3dqv

Structural Insights into NEDD8 Activation of Cullin-RING Ligases: Conformational Control of Conjugation

Method: X-RAY DIFFRACTION

▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

NEDD8

Homo sapiens

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein heterocomplex	Heteromer	Protein 3	Cullin-5 × 1 （Q93034） Rbx1 × 1 （P62877） ZINC ION × 3	Consistent with protein count
2	Protein heterocomplex	Heteromer	Protein 3	Cullin-5 × 1 （Q93034） Rbx1 × 1 （P62877） ZINC ION × 3	Consistent with protein count
3	Protein heterocomplex	Heteromer	Protein 6	Cullin-5 × 2 （Q93034） Rbx1 × 2 （P62877） ZINC ION × 6	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	NEDD8_HUMAN
Isoform	—
PDB entities	1
Chains and sequence ranges	Author chain A； PDBConstruct 6–81； UniProt 1–76 Author chain B； PDBConstruct 6–81； UniProt 1–76

Cullin-5

Homo sapiens

UniProt Q93034

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein heterocomplex	Heteromer	Protein 3	NEDD8 × 1 （Q15843） Rbx1 × 1 （P62877） ZINC ION × 3	Consistent with protein count
2	Protein heterocomplex	Heteromer	Protein 3	NEDD8 × 1 （Q15843） Rbx1 × 1 （P62877） ZINC ION × 3	Consistent with protein count
3	Protein heterocomplex	Heteromer	Protein 6	NEDD8 × 2 （Q15843） Rbx1 × 2 （P62877） ZINC ION × 6	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	CUL5_HUMAN
Isoform	—
PDB entities	2
Chains and sequence ranges	Author chain C； PDBConstruct 3–382； UniProt 401–780 Author chain D； PDBConstruct 3–382； UniProt 401–780

Rbx1

Homo sapiens

UniProt P62877

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein heterocomplex	Heteromer	Protein 3	NEDD8 × 1 （Q15843） Cullin-5 × 1 （Q93034） ZINC ION × 3	Consistent with protein count
2	Protein heterocomplex	Heteromer	Protein 3	NEDD8 × 1 （Q15843） Cullin-5 × 1 （Q93034） ZINC ION × 3	Consistent with protein count
3	Protein heterocomplex	Heteromer	Protein 6	NEDD8 × 2 （Q15843） Cullin-5 × 2 （Q93034） ZINC ION × 6	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	RBX1_HUMAN
Isoform	—
PDB entities	3
Chains and sequence ranges	Author chain R； PDBConstruct 3–106； UniProt 5–108 Author chain Y； PDBConstruct 3–106； UniProt 5–108

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id	3dqv
Deposition date deposition_date	2008-07-09
Structure title title	Structural Insights into NEDD8 Activation of Cullin-RING Ligases: Conformational Control of Conjugation
Keywords keywords	;ubiquitin, nedd8, scf, cullin-ring ligase, cullin, Nucleus, Ubl conjugation pathway, Host-virus interaction, Receptor, Ubl conjugation, Acetylation, Cytoplasm, DNA damage, DNA repair, Metal-binding, Zinc, Zinc-finger, SIGNALING PROTEIN, LIGASE ;; LIGASE
Experimental Method method	X-RAY DIFFRACTION

▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

3dqv__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

3dqv__assembly_1__model_1 | I(q)

100 plotted points; both axes use logarithmic scales.

3dqv__assembly_1__model_1 | P(r) · Pending

P(r) will be calculated and displayed separately for the same assembly/model.

Rg（Guinier）	30.62 Å
Rg (electron density)	29.76 Å
Total Rg	30.41 Å
Atom count	4435
Residues	523
Excluded volume	79911 Å³
Maximum q	0.500 Å⁻¹

Assembly	Model	Structure unit	Oligomeric description	Status	CRYSOL	Actions
1	1	`3dqv__assembly_1__model_1`	trimeric （3）	Success	4.1.3-1-20251215 (887e7ef)	View Download
2	1	`3dqv__assembly_2__model_1`	trimeric （3）	Success	4.1.3-1-20251215 (887e7ef)	View Download
3	1	`3dqv__assembly_3__model_1`	hexameric （6）	Success	4.1.3-1-20251215 (887e7ef)	View Download

▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (4)

Entity 1 Entity 1 polymer

Description description	NEDD8
Molecular weight formula_weight	9078.0 kDa
Mutation mutation	L162M
Source method src_method	man
Copy count entity_count	2

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	A,B
Atom count atom_count	8839

GSGGSMLIKVKTLTGKEIEIDIEPTDKVERIKERVEEKEGIPPQQQRLIYSGKQMNDEKTAADYKIMGGSVLHLVLALRGG

Source Source

Source organism organism	Homo sapiens
Common name common_name	human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Escherichia coli

Entity 2 Entity 2 polymer

Description description	Cullin-5
Molecular weight formula_weight	45601.8 kDa
Mutation mutation	L407E, L439K, V440K
Source method src_method	man
Copy count entity_count	2

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	C,D

GSESKCPEELANYCDMLLRKTPLSKKLTSEEIEAKLKEVLKKLKYVQNKDVFMRYHKAHLTRRLILDISADSEIEENMVEWLREVGMPADYVNKLARMFQDIKVSEDLNQAFKEMHKNNKLALPADSVNIKILNAGAWSRSSEKVFVSLPTELEDLIPEVEEFYKKNHSGRKLHWHHLMSNGIITFKNEVGQYDLEVTTFQLAVLFAWNQRPREKISFENLKLATELPDAELRRTLWSLVAFPKLKRQVLLYEPQVNSPKDFTEGTLFSVNQEFSLIKNAKVQKRGKINLIGRLQLTTERMREEENEGIVQLRILRTQEAIIQIMKMRKKISNAQLQTELVEILKNMFLPQKKMIKEQIEWLIEHKYIRRDESDINTFIYMA

Source Source

Source organism organism	Homo sapiens
Common name common_name	human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Escherichia coli

Entity 3 Entity 3 polymer

Description description	Rbx1
Molecular weight formula_weight	12183.5 kDa
Source method src_method	man
Copy count entity_count	2

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	R,Y

GSMDVDTPSGTNSGAGKKRFEVKKWNAVALWAWDIVVDNCAICRNHIMDLCIECQANQASATSEECTVAWGVCNHAFHFHCISRWLKTRQVCPLDNREWEFQKYGH

Source Source

Source organism organism	Homo sapiens
Common name common_name	human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Escherichia coli

Entity 4 Entity 4 non-polymer

Description description	ZINC ION
Molecular weight formula_weight	65.4 kDa
Source method src_method	syn
Copy count entity_count	6

▼

6. Fold Classification (SCOP + CATH) 16 domains

SCOP 2.08 (6 domains)

Domain ID domain_id	d3dqva2
Class class	d — Alpha and beta proteins (a+b)
Fold Fold fold	d.15 — beta-Grasp (ubiquitin-like)
Superfamily Superfamily superfamily	d.15.1 — Ubiquitin-like
Family Family family	d.15.1.1 — Ubiquitin-related

Domain ID domain_id	d3dqva3
Class class	l — Artifacts
Fold Fold fold	l.1 — Tags
Superfamily Superfamily superfamily	l.1.1 — Tags
Family Family family	l.1.1.1 — Tags

Domain ID domain_id	d3dqvb1
Class class	d — Alpha and beta proteins (a+b)
Fold Fold fold	d.15 — beta-Grasp (ubiquitin-like)
Superfamily Superfamily superfamily	d.15.1 — Ubiquitin-like
Family Family family	d.15.1.1 — Ubiquitin-related

Domain ID domain_id	d3dqvb2
Class class	l — Artifacts
Fold Fold fold	l.1 — Tags
Superfamily Superfamily superfamily	l.1.1 — Tags
Family Family family	l.1.1.1 — Tags

Domain ID domain_id	d3dqvr_
Class class	g — Small proteins
Fold Fold fold	g.44 — RING/U-box
Superfamily Superfamily superfamily	g.44.1 — RING/U-box
Family Family family	g.44.1.1 — RING finger domain, C3HC4

Domain ID domain_id	d3dqvy_
Class class	g — Small proteins
Fold Fold fold	g.44 — RING/U-box
Superfamily Superfamily superfamily	g.44.1 — RING/U-box
Family Family family	g.44.1.1 — RING finger domain, C3HC4

CATH v4.4 (10 domains)

Domain ID domain_id	3dqvA00
Class class	3 — Alpha Beta
Architecture architecture	10 — Roll
Topology topology	20 — Ubiquitin-like (UB roll)
Homologous superfamily homologous superfamily	90 — Phosphatidylinositol 3-kinase Catalytic Subunit; Chain A, domain 1

Domain ID domain_id	3dqvB00
Class class	3 — Alpha Beta
Architecture architecture	10 — Roll
Topology topology	20 — Ubiquitin-like (UB roll)
Homologous superfamily homologous superfamily	90 — Phosphatidylinositol 3-kinase Catalytic Subunit; Chain A, domain 1

Domain ID domain_id	3dqvC01
Class class	1 — Mainly Alpha
Architecture architecture	20 — Up-down Bundle
Topology topology	1310 — 5 helical Cullin repeat like
Homologous superfamily homologous superfamily	10 — Cullin Repeats

Domain ID domain_id	3dqvC02
Class class	3 — Alpha Beta
Architecture architecture	30 — 2-Layer Sandwich
Topology topology	230 — Ribosomal Protein S5; domain 2
Homologous superfamily homologous superfamily	130 — Cullin; Chain C, Domain 2

Domain ID domain_id	3dqvC03
Class class	1 — Mainly Alpha
Architecture architecture	10 — Orthogonal Bundle
Topology topology	10 — Arc Repressor Mutant, subunit A
Homologous superfamily homologous superfamily	10 — Winged helix-like DNA-binding domain superfamily/Winged helix DNA-binding domain

Domain ID domain_id	3dqvD01
Class class	1 — Mainly Alpha
Architecture architecture	20 — Up-down Bundle
Topology topology	1310 — 5 helical Cullin repeat like
Homologous superfamily homologous superfamily	10 — Cullin Repeats

Domain ID domain_id	3dqvD02
Class class	3 — Alpha Beta
Architecture architecture	30 — 2-Layer Sandwich
Topology topology	230 — Ribosomal Protein S5; domain 2
Homologous superfamily homologous superfamily	130 — Cullin; Chain C, Domain 2

Domain ID domain_id	3dqvD03
Class class	1 — Mainly Alpha
Architecture architecture	10 — Orthogonal Bundle
Topology topology	10 — Arc Repressor Mutant, subunit A
Homologous superfamily homologous superfamily	10 — Winged helix-like DNA-binding domain superfamily/Winged helix DNA-binding domain

Domain ID domain_id	3dqvR00
Class class	3 — Alpha Beta
Architecture architecture	30 — 2-Layer Sandwich
Topology topology	40 — Herpes Virus-1
Homologous superfamily homologous superfamily	10 — Zinc/RING finger domain, C3HC4 (zinc finger)

Domain ID domain_id	3dqvY00
Class class	3 — Alpha Beta
Architecture architecture	30 — 2-Layer Sandwich
Topology topology	40 — Herpes Virus-1
Homologous superfamily homologous superfamily	10 — Zinc/RING finger domain, C3HC4 (zinc finger)

▶

Unit-cell length a length_a	88.315 Å
Unit-cell length b length_b	122.442 Å
Unit-cell length c length_c	128.647 Å
Unit-cell angle α angle_alpha	90.00 °
Unit-cell angle β angle_beta	90.00 °
Unit-cell angle γ angle_gamma	90.00 °
Molecules per unit cell Z z_pdb	8

Space group space_group	P 21 21 21
Space-group number int_tables_number	19
Crystal system crystal_system	—

Resolution resolution	3.000 Å
Low-resolution limit resolution_low	50.000 Å
R factor r_factor	0.2490
R_work r_work	0.2490
R_free r_free	0.2990
