8q91

Structure of the human 20S U5 snRNP core

Method: ELECTRON MICROSCOPY

▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

CD2 antigen cytoplasmic tail-binding protein 2

Homo sapiens

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein–RNA	Heteromer	Protein 13 RNA 1	Pre-mRNA-processing-splicing factor 8 × 1 （Q6P2Q9） U5 snRNA × 1 Pre-mRNA-processing factor 6 × 1 （O94906） Probable ATP-dependent RNA helicase DDX23 × 1 （Q9BUQ8） 116 kDa U5 small nuclear ribonucleoprotein component × 1 （Q15029） U5 small nuclear ribonucleoprotein 200 kDa helicase × 1 （O75643） Small nuclear ribonucleoprotein F × 1 （P62306） Small nuclear ribonucleoprotein G × 1 （P62308） Small nuclear ribonucleoprotein Sm D1 × 1 （P62314） Small nuclear ribonucleoprotein Sm D2 × 1 （P62316） Small nuclear ribonucleoprotein Sm D3 × 1 （P62318） ;Small nuclear ribonucleoprotein-associated proteins B and B' ; × 1 （P14678） Small nuclear ribonucleoprotein E × 1 （P62304） GUANOSINE-5'-TRIPHOSPHATE × 1	Consistent with all polymers

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	CD2B2_HUMAN
Isoform	—
PDB entities	1
Chains and sequence ranges	Author chain F； PDBConstruct 1–341； UniProt 1–341

Pre-mRNA-processing-splicing factor 8

Homo sapiens

UniProt Q6P2Q9

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein–RNA	Heteromer	Protein 13 RNA 1	CD2 antigen cytoplasmic tail-binding protein 2 × 1 （O95400） U5 snRNA × 1 Pre-mRNA-processing factor 6 × 1 （O94906） Probable ATP-dependent RNA helicase DDX23 × 1 （Q9BUQ8） 116 kDa U5 small nuclear ribonucleoprotein component × 1 （Q15029） U5 small nuclear ribonucleoprotein 200 kDa helicase × 1 （O75643） Small nuclear ribonucleoprotein F × 1 （P62306） Small nuclear ribonucleoprotein G × 1 （P62308） Small nuclear ribonucleoprotein Sm D1 × 1 （P62314） Small nuclear ribonucleoprotein Sm D2 × 1 （P62316） Small nuclear ribonucleoprotein Sm D3 × 1 （P62318） ;Small nuclear ribonucleoprotein-associated proteins B and B' ; × 1 （P14678） Small nuclear ribonucleoprotein E × 1 （P62304） GUANOSINE-5'-TRIPHOSPHATE × 1	Consistent with all polymers

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	PRP8_HUMAN
Isoform	—
PDB entities	2
Chains and sequence ranges	Author chain A； PDBConstruct 1–2335； UniProt 1–2335

Pre-mRNA-processing factor 6

Homo sapiens

UniProt O94906

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein–RNA	Heteromer	Protein 13 RNA 1	CD2 antigen cytoplasmic tail-binding protein 2 × 1 （O95400） Pre-mRNA-processing-splicing factor 8 × 1 （Q6P2Q9） U5 snRNA × 1 Probable ATP-dependent RNA helicase DDX23 × 1 （Q9BUQ8） 116 kDa U5 small nuclear ribonucleoprotein component × 1 （Q15029） U5 small nuclear ribonucleoprotein 200 kDa helicase × 1 （O75643） Small nuclear ribonucleoprotein F × 1 （P62306） Small nuclear ribonucleoprotein G × 1 （P62308） Small nuclear ribonucleoprotein Sm D1 × 1 （P62314） Small nuclear ribonucleoprotein Sm D2 × 1 （P62316） Small nuclear ribonucleoprotein Sm D3 × 1 （P62318） ;Small nuclear ribonucleoprotein-associated proteins B and B' ; × 1 （P14678） Small nuclear ribonucleoprotein E × 1 （P62304） GUANOSINE-5'-TRIPHOSPHATE × 1	Consistent with all polymers

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	PRP6_HUMAN
Isoform	—
PDB entities	4
Chains and sequence ranges	Author chain E； PDBConstruct 1–941； UniProt 1–941

Probable ATP-dependent RNA helicase DDX23

Homo sapiens

UniProt Q9BUQ8

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein–RNA	Heteromer	Protein 13 RNA 1	CD2 antigen cytoplasmic tail-binding protein 2 × 1 （O95400） Pre-mRNA-processing-splicing factor 8 × 1 （Q6P2Q9） U5 snRNA × 1 Pre-mRNA-processing factor 6 × 1 （O94906） 116 kDa U5 small nuclear ribonucleoprotein component × 1 （Q15029） U5 small nuclear ribonucleoprotein 200 kDa helicase × 1 （O75643） Small nuclear ribonucleoprotein F × 1 （P62306） Small nuclear ribonucleoprotein G × 1 （P62308） Small nuclear ribonucleoprotein Sm D1 × 1 （P62314） Small nuclear ribonucleoprotein Sm D2 × 1 （P62316） Small nuclear ribonucleoprotein Sm D3 × 1 （P62318） ;Small nuclear ribonucleoprotein-associated proteins B and B' ; × 1 （P14678） Small nuclear ribonucleoprotein E × 1 （P62304） GUANOSINE-5'-TRIPHOSPHATE × 1	Consistent with all polymers

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	DDX23_HUMAN
Isoform	—
PDB entities	5
Chains and sequence ranges	Author chain D； PDBConstruct 1–820； UniProt 1–820

116 kDa U5 small nuclear ribonucleoprotein component

Homo sapiens

UniProt Q15029

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein–RNA	Heteromer	Protein 13 RNA 1	CD2 antigen cytoplasmic tail-binding protein 2 × 1 （O95400） Pre-mRNA-processing-splicing factor 8 × 1 （Q6P2Q9） U5 snRNA × 1 Pre-mRNA-processing factor 6 × 1 （O94906） Probable ATP-dependent RNA helicase DDX23 × 1 （Q9BUQ8） U5 small nuclear ribonucleoprotein 200 kDa helicase × 1 （O75643） Small nuclear ribonucleoprotein F × 1 （P62306） Small nuclear ribonucleoprotein G × 1 （P62308） Small nuclear ribonucleoprotein Sm D1 × 1 （P62314） Small nuclear ribonucleoprotein Sm D2 × 1 （P62316） Small nuclear ribonucleoprotein Sm D3 × 1 （P62318） ;Small nuclear ribonucleoprotein-associated proteins B and B' ; × 1 （P14678） Small nuclear ribonucleoprotein E × 1 （P62304） GUANOSINE-5'-TRIPHOSPHATE × 1	Consistent with all polymers

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	U5S1_HUMAN
Isoform	—
PDB entities	6
Chains and sequence ranges	Author chain C； PDBConstruct 1–972； UniProt 1–972

U5 small nuclear ribonucleoprotein 200 kDa helicase

Homo sapiens

UniProt O75643

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein–RNA	Heteromer	Protein 13 RNA 1	CD2 antigen cytoplasmic tail-binding protein 2 × 1 （O95400） Pre-mRNA-processing-splicing factor 8 × 1 （Q6P2Q9） U5 snRNA × 1 Pre-mRNA-processing factor 6 × 1 （O94906） Probable ATP-dependent RNA helicase DDX23 × 1 （Q9BUQ8） 116 kDa U5 small nuclear ribonucleoprotein component × 1 （Q15029） Small nuclear ribonucleoprotein F × 1 （P62306） Small nuclear ribonucleoprotein G × 1 （P62308） Small nuclear ribonucleoprotein Sm D1 × 1 （P62314） Small nuclear ribonucleoprotein Sm D2 × 1 （P62316） Small nuclear ribonucleoprotein Sm D3 × 1 （P62318） ;Small nuclear ribonucleoprotein-associated proteins B and B' ; × 1 （P14678） Small nuclear ribonucleoprotein E × 1 （P62304） GUANOSINE-5'-TRIPHOSPHATE × 1	Consistent with all polymers

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	U520_HUMAN
Isoform	—
PDB entities	7
Chains and sequence ranges	Author chain B； PDBConstruct 1–2136； UniProt 1–2136

Small nuclear ribonucleoprotein F

Homo sapiens

UniProt P62306

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein–RNA	Heteromer	Protein 13 RNA 1	CD2 antigen cytoplasmic tail-binding protein 2 × 1 （O95400） Pre-mRNA-processing-splicing factor 8 × 1 （Q6P2Q9） U5 snRNA × 1 Pre-mRNA-processing factor 6 × 1 （O94906） Probable ATP-dependent RNA helicase DDX23 × 1 （Q9BUQ8） 116 kDa U5 small nuclear ribonucleoprotein component × 1 （Q15029） U5 small nuclear ribonucleoprotein 200 kDa helicase × 1 （O75643） Small nuclear ribonucleoprotein G × 1 （P62308） Small nuclear ribonucleoprotein Sm D1 × 1 （P62314） Small nuclear ribonucleoprotein Sm D2 × 1 （P62316） Small nuclear ribonucleoprotein Sm D3 × 1 （P62318） ;Small nuclear ribonucleoprotein-associated proteins B and B' ; × 1 （P14678） Small nuclear ribonucleoprotein E × 1 （P62304） GUANOSINE-5'-TRIPHOSPHATE × 1	Consistent with all polymers

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	RUXF_HUMAN
Isoform	—
PDB entities	8
Chains and sequence ranges	Author chain m； PDBConstruct 1–86； UniProt 1–86

Small nuclear ribonucleoprotein G

Homo sapiens

UniProt P62308

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein–RNA	Heteromer	Protein 13 RNA 1	CD2 antigen cytoplasmic tail-binding protein 2 × 1 （O95400） Pre-mRNA-processing-splicing factor 8 × 1 （Q6P2Q9） U5 snRNA × 1 Pre-mRNA-processing factor 6 × 1 （O94906） Probable ATP-dependent RNA helicase DDX23 × 1 （Q9BUQ8） 116 kDa U5 small nuclear ribonucleoprotein component × 1 （Q15029） U5 small nuclear ribonucleoprotein 200 kDa helicase × 1 （O75643） Small nuclear ribonucleoprotein F × 1 （P62306） Small nuclear ribonucleoprotein Sm D1 × 1 （P62314） Small nuclear ribonucleoprotein Sm D2 × 1 （P62316） Small nuclear ribonucleoprotein Sm D3 × 1 （P62318） ;Small nuclear ribonucleoprotein-associated proteins B and B' ; × 1 （P14678） Small nuclear ribonucleoprotein E × 1 （P62304） GUANOSINE-5'-TRIPHOSPHATE × 1	Consistent with all polymers

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	RUXG_HUMAN
Isoform	—
PDB entities	9
Chains and sequence ranges	Author chain n； PDBConstruct 1–76； UniProt 1–76

Small nuclear ribonucleoprotein Sm D1

Homo sapiens

UniProt P62314

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein–RNA	Heteromer	Protein 13 RNA 1	CD2 antigen cytoplasmic tail-binding protein 2 × 1 （O95400） Pre-mRNA-processing-splicing factor 8 × 1 （Q6P2Q9） U5 snRNA × 1 Pre-mRNA-processing factor 6 × 1 （O94906） Probable ATP-dependent RNA helicase DDX23 × 1 （Q9BUQ8） 116 kDa U5 small nuclear ribonucleoprotein component × 1 （Q15029） U5 small nuclear ribonucleoprotein 200 kDa helicase × 1 （O75643） Small nuclear ribonucleoprotein F × 1 （P62306） Small nuclear ribonucleoprotein G × 1 （P62308） Small nuclear ribonucleoprotein Sm D2 × 1 （P62316） Small nuclear ribonucleoprotein Sm D3 × 1 （P62318） ;Small nuclear ribonucleoprotein-associated proteins B and B' ; × 1 （P14678） Small nuclear ribonucleoprotein E × 1 （P62304） GUANOSINE-5'-TRIPHOSPHATE × 1	Consistent with all polymers

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	SMD1_HUMAN
Isoform	—
PDB entities	10
Chains and sequence ranges	Author chain i； PDBConstruct 1–119； UniProt 1–119

Small nuclear ribonucleoprotein Sm D2

Homo sapiens

UniProt P62316

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein–RNA	Heteromer	Protein 13 RNA 1	CD2 antigen cytoplasmic tail-binding protein 2 × 1 （O95400） Pre-mRNA-processing-splicing factor 8 × 1 （Q6P2Q9） U5 snRNA × 1 Pre-mRNA-processing factor 6 × 1 （O94906） Probable ATP-dependent RNA helicase DDX23 × 1 （Q9BUQ8） 116 kDa U5 small nuclear ribonucleoprotein component × 1 （Q15029） U5 small nuclear ribonucleoprotein 200 kDa helicase × 1 （O75643） Small nuclear ribonucleoprotein F × 1 （P62306） Small nuclear ribonucleoprotein G × 1 （P62308） Small nuclear ribonucleoprotein Sm D1 × 1 （P62314） Small nuclear ribonucleoprotein Sm D3 × 1 （P62318） ;Small nuclear ribonucleoprotein-associated proteins B and B' ; × 1 （P14678） Small nuclear ribonucleoprotein E × 1 （P62304） GUANOSINE-5'-TRIPHOSPHATE × 1	Consistent with all polymers

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	SMD2_HUMAN
Isoform	—
PDB entities	11
Chains and sequence ranges	Author chain j； PDBConstruct 1–118； UniProt 1–118

Small nuclear ribonucleoprotein Sm D3

Homo sapiens

UniProt P62318

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein–RNA	Heteromer	Protein 13 RNA 1	CD2 antigen cytoplasmic tail-binding protein 2 × 1 （O95400） Pre-mRNA-processing-splicing factor 8 × 1 （Q6P2Q9） U5 snRNA × 1 Pre-mRNA-processing factor 6 × 1 （O94906） Probable ATP-dependent RNA helicase DDX23 × 1 （Q9BUQ8） 116 kDa U5 small nuclear ribonucleoprotein component × 1 （Q15029） U5 small nuclear ribonucleoprotein 200 kDa helicase × 1 （O75643） Small nuclear ribonucleoprotein F × 1 （P62306） Small nuclear ribonucleoprotein G × 1 （P62308） Small nuclear ribonucleoprotein Sm D1 × 1 （P62314） Small nuclear ribonucleoprotein Sm D2 × 1 （P62316） ;Small nuclear ribonucleoprotein-associated proteins B and B' ; × 1 （P14678） Small nuclear ribonucleoprotein E × 1 （P62304） GUANOSINE-5'-TRIPHOSPHATE × 1	Consistent with all polymers

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	SMD3_HUMAN
Isoform	—
PDB entities	12
Chains and sequence ranges	Author chain k； PDBConstruct 1–126； UniProt 1–126

;Small nuclear ribonucleoprotein-associated proteins B and B' ;

Homo sapiens

UniProt P14678

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein–RNA	Heteromer	Protein 13 RNA 1	CD2 antigen cytoplasmic tail-binding protein 2 × 1 （O95400） Pre-mRNA-processing-splicing factor 8 × 1 （Q6P2Q9） U5 snRNA × 1 Pre-mRNA-processing factor 6 × 1 （O94906） Probable ATP-dependent RNA helicase DDX23 × 1 （Q9BUQ8） 116 kDa U5 small nuclear ribonucleoprotein component × 1 （Q15029） U5 small nuclear ribonucleoprotein 200 kDa helicase × 1 （O75643） Small nuclear ribonucleoprotein F × 1 （P62306） Small nuclear ribonucleoprotein G × 1 （P62308） Small nuclear ribonucleoprotein Sm D1 × 1 （P62314） Small nuclear ribonucleoprotein Sm D2 × 1 （P62316） Small nuclear ribonucleoprotein Sm D3 × 1 （P62318） Small nuclear ribonucleoprotein E × 1 （P62304） GUANOSINE-5'-TRIPHOSPHATE × 1	Consistent with all polymers

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	RSMB_HUMAN
Isoform	—
PDB entities	13
Chains and sequence ranges	Author chain h； PDBConstruct 1–240； UniProt 1–240

Small nuclear ribonucleoprotein E

Homo sapiens

UniProt P62304

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein–RNA	Heteromer	Protein 13 RNA 1	CD2 antigen cytoplasmic tail-binding protein 2 × 1 （O95400） Pre-mRNA-processing-splicing factor 8 × 1 （Q6P2Q9） U5 snRNA × 1 Pre-mRNA-processing factor 6 × 1 （O94906） Probable ATP-dependent RNA helicase DDX23 × 1 （Q9BUQ8） 116 kDa U5 small nuclear ribonucleoprotein component × 1 （Q15029） U5 small nuclear ribonucleoprotein 200 kDa helicase × 1 （O75643） Small nuclear ribonucleoprotein F × 1 （P62306） Small nuclear ribonucleoprotein G × 1 （P62308） Small nuclear ribonucleoprotein Sm D1 × 1 （P62314） Small nuclear ribonucleoprotein Sm D2 × 1 （P62316） Small nuclear ribonucleoprotein Sm D3 × 1 （P62318） ;Small nuclear ribonucleoprotein-associated proteins B and B' ; × 1 （P14678） GUANOSINE-5'-TRIPHOSPHATE × 1	Consistent with all polymers

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	RUXE_HUMAN
Isoform	—
PDB entities	14
Chains and sequence ranges	Author chain l； PDBConstruct 1–92； UniProt 1–92

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id	8q91
Deposition date deposition_date	2023-08-19
Structure title title	Structure of the human 20S U5 snRNP core
Keywords keywords	snRNP, CD2BP2, spliceosome, U5, SPLICING; SPLICING
Experimental Method method	ELECTRON MICROSCOPY

▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

8q91__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

8q91__assembly_1__model_1 | I(q)

100 plotted points; both axes use logarithmic scales.

8q91__assembly_1__model_1 | P(r) · Pending

P(r) will be calculated and displayed separately for the same assembly/model.

Rg（Guinier）	58.13 Å
Rg (electron density)	57.43 Å
Total Rg	57.18 Å
Atom count	26706
Residues	3419
Excluded volume	462510 Å³
Maximum q	0.500 Å⁻¹

Assembly	Model	Structure unit	Oligomeric description	Status	CRYSOL	Actions
1	1	`8q91__assembly_1__model_1`	14-meric （14）	Success	4.1.3-1-20251215 (887e7ef)	View Download

▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (15)

Entity 1 Entity 1 polymer

Description description	CD2 antigen cytoplasmic tail-binding protein 2
Molecular weight formula_weight	37687.4 kDa
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	F
Atom count atom_count	26706

MPKRKVTFQGVGDEEDEDEIIVPKKKLVDPVAGSGGPGSRFKGKHSLDSDEEEDDDDGGSSKYDILASEDVEGQEAATLPSEGGVRITPFNLQEEMEEGHFDADGNYFLNRDAQIRDSWLDNIDWVKIRERPPGQRQASDSEEEDSLGQTSMSAQALLEGLLELLLPRETVAGALRRLGARGGGKGRKGPGQPSSPQRLDRLSGLADQMVARGNLGVYQETRERLAMRLKGLGCQTLGPHNPTPPPSLDMFAEELAEEELETPTPTQRGEAESRGDGLVDVMWEYKWENTGDAELYGPFTSAQMQTWVSEGYFPDGVYCRKLDPPGGQFYNSKRIDFDLYT

Source Source

Source organism organism	Homo sapiens
Common name common_name	human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Homo sapiens

Entity 2 Entity 2 polymer

Description description	Pre-mRNA-processing-splicing factor 8
Molecular weight formula_weight	273974.2 kDa
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	A

MAGVFPYRGPGNPVPGPLAPLPDYMSEEKLQEKARKWQQLQAKRYAEKRKFGFVDAQKEDMPPEHVRKIIRDHGDMTNRKFRHDKRVYLGALKYMPHAVLKLLENMPMPWEQIRDVPVLYHITGAISFVNEIPWVIEPVYISQWGSMWIMMRREKRDRRHFKRMRFPPFDDEEPPLDYADNILDVEPLEAIQLELDPEEDAPVLDWFYDHQPLRDSRKYVNGSTYQRWQFTLPMMSTLYRLANQLLTDLVDDNYFYLFDLKAFFTSKALNMAIPGGPKFEPLVRDINLQDEDWNEFNDINKIIIRQPIRTEYKIAFPYLYNNLPHHVHLTWYHTPNVVFIKTEDPDLPAFYFDPLINPISHRHSVKSQEPLPDDDEEFELPEFVEPFLKDTPLYTDNTANGIALLWAPRPFNLRSGRTRRALDIPLVKNWYREHCPAGQPVKVRVSYQKLLKYYVLNALKHRPPKAQKKRYLFRSFKATKFFQSTKLDWVEVGLQVCRQGYNMLNLLIHRKNLNYLHLDYNFNLKPVKTLTTKERKKSRFGNAFHLCREVLRLTKLVVDSHVQYRLGNVDAFQLADGLQYIFAHVGQLTGMYRYKYKLMRQIRMCKDLKHLIYYRFNTGPVGKGPGCGFWAAGWRVWLFFMRGITPLLERWLGNLLARQFEGRHSKGVAKTVTKQRVESHFDLELRAAVMHDILDMMPEGIKQNKARTILQHLSEAWRCWKANIPWKVPGLPTPIENMILRYVKAKADWWTNTAHYNRERIRRGATVDKTVCKKNLGRLTRLYLKAEQERQHNYLKDGPYITAEEAVAVYTTTVHWLESRRFSPIPFPPLSYKHDTKLLILALERLKEAYSVKSRLNQSQREELGLIEQAYDNPHEALSRIKRHLLTQRAFKEVGIEFMDLYSHLVPVYDVEPLEKITDAYLDQYLWYEADKRRLFPPWIKPADTEPPPLLVYKWCQGINNLQDVWETSEGECNVMLESRFEKMYEKIDLTLLNRLLRLIVDHNIADYMTAKNNVVINYKDMNHTNSYGIIRGLQFASFIVQYYGLVMDLLVLGLHRASEMAGPPQMPNDFLSFQDIATEAAHPIRLFCRYIDRIHIFFRFTADEARDLIQRYLTEHPDPNNENIVGYNNKKCWPRDARMRLMKHDVNLGRAVFWDIKNRLPRSVTTVQWENSFVSVYSKDNPNLLFNMCGFECRILPKCRTSYEEFTHKDGVWNLQNEVTKERTAQCFLRVDDESMQRFHNRVRQILMASGSTTFTKIVNKWNTALIGLMTYFREAVVNTQELLDLLVKCENKIQTRIKIGLNSKMPSRFPPVVFYTPKELGGLGMLSMGHVLIPQSDLRWSKQTDVGITHFRSGMSHEEDQLIPNLYRYIQPWESEFIDSQRVWAEYALKRQEAIAQNRRLTLEDLEDSWDRGIPRINTLFQKDRHTLAYDKGWRVRTDFKQYQVLKQNPFWWTHQRHDGKLWNLNNYRTDMIQALGGVEGILEHTLFKGTYFPTWEGLFWEKASGFEESMKWKKLTNAQRSGLNQIPNRRFTLWWSPTINRANVYVGFQVQLDLTGIFMHGKIPTLKISLIQIFRAHLWQKIHESIVMDLCQVFDQELDALEIETVQKETIHPRKSYKMNSSCADILLFASYKWNVSRPSLLADSKDVMDSTTTQKYWIDIQLRWGDYDSHDIERYARAKFLDYTTDNMSIYPSPTGVLIAIDLAYNLHSAYGNWFPGSKPLIQQAMAKIMKANPALYVLRERIRKGLQLYSSEPTEPYLSSQNYGELFSNQIIWFVDDTNVYRVTIHKTFEGNLTTKPINGAIFIFNPRTGQLFLKIIHTSVWAGQKRLGQLAKWKTAEEVAALIRSLPVEEQPKQIIVTRKGMLDPLEVHLLDFPNIVIKGSELQLPFQACLKVEKFGDLILKATEPQMVLFNLYDDWLKTISSYTAFSRLILILRALHVNNDRAKVILKPDKTTITEPHHIWPTLTDEEWIKVEVQLKDLILADYGKKNNVNVASLTQSEIRDIILGMEISAPSQQRQQIAEIEKQTKEQSQLTATQTRTVNKHGDEIITSTTSNYETQTFSSKTEWRVRAISAANLHLRTNHIYVSSDDIKETGYTYILPKNVLKKFICISDLRAQIAGYLYGVSPPDNPQVKEIRCIVMVPQWGTHQTVHLPGQLPQHEYLKEMEPLGWIHTQPNESPQLSPQDVTTHAKIMADNPSWDGEKTIIITCSFTPGSCTLTAYKLTPSGYEWGRQNTDKGNNPKGYLPSHYERVQMLLSDRFLGFFMVPAQSSWNYNFMGVRHDPNMKYELQLANPKEFYHEVHRPSHFLNFALLQEGEVYSADREDLYA

Source Source

Source organism organism	Homo sapiens
Common name common_name	human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Homo sapiens

Entity 3 Entity 3 polymer

Description description	U5 snRNA
Molecular weight formula_weight	37254.9 kDa
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polyribonucleotide
Chain IDs strand_id	5

AUACUCUGGUUUCUCUUCAGAUCGCAUAAAUCUUUCGCCUUUUACUAAAGAUUUCCGUGGAGAGGAACAACUCUGAGUCUUAACCCAAUUUUUUGAGGCCUUGCUUUGGCAAGGCUA

Source Source

Source organism organism	Homo sapiens
Common name common_name	human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Homo sapiens

Entity 4 Entity 4 polymer

Description description	Pre-mRNA-processing factor 6
Molecular weight formula_weight	107092.2 kDa
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	E

MNKKKKPFLGMPAPLGYVPGLGRGATGFTTRSDIGPARDANDPVDDRHAPPGKRTVGDQMKKNQAADDDDEDLNDTNYDEFNGYAGSLFSSGPYEKDDEEADAIYAALDKRMDERRKERREQREKEEIEKYRMERPKIQQQFSDLKRKLAEVTEEEWLSIPEVGDARNKRQRNPRYEKLTPVPDSFFAKHLQTGENHTSVDPRQTQFGGLNTPYPGGLNTPYPGGMTPGLMTPGTGELDMRKIGQARNTLMDMRLSQVSDSVSGQTVVDPKGYLTDLNSMIPTHGGDINDIKKARLLLKSVRETNPHHPPAWIASARLEEVTGKLQVARNLIMKGTEMCPKSEDVWLEAARLQPGDTAKAVVAQAVRHLPQSVRIYIRAAELETDIRAKKRVLRKALEHVPNSVRLWKAAVELEEPEDARIMLSRAVECCPTSVELWLALARLETYENARKVLNKARENIPTDRHIWITAAKLEEANGNTQMVEKIIDRAITSLRANGVEINREQWIQDAEECDRAGSVATCQAVMRAVIGIGIEEEDRKHTWMEDADSCVAHNALECARAIYAYALQVFPSKKSVWLRAAYFEKNHGTRESLEALLQRAVAHCPKAEVLWLMGAKSKWLAGDVPAARSILALAFQANPNSEEIWLAAVKLESENDEYERARRLLAKARSSAPTARVFMKSVKLEWVQDNIRAAQDLCEEALRHYEDFPKLWMMKGQIEEQKEMMEKAREAYNQGLKKCPHSTPLWLLLSRLEEKIGQLTRARAILEKSRLKNPKNPGLWLESVRLEYRAGLKNIANTLMAKALQECPNSGILWSEAIFLEARPQRRTKSVDALKKCEHDPHVLLAVAKLFWSQRKITKAREWFHRTVKIDSDLGDAWAFFYKFELQHGTEEQQEEVRKRCESAEPRHGELWCAVSKDIANWQKKIGDILRLVAGRIKNTF

Source Source

Source organism organism	Homo sapiens
Common name common_name	human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Homo sapiens

Entity 5 Entity 5 polymer

Description description	Probable ATP-dependent RNA helicase DDX23
Molecular weight formula_weight	95785.1 kDa
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	D

MAGELADKKDRDASPSKEERKRSRTPDRERDRDRDRKSSPSKDRKRHRSRDRRRGGSRSRSRSRSKSAERERRHKERERDKERDRNKKDRDRDKDGHRRDKDRKRSSLSPGRGKDFKSRKDRDSKKDEEDEHGDKKPKAQPLSLEELLAKKKAEEEAEAKPKFLSKAEREAEALKRRQQEVEERQRMLEEERKKRKQFQDLGRKMLEDPQERERRERRERMERETNGNEDEEGRQKIREEKDKSKELHAIKERYLGGIKKRRRTRHLNDRKFVFEWDASEDTSIDYNPLYKERHQVQLLGRGFIAGIDLKQQKREQSRFYGDLMEKRRTLEEKEQEEARLRKLRKKEAKQRWDDRHWSQKKLDEMTDRDWRIFREDYSITTKGGKIPNPIRSWKDSSLPPHILEVIDKCGYKEPTPIQRQAIPIGLQNRDIIGVAETGSGKTAAFLIPLLVWITTLPKIDRIEESDQGPYAIILAPTRELAQQIEEETIKFGKPLGIRTVAVIGGISREDQGFRLRMGCEIVIATPGRLIDVLENRYLVLSRCTYVVLDEADRMIDMGFEPDVQKILEHMPVSNQKPDTDEAEDPEKMLANFESGKHKYRQTVMFTATMPPAVERLARSYLRRPAVVYIGSAGKPHERVEQKVFLMSESEKRKKLLAILEQGFDPPIIIFVNQKKGCDVLAKSLEKMGYNACTLHGGKGQEQREFALSNLKAGAKDILVATDVAGRGIDIQDVSMVVNYDMAKNIEDYIHRIGRTGRAGKSGVAITFLTKEDSAVFYELKQAILESPVSSCPPELANHPDAQHKPGTILTKKRREETIFA

Source Source

Source organism organism	Homo sapiens
Common name common_name	human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Homo sapiens

Entity 6 Entity 6 polymer

Description description	116 kDa U5 small nuclear ribonucleoprotein component
Molecular weight formula_weight	109560.6 kDa
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	C

MDTDLYDEFGNYIGPELDSDEDDDELGRETKDLDEMDDDDDDDDVGDHDDDHPGMEVVLHEDKKYYPTAEEVYGPEVETIVQEEDTQPLTEPIIKPVKTKKFTLMEQTLPVTVYEMDFLADLMDNSELIRNVTLCGHLHHGKTCFVDCLIEQTHPEIRKRYDQDLCYTDILFTEQERGVGIKSTPVTVVLPDTKGKSYLFNIMDTPGHVNFSDEVTAGLRISDGVVLFIDAAEGVMLNTERLIKHAVQERLAVTVCINKIDRLILELKLPPTDAYYKLRHIVDEVNGLISMYSTDENLILSPLLGNVCFSSSQYSICFTLGSFAKIYADTFGDINYQEFAKRLWGDIYFNPKTRKFTKKAPTSSSQRSFVEFILEPLYKILAQVVGDVDTSLPRTLDELGIHLTKEELKLNIRPLLRLVCKKFFGEFTGFVDMCVQHIPSPKVGAKPKIEHTYTGGVDSDLGEAMSDCDPDGPLMCHTTKMYSTDDGVQFHAFGRVLSGTIHAGQPVKVLGENYTLEDEEDSQICTVGRLWISVARYHIEVNRVPAGNWVLIEGVDQPIVKTATITEPRGNEEAQIFRPLKFNTTSVIKIAVEPVNPSELPKMLDGLRKVNKSYPSLTTKVEESGEHVILGTGELYLDCVMHDLRKMYSEIDIKVADPVVTFCETVVETSSLKCFAETPNKKNKITMIAEPLEKGLAEDIENEVVQITWNRKKLGEFFQTKYDWDLLAARSIWAFGPDATGPNILVDDTLPSEVDKALLGSVKDSIVQGFQWGTREGPLCDELIRNVKFKILDAVVAQEPLHRGGGQIIPTARRVVYSAFLMATPRLMEPYYFVEVQAPADCVSAVYTVLARRRGHVTQDAPIPGSPLYTIKAFIPAIDSFGFETDLRTHTQGQAFSLSVFHHWQIVPGDPLDKSIVIRPLEPQPAPHLAREFMIKTRRRKGLSEDVSISKFFDDPMLLELAKQDVVLNYPM

Source Source

Source organism organism	Homo sapiens
Common name common_name	human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Homo sapiens

Entity 7 Entity 7 polymer

Description description	U5 small nuclear ribonucleoprotein 200 kDa helicase
Molecular weight formula_weight	244823.4 kDa
EC 编号 ec_number	3.6.4.13
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	B

MADVTARSLQYEYKANSNLVLQADRSLIDRTRRDEPTGEVLSLVGKLEGTRMGDKAQRTKPQMQEERRAKRRKRDEDRHDINKMKGYTLLSEGIDEMVGIIYKPKTKETRETYEVLLSFIQAALGDQPRDILCGAADEVLAVLKNEKLRDKERRKEIDLLLGQTDDTRYHVLVNLGKKITDYGGDKEIQNMDDNIDETYGVNVQFESDEEEGDEDVYGEVREEASDDDMEGDEAVVRCTLSANLVASGELMSSKKKDLHPRDIDAFWLQRQLSRFYDDAIVSQKKADEVLEILKTASDDRECENQLVLLLGFNTFDFIKVLRQHRMMILYCTLLASAQSEAEKERIMGKMEADPELSKFLYQLHETEKEDLIREERSRRERVRQSRMDTDLETMDLDQGGEALAPRQVLDLEDLVFTQGSHFMANKRCQLPDGSFRRQRKGYEEVHVPALKPKPFGSEEQLLPVEKLPKYAQAGFEGFKTLNRIQSKLYRAALETDENLLLCAPTGAGKTNVALMCMLREIGKHINMDGTINVDDFKIIYIAPMRSLVQEMVGSFGKRLATYGITVAELTGDHQLCKEEISATQIIVCTPEKWDIITRKGGERTYTQLVRLIILDEIHLLHDDRGPVLEALVARAIRNIEMTQEDVRLIGLSATLPNYEDVATFLRVDPAKGLFYFDNSFRPVPLEQTYVGITEKKAIKRFQIMNEIVYEKIMEHAGKNQVLVFVHSRKETGKTARAIRDMCLEKDTLGLFLREGSASTEVLRTEAEQCKNLELKDLLPYGFAIHHAGMTRVDRTLVEDLFADKHIQVLVSTATLAWGVNLPAHTVIIKGTQVYSPEKGRWTELGALDILQMLGRAGRPQYDTKGEGILITSHGELQYYLSLLNQQLPIESQMVSKLPDMLNAEIVLGNVQNAKDAVNWLGYAYLYIRMLRSPTLYGISHDDLKGDPLLDQRRLDLVHTAALMLDKNNLVKYDKKTGNFQVTELGRIASHYYITNDTVQTYNQLLKPTLSEIELFRVFSLSSEFKNITVREEEKLELQKLLERVPIPVKESIEEPSAKINVLLQAFISQLKLEGFALMADMVYVTQSAGRLMRAIFEIVLNRGWAQLTDKTLNLCKMIDKRMWQSMCPLRQFRKLPEEVVKKIEKKNFPFERLYDLNHNEIGELIRMPKMGKTIHKYVHLFPKLELSVHLQPITRSTLKVELTITPDFQWDEKVHGSSEAFWILVEDVDSEVILHHEYFLLKAKYAQDEHLITFFVPVFEPLPPQYFIRVVSDRWLSCETQLPVSFRHLILPEKYPPPTELLDLQPLPVSALRNSAFESLYQDKFPFFNPIQTQVFNTVYNSDDNVFVGAPTGSGKTICAEFAILRMLLQSSEGRCVYITPMEALAEQVYMDWYEKFQDRLNKKVVLLTGETSTDLKLLGKGNIIISTPEKWDILSRRWKQRKNVQNINLFVVDEVHLIGGENGPVLEVICSRMRYISSQIERPIRIVALSSSLSNAKDVAHWLGCSATSTFNFHPNVRPVPLELHIQGFNISHTQTRLLSMAKPVYHAITKHSPKKPVIVFVPSRKQTRLTAIDILTTCAADIQRQRFLHCTEKDLIPYLEKLSDSTLKETLLNGVGYLHEGLSPMERRLVEQLFSSGAIQVVVASRSLCWGMNVAAHLVIIMDTQYYNGKIHAYVDYPIYDVLQMVGHANRPLQDDEGRCVIMCQGSKKDFFKKFLYEPLPVESHLDHCMHDHFNAEIVTKTIENKQDAVDYLTWTFLYRRMTQNPNYYNLQGISHRHLSDHLSELVEQTLSDLEQSKCISIEDEMDVAPLNLGMIAAYYYINYTTIELFSMSLNAKTKVRGLIEIISNAAEYENIPIRHHEDNLLRQLAQKVPHKLNNPKFNDPHVKTNLLLQAHLSRMQLSAELQSDTEEILSKAIRLIQACVDVLSSNGWLSPALAAMELAQMVTQAMWSKDSYLKQLPHFTSEHIKRCTDKGVESVFDIMEMEDEERNALLQLTDSQIADVARFCNRYPNIELSYEVVDKDSIRSGGPVVVLVQLEREEEVTGPVIAPLFPQKREEGWWVVIGDAKSNSLISIKRLTLQQKAKVKLDFVAPATGAHNYTLYFMSDAYMGCDQEYKFSVDVKEAETDSDSD

Source Source

Source organism organism	Homo sapiens
Common name common_name	human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Homo sapiens

Entity 8 Entity 8 polymer

Description description	Small nuclear ribonucleoprotein F
Molecular weight formula_weight	9734.2 kDa
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	m

MSLPLNPKPFLNGLTGKPVMVKLKWGMEYKGYLVSVDGYMNMQLANTEEYIDGALSGHLGEVLIRCNNVLYIRGVEEEEEDGEMRE

Source Source

Source organism organism	Homo sapiens
Common name common_name	human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Homo sapiens

Entity 9 Entity 9 polymer

Description description	Small nuclear ribonucleoprotein G
Molecular weight formula_weight	8508.1 kDa
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	n

MSKAHPPELKKFMDKKLSLKLNGGRHVQGILRGFDPFMNLVIDECVEMATSGQQNNIGMVVIRGNSIIMLEALERV

Source Source

Source organism organism	Homo sapiens
Common name common_name	human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Homo sapiens

Entity 10 Entity 10 polymer

Description description	Small nuclear ribonucleoprotein Sm D1
Molecular weight formula_weight	13310.7 kDa
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	i

MKLVRFLMKLSHETVTIELKNGTQVHGTITGVDVSMNTHLKAVKMTLKNREPVQLETLSIRGNNIRYFILPDSLPLDTLLVDVEPKVKSKKREAVAGRGRGRGRGRGRGRGRGRGGPRR

Source Source

Source organism organism	Homo sapiens
Common name common_name	human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Homo sapiens

Entity 11 Entity 11 polymer

Description description	Small nuclear ribonucleoprotein Sm D2
Molecular weight formula_weight	13551.9 kDa
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	j

MSLLNKPKSEMTPEELQKREEEEFNTGPLSVLTQSVKNNTQVLINCRNNKKLLGRVKAFDRHCNMVLENVKEMWTEVPKSGKGKKKSKPVNKDRYISKMFLRGDSVIVVLRNPLIAGK

Source Source

Source organism organism	Homo sapiens
Common name common_name	human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Homo sapiens

Entity 12 Entity 12 polymer

Description description	Small nuclear ribonucleoprotein Sm D3
Molecular weight formula_weight	13940.3 kDa
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	k

MSIGVPIKVLHEAEGHIVTCETNTGEVYRGKLIEAEDNMNCQMSNITVTYRDGRVAQLEQVYIRGSKIRFLILPDMLKNAPMLKSMKNKNQGSGAGRGKAAILKAQVAARGRGRGMGRGNIFQKRR

Source Source

Source organism organism	Homo sapiens
Common name common_name	human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Homo sapiens

Entity 13 Entity 13 polymer

Description description	;Small nuclear ribonucleoprotein-associated proteins B and B' ;
Molecular weight formula_weight	24642.1 kDa
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	h

MTVGKSSKMLQHIDYRMRCILQDGRIFIGTFKAFDKHMNLILCDCDEFRKIKPKNSKQAEREEKRVLGLVLLRGENLVSMTVEGPPPKDTGIARVPLAGAAGGPGIGRAAGRGIPAGVPMPQAPAGLAGPVRGVGGPSQQVMTPQGRGTVAAAAAAATASIAGAPTQYPPGRGGPPPPMGRGAPPPGMMGPPPGMRPPMGPPMGIPPGRGTPMGMPPPGMRPPPPGMRGPPPPGMRPPRP

Source Source

Source organism organism	Homo sapiens
Common name common_name	human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Homo sapiens

Entity 14 Entity 14 polymer

Description description	Small nuclear ribonucleoprotein E
Molecular weight formula_weight	10817.6 kDa
Source method src_method	man
Copy count entity_count	1

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	l

MAYRGQGQKVQKVMVQPINLIFRYLQNRSRIQVWLYEQVNMRIEGCIIGFDEYMNLVLDDAEEIHSKTKSRKQLGRIMLKGDNITLLQSVSN

Source Source

Source organism organism	Homo sapiens
Common name common_name	human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Homo sapiens

Entity 15 Entity 15 non-polymer

Description description	GUANOSINE-5'-TRIPHOSPHATE
Molecular weight formula_weight	523.2 kDa
Source method src_method	syn
Copy count entity_count	1

▶

Unit-cell length a length_a	1.000 Å
Unit-cell length b length_b	1.000 Å
Unit-cell length c length_c	1.000 Å
Unit-cell angle α angle_alpha	90.00 °
Unit-cell angle β angle_beta	90.00 °
Unit-cell angle γ angle_gamma	90.00 °
Molecules per unit cell Z z_pdb	—

Space group space_group	P 1
Space-group number int_tables_number	1
Crystal system crystal_system	—

Resolution resolution	3.10 Å
Resolution测定Method resolution_method	—
颗粒数 num_particles	76918

Structure of the human 20S U5 snRNP core

1. Protein Identity and Related Structures Protein Identity & Related Structures

CD2 antigen cytoplasmic tail-binding protein 2

State in the Current Structure

Other States of the Same Protein in the Database

Monomer

Homodimer

Homotetramer

Other homooligomers

Heteromeric or nucleic-acid complex

Pre-mRNA-processing-splicing factor 8

State in the Current Structure

Other States of the Same Protein in the Database

Monomer

Homodimer

Homotetramer

Other homooligomers

Heteromeric or nucleic-acid complex

Pre-mRNA-processing factor 6

State in the Current Structure

Other States of the Same Protein in the Database

Monomer

Homodimer

Homotetramer

Other homooligomers

Heteromeric or nucleic-acid complex

Probable ATP-dependent RNA helicase DDX23

State in the Current Structure

Other States of the Same Protein in the Database

Monomer

Homodimer

Homotetramer

Other homooligomers

Heteromeric or nucleic-acid complex

116 kDa U5 small nuclear ribonucleoprotein component

State in the Current Structure

Other States of the Same Protein in the Database

Monomer

Homodimer

Homotetramer

Other homooligomers

Heteromeric or nucleic-acid complex

U5 small nuclear ribonucleoprotein 200 kDa helicase

State in the Current Structure

Other States of the Same Protein in the Database

Monomer

Homodimer

Homotetramer

Other homooligomers

Heteromeric or nucleic-acid complex

Small nuclear ribonucleoprotein F

State in the Current Structure

Other States of the Same Protein in the Database

Monomer

Homodimer

Homotetramer

Other homooligomers

Heteromeric or nucleic-acid complex

Small nuclear ribonucleoprotein G

State in the Current Structure

Other States of the Same Protein in the Database

Monomer

Homodimer

Homotetramer

Other homooligomers

Heteromeric or nucleic-acid complex

Small nuclear ribonucleoprotein Sm D1

State in the Current Structure

Other States of the Same Protein in the Database

Monomer

Homodimer

Homotetramer

Other homooligomers

Heteromeric or nucleic-acid complex

Small nuclear ribonucleoprotein Sm D2

State in the Current Structure

Other States of the Same Protein in the Database

Monomer

Homodimer

Homotetramer
