3cik

Human GRK2 in Complex with Gbetagamma subunits

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Beta-adrenergic receptor kinase 1

Homo sapiens

UniProt P25098

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 3 Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1 × 1 （P62871） Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2 × 1 （P63212） MAGNESIUM ION × 1 water × 2 Consistent with protein count

Other States of the Same Protein in the Database

Monomer
1bak 5uuu 5uvc

3 assemblies

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
3cik 3krw 3krx 3v5w 4mk0 4pnk 5he1 5ukk 5ukl 5wg3 5wg4 5wg5

17 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name ARBK1_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A； PDBConstruct 1–689； UniProt 1–689

Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1

Bos taurus

UniProt P62871

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 3 Beta-adrenergic receptor kinase 1 × 1 （P25098） Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2 × 1 （P63212） MAGNESIUM ION × 1 water × 2 Consistent with protein count

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
1b9x 1b9y 1gg2 1got 1gp2 1omw 1xhm 24xz 2bcj 2trc 3ah8 3cik

74 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name GBB1_BOVIN
Isoform —
PDB entities 2
Chains and sequence ranges Author chain B； PDBConstruct 1–340； UniProt 1–340

Guanine nucleotide-binding protein G(I)/G(S)/G(O) subunit gamma-2

Bos taurus

UniProt P63212

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Protein heterocomplex Heteromer Protein 3 Beta-adrenergic receptor kinase 1 × 1 （P25098） Guanine nucleotide-binding protein G(I)/G(S)/G(T) subunit beta-1 × 1 （P62871） MAGNESIUM ION × 1 water × 2 Consistent with protein count

Other States of the Same Protein in the Database

Monomer

None

Homodimer

None

Homotetramer

None

Other homooligomers

None

Heteromeric or nucleic-acid complex
1gg2 1gp2 1omw 1xhm 22em 22es 24xy 2bcj 3ah8 3cik 3krw 3krx

217 assemblies; showing the first 12

View Construct and Data Evidence
UniProt name GBG2_BOVIN
Isoform —
PDB entities 3
Chains and sequence ranges Author chain G； PDBConstruct 7–74； UniProt 1–68

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id3cik
Deposition date deposition_date2008-03-11
Structure title titleHuman GRK2 in Complex with Gbetagamma subunits
Keywords keywords;protein kinase, complex, G protein, receptor, WD40 repeat, ATP-binding, Nucleotide-binding, Serine/threonine-protein kinase, Transferase, Transducer, WD repeat, Lipoprotein, Membrane, Phosphoprotein, Prenylation, Transferase-Signaling protein COMPLEX ;; Transferase/Signaling protein
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

3cik__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

3cik__assembly_1__model_1 | I(q)

10-2 10-1 106 107 108 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

3cik__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg（Guinier）42.26 Å
Rg (electron density)42.36 Å
Total Rg42.52 Å
Atom count8166
Residues1018
Excluded volume144970 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 3cik__assembly_1__model_1 trimeric （3） Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (5)

▼

6. Fold Classification (SCOP + CATH) 12 domains

SCOP 2.08 (5 domains)

Domain ID domain_idd3cika1
Class classa — All alpha proteins
Fold Fold folda.91 — Regulator of G-protein signaling, RGS
Superfamily Superfamily superfamilya.91.1 — Regulator of G-protein signaling, RGS
Family Family familya.91.1.0 — automated matches
Domain ID domain_idd3cika2
Class classd — Alpha and beta proteins (a+b)
Fold Fold foldd.144 — Protein kinase-like (PK-like)
Superfamily Superfamily superfamilyd.144.1 — Protein kinase-like (PK-like)
Family Family familyd.144.1.7 — Protein kinases, catalytic subunit
Domain ID domain_idd3cika3
Class classb — All beta proteins
Fold Fold foldb.55 — PH domain-like barrel
Superfamily Superfamily superfamilyb.55.1 — PH domain-like
Family Family familyb.55.1.0 — automated matches
Domain ID domain_idd3cikb_
Class classb — All beta proteins
Fold Fold foldb.69 — 7-bladed beta-propeller
Superfamily Superfamily superfamilyb.69.4 — WD40 repeat-like
Family Family familyb.69.4.1 — WD40-repeat
Domain ID domain_idd3cikg_
Class classa — All alpha proteins
Fold Fold folda.137 — Non-globular all-alpha subunits of globular proteins
Superfamily Superfamily superfamilya.137.3 — Transducin (heterotrimeric G protein), gamma chain
Family Family familya.137.3.1 — Transducin (heterotrimeric G protein), gamma chain

CATH v4.4 (7 domains)

Domain ID domain_id3cikA01
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology287 — Helix Hairpins
Homologous superfamily homologous superfamily1270 —
Domain ID domain_id3cikA02
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology167 — Regulator of G-protein Signalling 4; domain 2
Homologous superfamily homologous superfamily10 — Regulator of G-protein Signalling 4, domain 2
Domain ID domain_id3cikA03
Class class3 — Alpha Beta
Architecture architecture30 — 2-Layer Sandwich
Topology topology200 — Phosphorylase Kinase; domain 1
Homologous superfamily homologous superfamily20 — Phosphorylase Kinase; domain 1
Domain ID domain_id3cikA04
Class class1 — Mainly Alpha
Architecture architecture10 — Orthogonal Bundle
Topology topology510 — Transferase(Phosphotransferase); domain 1
Homologous superfamily homologous superfamily10 — Transferase(Phosphotransferase) domain 1
Domain ID domain_id3cikA05
Class class2 — Mainly Beta
Architecture architecture30 — Roll
Topology topology29 — PH-domain like
Homologous superfamily homologous superfamily30 — Pleckstrin-homology domain (PH domain)/Phosphotyrosine-binding domain (PTB)
Domain ID domain_id3cikB00
Class class2 — Mainly Beta
Architecture architecture130 — 7 Propeller
Topology topology10 — Methylamine Dehydrogenase; Chain H
Homologous superfamily homologous superfamily10 — YVTN repeat-like/Quinoprotein amine dehydrogenase
Domain ID domain_id3cikG00
Class class4 — Few Secondary Structures
Architecture architecture10 — Irregular
Topology topology260 — G Protein Gi Gamma 2
Homologous superfamily homologous superfamily10 — Transducin (heterotrimeric G protein), gamma chain
▶

7. Citations (1)
