DNA damage-binding protein 1
Homo sapiens
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein heterocomplex Heteromer Protein × 3 PDB declaration: trimeric（3） Consistent with protein copy count | Chain A； UniProt 1–395 Chain A； UniProt 709–1140 | Not recorded | Cyclin-dependent kinase 12 × 1 （Q9NYV4） Cyclin-K × 1 （O75909） CIT CITRIC ACID × 2 RNU ~{N}-(5-methyl-2,3-dihydro-1,3-thiazol-2-yl)-3-(5-methylfuran-2-yl)carbonyl-1,3-thiazolidine-4-carboxamide × 1 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M ammonium citrate tribasic pH 7.0, 1 M sodium malonate additive | Resolution 3.42 Å R-free 0.237 |
| 2 | Protein heterocomplex Heteromer Protein × 3 PDB declaration: trimeric（3） Consistent with protein copy count | Chain D； UniProt 1–395 Chain D； UniProt 709–1140 | Not recorded | Cyclin-dependent kinase 12 × 1 （Q9NYV4） Cyclin-K × 1 （O75909） CIT CITRIC ACID × 3 RNU ~{N}-(5-methyl-2,3-dihydro-1,3-thiazol-2-yl)-3-(5-methylfuran-2-yl)carbonyl-1,3-thiazolidine-4-carboxamide × 1 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M ammonium citrate tribasic pH 7.0, 1 M sodium malonate additive | Resolution 3.42 Å R-free 0.237 |
| 3 | Protein heterocomplex Heteromer Protein × 3 PDB declaration: trimeric（3） Consistent with protein copy count | Chain G； UniProt 1–395 Chain G； UniProt 709–1140 | Not recorded | Cyclin-dependent kinase 12 × 1 （Q9NYV4） Cyclin-K × 1 （O75909） CIT CITRIC ACID × 2 RNU ~{N}-(5-methyl-2,3-dihydro-1,3-thiazol-2-yl)-3-(5-methylfuran-2-yl)carbonyl-1,3-thiazolidine-4-carboxamide × 1 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M ammonium citrate tribasic pH 7.0, 1 M sodium malonate additive | Resolution 3.42 Å R-free 0.237 |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 8BUB | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 10AY Cryo-EM structure of CRBN-DDB1 in complex with HBS1L and TNG961 Deposited 2026-01-09 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain C
1–1140（1140 aa）
Chain F
1–1140（1140 aa）
|
Not recorded | A1C4S N-{6-[(3R)-2,6-dioxopiperidin-3-yl]naphthalen-1-yl}-N'-{2-[6-(trifluoromethyl)-1-benzothiophen-2-yl]propan-2-yl}urea × 2 ZN ZINC ION × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5；0.1 M HEPES (pH 7.5), 0.24 M sodium chloride, 3 mM TCEP, 0.2 % n-octylglucoside
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.90 Å |
| 2HYE Crystal Structure of the DDB1-Cul4A-Rbx1-SV5V Complex Deposited 2006-08-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；277 K；100mM NaHEPES, 7-9% PEG4000, 10% iso-propanol, 5mM DTT, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 3.10 Å R-free 0.316 |
| 3E0C Crystal Structure of DNA Damage-Binding protein 1(DDB1) Deposited 2008-07-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；0.1 M Bis tris, pH 6.5,0.2 M Lithium sulfate, 25% PEG 3350, 1:6000 Protein:Chymotrypsin , VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.41 Å R-free 0.283 |
| 3EI1 Structure of hsDDB1-drDDB2 bound to a 14 bp 6-4 photoproduct containing DNA-duplex Deposited 2008-09-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 2 PDB declaration: tetrameric |
Chain A
1–1140（1140 aa）
|
Not recorded | PG4 TETRAETHYLENE GLYCOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.7；298 K；100mM Ca-Acetate, 100mM MES pH 5.7, 12-14 % PEG 400, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.80 Å R-free 0.278 |
| 3EI2 Structure of hsDDB1-drDDB2 bound to a 16 bp abasic site containing DNA-duplex Deposited 2008-09-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 2 PDB declaration: tetrameric |
Chain A
1–1140（1140 aa）
|
Not recorded | PG4 TETRAETHYLENE GLYCOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.7；298 K；100mM Ca-Acetate, 100mM MES pH 5.7, 12-14% PEG 400, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.60 Å R-free 0.268 |
| 3EI3 Structure of the hsDDB1-drDDB2 complex Deposited 2008-09-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | PG4 TETRAETHYLENE GLYCOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.7；298 K；100mM Ca-Acetate, 100mM MES pH 5.7, 12-14% PEG 400, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.30 Å R-free 0.251 |
| 3EI4 Structure of the hsDDB1-hsDDB2 complex Deposited 2008-09-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；298 K；200 mM (NH4)2SO4; 800 mM LiSO2; 100 mM Na-Citrate pH 5.6, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 3.30 Å R-free 0.288 |
| 3EI4 Structure of the hsDDB1-hsDDB2 complex Deposited 2008-09-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain C
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；298 K；200 mM (NH4)2SO4; 800 mM LiSO2; 100 mM Na-Citrate pH 5.6, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 3.30 Å R-free 0.288 |
| 3EI4 Structure of the hsDDB1-hsDDB2 complex Deposited 2008-09-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain E
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；298 K；200 mM (NH4)2SO4; 800 mM LiSO2; 100 mM Na-Citrate pH 5.6, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 3.30 Å R-free 0.288 |
| 3I7H Crystal Structure of DDB1 in Complex with the H-Box Motif of HBX Deposited 2009-07-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；16% PEG 4000, 0.2M SODIUM CHLORIDE, 0.1M MES, 0.005M DTT, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.90 Å R-free 0.279 |
| 3I7K Crystal Structure of DDB1 in Complex with the H-Box Motif of WHX Deposited 2009-07-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；16% PEG 4000, 0.2M SODIUM CHLORIDE, 0.1M MES, 0.005 M DTT, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.80 Å R-free 0.271 |
| 3I7L Crystal Structure of DDB1 in Complex with the H-Box Motif of DDB2 Deposited 2009-07-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；16% PEG 4000, 0.2M SODIUM CHLORIDE, 0.1M MES, 0.005 M DTT, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.80 Å R-free 0.289 |
| 3I7N Crystal Structure of DDB1 in Complex with the H-Box Motif of WDTC1 Deposited 2009-07-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；16% PEG 4000, 0.2M SODIUM CHLORIDE, 0.1M MES, 0.005M DTT, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.80 Å R-free 0.290 |
| 3I7O Crystal Structure of DDB1 in Complex with the H-Box Motif of IQWD1 Deposited 2009-07-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；16% PEG 4000, 0.2M SODIUM CHLORIDE, 0.1M MES, 0.005M DTT, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.80 Å R-free 0.320 |
| 3I7P Crystal Structure of DDB1 in Complex with the H-Box Motif of WDR40A Deposited 2009-07-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；16% PEG 4000, 0.2M SODIUM CHLORIDE, 0.1M MES, 0.005M DTT, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 3.00 Å R-free 0.301 |
| 3I89 Crystal Structure of DDB1 in Complex with the H-Box Motif of WDR22 Deposited 2009-07-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；16% PEG 4000, 0.2M SODIUM CHLORIDE, 0.1M MES, 0.005M DTT, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 3.00 Å R-free 0.304 |
| 3I8C Crystal Structure of DDB1 in Complex with the H-Box Motif of WDR21A Deposited 2009-07-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；16% PEG 4000, 0.2M SODIUM CHLORIDE, 0.1M MES, 0.005M DTT, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.80 Å R-free 0.308 |
| 3I8E Crystal Structure of DDB1 in Complex with the H-Box Motif of WDR42A Deposited 2009-07-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；16% PEG 4000, 0.2M SODIUM CHLORIDE, 0.1M MES, 0.005M DTT , pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 3.40 Å R-free 0.338 |
| 3I8E Crystal Structure of DDB1 in Complex with the H-Box Motif of WDR42A Deposited 2009-07-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；16% PEG 4000, 0.2M SODIUM CHLORIDE, 0.1M MES, 0.005M DTT , pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 3.40 Å R-free 0.338 |
| 4A08 Structure of hsDDB1-drDDB2 bound to a 13 bp CPD-duplex (purine at D-1 position) at 3.0 A resolution (CPD 1) Deposited 2011-09-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 2 PDB declaration: tetrameric |
Chain A
1–1140（1140 aa）
|
Mutation：YES | MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 CA CALCIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.6；100 MM MES, 25 MM NAOH, 18% PEG 350MME., pH 5.6
|
Resolution 3.00 Å R-free 0.294 |
| 4A09 Structure of hsDDB1-drDDB2 bound to a 15 bp CPD-duplex (purine at D-1 position) at 3.1 A resolution (CPD 2) Deposited 2011-09-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 2 PDB declaration: tetrameric |
Chain A
1–1140（1140 aa）
|
Mutation：YES | CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.3；100 MM MES, 15 MM NAOH, 21% PEG 200, pH 5.3
|
Resolution 3.10 Å R-free 0.308 |
| 4A0A Structure of hsDDB1-drDDB2 bound to a 16 bp CPD-duplex (pyrimidine at D-1 position) at 3.6 A resolution (CPD 3) Deposited 2011-09-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 2 PDB declaration: tetrameric |
Chain A
1–1140（1140 aa）
|
Mutation：YES | CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.6；100 MM MES, 28 MM NAOH, 16% PEG 350MME., pH 5.6
|
Resolution 3.60 Å R-free 0.347 |
| 4A0B Structure of hsDDB1-drDDB2 bound to a 16 bp CPD-duplex (pyrimidine at D-1 position) at 3.8 A resolution (CPD 4) Deposited 2011-09-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 2 PDB declaration: tetrameric |
Chain A
1–1140（1140 aa）
|
Mutation：YES | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.3；100 MM MES, 15 MM NAOH, 18% PEG 350MME., pH 5.3
|
Resolution 3.80 Å R-free 0.319 |
| 4A0B Structure of hsDDB1-drDDB2 bound to a 16 bp CPD-duplex (pyrimidine at D-1 position) at 3.8 A resolution (CPD 4) Deposited 2011-09-08 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein–DNA Heteromer；Protein × 2 PDB declaration: tetrameric |
Chain C
1–1140（1140 aa）
|
Mutation：YES | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.3；100 MM MES, 15 MM NAOH, 18% PEG 350MME., pH 5.3
|
Resolution 3.80 Å R-free 0.319 |
| 4A0K STRUCTURE OF DDB1-DDB2-CUL4A-RBX1 BOUND TO A 12 BP ABASIC SITE CONTAINING DNA-DUPLEX Deposited 2011-09-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 4 PDB declaration: hexameric |
Chain C
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.3；100MM TRIS-HCL PH 8.3, 33% PEG 200
|
Resolution 5.93 Å R-free 0.270 |
| 4A0L Structure of DDB1-DDB2-CUL4B-RBX1 bound to a 12 bp abasic site containing DNA-duplex Deposited 2011-09-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 4 PDB declaration: hexameric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.2；100MM MES PH 6.2, 3.1% PEG 6000, 4% ETHYLENEGLYCOL
|
Resolution 7.40 Å R-free 0.320 |
| 4A0L Structure of DDB1-DDB2-CUL4B-RBX1 bound to a 12 bp abasic site containing DNA-duplex Deposited 2011-09-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein–DNA Heteromer；Protein × 4 PDB declaration: hexameric |
Chain C
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.2；100MM MES PH 6.2, 3.1% PEG 6000, 4% ETHYLENEGLYCOL
|
Resolution 7.40 Å R-free 0.320 |
| 4A11 Structure of the hsDDB1-hsCSA complex Deposited 2011-09-13 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8；1.4-1.58 M NAKPO4, 0.1 M NAMALONATE, 0-0.1 M LI2SO4, pH 8.0
|
Resolution 3.31 Å R-free 0.233 |
| 4CI1 Structure of the DDB1-CRBN E3 ubiquitin ligase bound to thalidomide Deposited 2013-12-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Non-standard monomer：Yes (specific site not provided by mmCIF) | ZN ZINC ION × 1 EF2 S-Thalidomide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6；PROTEIN WAS CRYSTALLIZED FROM 100 MM NA-CACODYLATE; 80 MM NAH2PO4; 120 MM K2HPO4; 800 MM TRI-NA CITRATE., pH 6
|
Resolution 2.98 Å R-free 0.233 |
| 4CI2 Structure of the DDB1-CRBN E3 ubiquitin ligase bound to lenalidomide Deposited 2013-12-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 LVY S-Lenalidomide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；PROTEIN WAS CRYSTALLIZED FROM 100 MM NA-CACODYLATE PH 6.2, 80 MM NAH2PO4, 120 MM K2HPO4, 950 MM TRI-NA CITRATE.
|
Resolution 2.95 Å R-free 0.234 |
| 4CI3 Structure of the DDB1-CRBN E3 ubiquitin ligase bound to Pomalidomide Deposited 2013-12-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 Y70 S-Pomalidomide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；PROTEIN WAS CRYSTALLIZED FROM 100 MM NA-CACOCYLATE, 80 MM NAH2PO4, 120 MM K2HPO4, 700 MM TRI-NA CITRATE., pH 6.5
|
Resolution 3.50 Å R-free 0.235 |
| 4E54 Damaged DNA induced UV-damaged DNA-binding protein (UV-DDB) dimerization and its roles in chromatinized DNA repair Deposited 2012-03-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 2 PDB declaration: tetrameric |
Chain A
2–1140（1139 aa）
Fragment：DNA DAMAGE-BINDING PROTEIN 1 (DDB1; p127)
|
Mutation：NT-His10-DDB1 | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.5；277 K；20mM Tris pH 7.5, 2mM MgCl2, 1mM EDTA, 2mM TECP, 5% Glycerol, 0.02% azide. UV-DDB-AP24 complex (molar ratio of 1:3 UV-DDB:DNA) at 2.5 mg/mL.
'AP24' refers to synthetic DNA substrate of 24-bpr with a central abasic site mimic., VAPOR DIFFUSION, temperature 277K
|
Resolution 2.85 Å R-free 0.281 |
| 4E5Z Damaged DNA induced UV-damaged DNA-binding protein (UV-DDB) dimerization and its roles in chromatinized DNA repair Deposited 2012-03-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 2 PDB declaration: tetrameric |
Chain A
2–1140（1139 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 7.5；277 K；20mM Tris pH 7.5, 2mM MgCl2, 1mM EDTA, 2mM TECP, 5% Glycerol, 0.02% azide. UV-DDB-AP24 complex (molar ratio of 1:3 UV-DDB:DNA) at 2.5 mg/mL.
'AP24' refers to synthetic DNA substrate of 24-bpr with a central abasic site mimic., VAPOR DIFFUSION, temperature 277K
|
Resolution 3.22 Å R-free 0.284 |
| 4TZ4 Crystal Structure of Human Cereblon in Complex with DDB1 and Lenalidomide Deposited 2014-07-09 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
2–1140（1139 aa）
|
Not recorded | ZN ZINC ION × 1 LVY S-Lenalidomide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；293 K；100mM HEPES pH 7.5, 18% PEG 10K
|
Resolution 3.01 Å R-free 0.271 |
| 5FQD Structural basis of Lenalidomide induced CK1a degradation by the crl4crbn ubiquitin ligase Deposited 2015-12-09 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | ZN ZINC ION × 1 LVY S-Lenalidomide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
70 MM TRIS PH 7.0 140 MM MGCL2 7% W/V PEG 8000
|
Resolution 2.45 Å R-free 0.210 |
| 5FQD Structural basis of Lenalidomide induced CK1a degradation by the crl4crbn ubiquitin ligase Deposited 2015-12-09 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | ZN ZINC ION × 1 LVY S-Lenalidomide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
70 MM TRIS PH 7.0 140 MM MGCL2 7% W/V PEG 8000
|
Resolution 2.45 Å R-free 0.210 |
| 5HXB Cereblon in complex with DDB1, CC-885, and GSPT1 Deposited 2016-01-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain Y
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 85C 1-(3-chloro-4-methylphenyl)-3-({2-[(3S)-2,6-dioxopiperidin-3-yl]-1-oxo-2,3-dihydro-1H-isoindol-5-yl}methyl)urea × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；280 K；200mM Sodium Citrate, Tris pH 8.5, 18% PEG 3350
|
Resolution 3.60 Å R-free 0.273 |
| 5HXB Cereblon in complex with DDB1, CC-885, and GSPT1 Deposited 2016-01-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 85C 1-(3-chloro-4-methylphenyl)-3-({2-[(3S)-2,6-dioxopiperidin-3-yl]-1-oxo-2,3-dihydro-1H-isoindol-5-yl}methyl)urea × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；280 K；200mM Sodium Citrate, Tris pH 8.5, 18% PEG 3350
|
Resolution 3.60 Å R-free 0.273 |
| 5JK7 The X-ray structure of the DDB1-DCAF1-Vpr-UNG2 complex Deposited 2016-04-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；289.15 K；100 mM Na Ctrate, pH 5.6, 11% PEG 20000
|
Resolution 3.49 Å R-free 0.206 |
| 5JK7 The X-ray structure of the DDB1-DCAF1-Vpr-UNG2 complex Deposited 2016-04-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain B
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
BATCH MODE；289.15 K；100 mM Na Ctrate, pH 5.6, 11% PEG 20000
|
Resolution 3.49 Å R-free 0.206 |
| 5V3O Cereblon in complex with DDB1 and CC-220 Deposited 2017-03-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | 8W7 (3S)-3-[4-({4-[(morpholin-4-yl)methyl]phenyl}methoxy)-1-oxo-1,3-dihydro-2H-isoindol-2-yl]piperidine-2,6-dione × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；200mM NaCl, 20% PEG 3350
|
Resolution 3.20 Å R-free 0.267 |
| 6BN7 Crystal structure of DDB1-CRBN-BRD4(BD1) complex bound to dBET23 PROTAC. Deposited 2017-11-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 1 RN3 methyl {(6S)-4-(4-chlorophenyl)-2-[(8-{[({2-[(3S)-2,6-dioxopiperidin-3-yl]-1,3-dioxo-2,3-dihydro-1H-isoindol-4-yl}oxy)acetyl]amino}octyl)carbamoyl]-3,9-dimethyl-6H-thieno[3,2-f][1,2,4]triazolo[4,3-a][1,4]diazepin-6-yl}acetate × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；9% (w/v) PEG20K, 18% (v/v) PEG MME 550, 0.09M BICINE pH8.5, 9% Silver bullet B5 (0.33% w/v 2,7-Naphthalenedisulfonic acid disodium salt, 0.33% w/v Azelaic acid, 0.33% w/v trans-Cinnamic acid, 0.02 M HEPES sodium pH 6.8)
|
Resolution 3.50 Å R-free 0.256 |
| 6BN8 Crystal structure of DDB1-CRBN-BRD4(BD1) complex bound to dBET55 PROTAC. Deposited 2017-11-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；9% PEG20K, 18% PEG MME 550, 0.09M BICINE pH8.5, 9% Silver bullet G4 (0.16% w/v 3-Indolebutyric acid, 0.16% w/v Hexadecanedioic acid, 0.16% w/v Oxamic acid, 0.16% w/v Pyromellitic acid, 0.16% w/v Sebacic acid, 0.16% w/v Suberic acid, 0.02 M HEPES sodium pH 6.8)
|
Resolution 3.99 Å R-free 0.333 |
| 6BN9 Crystal structure of DDB1-CRBN-BRD4(BD1) complex bound to dBET70 PROTAC Deposited 2017-11-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；10% (w/v) PEG20K, 20% (v/v) PEG MME 550, 0.1M BICINE pH8.5, Silver Bullet F2 (0.2% w/v D-Fructose 1,6-bisphosphate trisodium salt hydrate, 0.2% w/v Glycerol phosphate disodium salt hydrate, 0.2% w/v L-O-Phosphoserine, 0.2% w/v O-Phospho-L-tyrosine, 0.2% w/v Phytic acid sodium salt hydrate, 0.02 M HEPES sodium pH 6.8)
|
Resolution 4.38 Å R-free 0.301 |
| 6BNB Crystal structure of DDB1-CRBN-BRD4(BD1) complex bound to dBET57 PROTAC Deposited 2017-11-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.34M NaH2PO4, 0.33M K2HPO4
|
Resolution 6.34 Å R-free 0.381 |
| 6BOY Crystal structure of DDB1-CRBN-BRD4(BD1) complex bound to dBET6 PROTAC. Deposited 2017-11-21 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 1 RN6 2-[(6S)-4-(4-chlorophenyl)-2,3,9-trimethyl-6H-thieno[3,2-f][1,2,4]triazolo[4,3-a][1,4]diazepin-6-yl]-N-(8-{[({2-[(3S)-2,6-dioxopiperidin-3-yl]-1,3-dioxo-2,3-dihydro-1H-isoindol-4-yl}oxy)acetyl]amino}octyl)acetamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；293 K；9% (w/v) PEG20K, 18% (v/v) PEG MME 550, 0.09M BICINE pH8.5, 9% (v/v) Silver bullet D11 (0.25% w/v 2,6-Naphthalenedisulfonic acid disodium salt, 0.25% w/v 4-Aminobenzoic acid, 0.25% w/v 5-Sulfosalicylic acid dihydrate, 0.25% w/v Naphthalene-1,3,6-trisulfonic acid trisodium salt hydrate, 0.02 M HEPES sodium pH 6.8)
|
Resolution 3.33 Å R-free 0.234 |
| 6DSZ Crystal structure of DDB1 in complex with DET1- and DDB1-associated protein 1 (DDA1) Deposited 2018-06-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；277 K；0.1 M MES monohydrate, pH 6.5, 20% (w/v) PEG4000, 180 mM NaCl, 5 mM DTT
|
Resolution 3.09 Å R-free 0.307 |
| 6DSZ Crystal structure of DDB1 in complex with DET1- and DDB1-associated protein 1 (DDA1) Deposited 2018-06-14 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；277 K；0.1 M MES monohydrate, pH 6.5, 20% (w/v) PEG4000, 180 mM NaCl, 5 mM DTT
|
Resolution 3.09 Å R-free 0.307 |
| 6FCV Structure of the human DDB1-CSA complex Deposited 2017-12-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2 M sodium citrate, 24% PEG 3350, 0.1 M bis-tris propane pH 8.0, 3% glycerol
|
Resolution 2.92 Å R-free 0.245 |
| 6H0G Structure of the DDB1-CRBN-pomalidomide complex bound to ZNF692(ZF4) Deposited 2018-07-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Mutation：;Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG) ; Mutation：;Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG) ; | ZN ZINC ION × 2 Y70 S-Pomalidomide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；Protein-drug solution:
350 uM ZNF692-ZF4, 70 uM DDB1/CRBN, 80 uM pomalidomide and in 50 mM HEPES pH 7.4, 200 mM NaCl, 0.25 mM TCEP
Crystallisation solution:
14.1% (w/v) PEG 5K MME and 70 mM Tris-HCl pH 7.5
|
Resolution 4.25 Å R-free 0.256 |
| 6H0G Structure of the DDB1-CRBN-pomalidomide complex bound to ZNF692(ZF4) Deposited 2018-07-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
706–1140（435 aa）
|
Mutation：;Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG) ; Mutation：;Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG),Central WD40 propeller domain (516-725 aa) replaced with a linker (sequence GNGNSG) ; | ZN ZINC ION × 2 Y70 S-Pomalidomide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；293 K；Protein-drug solution:
350 uM ZNF692-ZF4, 70 uM DDB1/CRBN, 80 uM pomalidomide and in 50 mM HEPES pH 7.4, 200 mM NaCl, 0.25 mM TCEP
Crystallisation solution:
14.1% (w/v) PEG 5K MME and 70 mM Tris-HCl pH 7.5
|
Resolution 4.25 Å R-free 0.256 |
| 6PAI Structure of the human DDB1-DDA1-DCAF15 E3 ubiquitin ligase bound to RBM39 and sulfonamide E7820 Deposited 2019-06-11 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–1140（1140 aa）
|
Not recorded | EPE 4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID × 2 O6M 3-cyano-N-(3-cyano-4-methyl-1H-indol-7-yl)benzene-1-sulfonamide × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；0.1 M sodium HEPES, pH 7.0, 15% w/v PEG4000
|
Resolution 2.90 Å R-free 0.252 |
| 6Q0R Structure of DDB1-DDA1-DCAF15 complex bound to E7820 and RBM39 Deposited 2019-08-02 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–395（395 aa）
Fragment：internal deletion of the BPB domain
Chain A
706–1140（435 aa）
Fragment：internal deletion of the BPB domain
|
Not recorded | OXM OXAMIC ACID × 1 O6M 3-cyano-N-(3-cyano-4-methyl-1H-indol-7-yl)benzene-1-sulfonamide × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；300 K；20% PEG 4000
|
Resolution 2.90 Å R-free 0.251 |
| 6Q0V Structure of DDB1-DDA1-DCAF15 complex bound to tasisulam and RBM39 Deposited 2019-08-02 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–395（395 aa）
Fragment：internal deletion of the BPB domain
Chain A
706–1140（435 aa）
Fragment：internal deletion of the BPB domain
|
Not recorded | P7M N-[(5-bromothiophen-2-yl)sulfonyl]-2,4-dichlorobenzamide × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；300 K；20% PEG 4000
|
Resolution 2.90 Å R-free 0.242 |
| 6Q0W Structure of DDB1-DDA1-DCAF15 complex bound to Indisulam and RBM39 Deposited 2019-08-02 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
1–395（395 aa）
Fragment：internal deletion of the BPB domain
Chain A
706–1140（435 aa）
Fragment：internal deletion of the BPB domain
|
Not recorded | EF6 N~1~-(3-chloro-1H-indol-7-yl)benzene-1,4-disulfonamide × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；300 K；20% PEG 4000
|
Resolution 2.90 Å R-free 0.264 |
| 6R8Y Cryo-EM structure of NCP-6-4PP(-1)-UV-DDB Deposited 2019-04-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 10 PDB declaration: dodecameric |
Chain K
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.30 Å |
| 6R8Z Cryo-EM structure of NCP_THF2(-1)-UV-DDB Deposited 2019-04-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 10 PDB declaration: dodecameric |
Chain K
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.90 Å |
| 6R90 Cryo-EM structure of NCP-THF2(+1)-UV-DDB class A Deposited 2019-04-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 10 PDB declaration: dodecameric |
Chain K
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.50 Å |
| 6R91 Cryo-EM structure of NCP_THF2(-3)-UV-DDB Deposited 2019-04-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 10 PDB declaration: dodecameric |
Chain K
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.10 Å |
| 6R92 Cryo-EM structure of NCP-THF2(+1)-UV-DDB class B Deposited 2019-04-02 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein–DNA Heteromer；Protein × 10 PDB declaration: dodecameric |
Chain K
1–395（395 aa）
Chain K
706–1140（435 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.80 Å |
| 6SJ7 Structure of the human DDB1-DDA1-DCAF15 E3 ubiquitin ligase bound to RBM39 and Indisulam Deposited 2019-08-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain B
1–1140（1140 aa）
|
Not recorded | EF6 N~1~-(3-chloro-1H-indol-7-yl)benzene-1,4-disulfonamide × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.54 Å |
| 6TD3 Structure of DDB1 bound to CR8-engaged CDK12-cyclinK Deposited 2019-11-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
708–1140（433 aa）
|
Not recorded | RC8 (2R)-2-({9-(1-methylethyl)-6-[(4-pyridin-2-ylbenzyl)amino]-9H-purin-2-yl}amino)butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；292 K；0.9 M ammonium citrate tribasic
|
Resolution 3.46 Å R-free 0.220 |
| 6TD3 Structure of DDB1 bound to CR8-engaged CDK12-cyclinK Deposited 2019-11-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
708–1140（433 aa）
|
Not recorded | RC8 (2R)-2-({9-(1-methylethyl)-6-[(4-pyridin-2-ylbenzyl)amino]-9H-purin-2-yl}amino)butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；292 K；0.9 M ammonium citrate tribasic
|
Resolution 3.46 Å R-free 0.220 |
| 6TD3 Structure of DDB1 bound to CR8-engaged CDK12-cyclinK Deposited 2019-11-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
708–1140（433 aa）
|
Not recorded | RC8 (2R)-2-({9-(1-methylethyl)-6-[(4-pyridin-2-ylbenzyl)amino]-9H-purin-2-yl}amino)butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；292 K；0.9 M ammonium citrate tribasic
|
Resolution 3.46 Å R-free 0.220 |
| 6UD7 Crystal structure of full-length human DCAF15-DDB1(deltaBPB)-DDA1-RBM39 in complex with indisulam Deposited 2019-09-18 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain B
1–395（395 aa）
Chain B
706–1140（435 aa）
|
Not recorded | GOL GLYCEROL × 2 EF6 N~1~-(3-chloro-1H-indol-7-yl)benzene-1,4-disulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；2% (v:v) TacsimateTM, pH 5.0, 0.1 M sodium citrate tribasic dihydrate, pH 5.6, and 10-20% (w:v) polyethylene glycol 3350
|
Resolution 2.30 Å R-free 0.248 |
| 6UE5 Crystal structure of full-length human DCAF15-DDB1-deltaPBP-DDA1-RBM39 in complex with 4-(aminomethyl)-N-(3-cyano-4-methyl-1H-indol-7-yl)benzenesulfonamide Deposited 2019-09-20 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain B
1–395（395 aa）
Chain B
706–1140（435 aa）
|
Not recorded | Q5J 4-(aminomethyl)-N-(3-cyano-4-methyl-1H-indol-7-yl)benzene-1-sulfonamide × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；291.5 K；2% (v:v) TacsimateTM, pH 5.0, 0.1 M sodium citrate tribasic
676 dihydrate, pH 5.6, and 10-20% (w:v) polyethylene glycol 3350
|
Resolution 2.61 Å R-free 0.266 |
| 6UML Structural Basis for Thalidomide Teratogenicity Revealed by the Cereblon-DDB1-SALL4-Pomalidomide Complex Deposited 2019-10-09 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 2 Y70 S-Pomalidomide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；293 K；10% PEG MME 500, 8% PEG 20K, 210mM calcium acetate, 100mM tris pH 7.5
|
Resolution 3.58 Å R-free 0.267 |
| 6XK9 Cereblon in complex with DDB1, CC-90009, and GSPT1 Deposited 2020-06-25 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain Y
1–1140（1140 aa）
|
Not recorded | V4M 2-(4-chlorophenyl)-N-({2-[(3S)-2,6-dioxopiperidin-3-yl]-1-oxo-2,3-dihydro-1H-isoindol-5-yl}methyl)-2,2-difluoroacetamide × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；293 K；20% PEG 3350, 100mM Tris-HCl (pH 7.5), 300mM sodium citrate
|
Resolution 3.64 Å R-free 0.245 |
| 6XK9 Cereblon in complex with DDB1, CC-90009, and GSPT1 Deposited 2020-06-25 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
1–1140（1140 aa）
|
Not recorded | V4M 2-(4-chlorophenyl)-N-({2-[(3S)-2,6-dioxopiperidin-3-yl]-1-oxo-2,3-dihydro-1H-isoindol-5-yl}methyl)-2,2-difluoroacetamide × 1 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；293 K；20% PEG 3350, 100mM Tris-HCl (pH 7.5), 300mM sodium citrate
|
Resolution 3.64 Å R-free 0.245 |
| 6ZUE Crystal structure of human DDB1 bound to human DCAF1 (amino acid residues 1046-1396) Deposited 2020-07-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.5；291 K；100 mM Tri-Na citrate pH 5.5
18% PEG 1000
|
Resolution 3.09 Å R-free 0.279 |
| 6ZX9 Crystal structure of SIV Vpr,fused to T4 lysozyme, isolated from moustached monkey, bound to human DDB1 and human DCAF1 (amino acid residues 1046-1396) Deposited 2020-07-29 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | GOL GLYCEROL × 8 ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；277.15 K；8-10% PEG 4000 (w/v), 200 mM MgCl2, 100 mM HEPES-NaOH, pH 7.0-8.2.
|
Resolution 2.52 Å R-free 0.260 |
| 7LPS Crystal structure of DDB1-CRBN-ALV1 complex bound to Helios (IKZF2 ZF2) Deposited 2021-02-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 2 RN9 3-[3-[[1-[(3~{S})-2,6-bis(oxidanylidene)piperidin-3-yl]-2,5-bis(oxidanylidene)pyrrol-3-yl]amino]phenyl]-~{N}-(3-chloranyl-4-methyl-phenyl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.57；293 K；30% (w/v) PEG3350, 0.1 M Tris pH 8.57
|
Resolution 3.78 Å R-free 0.303 |
| 7LPS Crystal structure of DDB1-CRBN-ALV1 complex bound to Helios (IKZF2 ZF2) Deposited 2021-02-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 2 RN9 3-[3-[[1-[(3~{S})-2,6-bis(oxidanylidene)piperidin-3-yl]-2,5-bis(oxidanylidene)pyrrol-3-yl]amino]phenyl]-~{N}-(3-chloranyl-4-methyl-phenyl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.57；293 K；30% (w/v) PEG3350, 0.1 M Tris pH 8.57
|
Resolution 3.78 Å R-free 0.303 |
| 7LPS Crystal structure of DDB1-CRBN-ALV1 complex bound to Helios (IKZF2 ZF2) Deposited 2021-02-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 2 RN9 3-[3-[[1-[(3~{S})-2,6-bis(oxidanylidene)piperidin-3-yl]-2,5-bis(oxidanylidene)pyrrol-3-yl]amino]phenyl]-~{N}-(3-chloranyl-4-methyl-phenyl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.57；293 K；30% (w/v) PEG3350, 0.1 M Tris pH 8.57
|
Resolution 3.78 Å R-free 0.303 |
| 7LPS Crystal structure of DDB1-CRBN-ALV1 complex bound to Helios (IKZF2 ZF2) Deposited 2021-02-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain J
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 2 RN9 3-[3-[[1-[(3~{S})-2,6-bis(oxidanylidene)piperidin-3-yl]-2,5-bis(oxidanylidene)pyrrol-3-yl]amino]phenyl]-~{N}-(3-chloranyl-4-methyl-phenyl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.57；293 K；30% (w/v) PEG3350, 0.1 M Tris pH 8.57
|
Resolution 3.78 Å R-free 0.303 |
| 7OKQ Cryo-EM Structure of the DDB1-DCAF1-CUL4A-RBX1 Complex Deposited 2021-05-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 16 PDB declaration: Hexadecameric |
Chain A
1–1140（1140 aa）
Chain E
1–1140（1140 aa）
Chain I
1–1140（1140 aa）
Chain M
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 8.40 Å |
| 7OO3 Pol II-CSB-CSA-DDB1-UVSSA (Structure1) Deposited 2021-05-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 17 PDB declaration: eicosameric |
Chain d
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 8 MG MAGNESIUM ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.80 Å |
| 7OOB Pol II-CSB-CSA-DDB1-UVSSA-ADPBeF3 (Structure2) Deposited 2021-05-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 15 PDB declaration: octadecameric |
Chain d
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 8 MG MAGNESIUM ION × 2 ADP ADENOSINE-5'-DIPHOSPHATE × 1 BEF BERYLLIUM TRIFLUORIDE ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.70 Å |
| 7OOP Pol II-CSB-CSA-DDB1-UVSSA-PAF-SPT6 (Structure 3) Deposited 2021-05-28 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 23 PDB declaration: 26-meric |
Chain d
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 8 MG MAGNESIUM ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.90 Å |
| 7OPC Pol II-CSB-CRL4CSA-UVSSA-SPT6-PAF (Structure 4) Deposited 2021-05-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 25 PDB declaration: 28-meric |
Chain d
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 8 MG MAGNESIUM ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.00 Å |
| 7OPD Pol II-CSB-CRL4CSA-UVSSA-SPT6-PAF (Structure 5) Deposited 2021-05-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 25 PDB declaration: 28-meric |
Chain d
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 8 MG MAGNESIUM ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.00 Å |
| 7U8F Ternary complex structure of Cereblon-DDB1 bound to IKZF2(ZF2) and the molecular glue DKY709 Deposited 2022-03-08 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
1–395（395 aa）
Chain B
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 2 LWK (3S)-3-[5-(1-benzylpiperidin-4-yl)-1-oxo-1,3-dihydro-2H-isoindol-2-yl]piperidine-2,6-dione × 1 SO4 SULFATE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；1.6 M potassium/sodium phosphate, pH 6.5
|
Resolution 3.15 Å R-free 0.243 |
| 7U8F Ternary complex structure of Cereblon-DDB1 bound to IKZF2(ZF2) and the molecular glue DKY709 Deposited 2022-03-08 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain E
1–395（395 aa）
Chain E
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 2 LWK (3S)-3-[5-(1-benzylpiperidin-4-yl)-1-oxo-1,3-dihydro-2H-isoindol-2-yl]piperidine-2,6-dione × 1 SO4 SULFATE ION × 4 EPE 4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；1.6 M potassium/sodium phosphate, pH 6.5
|
Resolution 3.15 Å R-free 0.243 |
| 7UKN Crystal Structure of DDB1 in Complex with the H-Box Motif of pUL145 Deposited 2022-04-01 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；277 K；100 mM MES (pH 6.5-6.7), 16% PEG 4000, 50 mM NaCl, 5 mM DTT
|
Resolution 2.90 Å R-free 0.261 |
| 7V7B CryoEM structure of DDB1-VprBP complex in ARM-up conformation Deposited 2021-08-21 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain B
1–1140（1140 aa）
Chain D
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.20 Å |
| 7V7C CryoEM structure of DDB1-VprBP-Vpr-UNG2(94-313) complex Deposited 2021-08-21 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 8 PDB declaration: octameric |
Chain B
1–1140（1140 aa）
Chain F
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.70 Å |
| 7ZN7 Cryo-EM structure of RCMV-E E27 bound to human DDB1 (deltaBPB) and rat STAT2 CCD Deposited 2022-04-20 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–396（396 aa）
Chain A
706–1140（435 aa）
|
Mutation：delta396-705 GNGNSG Mutation：delta396-705 GNGNSG | ZN ZINC ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.8
cryo-EM vitrification conditions
Cryogen ETHANE；45 seconds adsorption
2 seconds blot
|
Resolution 3.78 Å |
| 7ZNN Cryo-EM structure of RCMV-E E27 bound to human DDB1 (deltaBPB) and full-length rat STAT2 Deposited 2022-04-21 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–396（396 aa）
Chain A
706–1140（435 aa）
|
Mutation：Residues 396-705 have been replaced by a GNGNSG-linker Mutation：Residues 396-705 have been replaced by a GNGNSG-linker | ZN ZINC ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.8
cryo-EM vitrification conditions
Cryogen ETHANE；45 seconds adsorption
2 seconds blot
|
Resolution 4.80 Å |
| 8AJM Structure of human DDB1-DCAF12 in complex with the C-terminus of CCT5 Deposited 2022-07-28 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.83 Å |
| 8AJN Structure of the human DDB1-DCAF12 complex Deposited 2022-07-28 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.00 Å |
| 8AJO Negative-stain electron microscopy structure of DDB1-DCAF12-CCT5 Deposited 2022-07-28 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
|
Resolution 30.60 Å |
| 8B3D Structure of the Pol II-TCR-ELOF1 complex. Deposited 2022-09-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 17 PDB declaration: eicosameric |
Chain d
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 10 MG MAGNESIUM ION × 2 ADP ADENOSINE-5'-DIPHOSPHATE × 1 BEF BERYLLIUM TRIFLUORIDE ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.60 Å |
| 8B3F Pol II-CSB-CSA-DDB1-ELOF1 Deposited 2022-09-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 16 PDB declaration: nonadecameric |
Chain d
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 9 MG MAGNESIUM ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.10 Å |
| 8B3G C(N)RL4CSA-UVSSA-E2-ubiquitin complex. Deposited 2022-09-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 8 PDB declaration: octameric |
Chain d
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 3 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.40 Å |
| 8B3I CRL4CSA-E2-Ub (state 2) Deposited 2022-09-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 7 PDB declaration: heptameric |
Chain d
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 3 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.50 Å |
| 8BU1 Structure of DDB1 bound to DS17-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | GOL GLYCEROL × 5 RQL (2~{R})-2-[[6-[[5,6-bis(chloranyl)-1~{H}-benzimidazol-2-yl]methylamino]-9-(1-methylpyrazol-4-yl)purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M ammonium citrate tribasic pH 7.0, NDSB-256 additive
|
Resolution 2.98 Å R-free 0.218 |
| 8BU1 Structure of DDB1 bound to DS17-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | GOL GLYCEROL × 5 RQL (2~{R})-2-[[6-[[5,6-bis(chloranyl)-1~{H}-benzimidazol-2-yl]methylamino]-9-(1-methylpyrazol-4-yl)purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M ammonium citrate tribasic pH 7.0, NDSB-256 additive
|
Resolution 2.98 Å R-free 0.218 |
| 8BU1 Structure of DDB1 bound to DS17-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
709–1140（432 aa）
|
Not recorded | GOL GLYCEROL × 5 RQL (2~{R})-2-[[6-[[5,6-bis(chloranyl)-1~{H}-benzimidazol-2-yl]methylamino]-9-(1-methylpyrazol-4-yl)purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M ammonium citrate tribasic pH 7.0, NDSB-256 additive
|
Resolution 2.98 Å R-free 0.218 |
| 8BU2 Structure of DDB1 bound to DS18-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 12 RVQ ~{N}-[[5,6-bis(chloranyl)-1~{H}-benzimidazol-2-yl]methyl]-2-morpholin-4-yl-9-propan-2-yl-purin-6-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.30 M ammonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.13 Å R-free 0.217 |
| 8BU2 Structure of DDB1 bound to DS18-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 16 RVQ ~{N}-[[5,6-bis(chloranyl)-1~{H}-benzimidazol-2-yl]methyl]-2-morpholin-4-yl-9-propan-2-yl-purin-6-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.30 M ammonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.13 Å R-free 0.217 |
| 8BU2 Structure of DDB1 bound to DS18-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 13 RVQ ~{N}-[[5,6-bis(chloranyl)-1~{H}-benzimidazol-2-yl]methyl]-2-morpholin-4-yl-9-propan-2-yl-purin-6-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.30 M ammonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.13 Å R-free 0.217 |
| 8BU3 Structure of DDB1 bound to DS19-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 1 SO4 SULFATE ION × 6 RSI 2-morpholin-4-yl-9-propan-2-yl-~{N}-[(4-pyridin-2-ylphenyl)methyl]purin-6-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.49 M ammonium sulfate, ammonium citrate, 0.07 M HEPES pH 6.8
|
Resolution 3.42 Å R-free 0.213 |
| 8BU3 Structure of DDB1 bound to DS19-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
706–1140（435 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 1 SO4 SULFATE ION × 5 RSI 2-morpholin-4-yl-9-propan-2-yl-~{N}-[(4-pyridin-2-ylphenyl)methyl]purin-6-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.49 M ammonium sulfate, ammonium citrate, 0.07 M HEPES pH 6.8
|
Resolution 3.42 Å R-free 0.213 |
| 8BU3 Structure of DDB1 bound to DS19-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 9 RSI 2-morpholin-4-yl-9-propan-2-yl-~{N}-[(4-pyridin-2-ylphenyl)methyl]purin-6-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.49 M ammonium sulfate, ammonium citrate, 0.07 M HEPES pH 6.8
|
Resolution 3.42 Å R-free 0.213 |
| 8BU4 Structure of DDB1 bound to DS22-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 5 RQL (2~{R})-2-[[6-[[5,6-bis(chloranyl)-1~{H}-benzimidazol-2-yl]methylamino]-9-(1-methylpyrazol-4-yl)purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.07 M ammonium sulfate, 0.855 M ammonium citrate, 0.07 M HEPES pH 7
|
Resolution 3.09 Å R-free 0.223 |
| 8BU4 Structure of DDB1 bound to DS22-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 6 RQL (2~{R})-2-[[6-[[5,6-bis(chloranyl)-1~{H}-benzimidazol-2-yl]methylamino]-9-(1-methylpyrazol-4-yl)purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.07 M ammonium sulfate, 0.855 M ammonium citrate, 0.07 M HEPES pH 7
|
Resolution 3.09 Å R-free 0.223 |
| 8BU4 Structure of DDB1 bound to DS22-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 3 RQL (2~{R})-2-[[6-[[5,6-bis(chloranyl)-1~{H}-benzimidazol-2-yl]methylamino]-9-(1-methylpyrazol-4-yl)purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.07 M ammonium sulfate, 0.855 M ammonium citrate, 0.07 M HEPES pH 7
|
Resolution 3.09 Å R-free 0.223 |
| 8BU5 Structure of DDB1 bound to SR-4835-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 1 RMF ~{N}-[[5,6-bis(chloranyl)-1~{H}-benzimidazol-2-yl]methyl]-9-(1-methylpyrazol-4-yl)-2-morpholin-4-yl-purin-6-amine × 1 CIT CITRIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.28 M ammonium sulphate, 0.72 M ammonium citrate tribasic pH 7.0, 0.07 M HEPES pH 7.0
|
Resolution 3.13 Å R-free 0.220 |
| 8BU5 Structure of DDB1 bound to SR-4835-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
706–1140（435 aa）
|
Not recorded | RMF ~{N}-[[5,6-bis(chloranyl)-1~{H}-benzimidazol-2-yl]methyl]-9-(1-methylpyrazol-4-yl)-2-morpholin-4-yl-purin-6-amine × 1 CIT CITRIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.28 M ammonium sulphate, 0.72 M ammonium citrate tribasic pH 7.0, 0.07 M HEPES pH 7.0
|
Resolution 3.13 Å R-free 0.220 |
| 8BU5 Structure of DDB1 bound to SR-4835-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 2 RMF ~{N}-[[5,6-bis(chloranyl)-1~{H}-benzimidazol-2-yl]methyl]-9-(1-methylpyrazol-4-yl)-2-morpholin-4-yl-purin-6-amine × 1 CIT CITRIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.28 M ammonium sulphate, 0.72 M ammonium citrate tribasic pH 7.0, 0.07 M HEPES pH 7.0
|
Resolution 3.13 Å R-free 0.220 |
| 8BU6 Structure of DDB1 bound to DS55-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 2 RQE ~{N}-(1~{H}-benzimidazol-2-ylmethyl)-9-(1-methylpyrazol-4-yl)-2-morpholin-4-yl-purin-6-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.42 M ammonium sulphate, 0.07 M HEPES, pH 7.3
|
Resolution 3.45 Å R-free 0.249 |
| 8BU6 Structure of DDB1 bound to DS55-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 2 RQE ~{N}-(1~{H}-benzimidazol-2-ylmethyl)-9-(1-methylpyrazol-4-yl)-2-morpholin-4-yl-purin-6-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.42 M ammonium sulphate, 0.07 M HEPES, pH 7.3
|
Resolution 3.45 Å R-free 0.249 |
| 8BU6 Structure of DDB1 bound to DS55-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 2 RQE ~{N}-(1~{H}-benzimidazol-2-ylmethyl)-9-(1-methylpyrazol-4-yl)-2-morpholin-4-yl-purin-6-amine × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.42 M ammonium sulphate, 0.07 M HEPES, pH 7.3
|
Resolution 3.45 Å R-free 0.249 |
| 8BU7 Structure of DDB1 bound to 21195-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 1 RS5 1-[2,6-bis(chloranyl)phenyl]-6-[[4-(2-hydroxyethyloxy)phenyl]methyl]-3-propan-2-yl-5H-pyrazolo[3,4-d]pyrimidin-4-one × 1 SO4 SULFATE ION × 10 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.33 M ammonium sulfate, 0.045 M ammonium citrate, 0.07M HEPES pH 7
|
Resolution 3.25 Å R-free 0.219 |
| 8BU7 Structure of DDB1 bound to 21195-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
706–1140（435 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 2 RS5 1-[2,6-bis(chloranyl)phenyl]-6-[[4-(2-hydroxyethyloxy)phenyl]methyl]-3-propan-2-yl-5H-pyrazolo[3,4-d]pyrimidin-4-one × 1 SO4 SULFATE ION × 10 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.33 M ammonium sulfate, 0.045 M ammonium citrate, 0.07M HEPES pH 7
|
Resolution 3.25 Å R-free 0.219 |
| 8BU7 Structure of DDB1 bound to 21195-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
706–1140（435 aa）
|
Not recorded | RS5 1-[2,6-bis(chloranyl)phenyl]-6-[[4-(2-hydroxyethyloxy)phenyl]methyl]-3-propan-2-yl-5H-pyrazolo[3,4-d]pyrimidin-4-one × 1 SO4 SULFATE ION × 11 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.33 M ammonium sulfate, 0.045 M ammonium citrate, 0.07M HEPES pH 7
|
Resolution 3.25 Å R-free 0.219 |
| 8BU9 Structure of DDB1 bound to roscovitine-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 5 RRC R-ROSCOVITINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.42 M ammonium sulphate, 0.63 M ammonium citrate tribasic pH 7.0, 0.07 M HEPES pH 7.0
|
Resolution 3.51 Å R-free 0.223 |
| 8BU9 Structure of DDB1 bound to roscovitine-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 5 RRC R-ROSCOVITINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.42 M ammonium sulphate, 0.63 M ammonium citrate tribasic pH 7.0, 0.07 M HEPES pH 7.0
|
Resolution 3.51 Å R-free 0.223 |
| 8BU9 Structure of DDB1 bound to roscovitine-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 5 RRC R-ROSCOVITINE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.42 M ammonium sulphate, 0.63 M ammonium citrate tribasic pH 7.0, 0.07 M HEPES pH 7.0
|
Resolution 3.51 Å R-free 0.223 |
| 8BUA Structure of DDB1 bound to 919278-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | CIT CITRIC ACID × 2 RVH (2~{R})-~{N}-(1~{H}-benzimidazol-2-yl)-2-(3-oxidanylidene-1~{H}-isoindol-2-yl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M ammonium citrate, 100 %w/v SB38D2, 0.07 M HEPES pH 7
|
Resolution 3.19 Å R-free 0.225 |
| 8BUA Structure of DDB1 bound to 919278-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
706–1140（435 aa）
|
Not recorded | CIT CITRIC ACID × 3 RVH (2~{R})-~{N}-(1~{H}-benzimidazol-2-yl)-2-(3-oxidanylidene-1~{H}-isoindol-2-yl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M ammonium citrate, 100 %w/v SB38D2, 0.07 M HEPES pH 7
|
Resolution 3.19 Å R-free 0.225 |
| 8BUA Structure of DDB1 bound to 919278-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
706–1140（435 aa）
|
Not recorded | CIT CITRIC ACID × 4 RVH (2~{R})-~{N}-(1~{H}-benzimidazol-2-yl)-2-(3-oxidanylidene-1~{H}-isoindol-2-yl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M ammonium citrate, 100 %w/v SB38D2, 0.07 M HEPES pH 7
|
Resolution 3.19 Å R-free 0.225 |
| 8BUC Structure of DDB1 bound to dCeMM3-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 4 RKO 2-(1~{H}-benzimidazol-2-ylsulfanyl)-~{N}-(5-chloranylpyridin-2-yl)ethanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.07 M ammonium sulfate, 0.855 ammonium citrate, 0.07 M HEPES pH 7
|
Resolution 3.85 Å R-free 0.224 |
| 8BUC Structure of DDB1 bound to dCeMM3-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 1 RKO 2-(1~{H}-benzimidazol-2-ylsulfanyl)-~{N}-(5-chloranylpyridin-2-yl)ethanamide × 1 CIT CITRIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.07 M ammonium sulfate, 0.855 ammonium citrate, 0.07 M HEPES pH 7
|
Resolution 3.85 Å R-free 0.224 |
| 8BUC Structure of DDB1 bound to dCeMM3-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 4 RKO 2-(1~{H}-benzimidazol-2-ylsulfanyl)-~{N}-(5-chloranylpyridin-2-yl)ethanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.07 M ammonium sulfate, 0.855 ammonium citrate, 0.07 M HEPES pH 7
|
Resolution 3.85 Å R-free 0.224 |
| 8BUD Structure of DDB1 bound to Z7-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 10 RP9 ~{N}-(5-bromanylpyridin-2-yl)-3-(4-oxidanylidenequinazolin-3-yl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.50 M ammonium sulphate, 0.07 M HEPES, pH 7.0
|
Resolution 3.20 Å R-free 0.220 |
| 8BUD Structure of DDB1 bound to Z7-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 15 RP9 ~{N}-(5-bromanylpyridin-2-yl)-3-(4-oxidanylidenequinazolin-3-yl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.50 M ammonium sulphate, 0.07 M HEPES, pH 7.0
|
Resolution 3.20 Å R-free 0.220 |
| 8BUD Structure of DDB1 bound to Z7-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 14 RP9 ~{N}-(5-bromanylpyridin-2-yl)-3-(4-oxidanylidenequinazolin-3-yl)propanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.50 M ammonium sulphate, 0.07 M HEPES, pH 7.0
|
Resolution 3.20 Å R-free 0.220 |
| 8BUE Structure of DDB1 bound to Z11-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 12 RVU ~{N}-(1~{H}-benzimidazol-2-yl)-1-(2-methoxy-5-methyl-phenyl)-5-oxidanylidene-pyrrolidine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.45 M ammonium sulphate, 0.07 M HEPES, pH 7.1
|
Resolution 3.25 Å R-free 0.213 |
| 8BUE Structure of DDB1 bound to Z11-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 16 RVU ~{N}-(1~{H}-benzimidazol-2-yl)-1-(2-methoxy-5-methyl-phenyl)-5-oxidanylidene-pyrrolidine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.45 M ammonium sulphate, 0.07 M HEPES, pH 7.1
|
Resolution 3.25 Å R-free 0.213 |
| 8BUE Structure of DDB1 bound to Z11-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 15 RVU ~{N}-(1~{H}-benzimidazol-2-yl)-1-(2-methoxy-5-methyl-phenyl)-5-oxidanylidene-pyrrolidine-3-carboxamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.45 M ammonium sulphate, 0.07 M HEPES, pH 7.1
|
Resolution 3.25 Å R-free 0.213 |
| 8BUF Structure of DDB1 bound to Z12-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 12 RW6 2-(6,7-dihydro-4~{H}-thieno[3,2-c]pyridin-5-ylmethyl)-6,7-dimethoxy-3~{H}-quinazolin-4-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.47 M amonium sulphate, 0.07 M HEPES, pH 7.0
|
Resolution 3.30 Å R-free 0.220 |
| 8BUF Structure of DDB1 bound to Z12-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 17 RW6 2-(6,7-dihydro-4~{H}-thieno[3,2-c]pyridin-5-ylmethyl)-6,7-dimethoxy-3~{H}-quinazolin-4-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.47 M amonium sulphate, 0.07 M HEPES, pH 7.0
|
Resolution 3.30 Å R-free 0.220 |
| 8BUF Structure of DDB1 bound to Z12-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 17 RW6 2-(6,7-dihydro-4~{H}-thieno[3,2-c]pyridin-5-ylmethyl)-6,7-dimethoxy-3~{H}-quinazolin-4-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.47 M amonium sulphate, 0.07 M HEPES, pH 7.0
|
Resolution 3.30 Å R-free 0.220 |
| 8BUG Structure of DDB1 bound to HQ461-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | CIT CITRIC ACID × 2 RPW 2-[2-[(6-methylpyridin-2-yl)amino]-1,3-thiazol-4-yl]-~{N}-(5-methyl-1,3-thiazol-2-yl)ethanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M ammonium citrate tribasic pH 7.0, 0.1 M TMA additive
|
Resolution 3.53 Å R-free 0.231 |
| 8BUG Structure of DDB1 bound to HQ461-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | CIT CITRIC ACID × 2 RPW 2-[2-[(6-methylpyridin-2-yl)amino]-1,3-thiazol-4-yl]-~{N}-(5-methyl-1,3-thiazol-2-yl)ethanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M ammonium citrate tribasic pH 7.0, 0.1 M TMA additive
|
Resolution 3.53 Å R-free 0.231 |
| 8BUG Structure of DDB1 bound to HQ461-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
709–1140（432 aa）
|
Not recorded | CIT CITRIC ACID × 3 RPW 2-[2-[(6-methylpyridin-2-yl)amino]-1,3-thiazol-4-yl]-~{N}-(5-methyl-1,3-thiazol-2-yl)ethanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M ammonium citrate tribasic pH 7.0, 0.1 M TMA additive
|
Resolution 3.53 Å R-free 0.231 |
| 8BUH Structure of DDB1 bound to WX3-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 5 RR9 6-[[[2-[[(2~{R})-1-oxidanylbutan-2-yl]amino]-9-propan-2-yl-purin-6-yl]amino]methyl]-3-pyridin-2-yl-1~{H}-pyridin-2-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.7 M ammonium sulfate, 0.45 M ammonium citrate, 0.07 M HEPES pH 7
|
Resolution 3.79 Å R-free 0.232 |
| 8BUH Structure of DDB1 bound to WX3-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 3 RR9 6-[[[2-[[(2~{R})-1-oxidanylbutan-2-yl]amino]-9-propan-2-yl-purin-6-yl]amino]methyl]-3-pyridin-2-yl-1~{H}-pyridin-2-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.7 M ammonium sulfate, 0.45 M ammonium citrate, 0.07 M HEPES pH 7
|
Resolution 3.79 Å R-free 0.232 |
| 8BUH Structure of DDB1 bound to WX3-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 4 RR9 6-[[[2-[[(2~{R})-1-oxidanylbutan-2-yl]amino]-9-propan-2-yl-purin-6-yl]amino]methyl]-3-pyridin-2-yl-1~{H}-pyridin-2-one × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.7 M ammonium sulfate, 0.45 M ammonium citrate, 0.07 M HEPES pH 7
|
Resolution 3.79 Å R-free 0.232 |
| 8BUI Structure of DDB1 bound to DRF-053-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 1 SO4 SULFATE ION × 7 RV6 (2~{R})-2-[[9-propan-2-yl-6-[(4-pyridin-2-ylphenyl)amino]purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.42 M ammonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.50 Å R-free 0.221 |
| 8BUI Structure of DDB1 bound to DRF-053-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 7 RV6 (2~{R})-2-[[9-propan-2-yl-6-[(4-pyridin-2-ylphenyl)amino]purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.42 M ammonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.50 Å R-free 0.221 |
| 8BUI Structure of DDB1 bound to DRF-053-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 7 RV6 (2~{R})-2-[[9-propan-2-yl-6-[(4-pyridin-2-ylphenyl)amino]purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.42 M ammonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.50 Å R-free 0.221 |
| 8BUJ Structure of DDB1 bound to DS06-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 5 RUW (2~{R})-2-[[6-(octylamino)-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.38 M ammonium sulphate, 0.07 M HEPES, pH 7.0
|
Resolution 3.62 Å R-free 0.206 |
| 8BUJ Structure of DDB1 bound to DS06-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 4 RUW (2~{R})-2-[[6-(octylamino)-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.38 M ammonium sulphate, 0.07 M HEPES, pH 7.0
|
Resolution 3.62 Å R-free 0.206 |
| 8BUJ Structure of DDB1 bound to DS06-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 5 RUW (2~{R})-2-[[6-(octylamino)-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.38 M ammonium sulphate, 0.07 M HEPES, pH 7.0
|
Resolution 3.62 Å R-free 0.206 |
| 8BUK Structure of DDB1 bound to DS08-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 7 RWE (2~{R})-2-[[6-(naphthalen-2-ylmethylamino)-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.84 M ammonium sulfate, 0.36 M ammonium citrate, 0.07 M HEPES pH 7
|
Resolution 3.41 Å R-free 0.210 |
| 8BUK Structure of DDB1 bound to DS08-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 6 RWE (2~{R})-2-[[6-(naphthalen-2-ylmethylamino)-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 CIT CITRIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.84 M ammonium sulfate, 0.36 M ammonium citrate, 0.07 M HEPES pH 7
|
Resolution 3.41 Å R-free 0.210 |
| 8BUK Structure of DDB1 bound to DS08-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 7 RWE (2~{R})-2-[[6-(naphthalen-2-ylmethylamino)-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.84 M ammonium sulfate, 0.36 M ammonium citrate, 0.07 M HEPES pH 7
|
Resolution 3.41 Å R-free 0.210 |
| 8BUL Structure of DDB1 bound to DS11-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 1 SO4 SULFATE ION × 8 RSU (2~{R})-2-[[6-(3-phenylpropylamino)-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.30 M amonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.40 Å R-free 0.215 |
| 8BUL Structure of DDB1 bound to DS11-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
706–1140（435 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 1 SO4 SULFATE ION × 8 RSU (2~{R})-2-[[6-(3-phenylpropylamino)-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.30 M amonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.40 Å R-free 0.215 |
| 8BUL Structure of DDB1 bound to DS11-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 9 RSU (2~{R})-2-[[6-(3-phenylpropylamino)-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.30 M amonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.40 Å R-free 0.215 |
| 8BUM Structure of DDB1 bound to DS15-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 11 T6X (2R)-2-[[6-(5-naphthalen-1-ylpentylamino)-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.50 M amonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.36 Å R-free 0.212 |
| 8BUM Structure of DDB1 bound to DS15-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 15 T6X (2R)-2-[[6-(5-naphthalen-1-ylpentylamino)-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.50 M amonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.36 Å R-free 0.212 |
| 8BUM Structure of DDB1 bound to DS15-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 13 T6X (2R)-2-[[6-(5-naphthalen-1-ylpentylamino)-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.50 M amonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.36 Å R-free 0.212 |
| 8BUN Structure of DDB1 bound to DS16-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 10 RNF (2~{R})-2-[[6-[(4-phenylphenyl)methylamino]-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.40 M ammonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.08 Å R-free 0.211 |
| 8BUN Structure of DDB1 bound to DS16-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 12 RNF (2~{R})-2-[[6-[(4-phenylphenyl)methylamino]-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.40 M ammonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.08 Å R-free 0.211 |
| 8BUN Structure of DDB1 bound to DS16-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 12 RNF (2~{R})-2-[[6-[(4-phenylphenyl)methylamino]-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.40 M ammonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.08 Å R-free 0.211 |
| 8BUO Structure of DDB1 bound to DS24-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 9 RLC (2~{R})-2-[[6-[(3-fluoranyl-4-pyridin-2-yl-phenyl)methylamino]-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.47 M ammonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.58 Å R-free 0.219 |
| 8BUO Structure of DDB1 bound to DS24-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Insufficient information Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 7 RLC (2~{R})-2-[[6-[(3-fluoranyl-4-pyridin-2-yl-phenyl)methylamino]-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.47 M ammonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.58 Å R-free 0.219 |
| 8BUO Structure of DDB1 bound to DS24-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Insufficient information Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 10 RLC (2~{R})-2-[[6-[(3-fluoranyl-4-pyridin-2-yl-phenyl)methylamino]-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.47 M ammonium sulphate, 0.07 M HEPES, pH 6.8
|
Resolution 3.58 Å R-free 0.219 |
| 8BUP Structure of DDB1 bound to DS30-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 11 RWN (2~{R})-2-[[6-[3-(3-methylphenyl)propylamino]-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.44 M ammonium sulphate, 2.143 %v/v PEG 200, 0.07 M HEPES pH 7.5
|
Resolution 3.41 Å R-free 0.223 |
| 8BUP Structure of DDB1 bound to DS30-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 22 RWN (2~{R})-2-[[6-[3-(3-methylphenyl)propylamino]-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.44 M ammonium sulphate, 2.143 %v/v PEG 200, 0.07 M HEPES pH 7.5
|
Resolution 3.41 Å R-free 0.223 |
| 8BUP Structure of DDB1 bound to DS30-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 24 RWN (2~{R})-2-[[6-[3-(3-methylphenyl)propylamino]-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.44 M ammonium sulphate, 2.143 %v/v PEG 200, 0.07 M HEPES pH 7.5
|
Resolution 3.41 Å R-free 0.223 |
| 8BUQ Structure of DDB1 bound to DS43-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | CIT CITRIC ACID × 2 RQ9 (2~{R})-2-[[6-[[1-(3-chlorophenyl)pyrazol-3-yl]methylamino]-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M ammonium citrate tribasic pH 7.0, Jeff600 additive
|
Resolution 3.20 Å R-free 0.216 |
| 8BUQ Structure of DDB1 bound to DS43-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | CIT CITRIC ACID × 2 RQ9 (2~{R})-2-[[6-[[1-(3-chlorophenyl)pyrazol-3-yl]methylamino]-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M ammonium citrate tribasic pH 7.0, Jeff600 additive
|
Resolution 3.20 Å R-free 0.216 |
| 8BUQ Structure of DDB1 bound to DS43-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
709–1140（432 aa）
|
Not recorded | CIT CITRIC ACID × 2 RQ9 (2~{R})-2-[[6-[[1-(3-chlorophenyl)pyrazol-3-yl]methylamino]-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.9 M ammonium citrate tribasic pH 7.0, Jeff600 additive
|
Resolution 3.20 Å R-free 0.216 |
| 8BUR Structure of DDB1 bound to DS50-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 7 RQU ~{N}-[2-(2-methoxyphenyl)ethyl]-2-[[9-propan-2-yl-6-[(4-pyridin-2-ylphenyl)methylamino]purin-2-yl]amino]ethanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.42 M ammonium sulphate, 0.07 M HEPES, pH 7.0
|
Resolution 3.64 Å R-free 0.234 |
| 8BUR Structure of DDB1 bound to DS50-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 10 RQU ~{N}-[2-(2-methoxyphenyl)ethyl]-2-[[9-propan-2-yl-6-[(4-pyridin-2-ylphenyl)methylamino]purin-2-yl]amino]ethanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.42 M ammonium sulphate, 0.07 M HEPES, pH 7.0
|
Resolution 3.64 Å R-free 0.234 |
| 8BUR Structure of DDB1 bound to DS50-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 7 RQU ~{N}-[2-(2-methoxyphenyl)ethyl]-2-[[9-propan-2-yl-6-[(4-pyridin-2-ylphenyl)methylamino]purin-2-yl]amino]ethanamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.42 M ammonium sulphate, 0.07 M HEPES, pH 7.0
|
Resolution 3.64 Å R-free 0.234 |
| 8BUS Structure of DDB1 bound to DS59-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 5 RMX 1,3-dimethyl-5-[[[9-propan-2-yl-6-[(4-pyridin-2-ylphenyl)methylamino]purin-2-yl]amino]methyl]pyrazole-4-sulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.40 M ammonium sulphate, 0.07 M HEPES, pH 7.0
|
Resolution 3.26 Å R-free 0.228 |
| 8BUS Structure of DDB1 bound to DS59-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 3 RMX 1,3-dimethyl-5-[[[9-propan-2-yl-6-[(4-pyridin-2-ylphenyl)methylamino]purin-2-yl]amino]methyl]pyrazole-4-sulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.40 M ammonium sulphate, 0.07 M HEPES, pH 7.0
|
Resolution 3.26 Å R-free 0.228 |
| 8BUS Structure of DDB1 bound to DS59-engaged CDK12-cyclin K Deposited 2022-11-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
706–1140（435 aa）
|
Not recorded | SO4 SULFATE ION × 6 RMX 1,3-dimethyl-5-[[[9-propan-2-yl-6-[(4-pyridin-2-ylphenyl)methylamino]purin-2-yl]amino]methyl]pyrazole-4-sulfonamide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.40 M ammonium sulphate, 0.07 M HEPES, pH 7.0
|
Resolution 3.26 Å R-free 0.228 |
| 8BUT Structure of DDB1 bound to DS61-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 7 RQ5 2-[[6-[[4-(2-hydroxyethyloxy)phenyl]methylamino]-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.374 M ammonium sulfate, 0.07 M HEPES pH 7.3
|
Resolution 3.25 Å R-free 0.217 |
| 8BUT Structure of DDB1 bound to DS61-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 6 RQ5 2-[[6-[[4-(2-hydroxyethyloxy)phenyl]methylamino]-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.374 M ammonium sulfate, 0.07 M HEPES pH 7.3
|
Resolution 3.25 Å R-free 0.217 |
| 8BUT Structure of DDB1 bound to DS61-engaged CDK12-cyclin K Deposited 2022-11-30 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Chain G
709–1140（432 aa）
|
Not recorded | SO4 SULFATE ION × 8 RQ5 2-[[6-[[4-(2-hydroxyethyloxy)phenyl]methylamino]-9-propan-2-yl-purin-2-yl]amino]butan-1-ol × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.374 M ammonium sulfate, 0.07 M HEPES pH 7.3
|
Resolution 3.25 Å R-free 0.217 |
| 8CVP Cereblon-DDB1 in the Apo form Deposited 2022-05-18 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7；20mM HEPES pH 7.0, 240mM NaCl, 3mM TCEP
cryo-EM vitrification conditions
Cryogen ETHANE；Manual plunge in 4? coldroom
|
Resolution 3.40 Å |
| 8D7U Cereblon~DDB1 bound to CC-92480 with DDB1 in the linear conformation Deposited 2022-06-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 QFC Mezigdomide × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7；20mM HEPES pH 7.0, 240mM NaCl, 3mM TCEP
cryo-EM vitrification conditions
Cryogen ETHANE；Manual plunge in 4 degree C cold room
|
Resolution 3.10 Å |
| 8D7V Cereblon~DDB1 bound to CC-92480 with DDB1 in the twisted conformation Deposited 2022-06-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 QFC Mezigdomide × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7；20mM HEPES pH 7.0, 240mM NaCl, 3mM TCEP
cryo-EM vitrification conditions
Cryogen ETHANE；Manual plunge in 4 degree C cold room
|
Resolution 3.20 Å |
| 8D7W Cereblon~DDB1 bound to CC-92480 with DDB1 in the hinged conformation Deposited 2022-06-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 QFC Mezigdomide × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7；20mM HEPES pH 7.0, 240mM NaCl, 3mM TCEP
cryo-EM vitrification conditions
Cryogen ETHANE；Manual plunge in 4 degree C cold room
|
Resolution 3.10 Å |
| 8D7X Cereblon~DDB1 in the Apo form with DDB1 in the hinged conformation Deposited 2022-06-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7；20mM HEPES pH 7, 240mM NaCl, 3mM TCEP
cryo-EM vitrification conditions
Cryogen ETHANE；Manual plunge in 4 degree C cold room
|
Resolution 3.40 Å |
| 8D7Y Cereblon-DDB1 in the Apo form with DDB1 in the twisted conformation Deposited 2022-06-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7；20mM HEPES pH 7.0, 240mM NaCl, 3mM TCEP
cryo-EM vitrification conditions
Cryogen ETHANE；Manual plunge in 4 degree C cold room
|
Resolution 3.40 Å |
| 8D7Z Cereblon-DDB1 bound to CC-92480 and Ikaros ZF1-2-3 Deposited 2022-06-07 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 2 QFC Mezigdomide × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7；20mM HEPES pH 7.0, 240mM NaCl, 3mM TCEP
cryo-EM vitrification conditions
Cryogen ETHANE；Manual plunge in 4 degree C cold room
|
Resolution 3.10 Å |
| 8D80 Cereblon~DDB1 bound to Iberdomide and Ikaros ZF1-2-3 Deposited 2022-06-07 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 2 8W7 (3S)-3-[4-({4-[(morpholin-4-yl)methyl]phenyl}methoxy)-1-oxo-1,3-dihydro-2H-isoindol-2-yl]piperidine-2,6-dione × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7；20mM HEPES pH 7.0, 240mM NaCl, 3mM TCEP
cryo-EM vitrification conditions
Cryogen ETHANE；Manual plunge in 4 degree C cold room
|
Resolution 3.60 Å |
| 8D81 Cereblon~DDB1 bound to Pomalidomide Deposited 2022-06-07 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–395（395 aa）
Fragment：residues 396 through 706 deleted, substituted with GNGNSG,residues 396 through 706 deleted, substituted with GNGNSG
Chain A
706–1140（435 aa）
Fragment：residues 396 through 706 deleted, substituted with GNGNSG,residues 396 through 706 deleted, substituted with GNGNSG
|
Not recorded | ZN ZINC ION × 1 Y70 S-Pomalidomide × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7；20mM HEPES pH 7, 240mM NaCl, 3mM TCEP
cryo-EM vitrification conditions
Cryogen ETHANE；Manual plunge in 4 degree C cold room
|
Resolution 3.90 Å |
| 8DEY Ternary complex structure of Cereblon-DDB1 bound to IKZF2(ZF2,3) and the molecular glue DKY709 Deposited 2022-06-21 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
1–395（395 aa）
Fragment：UNP residues 1-395,706-1140,UNP residues 1-395,706-1140
Chain B
706–1140（435 aa）
Fragment：UNP residues 1-395,706-1140,UNP residues 1-395,706-1140
|
Not recorded | ZN ZINC ION × 3 LWK (3S)-3-[5-(1-benzylpiperidin-4-yl)-1-oxo-1,3-dihydro-2H-isoindol-2-yl]piperidine-2,6-dione × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；1.6 M potassium/sodium phosphate, pH 6.5
|
Resolution 3.70 Å R-free 0.348 |
| 8DEY Ternary complex structure of Cereblon-DDB1 bound to IKZF2(ZF2,3) and the molecular glue DKY709 Deposited 2022-06-21 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain E
1–395（395 aa）
Fragment：UNP residues 1-395,706-1140,UNP residues 1-395,706-1140
Chain E
706–1140（435 aa）
Fragment：UNP residues 1-395,706-1140,UNP residues 1-395,706-1140
|
Not recorded | ZN ZINC ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；1.6 M potassium/sodium phosphate, pH 6.5
|
Resolution 3.70 Å R-free 0.348 |
| 8G46 Cryo-EM structure of DDB1deltaB-DDA1-DCAF16-BRD4(BD2)-MMH2 Deposited 2023-02-08 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–395（395 aa）
Fragment：UNP residues 1-395 + GNGNSG linker + UNP residues 706-1140
Chain A
706–1140（435 aa）
Fragment：UNP residues 1-395 + GNGNSG linker + UNP residues 706-1140
|
Not recorded | ZN ZINC ION × 1 YK3 tert-butyl [(6S,10P)-4-{4-[(ethanesulfonyl)amino]phenyl}-2,3,9-trimethyl-6H-thieno[3,2-f][1,2,4]triazolo[4,3-a][1,4]diazepin-6-yl]acetate × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4；50 mM HEPES pH 7.4, 200 mM NaCl, 2 mM TCEP, 0.011% LMNG
cryo-EM vitrification conditions
Cryogen ETHANE；detergent added directly before grid application
|
Resolution 2.20 Å |
| 8G66 Structure with SJ3149 Deposited 2023-02-14 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 1 YOT (3S)-3-{5-[(1,2-benzoxazol-3-yl)amino]-1-oxo-1,3-dihydro-2H-isoindol-2-yl}piperidine-2,6-dione × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293.15 K；70 MM TRIS PH 7.0, 140 MM MGCL2, 7% W/V
PEG 8000
|
Resolution 3.45 Å R-free 0.272 |
| 8G66 Structure with SJ3149 Deposited 2023-02-14 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–395（395 aa）
Chain D
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293.15 K；70 MM TRIS PH 7.0, 140 MM MGCL2, 7% W/V
PEG 8000
|
Resolution 3.45 Å R-free 0.272 |
| 8OIZ Crystal structure of human CRBN-DDB1 in complex with Pomalidomide Deposited 2023-03-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 6 ZN ZINC ION × 1 Y70 S-Pomalidomide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.2；291 K；0.8 microliter of CRBN-DDB1 complex at 25 mg/mL (including 1 mM compound and 2 % DMSO final) plus 0.8 microliter of a crystallisation solution consisting of 0.1 M Hepes pH 8.2, 0.2 M NaCl and 10-16 % PEG Smear Medium, plus 0.2 microliter of seeds (established from the same conditions), against 500 microliter of crystallisation solution.
|
Resolution 2.50 Å R-free 0.262 |
| 8OJH Crystal structure of human CRBN-DDB1 in complex with compound 4 Deposited 2023-03-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 9 ZN ZINC ION × 1 VP9 4-azanyl-2-[(3~{S})-2,6-bis(oxidanylidene)piperidin-3-yl]-7-methoxy-isoindole-1,3-dione × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.2；291 K；0.8 microliter of CRBN-DDB1 complex at 25 mg/mL (including 1 mM compound and 2 % DMSO final) plus 0.8 microliter of a crystallisation solution consisting of 0.1 M Hepes pH 8.2, 0.2 M NaCl and 10-16 % PEG Smear Medium, plus 0.2 microliter of seeds (established from the same conditions), against 500 microliter of crystallisation solution.
|
Resolution 2.72 Å R-free 0.254 |
| 8QH5 CryoEM structure of UVSSA(VHS)-CSA-DDB1-DDA1 Deposited 2023-09-06 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain B
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.40 Å |
| 8ROX Structure of the human DDB1-DDA1-DCAF15 E3 ubiquitin ligase bound to compound furan 12 Deposited 2024-01-12 | Different construct Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
1–395（395 aa）
Chain B
706–1140（435 aa）
|
Not recorded | A1H17 5-[[3,4-bis(chloranyl)-1~{H}-indol-7-yl]sulfamoyl]-~{N},~{N},3-trimethyl-furan-2-carboxamide;ethane × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.30 Å |
| 8ROY Structure of the human DDB1-DDA1-DCAF15 E3 ubiquitin ligase bound to compound furan 24 Deposited 2024-01-12 | Different construct Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
1–395（395 aa）
Chain B
706–1140（435 aa）
|
Not recorded | A1H18 1-[5-[[3,4-bis(chloranyl)-1~{H}-indol-7-yl]sulfamoyl]-3-methyl-furan-2-yl]carbonyl-~{N}-methyl-piperidine-4-carboxamide × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.10 Å |
| 8T9A CryoEM structure of human DDB1-DCAF12 in complex with MAGEA3 Deposited 2023-06-23 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.17 Å |
| 8TL6 Cryo-EM structure of DDB1deltaB-DDA1-DCAF5 Deposited 2023-07-26 | Different construct Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5；25mM HEPES, pH 7.4, 200mM NaCl, 4mM TCEP
cryo-EM vitrification conditions
Cryogen NITROGEN
|
Resolution 2.63 Å |
| 8TNP Cryo-EM structure of DDB1dB:CRBN:Pomalidomide:SD40 Deposited 2023-08-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Mutation：residues 396-705 deleted Mutation：residues 396-705 deleted | ZN ZINC ION × 2 Y70 S-Pomalidomide × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7；20 mM HEPES/NaOH pH 7.0, 150 mM NaCl, and 3 mM TCEP. DMSO concentrations were kept below 2% (v/v)
cryo-EM vitrification conditions
Cryogen ETHANE；Leica EM-GP plunge freezer with chamber conditions of 10 C and 90% relative humidity. Grids were first pre-incubated with 4 uL of 10 uM CRBN-agnostic IKZF1_140-196_Q146A,G151N for 1 minute and then blotted from behind for 4 s. Immediately, 4 uL of mixture 1 diluted 10-fold--with the dilution buffer during the 1-minute incubation time--was applied to the grids before blotting for 4 s and plunging into liquid ethane at -181 C.
|
Resolution 3.30 Å |
| 8TNQ Cryo-EM structure of DDB1dB:CRBN:PT-179:SD40, conformation 1 Deposited 2023-08-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Mutation：residues 396-705 deleted Mutation：residues 396-705 deleted | ZN ZINC ION × 2 MIQ 2-[(3S)-2,6-dioxopiperidin-3-yl]-5-(morpholin-4-yl)-1H-isoindole-1,3(2H)-dione × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7；20 mM HEPES/NaOH pH 7.0, 150 mM NaCl, and 3 mM TCEP. DMSO concentrations were kept below 2% (v/v)
cryo-EM vitrification conditions
Cryogen ETHANE；Leica EM-GP plunge freezer with chamber conditions of 10 C and 90% relative humidity. Grids were first pre-incubated with 4 uL of 10 uM CRBN-agnostic IKZF1_140-196_Q146A,G151N for 1 minute and then blotted from behind for 4 s. Immediately, 4 uL of mixture 1 diluted 10-fold--with the dilution buffer during the 1-minute incubation time--was applied to the grids before blotting for 4 s and plunging into liquid ethane at -181 C.
|
Resolution 2.41 Å |
| 8TNR Cryo-EM structure of DDB1dB:CRBN:PT-179:SD40, conformation 2 Deposited 2023-08-02 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Mutation：residues 396-705 deleted Mutation：residues 396-705 deleted | ZN ZINC ION × 2 MIQ 2-[(3S)-2,6-dioxopiperidin-3-yl]-5-(morpholin-4-yl)-1H-isoindole-1,3(2H)-dione × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7；20 mM HEPES/NaOH pH 7.0, 150 mM NaCl, and 3 mM TCEP. DMSO concentrations were kept below 2% (v/v)
cryo-EM vitrification conditions
Cryogen ETHANE；Leica EM-GP plunge freezer with chamber conditions of 10 C and 90% relative humidity. Grids were first pre-incubated with 4 uL of 10 uM CRBN-agnostic IKZF1_140-196_Q146A,G151N for 1 minute and then blotted from behind for 4 s. Immediately, 4 uL of mixture 1 diluted 10-fold--with the dilution buffer during the 1-minute incubation time--was applied to the grids before blotting for 4 s and plunging into liquid ethane at -181 C.
|
Resolution 2.50 Å |
| 8TZX Ternary complex structure of Cereblon-DDB1 bound to WIZ(ZF7) and the molecular glue dWIZ-1 Deposited 2023-08-28 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
1–395（395 aa）
Fragment：UNP residues 1-395,706-1140,UNP residues 1-395,706-1140
Chain B
706–1140（435 aa）
Fragment：UNP residues 1-395,706-1140,UNP residues 1-395,706-1140
|
Not recorded | ZN ZINC ION × 2 U3I (3S)-3-(5-{(1R)-1-[(2R)-1-ethylpiperidin-2-yl]ethoxy}-1-oxo-1,3-dihydro-2H-isoindol-2-yl)piperidine-2,6-dione × 1 SO4 SULFATE ION × 2 EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；0.2 M Sodium Sulfate, 0.1 M Bis-Tris Propane pH 7.5, 20% w/v PEG 3350
|
Resolution 3.15 Å R-free 0.252 |
| 8TZX Ternary complex structure of Cereblon-DDB1 bound to WIZ(ZF7) and the molecular glue dWIZ-1 Deposited 2023-08-28 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain E
1–395（395 aa）
Fragment：UNP residues 1-395,706-1140,UNP residues 1-395,706-1140
Chain E
706–1140（435 aa）
Fragment：UNP residues 1-395,706-1140,UNP residues 1-395,706-1140
|
Not recorded | ZN ZINC ION × 2 U3I (3S)-3-(5-{(1R)-1-[(2R)-1-ethylpiperidin-2-yl]ethoxy}-1-oxo-1,3-dihydro-2H-isoindol-2-yl)piperidine-2,6-dione × 1 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；0.2 M Sodium Sulfate, 0.1 M Bis-Tris Propane pH 7.5, 20% w/v PEG 3350
|
Resolution 3.15 Å R-free 0.252 |
| 8U16 The ternary complex structure of DDB1-CRBN-SALL4(ZF1,2)-short bound to Pomalidomide Deposited 2023-08-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
1–395（395 aa）
Chain B
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 3 Y70 S-Pomalidomide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2M Sodium malonate, 20% PEG 3350
|
Resolution 2.90 Å R-free 0.273 |
| 8U16 The ternary complex structure of DDB1-CRBN-SALL4(ZF1,2)-short bound to Pomalidomide Deposited 2023-08-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain E
1–395（395 aa）
Chain E
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 3 Y70 S-Pomalidomide × 1 EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2M Sodium malonate, 20% PEG 3350
|
Resolution 2.90 Å R-free 0.273 |
| 8U17 The ternary complex structure of DDB1-CRBN-SALL4(ZF1,2)-long bound to Pomalidomide Deposited 2023-08-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
1–395（395 aa）
Chain B
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 3 Y70 S-Pomalidomide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2M Sodium malonate, 20% PEG 3350
|
Resolution 3.10 Å R-free 0.346 |
| 8U17 The ternary complex structure of DDB1-CRBN-SALL4(ZF1,2)-long bound to Pomalidomide Deposited 2023-08-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain E
1–395（395 aa）
Chain E
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 3 Y70 S-Pomalidomide × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2M Sodium malonate, 20% PEG 3350
|
Resolution 3.10 Å R-free 0.346 |
| 8UH6 Degrader-induced complex between PTPN2 and CRBN-DDB1 Deposited 2023-10-06 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | WO8 (5P)-3-(carboxymethoxy)-4-chloro-5-(3-{[(4S)-1-({3-[(4-{1-[(3R)-2,6-dioxopiperidin-3-yl]-3-methyl-2-oxo-2,3-dihydro-1H-benzimidazol-5-yl}piperidine-1-carbonyl)amino]phenyl}methanesulfonyl)-2,2-dimethylpiperidin-4-yl]amino}phenyl)thiophene-2-carboxylic acid × 1 ZN ZINC ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.30 Å |
| 8WQR Structure of the DDB1-AMBRA1 E3 ligase receptor complex linked to cell cycle regulation Deposited 2023-10-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.08 Å |
| 8ZSW Crystal Structure of Human DDB1, a Component of the E3 Ubiquitin Ligase Complex Deposited 2024-06-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ACT ACETATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；287 K；0.1M MES (pH 6.5), 0.1M sodium acetate, 27%(w/v) PEG 400
|
Resolution 2.25 Å R-free 0.229 |
| 9BBE Co-crystal structure of human DDB1 bound to fragment UB028668 Deposited 2024-04-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–1140（1140 aa）
|
Not recorded | TLA L(+)-TARTARIC ACID × 2 A1AK9 5-(4-methoxyphenyl)-3-[(3S)-pyrrolidin-3-yl]-1,2,4-oxadiazole × 1 UNX UNKNOWN LIGAND × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；20% (v/w) PEG 3350, 0.2 M di-NH4tart
|
Resolution 2.00 Å R-free 0.239 |
| 9BBG Co-crystal structure of human DDB1 bound to fragment UB028671 Deposited 2024-04-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–1140（1140 aa）
|
Not recorded | TLA L(+)-TARTARIC ACID × 2 A1ALA 1H-indol-6-amine × 1 EDO 1,2-ETHANEDIOL × 6 UNX UNKNOWN LIGAND × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；20% (v/w) PEG 3350, 0.2 M di-NH4tart
|
Resolution 1.70 Å R-free 0.218 |
| 9BBH Co-crystal structure of human DDB1 bound to fragment UB028670 Deposited 2024-04-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–1140（1140 aa）
|
Not recorded | TLA L(+)-TARTARIC ACID × 2 VVP 4-methoxy-1H-indole × 2 EDO 1,2-ETHANEDIOL × 2 UNX UNKNOWN LIGAND × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；20% (v/w) PEG 3350, 0.2 M di-NH4tart
|
Resolution 2.00 Å R-free 0.232 |
| 9BBI Co-crystal structure of human DDB1 bound to fragment UB028669 Deposited 2024-04-05 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–1140（1140 aa）
|
Not recorded | TLA L(+)-TARTARIC ACID × 2 A1ALB 3-([1,3]oxazolo[4,5-b]pyridin-2-yl)aniline × 1 UNX UNKNOWN LIGAND × 6 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；20% (v/w) PEG 3350, 0.2 M di-NH4tart
|
Resolution 1.90 Å R-free 0.221 |
| 9BJZ Structure of the human DDD-Ube2e2 complex Deposited 2024-04-26 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Mutation：residues 396-705 replaced with GNGNSG Mutation：residues 396-705 replaced with GNGNSG | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.83 Å |
| 9BZ0 Structure of an STK19-containing TC-NER complex Deposited 2024-05-24 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 19 PDB declaration: 22-meric |
Chain d
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 10 MG MAGNESIUM ION × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 1.90 Å |
| 9C5T Cryo EM structure of DCAF2 Deposited 2024-06-06 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.36 Å |
| 9C5U Cryo EM structure of DCAF2:Compound 1 complex Deposited 2024-06-06 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
1–1140（1140 aa）
|
Not recorded | A1AUM 1'-acetyl-1',4'-dihydro-3'H-spiro[cyclopentane-1,2'-quinoxalin]-3'-one × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.05 Å |
| 9C5V Cryo EM structure of a DCAF2:degrader:BRD4 ternary complex Deposited 2024-06-06 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain B
1–1140（1140 aa）
|
Not recorded | A1AUO N-({4-[(4-{[1'-(chloroacetyl)-3'-oxo-3',4'-dihydro-1'H-spiro[cyclopentane-1,2'-quinoxalin]-6'-yl]oxy}piperidin-1-yl)methyl]phenyl}methyl)-2-[(6S,10P)-4-(4-chlorophenyl)-2,3,9-trimethyl-6H-thieno[3,2-f][1,2,4]triazolo[4,3-a][1,4]diazepin-6-yl]acetamide × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.36 Å |
| 9D0W Cryo-EM structure of CDK2/CyclinE1 in complex with CRBN/DDB1 and Cpd 4 Deposited 2024-08-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 A1A1I (3R)-3-(5-{4-[(2-{4-[(8-cyclopentyl-7-oxo-7,8-dihydropyrido[2,3-d]pyrimidin-2-yl)amino]-3-methylbenzene-1-sulfonyl}-7-azaspiro[3.5]nonan-7-yl)methyl]piperidin-1-yl}-4-fluoro-3-methyl-2-oxo-2,3-dihydro-1H-1,3-benzimidazol-1-yl)piperidine-2,6-dione × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.95 Å |
| 9DHD The ternary complex of DDB1, DDA1, DET1 Deposited 2024-09-03 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
2–1140（1139 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.90 Å |
| 9DJT Ternary complex structure of Cereblon-DDB1 bound to WIZ(ZF7) and the molecular glue WIZ-5 Deposited 2024-09-06 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
1–395（395 aa）
Chain B
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 2 SO4 SULFATE ION × 1 A1A5H (3S)-3-(5-{[(4R)-6-ethyl-6-azaspiro[2.5]octan-4-yl]oxy}-1-oxo-1,3-dihydro-2H-isoindol-2-yl)piperidine-2,6-dione × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；0.2 M Sodium Sulfate, 0.1 M Bis-Tris Propane pH 7.5, 20% w/v PEG 3350
|
Resolution 2.95 Å R-free 0.260 |
| 9DJT Ternary complex structure of Cereblon-DDB1 bound to WIZ(ZF7) and the molecular glue WIZ-5 Deposited 2024-09-06 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain E
1–395（395 aa）
Chain E
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 2 SO4 SULFATE ION × 1 A1A5H (3S)-3-(5-{[(4R)-6-ethyl-6-azaspiro[2.5]octan-4-yl]oxy}-1-oxo-1,3-dihydro-2H-isoindol-2-yl)piperidine-2,6-dione × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；0.2 M Sodium Sulfate, 0.1 M Bis-Tris Propane pH 7.5, 20% w/v PEG 3350
|
Resolution 2.95 Å R-free 0.260 |
| 9DJX Ternary complex structure of Cereblon-DDB1 bound to WIZ(ZF7) and the molecular glue WIZ-6 Deposited 2024-09-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
1–395（395 aa）
Chain B
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 2 SO4 SULFATE ION × 1 A1A5I (3S)-3-(5-{[(3R,6S)-1-ethyl-6-methylpiperidin-3-yl]oxy}-1-oxo-1,3-dihydro-2H-isoindol-2-yl)piperidine-2,6-dione × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；0.2 M Sodium Sulfate, 0.1M BIS-TRIS Propane pH 7.5, 20% PEG3350 (Qiagen PACT G8)
|
Resolution 3.35 Å R-free 0.271 |
| 9DJX Ternary complex structure of Cereblon-DDB1 bound to WIZ(ZF7) and the molecular glue WIZ-6 Deposited 2024-09-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain E
1–395（395 aa）
Chain E
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 2 SO4 SULFATE ION × 2 A1A5I (3S)-3-(5-{[(3R,6S)-1-ethyl-6-methylpiperidin-3-yl]oxy}-1-oxo-1,3-dihydro-2H-isoindol-2-yl)piperidine-2,6-dione × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；0.2 M Sodium Sulfate, 0.1M BIS-TRIS Propane pH 7.5, 20% PEG3350 (Qiagen PACT G8)
|
Resolution 3.35 Å R-free 0.271 |
| 9DQD cryo-EM structure of human Cereblon/DDB1 in complex with a non-traditional CRBN binder Deposited 2024-09-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain B
1–395（395 aa）
Chain B
706–1140（435 aa）
|
Mutation：deletion of residues 396-705 Mutation：deletion of residues 396-705 | ZN ZINC ION × 1 A1BEP (3R)-3-{1-methyl-6-[(piperidin-4-yl)amino]-1H-indazol-3-yl}piperidine-2,6-dione × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.00 Å |
| 9DWV Ternary complex of CRBN-DDB1-PPIL4 RRM domain with FPFT-2216 Deposited 2024-10-10 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 A1BC8 (3S)-3-[(4M)-4-(4-methoxythiophen-3-yl)-1H-1,2,3-triazol-1-yl]piperidine-2,6-dione × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.50 Å |
| 9DWW Ternary complex of CRBN-DDB1-PDE6D with FPFT-2216 Deposited 2024-10-10 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 A1BC8 (3S)-3-[(4M)-4-(4-methoxythiophen-3-yl)-1H-1,2,3-triazol-1-yl]piperidine-2,6-dione × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.30 Å |
| 9E2U Crystal structure of DDB1-CRBN-ALV1 complex bound to triple ZnF of Helios (IKZF2 ZF1-3) Deposited 2024-10-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain I
1–395（395 aa）
Fragment：internal deletion of the BPB domain,internal deletion of the BPB domain
Chain I
706–1140（435 aa）
Fragment：internal deletion of the BPB domain,internal deletion of the BPB domain
|
Not recorded | RN9 3-[3-[[1-[(3~{S})-2,6-bis(oxidanylidene)piperidin-3-yl]-2,5-bis(oxidanylidene)pyrrol-3-yl]amino]phenyl]-~{N}-(3-chloranyl-4-methyl-phenyl)propanamide × 1 ZN ZINC ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；20.455% PEG 3350, 0.214 M Li3 Cit
|
Resolution 4.11 Å R-free 0.289 |
| 9E2U Crystal structure of DDB1-CRBN-ALV1 complex bound to triple ZnF of Helios (IKZF2 ZF1-3) Deposited 2024-10-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Fragment：internal deletion of the BPB domain,internal deletion of the BPB domain
Chain A
706–1140（435 aa）
Fragment：internal deletion of the BPB domain,internal deletion of the BPB domain
|
Not recorded | RN9 3-[3-[[1-[(3~{S})-2,6-bis(oxidanylidene)piperidin-3-yl]-2,5-bis(oxidanylidene)pyrrol-3-yl]amino]phenyl]-~{N}-(3-chloranyl-4-methyl-phenyl)propanamide × 1 ZN ZINC ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；20.455% PEG 3350, 0.214 M Li3 Cit
|
Resolution 4.11 Å R-free 0.289 |
| 9E2U Crystal structure of DDB1-CRBN-ALV1 complex bound to triple ZnF of Helios (IKZF2 ZF1-3) Deposited 2024-10-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–395（395 aa）
Fragment：internal deletion of the BPB domain,internal deletion of the BPB domain
Chain C
706–1140（435 aa）
Fragment：internal deletion of the BPB domain,internal deletion of the BPB domain
|
Not recorded | RN9 3-[3-[[1-[(3~{S})-2,6-bis(oxidanylidene)piperidin-3-yl]-2,5-bis(oxidanylidene)pyrrol-3-yl]amino]phenyl]-~{N}-(3-chloranyl-4-methyl-phenyl)propanamide × 1 ZN ZINC ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；20.455% PEG 3350, 0.214 M Li3 Cit
|
Resolution 4.11 Å R-free 0.289 |
| 9E2U Crystal structure of DDB1-CRBN-ALV1 complex bound to triple ZnF of Helios (IKZF2 ZF1-3) Deposited 2024-10-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain E
1–395（395 aa）
Fragment：internal deletion of the BPB domain,internal deletion of the BPB domain
Chain E
706–1140（435 aa）
Fragment：internal deletion of the BPB domain,internal deletion of the BPB domain
|
Not recorded | RN9 3-[3-[[1-[(3~{S})-2,6-bis(oxidanylidene)piperidin-3-yl]-2,5-bis(oxidanylidene)pyrrol-3-yl]amino]phenyl]-~{N}-(3-chloranyl-4-methyl-phenyl)propanamide × 1 ZN ZINC ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；20.455% PEG 3350, 0.214 M Li3 Cit
|
Resolution 4.11 Å R-free 0.289 |
| 9E2U Crystal structure of DDB1-CRBN-ALV1 complex bound to triple ZnF of Helios (IKZF2 ZF1-3) Deposited 2024-10-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 5 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
1–395（395 aa）
Fragment：internal deletion of the BPB domain,internal deletion of the BPB domain
Chain G
706–1140（435 aa）
Fragment：internal deletion of the BPB domain,internal deletion of the BPB domain
|
Not recorded | RN9 3-[3-[[1-[(3~{S})-2,6-bis(oxidanylidene)piperidin-3-yl]-2,5-bis(oxidanylidene)pyrrol-3-yl]amino]phenyl]-~{N}-(3-chloranyl-4-methyl-phenyl)propanamide × 1 ZN ZINC ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；20.455% PEG 3350, 0.214 M Li3 Cit
|
Resolution 4.11 Å R-free 0.289 |
| 9E2U Crystal structure of DDB1-CRBN-ALV1 complex bound to triple ZnF of Helios (IKZF2 ZF1-3) Deposited 2024-10-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 6 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain K
1–395（395 aa）
Fragment：internal deletion of the BPB domain,internal deletion of the BPB domain
Chain K
706–1140（435 aa）
Fragment：internal deletion of the BPB domain,internal deletion of the BPB domain
|
Not recorded | RN9 3-[3-[[1-[(3~{S})-2,6-bis(oxidanylidene)piperidin-3-yl]-2,5-bis(oxidanylidene)pyrrol-3-yl]amino]phenyl]-~{N}-(3-chloranyl-4-methyl-phenyl)propanamide × 1 ZN ZINC ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；20.455% PEG 3350, 0.214 M Li3 Cit
|
Resolution 4.11 Å R-free 0.289 |
| 9E2U Crystal structure of DDB1-CRBN-ALV1 complex bound to triple ZnF of Helios (IKZF2 ZF1-3) Deposited 2024-10-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 7 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain M
1–395（395 aa）
Fragment：internal deletion of the BPB domain,internal deletion of the BPB domain
Chain M
706–1140（435 aa）
Fragment：internal deletion of the BPB domain,internal deletion of the BPB domain
|
Not recorded | RN9 3-[3-[[1-[(3~{S})-2,6-bis(oxidanylidene)piperidin-3-yl]-2,5-bis(oxidanylidene)pyrrol-3-yl]amino]phenyl]-~{N}-(3-chloranyl-4-methyl-phenyl)propanamide × 1 ZN ZINC ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；20.455% PEG 3350, 0.214 M Li3 Cit
|
Resolution 4.11 Å R-free 0.289 |
| 9E2U Crystal structure of DDB1-CRBN-ALV1 complex bound to triple ZnF of Helios (IKZF2 ZF1-3) Deposited 2024-10-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 8 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain O
1–395（395 aa）
Fragment：internal deletion of the BPB domain,internal deletion of the BPB domain
Chain O
706–1140（435 aa）
Fragment：internal deletion of the BPB domain,internal deletion of the BPB domain
|
Not recorded | RN9 3-[3-[[1-[(3~{S})-2,6-bis(oxidanylidene)piperidin-3-yl]-2,5-bis(oxidanylidene)pyrrol-3-yl]amino]phenyl]-~{N}-(3-chloranyl-4-methyl-phenyl)propanamide × 1 ZN ZINC ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；20.455% PEG 3350, 0.214 M Li3 Cit
|
Resolution 4.11 Å R-free 0.289 |
| 9EJQ Crystal structure of DDB1 in complex with XS381952 Deposited 2024-11-28 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–1140（1140 aa）
|
Not recorded | TLA L(+)-TARTARIC ACID × 2 GOL GLYCEROL × 6 A1BIX (4S)-4-(3-ethoxyphenyl)-3-methyl-1-[(4R)-[1,2,4]triazolo[4,3-b]pyridazin-6-yl]-1,4,5,7-tetrahydro-6H-pyrazolo[3,4-b]pyridin-6-one × 1 EDO 1,2-ETHANEDIOL × 5 SO4 SULFATE ION × 7 UNX UNKNOWN LIGAND × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；20.0 P3350, 0.2 di-NH4tart
|
Resolution 1.87 Å R-free 0.220 |
| 9ER2 PolII-TCR-STK19 structure. Deposited 2024-03-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 19 PDB declaration: 22-meric |
Chain d
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 11 MG MAGNESIUM ION × 2 ADP ADENOSINE-5'-DIPHOSPHATE × 1 BEF BERYLLIUM TRIFLUORIDE ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.30 Å |
| 9FD2 Structure of Pol II-TC-NER-STK19 complex Deposited 2024-05-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 19 PDB declaration: 22-meric |
Chain b
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 10 MG MAGNESIUM ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.40 Å |
| 9FJX Crystal structure of human CRBN-DDB1 in complex with Lenalidomide Deposited 2024-05-31 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 5 DMS DIMETHYL SULFOXIDE × 3 ZN ZINC ION × 1 LVY S-Lenalidomide × 1 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.2；291 K；0.8 microliter of CRBN-DDB1 complex at 25 mg/mL (including 1 mM compound and 2 % DMSO final) plus 0.8 microliter of a crystallisation solution consisting of 0.1 M Hepes pH 8.2, 0.2 M NaCl and 10-16 % PEG Smear Medium, plus 0.2 microliter of seeds (established from the same conditions), against 500 microliter of crystallisation solution.
|
Resolution 2.00 Å R-free 0.232 |
| 9FMR Structure of DDB1/Cdk12/Cyclin K with molecular glue SR-4835 Deposited 2024-06-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric |
Chain A
1–391（391 aa）
Chain A
708–1140（433 aa）
Chain D
1–391（391 aa）
Chain D
708–1140（433 aa）
Chain G
1–391（391 aa）
Chain G
708–1140（433 aa）
|
Not recorded | RMF ~{N}-[[5,6-bis(chloranyl)-1~{H}-benzimidazol-2-yl]methyl]-9-(1-methylpyrazol-4-yl)-2-morpholin-4-yl-purin-6-amine × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；283 K；1 M potassium citrate and 15% glycerol
|
Resolution 3.90 Å R-free 0.250 |
| 9H59 Cryo-EM structure of DDB1-CRBN in complex with NK7-902 and NEK7 Deposited 2024-10-22 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | A1ISP 2-[(3S)-2,6-bis(oxidanylidene)piperidin-3-yl]-5-[(1S,2R,5S)-2-(ethylamino)-8-azabicyclo[3.2.1]octan-8-yl]isoindole-1,3-dione × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.40 Å |
| 9HNE Cereblon in complex with DDB1, GSPT1 and Compound-1 Deposited 2024-12-10 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 A1IWG 2-[(3~{S})-2,6-bis(oxidanylidene)piperidin-3-yl]-6-fluoranyl-1-oxidanylidene-3~{H}-isoindole-5-carboxylic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；292 K；0.2 M Sodium citrate, 0.1 M Bis-Tris propane pH 7.5, 20% w/v PEG 3350
|
Resolution 3.90 Å R-free 0.336 |
| 9HNE Cereblon in complex with DDB1, GSPT1 and Compound-1 Deposited 2024-12-10 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain E
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 A1IWG 2-[(3~{S})-2,6-bis(oxidanylidene)piperidin-3-yl]-6-fluoranyl-1-oxidanylidene-3~{H}-isoindole-5-carboxylic acid × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；292 K；0.2 M Sodium citrate, 0.1 M Bis-Tris propane pH 7.5, 20% w/v PEG 3350
|
Resolution 3.90 Å R-free 0.336 |
| 9HPI Cryo-EM structure of DDB1dB-CRBN-MRT-0031619, conformation 1 Deposited 2024-12-13 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Mutation：aa396-705 replaced with GNGNSG | ZN ZINC ION × 2 A1IW1 (3~{S})-3-[3-oxidanylidene-5-[8-(phenylcarbonyl)-2,8-diazaspiro[4.5]decan-2-yl]-1~{H}-isoindol-2-yl]piperidine-2,6-dione × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4；Sample supplemented with DDM directly before vitrification
cryo-EM vitrification conditions
Cryogen ETHANE；LEICA EMGP2
|
Resolution 2.93 Å |
| 9HPJ Cryo-EM structure of DDB1dB-CRBN-MRT-0031619, conformation 2 Deposited 2024-12-13 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Mutation：aa396-705 replaced with GNGNSG | ZN ZINC ION × 2 A1IW1 (3~{S})-3-[3-oxidanylidene-5-[8-(phenylcarbonyl)-2,8-diazaspiro[4.5]decan-2-yl]-1~{H}-isoindol-2-yl]piperidine-2,6-dione × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4；Sample supplemented with DDM directly before vitrification
cryo-EM vitrification conditions
Cryogen ETHANE；LEICA EMGP2
|
Resolution 3.10 Å |
| 9HWG Structure of the transcribing Pol II-TCR-RECQL5 complex Deposited 2025-01-03 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Other combination Heteromer；Protein × 18 PDB declaration: 21-meric |
Chain d
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 10 MG MAGNESIUM ION × 2 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5；20 mM HEPES pH 7.5, 50 mM KCl, 4 mM MgCl2, 1 mM DTT
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.50 Å |
| 9IVD Cryo-EM structure of CyclinD1 bound AMBRA1-DDB1 Deposited 2024-07-23 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.55 Å |
| 9J6J HBx fused DDB1 4M mutant Deposited 2024-08-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–1140（1140 aa）
|
Mutation：A583D,W774K,I770D,R772E | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.86 Å |
| 9J6K HBx complexed with DDB1 Deposited 2024-08-16 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.68 Å |
| 9LTJ Cryo-EM structure of DDB1-DDA1-DET1 complex Deposited 2025-02-06 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.65 Å |
| 9LTL Cryo-EM structure of DDB1-DDA1-DET1 complex Deposited 2025-02-06 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.93 Å |
| 9LTO Cryo-EM structure of DDB1-DDA1-DET1-Ube2e2 complex Deposited 2025-02-06 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain S
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.92 Å |
| 9LTR Cryo-EM structure of dimeric DDB1-DDA1-DET1-Ube2e2-COP1 complex Deposited 2025-02-06 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric |
Chain B
1–1140（1140 aa）
Chain E
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.03 Å |
| 9LTW protein structure of DDB1-DDA1-DET1 Deposited 2025-02-06 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.25 Å |
| 9LTZ protein structure of DDB1-DDA1-DET1-Ube2e2 complex Deposited 2025-02-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain S
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.26 Å |
| 9LU1 protein structure of DDB1-DDA1-DET1-Ube2e2 bound to COP1 dimer Deposited 2025-02-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain S
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.62 Å |
| 9LUL Local refinement of stacked like DDB1-DDA1-DET1-Ube2e2-COP1 complex (layer 1) Deposited 2025-02-09 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 16 PDB declaration: hexadecameric |
Chain c
1–1140（1140 aa）
Chain f
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.99 Å |
| 9LWI The head region of HBx-Smc5/6 ubiquitination complex Deposited 2025-02-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 9 PDB declaration: nonameric |
Chain B
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.12 Å |
| 9LWJ The head-arm region of HBx-Smc5/6 ubiquitination complex Deposited 2025-02-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric |
Chain B
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 7.19 Å |
| 9LWL HBx-Smc5/6 ubiquitination complex Deposited 2025-02-15 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric |
Chain B
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 6 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 8
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 7.25 Å |
| 9M0Y Local refinement of stacked like DDB1-DDA1-DET1-Ube2e2-COP1 complex (layer 2) Deposited 2025-02-25 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 16 PDB declaration: hexadecameric |
Chain S
1–1140（1140 aa）
Chain V
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 4.25 Å |
| 9NFQ Crystal structure of CRBN-DDB1 and MRT-3486 in complex with NEK7 Deposited 2025-02-21 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | A1BX6 (3S)-N-{[(4R)-3-(2,4-dioxo-1,3-diazinan-1-yl)imidazo[1,2-a]pyridin-7-yl]methyl}-2-(phenylmethanesulfonyl)-1,2,3,4-tetrahydroisoquinoline-3-carboxamide × 1 ZN ZINC ION × 1 ADP ADENOSINE-5'-DIPHOSPHATE × 1 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；0.029 M HEPES salt, 0.071 M MOPS acid, 0.06 M NaNO3, 0.06 M Na2HPO4, 0.06 M (NH4)2SO4, 11 % (w/v) PEG 8,000 and 25 % (v/v) ethylene glycol.
|
Resolution 3.25 Å R-free 0.261 |
| 9NFR Crystal structure of CRBN-DDB1 and MRT-23227 in complex with VAV1 Deposited 2025-02-21 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 A1BYX (3R)-3-{2-chloro-4'-[(1-methyl-1H-pyrazol-3-yl)methoxy][1,1'-biphenyl]-3-yl}piperidine-2,6-dione × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；2.6 % PEG Smear Low, 6.1 % PEG Smear Medium, 4.3 % PEG Smear High, 5 % glycerol, 0.1 M CaCl2, and 0.1 M MES pH 5.8
|
Resolution 3.40 Å R-free 0.271 |
| 9NGT Crystal structure of CRBN-DDB1 and FPFT-2216 in complex with mTOR Deposited 2025-02-22 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 A1BC8 (3S)-3-[(4M)-4-(4-methoxythiophen-3-yl)-1H-1,2,3-triazol-1-yl]piperidine-2,6-dione × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；70 mM MES pH 6.0, 1.8-3.2 % (w/v) PEG 3,000, and 13-24 % (w/v) PEG 200
|
Resolution 2.95 Å R-free 0.260 |
| 9NR3 CRBN-DDB1 in complex with GLUL-cN Deposited 2025-03-13 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–393（393 aa）
Chain A
709–1140（432 aa）
|
Not recorded | ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；8% v/v TacsimateTM pH 6.0, 20% w/v Polyethylene glycol 3,350
|
Resolution 2.93 Å R-free 0.278 |
| 9NWS Cryo-EM structure of DDB1dB:CRBN:mezigdomide:SALL4(392-449) Deposited 2025-03-24 | Different construct Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 2 QFC Mezigdomide × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4；50 mM HEPES/NaOH pH 7.4, 150 mM NaCl, 3 mM TCEP
cryo-EM vitrification conditions
Cryogen ETHANE；UltrAuFoil R 0.6/1 300 mesh grids were glow-discharged for 2 min at 20 mA and 39 Pa, pre-incubated with 4 uL of 10 uM FLAG-IKZF1(140-196;Q146A/G151N) for 1 min, and blotted from behind for 4 s. 4 uL of the sample was then applied to the grid. Grids were vitrified using an EM GP plunge freezer operated at 90% humidity and 10 C with 0 s pre-blot, 4 s blot, and 0 s post-blot.
|
Resolution 2.70 Å |
| 9NWT Cryo-EM structure of DDB1dB:CRBN:mezigdomide:SALL4(392-449;G416A) Deposited 2025-03-24 | Different construct Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 2 QFC Mezigdomide × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4；50 mM HEPES/NaOH pH 7.4, 150 mM NaCl, 3 mM TCEP
cryo-EM vitrification conditions
Cryogen ETHANE；UltrAuFoil R 0.6/1 300 mesh grids were glow-discharged for 2 min at 20 mA and 39 Pa, pre-incubated with 4 uL of 10 uM FLAG-IKZF1(140-196;Q146A/G151N) for 1 min, and blotted from behind for 4 s. 4 uL of the sample was then applied to the grid. Grids were vitrified using an EM GP plunge freezer operated at 90% humidity and 10 C with 0 s pre-blot, 4 s blot, and 0 s post-blot.
|
Resolution 2.70 Å |
| 9NYR Cryo-EM structure of CDK2/CyclinE1 in complex with CRBN/DDB1 and Cpd 24 Deposited 2025-03-28 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–1140（1140 aa）
|
Not recorded | A1B7G N-{(1R,4S)-4-[(4-{3-chloro-4-[(3R)-2,6-dioxo-1,2,3,6-tetrahydropyridin-3-yl]phenyl}piperazin-1-yl)methyl]cyclohexyl}-4-({4-[(3S)-3-hydroxy-3-methylpiperidin-1-yl]-5-(trifluoromethyl)pyrimidin-2-yl}amino)-3-methylbenzene-1-sulfonamide × 1 ZN ZINC ION × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5；50mM HEPES, pH 7.5, 150mM NaCl, 2mM TCEP, 2 mM FFC8, protein = 13.4 mg/ml
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.90 Å |
| 9OS2 Cryo-EM structure of the DDB1/CRBN-MRT-5702-G3BP2 ternary complex Deposited 2025-05-23 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 A1CED (1S,3S)-2-[(2-chlorophenyl)methanesulfonyl]-N-{[(4R)-3-(2,4-dioxo-1,3-diazinan-1-yl)imidazo[1,2-a]pyridin-7-yl]methyl}-1-methyl-1,2,3,4-tetrahydroisoquinoline-3-carboxamide × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.50 Å |
| 9OTY DDB1-CRBN with CK1 alpha, SB-405483, and DEG-47: composite map and model submission Deposited 2025-05-27 | Different construct Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–391（391 aa）
Chain A
710–1140（431 aa）
|
Not recorded | ZN ZINC ION × 1 A1CEH N-{2-[(3R)-2,6-dioxopiperidin-3-yl]-1-oxo-2,3-dihydro-1H-isoindol-5-yl}benzamide × 1 A1CEG N-[3-(benzyloxy)pyridin-2-yl]-N'-(4-cyano-2-hydroxyphenyl)urea × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7；10mM HEPES, 240mM NaCl, 3mM TCEP
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.00 Å |
| 9OUK DDB1-CRBN with Ikaros(ZF2) and DEG-47: composite map and model submission Deposited 2025-05-28 | Different construct Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 2 A1CEK N-{2-[(3S)-2,6-dioxopiperidin-3-yl]-1-oxo-2,3-dihydro-1H-isoindol-5-yl}benzamide × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7；10mM HEPES, 240mM NaCl, 3mM TCEP
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.69 Å |
| 9OUL DDB1-CRBN with Ikaros(ZF2), SB-405483, and DEG-47: composite map and model submission Deposited 2025-05-28 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 1 A1CEG N-[3-(benzyloxy)pyridin-2-yl]-N'-(4-cyano-2-hydroxyphenyl)urea × 1 A1CEK N-{2-[(3S)-2,6-dioxopiperidin-3-yl]-1-oxo-2,3-dihydro-1H-isoindol-5-yl}benzamide × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7；10mM HEPES, 240mM NaCl, 3mM TCEP
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.97 Å |
| 9Q22 Crystal structure of ternary complex Helios-ZF2:I-19:CRBN:DDB1 Deposited 2025-08-14 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–381（381 aa）
Fragment：UNP residues 1-381,706-1140
Chain A
706–1140（435 aa）
Fragment：UNP residues 1-381,706-1140
|
Not recorded | A1CNP (3S)-3-[5-(1-benzyl-4-hydroxypiperidin-4-yl)-1-oxo-1,3-dihydro-2H-isoindol-2-yl]piperidine-2,6-dione × 1 ZN ZINC ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；293 K；0.148 M lithium citrate, 0.1 M Tris, pH 7.5, 19.4% PEG3350
|
Resolution 3.41 Å R-free 0.252 |
| 9Q2D Cryo-EM structure of ternary complex Ikaros-ZF2:CC-885:CRBN:DDB1 (molecular glue degrader) Deposited 2025-08-15 | Different construct Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
1–395（395 aa）
Fragment：UNP residues 1-395,706-1140
Chain C
706–1140（435 aa）
Fragment：UNP residues 1-395,706-1140
|
Not recorded | ZN ZINC ION × 2 85C 1-(3-chloro-4-methylphenyl)-3-({2-[(3S)-2,6-dioxopiperidin-3-yl]-1-oxo-2,3-dihydro-1H-isoindol-5-yl}methyl)urea × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7
cryo-EM vitrification conditions
Cryogen ETHANE；blot time 4 sec
blot force 4
|
Resolution 2.94 Å |
| 9S3R Ternary complex structure of compound 1 bound to SMARCA2 bromodomain and DCAF16:DDB1deltaBPB Deposited 2025-07-25 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 A1JLV 2-[6-azanyl-5-[(1~{S},5~{R})-8-[2-[(~{E})-3-(azepan-1-yl)prop-1-enyl]pyridin-4-yl]-3,8-diazabicyclo[3.2.1]octan-3-yl]pyridazin-3-yl]phenol × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE；Applied 3.5 uL of sample to grid. wait = 10 sec, drain = 0 sec, blot = 4 sec, blotForce = 4
|
Resolution 3.30 Å |
| 9SAF Ternary PROTAC-mediated complex of BRD4-BD1/CRBN/DDB1 and JQ1-AcQ bifunctional degrader Deposited 2025-08-07 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 A1JM8 ~{N}-[(2~{S})-1-[[(3~{S})-2,6-bis(oxidanylidene)piperidin-3-yl]amino]-1-oxidanylidene-propan-2-yl]-9-[2-[(9~{S})-7-(4-chlorophenyl)-4,5,13-trimethyl-3-thia-1,8,11,12-tetrazatricyclo[8.3.0.0^{2,6}]trideca-2(6),4,10,12-tetraen-9-yl]ethanoylamino]nonanamide × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.55 Å |
| 9SAI Ternary PROTAC-mediated complex consisting of Cereblon, DDB1 and BRD4-BD1, non-covalently linked by JQ1-AcN Deposited 2025-08-07 | Different construct Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–395（395 aa）
Chain A
706–1140（435 aa）
|
Not recorded | ZN ZINC ION × 1 A1JM3 N-[(2S)-1-[[(3S)-2,5-bis(oxidanylidene)pyrrolidin-3-yl]amino]-1-oxidanylidene-propan-2-yl]-9-[2-[(9S)-7-(4-chlorophenyl)-4,5,13-trimethyl-3-thia-1,8,11,12-tetrazatricyclo[8.3.0.0^{2,6}]trideca-2(6),4,7,10,12-pentaen-9-yl]ethanoylamino]nonanamide × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.5；20 mM HEPES, 100 mM NaCl, 0.25 mM TCEP, pH: 7.5
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 2.66 Å |
| 9SFM Crystal structure of Cereblon-DDB1 in complex with SB-405483 and Lenalidomide Deposited 2025-08-19 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 6 ZN ZINC ION × 1 LVY S-Lenalidomide × 1 A1CEG N-[3-(benzyloxy)pyridin-2-yl]-N'-(4-cyano-2-hydroxyphenyl)urea × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；291 K；20% w/v PEG 4000 0.1 M TRIS pH 8.2, 0.2 M
|
Resolution 2.39 Å R-free 0.244 |
| 9U7T Structure of the human DCAF8-DDB1 complex Deposited 2025-03-25 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.10 Å |
| 9UUM Cryo-EM structure of mezigdomide-organized CRL4-DDB1-CRBN-IKZF3(ZF2-ZF3)-UbcH5a-Ub ubiquitylation assembly Deposited 2025-05-07 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 8 PDB declaration: octameric |
Chain B
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule | ELECTRON MICROSCOPY mmCIF provides none of the parsed conditions | Resolution 3.41 Å |
| 9UWG Structure of the human DCAF2-DDB1 complex Deposited 2025-05-12 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.21 Å |
| 9V0A Cryo-EM structure of pomalidomide-organized CRL4-DDB1-CRBN-IKZF3(ZF2-ZF3)-UbcH5a-Ub ubiquitylation assembly Deposited 2025-05-17 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 8 PDB declaration: octameric |
Chain B
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule | ELECTRON MICROSCOPY mmCIF provides none of the parsed conditions | Resolution 3.69 Å |
| 9V0B Cryo-EM structure of avadomide-organized CRL4-DDB1-CRBN-IKZF3(ZF2-ZF3)-UbcH5a-Ub ubiquitylation assembly Deposited 2025-05-17 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 8 PDB declaration: octameric |
Chain B
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule | ELECTRON MICROSCOPY mmCIF provides none of the parsed conditions | Resolution 3.54 Å |
| 9V0F Cryo-EM structure of cemsidomide-organized CRL4-DDB1-CRBN-IKZF3(ZF2-ZF3)-UbcH5a-Ub ubiquitylation assembly Deposited 2025-05-17 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 8 PDB declaration: octameric |
Chain B
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule | ELECTRON MICROSCOPY mmCIF provides none of the parsed conditions | Resolution 3.71 Å |
| 9W2F Cryo-EM structure of DDB1-CRBN in complex with dHuR-2 and HuR Deposited 2025-07-27 | Different construct Different mutation/modification Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–1140（1140 aa）
|
Not recorded | ZN ZINC ION × 1 A1EUN (3S)-3-[6-[1-[(4-methoxyphenyl)methyl]pyrazol-4-yl]-1-benzofuran-3-yl]piperidine-2,6-dione × 1 |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.40 Å |
| 9W90 DDB1-DDA1-DET1-Ube2e2-COP1-c-Jun-STK40 complex Deposited 2025-08-08 | Different construct Different oligomeric state Different ligand/ion Different experimental method Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric |
Chain B
1–1140（1140 aa）
Chain E
1–1140（1140 aa）
|
Not recorded | No recorded non-water small molecule |
ELECTRON MICROSCOPY
cryo-EM buffer
pH 7.4
cryo-EM vitrification conditions
Cryogen ETHANE
|
Resolution 3.70 Å |
| 9ZXM DDB1 delta with compound 6 Deposited 2026-01-05 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–393（393 aa）
Chain A
706–1140（435 aa）
|
Not recorded | A1C4E (3S,5S)-1-{(4P)-4-(2,2-difluoro-2H-1,3-benzodioxol-4-yl)-3-[(propan-2-yl)oxy]benzene-1-carbonyl}-N-methyl-5-phenylpiperidine-3-carboxamide × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2M ammonium acetate, 0.1M Bis Tris pH 5.5-6.5, and 25% PEG 3350
|
Resolution 2.19 Å R-free 0.246 |
| 9ZXN DDB1 delta with compound 26 Deposited 2026-01-05 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein monomer Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
1–393（393 aa）
Chain A
706–1140（435 aa）
|
Not recorded | A1C4F (3S,5S)-1-{(4P)-4-(2,2-difluoro-2H-1,3-benzodioxol-4-yl)-1-methyl-5-[(propan-2-yl)oxy]-1H-1,3-benzimidazole-7-carbonyl}-N-methyl-5-phenylpiperidine-3-carboxamide × 1 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2M ammonium acetate, 0.1M Bis Tris pH 5.5-6.5, and 25% PEG 3350
|
Resolution 2.07 Å R-free 0.235 |
202 other PDB entries and 288 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | DDB1_HUMAN |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 5–399； UniProt 1–395 Author chain A； PDBConstruct 409–840； UniProt 709–1140 Author chain D； PDBConstruct 5–399； UniProt 1–395 Author chain D； PDBConstruct 409–840； UniProt 709–1140 Author chain G； PDBConstruct 5–399； UniProt 1–395 Author chain G； PDBConstruct 409–840； UniProt 709–1140 |
