal Structure of Human Argonaute2 Bound to a Guide and Target RNA Containing Seed Pairing from 2-8 Deposited 2014-08-18 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：S387D MG MAGNESIUM ION × 3 IPH PHENOL × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；293 K；PEG 3350, Isopropanol, Phenol, Tris, Magnesium
Resolution 3.10 Å R-free 0.233
4W5R The Crystal Structure of Human Argonaute2 Bound to a Guide and Target RNA Containing Seed Pairing from 2-8 (Long Target) Deposited 2014-08-18 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：S387D IPA ISOPROPYL ALCOHOL × 2 IPH PHENOL × 3 MG MAGNESIUM ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；PEG 3350, Isopropanol, Tris, Phenol, Magnesium
Resolution 2.50 Å R-free 0.234
4W5T The Crystal Structure of Human Argonaute2 Bound to a Guide and Target RNA Containing Seed Pairing from 2-7 Deposited 2014-08-18 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：S387D MG MAGNESIUM ION × 2 IPH PHENOL × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；PEG 3350, Isopropanol, Phenol, Tris, Magnesium
Resolution 2.50 Å R-free 0.215
4Z4C Human Argonaute2 Bound to t1-C Target RNA Deposited 2015-04-02 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：S387D MG MAGNESIUM ION × 3 IPA ISOPROPYL ALCOHOL × 1 IPH PHENOL × 4 PO4 PHOSPHATE ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；PEG 3350, Tris, Isopropanol, Phenol, Magnesium
Resolution 2.30 Å R-free 0.219
4Z4D Human Argonaute2 Bound to t1-G Target RNA Deposited 2015-04-02 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：S387D MG MAGNESIUM ION × 3 IPH PHENOL × 4 IPA ISOPROPYL ALCOHOL × 5 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；PEG 3350, Tris, Isopropanol, Phenol, Magnesium
Resolution 1.60 Å R-free 0.189
4Z4E Human Argonaute2 Bound to t1-U Target RNA Deposited 2015-04-02 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：S387D MG MAGNESIUM ION × 3 IPA ISOPROPYL ALCOHOL × 2 IPH PHENOL × 4 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；PEG 3350, Tris, Isopropanol, Phenol, Magnesium
Resolution 1.80 Å R-free 0.185
4Z4F Human Argonaute2 Bound to t1-DAP Target RNA Deposited 2015-04-02 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：S387D MG MAGNESIUM ION × 3 IPH PHENOL × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；PEG 3350, Tris, Isopropanol, Phenol, Magnesium
Resolution 2.80 Å R-free 0.233
4Z4G Human Argonaute2 Bound to t1-Inosine Target RNA Deposited 2015-04-02 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：S387D MG MAGNESIUM ION × 3 IPH PHENOL × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；PEG 3350, Tris, Isopropanol, Phenol, Magnesium
Resolution 2.70 Å R-free 0.224
4Z4H Human Argonaute2 A481T Mutant Bound to t1-A Target RNA Deposited 2015-04-02 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：S387D A481T MG MAGNESIUM ION × 3 IPH PHENOL × 4 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；PEG 3350, Tris, Isopropanol, Phenol, Magnesium
Resolution 2.50 Å R-free 0.211
4Z4I Human Argonaute2 A481T Mutant Bound to t1-G Target RNA Deposited 2015-04-02 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：S387D A481T MG MAGNESIUM ION × 3 IPH PHENOL × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；PEG 3350, Tris, Isopropanol, Phenol, Magnesium
Resolution 2.80 Å R-free 0.233
5JS1 Human Argonaute2 Bound to an siRNA Deposited 2016-05-07 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: dimeric
Chain A 1–859（859 aa）
Mutation：S387D IPH PHENOL × 2 MG MAGNESIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 9；293 K；16% PEG 3350, 50mM Phenol, 10% Isopropanol, 5mM Magnesium Chloride, 100mM Tris
Resolution 2.50 Å R-free 0.247
5JS2 Human Argonaute-2 Bound to a Modified siRNA Deposited 2016-05-07 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: dimeric
Chain A 1–859（859 aa）
Mutation：S387D IPH PHENOL × 2 PO4 PHOSPHATE ION × 1 MG MAGNESIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 9；293 K；12% PEG 3350, 75mM Phenol, 12% Isopropanol, 100mM Tris
Resolution 2.95 Å R-free 0.261
5KI6 Human Argonaute-2 bound to a guide RNA with a nucleobase modification at position 1 Deposited 2016-06-16 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: dimeric
Chain A 1–859（859 aa）
Not recorded IPH PHENOL × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 9；293 K；PEG 3350, Phenol, Tris, Spermine, Isopropanol
Resolution 2.15 Å R-free 0.270
5T7B Argonaute-2 - 5'-(E)-vinylphosphonate 2'-O-methyl-uridine modified mrTTR guide RNA complex Deposited 2016-09-02 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: dimeric
Chain A 1–859（859 aa）
Not recorded IPH PHENOL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION；290 K；100 mM Tris pH=9.0, 10% PEG 3350 (w/v), 8% 2-propanol (v/v), 0.12 M phenol
Resolution 2.53 Å R-free 0.238
5WEA Human Argonaute2 Helix-7 Mutant Deposited 2017-07-08 Different mutation/modification Different oligomeric state Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: dimeric
Chain A 1–859（859 aa）
Mutation：M364A, I365A, S387D IPH PHENOL × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293 K；12% PEG 3350, 0.1 M phenol, 12% isopropanol, 0.1 M tris, pH 9.0
Resolution 3.12 Å R-free 0.282
6CBD Crystal Structure of Human Argonaute2 Bound to Three Tryptophans Deposited 2018-02-02 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：S387D TRP TRYPTOPHAN × 3 IPA ISOPROPYL ALCOHOL × 3 MG MAGNESIUM ION × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8.2；293 K；14% PEG 3350, 0.1 M Tris pH 8.2, 12% Isopropanol, 10 mM MgCl2, L-tryptophan to saturation
Resolution 2.20 Å R-free 0.215
6MDZ Human Argonaute2-miR-122 bound to a target RNA with two central mismatches (bu2) Deposited 2018-09-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：S387D, D669A, D824A, S828D, S831D, S834A IPH PHENOL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；10% PEG3350, 50mM Tris pH8, 20mM MgCl2, 75mM Phenol
Resolution 3.40 Å R-free 0.264
6MDZ Human Argonaute2-miR-122 bound to a target RNA with two central mismatches (bu2) Deposited 2018-09-05 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain B 1–859（859 aa）
Mutation：S387D, D669A, D824A, S828D, S831D, S834A IPH PHENOL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；10% PEG3350, 50mM Tris pH8, 20mM MgCl2, 75mM Phenol
Resolution 3.40 Å R-free 0.264
6MFR Human Argonaute2-miR-122 bound to a target RNA with three central mismatches (bu3) Deposited 2018-09-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：D669A, S387D, S824A, S828D, s831D, S834A IPH PHENOL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；10% PEG3350, 50mM Tris pH8, 20mM MgCl2, 75mM Phenol
Resolution 3.60 Å R-free 0.283
6MFR Human Argonaute2-miR-122 bound to a target RNA with three central mismatches (bu3) Deposited 2018-09-12 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain B 1–859（859 aa）
Mutation：D669A, S387D, S824A, S828D, s831D, S834A IPH PHENOL × 2 PO4 PHOSPHATE ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；10% PEG3350, 50mM Tris pH8, 20mM MgCl2, 75mM Phenol
Resolution 3.60 Å R-free 0.283
6N4O Human Argonaute2-miR-122 bound to a seed and supplementary paired target Deposited 2018-11-19 Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：D669A, S387D, S824A, S828D, S831D, S834A No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；26% MPD, 5% PEG 3350, 50 mM imidazole pH 8
Resolution 2.90 Å R-free 0.257
6NIT Human Argonaute2-miR-122 bound to a target RNA with four central mismatches (bu4) Deposited 2018-12-31 Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：D669A, S387D, S824A, S828D, S831D, S834A No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；10% PEG3350, 50mM Tris pH8, 20mM MgCl2, 75mM Phenol
Resolution 3.80 Å R-free 0.294
6NIT Human Argonaute2-miR-122 bound to a target RNA with four central mismatches (bu4) Deposited 2018-12-31 Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain B 1–859（859 aa）
Mutation：D669A, S387D, S824A, S828D, S831D, S834A No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；10% PEG3350, 50mM Tris pH8, 20mM MgCl2, 75mM Phenol
Resolution 3.80 Å R-free 0.294
6RA4 Human ARGONAUTE-2 PAZ DOMAIN (214-347) IN COMPLEX WITH CGUGACUCU Deposited 2019-04-05 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Homooligomer；Protein × 2 PDB declaration: tetrameric
Chain A 222–355（134 aa）
Chain B 222–355（134 aa）
Not recorded GOL GLYCEROL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7.6；292 K；Drop was a 1:1 mix of protein stock (9.4MG/ML HAGO2 PAZ [214 TO 347] IN 100MM POTASSIUM CHLORIDE, 10MM DTT, 5MM HEPES/KOH PH 7.6, WITH A 1.1-FOLD EXCESS OF OLIGONUCLEOTIDE ADDED FROM A 1.75MM STOCK SOLUTION IN 100MM POTASSIUM CHLORIDE, 10MM DTT, 5MM HEPES) and reservoir solution (0.2M sodium CHLORIDE 20% PEG 3,350)
Resolution 1.90 Å R-free 0.268
7C6B Crystal structure of Ago2 MID domain in complex with 6-(3-(2-carboxyethyl)phenyl)purine riboside monophosphate Deposited 2020-05-21 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 440–578（139 aa）
Not recorded K2R 3-[3-[9-[(2R,3R,4S,5R)-3,4-bis(oxidanyl)-5-(phosphonooxymethyl)oxolan-2-yl]purin-6-yl]phenyl]propanoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 8；277.15 K；0.1M imidazole pH8.0, 0.2M NaCl, 0.46M NaH2PO4, 1.84M K2HPO4
Resolution 1.70 Å R-free 0.229
7C6B Crystal structure of Ago2 MID domain in complex with 6-(3-(2-carboxyethyl)phenyl)purine riboside monophosphate Deposited 2020-05-21 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 440–578（139 aa）
Not recorded K2R 3-[3-[9-[(2R,3R,4S,5R)-3,4-bis(oxidanyl)-5-(phosphonooxymethyl)oxolan-2-yl]purin-6-yl]phenyl]propanoic acid × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 8；277.15 K；0.1M imidazole pH8.0, 0.2M NaCl, 0.46M NaH2PO4, 1.84M K2HPO4
Resolution 1.70 Å R-free 0.229
7C6B Crystal structure of Ago2 MID domain in complex with 6-(3-(2-carboxyethyl)phenyl)purine riboside monophosphate Deposited 2020-05-21 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain C 440–578（139 aa）
Not recorded K2R 3-[3-[9-[(2R,3R,4S,5R)-3,4-bis(oxidanyl)-5-(phosphonooxymethyl)oxolan-2-yl]purin-6-yl]phenyl]propanoic acid × 1 PO4 PHOSPHATE ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 8；277.15 K；0.1M imidazole pH8.0, 0.2M NaCl, 0.46M NaH2PO4, 1.84M K2HPO4
Resolution 1.70 Å R-free 0.229
7D7U Crystal structure of Ago2 MID domain in complex with 8-Br-adenosin-5'-monophosphate Deposited 2020-10-06 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 440–578（139 aa） Fragment：MID domain
Not recorded 8BR 8-BROMO-ADENOSINE-5'-MONOPHOSPHATE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 8；277.15 K；0.1M imidazole pH8.0, 0.2M NaCl, 0.46M NaH2PO4, 1.84M K2HPO4
Resolution 2.00 Å R-free 0.247
7D7U Crystal structure of Ago2 MID domain in complex with 8-Br-adenosin-5'-monophosphate Deposited 2020-10-06 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 440–578（139 aa） Fragment：MID domain
Not recorded 8BR 8-BROMO-ADENOSINE-5'-MONOPHOSPHATE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 8；277.15 K；0.1M imidazole pH8.0, 0.2M NaCl, 0.46M NaH2PO4, 1.84M K2HPO4
Resolution 2.00 Å R-free 0.247
7D7U Crystal structure of Ago2 MID domain in complex with 8-Br-adenosin-5'-monophosphate Deposited 2020-10-06 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain C 440–578（139 aa） Fragment：MID domain
Not recorded 8BR 8-BROMO-ADENOSINE-5'-MONOPHOSPHATE × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 8；277.15 K；0.1M imidazole pH8.0, 0.2M NaCl, 0.46M NaH2PO4, 1.84M K2HPO4
Resolution 2.00 Å R-free 0.247
7KI3 Human Argonaute2:miR-122 bound to the HCV genotype 1a site-1 RNA Deposited 2020-10-22 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：S387D, S824A, S828D, S831D, S834A BA BARIUM ION × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；PEG8000, barium chloride, Tris-HCl
Resolution 3.00 Å R-free 0.276
7KI3 Human Argonaute2:miR-122 bound to the HCV genotype 1a site-1 RNA Deposited 2020-10-22 Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain D 1–859（859 aa）
Mutation：S387D, S824A, S828D, S831D, S834A BA BARIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；PEG8000, barium chloride, Tris-HCl
Resolution 3.00 Å R-free 0.276
8D6J Human Ago2 bound to miR122(21nt) with PIWI loop swapped to AtAgo10 sequence Deposited 2022-06-06 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: dimeric
Chain A 1–859（859 aa）
Not recorded MG MAGNESIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293.15 K；0.1M Tris 8, 0.01 MgCl2, 0.1M Phenol,15% PEG 3350, 10% Isoproponal.
Resolution 2.50 Å R-free 0.284
8D71 Human Ago2 bound to miR122(21nt) Deposited 2022-06-07 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: dimeric
Chain A 1–859（859 aa）
Not recorded MG MAGNESIUM ION × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；293.15 K；0.1M Tris 8, 0.01 MgCl2, 0.1M Phenol,15% PEG 3350, 10% Isoproponal
Resolution 2.50 Å R-free 0.280
8THQ Nonamer RNA bound to hAgo2-PAZ Deposited 2023-07-17 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Homooligomer；Protein × 2 PDB declaration: tetrameric
Chain A 227–352（126 aa） Fragment：PAZ domain
Chain B 227–352（126 aa） Fragment：PAZ domain
Not recorded No recorded non-water small molecule X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；pH 7；291 K；0.1 M HEPES pH 7.0, 30% v/v Jeffamine ED-2001
Resolution 2.41 Å R-free 0.284
9BEZ MID domain of human Argo2 bound to RNA Deposited 2024-04-16 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 3 PDB declaration: trimeric
Chain A 440–575（136 aa）
Chain B 440–575（136 aa）
Chain C 440–575（136 aa）
Not recorded A1ANT [(3~{S},4~{R},5~{R})-5-[5-methyl-2,4-bis(oxidanylidene)pyrimidin-1-yl]-4-oxidanyl-oxolan-3-yl] [oxidanyl(phosphonooxy)phosphoryl] hydrogen phosphate × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；291.15 K；Drops were equal volumes of 15 mg/ml protein and 2.1M DL-Malic acid. The reservoir was 2.1M DL-Malic acid. Using MRC drop plates.
Resolution 1.90 Å R-free 0.288
9BF0 MID domain of human Argo2 bound to UTP Deposited 2024-04-16 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 3 PDB declaration: trimeric
Chain A 442–575（134 aa）
Chain B 442–575（134 aa）
Chain C 442–575（134 aa）
Not recorded UTP URIDINE 5'-TRIPHOSPHATE × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；291.15 K；drop was 1:1 15 mg/ml protein with RNA: 1.4 M Sodium citrate tribasic dihydrate, 0.1 M HEPES pH 7.5
Resolution 1.78 Å R-free 0.234
9BF2 MID domain of Ago2 bound to UMP Deposited 2024-04-16 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein homooligomer Homooligomer；Protein × 3 PDB declaration: trimeric
Chain A 440–575（136 aa）
Chain B 440–575（136 aa）
Chain C 440–575（136 aa）
Not recorded U URIDINE-5'-MONOPHOSPHATE × 3 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, SITTING DROP；291.15 K；Drop was 1:1 15 mg/ml MID-UMP and 1.4M sodium citrate tribasic dihydrate, 0.1M HEPES pH7.5
Resolution 1.59 Å R-free 0.187
9CMP Structure of human Argonaute2-guide-target complex in a fully paired, slicing-competent conformation Deposited 2024-07-15 Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 2–859（858 aa）
Mutation：D669A MG MAGNESIUM ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.5
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.30 Å
9DHX human Argonaute2 R315V/H316A - guide RNA in complex with a fully complementary target Deposited 2024-09-04 Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：R315V, H316A, S387D, S824A, S828D, S831D, S834A MG MAGNESIUM ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 8
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.10 Å
9K6P Cryo-EM Structure of hAGO2D669A-siRNA-target (12-nt) Deposited 2024-10-22 Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：D669A No recorded non-water small molecule ELECTRON MICROSCOPY
cryo-EM buffer pH 8
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 3.20 Å
9K6Q "Cryo-EM Structure of hAGO2D669A-siRNA-target (14-nt, sesqui-lobed) Deposited 2024-10-22 Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：D669A MG MAGNESIUM ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 8
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 2.70 Å
9K6R Cryo-EM Structure of hAGO2D669A-siRNA-target (14-nt, uni-lobed) Deposited 2024-10-22 Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 20–859（840 aa）
Mutation：D669A MG MAGNESIUM ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 8
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 2.70 Å
9K6S Cryo-EM Structure of hAGO2D669A-siRNA-target (19-nt) Deposited 2024-10-22 Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Mutation：D669A MG MAGNESIUM ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 8
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 2.80 Å
9K6T Cryo-EM Structure of hAGO2D669A-siRNA-target (21-nt) Deposited 2024-10-22 Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Not recorded MG MAGNESIUM ION × 1 ELECTRON MICROSCOPY
cryo-EM buffer pH 8
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 2.80 Å
9LMZ hAGO2-MID in complex with a chemical modified uridine monophosphate Deposited 2025-01-20 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 440–574（135 aa）
Not recorded A1EY1 [(2R,3S,4R,5R)-5-[2,4-bis(oxidanylidene)thieno[2,3-d]pyrimidin-1-yl]-3,4-bis(oxidanyl)oxolan-2-yl]methyl dihydrogen phosphate × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；290 K；0.25M Ammonium sulfate 0.1M Sodium cacodylate trihydrate pH 6.5 30% w/v Polyethylene glycol 8,000
Resolution 1.80 Å R-free 0.206
9LMZ hAGO2-MID in complex with a chemical modified uridine monophosphate Deposited 2025-01-20 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 440–574（135 aa）
Not recorded A1EY1 [(2R,3S,4R,5R)-5-[2,4-bis(oxidanylidene)thieno[2,3-d]pyrimidin-1-yl]-3,4-bis(oxidanyl)oxolan-2-yl]methyl dihydrogen phosphate × 1 ECC (4S)-4-amino-5-hydroxypentanamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；290 K；0.25M Ammonium sulfate 0.1M Sodium cacodylate trihydrate pH 6.5 30% w/v Polyethylene glycol 8,000
Resolution 1.80 Å R-free 0.206
9LMZ hAGO2-MID in complex with a chemical modified uridine monophosphate Deposited 2025-01-20 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain C 440–574（135 aa）
Not recorded A1EY1 [(2R,3S,4R,5R)-5-[2,4-bis(oxidanylidene)thieno[2,3-d]pyrimidin-1-yl]-3,4-bis(oxidanyl)oxolan-2-yl]methyl dihydrogen phosphate × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；290 K；0.25M Ammonium sulfate 0.1M Sodium cacodylate trihydrate pH 6.5 30% w/v Polyethylene glycol 8,000
Resolution 1.80 Å R-free 0.206
9LSN hAGO2-MID in complex with a chemical modified uridine monophosphate Deposited 2025-02-04 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 440–574（135 aa）
Not recorded A1EL7 [(2R,3S,4R,5R)-5-[2,4-bis(oxidanylidene)thieno[3,2-d]pyrimidin-1-yl]-3,4-bis(oxidanyl)oxolan-2-yl]methyl dihydrogen phosphate × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；290 K；0.25M Ammonium sulfate 0.1M Sodium cacodylate trihydrate pH 6.5 30% w/v Polyethylene glycol 8,000
Resolution 1.75 Å R-free 0.218
9LSN hAGO2-MID in complex with a chemical modified uridine monophosphate Deposited 2025-02-04 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 440–574（135 aa）
Not recorded A1EL7 [(2R,3S,4R,5R)-5-[2,4-bis(oxidanylidene)thieno[3,2-d]pyrimidin-1-yl]-3,4-bis(oxidanyl)oxolan-2-yl]methyl dihydrogen phosphate × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；290 K；0.25M Ammonium sulfate 0.1M Sodium cacodylate trihydrate pH 6.5 30% w/v Polyethylene glycol 8,000
Resolution 1.75 Å R-free 0.218
9LSN hAGO2-MID in complex with a chemical modified uridine monophosphate Deposited 2025-02-04 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain C 440–574（135 aa）
Not recorded A1EL7 [(2R,3S,4R,5R)-5-[2,4-bis(oxidanylidene)thieno[3,2-d]pyrimidin-1-yl]-3,4-bis(oxidanyl)oxolan-2-yl]methyl dihydrogen phosphate × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；290 K；0.25M Ammonium sulfate 0.1M Sodium cacodylate trihydrate pH 6.5 30% w/v Polyethylene glycol 8,000
Resolution 1.75 Å R-free 0.218
9LSO hAGO2-MID in complex with a chemical modified uridine monophosphate Deposited 2025-02-04 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain A 440–574（135 aa）
Not recorded A1EL8 [(2R,3S,4R,5R)-5-[2,4-bis(oxidanylidene)thieno[3,4-d]pyrimidin-1-yl]-3,4-bis(oxidanyl)oxolan-2-yl]methyl dihydrogen phosphate × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；290 K；0.25M Ammonium sulfate 0.1M Sodium cacodylate trihydrate pH 6.5 30% w/v Polyethylene glycol 8,000
Resolution 2.13 Å R-free 0.241
9LSO hAGO2-MID in complex with a chemical modified uridine monophosphate Deposited 2025-02-04 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 2 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain B 440–574（135 aa）
Not recorded A1EL8 [(2R,3S,4R,5R)-5-[2,4-bis(oxidanylidene)thieno[3,4-d]pyrimidin-1-yl]-3,4-bis(oxidanyl)oxolan-2-yl]methyl dihydrogen phosphate × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；290 K；0.25M Ammonium sulfate 0.1M Sodium cacodylate trihydrate pH 6.5 30% w/v Polyethylene glycol 8,000
Resolution 2.13 Å R-free 0.241
9LSO hAGO2-MID in complex with a chemical modified uridine monophosphate Deposited 2025-02-04 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 3 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric
Chain C 440–574（135 aa）
Not recorded A1EL8 [(2R,3S,4R,5R)-5-[2,4-bis(oxidanylidene)thieno[3,4-d]pyrimidin-1-yl]-3,4-bis(oxidanyl)oxolan-2-yl]methyl dihydrogen phosphate × 1 ECC (4S)-4-amino-5-hydroxypentanamide × 1 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；290 K；0.25M Ammonium sulfate 0.1M Sodium cacodylate trihydrate pH 6.5 30% w/v Polyethylene glycol 8,000
Resolution 2.13 Å R-free 0.241
9OBD Crystal structure of human Argonaute2 in complex with a fully modified siRNA with a 5'-phenylpropargyl phosphate Deposited 2025-04-22 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: dimeric
Chain A 1–859（859 aa）
Mutation：S387D S824A S828D S831D S834A MG MAGNESIUM ION × 1 IPH PHENOL × 3 IPA ISOPROPYL ALCOHOL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；PEG3350, Tris-HCl pH8, 2-propanol, phenol
Resolution 2.02 Å R-free 0.267
9OBE Crystal structure of human Argonaute2 in complex with a fully modified siRNA with a 5'-phenylpropyl phosphate Deposited 2025-04-22 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: dimeric
Chain A 1–859（859 aa）
Not recorded MG MAGNESIUM ION × 1 IPH PHENOL × 2 X-RAY DIFFRACTION
X-ray crystallization conditions VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；PEG3350, Tris-HCl pH8, 2-propanol, phenol
Resolution 2.30 Å R-free 0.252
9RWZ ZSWIM8-CUL3 complex bound to AGO2-miR-7-CYRANO Deposited 2025-07-10 Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Heteromer；Protein × 9 PDB declaration: 11-meric
Chain A 2–859（858 aa）
Not recorded ZN ZINC ION × 2 ELECTRON MICROSCOPY
cryo-EM buffer pH 7.8；25 mM HEPES, 50 mM NaCl, 1 mM TCEP, pH 7.8
cryo-EM vitrification conditions Cryogen ETHANE-PROPANE
Resolution 3.10 Å
9W5I AGO maturation complex (AMC): AGO2-miRNA duplex in complex with Hsp90 beta and co-chaperone p23 Deposited 2025-08-01 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Heteromer；Protein × 4 PDB declaration: hexameric
Chain D 1–859（859 aa）
Not recorded ATP ADENOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 3 ELECTRON MICROSCOPY
cryo-EM buffer pH 8
cryo-EM vitrification conditions Cryogen ETHANE
Resolution 2.63 Å
9YM9 Structure of AGO2 primary RISC (pri-RISC) Deposited 2025-10-09 Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY mmCIF provides none of the parsed conditions Resolution 3.79 Å
9YMA Structure of AGO2 vise-RISC Deposited 2025-10-09 Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY mmCIF provides none of the parsed conditions Resolution 3.87 Å
9YMB Structure of AGO2 wedging RISC (wedg-RISC) Deposited 2025-10-09 Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY mmCIF provides none of the parsed conditions Resolution 3.77 Å
9YMC Structure of AGO2 passenger-ejecting RISC (ej-RISC) Deposited 2025-10-09 Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: trimeric
Chain A 1–859（859 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY mmCIF provides none of the parsed conditions Resolution 3.28 Å
9YMD Structure of AGO2 mature RISC (mat-RISC) Deposited 2025-10-09 Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics Assembly 1 Protein–RNA Monomer；Protein × 1 PDB declaration: dimeric
Chain A 1–859（859 aa）
Not recorded No recorded non-water small molecule ELECTRON MICROSCOPY mmCIF provides none of the parsed conditions Resolution 3.45 Å

66 other PDB entries and 96 assemblies. Open the comparison page and filter oligomeric states

View Construct and Data Evidence
UniProt name AGO2_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 1–859； UniProt 1–859

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

SAXS scattering curve SAXS Profile

SAXS profile for 6mfn

P(r) Distance Distribution P(r) Distribution

P(r) distribution for 6mfn
Download Download
▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id6mfn
Deposition date deposition_date2018-09-11
Structure title titleHuman Argonaute2-miR-27a bound to HSUR1 target RNA
Keywords keywordsRNA-binding protein, microRNA, target directed microRNA decay, HYDROLASE-RNA complex; HYDROLASE/RNA
Experimental Method methodX-RAY DIFFRACTION
▼

3. SAXS Parameters (CRYSOL theoretical calculation) 3. SAXS Parameters (CRYSOL)

Radius of gyration Rg (Guinier) rg_guinier31.46 Å
Radius of gyration Rg (electron density) rg_electron31.22 Å
Forward intensity I(0) i0160334000.00
Molecular weight molecular_weight97411.0 kDa
Excluded volume excluded_volume120580 ų
Envelope volume envelope_volume157400 ų
Hydration-shell volume shell_volume41828 ų
Envelope diameter envelope_diameter109.9 Å
Shell Rg shell_rg38.45 Å
Envelope Rg envelope_rg31.17 Å
Shape Rg shape_rg31.22 Å
Total Rg total_rg31.81 Å
Total atoms total_atoms6823
Residues n_residues822
Spherical-harmonic order n_harmonics20
q range q_range— – 0.5000 Å−1
Data points n_points101
Shell type shell_typedirectional
Solvent electron density solvent_density0.3340 e/ų
Shell contrast contrast_shell0.0300 e/ų
CRYSOL version crysol_version4.1.3
▼

4. P(r) Distance Distribution (GNOM inversion) 4. P(r) Analysis (GNOM)

Maximum dimension Dmax dmax100.6 Å
Rg (real space) rg_real31.42 Å
Rg uncertainty (real space) rg_real_error0.77 Å
I(0) (real space) i0_real1.6030e+08
I(0) uncertainty (real space) i0_real_error2.3990e+06
Rg (reciprocal space) rg_reciprocal31.44 Å
I(0) (reciprocal space) i0_reciprocal160300000.0000
Solution quality estimate total_estimate0.8262
Solution quality rating solution_quality GOOD a GOOD solution
P(r) peaks n_peaks2
Primary peak position r_peak_primary38.2 Å
Skewness Skewness skewness0.295
Kurtosis Kurtosis kurtosis-0.433
Angular range angular_range— – 0.2500 Å−1
Current regularization parameter α current_alpha0.0000
Highest regularization parameter α highest_alpha35390000.0000
Real-space data points n_real_points51
GNOM version gnom_version4.1.3
Quality Criteria quality_criteria AN1: 0.000; Oscil: 0.912; Stabil: 1.000; Sysdev: 1.000; Positv: 1.000; Valcen: 1.000; Smooth: 0.000
▶

5. Crystallography and Experiment 5. Crystallography & Experiment

▶

6. Entities and Polymers Entities & Polymers (5)

▼

7. Fold Classification (SCOP + CATH) 3 domains

CATH v4.4 (3 domains)

Domain ID domain_id6mfnA02
Class class2 — Mainly Beta
Architecture architecture170 — Beta Complex
Topology topology260 — paz domain
Homologous superfamily homologous superfamily10 — paz domain
Domain ID domain_id6mfnA03
Class class3 — Alpha Beta
Architecture architecture40 — 3-Layer(aba) Sandwich
Topology topology50 — Rossmann fold
Homologous superfamily homologous superfamily2300 — Response regulator
Domain ID domain_id6mfnA04
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology420 — Nucleotidyltransferase; domain 5
Homologous superfamily homologous superfamily10 — Ribonuclease H-like superfamily/Ribonuclease H
▶

8. Citations (1)

▶

9. Files and Curves (10)
