Tubulin alpha-1B chain
OrganismNot specified
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein heterocomplex Heteromer Protein × 6 PDB declaration: hexameric（6） Consistent with protein copy count | Chain A； UniProt 1–451 Chain C； UniProt 1–451 | Not recorded | Tubulin beta chain × 2 （A0A287AGU7） Stathmin-4 × 1 （P63042） Tubulin tyrosine ligase × 1 （E1BQ43） GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 5 CA CALCIUM ION × 4 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 IC1 3-[(2,4,6-TRIMETHOXY-PHENYL)-METHYLENE]-INDOLIN-2-ONE × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；pH 6.7；277 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCL2, pH 6.7 | Resolution 2.85 Å R-free 0.233 |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 7DB9 | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 3J8X High-resolution structure of no-nucleotide kinesin on microtubules Deposited 2014-11-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
25 mM PIPES, 25 mM NaCl, 2 mM MgCl2, 1 mM EGTA；pH 6.8；25 mM PIPES, 25 mM NaCl, 2 mM MgCl2, 1 mM EGTA
cryo-EM vitrification conditions
No glow discharge was applied. After sample application to grid, liquid was mostly 'wicked' away by edgewise application of filter paper. Subsequently, blotting and plunge freezing were performed with ~0.5 second delay after blotting but prior to plunging.；Cryogen ETHANE；No glow discharge was applied. After sample application to grid, liquid was mostly 'wicked' away by edgewise application of filter paper. Subsequently, blotting and plunge freezing were performed with ~0.5 second delay after blotting but prior to plunging into liquid ethane.
|
Resolution 5.00 Å |
| 3J8Y High-resolution structure of ATP analog-bound kinesin on microtubules Deposited 2014-11-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | ATP ADENOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
25 mM PIPES, 25 mM NaCl, 2 mM MgCl2, 1 mM EGTA；pH 6.8；25 mM PIPES, 25 mM NaCl, 2 mM MgCl2, 1 mM EGTA
cryo-EM vitrification conditions
No glow discharge was applied. After sample application to grid, liquid was mostly 'wicked' away by edgewise application of filter paper. Subsequently, blotting and plunge freezing were performed with ~0.5 second delay after blotting but prior to plunging.；Cryogen ETHANE；No glow discharge was applied. After sample application to grid, liquid was mostly 'wicked' away by edgewise application of filter paper. Subsequently, blotting and plunge freezing were performed with ~0.5 second delay after blotting but prior to plunging into liquid ethane.
|
Resolution 5.00 Å |
| 3JAK Cryo-EM structure of GTPgammaS-microtubule co-polymerized with EB3 (merged dataset with and without kinesin bound) Deposited 2015-06-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 14 PDB declaration: tetradecameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
Chain E
1–451（451 aa）
Chain J
1–451（451 aa）
Chain K
1–451（451 aa）
Chain L
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 6 GSP 5'-GUANOSINE-DIPHOSPHATE-MONOTHIOPHOSPHATE × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
BRB80；pH 6.8；80 mM PIPES, 1 mM EGTA, 1 mM MgCl2, 1 mM DTT, 0.05% Nonidet P-40
cryo-EM vitrification conditions
Blot once for 4 seconds before plunging.；90.4 K；Cryogen ETHANE；Blot once for 4 seconds before plunging into liquid ethane (FEI VITROBOT MARK II).
|
Resolution 3.30 Å |
| 3JAL Cryo-EM structure of GMPCPP-microtubule co-polymerized with EB3 Deposited 2015-06-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 14 PDB declaration: tetradecameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
Chain E
1–451（451 aa）
Chain J
1–451（451 aa）
Chain K
1–451（451 aa）
Chain L
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 6 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
BRB80；pH 6.8；80 mM PIPES, 1 mM EGTA, 1 mM MgCl2, 1 mM DTT, 0.05% Nonidet P-40
cryo-EM vitrification conditions
Blot once for 4 seconds before plunging；90.4 K；Cryogen ETHANE；Blot once for 4 seconds before plunging into liquid ethane (FEI VITROBOT MARK II).
|
Resolution 3.50 Å |
| 3JAR Cryo-EM structure of GDP-microtubule co-polymerized with EB3 Deposited 2015-06-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 14 PDB declaration: tetradecameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
Chain E
1–451（451 aa）
Chain J
1–451（451 aa）
Chain K
1–451（451 aa）
Chain L
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 6 GDP GUANOSINE-5'-DIPHOSPHATE × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
BRB80；pH 6.8；80 mM PIPES, 1 mM EGTA, 1 mM MgCl2, 1 mM DTT, 0.05% Nonidet P-40
cryo-EM vitrification conditions
Blot once for 4 seconds before plunging/；90.4 K；Cryogen ETHANE；Blot once for 4 seconds before plunging into liquid ethane (FEI VITROBOT MARK II).
|
Resolution 3.40 Å |
| 3JAS Cryo-EM structure of dynamic GDP-microtubule (14 protofilaments) decorated with kinesin Deposited 2015-06-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 12 PDB declaration: dodecameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
Chain E
1–451（451 aa）
Chain J
1–451（451 aa）
Chain K
1–451（451 aa）
Chain L
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 6 GDP GUANOSINE-5'-DIPHOSPHATE × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
BRB80；pH 6.8；80 mM PIPES, 1 mM EGTA, 1 mM MgCl2, 1 mM DTT, 0.05% Nonidet P-40
cryo-EM vitrification conditions
Blot once for 4 seconds before plunging.；90.4 K；Cryogen ETHANE；Blot once for 4 seconds before plunging into liquid ethane (FEI VITROBOT MARK II).
|
Resolution 3.50 Å |
| 3JAT Cryo-EM structure of GMPCPP-microtubule (14 protofilaments) decorated with kinesin Deposited 2015-06-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 12 PDB declaration: dodecameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
Chain E
1–451（451 aa）
Chain J
1–451（451 aa）
Chain K
1–451（451 aa）
Chain L
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 12 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
BRB80；pH 6.8；80 mM PIPES, 1 mM EGTA, 1 mM MgCl2, 1 mM DTT, 0.05% Nonidet P-40
cryo-EM vitrification conditions
Blot once for 4 seconds before plunging.；90.4 K；Cryogen ETHANE；Blot once for 4 seconds before plunging into liquid ethane (FEI VITROBOT MARK II).
|
Resolution 3.50 Å |
| 3JAW Atomic model of a microtubule seam based on a cryo-EM reconstruction of the EB3-bound microtubule (merged dataset containing tubulin bound to GTPgammaS, GMPCPP, and GDP) Deposited 2015-06-30 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 GSP 5'-GUANOSINE-DIPHOSPHATE-MONOTHIOPHOSPHATE × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
BRB80；pH 6.8；80 mM PIPES, 1 mM EGTA, 1 mM MgCl2, 1 mM DTT, 0.05% Nonidet P-40
cryo-EM vitrification conditions
Blot once for 4 seconds before plunging.；90.4 K；Cryogen ETHANE；Blot once for 4 seconds before plunging into liquid ethane (FEI VITROBOT MARK II).
|
Resolution 3.90 Å |
| 4ZHQ Crystal structure of Tubulin-Stathmin-TTL-MMAE Complex Deposited 2015-04-26 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 4 CA CALCIUM ION × 3 GOL GLYCEROL × 8 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 4Q5 N-methyl-L-valyl-N-[(3R,4S,5S)-1-{(2S)-2-[(1R,2R)-3-{[(1S,2R)-1-hydroxy-1-phenylpropan-2-yl]amino}-1-methoxy-2-methyl-3-oxopropyl]pyrrolidin-1-yl}-3-methoxy-5-methyl-1-oxoheptan-4-yl]-N-methyl-L-valinamide × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.7；293 K；6% PEG, 5% glycerol, 0.1M MES, 30 mM CaCl2, 30 mM MgCl2
|
Resolution 2.55 Å R-free 0.245 |
| 4ZI7 CRYSTAL STRUCTURE OF TUBULIN-STATHMIN-TTL-HTI286 COMPLEX Deposited 2015-04-27 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 4 CA CALCIUM ION × 4 GOL GLYCEROL × 8 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 4SL N,beta,beta-trimethyl-L-phenylalanyl-N-[(3S,4Z)-5-carboxy-2-methylhex-4-en-3-yl]-N,3-dimethyl-L-valinamide × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；PEG, glycerol, MES, CaCl2, MgCl2
|
Resolution 2.51 Å R-free 0.239 |
| 4ZOL Crystal Structure of Tubulin-Stathmin-TTL-Tubulysin M Complex Deposited 2015-05-06 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GOL GLYCEROL × 7 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 55Q (2R,4R)-4-{[(2-{(1R,3R)-1-(acetyloxy)-4-methyl-3-[methyl(N-{[(2S)-1-methylpiperidin-2-yl]carbonyl}-D-isoleucyl)amino]pentyl}-1,3-thiazol-4-yl)carbonyl]amino}-2-methyl-5-phenylpentanoic acid × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.7；293 K；6% PEG, 5% glycerol, 0.1M MES, 30 mM CaCl2, 30 mM MgCl2
|
Resolution 2.50 Å R-free 0.232 |
| 5CA0 Crystal structure of T2R-TTL-Lexibulin complex Deposited 2015-06-29 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 3 CA CALCIUM ION × 2 GOL GLYCEROL × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 LXL 1-ethyl-3-[2-methoxy-4-(5-methyl-4-{[(1S)-1-(pyridin-3-yl)butyl]amino}pyrimidin-2-yl)phenyl]urea × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% polyethylene glycol 4000, 8% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.50 Å R-free 0.237 |
| 5EZY Crystal structure of T2R-TTL-taccalonolide AJ complex Deposited 2015-11-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 TAJ taccalonolide AJ × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% polyethylene glycol 4000, 8% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.05 Å R-free 0.208 |
| 5FNV a new complex structure of tubulin with an alpha-beta unsaturated lactone Deposited 2015-11-16 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 X3H PIRONETIN × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.7；0.1M MES PH6.7;6% PEG4000 ;5% GLYCEROL;30MM CACL2;30MM MGCL2
|
Resolution 2.61 Å R-free 0.226 |
| 5H74 Crystal structure of T2R-TTL-14b complex Deposited 2016-11-17 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Fragment：UNP residues 1-450
Chain C
1–450（450 aa）
Fragment：UNP residues 1-450
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 3 7LG (2~{S},4~{R})-4-[[2-[(1~{R},3~{R})-1-acetyloxy-3-[hexyl-[(2~{S},3~{S})-3-methyl-2-[[(2~{R})-1-methylpiperidin-2-yl]carbonylamino]pentanoyl]amino]-4-methyl-pentyl]-1,3-thiazol-4-yl]carbonylamino]-5-(4-fluorophenyl)-2-methyl-pentanoic acid × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.60 Å R-free 0.248 |
| 5H7O Crystal structure of DJ-101 in complex with tubulin protein Deposited 2016-11-20 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GOL GLYCEROL × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 7Q7 2-(1H-indol-4-yl)-4-(3,4,5-trimethoxyphenyl)-1H-imidazo[4,5-c]pyridine × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；6% poly(ethylene glycol) 4000, 8% glycerol,
0.1 M Mes, 30 mM CaCl2 and 30 mM MgCl2 (pH 6.7)
|
Resolution 2.80 Å R-free 0.256 |
| 5JCB Microtubule depolymerizing agent podophyllotoxin derivative YJTSF1 Deposited 2016-04-14 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 7 GOL GLYCEROL × 8 IMD IMIDAZOLE × 2 CA CALCIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 NA SODIUM ION × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 NV4 (5R,5aR,8aS,9R)-9-[(4H-1,2,4-triazol-3-yl)sulfanyl]-5-(3,4,5-trimethoxyphenyl)-5,8,8a,9-tetrahydro-2H-furo[3',4':6,7]naphtho[2,3-d][1,3]dioxol-6(5aH)-one × 2 PEG DI(HYDROXYETHYL)ETHER × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；PEG 4000, Glycerol, Magnesium chloride, Calcium chloride
|
Resolution 2.30 Å R-free 0.200 |
| 5JQG An apo tubulin-RB-TTL complex structure used for side-by-side comparison Deposited 2016-05-04 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 3 CL CHLORIDE ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.7；293 K；0.1M MES, 6% PEG4000, 5% Glycerol, 30mM CaCl2, 30mM MgCl2
|
Resolution 2.24 Å R-free 0.212 |
| 5KMG Near-atomic cryo-EM structure of PRC1 bound to the microtubule Deposited 2016-06-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 42 PDB declaration: 42-meric |
Chain A
1–441（441 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 14 MG MAGNESIUM ION × 14 GDP GUANOSINE-5'-DIPHOSPHATE × 14 POU Peloruside A × 14 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE；blot for 4 seconds, blot force 10
|
Resolution 3.50 Å |
| 5KMG Near-atomic cryo-EM structure of PRC1 bound to the microtubule Deposited 2016-06-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–441（441 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 POU Peloruside A × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE；blot for 4 seconds, blot force 10
|
Resolution 3.50 Å |
| 5KMG Near-atomic cryo-EM structure of PRC1 bound to the microtubule Deposited 2016-06-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–441（441 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 POU Peloruside A × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE；blot for 4 seconds, blot force 10
|
Resolution 3.50 Å |
| 5XIW Crystal structure of T2R-TTL-Colchicine complex Deposited 2017-04-27 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GOL GLYCEROL × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 LOC N-[(7S)-1,2,3,10-tetramethoxy-9-oxo-6,7-dihydro-5H-benzo[d]heptalen-7-yl]ethanamide × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% polyethylene glycol 4000, 8% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.90 Å R-free 0.253 |
| 5XKE Crystal structure of T2R-TTL-Demecolcine complex Deposited 2017-05-07 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GOL GLYCEROL × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 LON (7S)-1,2,3,10-tetramethoxy-7-(methylamino)-6,7-dihydro-5H-benzo[a]heptalen-9-one × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% polyethylene glycol 4000, 8% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.60 Å R-free 0.264 |
| 5XKF Crystal structure of T2R-TTL-MPC6827 complex Deposited 2017-05-07 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GOL GLYCEROL × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 88U N-(4-methoxyphenyl)-N,2-dimethyl-quinazolin-4-amine × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% polyethylene glycol 4000, 8% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.80 Å R-free 0.259 |
| 5XKG Crystal structure of T2R-TTL-CH1 complex Deposited 2017-05-07 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GOL GLYCEROL × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 890 4-[(3-azanyl-4-methoxy-phenyl)-methyl-amino]chromen-2-one × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% polyethylene glycol 4000, 8% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.20 Å R-free 0.240 |
| 5XKH Crystal structure of T2R-TTL-CF1 complex Deposited 2017-05-07 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GOL GLYCEROL × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 89C 4-[(4-methoxy-3-oxidanyl-phenyl)-methyl-amino]chromen-2-one × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% polyethylene glycol 4000, 8% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.25 Å R-free 0.240 |
| 5XP3 Crystal structure of apo T2R-TTL Deposited 2017-05-31 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GOL GLYCEROL × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% polyethylene glycol 4000, 8% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.30 Å R-free 0.240 |
| 5YL2 Crystal structure of T2R-TTL-Y28 complex Deposited 2017-10-16 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GOL GLYCEROL × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 8WU (E)-1-(5-methoxy-2,2-dimethyl-chromen-8-yl)-3-(4-methoxy-3-oxidanyl-phenyl)prop-2-en-1-one × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% polyethylene glycol 4000, 8% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.09 Å R-free 0.254 |
| 5YLJ Crystal structure of T2R-TTL-Millepachine complex Deposited 2017-10-17 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GOL GLYCEROL × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 8X0 (E)-1-(5-methoxy-2,2-dimethyl-chromen-8-yl)-3-(4-methoxyphenyl)prop-2-en-1-one × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% polyethylene glycol 4000, 8% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.70 Å R-free 0.255 |
| 5YLS Crystal structure of T2R-TTL-Y50 complex Deposited 2017-10-18 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GOL GLYCEROL × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 Y50 E-3-(3-azanyl-4-methoxy-phenyl)-1-(5-methoxy-2,2-dimethyl-chromen-8-yl)prop-2-en-1-one × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% polyethylene glycol 4000, 8% glycerol, 0.1M MES, 30mM CaCl2, 30mM MgCl2, pH 6.7
|
Resolution 3.00 Å R-free 0.253 |
| 5Z4U Crystal Structure of T2R-TTL complex with 7a3 Deposited 2018-01-14 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 96C 4-(4-ethoxyphenyl)-1-methyl-3-(3,4,5-trimethoxyphenyl)-1H-pyrazole × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.7；293 K；6% poly(ethylene glycol) 4000, 8% glycerol, 0.1 M Mes, 30 mM CaCl2, 30 mM MgCl2 (pH 6.7)
|
Resolution 3.18 Å R-free 0.235 |
| 5ZXH The structure of MT189-tubulin complex Deposited 2018-05-21 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 9LX 2-(6-fluoro-3-{[(4-methoxyphenyl)methyl]amino}imidazo[1,2-a]pyridin-2-yl)phenol × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.7；293 K；6% POLY(ETHYLENE GLYCOL) 4000, 8% GLYCEROL, 0.1 M MES, 30 MM CACL2, 30 MM MGCL2 (pH 6.7)
|
Resolution 2.80 Å R-free 0.259 |
| 6AGK The structure of CH-II-77-tubulin complex Deposited 2018-08-13 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 3 CA CALCIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 9WR [6-(3-hydroxy-4-methylphenyl)pyridin-2-yl](3,4,5-trimethoxyphenyl)methanone × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；6% POLYETHYLENE GLYCOL 4000, 8% GLYCEROL, 0.1M MES, 30MM CACL2, 30MM MGCL2, PH 6.7,
|
Resolution 2.80 Å R-free 0.264 |
| 6B0C KLP10A-AMPPNP in complex with curved tubulin and a microtubule Deposited 2017-09-14 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 175 PDB declaration: 175-meric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 70 MG MAGNESIUM ION × 105 GDP GUANOSINE-5'-DIPHOSPHATE × 70 TA1 TAXOL × 35 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 35 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.51 Å |
| 6B0C KLP10A-AMPPNP in complex with curved tubulin and a microtubule Deposited 2017-09-14 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 2 TA1 TAXOL × 1 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.51 Å |
| 6B0C KLP10A-AMPPNP in complex with curved tubulin and a microtubule Deposited 2017-09-14 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 2 TA1 TAXOL × 1 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.51 Å |
| 6B0I Apo KLP10A in complex with a microtubule Deposited 2017-09-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 105 PDB declaration: 105-meric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 35 MG MAGNESIUM ION × 35 GDP GUANOSINE-5'-DIPHOSPHATE × 35 TA1 TAXOL × 35 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；with 20.10^(-3) unit of potato apyrase (Sigma-Aldrich, MO)
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.78 Å |
| 6B0I Apo KLP10A in complex with a microtubule Deposited 2017-09-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；with 20.10^(-3) unit of potato apyrase (Sigma-Aldrich, MO)
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.78 Å |
| 6B0I Apo KLP10A in complex with a microtubule Deposited 2017-09-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；with 20.10^(-3) unit of potato apyrase (Sigma-Aldrich, MO)
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.78 Å |
| 6B0L KLP10A-AMPPNP in complex with a microtubule Deposited 2017-09-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 105 PDB declaration: 105-meric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 35 MG MAGNESIUM ION × 70 GDP GUANOSINE-5'-DIPHOSPHATE × 35 TA1 TAXOL × 35 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 35 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.98 Å |
| 6B0L KLP10A-AMPPNP in complex with a microtubule Deposited 2017-09-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.98 Å |
| 6B0L KLP10A-AMPPNP in complex with a microtubule Deposited 2017-09-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.98 Å |
| 6BJC TPX2_mini decorated GMPCPP-microtubule Deposited 2017-11-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 14 PDB declaration: tetradecameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
Chain E
1–451（451 aa）
Chain J
1–451（451 aa）
Chain K
1–451（451 aa）
Chain L
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 12 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；BRB80
cryo-EM vitrification conditions
Cryogen ETHANE；blot for 4 seconds before plunging
|
Resolution 3.30 Å |
| 6BR1 Tubulin-RB3_SLD-TTL in complex with heterocyclic pyrimidine compound 4a Deposited 2017-11-29 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 CA CALCIUM ION × 2 MG MAGNESIUM ION × 4 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 E3Y 2-chloro-4-(6-methoxy-3,4-dihydroquinolin-1(2H)-yl)pyrido[2,3-d]pyrimidine × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% PEG 4000, 5% Glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.30 Å R-free 0.235 |
| 6BRF Tubulin-RB3_SLD-TTL in complex with heterocyclic pyrimidine compound 4b Deposited 2017-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 CA CALCIUM ION × 2 MG MAGNESIUM ION × 4 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 E44 2-chloro-4-(6-methoxy-3,4-dihydroquinolin-1(2H)-yl)pyrido[3,2-d]pyrimidine × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% PEG 4000, 5% Glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.50 Å R-free 0.237 |
| 6BRY Tubulin-RB3_SLD-TTL in complex with heterocyclic pyrimidine compound 6a Deposited 2017-12-01 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 3 GK9 1-(2-chlorofuro[3,2-d]pyrimidin-4-yl)-6-methoxy-1,2,3,4-tetrahydroquinoline × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% PEG 4000, 5% Glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.70 Å R-free 0.236 |
| 6BS2 Tubulin-RB3_SLD-TTL in complex with heterocyclic pyrimidine compound 8b Deposited 2017-12-01 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 CA CALCIUM ION × 2 MG MAGNESIUM ION × 4 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 3 E9Y 1-(3,6-dimethyl[1,2]oxazolo[5,4-d]pyrimidin-4-yl)-6-methoxy-1,2,3,4-tetrahydroquinoline × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% PEG 4000, 5% Glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.65 Å R-free 0.234 |
| 6CVJ Model of synthetic tau (four tandem repeats of first repeat sequence) bound to the microtubule Deposited 2018-03-28 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 120 PDB declaration: 120-meric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 30 MG MAGNESIUM ION × 30 GDP GUANOSINE-5'-DIPHOSPHATE × 60 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE；blot force 10 pN, 6 second blot time. used C-flat 1.2/1.3 holey grids. First 2 uL of microtubules were adhered to grid for 30 seconds, followed by 2 4 uL washes of tau with 30 second incubation for each wash
|
Resolution 3.20 Å |
| 6CVJ Model of synthetic tau (four tandem repeats of first repeat sequence) bound to the microtubule Deposited 2018-03-28 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE；blot force 10 pN, 6 second blot time. used C-flat 1.2/1.3 holey grids. First 2 uL of microtubules were adhered to grid for 30 seconds, followed by 2 4 uL washes of tau with 30 second incubation for each wash
|
Resolution 3.20 Å |
| 6CVJ Model of synthetic tau (four tandem repeats of first repeat sequence) bound to the microtubule Deposited 2018-03-28 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE；blot force 10 pN, 6 second blot time. used C-flat 1.2/1.3 holey grids. First 2 uL of microtubules were adhered to grid for 30 seconds, followed by 2 4 uL washes of tau with 30 second incubation for each wash
|
Resolution 3.20 Å |
| 6CVN Model of synthetic tau (R2x4) bound to the microtubule Deposited 2018-03-28 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 120 PDB declaration: 120-meric |
Chain B
1–451（451 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 60 GTP GUANOSINE-5'-TRIPHOSPHATE × 30 MG MAGNESIUM ION × 30 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE；blot force 10 pN, 6 second blot time. used C-flat 1.2/1.3 holey grids. First 2 uL of microtubules were adhered to grid for 30 seconds, followed by 2 4 uL washes of tau with 30 second incubation for each wash.
|
Resolution 3.90 Å |
| 6CVN Model of synthetic tau (R2x4) bound to the microtubule Deposited 2018-03-28 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain B
1–451（451 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 2 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE；blot force 10 pN, 6 second blot time. used C-flat 1.2/1.3 holey grids. First 2 uL of microtubules were adhered to grid for 30 seconds, followed by 2 4 uL washes of tau with 30 second incubation for each wash.
|
Resolution 3.90 Å |
| 6CVN Model of synthetic tau (R2x4) bound to the microtubule Deposited 2018-03-28 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain B
1–451（451 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 2 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE；blot force 10 pN, 6 second blot time. used C-flat 1.2/1.3 holey grids. First 2 uL of microtubules were adhered to grid for 30 seconds, followed by 2 4 uL washes of tau with 30 second incubation for each wash.
|
Resolution 3.90 Å |
| 6D88 Tubulin-RB3_SLD-TTL in complex with compound 13f Deposited 2018-04-26 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 CA CALCIUM ION × 2 MG MAGNESIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 G9K [2-(1H-indol-3-yl)-1H-imidazol-4-yl](8-methoxy-1,4-benzodioxin-6-yl)methanone × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% PEG 4000, 5% Glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2
|
Resolution 2.85 Å R-free 0.246 |
| 6DPU Undecorated GMPCPP microtubule Deposited 2018-06-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 12 PDB declaration: dodecameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
Chain E
1–451（451 aa）
Chain J
1–451（451 aa）
Chain K
1–451（451 aa）
Chain L
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 12 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；BRB80 buffer (80 mM PIPES, pH 6.8, 1 mM EGTA, 1 mM MgCl2) supplemented with 1 mM GMPCPP, 1 mM DTT, and 0.05% Nonident P-40
cryo-EM vitrification conditions
Cryogen ETHANE；Blot for 4 seconds before plunging.
|
Resolution 3.10 Å |
| 6DPV Undecorated GDP microtubule Deposited 2018-06-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 12 PDB declaration: dodecameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
Chain E
1–451（451 aa）
Chain J
1–451（451 aa）
Chain K
1–451（451 aa）
Chain L
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 6 GDP GUANOSINE-5'-DIPHOSPHATE × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；BRB80 buffer (80 mM PIPES pH 6.8, 1 mM EGTA, 1 mM MgCl2) supplemented with 1 mM GTP, 1 mM DTT, and 0.05% Nonident P-40
cryo-EM vitrification conditions
Cryogen ETHANE；Blot for 4 seconds before plunging.
|
Resolution 3.30 Å |
| 6DPW Undecorated GTPgammaS microtubule Deposited 2018-06-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 12 PDB declaration: dodecameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
Chain E
1–451（451 aa）
Chain J
1–451（451 aa）
Chain K
1–451（451 aa）
Chain L
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 6 GSP 5'-GUANOSINE-DIPHOSPHATE-MONOTHIOPHOSPHATE × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；Modified BRB80 buffer (80 mM PIPES, pH 6.8, 1 mM EGTA, 0.2 mM MgCl2) supplemented with 1 mM GTPgammaS, 1 mM DTT, and 0.05% Nonident P-40
cryo-EM vitrification conditions
Cryogen ETHANE；Blot for 4 seconds before plunging.
|
Resolution 3.50 Å |
| 6EG5 The structure of SB-1-202-tubulin complex Deposited 2018-08-18 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 6 CA CALCIUM ION × 4 CL CHLORIDE ION × 1 GOL GLYCEROL × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 J7S 4-(2-chloropyrido[2,3-d]pyrimidin-4-yl)-7-methoxy-3,4-dihydroquinoxalin-2(1H)-one × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；6% POLYETHYLENE GLYCOL 4000, 8% GLYCEROL, 0.1 M MES, 30 MM CACL2, 30 MM MGCL2, PH 6.7
|
Resolution 2.45 Å R-free 0.236 |
| 6EVW Cryo-EM structure of GMPCPP-microtubule co-polymerised with doublecortin Deposited 2017-11-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 12 PDB declaration: dodecameric |
Chain A
1–438（438 aa）
Chain C
1–438（438 aa）
Chain E
1–438（438 aa）
Chain J
1–438（438 aa）
Chain K
1–438（438 aa）
Chain L
1–438（438 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 12 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.40 Å |
| 6EVX Cryo-EM structure of GDP.Pi-microtubule rapidly co-polymerised with doublecortin Deposited 2017-11-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 12 PDB declaration: dodecameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
Chain E
1–451（451 aa）
Chain J
1–451（451 aa）
Chain K
1–451（451 aa）
Chain L
1–451（451 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 6 GTP GUANOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 6 PO4 PHOSPHATE ION × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.20 Å |
| 6EVY Cryo-EM structure of GTPgammaS-microtubule co-polymerised with doublecortin Deposited 2017-11-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 12 PDB declaration: dodecameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
Chain E
1–451（451 aa）
Chain J
1–451（451 aa）
Chain K
1–451（451 aa）
Chain L
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 6 GSP 5'-GUANOSINE-DIPHOSPHATE-MONOTHIOPHOSPHATE × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.40 Å |
| 6EVZ Cryo-EM structure of GDP-microtubule co-polymerised with doublecortin Deposited 2017-11-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 12 PDB declaration: dodecameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
Chain E
1–451（451 aa）
Chain J
1–451（451 aa）
Chain K
1–451（451 aa）
Chain L
1–451（451 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 6 GTP GUANOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.80 Å |
| 6EW0 Cryo-EM structure of GDP-microtubule co-polymerised with doublecortin and supplemented with Taxol Deposited 2017-11-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 12 PDB declaration: dodecameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
Chain E
1–451（451 aa）
Chain J
1–451（451 aa）
Chain K
1–451（451 aa）
Chain L
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 6 GDP GUANOSINE-5'-DIPHOSPHATE × 6 TA1 TAXOL × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.80 Å |
| 6JCJ Structure of crolibulin in complex with tubulin Deposited 2019-01-29 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 3 CA CALCIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 BG0 (4R)-2,7,8-triamino-4-(3-bromo-4,5-dimethoxyphenyl)-4H-1-benzopyran-3-carbonitrile × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；6% POLYETHYLENE GLYCOL 4000, 8% GLYCEROL, 0.1 M MES, 30 MM CACL2, 30 MM MGCL2, PH 6.7
|
Resolution 2.50 Å R-free 0.282 |
| 6KPP BNC105 in complex with tubulin Deposited 2019-08-15 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 DO6 (6-methoxy-2-methyl-7-oxidanyl-1-benzofuran-3-yl)-(3,4,5-trimethoxyphenyl)methanone × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；277 K；6% PEG, 5% glycerol, 0.1M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.75 Å R-free 0.235 |
| 6LS4 A novel anti-tumor agent S-40 in complex with tubulin Deposited 2020-01-17 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 6 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 GOL GLYCEROL × 1 S40 3-[(4-cyclopropylphenyl)sulfonylamino]-4-methyl-N-(pyridin-3-ylmethyl)benzamide × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；6% PEG 4000, 6% GLYCEROL, 30mM MAGNESIUM CHLORIDE, 30mM CALCIUM CHLORIDE, 3.3% Jeffamin M-600, 100mM MES
|
Resolution 2.40 Å R-free 0.240 |
| 6LSM Tubulin Polymerization Inhibitors Deposited 2020-01-17 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 6 CA CALCIUM ION × 4 CL CHLORIDE ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 ERX 2-(4-methylphenyl)-7-(3,4,5-trimethoxyphenyl)pyrazolo[1,5-a]pyrimidine × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；277 K；6% PEG, 5% glycerol, 0.1M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.75 Å R-free 0.227 |
| 6LSN Crystal structure of tubulin-inhibitor complex Deposited 2020-01-17 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 6 CA CALCIUM ION × 4 CL CHLORIDE ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 ERR 2-(1-methylindol-5-yl)-7-(3,4,5-trimethoxyphenyl)pyrazolo[1,5-a]pyrimidine × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；277 K；6% PEG, 5% glycerol, 0.1M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.44 Å R-free 0.220 |
| 6N47 The structure of SB-2-204-tubulin complex Deposited 2018-11-17 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 CA CALCIUM ION × 4 CL CHLORIDE ION × 1 MG MAGNESIUM ION × 4 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 KB4 4-(2-chloropyrido[3,2-d]pyrimidin-4-yl)-7-methoxy-3,4-dihydroquinoxalin-2(1H)-one × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% POLYETHYLENE GLYCOL 4000, 8% GLYCEROL, 0.1 M MES, 30 MM CACL2, 30 MM MGCL2, PH 6.7
|
Resolution 2.60 Å R-free 0.246 |
| 6NNG Tubulin-RB3_SLD-TTL in complex with compound DJ95 Deposited 2019-01-15 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 DJ9 2-(1H-indol-6-yl)-4-(3,4,5-trimethoxyphenyl)-1H-imidazo[4,5-c]pyridine × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% PEG 4000, 5% Glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2
|
Resolution 2.40 Å R-free 0.227 |
| 6O2Q Acetylated Microtubules Deposited 2019-02-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 12 PDB declaration: dodecameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
Chain E
1–451（451 aa）
Chain J
1–451（451 aa）
Chain K
1–451（451 aa）
Chain L
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 6 GDP GUANOSINE-5'-DIPHOSPHATE × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；Contains 80 mM PIPES, 1 mM MgCl2, 1 mM EGTA, pH 6.8 with KOH (stored at 4 degrees Celsius).
cryo-EM vitrification conditions
Cryogen ETHANE；Blotted for 4 seconds at blot force 10.
|
Resolution 3.70 Å |
| 6O2R Deacetylated Microtubules Deposited 2019-02-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 12 PDB declaration: dodecameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
Chain E
1–451（451 aa）
Chain J
1–451（451 aa）
Chain K
1–451（451 aa）
Chain L
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 6 MG MAGNESIUM ION × 6 GDP GUANOSINE-5'-DIPHOSPHATE × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；Contains 80 mM PIPES, 1 mM MgCl2, 1 mM EGTA, pH 6.8 with KOH (stored at 4 degrees Celsius).
cryo-EM vitrification conditions
Cryogen ETHANE；Blotted for 4 seconds at blot force 10.
|
Resolution 3.30 Å |
| 6O2S Deacetylated Microtubules Deposited 2019-02-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 104 PDB declaration: 104-meric |
Chain 1A
1–451（451 aa）
Chain 1B
1–451（451 aa）
Chain 1C
1–451（451 aa）
Chain 1D
1–451（451 aa）
Chain 1E
1–451（451 aa）
Chain 1F
1–451（451 aa）
Chain 1G
1–451（451 aa）
Chain 1I
1–451（451 aa）
Chain 1J
1–451（451 aa）
Chain 1K
1–451（451 aa）
Chain 1L
1–451（451 aa）
Chain 1M
1–451（451 aa）
Chain 1N
1–451（451 aa）
Chain 2A
1–451（451 aa）
Chain 2B
1–451（451 aa）
Chain 2C
1–451（451 aa）
Chain 2D
1–451（451 aa）
Chain 2E
1–451（451 aa）
Chain 2F
1–451（451 aa）
Chain 2G
1–451（451 aa）
Chain 2I
1–451（451 aa）
Chain 2J
1–451（451 aa）
Chain 2K
1–451（451 aa）
Chain 2L
1–451（451 aa）
Chain 2M
1–451（451 aa）
Chain 2N
1–451（451 aa）
Chain 3A
1–451（451 aa）
Chain 3B
1–451（451 aa）
Chain 3C
1–451（451 aa）
Chain 3D
1–451（451 aa）
Chain 3E
1–451（451 aa）
Chain 3F
1–451（451 aa）
Chain 3G
1–451（451 aa）
Chain 3I
1–451（451 aa）
Chain 3J
1–451（451 aa）
Chain 3K
1–451（451 aa）
Chain 3L
1–451（451 aa）
Chain 3M
1–451（451 aa）
Chain 3N
1–451（451 aa）
Chain 4A
1–451（451 aa）
Chain 4B
1–451（451 aa）
Chain 4C
1–451（451 aa）
Chain 4D
1–451（451 aa）
Chain 4E
1–451（451 aa）
Chain 4F
1–451（451 aa）
Chain 4G
1–451（451 aa）
Chain 4I
1–451（451 aa）
Chain 4J
1–451（451 aa）
Chain 4K
1–451（451 aa）
Chain 4L
1–451（451 aa）
Chain 4M
1–451（451 aa）
Chain 4N
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 52 MG MAGNESIUM ION × 52 GDP GUANOSINE-5'-DIPHOSPHATE × 52 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；Contains 80 mM PIPES, 1 mM MgCl2, 1 mM EGTA, pH 6.8 with KOH (stored at 4 degrees Celsius).
cryo-EM vitrification conditions
Cryogen ETHANE；Blotted for 4 seconds at blot force 10.
|
Resolution 4.00 Å |
| 6O2T Acetylated Microtubules Deposited 2019-02-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 104 PDB declaration: 104-meric |
Chain 1A
1–451（451 aa）
Chain 1B
1–451（451 aa）
Chain 1C
1–451（451 aa）
Chain 1D
1–451（451 aa）
Chain 1E
1–451（451 aa）
Chain 1F
1–451（451 aa）
Chain 1G
1–451（451 aa）
Chain 1I
1–451（451 aa）
Chain 1J
1–451（451 aa）
Chain 1K
1–451（451 aa）
Chain 1L
1–451（451 aa）
Chain 1M
1–451（451 aa）
Chain 1N
1–451（451 aa）
Chain 2A
1–451（451 aa）
Chain 2B
1–451（451 aa）
Chain 2C
1–451（451 aa）
Chain 2D
1–451（451 aa）
Chain 2E
1–451（451 aa）
Chain 2F
1–451（451 aa）
Chain 2G
1–451（451 aa）
Chain 2I
1–451（451 aa）
Chain 2J
1–451（451 aa）
Chain 2K
1–451（451 aa）
Chain 2L
1–451（451 aa）
Chain 2M
1–451（451 aa）
Chain 2N
1–451（451 aa）
Chain 3A
1–451（451 aa）
Chain 3B
1–451（451 aa）
Chain 3C
1–451（451 aa）
Chain 3D
1–451（451 aa）
Chain 3E
1–451（451 aa）
Chain 3F
1–451（451 aa）
Chain 3G
1–451（451 aa）
Chain 3I
1–451（451 aa）
Chain 3J
1–451（451 aa）
Chain 3K
1–451（451 aa）
Chain 3L
1–451（451 aa）
Chain 3M
1–451（451 aa）
Chain 3N
1–451（451 aa）
Chain 4A
1–451（451 aa）
Chain 4B
1–451（451 aa）
Chain 4C
1–451（451 aa）
Chain 4D
1–451（451 aa）
Chain 4E
1–451（451 aa）
Chain 4F
1–451（451 aa）
Chain 4G
1–451（451 aa）
Chain 4I
1–451（451 aa）
Chain 4J
1–451（451 aa）
Chain 4K
1–451（451 aa）
Chain 4L
1–451（451 aa）
Chain 4M
1–451（451 aa）
Chain 4N
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 52 MG MAGNESIUM ION × 52 GDP GUANOSINE-5'-DIPHOSPHATE × 52 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；Contains 80 mM PIPES, 1 mM MgCl2, 1 mM EGTA, pH 6.8 with KOH (stored at 4 degrees Celsius).
cryo-EM vitrification conditions
Cryogen ETHANE；Blotted for 4 seconds at blot force 10.
|
Resolution 4.10 Å |
| 6O5M Tubulin-RB3_SLD-TTL in complex with compound 10bb Deposited 2019-03-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 CA CALCIUM ION × 2 MG MAGNESIUM ION × 4 GOL GLYCEROL × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 G8K [2-(1H-indol-4-yl)-1H-imidazol-4-yl](3,4,5-trimethoxyphenyl)methanone × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% PEG 4000, 5% Glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2
|
Resolution 2.30 Å R-free 0.223 |
| 6O5N Tubulin-RB3_SLD-TTL in complex with compound 10ab Deposited 2019-03-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 3 CA CALCIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 QW9 [2-(4-methyl-1H-indol-3-yl)-1H-imidazol-5-yl](3,4,5-trimethoxyphenyl)methanone × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% PEG 4000, 5% Glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2
|
Resolution 3.00 Å R-free 0.245 |
| 6O61 Tubulin-RB3_SLD-TTL in complex with compound ABI-231 Deposited 2019-03-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 3 CA CALCIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 KUM [2-(1H-indol-3-yl)-1H-imidazol-5-yl](3,4,5-trimethoxyphenyl)methanone × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% PEG 4000, 5% Glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2
|
Resolution 2.60 Å R-free 0.243 |
| 6PC4 Tubulin-RB3_SLD-TTL in complex with compound ABI-274 Deposited 2019-06-15 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 3 CA CALCIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 O91 [2-(4-methylphenyl)-1H-imidazol-4-yl](3,4,5-trimethoxyphenyl)methanone × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% PEG 4000, 5% Glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2
|
Resolution 2.60 Å R-free 0.234 |
| 6RZA Cryo-EM structure of the human inner arm dynein DNAH7 microtubule binding domain bound to microtubules Deposited 2019-06-13 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–437（437 aa）
Chain C
1–437（437 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 TA1 TAXOL × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.50 Å |
| 6RZB Cryo-EM structure of mouse cytoplasmic dynein-1 microtubule binding domain bound to microtubules Deposited 2019-06-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–437（437 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.10 Å |
| 6TA3 Human kinesin-5 motor domain in the GSK-1 state bound to microtubules (Conformation 1) Deposited 2019-10-29 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–438（438 aa）
|
Not recorded | G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 2 MG MAGNESIUM ION × 2 MZK 6-[4-(trifluoromethyl)phenyl]-3,4-dihydro-1~{H}-quinolin-2-one × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.6
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.80 Å |
| 6TA4 Human kinesin-5 motor domain in the AMPPNP state bound to microtubules Deposited 2019-10-29 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–438（438 aa）
|
Not recorded | G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 1 MG MAGNESIUM ION × 3 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.2
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 6.10 Å |
| 6TIW Human kinesin-5 motor domain in the GSK state bound to microtubules (Conformation 2) Deposited 2019-11-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–438（438 aa）
|
Not recorded | MZK 6-[4-(trifluoromethyl)phenyl]-3,4-dihydro-1~{H}-quinolin-2-one × 1 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 2 MG MAGNESIUM ION × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.6
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.80 Å |
| 6WWE Apo KIF14[391-772] in complex with a microtubule Deposited 2020-05-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.90 Å |
| 6WWF KIF14[391-772] - ADP in complex with a microtubule Deposited 2020-05-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.30 Å |
| 6WWG KIF14[391-772] dimer two-heads-bound state - ADP-AlFx in complex with a microtubule Deposited 2020-05-09 | Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain E
1–451（451 aa）
|
Not recorded | AF3 ALUMINUM FLUORIDE × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 2 MG MAGNESIUM ION × 3 GTP GUANOSINE-5'-TRIPHOSPHATE × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 TA1 TAXOL × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.90 Å |
| 6WWH KIF14[391-772] dimer two-heads-bound state - AMP-PNP in complex with a microtubule Deposited 2020-05-09 | Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain E
1–451（451 aa）
|
Not recorded | MG MAGNESIUM ION × 4 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 2 GTP GUANOSINE-5'-TRIPHOSPHATE × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 TA1 TAXOL × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.80 Å |
| 6WWI Apo KIF14[391-755] in complex with a microtubule Deposited 2020-05-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.60 Å |
| 6WWJ KIF14[391-755] - ADP in complex with a microtubule Deposited 2020-05-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.40 Å |
| 6WWK KIF14[391-755] dimer two-heads-bound state - ADP-AlFx in complex with a microtubule Deposited 2020-05-09 | Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain E
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 TA1 TAXOL × 2 AF3 ALUMINUM FLUORIDE × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.00 Å |
| 6WWL KIF14[391-755] dimer two-heads-bound state - AMP-PNP in complex with a microtubule Deposited 2020-05-09 | Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain E
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 2 TA1 TAXOL × 2 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.10 Å |
| 6WWM KIF14[391-748] - ADP in complex with a microtubule Deposited 2020-05-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.80 Å |
| 6WWN KIF14[391-748] - ADP-AlFx in complex with a microtubule Deposited 2020-05-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 AF3 ALUMINUM FLUORIDE × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.50 Å |
| 6WWO KIF14[391-748] - AMP-PNP in complex with a microtubule Deposited 2020-05-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.80 Å |
| 6WWP Apo KIF14[391-743] in complex with a microtubule Deposited 2020-05-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.10 Å |
| 6WWQ KIF14[391-743] - ADP in complex with a microtubule Deposited 2020-05-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.00 Å |
| 6WWR Kif14[391-743] - ADP-AlFx open state class in complex with a microtubule Deposited 2020-05-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.70 Å |
| 6WWS Kif14[391-743] - AMP-PNP open state class in complex with a microtubule Deposited 2020-05-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.70 Å |
| 6WWT Apo KIF14[391-735] in complex with a microtubule Deposited 2020-05-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.20 Å |
| 6WWU KIF14[391-735] - ADP-AlFx in complex with a microtubule Deposited 2020-05-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.70 Å |
| 6WWV KIF14[391-735] - ANP-PNP in complex with a microtubule Deposited 2020-05-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.10 Å |
| 6X1C Tubulin-RB3_SLD-TTL in complex with compound 5j Deposited 2020-05-18 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 CA CALCIUM ION × 2 MG MAGNESIUM ION × 5 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 Y5J 4-(2-chlorofuro[3,2-d]pyrimidin-4-yl)-7-methoxy-3,4-dihydroquinoxalin-2(1H)-one × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% PEG 4000, 5% glycerol, 0.1M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.90 Å R-free 0.216 |
| 6X1E Tubulin-RB3_SLD-TTL in complex with compound 5l Deposited 2020-05-18 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 CA CALCIUM ION × 2 MG MAGNESIUM ION × 5 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 Y5L 4-(2-chloro-6,7-dihydro-5H-cyclopenta[d]pyrimidin-4-yl)-7-methoxy-3,4-dihydroquinoxalin-2(1H)-one × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% PEG 4000, 5% glycerol, 0.1M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.90 Å R-free 0.224 |
| 6X1F Tubulin-RB3_SLD-TTL in complex with compound 5m Deposited 2020-05-18 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 CA CALCIUM ION × 2 MG MAGNESIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 Y5M 7-methoxy-4-(2-methyl-6,7-dihydro-5H-cyclopenta[d]pyrimidin-4-yl)-3,4-dihydroquinoxalin-2(1H)-one × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；6% PEG 4000, 5% glycerol, 0.1M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.70 Å R-free 0.241 |
| 6XER Tubulin-RB3_SLD in complex with colchicine Deposited 2020-06-13 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–438（438 aa）
Chain C
1–438（438 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 2 SO4 SULFATE ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 1 LOC N-[(7S)-1,2,3,10-tetramethoxy-9-oxo-6,7-dihydro-5H-benzo[d]heptalen-7-yl]ethanamide × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 5.6；293 K；PEG 4000, ammonium sulfate, tri-sodium citrate
|
Resolution 2.50 Å R-free 0.223 |
| 6XES Tubulin-RB3_SLD in complex with compound 40a Deposited 2020-06-13 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–438（438 aa）
Chain C
1–438（438 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 SO4 SULFATE ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TU3 [6-(3-hydroxy-4-methylphenyl)pyrazin-2-yl](3,4,5-trimethoxyphenyl)methanone × 2 MG MAGNESIUM ION × 1 DMS DIMETHYL SULFOXIDE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.6；293 K；PEG 4000, ammonium sulfate, tri-sodium citrate
|
Resolution 2.32 Å R-free 0.226 |
| 6XET Tubulin-RB3_SLD in complex with compound 60c Deposited 2020-06-13 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–438（438 aa）
Chain C
1–438（438 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 SO4 SULFATE ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TU2 [3-fluoro-6-(3-hydroxy-4-methylphenyl)pyridin-2-yl](3,4,5-trimethoxyphenyl)methanone × 2 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.6；293 K；PEG 4000, ammonium sulfate, tri-sodium citrate
|
Resolution 2.60 Å R-free 0.231 |
| 6Y4M Structure of Tubulin Tyrosine Ligase in Complex with Tb111 Deposited 2020-02-21 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 O9B (2~{R})-1-methylpiperidine-2-carboxylic acid × 1 O9H [(1~{R},3~{R})-1-acetyloxy-1-[4-methanoyl-5-(2-phenylmethoxyethyl)-2,3-dihydro-1,3-thiazol-2-yl]-4-methyl-pentan-3-yl]-methyl-azanium × 1 OH5 (2~{S},4~{R})-4-azanyl-2-methyl-5-phenyl-pentanoic acid × 1 PGE TRIETHYLENE GLYCOL × 1 VAL VALINE × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；293 K；0.03 M calcium chloride, 0.03 M magnesium chloride, 0.10 M MES pH 6.50, 3.20% w/v
PEG 4000, 5.00% w/v glycerol
|
Resolution 3.34 Å R-free 0.234 |
| 6Y4N Structure of Tubulin Tyrosine Ligase in Complex with Tb116 Deposited 2020-02-21 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 CA CALCIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 O9B (2~{R})-1-methylpiperidine-2-carboxylic acid × 1 O9K [(1~{R},3~{R})-1-(4-methanoyl-1,3-thiazol-2-yl)-4-methyl-3-(methylamino)pentyl] ethanoate × 1 O9N methyl (2~{S},4~{S})-2,4-bis(azanyl)-5-phenyl-pentanoate × 1 PGE TRIETHYLENE GLYCOL × 1 VAL VALINE × 1 P6S benzyl hydrogen carbonate × 1 PEG DI(HYDROXYETHYL)ETHER × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；293 K；30 mM calcium chloride, 30 mM magnesium chloride, 0.10 M MES pH 6.0, 2.0% w/v PEG 4000, 5.0% w/v glycerol
|
Resolution 2.85 Å R-free 0.220 |
| 6ZPI Microtubule complexed with Kif15 motor domain. Symmetrised asymmetric unit Deposited 2020-07-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–437（437 aa）
|
Not recorded | ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 MG MAGNESIUM ION × 2 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.50 Å |
| 7CBZ Crystal structure of T2R-TTL-A31 complex Deposited 2020-06-15 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 5 CA CALCIUM ION × 6 FUO 2-[5-[4-[2-[4-(2-cyclopropylethanoyl)piperazin-1-yl]ethoxy]phenyl]pyridin-2-yl]-N-(phenylmethyl)ethanamide × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% PEG4000, 8% glycerol, 0.1 M
MES (pH 6.7), 30 mM CaCl2, and 30 mM MgCl2.
|
Resolution 2.61 Å R-free 0.255 |
| 7CDA Crystal structure of T2R-TTL-PAC complex Deposited 2020-06-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GOL GLYCEROL × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 AEU N-[(3-phenoxyphenyl)methyl]-9H-beta-carbolin-3-amine × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；289 K；6% poly(ethylene glycol) 4000, 8% glycerol, 0.1 M MES (pH 6.7), 30 mM CaCl2 and 30 mM MgCl2.
|
Resolution 2.66 Å R-free 0.257 |
| 7CE6 Crystal structure of T2R-TTL-Compound9 complex Deposited 2020-06-22 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GOL GLYCEROL × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 AF6 N-benzyl-9H-beta-carbolin-3-amine × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；289 K；6% poly(ethylene glycol) 4000, 8% glycerol, 0.1 M MES (pH 6.7), 30 mM CaCl2 and 30 mM MgCl2.
|
Resolution 2.69 Å R-free 0.248 |
| 7CE8 Crystal structure of T2R-TTL-Compound11 complex Deposited 2020-06-22 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GOL GLYCEROL × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 AEX N-butyl-9H-beta-carbolin-3-amine × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；289 K；6% poly(ethylene glycol) 4000, 8% glycerol, 0.1 M MES (pH 6.7), 30 mM CaCl2 and 30 mM MgCl2
|
Resolution 2.73 Å R-free 0.242 |
| 7CEK Crystal structure of T2R-TTL-BML-284 complex Deposited 2020-06-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 CA CALCIUM ION × 6 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 FW9 N4-(1,3-benzodioxol-5-ylmethyl)-6-(3-methoxyphenyl)pyrimidine-2,4-diamine × 2 CL CHLORIDE ION × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；289 K；6% poly(ethylene glycol) 4000, 8% glycerol, 0.1 M MES (pH 6.7), 30 mM CaCl2 and 30 mM MgCl2.
|
Resolution 2.70 Å R-free 0.271 |
| 7CLD Crystal structure of T2R-TTL-Cevipabulin complex Deposited 2020-07-20 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 CA CALCIUM ION × 7 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 G2X 6-[2,6-bis(fluoranyl)-4-[3-(methylamino)propoxy]phenyl]-5-chloranyl-N-[(2S)-1,1,1-tris(fluoranyl)propan-2-yl]-[1,2,4]triazolo[1,5-a]pyrimidin-7-amine × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；6% poly(ethylene glycol) 4000, 8% glycerol, 0.1 M MES (pH 6.7), 30 mM CaCl2 and 30 mM MgCl2.
|
Resolution 2.61 Å R-free 0.258 |
| 7CNM YDX in complex with tubulin Deposited 2020-08-02 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 3 CA CALCIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 3 G70 (2~{S},4~{S})-4-[[2-[(1~{R},3~{R})-1-acetyloxy-4-methyl-3-[[(2~{S},3~{S})-3-methyl-2-[[(2~{R})-1-methylpiperidin-2-yl]carbonylamino]pentanoyl]amino]pentyl]-1,3-thiazol-4-yl]carbonylamino]-5-cyclohexyl-2-methyl-pentanoic acid × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；277 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.44 Å R-free 0.237 |
| 7CNN vinorelbine in complex with tubulin Deposited 2020-08-02 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 CA CALCIUM ION × 4 CL CHLORIDE ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 GDF Vinorelbine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；277 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.50 Å R-free 0.229 |
| 7CNO Phomopsin A in complex with tubulin Deposited 2020-08-02 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 4 CA CALCIUM ION × 4 CL CHLORIDE ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 HOS Phomopsin A × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；277 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCL2, 30 mM MgCl2, pH 6.7
|
Resolution 2.50 Å R-free 0.239 |
| 7DAD EPD in complex with tubulin Deposited 2020-10-16 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 CA CALCIUM ION × 4 CL CHLORIDE ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 EPD EPOTHILONE D × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；277 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCL2, pH 6.7
|
Resolution 2.85 Å R-free 0.226 |
| 7DAE EPB in complex with tubulin Deposited 2020-10-16 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 4 CA CALCIUM ION × 4 CL CHLORIDE ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 EPB 7,11-DIHYDROXY-8,8,10,12,16-PENTAMETHYL-3-[1-METHYL-2-(2-METHYL-THIAZOL-4-YL)VINYL]-4,17-DIOXABICYCLO[14.1.0]HEPTADECANE-5,9-DIONE × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；277 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCL2, pH 6.7
|
Resolution 2.39 Å R-free 0.222 |
| 7DAF IXA in complex with tubulin Deposited 2020-10-16 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 6 CA CALCIUM ION × 4 CL CHLORIDE ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 GZX (1~{S},3~{S},7~{S},10~{R},11~{S},12~{S},16~{R})-8,8,10,12,16-pentamethyl-3-[(~{E})-1-(2-methyl-1,3-thiazol-4-yl)prop-1-en-2-yl]-7,11-bis(oxidanyl)-17-oxa-4-azabicyclo[14.1.0]heptadecane-5,9-dione × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；277 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCL2, pH 6.7
|
Resolution 2.40 Å R-free 0.222 |
| 7DBA RYX in complex with tubulin Deposited 2020-10-19 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 CL CHLORIDE ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 H1O 2-(1-methylindol-4-yl)-7-(3,4,5-trimethoxyphenyl)-1~{H}-benzimidazole × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；277 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCL2, pH 6.7
|
Resolution 2.46 Å R-free 0.228 |
| 7DBB SSE in complex with tubulin Deposited 2020-10-19 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 CA CALCIUM ION × 4 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 H1F 5-phenyl-3-(3,4,5-trimethoxyphenyl)-3,4-dihydropyrazole-2-carbothioamide × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；277 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCL2, pH 6.7
|
Resolution 2.81 Å R-free 0.230 |
| 7DBC PRA in complex with tubulin Deposited 2020-10-19 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 CA CALCIUM ION × 2 H1C methyl ~{N}-(5-butyl-1~{H}-benzimidazol-2-yl)carbamate × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；277 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCL2, pH 6.7
|
Resolution 2.40 Å R-free 0.234 |
| 7DBD 444 in complex with tubulin Deposited 2020-10-19 | Different ligand/ion Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 H0U ~{N}-[5-(5-cyanothiophen-2-yl)-2-methyl-phenyl]-4-methyl-benzenesulfonamide × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；277 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCL2, pH 6.7
|
Resolution 3.09 Å R-free 0.244 |
| 7DMZ GMPCPP microtubule complex Deposited 2020-12-08 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain B
1–451（451 aa）
Chain D
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 2 TAJ taccalonolide AJ × 3 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 3 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.30 Å |
| 7DN0 AJ-GMPCPP-MT-non-seam Deposited 2020-12-08 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain B
1–451（451 aa）
Chain C
1–451（451 aa）
Chain D
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 4 MG MAGNESIUM ION × 4 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 2 TAJ taccalonolide AJ × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.50 Å |
| 7DP8 Crystal structure of T2R-TTL-Cevipabulin-eribulin complex Deposited 2020-12-18 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 CA CALCIUM ION × 6 GOL GLYCEROL × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 G2X 6-[2,6-bis(fluoranyl)-4-[3-(methylamino)propoxy]phenyl]-5-chloranyl-N-[(2S)-1,1,1-tris(fluoranyl)propan-2-yl]-[1,2,4]triazolo[1,5-a]pyrimidin-7-amine × 2 6K9 (1S,3S,6S,9S,12S,14R,16R,18S,20R,21R,22S,26R,29S,31R,32S,33R,35R,36S)-20-[(2S)-3-amino-2-hydroxypropyl]-21-methoxy-14-methyl-8,15-dimethylidene-2,19,30,34,37,39,40,41-octaoxanonacyclo[24.9.2.1~3,32~.1~3,33~.1~6,9~.1~12,16~.0~18,22~.0~29,36~.0~31,35~]hentetracontan-24-one (non-preferred name) × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；6% poly(ethylene glycol) 4000, 8% glycerol, 0.1 M MES (pH 6.7), 30 mM CaCl2 and 30 mM MgCl2
|
Resolution 2.45 Å R-free 0.264 |
| 7EMJ Crystal structure of T2R-TTL-Barbigerone complex Deposited 2021-04-14 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 CA CALCIUM ION × 6 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 J6L 8,8-dimethyl-3-(2,4,5-trimethoxyphenyl)pyrano[2,3-f]chromen-4-one × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% PEG 4000, 5% glycerol, 0.1 M MES, 30 mM CaCl2 and 30 mM MgCl2, pH 6.7
|
Resolution 2.33 Å R-free 0.241 |
| 7EN3 Crystal structure of tubulin in complex with Tubulysin analogue TGL Deposited 2021-04-15 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 3 CA CALCIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 3 J6R (2S,4R)-5-(4-fluorophenyl)-2-methyl-4-[[2-[(1R,3R)-4-methyl-3-[5-methylhexyl-[(2S,3S)-3-methyl-2-[[(2R)-1-methylpiperidin-2-yl]carbonylamino]pentanoyl]amino]-1-oxidanyl-pentyl]-1,3-thiazol-4-yl]carbonylamino]pentanoic acid × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.7；293 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2
|
Resolution 2.64 Å R-free 0.239 |
| 7EXC Crystal structure of T2R-TTL-1129A2 complex Deposited 2021-05-26 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 GOL GLYCEROL × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 JEL N-[[3-(1,3-benzodioxol-5-yloxy)phenyl]methyl]-9H-pyrido[3,4-b]indol-3-amine × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；6% poly(ethylene glycol) 4000, 8% glycerol, 0.1 M MES (pH 6.7), 30 mM CaCl2, 30 mM MgCl2
|
Resolution 2.39 Å R-free 0.264 |
| 7L05 Complex of novel maytansinoid M24 bound to T2R-TTL (two tubulin alpha/beta heterodimers, RB3 stathmin-like domain, and tubulin tyrosine ligase) Deposited 2020-12-11 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 5 CA CALCIUM ION × 4 CL CHLORIDE ION × 1 EDO 1,2-ETHANEDIOL × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 XQ4 (1S,2R,3S,5S,6S,16E,18E,20R,21S)-11-chloro-21-hydroxy-12,20-dimethoxy-2,5,9,16-tetramethyl-8,23-dioxo-4,24-dioxa-9,22-diazatetracyclo[19.3.1.1~10,14~.0~3,5~]hexacosa-10(26),11,13,16,18-pentaen-6-yl (2S)-2-{methyl[3-(methylamino)propanoyl]amino}propanoate (non-preferred name) × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；298 K；PEG 3350, MES, CaCl2, MgCl2, glycerol
|
Resolution 2.21 Å R-free 0.217 |
| 7LVQ KIF14[391-743] - AMP-PNP closed state class in complex with a microtubule Deposited 2021-02-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.90 Å |
| 7LVR KIF14[391-743] - ADP-AlFx closed state class in complex with a microtubule Deposited 2021-02-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 AF3 ALUMINUM FLUORIDE × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.90 Å |
| 7LZ7 Tubulin-RB3_SLD-TTL in complex with compound 5k Deposited 2021-03-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 CA CALCIUM ION × 2 MG MAGNESIUM ION × 5 YJ7 4-(3,6-dimethyl[1,2]oxazolo[5,4-d]pyrimidin-4-yl)-7-methoxy-3,4-dihydroquinoxalin-2(1H)-one × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；PEG 4000, glycerol, MES, CaCl2, MgCl2
|
Resolution 2.80 Å R-free 0.211 |
| 7LZ8 Tubulin-RB3_SLD-TTL in complex with compound 5t Deposited 2021-03-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 CA CALCIUM ION × 4 MG MAGNESIUM ION × 4 CL CHLORIDE ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 YJ4 4-[2-(ethylamino)pyrido[3,2-d]pyrimidin-4-yl]-7-methoxy-3,4-dihydroquinoxalin-2(1H)-one × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.7；293 K；PEG 4000, MES, glycerol, CaCl2, MgCl2, ethyl acetate
|
Resolution 2.92 Å R-free 0.228 |
| 7NB8 Plasmodium falciparum kinesin-5 motor domain without nucleotide, complexed with 14 protofilament microtubule. Deposited 2021-01-25 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 2 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 8
cryo-EM vitrification conditions
Cryogen ETHANE；3.5 uM microtubules were incubated to the grid and incubated for 30 seconds. The grid was blotted, then 40 uM kinesin motor domain added and incubated for 30 seconds. The grid was again blotted and 40 uM kinesin motor domain added for 30 seconds. Then the grid was blotted and plunge frozen.
|
Resolution 4.40 Å |
| 7NBA Plasmodium falciparum kinesin-5 motor domain bound to AMPPNP, complexed with 14 protofilament microtubule. Deposited 2021-01-25 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 3 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 1 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 8
cryo-EM vitrification conditions
Cryogen ETHANE；5 uM microtubules were applied to the grid and incubated for 30 seconds. The grid was blotted, then 40 uM kinesin motor domain added, incubated for 30 seconds, then blotted. 40 uM Kinesin motor domain was again added, incubated for 40 seconds, blotted, then plunge frozen.
|
Resolution 4.00 Å |
| 7PQC tau-microtubule structural ensemble based on CryoEM data Deposited 2021-09-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 15 PDB declaration: pentadecameric |
Chain B
1–451（451 aa）
Chain D
1–451（451 aa）
Chain F
1–451（451 aa）
Chain H
1–451（451 aa）
Chain J
1–451（451 aa）
Chain L
1–451（451 aa）
Chain N
1–451（451 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 7 GTP GUANOSINE-5'-TRIPHOSPHATE × 7 MG MAGNESIUM ION × 7 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.10 Å |
| 7PQP tau-microtubule structural ensemble based on CryoEM data Deposited 2021-09-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 15 PDB declaration: pentadecameric |
Chain B
1–451（451 aa）
Chain D
1–451（451 aa）
Chain F
1–451（451 aa）
Chain H
1–451（451 aa）
Chain J
1–451（451 aa）
Chain L
1–451（451 aa）
Chain N
1–451（451 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 7 GTP GUANOSINE-5'-TRIPHOSPHATE × 7 MG MAGNESIUM ION × 7 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.10 Å |
| 7RS6 Cryo-EM structure of Kip3 (AMPPNP) bound to GMPCPP-Stabilized Microtubules Deposited 2021-08-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
Chain E
1–451（451 aa）
Chain G
1–451（451 aa）
Chain I
1–451（451 aa）
Chain L
1–451（451 aa）
Chain N
1–451（451 aa）
Chain P
1–451（451 aa）
Chain R
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 9 MG MAGNESIUM ION × 27 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 9 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 9 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；BRB80 buffer (80 mM PIPES-KOH, pH 6.8; 1 mM MgCl2, 1 mM EGTA, 1 mM DTT)
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.10 Å |
| 7SGS Cryo-EM structure of full-length MAP7 bound to the microtubule Deposited 2021-10-07 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain B
1–451（451 aa）
Chain D
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.30 Å |
| 7TQX CaKip3[2-482] - AMP-PNP in complex with a microtubule Deposited 2022-01-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.80 Å |
| 7TQY CaKip3[2-482] - ADP-AlFx in complex with a microtubule Deposited 2022-01-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | AF3 ALUMINUM FLUORIDE × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 2 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.60 Å |
| 7TQZ Apo CaKip3[2-482] in complex with a microtubule Deposited 2022-01-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.70 Å |
| 7TR0 CaKip3[2-436] - AMP-PNP in complex with a microtubule Deposited 2022-01-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.70 Å |
| 7TR1 CaKip3[2-436]-L2-mutant(HsKHC) - AMP-PNP in complex with a microtubule Deposited 2022-01-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | MG MAGNESIUM ION × 2 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.10 Å |
| 7TR2 Apo CaKip3[2-436]-L2-mutant(HsKHC) in complex with a microtubule Deposited 2022-01-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.00 Å |
| 7TR3 CaKip3[2-482] - AMP-PNP in complex with a dolastatin-10-stabilized tubulin ring Deposited 2022-01-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 SR6 dolastatin-10 × 1 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.90 Å |
| 7TTD Tubulin-RB3_SLD in complex with compound 12e Deposited 2022-02-01 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–438（438 aa）
Chain C
1–438（438 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 SO4 SULFATE ION × 4 GDP GUANOSINE-5'-DIPHOSPHATE × 1 JUL 7-methoxy-4-[2-(morpholin-4-yl)-6,7-dihydro-5H-cyclopenta[d]pyrimidin-4-yl]-3,4-dihydroquinoxalin-2(1H)-one × 2 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 5.6；293 K；0.2M ammonium sulfate, 0.1 M tri-sodium citrate, pH 5.6, 12 ~14 % PEG 4K
|
Resolution 2.27 Å R-free 0.224 |
| 7TTE Tubulin-RB3_SLD in complex with compound 12j Deposited 2022-02-01 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–438（438 aa）
Chain C
1–438（438 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 SO4 SULFATE ION × 4 GDP GUANOSINE-5'-DIPHOSPHATE × 1 JVR 4-[2-(cyclopropylamino)-6,7-dihydro-5H-cyclopenta[d]pyrimidin-4-yl]-7-methoxy-3,4-dihydroquinoxalin-2(1H)-one × 2 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 5.6；293 K；0.2M ammonium sulfate, 0.1 M tri-sodium citrate, pH 5.6, 14 % PEG 4K
|
Resolution 2.70 Å R-free 0.239 |
| 7TTF Tubulin-RB3_SLD in complex with compound 12k Deposited 2022-02-01 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–438（438 aa）
Chain C
1–438（438 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 SO4 SULFATE ION × 7 GDP GUANOSINE-5'-DIPHOSPHATE × 1 JV9 7-methoxy-4-[2-(methylamino)-6,7-dihydro-5H-cyclopenta[d]pyrimidin-4-yl]-3,4-dihydroquinoxalin-2(1H)-one × 2 GOL GLYCEROL × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 5.6；293 K；0.2M ammonium sulfate, 0.1 M tri-sodium citrate, pH 5.6, 14 % PEG 4K
|
Resolution 2.10 Å R-free 0.238 |
| 7XQX Crystal structure of T2R-TTL-27a complex Deposited 2022-05-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 3 CA CALCIUM ION × 2 CL CHLORIDE ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 GXI 2-chloranyl-7-fluoranyl-N-(4-methoxyphenyl)-N-methyl-quinazolin-4-amine × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；277 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 3.36 Å R-free 0.245 |
| 7XQY Crystal structure of T2R-TTL-15 complex Deposited 2022-05-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 3 CA CALCIUM ION × 2 CL CHLORIDE ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 GX5 2-chloranyl-N-(4-methoxyphenyl)-N-methyl-pyrido[3,2-d]pyrimidin-4-amine × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；277 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.35 Å R-free 0.236 |
| 7XR0 Crystal structure of T2R-TTL-27a complex Deposited 2022-05-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 3 CA CALCIUM ION × 2 CL CHLORIDE ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 GWC 2-chloranyl-5-fluoranyl-N-(4-methoxyphenyl)-N-methyl-quinazolin-4-amine × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；277 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.70 Å R-free 0.246 |
| 7XR1 Crystal structure of T2R-TTL-3a complex Deposited 2022-05-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 3 CA CALCIUM ION × 2 CL CHLORIDE ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 GY2 2-chloranyl-6-fluoranyl-N-(4-methoxyphenyl)-N-methyl-quinazolin-4-amine × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；277 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.81 Å R-free 0.246 |
| 7YHN ANTI-TUMOR AGENT Y48 IN COMPLEX WITH TUBULIN Deposited 2022-07-14 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 6 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 IUK 4-methyl-3-[(4-methylphenyl)sulfonylamino]-~{N}-[(6-methylpyridin-3-yl)methyl]benzamide × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；6% PEG 4000, 8% GLYCEROL, 30MM MAGNESIUM CHLORIDE, 30MM CALCIUM CHLORIDE, 100MM MES
|
Resolution 2.60 Å R-free 0.272 |
| 7YSN Tubulin heterodimer structure of GMPCPP state in solution Deposited 2022-08-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.50 Å |
| 7YSO Tubulin heterodimer structure of GDP-1 state in solution Deposited 2022-08-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.60 Å |
| 7YSP Tubulin heterodimer structure of GDP-2 state in solution Deposited 2022-08-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.90 Å |
| 7Z2A P. berghei kinesin-8B motor domain in no nucleotide state bound to tubulin dimer Deposited 2022-02-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–437（437 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 2 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.30 Å |
| 7Z2B P. berghei kinesin-8B motor domain in AMPPNP state bound to tubulin dimer Deposited 2022-02-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–437（437 aa）
|
Not recorded | ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 MG MAGNESIUM ION × 3 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.30 Å |
| 7Z2C P. falciparum kinesin-8B motor domain in no nucleotide bound to tubulin dimer Deposited 2022-02-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–437（437 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 2 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.10 Å |
| 8DIQ Tubulin-RB3_SLD-TTL in complex with SB226 Deposited 2022-06-29 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 CA CALCIUM ION × 2 MG MAGNESIUM ION × 5 DMS DIMETHYL SULFOXIDE × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 JVI 4-[2-(ethylamino)-6,7-dihydro-5H-cyclopenta[d]pyrimidin-4-yl]-7-methoxy-3,4-dihydroquinoxalin-2(1H)-one × 2 GOL GLYCEROL × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；PEG4K, MES, Glycerol, CaCl2, MgCl2
|
Resolution 2.40 Å R-free 0.209 |
| 8F18 Apo KIF20A[1-565] class-2 in complex with a microtubule Deposited 2022-11-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | MG MAGNESIUM ION × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.20 Å |
| 8F1A Apo KIF20A[1-565] class-1 in complex with a microtubule Deposited 2022-11-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.10 Å |
| 8JJB Crystal structure of T2R-TTL-Y61 complex Deposited 2023-05-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 CA CALCIUM ION × 6 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 USI ~{N}4-(1~{H}-indol-5-ylmethyl)-6-(3-methoxyphenyl)pyrimidine-2,4-diamine × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 CL CHLORIDE ION × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；6% poly(ethylene glycol) 4000, 8% glycerol, 0.1 M MES (pH 6.7), 30 mM CaCl2, 30 mM MgCl2
|
Resolution 2.68 Å R-free 0.260 |
| 8JJC Tubulin-Y62 Deposited 2023-05-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 CA CALCIUM ION × 6 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 UPO 4-(6,7-dimethoxy-3,4-dihydro-1~{H}-isoquinolin-2-yl)-6-(3-methoxyphenyl)pyrimidin-2-amine × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 CL CHLORIDE ION × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；6% poly(ethylene glycol) 4000, 8% glycerol, 0.1 M MES (pH 6.7), 30 mM CaCl2, 30 mM MgCl2
|
Resolution 2.76 Å R-free 0.264 |
| 8RC1 MAP7 MTBD (microtubule binding domain) decorated microtubule protofilament Deposited 2023-12-05 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.5；80mM PIPES, 2mM MgCl2, 1mM EGTA
cryo-EM vitrification conditions
Cryogen ETHANE；Microtubules stabilised by MAP7 MTBD were applied to a glow discharged grid, incubated for 30 seconds at room temperature following which excess sample was wicked off and MAP7 MTBD was immediately added to the grid. After incubation for 60 seconds in a Vitrobot, excess liquid was blotted off and the grid was plunge frozen in liquid ethane.
|
Resolution 3.70 Å |
| 8RHB Microtubule-associated kinesin-1 tail complex bound to AMPPNP, single-headed state Deposited 2023-12-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–451（451 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 MG MAGNESIUM ION × 2 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；BRB80 + 5mM AMPPNP
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.00 Å |
| 8RHH Microtubule-associated kinesin-1 tail complex bound to AMPPNP, two-headed state Deposited 2023-12-15 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: pentameric |
Chain A
1–451（451 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 2 MG MAGNESIUM ION × 3 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；BRB80 + 5mM AMPPNP
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.00 Å |
| 8RIK Microtubule-associated kinesin-1 tail complex bound to ADP, single-headed state Deposited 2023-12-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: tetrameric |
Chain A
1–451（451 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；BRB80 + 5 mM ADP
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.60 Å |
| 8RIZ Microtubule-associated kinesin-1 tail complex bound to ADP, two-headed state Deposited 2023-12-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–451（451 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 2 ADP ADENOSINE-5'-DIPHOSPHATE × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；BRB80 + 5mM ADP
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.60 Å |
| 8UTN KIF1A[1-393] AMP-PNP bound two-heads-bound state in complex with a microtubule (class T23L1) Deposited 2023-10-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric |
Chain A
1–451（451 aa）
Chain E
1–451（451 aa）
Chain S
1–451（451 aa）
|
Not recorded | MG MAGNESIUM ION × 4 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 2 GTP GUANOSINE-5'-TRIPHOSPHATE × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 2 TA1 TAXOL × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.10 Å |
| 8UTO KIF1A[1-393] AMP-PNP bound two-heads-bound state in complex with a microtubule - class T2L1 Deposited 2023-10-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric |
Chain A
1–451（451 aa）
Chain E
1–451（451 aa）
Chain S
1–451（451 aa）
|
Not recorded | MG MAGNESIUM ION × 4 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 2 GTP GUANOSINE-5'-TRIPHOSPHATE × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 2 TA1 TAXOL × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.20 Å |
| 8UTP KIF1A[1-393] - AMP-PNP two-heads-bound state in complex with a microtubule - class T3L1 Deposited 2023-10-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric |
Chain A
1–451（451 aa）
Chain E
1–451（451 aa）
Chain S
1–451（451 aa）
|
Not recorded | MG MAGNESIUM ION × 4 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 2 GTP GUANOSINE-5'-TRIPHOSPHATE × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 2 TA1 TAXOL × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.20 Å |
| 8UTQ KIF1A[1-393] AMP-PNP bound one-head-bound state in complex with a microtubule - class T1L02* Deposited 2023-10-31 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–451（451 aa）
Chain E
1–451（451 aa）
|
Not recorded | MG MAGNESIUM ION × 3 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 TA1 TAXOL × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.10 Å |
| 8UTR KIF1A[1-393] ADP bound in complex with a microtubule Deposited 2023-10-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | ADP ADENOSINE-5'-DIPHOSPHATE × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.30 Å |
| 8UTS KIF1A[1-393] APO in complex with a microtubule Deposited 2023-10-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.70 Å |
| 8UTT KIF1A[1-393] P305L mutant AMP-PNP bound two-heads-bound state in complex with a microtubule Deposited 2023-10-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric |
Chain A
1–451（451 aa）
Chain E
1–451（451 aa）
Chain S
1–451（451 aa）
|
Not recorded | MG MAGNESIUM ION × 4 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 2 GTP GUANOSINE-5'-TRIPHOSPHATE × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 2 TA1 TAXOL × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.10 Å |
| 8UTU KIF1A[1-393] P305L mutant AMP-PNP bound one and two heads bound states merged, in complex with a microtubule Deposited 2023-10-31 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–451（451 aa）
Chain E
1–451（451 aa）
|
Not recorded | MG MAGNESIUM ION × 3 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.00 Å |
| 8UTV KIF1A[1-393] P305L mutant ADP bound in complex with a microtubule Deposited 2023-10-31 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–451（451 aa）
Chain E
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.00 Å |
| 8UTW KIF1A[1-393] P305L mutant APO in complex with a microtubule Deposited 2023-10-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.40 Å |
| 8UTY KIF1A[1-393] P364L mutant AMP-PNP bound two-heads-bound state in complex with a microtubule Deposited 2023-10-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric |
Chain A
1–451（451 aa）
Chain E
1–451（451 aa）
Chain S
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 GDP GUANOSINE-5'-DIPHOSPHATE × 2 TA1 TAXOL × 2 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.30 Å |
| 8V4K CCP5 in complex with microtubules class1 Deposited 2023-11-29 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | MG MAGNESIUM ION × 4 GTP GUANOSINE-5'-TRIPHOSPHATE × 2 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 2 ZN ZINC ION × 1 GLU GLUTAMIC ACID × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.10 Å |
| 8V4L CCP5 in complex with microtubules class2 Deposited 2023-11-29 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | MG MAGNESIUM ION × 4 GTP GUANOSINE-5'-TRIPHOSPHATE × 2 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 2 GLU GLUTAMIC ACID × 1 ZN ZINC ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.90 Å |
| 8V4M CCP5 in complex with microtubules class3 Deposited 2023-11-29 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | MG MAGNESIUM ION × 4 GTP GUANOSINE-5'-TRIPHOSPHATE × 2 G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 2 GLU GLUTAMIC ACID × 1 ZN ZINC ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.00 Å |
| 8WMO Crystal structure analysis of tubulin and heterocyclic podophyllotoxins complex for anticancer agents Deposited 2023-10-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–440（440 aa）
Chain C
1–440（440 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 EDO 1,2-ETHANEDIOL × 8 PEG DI(HYDROXYETHYL)ETHER × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 WIW (5~{S},5~{a}~{R},8~{a}~{R},9~{R})-5-pyrimidin-2-ylsulfanyl-9-(3,4,5-trimethoxyphenyl)-5~{a},6,8~{a},9-tetrahydro-5~{H}-[2]benzofuro[5,6-f][1,3]benzodioxol-8-one × 1 CA CALCIUM ION × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；277 K；6% glycerol, 6% PEG4000, 30 mM MgCl2, 30 mM CaCl2, 100 mM MES-Na
|
Resolution 2.89 Å R-free 0.266 |
| 8WMU Structural basis of tubulin and heterocyclic podophyllotoxins complex for anticancer agents with dual-binding sites Deposited 2023-10-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–440（440 aa）
Chain C
1–440（440 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 3 CA CALCIUM ION × 2 GOL GLYCEROL × 1 PEG DI(HYDROXYETHYL)ETHER × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 A1D55 (5~{S},5~{a}~{S},8~{a}~{R},9~{R})-5-(quinolin-6-ylamino)-9-(3,4,5-trimethoxyphenyl)-5~{a},6,8~{a},9-tetrahydro-5~{H}-[2]benzofuro[6,5-f][1,3]benzodioxol-8-one × 1 EDO 1,2-ETHANEDIOL × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；277 K；6% PEG4000, 6% glycerol, 30 mM MgCl2, 30 mM CaCl2, 100 mM MES-Na
|
Resolution 2.70 Å R-free 0.245 |
| 8YEM Tubulin-RB3_SLD-TTL in complex with compound 9 Deposited 2024-02-22 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–440（440 aa）
Chain C
1–440（440 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 CA CALCIUM ION × 2 MG MAGNESIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 A1D6D 4-(2-chloranyl-6-fluoranyl-quinazolin-4-yl)-7-methoxy-1,3-dihydroquinoxalin-2-one × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% PEG 4000, 5% Glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2
|
Resolution 2.74 Å R-free 0.284 |
| 8YER Tubulin-RB3_SLD-TTL in complex with compound 4 Deposited 2024-02-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–440（440 aa）
Chain C
1–440（440 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 CA CALCIUM ION × 2 MG MAGNESIUM ION × 3 A1D6E 6-fluoranyl-4-(6-methoxy-3,4-dihydro-2~{H}-quinolin-1-yl)-~{N}-methyl-quinazolin-2-amine × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% PEG 4000, 5% Glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2
|
Resolution 2.71 Å R-free 0.286 |
| 8YEU Tubulin-RB3_SLD-TTL in complex with compound 2NH2 Deposited 2024-02-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–440（440 aa）
Chain C
1–440（440 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 CA CALCIUM ION × 2 MG MAGNESIUM ION × 3 A1D6L 6-fluoranyl-4-(6-methoxy-3,4-dihydro-2~{H}-quinolin-1-yl)quinazolin-2-amine × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% PEG 4000, 5% Glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2
|
Resolution 3.05 Å R-free 0.268 |
| 8YRK Tubulin-Compound KY216: stathmin-like domain complex Deposited 2024-03-21 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 4 CA CALCIUM ION × 2 CL CHLORIDE ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 GOL GLYCEROL × 1 A1D62 (11R,16S)-11-(3,5-dichloro-4-methoxyphenyl)-4,7-dioxa-12,14-diazatetracyclo[8.7.0.03,8.012,16]heptadeca-1,3(8),9-triene-13,15-dione × 2 EDO 1,2-ETHANEDIOL × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291.15 K；PEG,magnesium choride,calcium chloride,Ethylene glycol,MES
|
Resolution 2.74 Å R-free 0.226 |
| 8YTX Tubulin-RB3-TTL in complex with compound SI9 Deposited 2024-03-26 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–440（440 aa）
Chain C
1–440（440 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 CA CALCIUM ION × 2 MG MAGNESIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 A1D68 2-chloranyl-~{N}-(4-methoxyphenyl)-~{N}-methyl-thieno[2,3-d]pyrimidin-4-amine × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% PEG 4000, 5% Glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2
|
Resolution 2.53 Å R-free 0.266 |
| 8YU9 Tubulin-RB3-TTL in complex with compound SI10 Deposited 2024-03-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–440（440 aa）
Chain C
1–440（440 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 CA CALCIUM ION × 2 MG MAGNESIUM ION × 3 A1D7A 4-(2-chloranylthieno[3,2-d]pyrimidin-4-yl)-7-methoxy-1,3-dihydroquinoxalin-2-one × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% PEG 4000, 5% Glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2
|
Resolution 3.25 Å R-free 0.286 |
| 8YUA Tubulin-RB3-TTL in complex with compound SI10 Deposited 2024-03-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–440（440 aa）
Chain C
1–440（440 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 CA CALCIUM ION × 2 MG MAGNESIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 A1D69 2-chloranyl-~{N}-(4-methoxyphenyl)-~{N}-methyl-thieno[3,2-d]pyrimidin-4-amine × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% PEG 4000, 5% Glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2
|
Resolution 2.37 Å R-free 0.254 |
| 8YY2 Kinesin-14 in nucleotide-free state bound to 13 PF Microtubule Deposited 2024-04-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；100 mM PIPES pH 6.8, 1 mM MgCl2, 1 mM EGTA, and 1 mM GTP
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.60 Å |
| 8YY3 Kinesin-14 in nucleotide-free state bound to 14 PF Microtubule Deposited 2024-04-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；100 mM PIPES pH 6.8, 1 mM MgCl2, 1 mM EGTA, and 1 mM GTP
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.24 Å |
| 8YY4 Kinesin-14 with AlF3 bound to 13 PF Microtubule Deposited 2024-04-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 2 MG MAGNESIUM ION × 2 ALF TETRAFLUOROALUMINATE ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；100 mM PIPES pH 6.8, 1 mM MgCl2, 1 mM EGTA, 1 mM GTP, 2 mM ADP, 2 mM AlCl3, and 8 mM NaF
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.02 Å |
| 8YY5 Kinesin-14 with AlF3 bound to 14 PF Microtubule Deposited 2024-04-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 2 MG MAGNESIUM ION × 2 ALF TETRAFLUOROALUMINATE ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；100 mM PIPES pH 6.8, 1 mM MgCl2, 1 mM EGTA, 1 mM GTP, 2 mM ADP, 2 mM AlCl3, and 8 mM NaF
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.99 Å |
| 8ZB8 Crystal structure of T2R-TTL-DPP21 complex Deposited 2024-04-26 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 3 CA CALCIUM ION × 2 GOL GLYCEROL × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 A1D8I ~{N},2-dimethyl-~{N}-(1-methylindol-5-yl)thieno[3,2-d]pyrimidin-4-amine × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% polyethylene glycol 4000, 8% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.94 Å R-free 0.259 |
| 9DA8 Tau-Microtubule structure in the presence of ATP Deposited 2024-08-21 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 8 PDB declaration: octameric |
Chain B
1–451（451 aa）
Chain L
1–451（451 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 4 TA1 TAXOL × 4 GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.9
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.94 Å |
| 9DHZ Cryo-EM structure of HURP bound to a microtubule Deposited 2024-09-04 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain B
1–451（451 aa）
Chain L
1–451（451 aa）
|
Not recorded | TA1 TAXOL × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.9
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.10 Å |
| 9DI0 Cryo-EM structure of Kif18A bound to a microtubule Deposited 2024-09-04 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 3 PDB declaration: trimeric |
Chain L
1–451（451 aa）
|
Not recorded | ADP ADENOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 2 TA1 TAXOL × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.9
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.10 Å |
| 9DUQ HURP(65-174) bound to GMPCPP-stabilized microtubule Deposited 2024-10-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 27 PDB declaration: 27-meric |
Chain A
1–439（439 aa）
Chain C
1–439（439 aa）
Chain E
1–439（439 aa）
Chain G
1–439（439 aa）
Chain I
1–439（439 aa）
Chain K
1–439（439 aa）
Chain M
1–439（439 aa）
Chain O
1–439（439 aa）
Chain Q
1–439（439 aa）
|
Not recorded | G2P PHOSPHOMETHYLPHOSPHONIC ACID GUANYLATE ESTER × 9 MG MAGNESIUM ION × 18 GTP GUANOSINE-5'-TRIPHOSPHATE × 9 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；BRB80 (1X): 80 mM PIPES, 1 mM MgCl2, 1 mM EGTA, pH 6.8 with KOH
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.80 Å |
| 9DXC Model of tubulin dimers used for determining the dimer rise in a taxol-stabilized microtubule-HURP complex Deposited 2024-10-11 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.10 Å |
| 9DXE Model of tubulin dimers used for determining the dimer rise in a taxol-stabilized microtubule Deposited 2024-10-11 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.30 Å |
| 9GNQ Microtubule-associated Kif5B IAK tail mutant bound to ADP Deposited 2024-09-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；BRB80 + 5mM AMPPNP
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.90 Å |
| 9IM5 Tubulin-RB3(MUT)-TTL-Y12 Deposited 2024-07-02 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 4 CA CALCIUM ION × 3 CL CHLORIDE ION × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 A1L2T ~{N}4-(1,3-benzodioxol-5-ylmethyl)-6-(1~{H}-indol-4-yl)pyrimidine-2,4-diamine × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% PEG 4000, 5% glycerol, 0.1M MES, 30mM CaCl2, 30mM MgCl2, pH 6.7
|
Resolution 2.86 Å R-free 0.246 |
| 9IMO Crystal structure of Tubulin-RB3-TTL-Y12 Deposited 2024-07-04 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 5 CA CALCIUM ION × 3 A1L2T ~{N}4-(1,3-benzodioxol-5-ylmethyl)-6-(1~{H}-indol-4-yl)pyrimidine-2,4-diamine × 4 GDP GUANOSINE-5'-DIPHOSPHATE × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% PEG 4000, 5% glycerol, 0.1M MES, 30mM CaCl2, 30mM MgCl2, pH 6.7
|
Resolution 2.75 Å R-free 0.255 |
| 9IXB Structure of tubulin and nitrogen-containing heterocyclic substituted podophyllotoxin derivatives complex Deposited 2024-07-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–440（440 aa）
Chain C
1–440（440 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 EDO 1,2-ETHANEDIOL × 1 MG MAGNESIUM ION × 3 CA CALCIUM ION × 1 NA SODIUM ION × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 A1ECQ (5~{S},5~{a}~{S},8~{a}~{R},9~{R})-5-(1~{H}-indazol-5-ylamino)-9-(3,4,5-trimethoxyphenyl)-5~{a},6,8~{a},9-tetrahydro-5~{H}-[2]benzofuro[6,5-f][1,3]benzodioxol-8-one × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 IMD IMIDAZOLE × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；277 K；6% PEG4000, 6% glycerol, 30 mM MgCl2, 30 mM CaCl2, 100 mM MES-Na
|
Resolution 3.48 Å R-free 0.267 |
| 9K7E Crystal structure of T2R-TTL-taccalonolide Y8 complex Deposited 2024-10-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–440（440 aa）
Chain C
1–440（440 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 CA CALCIUM ION × 2 MG MAGNESIUM ION × 3 A1EE1 (4~{R})-5-(4-hydroxyphenyl)-3-(4-methylphenyl)-4-phenyl-2,4-dihydropyrrolo[3,4-c]pyrazol-6-one × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.45 Å R-free 0.267 |
| 9KBL Crystal structure of T2R-TTL-IKP104 Deposited 2024-10-31 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 CA CALCIUM ION × 7 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 W4Q 1-(2-chloranyl-3,5-dimethoxy-phenyl)-2-(4-fluorophenyl)-3-methyl-6-phenyl-pyridin-4-one × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；6% poly(ethylene glycol) 4000, 8% glycerol, 0.1 M MES (pH 6.7), 30 mM CaCl2 and 30 mM MgCl2.
|
Resolution 3.14 Å R-free 0.238 |
| 9KBN Crystal structure of T2R-TTL-IKP104-Colchicine Deposited 2024-10-31 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 CA CALCIUM ION × 7 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 W4Q 1-(2-chloranyl-3,5-dimethoxy-phenyl)-2-(4-fluorophenyl)-3-methyl-6-phenyl-pyridin-4-one × 1 LOC N-[(7S)-1,2,3,10-tetramethoxy-9-oxo-6,7-dihydro-5H-benzo[d]heptalen-7-yl]ethanamide × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；6% poly(ethylene glycol) 4000, 8% glycerol, 0.1 M MES (pH 6.7), 30 mM CaCl2 and 30 mM MgCl2.
|
Resolution 2.56 Å R-free 0.262 |
| 9KBW CryoEM structure of microtubule bound with GAS2-GAR domain. Deposited 2024-10-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–439（439 aa）
|
Not recorded | ZN ZINC ION × 1 GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；80 mM PIPES, pH 6.8, 2 mM MgCl2, 1 mM EGTA, 1mM DTT
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.20 Å |
| 9L7M Nucleotide-free kinesin-1 motor domain bound to the microtubule Deposited 2024-12-26 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 4 MG MAGNESIUM ION × 4 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.48 Å |
| 9LNL Crystal structure of T2R-TTL-YQVB15 complex Deposited 2025-01-21 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 CA CALCIUM ION × 2 MG MAGNESIUM ION × 2 A1EPQ 10',11'-difluoro-12'-methoxyvinblastine × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.85 Å R-free 0.277 |
| 9LNV Crystal structure of T2R-TTL-YQVB6 Complex Deposited 2025-01-22 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 CA CALCIUM ION × 2 A1EPR 10'-fluorovinblastine × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.67 Å R-free 0.288 |
| 9LNW Crystal structure of T2R-TTL-YQVB8 Complex Deposited 2025-01-22 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 CA CALCIUM ION × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 A1EPS 10'-bromovinblastine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.55 Å R-free 0.292 |
| 9LNX Crystal structure of T2R-TTL-YQVB9 Complex Deposited 2025-01-22 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–450（450 aa）
Chain C
1–450（450 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 CA CALCIUM ION × 2 A1EPT 10'-methoxyvinblastine × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；6% PEG, 5% glycerol, 0.1 M MES, 30 mM CaCl2, 30 mM MgCl2, pH 6.7
|
Resolution 2.59 Å R-free 0.296 |
| 9M1L Cryo-EM structure of the TBC-DE-Arl2-alpha-beta-tubulin complex with GTP Deposited 2025-02-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain a
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 3 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.55 Å |
| 9M1M Cryo-EM structure of the TBC-DEC-Arl2-alpha-beta-tubulin complex with GDP-AlFx Deposited 2025-02-26 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain a
1–451（451 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 1 AF3 ALUMINUM FLUORIDE × 1 MG MAGNESIUM ION × 3 GTP GUANOSINE-5'-TRIPHOSPHATE × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.21 Å |
| 9M1N Cryo-EM structure of the TBC-DC-Arl2-alpha-beta-tubulin complex with GDP-AlFx Deposited 2025-02-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain a
1–451（451 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 1 AF3 ALUMINUM FLUORIDE × 1 MG MAGNESIUM ION × 3 GTP GUANOSINE-5'-TRIPHOSPHATE × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.24 Å |
| 9MLF TUBULIN-RB3_SLD IN COMPLEX WITH COMPOUND QW-4-183-llb Deposited 2024-12-19 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–438（438 aa）
Chain C
1–438（438 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 A1BMG [(4M)-4-(1H-indol-4-yl)-1H-imidazol-2-yl](3,4,5-trimethoxyphenyl)methanone × 2 SO4 SULFATE ION × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.6；293.15 K；0.1 M trisodium citrate, pH 5.6, 0.2 M ammonium sulfate, 12.2% PEG 4000
|
Resolution 2.40 Å R-free 0.233 |
| 9N9E Cryo-EM structure of the SAH domain of Caenorhabditis elegans ICP-1 bound to the paclitaxel-stabilized microtubule Deposited 2025-02-10 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 ZN ZINC ION × 2 MG MAGNESIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.60 Å |
| 9N9F Cryo-EM structure of the SAH domain of human INCENP bound to the paclitaxel-stabilized microtubule Deposited 2025-02-10 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 ZN ZINC ION × 2 MG MAGNESIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.91 Å |
| 9N9G Cryo-EM structure of the human Hec1-Nuf2 dimer bound to the paclitaxel-stabilized microtubule Deposited 2025-02-10 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric |
Chain A
1–451（451 aa）
Chain a
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 4 GDP GUANOSINE-5'-DIPHOSPHATE × 2 TA1 TAXOL × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.00 Å |
| 9N9H Cryo-EM structure of the Xenopus laevis mitotic centromere-associated kinesin (MCAK) bound to the paclitaxel-stabilized microtubule Deposited 2025-02-10 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–451（451 aa）
Chain a
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 4 GDP GUANOSINE-5'-DIPHOSPHATE × 2 TA1 TAXOL × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.31 Å |
| 9N9I Cryo-EM structure of the Xenopus laevis mitotic centromere-associated kinesin (MCAK) bound to the paclitaxel-stabilized microtubule Deposited 2025-02-10 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric |
Chain 1
1–451（451 aa）
Chain 4
1–451（451 aa）
Chain A
1–451（451 aa）
Chain a
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 4 MG MAGNESIUM ION × 8 GDP GUANOSINE-5'-DIPHOSPHATE × 4 TA1 TAXOL × 4 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.30 Å |
| 9NNL Bordetella filamentous hemagglutinin (FhaB) C-terminal domain bound to microtubules Deposited 2025-03-05 | Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 8 PDB declaration: octameric |
Chain A
1–451（451 aa）
Chain E
1–451（451 aa）
|
Not recorded | GDP GUANOSINE-5'-DIPHOSPHATE × 4 TA1 TAXOL × 4 GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.42 Å |
| 9O6I TUBULIN-RB3_SLD IN COMPLEX WITH COMPOUND QW-5-70 Deposited 2025-04-13 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–438（438 aa）
Chain C
1–438（438 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 A1B97 [(4M)-4-(1H-indazol-4-yl)-1H-imidazol-2-yl](3,4,5-trimethoxyphenyl)methanone × 2 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.6；293.15 K；0.1 M trisodium citrate, pH 5.6, 0.2 M ammonium sulfate, 12.2% PEG 4000
|
Resolution 2.51 Å R-free 0.244 |
| 9U6A Tubulin-DARPin D1 in complex with a flavone Deposited 2025-03-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 2 A1L8X 3-methoxy-2-(4-methoxy-3-oxidanyl-phenyl)-5,7-bis(oxidanyl)chromen-4-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；PEG 3000, ammonium sulfate, bis-tris methane
|
Resolution 1.92 Å R-free 0.224 |
| 9U6D Crystal structure of tubulin-RB3-TTL in complex with X8 Deposited 2025-03-23 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 5 CA CALCIUM ION × 6 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 2 A1L8Z 2-[2-fluoranyl-4-[4-[2-[4-[(1~{R},2~{S})-2-fluoranylcyclopropyl]carbonylpiperazin-1-yl]ethoxy]phenyl]phenyl]-~{N}-(phenylmethyl)ethanamide × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；6% PEG 4000, 5% glycerol, 0.1M MES, 30mM CaCl2, 30mM MgCl2, pH 6.7
|
Resolution 2.54 Å R-free 0.238 |
| 9U9Q Tubulin-RB3-TTL in complex with C38 Deposited 2025-03-29 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain C
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 3 MG MAGNESIUM ION × 5 CA CALCIUM ION × 7 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 A1L80 2-(1-benzofuran-5-yl)-6-[2,6-bis(fluoranyl)-4-[3-(methylamino)propoxy]phenyl]-5-chloranyl-~{N}-[(2~{S})-1,1,1-tris(fluoranyl)propan-2-yl]-[1,2,4]triazolo[1,5-a]pyrimidin-7-amine × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ACP PHOSPHOMETHYLPHOSPHONIC ACID ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；6% PEG 4000, 5% glycerol, 0.1M MES, 30mM CaCl2, 30mM MgCl2, pH 6.7
|
Resolution 2.93 Å R-free 0.269 |
| 9UMU Giraffe KIF5A motor domain in nucleotide free state bound to microtubule Deposited 2025-04-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.9
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.40 Å |
| 9YA5 KIF1A R350G bound to microtubules in two-heads-bound state with AMP-PNP Deposited 2025-09-15 | Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain E
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 2 MG MAGNESIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 2 TA1 TAXOL × 2 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；BRB80 buffer composed of 80 mM
PIPES, 2 mM MgCl2, 1 mM EGTA, PH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE；4uL of a 6uM MT solution in BRB80 (80mM PIPES, 2mM MgCl2, 1mM EGTA pH 6.8) along with 20uM paclitaxel was added onto a plasma-cleaned grid. The MTs were incubated for 1 minute at room temperature, and then the excess liquid was removed from the grid using Whatman #1 paper. Next, 4uL of a solution containing 20uM KIF1A-R350G in BRB80 supplemented with 20uM paclitaxel and 5mM AMP-PNP was added to the grid. The grid with the MT and kinesin mixture was then mounted into a Vitrobot, incubated for 1 minute at room temperature, and plunge-frozen into liquid nitrogen-cooled ethane.
|
Resolution 2.95 Å |
| 9YA7 KIF1A R350G bound to microtubules in the apo state Deposited 2025-09-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；BRB80 buffer composed of 80 mM
PIPES, 2 mM MgCl2, 1 mM EGTA, PH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE；4uL of a 6uM MT solution in BRB80 (80mM PIPES, 2mM MgCl2, 1mM EGTA pH 6.8) along with 20uM paclitaxel was added onto a plasma-cleaned grid. The MTs were incubated for 1 minute at room temperature, and then the excess liquid was removed from the grid using Whatman #1 paper. Next, 4uL of a solution containing 20uM KIF1A-R350G in BRB80 supplemented with 20uM paclitaxel and 0.005 units per uL apyrase was added to the grid. The grid with the MT and kinesin mixture was then mounted into a Vitrobot, incubated for 1 minute at room temperature, and plunge-frozen into liquid nitrogen-cooled ethane.
|
Resolution 3.29 Å |
| 9YAB KIF1A R350W bound to microtubules in the apo state Deposited 2025-09-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 TA1 TAXOL × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；BRB80 buffer composed of 80 mM
PIPES, 2 mM MgCl2, 1 mM EGTA, PH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE；4uL of a 6uM MT solution in BRB80 (80mM PIPES, 2mM MgCl2, 1mM EGTA pH 6.8) along with 20uM paclitaxel was added onto a plasma-cleaned grid. The MTs were incubated for 1 minute at room temperature, and then the excess liquid was removed from the grid using Whatman #1 paper. Next, 4uL of a solution containing 17.5uM KIF1A-R350W in BRB80 supplemented with 20uM paclitaxel and 0.005 units per uL apyrase was added to the grid. The grid with the MT and kinesin mixture was then mounted into a Vitrobot, incubated for 1 minute at room temperature, and plunge-frozen into liquid nitrogen-cooled ethane.
|
Resolution 3.21 Å |
| 9YAI KIF1A R350W bound to microtubules in two-heads-bound state with AMP-PNP Deposited 2025-09-16 | Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
1–451（451 aa）
Chain E
1–451（451 aa）
|
Not recorded | MG MAGNESIUM ION × 3 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 2 GTP GUANOSINE-5'-TRIPHOSPHATE × 2 GDP GUANOSINE-5'-DIPHOSPHATE × 2 TA1 TAXOL × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8；BRB80 buffer composed of 80 mM
PIPES, 2 mM MgCl2, 1 mM EGTA, PH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE；4uL of a 6uM MT solution in BRB80 (80mM PIPES, 2mM MgCl2, 1mM EGTA pH 6.8) along with 20uM paclitaxel was added onto a plasma-cleaned grid. The MTs were incubated for 1 minute at room temperature, and then the excess liquid was removed from the grid using Whatman #1 paper. Next, 4uL of a solution containing 17.5uM KIF1A-R350W in BRB80 supplemented with 20uM paclitaxel and 5mM AMP-PNP was added to the grid. The grid with the MT and kinesin mixture was then mounted into a Vitrobot, incubated for 1 minute at room temperature, and plunge-frozen into liquid nitrogen-cooled ethane.
|
Resolution 3.12 Å |
| 9YMG Human KIF18A-DARPin fusion protein bound to AMP-PNP and tubulin Deposited 2025-10-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 3 EDO 1,2-ETHANEDIOL × 1 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；0.2 M ammonium nitrate, 0.1 M sodium acetate pH 5.6, 20% (w/v) PEG Smear Low (5% PEG 400, 5% PEG 500 MME, 5% PEG 600, 5% PEG 1000), 5% (v/v) ethylene glycol
|
Resolution 2.41 Å R-free 0.238 |
| 9YMG Human KIF18A-DARPin fusion protein bound to AMP-PNP and tubulin Deposited 2025-10-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–451（451 aa）
|
Not recorded | GTP GUANOSINE-5'-TRIPHOSPHATE × 1 MG MAGNESIUM ION × 3 GDP GUANOSINE-5'-DIPHOSPHATE × 1 ANP PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；0.2 M ammonium nitrate, 0.1 M sodium acetate pH 5.6, 20% (w/v) PEG Smear Low (5% PEG 400, 5% PEG 500 MME, 5% PEG 600, 5% PEG 1000), 5% (v/v) ethylene glycol
|
Resolution 2.41 Å R-free 0.238 |
| 9YXQ Cryo-EM structure of the Xenopus laevis mitotic centromere-associated kinesin (MCAK) bound to the paclitaxel-stabilized microtubule Deposited 2025-10-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 14 PDB declaration: 14-meric |
Chain 1
1–451（451 aa）
Chain 3
1–451（451 aa）
Chain 6
1–451（451 aa）
Chain 8
1–451（451 aa）
Chain A
1–451（451 aa）
Chain a
1–451（451 aa）
|
Not recorded | MG MAGNESIUM ION × 11 GTP GUANOSINE-5'-TRIPHOSPHATE × 6 GDP GUANOSINE-5'-DIPHOSPHATE × 6 TA1 TAXOL × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 6.8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.39 Å |
230 other PDB entries and 243 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | TBA1B_PIG |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 1–451； UniProt 1–451 Author chain C； PDBConstruct 1–451； UniProt 1–451 |
