HLA class I histocompatibility antigen, A-2 alpha chain
Homo sapiens
State in the Current Structure
| Assembly | Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Associated Components | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|
| 1 | Protein heterocomplex Heteromer Protein × 3 PDB declaration: trimeric（3） Consistent with protein copy count | Chain A； UniProt 25–300 | Not recorded | Beta-2-microglobulin × 1 （P61769） LEU-LEU-TRP-ASN-GLY-PRO-MET-HIS-VAL × 1 PEG DI(HYDROXYETHYL)ETHER × 2 SO4 SULFATE ION × 3 GOL GLYCEROL × 1 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M Sodium Cacodylate pH 6.5, 0.2 M Ammonium Sulphate, 20 % PEG 4000 | Resolution 2.70 Å R-free 0.301 |
| 2 | Protein heterocomplex Heteromer Protein × 3 PDB declaration: trimeric（3） Consistent with protein copy count | Chain D； UniProt 25–300 | Not recorded | Beta-2-microglobulin × 1 （P61769） LEU-LEU-TRP-ASN-GLY-PRO-MET-HIS-VAL × 1 SO4 SULFATE ION × 2 GOL GLYCEROL × 1 EDO 1,2-ETHANEDIOL × 2 | X-RAY DIFFRACTION X-ray crystallization conditions：VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M Sodium Cacodylate pH 6.5, 0.2 M Ammonium Sulphate, 20 % PEG 4000 | Resolution 2.70 Å R-free 0.301 |
Other States of the Same Protein in the Database
Each row is a biological assembly of the same UniProt protein in another PDB entry. The “Difference from current entry” column identifies evidence-level differences; no tag means the currently parsed fields agree.
| Other PDB | Difference from Current Entry 6SS9 | Assembly / Oligomeric State | Construct | Mutations and Modifications | Ligands, Ions and Non-polymers | Method and Experimental Conditions | Structure Quality |
|---|---|---|---|---|---|---|---|
| 1AKJ COMPLEX OF THE HUMAN MHC CLASS I GLYCOPROTEIN HLA-A2 AND THE T CELL CORECEPTOR CD8 Deposited 1997-05-21 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：EXTRACELLULAR DOMAIN
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；PROTEIN WAS CRYSTALLIZED FROM 12% PEG 20000, 100 MM MES, PH 6.5
|
Resolution 2.65 Å R-free 0.276 |
| 1AO7 COMPLEX BETWEEN HUMAN T-CELL RECEPTOR, VIRAL PEPTIDE (TAX), AND HLA-A 0201 Deposited 1997-07-21 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAINS ALPHA 1, ALPHA 2, ALPHA 3
|
Not recorded | EMC ETHYL MERCURY ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；CRYSTALLIZED FROM 10% PEG 8000, 100 MM MGACETATE, 50 MM NACACODYLATE, PH 6.5
|
Resolution 2.60 Å R-free 0.320 |
| 1AO7 COMPLEX BETWEEN HUMAN T-CELL RECEPTOR, VIRAL PEPTIDE (TAX), AND HLA-A 0201 Deposited 1997-07-21 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 10 PDB declaration: decameric |
Chain A
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAINS ALPHA 1, ALPHA 2, ALPHA 3
|
Not recorded | EMC ETHYL MERCURY ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；CRYSTALLIZED FROM 10% PEG 8000, 100 MM MGACETATE, 50 MM NACACODYLATE, PH 6.5
|
Resolution 2.60 Å R-free 0.320 |
| 1AQD HLA-DR1 (DRA, DRB1 0101) HUMAN CLASS II HISTOCOMPATIBILITY PROTEIN (EXTRACELLULAR DOMAIN) COMPLEXED WITH ENDOGENOUS PEPTIDE Deposited 1997-07-28 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
127–141（15 aa）
Fragment：ANTIGENIC PEPTIDE
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 3.5；CRYSTALS GREW AS NEEDLES FROM 10MG/ML HLA-DR1 / PEPTIDE COMPLEX, 15% PEG 4000, 100MM GLYCINE, PH 3.5, AT ROOM TEMPERATURE, OVER ONE WEEK.
|
Resolution 2.45 Å R-free 0.279 |
| 1AQD HLA-DR1 (DRA, DRB1 0101) HUMAN CLASS II HISTOCOMPATIBILITY PROTEIN (EXTRACELLULAR DOMAIN) COMPLEXED WITH ENDOGENOUS PEPTIDE Deposited 1997-07-28 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain I
127–141（15 aa）
Fragment：ANTIGENIC PEPTIDE
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 3.5；CRYSTALS GREW AS NEEDLES FROM 10MG/ML HLA-DR1 / PEPTIDE COMPLEX, 15% PEG 4000, 100MM GLYCINE, PH 3.5, AT ROOM TEMPERATURE, OVER ONE WEEK.
|
Resolution 2.45 Å R-free 0.279 |
| 1AQD HLA-DR1 (DRA, DRB1 0101) HUMAN CLASS II HISTOCOMPATIBILITY PROTEIN (EXTRACELLULAR DOMAIN) COMPLEXED WITH ENDOGENOUS PEPTIDE Deposited 1997-07-28 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain F
127–141（15 aa）
Fragment：ANTIGENIC PEPTIDE
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 3.5；CRYSTALS GREW AS NEEDLES FROM 10MG/ML HLA-DR1 / PEPTIDE COMPLEX, 15% PEG 4000, 100MM GLYCINE, PH 3.5, AT ROOM TEMPERATURE, OVER ONE WEEK.
|
Resolution 2.45 Å R-free 0.279 |
| 1AQD HLA-DR1 (DRA, DRB1 0101) HUMAN CLASS II HISTOCOMPATIBILITY PROTEIN (EXTRACELLULAR DOMAIN) COMPLEXED WITH ENDOGENOUS PEPTIDE Deposited 1997-07-28 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain L
127–141（15 aa）
Fragment：ANTIGENIC PEPTIDE
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 3.5；CRYSTALS GREW AS NEEDLES FROM 10MG/ML HLA-DR1 / PEPTIDE COMPLEX, 15% PEG 4000, 100MM GLYCINE, PH 3.5, AT ROOM TEMPERATURE, OVER ONE WEEK.
|
Resolution 2.45 Å R-free 0.279 |
| 1B0G CLASS I HISTOCOMPATIBILITY ANTIGEN (HLA-A2.1)/BETA 2-MICROGLOBULIN/PEPTIDE P1049 COMPLEX Deposited 1998-11-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；PROTEIN WAS CRYSTALLIZED IN THE HANGING DROP VAPOR DIFFUSION METHOD. THE RESERVOIR SOLUTION CONTAINED 12-16% PEG6000, 6% DIOXANE IN 25MM MES BUFFER, PH6.5. THE HANGING DROP WAS A 1:1 MIXTURE OF THE RESERVOIR SOLUTION AND THE PROTEIN SOLUTION WHICH CONTAINED 10MG/ML PROTEIN IN 25MM MES BUFFER, PH6.5., vapor diffusion - hanging drop
|
Resolution 2.50 Å R-free 0.304 |
| 1B0G CLASS I HISTOCOMPATIBILITY ANTIGEN (HLA-A2.1)/BETA 2-MICROGLOBULIN/PEPTIDE P1049 COMPLEX Deposited 1998-11-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；PROTEIN WAS CRYSTALLIZED IN THE HANGING DROP VAPOR DIFFUSION METHOD. THE RESERVOIR SOLUTION CONTAINED 12-16% PEG6000, 6% DIOXANE IN 25MM MES BUFFER, PH6.5. THE HANGING DROP WAS A 1:1 MIXTURE OF THE RESERVOIR SOLUTION AND THE PROTEIN SOLUTION WHICH CONTAINED 10MG/ML PROTEIN IN 25MM MES BUFFER, PH6.5., vapor diffusion - hanging drop
|
Resolution 2.50 Å R-free 0.304 |
| 1B0R CRYSTAL STRUCTURE OF HLA-A*0201 COMPLEXED WITH A PEPTIDE WITH THE CARBOXYL-TERMINAL GROUP SUBSTITUTED BY A METHYL GROUP Deposited 1998-11-12 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAINS ALPHA 1,ALPHA 2 AND ALPHA 3
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；pH 6.50
|
Resolution 2.90 Å R-free 0.314 |
| 1BD2 COMPLEX BETWEEN HUMAN T-CELL RECEPTOR B7, VIRAL PEPTIDE (TAX) AND MHC CLASS I MOLECULE HLA-A 0201 Deposited 1998-05-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAINS ALPHA 1, ALPHA 2, ALPHA 3
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.1；12% PEG8000, 20MM MOPS, 100MM MAGNESIUM ACETATE,PH7.1
|
Resolution 2.50 Å R-free 0.312 |
| 1DUY CRYSTAL STRUCTURE OF HLA-A*0201/OCTAMERIC TAX PEPTIDE COMPLEX Deposited 2000-01-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：HEAVY CHAIN
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.5；298 K；13-20% polyethylene glycol 6000, 25 mM MES buffer, pH 6.5, VAPOR DIFFUSION, temperature 298K
|
Resolution 2.15 Å R-free 0.254 |
| 1DUY CRYSTAL STRUCTURE OF HLA-A*0201/OCTAMERIC TAX PEPTIDE COMPLEX Deposited 2000-01-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：HEAVY CHAIN
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.5；298 K；13-20% polyethylene glycol 6000, 25 mM MES buffer, pH 6.5, VAPOR DIFFUSION, temperature 298K
|
Resolution 2.15 Å R-free 0.254 |
| 1DUZ HUMAN CLASS I HISTOCOMPATIBILITY ANTIGEN (HLA-A 0201) IN COMPLEX WITH A NONAMERIC PEPTIDE FROM HTLV-1 TAX PROTEIN Deposited 2000-01-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：HEAVY CHAIN
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；13-20% polyethylene glycol 6000, 25 mM MES buffer, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.80 Å R-free 0.250 |
| 1DUZ HUMAN CLASS I HISTOCOMPATIBILITY ANTIGEN (HLA-A 0201) IN COMPLEX WITH A NONAMERIC PEPTIDE FROM HTLV-1 TAX PROTEIN Deposited 2000-01-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：HEAVY CHAIN
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；13-20% polyethylene glycol 6000, 25 mM MES buffer, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.80 Å R-free 0.250 |
| 1EEY Crystal Structure Determination Of HLA A2 Complexed to Peptide GP2 with the substitution (I2L/V5L/L9V) Deposited 2000-02-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–275（275 aa）
Fragment：RESIDUES 1-275 OF EXTRACELLULAR PORTION
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；14% PEG 8000, 25 mM MES, pH6.5., VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.25 Å R-free 0.286 |
| 1EEY Crystal Structure Determination Of HLA A2 Complexed to Peptide GP2 with the substitution (I2L/V5L/L9V) Deposited 2000-02-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–275（275 aa）
Fragment：RESIDUES 1-275 OF EXTRACELLULAR PORTION
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；14% PEG 8000, 25 mM MES, pH6.5., VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.25 Å R-free 0.286 |
| 1EEZ Crystal Structure Determination of HLA-A2.1 Complexed to GP2 Peptide Variant(I2L/V5L) Deposited 2000-02-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
1–275（275 aa）
Fragment：RESIDUES 1-275 OF EXTRACELLULAR PORTION
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；18% PEG8000, 25 mM MES, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.30 Å R-free 0.290 |
| 1EEZ Crystal Structure Determination of HLA-A2.1 Complexed to GP2 Peptide Variant(I2L/V5L) Deposited 2000-02-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
1–275（275 aa）
Fragment：RESIDUES 1-275 OF EXTRACELLULAR PORTION
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；18% PEG8000, 25 mM MES, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.30 Å R-free 0.290 |
| 1HHG THE ANTIGENIC IDENTITY OF PEPTIDE(SLASH)MHC COMPLEXES: A COMPARISON OF THE CONFORMATION OF FIVE PEPTIDES PRESENTED BY HLA-A2 Deposited 1993-06-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.60 Å |
| 1HHG THE ANTIGENIC IDENTITY OF PEPTIDE(SLASH)MHC COMPLEXES: A COMPARISON OF THE CONFORMATION OF FIVE PEPTIDES PRESENTED BY HLA-A2 Deposited 1993-06-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.60 Å |
| 1HHH THE ANTIGENIC IDENTITY OF PEPTIDE(SLASH)MHC COMPLEXES: A COMPARISON OF THE CONFORMATION OF FIVE PEPTIDES PRESENTED BY HLA-A2 Deposited 1993-06-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 3.00 Å |
| 1HHI THE ANTIGENIC IDENTITY OF PEPTIDE(SLASH)MHC COMPLEXES: A COMPARISON OF THE CONFORMATION OF FIVE PEPTIDES PRESENTED BY HLA-A2 Deposited 1993-06-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.50 Å |
| 1HHI THE ANTIGENIC IDENTITY OF PEPTIDE(SLASH)MHC COMPLEXES: A COMPARISON OF THE CONFORMATION OF FIVE PEPTIDES PRESENTED BY HLA-A2 Deposited 1993-06-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.50 Å |
| 1HHJ THE ANTIGENIC IDENTITY OF PEPTIDE(SLASH)MHC COMPLEXES: A COMPARISON OF THE CONFORMATION OF FIVE PEPTIDES PRESENTED BY HLA-A2 Deposited 1993-06-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.50 Å |
| 1HHJ THE ANTIGENIC IDENTITY OF PEPTIDE(SLASH)MHC COMPLEXES: A COMPARISON OF THE CONFORMATION OF FIVE PEPTIDES PRESENTED BY HLA-A2 Deposited 1993-06-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.50 Å |
| 1HHK THE ANTIGENIC IDENTITY OF PEPTIDE(SLASH)MHC COMPLEXES: A COMPARISON OF THE CONFORMATION OF FIVE PEPTIDES PRESENTED BY HLA-A2 Deposited 1993-06-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
20–299（280 aa）
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.50 Å |
| 1HHK THE ANTIGENIC IDENTITY OF PEPTIDE(SLASH)MHC COMPLEXES: A COMPARISON OF THE CONFORMATION OF FIVE PEPTIDES PRESENTED BY HLA-A2 Deposited 1993-06-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.50 Å |
| 1HLA STRUCTURE OF THE HUMAN CLASS I HISTOCOMPATIBILITY ANTIGEN, HLA-A2 Deposited 1987-10-15 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
25–294（270 aa）
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 3.50 Å |
| 1I1F Crystal structure of human class i mhc (hla-a2.1) complexed with beta 2-microglobulin and hiv-rt variant peptide i1y Deposited 1999-04-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：PEPTIDE-BINDING DOMAIN + ALPHA3
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；PROTEIN WAS CRYSTALLIZED IN THE HANGING DROP VAPOR DIFFUSION METHOD. THE
RESERVOIR SOLUTION CONTAINED 16% PEG8000 IN 25MM MES BUFFER, PH6.5. THE
HANGING DROP WAS A 1:1 MIXTURE OF THE RESERVOIR SOLUTION AND THE PROTEIN
SOLUTION WHICH CONTAINED 10MG/ML PROTEIN IN 25MM MES BUFFER, PH6.5.
|
Resolution 2.80 Å R-free 0.315 |
| 1I1F Crystal structure of human class i mhc (hla-a2.1) complexed with beta 2-microglobulin and hiv-rt variant peptide i1y Deposited 1999-04-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：PEPTIDE-BINDING DOMAIN + ALPHA3
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；PROTEIN WAS CRYSTALLIZED IN THE HANGING DROP VAPOR DIFFUSION METHOD. THE
RESERVOIR SOLUTION CONTAINED 16% PEG8000 IN 25MM MES BUFFER, PH6.5. THE
HANGING DROP WAS A 1:1 MIXTURE OF THE RESERVOIR SOLUTION AND THE PROTEIN
SOLUTION WHICH CONTAINED 10MG/ML PROTEIN IN 25MM MES BUFFER, PH6.5.
|
Resolution 2.80 Å R-free 0.315 |
| 1I1Y CRYSTAL STRUCTURE OF HUMAN CLASS I MHC (HLA-A2.1) COMPLEXED WITH BETA 2-MICROGLOBULIN AND HIV-RT VARIANT PEPTIDE I1Y Deposited 1999-04-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：PEPTIDE-BINDING DOMAIN + ALPHA3
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；PROTEIN WAS CRYSTALLIZED IN THE HANGING DROP VAPOR DIFFUSION METHOD. THE
RESERVOIR SOLUTION CONTAINED 18% PEG8000, IN 25MM MES BUFFER, PH6.5. THE
HANGING DROP WAS A 1:1 MIXTURE OF THE RESERVOIR SOLUTION AND THE PROTEIN
SOLUTION WHICH CONTAINED 10MG/ML PROTEIN IN 25MM MES BUFFER, PH6.5., pH 6.50, VAPOR DIFFUSION, HANGING DROP
|
Resolution 2.20 Å R-free 0.289 |
| 1I1Y CRYSTAL STRUCTURE OF HUMAN CLASS I MHC (HLA-A2.1) COMPLEXED WITH BETA 2-MICROGLOBULIN AND HIV-RT VARIANT PEPTIDE I1Y Deposited 1999-04-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：PEPTIDE-BINDING DOMAIN + ALPHA3
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；PROTEIN WAS CRYSTALLIZED IN THE HANGING DROP VAPOR DIFFUSION METHOD. THE
RESERVOIR SOLUTION CONTAINED 18% PEG8000, IN 25MM MES BUFFER, PH6.5. THE
HANGING DROP WAS A 1:1 MIXTURE OF THE RESERVOIR SOLUTION AND THE PROTEIN
SOLUTION WHICH CONTAINED 10MG/ML PROTEIN IN 25MM MES BUFFER, PH6.5., pH 6.50, VAPOR DIFFUSION, HANGING DROP
|
Resolution 2.20 Å R-free 0.289 |
| 1I4F CRYSTAL STRUCTURE OF HLA-A*0201/MAGE-A4-PEPTIDE COMPLEX Deposited 2001-02-21 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | 1PG 2-(2-{2-[2-(2-METHOXY-ETHOXY)-ETHOXY]-ETHOXY}-ETHOXY)-ETHANOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；291 K；PEG 8000, Tris-HCl, NaCl. PEG 400 as cryo protectant., pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 1.40 Å R-free 0.173 |
| 1I7R CRYSTAL STRUCTURE OF CLASS I MHC A2 IN COMPLEX WITH PEPTIDE P1058 Deposited 2001-03-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAIN, RESIDUES 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；PEG6000, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.20 Å R-free 0.307 |
| 1I7R CRYSTAL STRUCTURE OF CLASS I MHC A2 IN COMPLEX WITH PEPTIDE P1058 Deposited 2001-03-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAIN, RESIDUES 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；PEG6000, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.20 Å R-free 0.307 |
| 1I7T CRYSTAL STRUCTURE OF CLASS I MHC A2 IN COMPLEX WITH PEPTIDE P1049-5V Deposited 2001-03-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAIN, RESIDUES 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；PEG6000, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.80 Å R-free 0.285 |
| 1I7T CRYSTAL STRUCTURE OF CLASS I MHC A2 IN COMPLEX WITH PEPTIDE P1049-5V Deposited 2001-03-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAIN, RESIDUES 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；PEG6000, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.80 Å R-free 0.285 |
| 1I7U CRYSTAL STRUCTURE OF CLASS I MHC A2 IN COMPLEX WITH PEPTIDE P1049-6V Deposited 2001-03-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAIN, RESIDUES 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；PEG6000, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.80 Å R-free 0.258 |
| 1I7U CRYSTAL STRUCTURE OF CLASS I MHC A2 IN COMPLEX WITH PEPTIDE P1049-6V Deposited 2001-03-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAIN, RESIDUES 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；PEG6000, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.80 Å R-free 0.258 |
| 1IM3 Crystal Structure of the human cytomegalovirus protein US2 bound to the MHC class I molecule HLA-A2/tax Deposited 2001-05-09 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
25–299（275 aa）
Fragment：extracellular domain, heavy chain
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；PEG 6000, MPD, Tris, pH 7.75, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.20 Å R-free 0.240 |
| 1IM3 Crystal Structure of the human cytomegalovirus protein US2 bound to the MHC class I molecule HLA-A2/tax Deposited 2001-05-09 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain E
25–299（275 aa）
Fragment：extracellular domain, heavy chain
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；PEG 6000, MPD, Tris, pH 7.75, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.20 Å R-free 0.240 |
| 1IM3 Crystal Structure of the human cytomegalovirus protein US2 bound to the MHC class I molecule HLA-A2/tax Deposited 2001-05-09 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain I
25–299（275 aa）
Fragment：extracellular domain, heavy chain
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；PEG 6000, MPD, Tris, pH 7.75, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.20 Å R-free 0.240 |
| 1IM3 Crystal Structure of the human cytomegalovirus protein US2 bound to the MHC class I molecule HLA-A2/tax Deposited 2001-05-09 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain M
25–299（275 aa）
Fragment：extracellular domain, heavy chain
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.75；291 K；PEG 6000, MPD, Tris, pH 7.75, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.20 Å R-free 0.240 |
| 1JF1 Crystal structure of HLA-A2*0201 in complex with a decameric altered peptide ligand from the MART-1/Melan-A Deposited 2001-06-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：HEAVY CHAIN
|
Not recorded | ZN ZINC ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；16% PEG, 25 mM MES and 0.10% NaN3, pH 6.5, VAPOR DIFFUSION, HANGING DROP, at 293K
|
Resolution 1.85 Å R-free 0.225 |
| 1JHT Crystal structure of HLA-A2*0201 in complex with a nonameric altered peptide ligand (ALGIGILTV) from the MART-1/Melan-A. Deposited 2001-06-28 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：HEAVY CHAIN
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；16% PEG, 25 mM MES, 0.10% NaN3, pH 6.5, VAPOR DIFFUSION, HANGING DROP, at 293K
|
Resolution 2.15 Å R-free 0.252 |
| 1LP9 Xenoreactive complex AHIII 12.2 TCR bound to p1049/HLA-A2.1 Deposited 2002-05-07 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；PEG3350, 25mM MES , pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.00 Å R-free 0.253 |
| 1LP9 Xenoreactive complex AHIII 12.2 TCR bound to p1049/HLA-A2.1 Deposited 2002-05-07 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain H
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；PEG3350, 25mM MES , pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.00 Å R-free 0.253 |
| 1OGA A structural basis for immunodominant human T-cell receptor recognition. Deposited 2003-04-28 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：EXTRACELLULAR ALPHA-1, -2, -3, RESIDUES 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；14% PEG8000, 50MM MES PH 6.5
|
Resolution 1.40 Å R-free 0.231 |
| 1P7Q Crystal Structure of HLA-A2 Bound to LIR-1, a Host and Viral MHC Receptor Deposited 2003-05-05 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
25–300（276 aa）
Fragment：residue 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；298 K；PEG 4000, Sodium Acetate, Tris, L-Cysteine, Triton X-100, pH 8.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 3.40 Å R-free 0.309 |
| 1QEW HUMAN CLASS I HISTOCOMPATIBILITY ANTIGEN (HLA-A 0201) COMPLEX WITH A NONAMERIC PEPTIDE FROM MELANOMA-ASSOCIATED ANTIGEN 3 (RESIDUES 271-279) Deposited 1999-04-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：residues 25-299,SWS P01892
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 5.6；20 % POLYETHYLENGLYCOL 8000, SODIUM CITRATE, PH 5.6
|
Resolution 2.20 Å R-free 0.242 |
| 1QR1 POOR BINDING OF A HER-2/NEU EPITOPE (GP2) TO HLA-A2.1 IS DUE TO A LACK OF INTERACTIONS IN THE CENTER OF THE PEPTIDE Deposited 1999-06-17 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：RESIDUES 1-275 OF EXTRACELLULAR PORTION
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；14% PEG 6000, 25 mM MES, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 22K
|
Resolution 2.40 Å R-free 0.284 |
| 1QR1 POOR BINDING OF A HER-2/NEU EPITOPE (GP2) TO HLA-A2.1 IS DUE TO A LACK OF INTERACTIONS IN THE CENTER OF THE PEPTIDE Deposited 1999-06-17 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：RESIDUES 1-275 OF EXTRACELLULAR PORTION
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；295 K；14% PEG 6000, 25 mM MES, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 22K
|
Resolution 2.40 Å R-free 0.284 |
| 1QRN CRYSTAL STRUCTURE OF HUMAN A6 TCR COMPLEXED WITH HLA-A2 BOUND TO ALTERED HTLV-1 TAX PEPTIDE P6A Deposited 1999-06-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–298（274 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；287 K；seeding with hanging drop vapor diffusion; 50 mM MOPS pH 7.0,
75 mM MgSO4, 13% PEG 8000, VAPOR DIFFUSION, HANGING DROP, temperature 287K
|
Resolution 2.80 Å R-free 0.273 |
| 1QSE STRUCTURE OF HUMAN A6-TCR BOUND TO HLA-A2 COMPLEXED WITH ALTERED HTLV-1 TAX PEPTIDE V7R Deposited 1999-06-21 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–298（274 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；290 K；seeding with hanging drop vapor diffusion; 50 mM MOPS, pH 7.0, 75 mM MgSO4 and
13% PEG 8000, VAPOR DIFFUSION, HANGING DROP, temperature 290K
|
Resolution 2.80 Å R-free 0.290 |
| 1QSF STRUCTURE OF A6-TCR BOUND TO HLA-A2 COMPLEXED WITH ALTERED HTLV-1 TAX PEPTIDE Y8A Deposited 1999-06-21 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–298（274 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；290 K；seeding with hanging drop vapor diffusion; 50 mM MOPS, pH 7.0, 75 mM MgSO4 and
13% PEG 8000, VAPOR DIFFUSION, HANGING DROP, temperature 290K
|
Resolution 2.80 Å R-free 0.286 |
| 1S9W Crystal Structure Analysis of NY-ESO-1 epitope, SLLMWITQC, in complex with HLA-A2 Deposited 2004-02-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
Fragment：Extracellular Domains alpha1, alpha2, alpha3
|
Not recorded | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；2.0M ammonium sulphate, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.20 Å R-free 0.267 |
| 1S9X Crystal Structure Analysis of NY-ESO-1 epitope analogue, SLLMWITQA, in complex with HLA-A2 Deposited 2004-02-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
Fragment：Extracellular Domains alpha1, alpha2, alpha3
|
Not recorded | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；2.0M ammonium sulphate, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.50 Å R-free 0.279 |
| 1S9Y Crystal Structure Analysis of NY-ESO-1 epitope analogue, SLLMWITQS, in complex with HLA-A2 Deposited 2004-02-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
Fragment：Extracellular Domains alpha1, alpha2, alpha3
|
Not recorded | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；2.0M ammonium sulphate, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.30 Å R-free 0.273 |
| 1T1W Structural basis for degenerate recognition of HIV peptide variants by cytotoxic lymphocyte, variant SL9-3F6I8V Deposited 2004-04-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；PEG, MES, pH 6.50, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.20 Å R-free 0.237 |
| 1T1X Structural basis for degenerate recognition of HIV peptide variants by cytotoxic lymphocyte, variant SL9-4L Deposited 2004-04-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；PEG/MES, pH 6.50, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.20 Å R-free 0.240 |
| 1T1Y Structural basis for degenerate recognition of HIV peptide variants by cytotoxic lymphocyte, variant SL9-5V Deposited 2004-04-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；PEG, MES, pH 6.50, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.239 |
| 1T1Z Structural basis for degenerate recognition of HIV peptide variants by cytotoxic lymphocyte, variant SL9-6A Deposited 2004-04-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；PEG, MES, pH 6.50, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.90 Å R-free 0.225 |
| 1T20 Structural basis for degenerate recognition of HIV peptide variants by cytotoxic lymphocyte, variant SL9-6I Deposited 2004-04-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；PEG, MES, pH 6.50, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.20 Å R-free 0.247 |
| 1T21 Structural basis for degenerate recognition of HIV peptide variants by cytotoxic lymphocyte, variant SL9, monoclinic crystal Deposited 2004-04-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；PEG, MES, pH 6.50, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.19 Å R-free 0.238 |
| 1T22 Structural basis for degenerate recognition of HIV peptide variants by cytotoxic lymphocyte, variant SL9, orthorhombic crystal Deposited 2004-04-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；PEG, MES, pH 6.50, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.20 Å R-free 0.231 |
| 1TVB Crystal structure of Melanoma Antigen gp100(209-217) Bound to Human Class I MHC HLA-A2 Deposited 2004-06-29 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：alpha-chain
|
Not recorded | GOL GLYCEROL × 9 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG 3350, MES, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.80 Å R-free 0.216 |
| 1TVB Crystal structure of Melanoma Antigen gp100(209-217) Bound to Human Class I MHC HLA-A2 Deposited 2004-06-29 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：alpha-chain
|
Not recorded | GOL GLYCEROL × 13 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG 3350, MES, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.80 Å R-free 0.216 |
| 1TVH Crystal structure of Modified Melanoma Antigen gp100(209-T2M) Bound to Human Class I MHC HLA-A2 Deposited 2004-06-29 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：alpha-chain
|
Not recorded | GOL GLYCEROL × 13 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG 3350, MES, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.80 Å R-free 0.247 |
| 1TVH Crystal structure of Modified Melanoma Antigen gp100(209-T2M) Bound to Human Class I MHC HLA-A2 Deposited 2004-06-29 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：alpha-chain
|
Not recorded | GOL GLYCEROL × 15 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG 3350, MES, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.80 Å R-free 0.247 |
| 2AV1 Crystal structure of HTLV-1 TAX peptide Bound to Human Class I MHC HLA-A2 with the E63Q and K66A mutations in the heavy chain. Deposited 2005-08-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Mutation：E63Q, K66A | GOL GLYCEROL × 13 SCN THIOCYANATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 20%, MES 0.025M, NaSCN 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.95 Å R-free 0.231 |
| 2AV1 Crystal structure of HTLV-1 TAX peptide Bound to Human Class I MHC HLA-A2 with the E63Q and K66A mutations in the heavy chain. Deposited 2005-08-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Mutation：E63Q, K66A | GOL GLYCEROL × 10 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 20%, MES 0.025M, NaSCN 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.95 Å R-free 0.231 |
| 2AV7 Crystal structure of HTLV-1 TAX peptide Bound to Human Class I MHC HLA-A2 with the K66A mutation in the heavy chain. Deposited 2005-08-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Mutation：K66A | GOL GLYCEROL × 14 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M., pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.05 Å R-free 0.234 |
| 2AV7 Crystal structure of HTLV-1 TAX peptide Bound to Human Class I MHC HLA-A2 with the K66A mutation in the heavy chain. Deposited 2005-08-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Mutation：K66A | GOL GLYCEROL × 6 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M., pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.05 Å R-free 0.234 |
| 2BNQ Structural and kinetic basis for heightened immunogenicity of T cell vaccines Deposited 2005-03-31 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：EXTRACELLULAR ALPHA-1, -2, -3, RESIDUES 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.2；pH 7.20
|
Resolution 1.70 Å R-free 0.253 |
| 2BNR Structural and kinetic basis for heightened immunogenicity of T cell vaccines Deposited 2005-03-31 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：EXTRACELLULAR ALPHA-1, -2, -3, RESIDUES 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.2；pH 7.20
|
Resolution 1.90 Å |
| 2C7U Conflicting selective forces affect CD8 T-cell receptor contact sites in an HLA-A2 immunodominant HIV epitope. Deposited 2005-11-29 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；pH 6.50
|
Resolution 2.38 Å R-free 0.314 |
| 2C7U Conflicting selective forces affect CD8 T-cell receptor contact sites in an HLA-A2 immunodominant HIV epitope. Deposited 2005-11-29 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；pH 6.50
|
Resolution 2.38 Å R-free 0.314 |
| 2CLR THREE DIMENSIONAL STRUCTURE OF A PEPTIDE EXTENDING OUT ONE END OF A CLASS I MHC BINDING SITE Deposited 1994-08-01 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å |
| 2CLR THREE DIMENSIONAL STRUCTURE OF A PEPTIDE EXTENDING OUT ONE END OF A CLASS I MHC BINDING SITE Deposited 1994-08-01 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å |
| 2F53 Directed Evolution of Human T-cell Receptor CDR2 residues by phage display dramatically enhances affinity for cognate peptide-MHC without apparent cross-reactivity Deposited 2005-11-25 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：Extracellular domains alpha 1, alpha2 and alpha3, residues 25-299
|
Not recorded | NA SODIUM ION × 1 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；85 mM HEPES, 8.5% Iso-propanol, 17% PEG4000, 15% glycerol, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.10 Å R-free 0.231 |
| 2F53 Directed Evolution of Human T-cell Receptor CDR2 residues by phage display dramatically enhances affinity for cognate peptide-MHC without apparent cross-reactivity Deposited 2005-11-25 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：Extracellular domains alpha 1, alpha2 and alpha3, residues 25-299
|
Not recorded | NA SODIUM ION × 1 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；85 mM HEPES, 8.5% Iso-propanol, 17% PEG4000, 15% glycerol, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.10 Å R-free 0.231 |
| 2F54 Directed evolution of human T cell receptor CDR2 residues by phage display dramatically enhances affinity for cognate peptide-MHC without increasing apparent cross-reactivity Deposited 2005-11-25 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–298（274 aa）
Fragment：alpha 1, alpha 2, alpha 3, residues 25-298
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；85 mM HEPES, 8.5% iso-propanol, 17% PEG 4000, 15% glycerol, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.70 Å R-free 0.286 |
| 2F54 Directed evolution of human T cell receptor CDR2 residues by phage display dramatically enhances affinity for cognate peptide-MHC without increasing apparent cross-reactivity Deposited 2005-11-25 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–298（274 aa）
Fragment：alpha 1, alpha 2, alpha 3, residues 25-298
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；293 K；85 mM HEPES, 8.5% iso-propanol, 17% PEG 4000, 15% glycerol, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.70 Å R-free 0.286 |
| 2GJ6 The complex between TCR A6 and human Class I MHC HLA-A2 with the modified HTLV-1 TAX (Y5K-4-[3-Indolyl]-butyric acid) peptide Deposited 2006-03-30 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
|
Not recorded | SO4 SULFATE ION × 5 GOL GLYCEROL × 13 3IB 3-INDOLEBUTYRIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；297 K；PEG8000 30%, 0.1 M Sodium Cacodylate, 0.2 M Ammonium sulfate, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 297K
|
Resolution 2.56 Å R-free 0.250 |
| 2J8U Large CDR3a loop alteration as a function of MHC mutation. Deposited 2006-10-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：ECTO-DOMAIN, RESIDUES 25-299
|
Mutation：K66A | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；1.0 M NACL 20% PEG 8000 MES, PH 6.5
|
Resolution 2.88 Å R-free 0.293 |
| 2J8U Large CDR3a loop alteration as a function of MHC mutation. Deposited 2006-10-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain H
25–299（275 aa）
Fragment：ECTO-DOMAIN, RESIDUES 25-299
|
Mutation：K66A | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；1.0 M NACL 20% PEG 8000 MES, PH 6.5
|
Resolution 2.88 Å R-free 0.293 |
| 2JCC AH3 recognition of mutant HLA-A2 W167A Deposited 2006-12-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：ECTODOMAIN, RESIDUES 25-299
|
Mutation：YES | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；pH 6.5
|
Resolution 2.50 Å R-free 0.292 |
| 2JCC AH3 recognition of mutant HLA-A2 W167A Deposited 2006-12-21 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain H
25–299（275 aa）
Fragment：ECTODOMAIN, RESIDUES 25-299
|
Mutation：YES | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；pH 6.5
|
Resolution 2.50 Å R-free 0.292 |
| 2P5E Crystal Structures of High Affinity Human T-Cell Receptors Bound to pMHC Reveal Native Diagonal Binding Geometry Deposited 2007-03-15 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：EXTRACELLULAR DOMAINS ALPHA 1, ALPHA2 AND ALPHA3, RESIDUES 25-299
|
Not recorded | GOL GLYCEROL × 8 MG MAGNESIUM ION × 1 SO4 SULFATE ION × 5 IPA ISOPROPYL ALCOHOL × 1 EPE 4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；293 K；85 mM HEPES, 8.5% Isopropanol, 17% PEG 4000, 15% Glycerol, pH 7.5, VAPOR DIFFUSION, temperature 293K, pH 7.50
|
Resolution 1.89 Å R-free 0.236 |
| 2P5W Crystal structures of high affinity human T-cell receptors bound to pMHC reveal native diagonal binding geometry Deposited 2007-03-16 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：EXTRACELLULAR DOMAINS ALPHA 1, ALPHA2 AND ALPHA3, RESIDUES 25-299
|
Not recorded | SO4 SULFATE ION × 6 GOL GLYCEROL × 11 CA CALCIUM ION × 1 MG MAGNESIUM ION × 1 EPE 4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；293 K；85 MM HEPES, 8.5% ISO-PROPANOL, 17% PEG4000, 15% GLYCEROL, PH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K, pH 7.50
|
Resolution 2.20 Å R-free 0.245 |
| 2PYE Crystal Structures of High Affinity Human T-Cell Receptors Bound to pMHC RevealNative Diagonal Binding Geometry TCR Clone C5C1 Complexed with MHC Deposited 2007-05-16 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：EXTRACELLULAR DOMAINS ALPHA 1, ALPHA2 AND ALPHA3, RESIDUES 25-299
|
Not recorded | SO4 SULFATE ION × 9 PGE TRIETHYLENE GLYCOL × 3 7PE 2-(2-(2-(2-(2-(2-ETHOXYETHOXY)ETHOXY)ETHOXY)ETHOXY)ETHOXY)ETHANOL × 1 GOL GLYCEROL × 11 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；291 K；85 mM Na HEPES buffer pH7.5, 8.5 % iso-propanol, 17% PEG 4000, 15% glycerol, pH 7.50, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.30 Å R-free 0.283 |
| 2UWE Large CDR3a loop alteration as a function of MHC mutation Deposited 2007-03-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：ECTO-DOMAIN, RESIDUES 25-299
|
Mutation：YES | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.8；14% PEG 8000, 1 M NACL, 25 MM HEPES, PH 7.8
|
Resolution 2.40 Å R-free 0.290 |
| 2UWE Large CDR3a loop alteration as a function of MHC mutation Deposited 2007-03-20 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain H
25–299（275 aa）
Fragment：ECTO-DOMAIN, RESIDUES 25-299
|
Mutation：YES | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.8；14% PEG 8000, 1 M NACL, 25 MM HEPES, PH 7.8
|
Resolution 2.40 Å R-free 0.290 |
| 2V2W T CELL CROSS-REACTIVITY AND CONFORMATIONAL CHANGES DURING TCR ENGAGEMENT Deposited 2007-06-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：PEPTIDE BINDING DOMAIN, RESIDUES 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；pH 6.5
|
Resolution 1.60 Å R-free 0.237 |
| 2V2W T CELL CROSS-REACTIVITY AND CONFORMATIONAL CHANGES DURING TCR ENGAGEMENT Deposited 2007-06-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–300（276 aa）
Fragment：PEPTIDE BINDING DOMAIN, RESIDUES 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；pH 6.5
|
Resolution 1.60 Å R-free 0.237 |
| 2V2X T cell cross-reactivity and conformational changes during TCR engagement. Deposited 2007-06-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：PEPTIDE BINDING DOMAIN, RESIDUES 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；pH 6.5
|
Resolution 1.60 Å R-free 0.238 |
| 2V2X T cell cross-reactivity and conformational changes during TCR engagement. Deposited 2007-06-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–300（276 aa）
Fragment：PEPTIDE BINDING DOMAIN, RESIDUES 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；pH 6.5
|
Resolution 1.60 Å R-free 0.238 |
| 2VLJ The Structural Dynamics and Energetics of an Immunodominant T-cell Receptor are Programmed by its Vbeta Domain Deposited 2008-01-15 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：HLA-A2, RESIDUES 25-300
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.40 Å R-free 0.272 |
| 2VLK The Structural Dynamics and Energetics of an Immunodominant T-cell Receptor are Programmed by its Vbeta Domain Deposited 2008-01-15 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：HLA-A2, RESIDUES 25-300
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.50 Å R-free 0.288 |
| 2VLL The Structural Dynamics and Energetics of an Immunodominant T-cell Receptor are Programmed by its Vbeta Domain Deposited 2008-01-15 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A2, RESIDUES 25-300
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.60 Å R-free 0.242 |
| 2VLL The Structural Dynamics and Energetics of an Immunodominant T-cell Receptor are Programmed by its Vbeta Domain Deposited 2008-01-15 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–300（276 aa）
Fragment：HLA-A2, RESIDUES 25-300
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.60 Å R-free 0.242 |
| 2VLR The Structural Dynamics and Energetics of an Immunodominant T-cell Receptor are Programmed by its Vbeta Domain Deposited 2008-01-15 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：HLA-A2, RESIDUES 25-300
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å R-free 0.281 |
| 2VLR The Structural Dynamics and Energetics of an Immunodominant T-cell Receptor are Programmed by its Vbeta Domain Deposited 2008-01-15 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–300（276 aa）
Fragment：HLA-A2, RESIDUES 25-300
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.30 Å R-free 0.281 |
| 2X4N Crystal structure of MHC CLass I HLA-A2.1 bound to residual fragments of a photocleavable peptide that is cleaved upon UV-light treatment Deposited 2010-02-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：RESIDUES 25-299
|
Not recorded | GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；100 MM MES PH 5.5, 20% PEG 1500. CRYSTALS WERE FROZEN IN 100 MM MES, 30% PEG 1500, 10% GLYCEROL
|
Resolution 2.34 Å R-free 0.274 |
| 2X4N Crystal structure of MHC CLass I HLA-A2.1 bound to residual fragments of a photocleavable peptide that is cleaved upon UV-light treatment Deposited 2010-02-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：RESIDUES 25-299
|
Not recorded | GOL GLYCEROL × 7 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；100 MM MES PH 5.5, 20% PEG 1500. CRYSTALS WERE FROZEN IN 100 MM MES, 30% PEG 1500, 10% GLYCEROL
|
Resolution 2.34 Å R-free 0.274 |
| 2X4O Crystal structure of MHC CLass I HLA-A2.1 bound to HIV-1 envelope peptide env120-128 Deposited 2010-02-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：RESIDUES 25-299
|
Not recorded | GOL GLYCEROL × 5 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；pH 6.5
|
Resolution 2.30 Å R-free 0.239 |
| 2X4O Crystal structure of MHC CLass I HLA-A2.1 bound to HIV-1 envelope peptide env120-128 Deposited 2010-02-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：RESIDUES 25-299
|
Not recorded | GOL GLYCEROL × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；pH 6.5
|
Resolution 2.30 Å R-free 0.239 |
| 2X4P Crystal structure of MHC CLass I HLA-A2.1 bound to a photocleavable peptide Deposited 2010-02-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：RESIDUES 25-299
|
Not recorded | GOL GLYCEROL × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；0.1 M MES PH 6.5, 20% PEG1500
|
Resolution 2.30 Å R-free 0.222 |
| 2X4P Crystal structure of MHC CLass I HLA-A2.1 bound to a photocleavable peptide Deposited 2010-02-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：RESIDUES 25-299
|
Not recorded | GOL GLYCEROL × 4 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；0.1 M MES PH 6.5, 20% PEG1500
|
Resolution 2.30 Å R-free 0.222 |
| 2X4Q Crystal structure of MHC CLass I HLA-A2.1 bound to a photocleavable peptide Deposited 2010-02-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：RESIDUES 25-299
|
Not recorded | MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；0.1M MES PH 6.5, 20% PEG1500
|
Resolution 1.90 Å R-free 0.206 |
| 2X4Q Crystal structure of MHC CLass I HLA-A2.1 bound to a photocleavable peptide Deposited 2010-02-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：RESIDUES 25-299
|
Not recorded | MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；0.1M MES PH 6.5, 20% PEG1500
|
Resolution 1.90 Å R-free 0.206 |
| 2X4R Crystal structure of MHC CLass I HLA-A2.1 bound to Cytomegalovirus (CMV) pp65 epitope Deposited 2010-02-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：RESIDUES 25-299
|
Not recorded | GOL GLYCEROL × 7 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；0.1 M MES PH 6.5, 20% PEG1500
|
Resolution 2.30 Å R-free 0.220 |
| 2X4R Crystal structure of MHC CLass I HLA-A2.1 bound to Cytomegalovirus (CMV) pp65 epitope Deposited 2010-02-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：RESIDUES 25-299
|
Not recorded | GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；0.1 M MES PH 6.5, 20% PEG1500
|
Resolution 2.30 Å R-free 0.220 |
| 2X4S Crystal structure of MHC CLass I HLA-A2.1 bound to a peptide representing the epitope of the H5N1 (Avian Flu) Nucleoprotein Deposited 2010-02-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：RESIDUES 25 - 299
|
Not recorded | GOL GLYCEROL × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；pH 6.5
|
Resolution 2.55 Å R-free 0.247 |
| 2X4S Crystal structure of MHC CLass I HLA-A2.1 bound to a peptide representing the epitope of the H5N1 (Avian Flu) Nucleoprotein Deposited 2010-02-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：RESIDUES 25 - 299
|
Not recorded | MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；pH 6.5
|
Resolution 2.55 Å R-free 0.247 |
| 2X4T Crystal structure of MHC CLass I HLA-A2.1 bound to a Peiodate- cleavable peptide Deposited 2010-02-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：RESIDUES 25-299
|
Not recorded | GOL GLYCEROL × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；0.1 M MES PH 6.5, 22% PEG1500
|
Resolution 2.30 Å R-free 0.236 |
| 2X4T Crystal structure of MHC CLass I HLA-A2.1 bound to a Peiodate- cleavable peptide Deposited 2010-02-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：RESIDUES 25-299
|
Not recorded | GOL GLYCEROL × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；0.1 M MES PH 6.5, 22% PEG1500
|
Resolution 2.30 Å R-free 0.236 |
| 2X4U Crystal structure of MHC CLass I HLA-A2.1 bound to HIV-1 Peptide RT468-476 Deposited 2010-02-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：RESIDUES 25-299
|
Not recorded | GOL GLYCEROL × 5 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；100 MM MES PH 5.5, 20% PEG 1500. CRYSTALS WERE FROZEN IN 100 MM MES, 30% PEG 1500, 10% GLYCEROL
|
Resolution 2.10 Å R-free 0.234 |
| 2X4U Crystal structure of MHC CLass I HLA-A2.1 bound to HIV-1 Peptide RT468-476 Deposited 2010-02-02 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：RESIDUES 25-299
|
Not recorded | GOL GLYCEROL × 4 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；100 MM MES PH 5.5, 20% PEG 1500. CRYSTALS WERE FROZEN IN 100 MM MES, 30% PEG 1500, 10% GLYCEROL
|
Resolution 2.10 Å R-free 0.234 |
| 2X70 Crystal structure of MHC CLass I HLA-A2.1 bound to a photocleavable peptide Deposited 2010-02-22 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：RESIDUES 25-299
|
Not recorded | GOL GLYCEROL × 2 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；VAPOUR DIFFUSION HANGING DROP AT 293K: 2 MICROLITER OF 5 MG/ML PROTEIN IN 0.1 M MES PH 6.0 WAS MIXED WITH 2 MICROLITER OF 0.1 M MES PH 6.5, 20-22% PEG 1500. SEEDING WAS USED TO GET BIGGER CRYSTALS
|
Resolution 2.00 Å R-free 0.225 |
| 2X70 Crystal structure of MHC CLass I HLA-A2.1 bound to a photocleavable peptide Deposited 2010-02-22 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：RESIDUES 25-299
|
Not recorded | GOL GLYCEROL × 3 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；VAPOUR DIFFUSION HANGING DROP AT 293K: 2 MICROLITER OF 5 MG/ML PROTEIN IN 0.1 M MES PH 6.0 WAS MIXED WITH 2 MICROLITER OF 0.1 M MES PH 6.5, 20-22% PEG 1500. SEEDING WAS USED TO GET BIGGER CRYSTALS
|
Resolution 2.00 Å R-free 0.225 |
| 3BGM Crystal Structure of PKD2 Phosphopeptide Bound to Human Class I MHC HLA-A2 Deposited 2007-11-27 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
Fragment：Alpha-1, Alpha-2, Alpha-3
|
Not recorded | EDO 1,2-ETHANEDIOL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；17% PEG 8000, 0.1M HEPES, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.60 Å R-free 0.232 |
| 3BH8 Crystal Structure of RQA_M Phosphopeptide Bound to HUMAN Class I MHC HLA-A2 Deposited 2007-11-28 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
Fragment：Alpha-1, Alpha-2, Alpha-3
|
Not recorded | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；17% PEG 8000, 0.1M HEPES, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.65 Å R-free 0.231 |
| 3BH9 Crystal Structure of RTY Phosphopeptide Bound to Human Class I MHC HLA-A2 Deposited 2007-11-28 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：Alpha-1, Alpha-2, Alpha-3
|
Not recorded | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；21% PEG 3350, 0.1M sodium thiocyanate, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.70 Å R-free 0.229 |
| 3BH9 Crystal Structure of RTY Phosphopeptide Bound to Human Class I MHC HLA-A2 Deposited 2007-11-28 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 6 PDB declaration: hexameric |
Chain A
25–299（275 aa）
Fragment：Alpha-1, Alpha-2, Alpha-3
|
Not recorded | NA SODIUM ION × 2 EDO 1,2-ETHANEDIOL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；21% PEG 3350, 0.1M sodium thiocyanate, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.70 Å R-free 0.229 |
| 3BHB Crystal Structure of KMD Phosphopeptide Bound to Human Class I MHC HLA-A2 Deposited 2007-11-28 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
Fragment：Alpha-1, Alpha-2, Alpha-3
|
Not recorded | EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；24% POLYACRYLIC ACID, 0.1M HEPES, 0.09M MgCl2, pH 7.5, VAPOR DIFFUSION, hanging drop, temperature 298K
|
Resolution 2.20 Å R-free 0.256 |
| 3D25 Crystal structure of HA-1 minor histocompatibility antigen bound to human class I MHC HLA-A2 Deposited 2008-05-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；298 K；20 % PEG 10K, 0.1 M HEPES, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K, pH 7.50
|
Resolution 1.30 Å R-free 0.204 |
| 3D39 The complex between TCR A6 and human Class I MHC HLA-A2 with the modified HTLV-1 TAX (Y5(4-fluoroPhenylalanine)) peptide Deposited 2008-05-09 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；297 K；TRIS 0.1 M, PEG4000 15%, MgCl2 0.2M, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 297K
|
Resolution 2.81 Å R-free 0.269 |
| 3D3V The complex between TCR A6 and human Class I MHC HLA-A2 with the modified HTLV-1 TAX (Y5(3,4-difluoroPhenylalanine)) peptide Deposited 2008-05-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 6 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；297 K；TRIS 0.1 M, PEG4000 15%, MgCl2 0.2M, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 297K
|
Resolution 2.80 Å R-free 0.278 |
| 3FQN Phosphorylation of self-peptides alters Human Leukocyte Antigen Class I-restricted antigen presentation and generates tumor specific epitopes Deposited 2009-01-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAINS ALPHA1, ALPHA2, ALPHA3, UNP residues 25-299
|
Not recorded | CD CADMIUM ION × 6 MG MAGNESIUM ION × 2 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；13% PEG3350, 5mM CdCl2, 5mM MgCl2, 0.1M NaCl, pH7.4, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.65 Å R-free 0.197 |
| 3FQR Phosphorylation of self-peptides alters Human Leukocyte Antigen Class I-restricted antigen presentation and generates tumor specific epitopes Deposited 2009-01-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAINS ALPHA1, ALPHA2, ALPHA3, UNP residues 25-299
|
Not recorded | GOL GLYCEROL × 3 MG MAGNESIUM ION × 2 CD CADMIUM ION × 6 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；13% PEG3350, 5mM CdCl2, 5mM MgCl2, 0.1M NaCl, pH7.4, temperature 293K, VAPOR DIFFUSION, HANGING DROP
|
Resolution 1.70 Å R-free 0.189 |
| 3FQT Phosphorylation of self-peptides alters Human Leukocyte Antigen Class I-restricted antigen presentation and generates tumor specific epitopes Deposited 2009-01-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAINS ALPHA1, ALPHA2, ALPHA3, UNP residues 25-299
|
Not recorded | CD CADMIUM ION × 6 MG MAGNESIUM ION × 1 GOL GLYCEROL × 6 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；13% PEG3350, 3mM CdCl2, 3mM MgCl2, 0.1M NaCl, pH7.4, temperature 293K, VAPOR DIFFUSION, HANGING DROP
|
Resolution 1.80 Å R-free 0.204 |
| 3FQU Phosphorylation of self-peptides alters Human Leukocyte Antigen Class I-restricted antigen presentation and generates tumor specific epitopes Deposited 2009-01-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAINS ALPHA1, ALPHA2, ALPHA3, UNP residues 25-299
|
Not recorded | GOL GLYCEROL × 4 CD CADMIUM ION × 6 MG MAGNESIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；13% PEG3350, 3mM CdCl2, 3mM MgCl2, 0.1M NaCl, pH7.4, temperature 293K, VAPOR DIFFUSION, HANGING DROP
|
Resolution 1.80 Å R-free 0.202 |
| 3FQW Phosphorylation of self-peptides alters Human Leukocyte Antigen Class I-restricted antigen presentation and generates tumor specific epitopes Deposited 2009-01-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAINS ALPHA1, ALPHA2, ALPHA3, UNP residues 25-299
|
Not recorded | CD CADMIUM ION × 5 CO COBALT (II) ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；13% PEG3350, 10mM CdCl2, 10mM CoCl2, 0.1M NaCl, pH7.4, temperature 293K, VAPOR DIFFUSION, HANGING DROP
|
Resolution 1.93 Å R-free 0.196 |
| 3FQX Phosphorylation of self-peptides alters Human Leukocyte Antigen Class I-restricted antigen presentation and generates tumor specific epitopes Deposited 2009-01-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAINS ALPHA1, ALPHA2, ALPHA3, UNP residues 25-299
|
Not recorded | CD CADMIUM ION × 5 MG MAGNESIUM ION × 2 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.4；293 K；13% PEG3350, 5mM CdCl2, 5mM MgCl2, 0.1M NaCl, pH7.4, temperature 293K, VAPOR DIFFUSION, HANGING DROP
|
Resolution 1.70 Å R-free 0.197 |
| 3FT2 Crystal Structure of a citrulline peptide variant of the minor histocompatibility peptide HA-1 in complex with HLA-A2 Deposited 2009-01-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Mutation：A269V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；12-15% w/v PEG 6000, 0.1 M NaCl and 0.1 M tri-sodium-citrate, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.80 Å R-free 0.218 |
| 3FT3 Crystal Structure of the minor histocompatibility peptide HA-1His in complex with HLA-A2 Deposited 2009-01-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Mutation：A269V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；12-15% w/v PEG 6000, 0.1 M NaCl and 0.1 M tri-sodium-citrate, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.95 Å R-free 0.231 |
| 3FT4 Crystal Structure of the minor histocompatibility peptide HA-1Arg in complex with HLA-A2 Deposited 2009-01-12 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Mutation：A269V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；12-15% w/v PEG 6000, 0.1 M NaCl and 0.1 M tri-sodium-citrate, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.90 Å R-free 0.224 |
| 3GIV Antigen processing influences HIV-specific cytotoxic T lymphocyte immunodominance Deposited 2009-03-06 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：residues in UNP 25-299
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å R-free 0.238 |
| 3GIV Antigen processing influences HIV-specific cytotoxic T lymphocyte immunodominance Deposited 2009-03-06 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：residues in UNP 25-299
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.00 Å R-free 0.238 |
| 3GJF Rational development of high-affinity T-cell receptor-like antibodies Deposited 2009-03-08 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.90 Å R-free 0.251 |
| 3GJF Rational development of high-affinity T-cell receptor-like antibodies Deposited 2009-03-08 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain D
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 1.90 Å R-free 0.251 |
| 3GSN Crystal structure of the public RA14 TCR in complex with the HCMV dominant NLV/HLA-A2 epitope Deposited 2009-03-27 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain H
25–298（274 aa）
|
Mutation：A245V | SO4 SULFATE ION × 1 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；293 K；18-24% PEG 3350, 0.3M LiSO4, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.80 Å R-free 0.290 |
| 3GSO Crystal structure of the binary complex between HLA-A2 and HCMV NLV peptide Deposited 2009-03-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；9-20% PEG 6000, 0.1M tri-Na Citrate, 0-0.1M NaCl, pH 6.5, vapor diffusion, hanging drop, temperature 293K
|
Resolution 1.60 Å R-free 0.229 |
| 3GSQ Crystal structure of the binary complex between HLA-A2 and HCMV NLV-M5S peptide variant Deposited 2009-03-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；9-20% PEG 6000, 0.1M tri-Na Citrate, 0-0.1M NaCl, pH 6.5, vapor diffusion, hanging drop, temperature 293K
|
Resolution 2.12 Å R-free 0.246 |
| 3GSR Crystal structure of the binary complex between HLA-A2 and HCMV NLV-M5V peptide variant Deposited 2009-03-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；9-20% PEG 6000, 0.1M tri-Na Citrate, 0-0.1M NaCl, pH 6.5, vapor diffusion, hanging drop, temperature 293K
|
Resolution 1.95 Å R-free 0.226 |
| 3GSU Crystal structure of the binary complex between HLA-A2 and HCMV NLV-M5T peptide variant Deposited 2009-03-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；9-20% PEG 6000, 0.1M tri-Na Citrate, 0-0.1M NaCl, pH 6.5, vapor diffusion, hanging drop, temperature 293K
|
Resolution 1.80 Å R-free 0.242 |
| 3GSV Crystal structure of the binary complex between HLA-A2 and HCMV NLV-M5Q peptide variant Deposited 2009-03-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；9-20% PEG 6000, 0.1M tri-Na Citrate, 0-0.1M NaCl, pH 6.5, vapor diffusion, hanging drop, temperature 293K
|
Resolution 1.90 Å R-free 0.242 |
| 3GSW Crystal structure of the binary complex between HLA-A2 and HCMV NLV-T8A peptide variant Deposited 2009-03-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；9-20% PEG 6000, 0.1M tri-Na Citrate, 0-0.1M NaCl, pH 6.5, vapor diffusion, hanging drop, temperature 293K
|
Resolution 1.81 Å R-free 0.227 |
| 3GSX Crystal structure of the binary complex between HLA-A2 and HCMV NLV-T8V peptide variant Deposited 2009-03-27 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；9-20% PEG 6000, 0.1M tri-Na Citrate, 0-0.1M NaCl, pH 6.5, vapor diffusion, hanging drop, temperature 293K
|
Resolution 2.10 Å R-free 0.247 |
| 3H7B Human Class I MHC HLA-A2 in complex with the Tel1p peptide Deposited 2009-04-24 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaCl 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.88 Å R-free 0.242 |
| 3H7B Human Class I MHC HLA-A2 in complex with the Tel1p peptide Deposited 2009-04-24 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaCl 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.88 Å R-free 0.242 |
| 3H9H Human Class I MHC HLA-A2(A150P) in complex with the Tel1p peptide Deposited 2009-04-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Mutation：A150P | GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaF 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.00 Å R-free 0.226 |
| 3H9H Human Class I MHC HLA-A2(A150P) in complex with the Tel1p peptide Deposited 2009-04-30 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Mutation：A150P | GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaF 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.00 Å R-free 0.226 |
| 3H9S The complex between TCR A6 and human Class I MHC HLA-A2 with the bound Tel1p peptide Deposited 2009-04-30 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 6 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；297 K；PEG4000 15%, TRIS 0.1M, MgCl2 0.2M, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 297K
|
Resolution 2.70 Å R-free 0.289 |
| 3HAE Rational development of high-affinity T-cell receptor-like antibodies Deposited 2009-05-01 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.9；294 K；12% PEG 8000, 50mM Mes, pH 6.9, VAPOR DIFFUSION, temperature 294K
|
Resolution 2.90 Å R-free 0.283 |
| 3HAE Rational development of high-affinity T-cell receptor-like antibodies Deposited 2009-05-01 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain D
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.9；294 K；12% PEG 8000, 50mM Mes, pH 6.9, VAPOR DIFFUSION, temperature 294K
|
Resolution 2.90 Å R-free 0.283 |
| 3HAE Rational development of high-affinity T-cell receptor-like antibodies Deposited 2009-05-01 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain J
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.9；294 K；12% PEG 8000, 50mM Mes, pH 6.9, VAPOR DIFFUSION, temperature 294K
|
Resolution 2.90 Å R-free 0.283 |
| 3HAE Rational development of high-affinity T-cell receptor-like antibodies Deposited 2009-05-01 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain P
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.9；294 K；12% PEG 8000, 50mM Mes, pH 6.9, VAPOR DIFFUSION, temperature 294K
|
Resolution 2.90 Å R-free 0.283 |
| 3HLA HUMAN CLASS I HISTOCOMPATIBILITY ANTIGEN A2.1 Deposited 1989-10-06 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 2 PDB declaration: dimeric |
Chain A
25–294（270 aa）
|
Not recorded | No recorded non-water small molecule | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.60 Å |
| 3HPJ Human Class I MHC HLA-A2 in complex with the WT-1 (126-134) peptide Deposited 2009-06-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：residues 25-299
|
Not recorded | GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaCl 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.00 Å R-free 0.236 |
| 3HPJ Human Class I MHC HLA-A2 in complex with the WT-1 (126-134) peptide Deposited 2009-06-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：residues 25-299
|
Not recorded | GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaCl 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.00 Å R-free 0.236 |
| 3I6G Newly identified epitope Mn2 from SARS-CoV M protein complexed withHLA-A*0201 Deposited 2009-07-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；0.1M Ammonium acetate, 0.1M BIS-TRIS, pH6.0, 13-17% Polyethylene glycol 10,000, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.20 Å R-free 0.246 |
| 3I6G Newly identified epitope Mn2 from SARS-CoV M protein complexed withHLA-A*0201 Deposited 2009-07-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；277 K；0.1M Ammonium acetate, 0.1M BIS-TRIS, pH6.0, 13-17% Polyethylene glycol 10,000, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.20 Å R-free 0.246 |
| 3I6K Newly identified epitope from SARS-CoV membrane protein complexed with HLA-A*0201 Deposited 2009-07-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：alpha 1-3 regions, UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.5；277 K；0.1M BIS-TRIS pH 5.5, 10% w/v Polyethylene glycol 3350, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.80 Å R-free 0.243 |
| 3I6K Newly identified epitope from SARS-CoV membrane protein complexed with HLA-A*0201 Deposited 2009-07-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain E
25–299（275 aa）
Fragment：alpha 1-3 regions, UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.5；277 K；0.1M BIS-TRIS pH 5.5, 10% w/v Polyethylene glycol 3350, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.80 Å R-free 0.243 |
| 3IXA Human Class I MHC HLA-A2(A150P) in complex with the Tax peptide Deposited 2009-09-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：HLA-A*0201 heavy chain
|
Mutation：A150P | GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaF 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.10 Å R-free 0.230 |
| 3IXA Human Class I MHC HLA-A2(A150P) in complex with the Tax peptide Deposited 2009-09-03 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：HLA-A*0201 heavy chain
|
Mutation：A150P | GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaF 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 2.10 Å R-free 0.230 |
| 3KLA Ca2+ release from the endoplasmic reticulum of NY-ESO-1 specific T cells is modulated by the affinity of T cell receptor and by the use of the CD8 co-receptor Deposited 2009-11-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：HLA-A2
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；294 K；16% PEG 8K, 20mM MES, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 294K
|
Resolution 1.65 Å R-free 0.239 |
| 3KLA Ca2+ release from the endoplasmic reticulum of NY-ESO-1 specific T cells is modulated by the affinity of T cell receptor and by the use of the CD8 co-receptor Deposited 2009-11-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：HLA-A2
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；294 K；16% PEG 8K, 20mM MES, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 294K
|
Resolution 1.65 Å R-free 0.239 |
| 3MGO Crystal structure of a H5-specific CTL epitope derived from H5N1 influenza virus in complex with HLA-A*0201 Deposited 2010-04-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：Extracellular domain, UNP residues 25-275
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；25mM MES(pH 6.5), 16% PEG 6000, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.30 Å R-free 0.247 |
| 3MGO Crystal structure of a H5-specific CTL epitope derived from H5N1 influenza virus in complex with HLA-A*0201 Deposited 2010-04-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：Extracellular domain, UNP residues 25-275
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；25mM MES(pH 6.5), 16% PEG 6000, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.30 Å R-free 0.247 |
| 3MGO Crystal structure of a H5-specific CTL epitope derived from H5N1 influenza virus in complex with HLA-A*0201 Deposited 2010-04-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
25–299（275 aa）
Fragment：Extracellular domain, UNP residues 25-275
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；25mM MES(pH 6.5), 16% PEG 6000, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.30 Å R-free 0.247 |
| 3MGO Crystal structure of a H5-specific CTL epitope derived from H5N1 influenza virus in complex with HLA-A*0201 Deposited 2010-04-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain J
25–299（275 aa）
Fragment：Extracellular domain, UNP residues 25-275
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；25mM MES(pH 6.5), 16% PEG 6000, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.30 Å R-free 0.247 |
| 3MGT Crystal structure of a H5-specific CTL epitope variant derived from H5N1 influenza virus in complex with HLA-A*0201 Deposited 2010-04-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：Extracellular domain, UNP residues 25-275
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；25mM MES(pH 6.5), 16% PEG 6000, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.20 Å R-free 0.237 |
| 3MGT Crystal structure of a H5-specific CTL epitope variant derived from H5N1 influenza virus in complex with HLA-A*0201 Deposited 2010-04-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：Extracellular domain, UNP residues 25-275
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；25mM MES(pH 6.5), 16% PEG 6000, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.20 Å R-free 0.237 |
| 3MGT Crystal structure of a H5-specific CTL epitope variant derived from H5N1 influenza virus in complex with HLA-A*0201 Deposited 2010-04-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
25–299（275 aa）
Fragment：Extracellular domain, UNP residues 25-275
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；25mM MES(pH 6.5), 16% PEG 6000, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.20 Å R-free 0.237 |
| 3MGT Crystal structure of a H5-specific CTL epitope variant derived from H5N1 influenza virus in complex with HLA-A*0201 Deposited 2010-04-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain J
25–299（275 aa）
Fragment：Extracellular domain, UNP residues 25-275
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；25mM MES(pH 6.5), 16% PEG 6000, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.20 Å R-free 0.237 |
| 3MR9 Crystal Structure of MHC class I HLA-A2 molecule complexed with HCMV pp65-495-503 nonapeptide M5A variant Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；12% PEG 6000, 0.1M NaCitrate, 0.15M NaCl, 3.5mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.93 Å R-free 0.266 |
| 3MRB Crystal Structure of MHC class I HLA-A2 molecule complexed with HCMV pp65-495-503 nonapeptide A7H variant Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；12% PEG 6000, 0.1M NaCacodylate, 5mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.40 Å R-free 0.244 |
| 3MRC Crystal Structure of MHC class I HLA-A2 molecule complexed with HCMV pp65-495-503 nonapeptide V6C variant Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；12% PEG 6000, 0.1M NaCitrate, 0.15M NaCl, 3.45mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.80 Å R-free 0.223 |
| 3MRD Crystal Structure of MHC class I HLA-A2 molecule complexed with HCMV pp65-495-503 nonapeptide V6G variant Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；10% PEG 6000, 0.1M MES, 5mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.70 Å R-free 0.226 |
| 3MRE Crystal Structure of MHC class I HLA-A2 molecule complexed with EBV bmlf1-280-288 nonapeptide Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；15% PEG 6000, 0.1M NaCitrate, 0.1M NaCl, 5mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.10 Å R-free 0.204 |
| 3MRF Crystal Structure of MHC class I HLA-A2 molecule complexed with EBV bmlf1-280-288 nonapeptide T4P variant Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；12% PEG 6000, 0.1M NaCacodylate, 0.1M NaCl, 7.5mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.30 Å R-free 0.257 |
| 3MRG Crystal Structure of MHC class I HLA-A2 molecule complexed with HCV NS3-1073-1081 nonapeptide Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | CIT CITRIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；17% PEG 6000, 0.1M NaCitrate, 0.05M NaCl, 5mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.30 Å R-free 0.202 |
| 3MRH Crystal Structure of MHC class I HLA-A2 molecule complexed with HCV NS3-1073-1081 nonapeptide N3S variant Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；9% PEG 6000, 0.1M NaCitrate, 5mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.40 Å R-free 0.308 |
| 3MRI Crystal Structure of MHC class I HLA-A2 molecule complexed with HCV NS3-1073-1081 nonapeptide G4M-V5W variant Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；9% PEG 6000, 0.1M NaCitrate, 0.1M NaCl, 5mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.10 Å R-free 0.296 |
| 3MRJ Crystal Structure of MHC class I HLA-A2 molecule complexed with HCV NS3-1073-1081 nonapeptide V5M variant Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；13% PEG 6000, 0.1M NaCitrate, 0.05M NaCl, 2.84mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.87 Å R-free 0.230 |
| 3MRK Crystal Structure of MHC class I HLA-A2 molecule complexed with AFP137 nonapeptide Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；10% PEG 6000, 0.1M NaCitrate, 5mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.40 Å R-free 0.232 |
| 3MRL Crystal Structure of MHC class I HLA-A2 molecule complexed with HCV NS3-1073-1081 nonapeptide C6V variant Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；15% PEG 6000, 0.1M NaCitrate, 3.6mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.41 Å R-free 0.279 |
| 3MRM Crystal Structure of MHC class I HLA-A2 molecule complexed with HCV NS3-1406-1415 decapeptide Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；18% PEG 6000, 0.1M NaCitrate, 0.02M NaCl, 5mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.90 Å R-free 0.250 |
| 3MRN Crystal Structure of MHC class I HLA-A2 molecule complexed with HCV NS4b-1807-1816 decapeptide Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；18% PEG 6000, 0.1M NaCitrate, 0.1M NaCl, 5mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.30 Å R-free 0.298 |
| 3MRO Crystal Structure of MHC class I HLA-A2 molecule complexed with Melan-A MART1 decapeptide variant Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；12% PEG 6000, 0.1M NaCitrate, 0.1M NaCl, 3mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.35 Å R-free 0.279 |
| 3MRP Crystal Structure of MHC class I HLA-A2 molecule complexed with Melan-A MART1 decapeptide variant Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；13% PEG 6000, 0.1M NaCitrate, 0.1M NaCl, 2.61mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.10 Å R-free 0.227 |
| 3MRQ Crystal Structure of MHC class I HLA-A2 molecule complexed with Melan-A MART1 decapeptide variant Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；17% PEG 6000, 0.1M NaCitrate, 0.1M NaCl, 2.61mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.20 Å R-free 0.235 |
| 3MRR Crystal Structure of MHC class I HLA-A2 molecule complexed with Human Prostaglandin Transporter decapeptide Deposited 2010-04-29 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：HLA-A*0201 alpha chain, UNP resiude 25-300
|
Mutation：A245V | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；15% PEG 6000, 0.1M NaCitrate, 0.1M NaCl, 3mg/ml protein conc., pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.60 Å R-free 0.224 |
| 3MYJ Human Class I MHC HLA-A2 in complex with the WT-1 (126-134) (R1Y) peptide variant. Deposited 2010-05-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：residue 25-299
|
Not recorded | GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, KCl 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.89 Å R-free 0.230 |
| 3MYJ Human Class I MHC HLA-A2 in complex with the WT-1 (126-134) (R1Y) peptide variant. Deposited 2010-05-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：residue 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, KCl 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.89 Å R-free 0.230 |
| 3O3A Human Class I MHC HLA-A2 in complex with the Peptidomimetic ELA-1 Deposited 2010-07-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-298
|
Not recorded | GOL GLYCEROL × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, KCl 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.80 Å R-free 0.212 |
| 3O3A Human Class I MHC HLA-A2 in complex with the Peptidomimetic ELA-1 Deposited 2010-07-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：UNP residues 25-298
|
Not recorded | GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, KCl 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.80 Å R-free 0.212 |
| 3O3B Human Class I MHC HLA-A2 in complex with the Peptidomimetic ELA-1.1 Deposited 2010-07-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-298
|
Not recorded | GOL GLYCEROL × 6 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, KCl 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.90 Å R-free 0.238 |
| 3O3B Human Class I MHC HLA-A2 in complex with the Peptidomimetic ELA-1.1 Deposited 2010-07-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：UNP residues 25-298
|
Not recorded | GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, KCl 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.90 Å R-free 0.238 |
| 3O3D Human Class I MHC HLA-A2 in complex with the Peptidomimetic ELA-2 Deposited 2010-07-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-298
|
Not recorded | GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, KCl 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.70 Å R-free 0.219 |
| 3O3D Human Class I MHC HLA-A2 in complex with the Peptidomimetic ELA-2 Deposited 2010-07-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：UNP residues 25-298
|
Not recorded | GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, KCl 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.70 Å R-free 0.219 |
| 3O3E Human Class I MHC HLA-A2 in complex with the Peptidomimetic ELA-2.1 Deposited 2010-07-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-298
|
Not recorded | GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaF 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.85 Å R-free 0.230 |
| 3O3E Human Class I MHC HLA-A2 in complex with the Peptidomimetic ELA-2.1 Deposited 2010-07-23 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：UNP residues 25-298
|
Not recorded | GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaF 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.85 Å R-free 0.230 |
| 3PWJ Human Class I MHC HLA-A2 in complex with the HuD (G2L,I9V) peptide variant Deposited 2010-12-08 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaCl 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.70 Å R-free 0.215 |
| 3PWJ Human Class I MHC HLA-A2 in complex with the HuD (G2L,I9V) peptide variant Deposited 2010-12-08 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaCl 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.70 Å R-free 0.215 |
| 3PWL Human Class I MHC HLA-A2 in complex with the HuD peptide Deposited 2010-12-08 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaCl 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.65 Å R-free 0.195 |
| 3PWL Human Class I MHC HLA-A2 in complex with the HuD peptide Deposited 2010-12-08 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaCl 0.1M, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 277K
|
Resolution 1.65 Å R-free 0.195 |
| 3PWN Human Class I MHC HLA-A2 in complex with the HuD (G2L) peptide variant Deposited 2010-12-08 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaCl 0.1M, pH 6.5, vapor diffusion, sitting drop, temperature 277K
|
Resolution 1.60 Å R-free 0.214 |
| 3PWN Human Class I MHC HLA-A2 in complex with the HuD (G2L) peptide variant Deposited 2010-12-08 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaCl 0.1M, pH 6.5, vapor diffusion, sitting drop, temperature 277K
|
Resolution 1.60 Å R-free 0.214 |
| 3PWP The complex between TCR A6 and human Class I MHC HLA-A2 with the bound HuD peptide Deposited 2010-12-08 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 7 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；298 K；30% PEG3350, 0.1M TRIS, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 298K
|
Resolution 2.69 Å R-free 0.259 |
| 3QDG The complex between TCR DMF5 and human Class I MHC HLA-A2 with the bound MART-1(26-35)(A27L) peptide Deposited 2011-01-18 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；297 K；PEG 30%, TRIS 0.1M, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 297K
|
Resolution 2.69 Å R-free 0.278 |
| 3QDJ The complex between TCR DMF5 and human Class I MHC HLA-A2 with the bound MART-1(27-35) nonameric peptide Deposited 2011-01-18 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；297 K；PEG 24%, TRIS 0.1M, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 297K
|
Resolution 2.30 Å R-free 0.299 |
| 3QDM The complex between TCR DMF4 and human Class I MHC HLA-A2 with the bound MART-1(26-35)(A27L) decameric peptide Deposited 2011-01-18 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；297 K；PEG 24%, TRIS 0.1, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 297K
|
Resolution 2.80 Å R-free 0.284 |
| 3QEQ The complex between TCR DMF4 and human Class I MHC HLA-A2 with the bound MART-1(27-35) nonameric peptide Deposited 2011-01-20 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8.5；297 K；PEG 24%, TRIS 0.1M, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 297K
|
Resolution 2.59 Å R-free 0.269 |
| 3QFD Human Class I MHC HLA-A2 in complex with Mart-1(27-35) nonameric peptide Deposited 2011-01-21 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 4 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaCl 0.1M, pH 6.5, vapor diffusion, sitting drop, temperature 277K
|
Resolution 1.68 Å R-free 0.211 |
| 3QFD Human Class I MHC HLA-A2 in complex with Mart-1(27-35) nonameric peptide Deposited 2011-01-21 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaCl 0.1M, pH 6.5, vapor diffusion, sitting drop, temperature 277K
|
Resolution 1.68 Å R-free 0.211 |
| 3QFJ The complex between TCR A6 and human Class I MHC HLA-A2 with the modified TAX (Y5F) peptide Deposited 2011-01-21 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 11 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 8.5；297 K；PEG 24%, TRIS 0.1 M, pH 8.5, VAPOR DIFFUSION, SITTING DROP, temperature 297K
|
Resolution 2.29 Å R-free 0.271 |
| 3REW Crystal structure of an lmp2a-derived peptide bound to human class i mhc hla-a2 Deposited 2011-04-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | IOD IODIDE ION × 5 EDO 1,2-ETHANEDIOL × 2 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；22% PEG 3350, 0.2M AMMONIUM IODIDE, VAPOR DIFFUSION, HANGING DROP, TEMPERATURE 298K
|
Resolution 1.90 Å R-free 0.239 |
| 3REW Crystal structure of an lmp2a-derived peptide bound to human class i mhc hla-a2 Deposited 2011-04-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | IOD IODIDE ION × 3 CL CHLORIDE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；22% PEG 3350, 0.2M AMMONIUM IODIDE, VAPOR DIFFUSION, HANGING DROP, TEMPERATURE 298K
|
Resolution 1.90 Å R-free 0.239 |
| 3UTQ Human HLA-A*0201-ALWGPDPAAA Deposited 2011-11-26 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.5；291 K；20% w/v PEG3350, 0.2 M potassium/sodium tartrate, 0.1 M Bis-tris propane, pH 6.5, VAPOR DIFFUSION, temperature 291K
|
Resolution 1.67 Å R-free 0.244 |
| 3UTS 1E6-A*0201-ALWGPDPAAA Complex, Monoclinic Deposited 2011-11-26 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.5；291 K；20% w/v PEG3350, 0.2 M sodium citrate, 0.1 M Bis-tris propane, pH 6.5, VAPOR DIFFUSION, temperature 291K
|
Resolution 2.71 Å R-free 0.269 |
| 3UTS 1E6-A*0201-ALWGPDPAAA Complex, Monoclinic Deposited 2011-11-26 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | SO4 SULFATE ION × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.5；291 K；20% w/v PEG3350, 0.2 M sodium citrate, 0.1 M Bis-tris propane, pH 6.5, VAPOR DIFFUSION, temperature 291K
|
Resolution 2.71 Å R-free 0.269 |
| 3UTT 1E6-A*0201-ALWGPDPAAA Complex, Triclinic Deposited 2011-11-26 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.5；291 K；20% w/v PEG3350, 0.2 M sodium citrate, 0.1 M Bis-tris propane, pH 6.5, VAPOR DIFFUSION, temperature 291K
|
Resolution 2.60 Å R-free 0.274 |
| 3UTT 1E6-A*0201-ALWGPDPAAA Complex, Triclinic Deposited 2011-11-26 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION；pH 6.5；291 K；20% w/v PEG3350, 0.2 M sodium citrate, 0.1 M Bis-tris propane, pH 6.5, VAPOR DIFFUSION, temperature 291K
|
Resolution 2.60 Å R-free 0.274 |
| 3V5D HLA-A2.1 KVAELVHFL Deposited 2011-12-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；25 mM MES pH 6.5, 12% PEG 8000, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.264 |
| 3V5D HLA-A2.1 KVAELVHFL Deposited 2011-12-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；25 mM MES pH 6.5, 12% PEG 8000, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.00 Å R-free 0.264 |
| 3V5H HLA-A2.1 KVAEIVHFL Deposited 2011-12-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；25 mM MES pH6.5, 12% PEG 8000, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.63 Å R-free 0.214 |
| 3V5H HLA-A2.1 KVAEIVHFL Deposited 2011-12-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；25 mM MES pH6.5, 12% PEG 8000, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 1.63 Å R-free 0.214 |
| 3V5K HLA2.1 KVAELVWFL Deposited 2011-12-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；25 mM MES pH6.5 12% PEG 8000, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.31 Å R-free 0.228 |
| 3V5K HLA2.1 KVAELVWFL Deposited 2011-12-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；25 mM MES pH6.5 12% PEG 8000, VAPOR DIFFUSION, HANGING DROP, temperature 293K
|
Resolution 2.31 Å R-free 0.228 |
| 4E5X Crystal structure of a complex between the human adenovirus type 2 E3-19K protein and MHC class I molecule HLA-A2/Tax Deposited 2012-03-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
25–299（275 aa）
Fragment：heavy chain
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；290 K；0.8M succinic acid pH7.0
0.1M calcium chloride dihydrate, VAPOR DIFFUSION, HANGING DROP, temperature 290K
|
Resolution 1.95 Å R-free 0.241 |
| 4E5X Crystal structure of a complex between the human adenovirus type 2 E3-19K protein and MHC class I molecule HLA-A2/Tax Deposited 2012-03-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain D
25–299（275 aa）
Fragment：heavy chain
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；290 K；0.8M succinic acid pH7.0
0.1M calcium chloride dihydrate, VAPOR DIFFUSION, HANGING DROP, temperature 290K
|
Resolution 1.95 Å R-free 0.241 |
| 4EUP The complex between TCR JKF6 and human Class I MHC HLA-A2 presenting the MART-1(27-35)(A27L) peptide Deposited 2012-04-25 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain D
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；0.1 M Bis-Tris, 16% PEG10000, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.88 Å R-free 0.295 |
| 4EUP The complex between TCR JKF6 and human Class I MHC HLA-A2 presenting the MART-1(27-35)(A27L) peptide Deposited 2012-04-25 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；0.1 M Bis-Tris, 16% PEG10000, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.88 Å R-free 0.295 |
| 4FTV The complex between the high affinity version of A6 TCR (A6c134) and human Class I MHC HLA-A2 with the bound TAX nonameric peptide Deposited 2012-06-28 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | GOL GLYCEROL × 10 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；277 K；PEG3350 24%, MES 0.025M, NaCl 0.1M, pH 6.5, vapor diffusion, sitting drop, temperature 277K
|
Resolution 2.74 Å R-free 0.260 |
| 4GKS A2-MHC Complex carrying FLTGIGIITV Deposited 2012-08-13 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 7 SO4 SULFATE ION × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；293 K；25% PEG 8000, 200 mM Ammonium Sulphate, 200 mM Cacodylate Buffer, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.35 Å R-free 0.285 |
| 4GKS A2-MHC Complex carrying FLTGIGIITV Deposited 2012-08-13 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 6 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；293 K；25% PEG 8000, 200 mM Ammonium Sulphate, 200 mM Cacodylate Buffer, pH 6.5, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.35 Å R-free 0.285 |
| 4I4W Peptide length determines the outcome of T cell receptor/peptide-MHCI engagement Deposited 2012-11-28 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 18 GOL GLYCEROL × 3 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
pH 7.5；291 K；0.2M Ammonium sulphate, 22.5% PEG 8K, 0.1M HEPES, pH 7.5, VAPOR DIFFUSION, temperature 291K
|
Resolution 1.77 Å R-free 0.222 |
| 4JFD Preservation of peptide specificity during TCR-MHC contact dominated affinity enhancement of a melanoma-specific TCR Deposited 2013-02-28 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | TAM TRIS(HYDROXYETHYL)AMINOMETHANE × 1 SO4 SULFATE ION × 11 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；291 K；0.1 M TRIS, 15% PEG 4000, 17.4% glycerol, pH 7.5, vapor diffusion, sitting drop, temperature 291K
|
Resolution 2.46 Å R-free 0.248 |
| 4JFE Preservation of peptide specificity during TCR-MHC contact dominated affinity enhancement of a melanoma-specific TCR Deposited 2013-02-28 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | SO4 SULFATE ION × 4 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；291 K；0.1 M BIS TRIS Propane, 20% PEG 4000, 0.2M Ammonium sulphate, 17.4% glycerol, pH 7.0, vapor diffusion, sitting drop, temperature 291K
|
Resolution 2.70 Å R-free 0.250 |
| 4JFF Preservation of peptide specificity during TCR-MHC contact dominated affinity enhancement of a melanoma-specific TCR Deposited 2013-02-28 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | EPE 4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID × 2 SO4 SULFATE ION × 7 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；291 K；0.1 M TRIS, 15% PEG 4000, 17.4% Glycerol, pH 7.0, vapor diffusion, sitting drop, temperature 291K
|
Resolution 2.43 Å R-free 0.263 |
| 4JFO A2 HLA complex with E1A heteroclitic variant of Melanoma peptide Deposited 2013-02-28 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 6 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；291 K；25 mM MES, 24% PEG 3350, 10 mM NaCl, pH 6.5, vapor diffusion, sitting drop, temperature 291K
|
Resolution 2.11 Å R-free 0.296 |
| 4JFO A2 HLA complex with E1A heteroclitic variant of Melanoma peptide Deposited 2013-02-28 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；291 K；25 mM MES, 24% PEG 3350, 10 mM NaCl, pH 6.5, vapor diffusion, sitting drop, temperature 291K
|
Resolution 2.11 Å R-free 0.296 |
| 4JFP A2 HLA complex with G4A heteroclitic variant of Melanoma peptide Deposited 2013-02-28 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | GOL GLYCEROL × 5 EDO 1,2-ETHANEDIOL × 3 SO4 SULFATE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；291 K；0.1 M sodium cacodylate, 20% PEG 8000, 0.2 M ammonium sulphate, pH 6.0, vapor diffusion, sitting drop, temperature 291K
|
Resolution 1.91 Å R-free 0.228 |
| 4JFP A2 HLA complex with G4A heteroclitic variant of Melanoma peptide Deposited 2013-02-28 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–300（276 aa）
|
Not recorded | GOL GLYCEROL × 2 EDO 1,2-ETHANEDIOL × 3 EPE 4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；291 K；0.1 M sodium cacodylate, 20% PEG 8000, 0.2 M ammonium sulphate, pH 6.0, vapor diffusion, sitting drop, temperature 291K
|
Resolution 1.91 Å R-free 0.228 |
| 4JFQ A2 HLA complex with L8A heteroclitic variant of Melanoma peptide Deposited 2013-02-28 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | GOL GLYCEROL × 11 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；291 K；25 mM MES, 24% PEG 3350, 10 mM NaCl, pH 6.5, vapor diffusion, sitting drop, temperature 291K
|
Resolution 1.90 Å R-free 0.297 |
| 4JFQ A2 HLA complex with L8A heteroclitic variant of Melanoma peptide Deposited 2013-02-28 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–300（276 aa）
|
Not recorded | GOL GLYCEROL × 8 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；291 K；25 mM MES, 24% PEG 3350, 10 mM NaCl, pH 6.5, vapor diffusion, sitting drop, temperature 291K
|
Resolution 1.90 Å R-free 0.297 |
| 4K7F Newly identified epitope V60 from HBV core protein complexed with HLA-A*0201 Deposited 2013-04-17 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；0.1M Bis-Tris, 20%(wt/vol) polyethylene glycol 3350, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.00 Å R-free 0.259 |
| 4K7F Newly identified epitope V60 from HBV core protein complexed with HLA-A*0201 Deposited 2013-04-17 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；0.1M Bis-Tris, 20%(wt/vol) polyethylene glycol 3350, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 291K
|
Resolution 2.00 Å R-free 0.259 |
| 4L29 Structure of wtMHC class I with NY-ESO1 double mutant Deposited 2013-06-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 3.09 Å R-free 0.201 |
| 4L29 Structure of wtMHC class I with NY-ESO1 double mutant Deposited 2013-06-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 10 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain S
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 3.09 Å R-free 0.201 |
| 4L29 Structure of wtMHC class I with NY-ESO1 double mutant Deposited 2013-06-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 11 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain U
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 3.09 Å R-free 0.201 |
| 4L29 Structure of wtMHC class I with NY-ESO1 double mutant Deposited 2013-06-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 12 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain W
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 3.09 Å R-free 0.201 |
| 4L29 Structure of wtMHC class I with NY-ESO1 double mutant Deposited 2013-06-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 13 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain Y
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 3.09 Å R-free 0.201 |
| 4L29 Structure of wtMHC class I with NY-ESO1 double mutant Deposited 2013-06-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 14 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain a
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 3.09 Å R-free 0.201 |
| 4L29 Structure of wtMHC class I with NY-ESO1 double mutant Deposited 2013-06-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 3.09 Å R-free 0.201 |
| 4L29 Structure of wtMHC class I with NY-ESO1 double mutant Deposited 2013-06-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain E
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 3.09 Å R-free 0.201 |
| 4L29 Structure of wtMHC class I with NY-ESO1 double mutant Deposited 2013-06-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 3.09 Å R-free 0.201 |
| 4L29 Structure of wtMHC class I with NY-ESO1 double mutant Deposited 2013-06-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 5 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain I
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 4 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 3.09 Å R-free 0.201 |
| 4L29 Structure of wtMHC class I with NY-ESO1 double mutant Deposited 2013-06-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 6 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain K
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 3.09 Å R-free 0.201 |
| 4L29 Structure of wtMHC class I with NY-ESO1 double mutant Deposited 2013-06-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 7 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain M
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 3.09 Å R-free 0.201 |
| 4L29 Structure of wtMHC class I with NY-ESO1 double mutant Deposited 2013-06-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 8 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain O
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 3.09 Å R-free 0.201 |
| 4L29 Structure of wtMHC class I with NY-ESO1 double mutant Deposited 2013-06-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 9 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain Q
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 3 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 3.09 Å R-free 0.201 |
| 4L3C Structure of HLA-A2 in complex with D76N b2m mutant and NY-ESO1 double mutant Deposited 2013-06-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 3 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.64 Å R-free 0.218 |
| 4L3C Structure of HLA-A2 in complex with D76N b2m mutant and NY-ESO1 double mutant Deposited 2013-06-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 10 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain S
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.64 Å R-free 0.218 |
| 4L3C Structure of HLA-A2 in complex with D76N b2m mutant and NY-ESO1 double mutant Deposited 2013-06-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 11 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain U
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.64 Å R-free 0.218 |
| 4L3C Structure of HLA-A2 in complex with D76N b2m mutant and NY-ESO1 double mutant Deposited 2013-06-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 12 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain W
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 3 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.64 Å R-free 0.218 |
| 4L3C Structure of HLA-A2 in complex with D76N b2m mutant and NY-ESO1 double mutant Deposited 2013-06-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 13 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain Y
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.64 Å R-free 0.218 |
| 4L3C Structure of HLA-A2 in complex with D76N b2m mutant and NY-ESO1 double mutant Deposited 2013-06-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 14 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain a
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.64 Å R-free 0.218 |
| 4L3C Structure of HLA-A2 in complex with D76N b2m mutant and NY-ESO1 double mutant Deposited 2013-06-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 3 GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.64 Å R-free 0.218 |
| 4L3C Structure of HLA-A2 in complex with D76N b2m mutant and NY-ESO1 double mutant Deposited 2013-06-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain E
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.64 Å R-free 0.218 |
| 4L3C Structure of HLA-A2 in complex with D76N b2m mutant and NY-ESO1 double mutant Deposited 2013-06-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.64 Å R-free 0.218 |
| 4L3C Structure of HLA-A2 in complex with D76N b2m mutant and NY-ESO1 double mutant Deposited 2013-06-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 5 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain I
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 5 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.64 Å R-free 0.218 |
| 4L3C Structure of HLA-A2 in complex with D76N b2m mutant and NY-ESO1 double mutant Deposited 2013-06-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 6 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain K
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.64 Å R-free 0.218 |
| 4L3C Structure of HLA-A2 in complex with D76N b2m mutant and NY-ESO1 double mutant Deposited 2013-06-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 7 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain M
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 3 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.64 Å R-free 0.218 |
| 4L3C Structure of HLA-A2 in complex with D76N b2m mutant and NY-ESO1 double mutant Deposited 2013-06-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 8 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain O
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 2 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.64 Å R-free 0.218 |
| 4L3C Structure of HLA-A2 in complex with D76N b2m mutant and NY-ESO1 double mutant Deposited 2013-06-05 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 9 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain Q
25–300（276 aa）
Fragment：UNP RESIDUES 25-300
|
Not recorded | CL CHLORIDE ION × 5 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；1.9 M ammonium sulphate, 2% PEG 6K, 100 mM Tris-HCl, VAPOR DIFFUSION, SITTING DROP, temperature 293K
|
Resolution 2.64 Å R-free 0.218 |
| 4L3E The complex between high affinity TCR DMF5(alpha-D26Y,beta-L98W) and human Class I MHC HLA-A2 with the bound MART-1(26-35)(A27L) peptide Deposited 2013-06-05 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；298 K；12% PEG3350, 0.1 M Tris-HCl, 0.25 M magnesium chloride, pH 8, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.56 Å R-free 0.266 |
| 4MNQ TCR-peptide specificity overrides affinity enhancing TCR-MHC interactions Deposited 2013-09-11 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | GOL GLYCEROL × 1 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；291 K；TRIS 0.02M, 20% PEG 4000, 0.01M NaCl, pH 7.5, VAPOR DIFFUSION, SITTING DROP, temperature 291K
|
Resolution 2.74 Å R-free 0.284 |
| 4NNX Crystal structure of PKD2 phosphopeptide bound to HLA-A2 Deposited 2013-11-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
Fragment：extracellular domain (UNP residues 25-298)
|
Not recorded | CD CADMIUM ION × 4 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；11% PEG3350, 0.1 M HEPES, pH 7.5, 0.15 M sodium chloride, 0.003 M magnesium chloride, 0.003 M cadmium chloride, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.10 Å R-free 0.236 |
| 4NNY Crystal structure of non-phosphorylated form of PKD2 phosphopeptide bound to HLA-A2 Deposited 2013-11-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
Fragment：extracellular domain (UNP residues 25-298)
|
Not recorded | CD CADMIUM ION × 3 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；15% PEG3350, 0.1 M HEPES, 0.2 M sodium chloride, 0.003 M magnesium chloride, 0.003 M cadmium chloride, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.90 Å R-free 0.229 |
| 4NO0 Crystal structure of non-phosphorylated form of RQA_V phosphopeptide bound to HLA-A2 in complex with LILRB1 Deposited 2013-11-19 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
25–300（276 aa）
Fragment：extracellular domain (UNP residues 25-300)
|
Not recorded | EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；18% PEG3350, 0.1 M HEPES, pH 7.4, 0.2 M ammonium acetate, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.70 Å R-free 0.309 |
| 4NO2 Crystal structure of RQA_V phosphopeptide bound to HLA-A2 Deposited 2013-11-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
Fragment：extracellular domain (UNP residues 25-298)
|
Not recorded | EDO 1,2-ETHANEDIOL × 3 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；20% PEG8000, 0.1 M HEPES, pH 7.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.00 Å R-free 0.249 |
| 4NO3 Crystal structure of AMPD2 phosphopeptide bound to HLA-A2 Deposited 2013-11-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
Fragment：extracellular domain (UNP residues 25-298)
|
Not recorded | EDO 1,2-ETHANEDIOL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；298 K；12% PEG3350, 8% tacsimate, pH 8.0, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 1.70 Å R-free 0.232 |
| 4NO5 Crystal structure of non-phosphorylated form of AMPD2 phosphopeptide bound to HLA-A2 Deposited 2013-11-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：extracellular domain (UNP residues 25-299)
|
Not recorded | EDO 1,2-ETHANEDIOL × 3 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；19% PEG3350, 0.1 M Bis-Tris propane, 0.1 M sodium tartrate, pH 6.5, VAPOR DIFFUSION, HANGING DROP, temperature 298K
|
Resolution 2.10 Å R-free 0.237 |
| 4OV5 Structure of HLA-DR1 with a bound peptide with non-optimal alanine in the P1 pocket Deposited 2014-02-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
128–141（14 aa）
Fragment：peptide (UNP residues 128-141)
|
Mutation：W1A, Q9L | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；277 K；4% PEG4000, 10% ethylene glycol, 100 mM sodium acetate, pH 5.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.20 Å R-free 0.239 |
| 4OV5 Structure of HLA-DR1 with a bound peptide with non-optimal alanine in the P1 pocket Deposited 2014-02-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain F
128–141（14 aa）
Fragment：peptide (UNP residues 128-141)
|
Mutation：W1A, Q9L | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；277 K；4% PEG4000, 10% ethylene glycol, 100 mM sodium acetate, pH 5.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.20 Å R-free 0.239 |
| 4OV5 Structure of HLA-DR1 with a bound peptide with non-optimal alanine in the P1 pocket Deposited 2014-02-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain I
128–141（14 aa）
Fragment：peptide (UNP residues 128-141)
|
Mutation：W1A, Q9L | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；277 K；4% PEG4000, 10% ethylene glycol, 100 mM sodium acetate, pH 5.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.20 Å R-free 0.239 |
| 4OV5 Structure of HLA-DR1 with a bound peptide with non-optimal alanine in the P1 pocket Deposited 2014-02-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain L
128–141（14 aa）
Fragment：peptide (UNP residues 128-141)
|
Mutation：W1A, Q9L | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；277 K；4% PEG4000, 10% ethylene glycol, 100 mM sodium acetate, pH 5.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.20 Å R-free 0.239 |
| 4OV5 Structure of HLA-DR1 with a bound peptide with non-optimal alanine in the P1 pocket Deposited 2014-02-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 5 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain O
128–141（14 aa）
Fragment：peptide (UNP residues 128-141)
|
Mutation：W1A, Q9L | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；277 K；4% PEG4000, 10% ethylene glycol, 100 mM sodium acetate, pH 5.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.20 Å R-free 0.239 |
| 4OV5 Structure of HLA-DR1 with a bound peptide with non-optimal alanine in the P1 pocket Deposited 2014-02-20 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 6 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain R
128–141（14 aa）
Fragment：peptide (UNP residues 128-141)
|
Mutation：W1A, Q9L | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5；277 K；4% PEG4000, 10% ethylene glycol, 100 mM sodium acetate, pH 5.0, VAPOR DIFFUSION, HANGING DROP, temperature 277K
|
Resolution 2.20 Å R-free 0.239 |
| 4QOK Structural basis for ineffective T-cell responses to MHC anchor residue improved heteroclitic peptides Deposited 2014-06-20 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；291 K；0.1 M Sodium Cacodylate, pH 6.5, 15% PEG 4000, 15% Glycerol, VAPOR DIFFUSION, SITTING DROP, temperature 291K
|
Resolution 3.00 Å R-free 0.262 |
| 4U6X Crystal Structure of HLA-A*0201 in complex with ALQDA, a 15 mer self-peptide Deposited 2014-07-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | CL CHLORIDE ION × 4 PEG DI(HYDROXYETHYL)ETHER × 3 MG MAGNESIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 7.5；277 K；18-22.5% PEG 3350, Hepes pH 7.5, 0.1M MgCl2
|
Resolution 1.68 Å R-free 0.202 |
| 4U6Y Crystal Structure of HLA-A*0201 in complex with FLNDK, a 15 mer self-peptide Deposited 2014-07-30 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | PEG DI(HYDROXYETHYL)ETHER × 2 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 7.5；277 K；18-225 PEG 3350, Hepes pH 7.5, 0.1M MgCl2
|
Resolution 1.47 Å R-free 0.189 |
| 4UQ3 Crystal structure of HLA-A0201 in complex with an azobenzene- containing peptide Deposited 2014-06-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAIN, RESIDUES 25-299
|
Not recorded | IPA ISOPROPYL ALCOHOL × 4 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.10 Å R-free 0.221 |
| 4UQ3 Crystal structure of HLA-A0201 in complex with an azobenzene- containing peptide Deposited 2014-06-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
25–299（275 aa）
Fragment：EXTRACELLULAR DOMAIN, RESIDUES 25-299
|
Not recorded | IPA ISOPROPYL ALCOHOL × 4 | X-RAY DIFFRACTION mmCIF provides none of the parsed conditions | Resolution 2.10 Å R-free 0.221 |
| 4WJ5 Structure of HLA-A2 in complex with an altered peptide ligands based on Mart-1 variant epitope Deposited 2014-09-29 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；295 K；Good diffracting crystals were obtained by streak seeding
|
Resolution 1.65 Å R-free 0.179 |
| 4WJ5 Structure of HLA-A2 in complex with an altered peptide ligands based on Mart-1 variant epitope Deposited 2014-09-29 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 9 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；295 K；Good diffracting crystals were obtained by streak seeding
|
Resolution 1.65 Å R-free 0.179 |
| 4WUU Structure of ESK1 in complex with HLA-A*0201/WT1 Deposited 2014-11-03 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 5.25；291 K；0.1 M Bis-Tris HCl pH 5.5, 25 percent PEG 3350
|
Resolution 3.05 Å R-free 0.254 |
| 5C07 1E6 TCR in complex with HLA-A02 carrying YQFGPDFPIA Deposited 2015-06-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | SO4 SULFATE ION × 3 EDO 1,2-ETHANEDIOL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2M sodium cholride, 0.1M HEPES pH7, 20% PEG 3350
|
Resolution 2.11 Å R-free 0.237 |
| 5C07 1E6 TCR in complex with HLA-A02 carrying YQFGPDFPIA Deposited 2015-06-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | SO4 SULFATE ION × 3 EDO 1,2-ETHANEDIOL × 6 GOL GLYCEROL × 7 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2M sodium cholride, 0.1M HEPES pH7, 20% PEG 3350
|
Resolution 2.11 Å R-free 0.237 |
| 5C08 1E6 TCR in Complex with HLA-A0e carrying RQWGPDPAAV Deposited 2015-06-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | EDO 1,2-ETHANEDIOL × 12 GOL GLYCEROL × 3 SO4 SULFATE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2M sodium cholride, 0.1M MES pH6, 20% PEG 6000
|
Resolution 2.33 Å R-free 0.272 |
| 5C08 1E6 TCR in Complex with HLA-A0e carrying RQWGPDPAAV Deposited 2015-06-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | EDO 1,2-ETHANEDIOL × 13 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2M sodium cholride, 0.1M MES pH6, 20% PEG 6000
|
Resolution 2.33 Å R-free 0.272 |
| 5C09 HLA class I histocompatibility antigen Deposited 2015-06-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | SO4 SULFATE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1M sodium cacodylate pH6.5, 15% PEG 4000, 0.2M sodium acetate
|
Resolution 2.48 Å R-free 0.259 |
| 5C09 HLA class I histocompatibility antigen Deposited 2015-06-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | SO4 SULFATE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1M sodium cacodylate pH6.5, 15% PEG 4000, 0.2M sodium acetate
|
Resolution 2.48 Å R-free 0.259 |
| 5C0A 1E6 TCR in complex with HLA-A02 carrying MVW peptide Deposited 2015-06-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | EDO 1,2-ETHANEDIOL × 5 SO4 SULFATE ION × 5 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1M HEPES pH7.5, 15% PEG 4000, 0.2M sodium acetate
|
Resolution 2.46 Å R-free 0.232 |
| 5C0A 1E6 TCR in complex with HLA-A02 carrying MVW peptide Deposited 2015-06-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | EDO 1,2-ETHANEDIOL × 8 SO4 SULFATE ION × 3 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1M HEPES pH7.5, 15% PEG 4000, 0.2M sodium acetate
|
Resolution 2.46 Å R-free 0.232 |
| 5C0B 1E6 TCR in complex with HLA-A02 carrying RQFGPDFPTI Deposited 2015-06-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | EDO 1,2-ETHANEDIOL × 30 GOL GLYCEROL × 3 SO4 SULFATE ION × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1M HEPES, pH 7.5, 15% PEG 4000, 0.2M sodium acetate
|
Resolution 2.03 Å R-free 0.231 |
| 5C0B 1E6 TCR in complex with HLA-A02 carrying RQFGPDFPTI Deposited 2015-06-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | EDO 1,2-ETHANEDIOL × 25 GOL GLYCEROL × 3 SO4 SULFATE ION × 3 PG4 TETRAETHYLENE GLYCOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1M HEPES, pH 7.5, 15% PEG 4000, 0.2M sodium acetate
|
Resolution 2.03 Å R-free 0.231 |
| 5C0C 1E6 TCR in complex with HLA-A02 carrying RQFGPDWIVA Deposited 2015-06-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | EDO 1,2-ETHANEDIOL × 15 PG4 TETRAETHYLENE GLYCOL × 2 SO4 SULFATE ION × 4 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1M HEPES pH7, 15% PEG 4000, 0.2M sodium acetate
|
Resolution 1.97 Å R-free 0.227 |
| 5C0C 1E6 TCR in complex with HLA-A02 carrying RQFGPDWIVA Deposited 2015-06-12 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | EDO 1,2-ETHANEDIOL × 18 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1M HEPES pH7, 15% PEG 4000, 0.2M sodium acetate
|
Resolution 1.97 Å R-free 0.227 |
| 5C0D HLA-A02 carrying AQWGPDPAAA Deposited 2015-06-12 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2M sodium malonate, 0.1M BIS TRIS propane, pH 6.5, 20% PEG3350
|
Resolution 1.68 Å R-free 0.214 |
| 5C0E HLA-A02 carrying YLGGPDFPTI Deposited 2015-06-12 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：RESIDUES 25-300
|
Not recorded | BR BROMIDE ION × 1 EDO 1,2-ETHANEDIOL × 17 GOL GLYCEROL × 4 PG4 TETRAETHYLENE GLYCOL × 11 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1M TRIS pH8, 25% PEG 4000, 15% glycerol
|
Resolution 1.49 Å R-free 0.179 |
| 5C0F HLA-A02 carrying RQWGPDPAAV Deposited 2015-06-12 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：residues 25-300
|
Not recorded | EDO 1,2-ETHANEDIOL × 18 GOL GLYCEROL × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 1 SO4 SULFATE ION × 4 ACY ACETIC ACID × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1M TRIS, pH 8, 20% PEG 8000, 15% glycerol
|
Resolution 1.46 Å R-free 0.181 |
| 5C0G HLA-A02 carrying YLGGPDFPTI Deposited 2015-06-12 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：residues 25-300
|
Not recorded | EDO 1,2-ETHANEDIOL × 14 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2M sodium nitrate, 0.1M BIS TRIS propane pH6.5, 20% PEG 3350
|
Resolution 1.37 Å R-free 0.188 |
| 5C0I HAL-A02 carrying RQFGPDFPTI Deposited 2015-06-12 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：residues 25-300
|
Not recorded | EDO 1,2-ETHANEDIOL × 10 GOL GLYCEROL × 4 SO4 SULFATE ION × 2 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2M potassium/sodium tartrate, 0.1M BIS TRIS propane, pH 8.5, 20% PEG 3350
|
Resolution 1.53 Å R-free 0.191 |
| 5C0J HLA-A02 carrying RQFGPDWIVA Deposited 2015-06-12 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
Fragment：resdieus 25-300
|
Not recorded | EDO 1,2-ETHANEDIOL × 11 SO4 SULFATE ION × 2 CA CALCIUM ION × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2M sodium sulphate, 0.1M BIS TRIS propane, pH 6.5, 20% PEG 3350
|
Resolution 1.64 Å R-free 0.214 |
| 5D2L Crystal structure of TCR C7 in complex with HCMV NLV epitope presented by HLA-A2 Deposited 2015-08-05 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；293 K；30% PEG 400, 0.1M Tris-HCl pH 8.5, 0.2M MgCl2
|
Resolution 3.51 Å R-free 0.355 |
| 5D2L Crystal structure of TCR C7 in complex with HCMV NLV epitope presented by HLA-A2 Deposited 2015-08-05 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain G
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；293 K；30% PEG 400, 0.1M Tris-HCl pH 8.5, 0.2M MgCl2
|
Resolution 3.51 Å R-free 0.355 |
| 5D2L Crystal structure of TCR C7 in complex with HCMV NLV epitope presented by HLA-A2 Deposited 2015-08-05 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain M
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；293 K；30% PEG 400, 0.1M Tris-HCl pH 8.5, 0.2M MgCl2
|
Resolution 3.51 Å R-free 0.355 |
| 5D2L Crystal structure of TCR C7 in complex with HCMV NLV epitope presented by HLA-A2 Deposited 2015-08-05 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain C
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；293 K；30% PEG 400, 0.1M Tris-HCl pH 8.5, 0.2M MgCl2
|
Resolution 3.51 Å R-free 0.355 |
| 5D2N Crystal structure of C25-NLV-HLA-A2 complex Deposited 2015-08-05 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain H
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | IMD IMIDAZOLE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；PEG3000, Imidazole, Calcium Acetate
|
Resolution 2.10 Å R-free 0.253 |
| 5D2N Crystal structure of C25-NLV-HLA-A2 complex Deposited 2015-08-05 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | IMD IMIDAZOLE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；PEG3000, Imidazole, Calcium Acetate
|
Resolution 2.10 Å R-free 0.253 |
| 5D9S Structure of HLA-A2:01 with the 11-mer peptide F11V Deposited 2015-08-19 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
|
Not recorded | GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293.15 K；30% PEG 5000 MME, 0.1M Tris-HCl pH 8.0, 0.2M lithium sulfate
|
Resolution 1.87 Å R-free 0.223 |
| 5DDH Structure of HLA-A2:01 with the 12-mer peptide F12K Deposited 2015-08-24 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
|
Not recorded | GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 8；293.15 K；30% PEG 4000, 0.1M Tris-HCl 8.0, 0.2M lithium sulfate
|
Resolution 1.50 Å R-free 0.218 |
| 5E00 Structure of HLA-A2 P130 Deposited 2015-09-26 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：UNP RESIDUES 25-299
|
Not recorded | SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；291 K；0.1mol/liter bis-Tris (pH 6.5), 20% (wt/vol) polyethylene glycol 3350
|
Resolution 1.70 Å R-free 0.205 |
| 5E6I Crystal structure of TCR PF8 in complex with flu MP(58-66) epitope presented by HLA-A2 Deposited 2015-10-09 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain I
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；0.1M immidazole pH8, 0.2M calcium acetate, 10%(v/v) PEG8000
|
Resolution 4.00 Å R-free 0.338 |
| 5E6I Crystal structure of TCR PF8 in complex with flu MP(58-66) epitope presented by HLA-A2 Deposited 2015-10-09 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain C
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；0.1M immidazole pH8, 0.2M calcium acetate, 10%(v/v) PEG8000
|
Resolution 4.00 Å R-free 0.338 |
| 5E6I Crystal structure of TCR PF8 in complex with flu MP(58-66) epitope presented by HLA-A2 Deposited 2015-10-09 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain M
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；0.1M immidazole pH8, 0.2M calcium acetate, 10%(v/v) PEG8000
|
Resolution 4.00 Å R-free 0.338 |
| 5E6I Crystal structure of TCR PF8 in complex with flu MP(58-66) epitope presented by HLA-A2 Deposited 2015-10-09 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain R
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；293 K；0.1M immidazole pH8, 0.2M calcium acetate, 10%(v/v) PEG8000
|
Resolution 4.00 Å R-free 0.338 |
| 5E9D RD-1 Mart-1 High bound to Mart-1 decameric peptide (ELA) in complex with HLA-A2 Deposited 2015-10-15 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；300 K；PEG 4000, 0.002 M Zinc Acetate, 5% 2- propanol.
|
Resolution 2.51 Å R-free 0.232 |
| 5E9D RD-1 Mart-1 High bound to Mart-1 decameric peptide (ELA) in complex with HLA-A2 Deposited 2015-10-15 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 5.6；300 K；PEG 4000, 0.002 M Zinc Acetate, 5% 2- propanol.
|
Resolution 2.51 Å R-free 0.232 |
| 5ENW Structure of HLA-A2:01 with peptide G9L Deposited 2015-11-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
|
Not recorded | GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293.15 K；30% PEG 4000, 0.1M Tris-HCl pH 8.0, 0.2M lithium sulfate
|
Resolution 1.85 Å R-free 0.244 |
| 5EOT Structure of HLA-A2:01 with peptide G13E Deposited 2015-11-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
26–298（273 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293.15 K；30% PEG 5000 MME, 0.1M Tris-HCl pH 8.0, 0.2M lithium sulfate
|
Resolution 2.10 Å R-free 0.237 |
| 5EU3 HLA Class I antigen Deposited 2015-11-18 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 1 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；294 K；0.1 M Hepes pH 7.5, 0.2 M Ammonium Sulphate, 25 % PEG 4000
|
Resolution 1.97 Å R-free 0.255 |
| 5EU4 HLA Class I antigen Deposited 2015-11-18 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | GOL GLYCEROL × 1 EDO 1,2-ETHANEDIOL × 4 SO4 SULFATE ION × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；294 K；0.1 M Tris pH 8.0, 15 % Glycerol, 20 % PEG 4000
|
Resolution 2.12 Å R-free 0.211 |
| 5EU4 HLA Class I antigen Deposited 2015-11-18 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 2 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；294 K；0.1 M Tris pH 8.0, 15 % Glycerol, 20 % PEG 4000
|
Resolution 2.12 Å R-free 0.211 |
| 5EU5 HLA Class I antigen Deposited 2015-11-18 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 18 GOL GLYCEROL × 10 SO4 SULFATE ION × 8 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7.5；294 K；0.1 M Hepes pH 7.5, 0.2 M Ammonium Sulphate, 25 % PEG 4000
|
Resolution 1.54 Å R-free 0.201 |
| 5EU6 HLA Class I antigen Deposited 2015-11-18 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 10 GOL GLYCEROL × 3 SO4 SULFATE ION × 8 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；294 K；0.2 M sodium sulphate, 0.1 M Bis Tris propane pH 6.5, 20% w/v PEG 3350.
|
Resolution 2.02 Å R-free 0.222 |
| 5EUO PF6-M1-HLA-A2 Deposited 2015-11-18 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；PEG3350, Imidazole
|
Resolution 2.10 Å R-free 0.281 |
| 5EUO PF6-M1-HLA-A2 Deposited 2015-11-18 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain C
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | IMD IMIDAZOLE × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7；293 K；PEG3350, Imidazole
|
Resolution 2.10 Å R-free 0.281 |
| 5F7D Structure of HLA-A2:01 with peptide G11N Deposited 2015-12-07 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
26–298（273 aa）
|
Not recorded | GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293.15 K；30% PEG 4000, 0.1M Tris-HCl pH 8.0, 0.2M lithium sulfate
|
Resolution 2.30 Å R-free 0.257 |
| 5F9J Structure of HLA-A2:01 with peptide Y9L Deposited 2015-12-09 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
|
Not recorded | GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293.15 K；30% PEG 4000, 0.1M Tris-HCl pH 8.0, 0.2M lithium sulfate
|
Resolution 2.51 Å R-free 0.276 |
| 5FA3 Structure of HLA-A2:01 with peptide G9V Deposited 2015-12-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
26–298（273 aa）
|
Not recorded | GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293.15 K；30% PEG 4000, 0.1M Tris-HCl pH 8.0, 0.2 M lithium sulfate
|
Resolution 1.86 Å R-free 0.235 |
| 5FA4 Structure of HLA-A2:01 with peptide Y16R Deposited 2015-12-10 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
|
Not recorded | GOL GLYCEROL × 2 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293.15 K；30% PEG 4000, 0.1M Tris-HCl pH 8.0, 0.1M lithium sulfate
|
Resolution 2.40 Å R-free 0.259 |
| 5FDW Structure of HLA-A2:01 with peptide Y10L Deposited 2015-12-16 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
|
Not recorded | GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293.15 K；30% PEG 4000, 0.1M Tris-HCl pH 8.0, 0.2M lithium sulfate
|
Resolution 2.70 Å R-free 0.285 |
| 5HHM Crystal Structure of the JM22 TCR in complex with HLA-A*0201 in complex with M1-F5L Deposited 2016-01-11 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；50mM Tris-HCl, 70mM NaCl, 16%PEG10K, 14% glycerol
|
Resolution 2.50 Å R-free 0.289 |
| 5HHM Crystal Structure of the JM22 TCR in complex with HLA-A*0201 in complex with M1-F5L Deposited 2016-01-11 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；50mM Tris-HCl, 70mM NaCl, 16%PEG10K, 14% glycerol
|
Resolution 2.50 Å R-free 0.289 |
| 5HHN Crystal Structure of HLA-A*0201 in complex with M1-F5L Deposited 2016-01-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
Fragment：UNP residues 25-298
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；18-22% PEG 3350, Na citrate pH 6.5, 0.1M MgCl2
|
Resolution 2.03 Å R-free 0.215 |
| 5HHO Crystal Structure of the JM22 TCR in complex with HLA-A*0201 in complex with M1-G4E Deposited 2016-01-11 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
Fragment：UNP residues 25-300
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；50mM Tris-HCl, 70mM NaCl, 16%PEG10K, 14% glycerol
|
Resolution 2.95 Å R-free 0.279 |
| 5HHP Crystal Structure of HLA-A*0201 in complex with M1-G4E Deposited 2016-01-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
Fragment：UNP residues 25-298
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；18-22% PEG 3350, Na citrate pH 6.5, 0.1M MgCl2
|
Resolution 1.90 Å R-free 0.209 |
| 5HHQ Crystal Structure of HLA-A*0201 in complex with M1-L3W Deposited 2016-01-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–298（274 aa）
Fragment：UNP residues 25-298
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；18-22% PEG 3350, Na citrate pH 6.5, 0.1M MgCl2
|
Resolution 2.10 Å R-free 0.227 |
| 5HYJ 1E6 TCR in Complex with HLA-A02 carrying AQWGPDPAAA Deposited 2016-02-01 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；291 K；0.2M sodium citrate, 0.1M BIS TRIS propane pH6.5, 20% PEG 3350
|
Resolution 3.06 Å R-free 0.293 |
| 5HYJ 1E6 TCR in Complex with HLA-A02 carrying AQWGPDPAAA Deposited 2016-02-01 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6.5；291 K；0.2M sodium citrate, 0.1M BIS TRIS propane pH6.5, 20% PEG 3350
|
Resolution 3.06 Å R-free 0.293 |
| 5IRO Crystal structure of a complex between the Human adenovirus type 4 E3-19K protein and MHC class molecule HLA-A2/TAX Deposited 2016-03-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 6.5；291 K；1.5M (NH4)2SO4,0.1M Bis-Tris pH6.5, 0.1MNaCI
|
Resolution 2.64 Å R-free 0.288 |
| 5IRO Crystal structure of a complex between the Human adenovirus type 4 E3-19K protein and MHC class molecule HLA-A2/TAX Deposited 2016-03-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain E
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 6.5；291 K；1.5M (NH4)2SO4,0.1M Bis-Tris pH6.5, 0.1MNaCI
|
Resolution 2.64 Å R-free 0.288 |
| 5IRO Crystal structure of a complex between the Human adenovirus type 4 E3-19K protein and MHC class molecule HLA-A2/TAX Deposited 2016-03-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain I
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 6.5；291 K；1.5M (NH4)2SO4,0.1M Bis-Tris pH6.5, 0.1MNaCI
|
Resolution 2.64 Å R-free 0.288 |
| 5IRO Crystal structure of a complex between the Human adenovirus type 4 E3-19K protein and MHC class molecule HLA-A2/TAX Deposited 2016-03-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain M
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 6.5；291 K；1.5M (NH4)2SO4,0.1M Bis-Tris pH6.5, 0.1MNaCI
|
Resolution 2.64 Å R-free 0.288 |
| 5IRO Crystal structure of a complex between the Human adenovirus type 4 E3-19K protein and MHC class molecule HLA-A2/TAX Deposited 2016-03-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 5 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain Q
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 6.5；291 K；1.5M (NH4)2SO4,0.1M Bis-Tris pH6.5, 0.1MNaCI
|
Resolution 2.64 Å R-free 0.288 |
| 5IRO Crystal structure of a complex between the Human adenovirus type 4 E3-19K protein and MHC class molecule HLA-A2/TAX Deposited 2016-03-14 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 6 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain U
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
EVAPORATION；pH 6.5；291 K；1.5M (NH4)2SO4,0.1M Bis-Tris pH6.5, 0.1MNaCI
|
Resolution 2.64 Å R-free 0.288 |
| 5ISZ Crystal structure of LS01-TCR/M1-HLA-A*02 complex Deposited 2016-03-15 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
|
Not recorded | GOL GLYCEROL × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；277 K；14% (w/v) PEG 4000, 100 mM Na-HEPES pH 7.0, 200 mM ammonium sulfate
|
Resolution 2.06 Å R-free 0.200 |
| 5JHD Crystal structure of LS10-TCR/M1-HLA-A*02 complex Deposited 2016-04-20 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
|
Not recorded | EDT {[-(BIS-CARBOXYMETHYL-AMINO)-ETHYL]-CARBOXYMETHYL-AMINO}-ACETIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；294 K；10%(W/V) PEG8000, 100mM Tris-Cl, 200mM Magnesium chloirde
|
Resolution 2.46 Å R-free 0.223 |
| 5JHD Crystal structure of LS10-TCR/M1-HLA-A*02 complex Deposited 2016-04-20 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–299（275 aa）
|
Not recorded | EDT {[-(BIS-CARBOXYMETHYL-AMINO)-ETHYL]-CARBOXYMETHYL-AMINO}-ACETIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；294 K；10%(W/V) PEG8000, 100mM Tris-Cl, 200mM Magnesium chloirde
|
Resolution 2.46 Å R-free 0.223 |
| 5JZI Crystal structure of 1406 TCR bound to HLA-A2 with HCV 1406-1415 antigen peptide Deposited 2016-05-16 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.1；298 K；13% PEG 3350, 0.1M Sodium Cacodylate, 0.2m Ammonium Sulfate, 3% w/v 1,5-Diaminopentane dihydrochloride
|
Resolution 2.50 Å R-free 0.232 |
| 5JZI Crystal structure of 1406 TCR bound to HLA-A2 with HCV 1406-1415 antigen peptide Deposited 2016-05-16 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.1；298 K；13% PEG 3350, 0.1M Sodium Cacodylate, 0.2m Ammonium Sulfate, 3% w/v 1,5-Diaminopentane dihydrochloride
|
Resolution 2.50 Å R-free 0.232 |
| 5MEN Human Leukocyte Antigen A02 presenting ILAKFLHWL, in complex with cognate T-Cell Receptor Deposited 2016-11-16 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 5 GOL GLYCEROL × 1 SO4 SULFATE ION × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2M ammonium sulphate, 0.1M HEPES pH7, 20% PEG 8000
|
Resolution 2.81 Å R-free 0.272 |
| 5MEO Human Leukocyte Antigen presenting ILGKFLHRL Deposited 2016-11-16 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 15 GOL GLYCEROL × 4 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2 M ammonium sulphate, 0.1 M Tris pH 7.5, 25% PEG 8000
|
Resolution 1.77 Å R-free 0.214 |
| 5MEP Human Leukocyte Antigen A02 presenting ILGKFLHWL Deposited 2016-11-16 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 6 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2M ammonium sulphate, 0.1M MES pH7, 15% PEG 8000
|
Resolution 2.71 Å R-free 0.239 |
| 5MEP Human Leukocyte Antigen A02 presenting ILGKFLHWL Deposited 2016-11-16 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2M ammonium sulphate, 0.1M MES pH7, 15% PEG 8000
|
Resolution 2.71 Å R-free 0.239 |
| 5MEQ Human Leukocyte Antigen A02 presenting ILAKFLHTL Deposited 2016-11-16 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | SO4 SULFATE ION × 1 EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2M ammonium sulphate, 0.1M HEPES pH7, 20% PEG 8000
|
Resolution 2.27 Å R-free 0.264 |
| 5MER Human Leukocyte Antigen A02 presenting ILAKFLHEL Deposited 2016-11-16 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 10 CA CALCIUM ION × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 SO4 SULFATE ION × 3 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2M ammonium sulphate, 0.1M MES pH7, 25% PEG 8000
|
Resolution 1.88 Å R-free 0.224 |
| 5MER Human Leukocyte Antigen A02 presenting ILAKFLHEL Deposited 2016-11-16 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 10 CA CALCIUM ION × 1 MES 2-(N-MORPHOLINO)-ETHANESULFONIC ACID × 2 SO4 SULFATE ION × 7 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2M ammonium sulphate, 0.1M MES pH7, 25% PEG 8000
|
Resolution 1.88 Å R-free 0.224 |
| 5N1Y HLA-A02 carrying MVWGPDPLYV Deposited 2017-02-06 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 10 GOL GLYCEROL × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2M ammonium chloride, 0.1M TRIS pH8, 20% PEG 6000
|
Resolution 1.39 Å R-free 0.201 |
| 5N6B Human Leukocyte Antigen Class I A02 Carrying LLWNPGMAV Deposited 2017-02-14 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 7 EPE 4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID × 1 PEG DI(HYDROXYETHYL)ETHER × 2 SO4 SULFATE ION × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2M ammonium sulphate, 0.1M HEPES pH7, 20% PEG 4000
|
Resolution 1.71 Å R-free 0.214 |
| 5N6B Human Leukocyte Antigen Class I A02 Carrying LLWNPGMAV Deposited 2017-02-14 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 4 EPE 4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID × 1 PEG DI(HYDROXYETHYL)ETHER × 1 SO4 SULFATE ION × 1 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.2M ammonium sulphate, 0.1M HEPES pH7, 20% PEG 4000
|
Resolution 1.71 Å R-free 0.214 |
| 5NHT human 199.54-16 TCR in complex with Melan-A/MART-1 (26-35) peptide and HLA-A2 Deposited 2017-03-22 | Different construct Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 5 PDB declaration: pentameric |
Chain H
25–300（276 aa）
Fragment：UNP Residues 25-300
|
Mutation：A245V | SCN THIOCYANATE ION × 1 K POTASSIUM ION × 2 CL CHLORIDE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；PEG3350 8 %, K Thiocyanate 0.1 M, Bis-Tris propane pH 6.5 0.1 M, protein concentration 3.5 mg/ml
|
Resolution 3.20 Å R-free 0.299 |
| 5NME 868 TCR in complex with HLA A02 presenting SLYNTVATL Deposited 2017-04-05 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 4 SO4 SULFATE ION × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M Sodium Cacodylate, pH 6.0, 15% PEG 4000, 0.2 M Ammonium Sulphate
|
Resolution 2.94 Å R-free 0.263 |
| 5NME 868 TCR in complex with HLA A02 presenting SLYNTVATL Deposited 2017-04-05 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 4 SO4 SULFATE ION × 4 GOL GLYCEROL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M Sodium Cacodylate, pH 6.0, 15% PEG 4000, 0.2 M Ammonium Sulphate
|
Resolution 2.94 Å R-free 0.263 |
| 5NMF 868 TCR in complex with HLA A02 presenting SLYNTIATL Deposited 2017-04-05 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 5 GOL GLYCEROL × 2 SO4 SULFATE ION × 8 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M Sodium Cacodylate, pH 6.0, 15% PEG 4000, 0.2 M Ammonium Sulphate
|
Resolution 2.89 Å R-free 0.255 |
| 5NMF 868 TCR in complex with HLA A02 presenting SLYNTIATL Deposited 2017-04-05 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 14 GOL GLYCEROL × 1 SO4 SULFATE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M Sodium Cacodylate, pH 6.0, 15% PEG 4000, 0.2 M Ammonium Sulphate
|
Resolution 2.89 Å R-free 0.255 |
| 5NMG 868 TCR in complex with HLA A02 presenting SLYFNTIAVL Deposited 2017-04-05 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 13 GOL GLYCEROL × 3 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M Sodium Cacodylate, pH 5.5, 15% PEG 4000, 0.2 M Ammonium Sulphate
|
Resolution 2.75 Å R-free 0.254 |
| 5NMG 868 TCR in complex with HLA A02 presenting SLYFNTIAVL Deposited 2017-04-05 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 3 SO4 SULFATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M Sodium Cacodylate, pH 5.5, 15% PEG 4000, 0.2 M Ammonium Sulphate
|
Resolution 2.75 Å R-free 0.254 |
| 5NMH HLA A02 presenting SLYNTIATL Deposited 2017-04-05 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 7 GOL GLYCEROL × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M Sodium Cacodylate, pH 6.0, 25% PEG 4000, 0.2 M Ammonium Sulphate
|
Resolution 1.55 Å R-free 0.196 |
| 5NMK HLA A02 presenting SLFNTIAVL Deposited 2017-04-06 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 9 GOL GLYCEROL × 1 SO4 SULFATE ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M Sodium Cacodylate, pH 6.0, 25% PEG 4000, 0.2 M Ammonium Sulphate
|
Resolution 1.66 Å R-free 0.210 |
| 5NQK human 199.16 TCR in complex with Melan-A/MART-1 (26-35) peptide and HLA-A2 Deposited 2017-04-20 | Different mutation/modification Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 5 PDB declaration: pentameric |
Chain H
25–300（276 aa）
|
Mutation：A245V | NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；293 K；PEG3350 11%, bis-tris propane pH 6.5 0.1M, KNa tartrate 0.1M
|
Resolution 3.25 Å R-free 0.316 |
| 5SWQ Crystal Structure of HLA-A*0201 in complex with NA231, an influenza epitope Deposited 2016-08-08 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；20%PEG6K, 0.1M Na-Citrate pH6.5, 0.2M NaCl
|
Resolution 2.00 Å R-free 0.258 |
| 5TEZ TCR F50 recgonizing M1-HLA-A2 Deposited 2016-09-23 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；295 K；PEG 3350, 0.1 M imidazole (pH 8.0), and 0.2 M sodium malonate
|
Resolution 1.70 Å R-free 0.224 |
| 5WSH Structure of HLA-A2 P130 Deposited 2016-12-07 | Different construct Different mutation/modification Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：UNP RESIDUES 25-299
|
Mutation：A269V | PEG DI(HYDROXYETHYL)ETHER × 3 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；0.1mol/L bis-tris(pH6.5), 20%(wt/vol) polyethylene glycol 3350
|
Resolution 2.00 Å R-free 0.196 |
| 5YXN A T cell receptor in complex with HLA-A0201 restricted Hepatitis C virus NS3 peptide (KLVALGINAV) Deposited 2017-12-06 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain C
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；21% PEG 3350, 0.18 M Ammonium tartrate dibasic
|
Resolution 2.03 Å R-free 0.223 |
| 5YXU an affinity enhanced T cell receptor in complex with HLA-A0201 restricted HCV NS3 peptide KLVALGINAV Deposited 2017-12-07 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain E
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；15% PEG 3350, 0.2M potassium nitrate
|
Resolution 2.70 Å R-free 0.289 |
| 5YXU an affinity enhanced T cell receptor in complex with HLA-A0201 restricted HCV NS3 peptide KLVALGINAV Deposited 2017-12-07 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain C
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；291 K；15% PEG 3350, 0.2M potassium nitrate
|
Resolution 2.70 Å R-free 0.289 |
| 6AM5 Crystal structure of DMF5 TCR bound to HLA-A2 presenting synthetic peptide SMLGIGIVPV Deposited 2017-08-09 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.1；298 K；13% PEG3350, 0.25 M magnesium chloride, 0.1 M Tris
|
Resolution 2.39 Å R-free 0.244 |
| 6AMT Human Class I MHC HLA-A2 in complex with synthetic peptide MMWDRGLGMM Deposited 2017-08-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；298 K；25% PEG1000, 0.01% sodium azide, 0.1 M MES
|
Resolution 2.50 Å R-free 0.249 |
| 6AMT Human Class I MHC HLA-A2 in complex with synthetic peptide MMWDRGLGMM Deposited 2017-08-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.4；298 K；25% PEG1000, 0.01% sodium azide, 0.1 M MES
|
Resolution 2.50 Å R-free 0.249 |
| 6AMU Crystal structure of DMF5 TCR bound to HLA-A2 presenting synthetic peptide MMWDRGLGMM Deposited 2017-08-11 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
26–298（273 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.9；298 K；18% PEG3350, 0.25 M magnesium chloride, 0.1 M HEPES
|
Resolution 2.15 Å R-free 0.226 |
| 6APN HLA-A*0201 single chain trimer with HPV.16 E7 peptide LLMGTLGIV Deposited 2017-08-17 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
26–301（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；295 K；0.1 M MES, pH 6,5, 25% PEG 2000 MME
|
Resolution 2.22 Å R-free 0.260 |
| 6APN HLA-A*0201 single chain trimer with HPV.16 E7 peptide LLMGTLGIV Deposited 2017-08-17 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric |
Chain B
26–301（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；295 K；0.1 M MES, pH 6,5, 25% PEG 2000 MME
|
Resolution 2.22 Å R-free 0.260 |
| 6D78 The complex between high-affinity TCR DMF5(alpha-D26Y,beta-L98W) and human Class I MHC HLA-A2 with the bound MART-1(27-35)peptide Deposited 2018-04-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；298 K；0.1 M Tris, 12% PEG6000, 0.2 M magnesium chloride
|
Resolution 2.35 Å R-free 0.255 |
| 6D7G Structure of 5F3 TCR in complex with HLA-A2/MART-1 Deposited 2018-04-24 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | NAG 2-acetamido-2-deoxy-beta-D-glucopyranose × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；295.15 K；PEG 550 MME, TRIS, VAPOR DIFFUSION,
SITTING DROP, TEMPERATURE 295K
|
Resolution 2.75 Å R-free 0.237 |
| 6DKP The complex among DMF5(alpha-D26Y, alpha-Y50A,beta-L98W) TCR, human Class I MHC HLA-A2 and MART-1(26-35)(A27L) peptide Deposited 2018-05-30 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–299（275 aa）
Fragment：residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8；298 K；12% Peg 3350, 250mM MgCl2, 0.1M HEPES
|
Resolution 2.97 Å R-free 0.286 |
| 6E1I HLA-A*0201 single chain trimer with murine H2K alpha 3 domain and HPV.16 E7 peptide YMLDLQPET Deposited 2018-07-09 | Different construct Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Monomer；Protein × 1 PDB declaration: monomeric |
Chain A
25–207（183 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；295 K；0.1 M Hepes, 25% PEG 6000
|
Resolution 1.99 Å R-free 0.233 |
| 6EQA HLA class I histocompatibility antigen Deposited 2017-10-12 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | SO4 SULFATE ION × 4 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M HEPES pH 7.5, 25% PEG 4000 and 15% glycerol
|
Resolution 3.16 Å R-free 0.263 |
| 6EQB HLA class I histocompatibility antigen Deposited 2017-10-12 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | EPE 4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID × 2 SO4 SULFATE ION × 4 EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M HEPES pH 7.0, 20% PEG 4000 and 15% glycerol
|
Resolution 2.81 Å R-free 0.251 |
| 6EWA Crystal structure of HLA-A2 in complex with LILRB1 Deposited 2017-11-03 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；17.5% PEG 3350, 0.2M Ammonium acetate, 0.1M Tris HCL
|
Resolution 2.39 Å R-free 0.279 |
| 6EWA Crystal structure of HLA-A2 in complex with LILRB1 Deposited 2017-11-03 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain E
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；17.5% PEG 3350, 0.2M Ammonium acetate, 0.1M Tris HCL
|
Resolution 2.39 Å R-free 0.279 |
| 6EWC Crystal structure of non-phosphorylated form of RLS PHOSPHOPEPTIDE BOUND TO HLA-A2 in complex with LILRB1 Deposited 2017-11-03 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；298 K；12.8% PEG 3350, 3% Tacsimate, 10% dimethyl sulphoxide
|
Resolution 3.20 Å R-free 0.246 |
| 6EWC Crystal structure of non-phosphorylated form of RLS PHOSPHOPEPTIDE BOUND TO HLA-A2 in complex with LILRB1 Deposited 2017-11-03 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain E
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6；298 K；12.8% PEG 3350, 3% Tacsimate, 10% dimethyl sulphoxide
|
Resolution 3.20 Å R-free 0.246 |
| 6EWO Crystal structure of non-phosphorylated form of RTF PHOSPHOPEPTIDE BOUND TO HLA-A2 in complex with LILRB1 Deposited 2017-11-06 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain A
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；20% PEG 3350, 0.2M Potassium sodium tartrate
|
Resolution 2.30 Å R-free 0.276 |
| 6EWO Crystal structure of non-phosphorylated form of RTF PHOSPHOPEPTIDE BOUND TO HLA-A2 in complex with LILRB1 Deposited 2017-11-06 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 4 PDB declaration: tetrameric |
Chain E
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；298 K；20% PEG 3350, 0.2M Potassium sodium tartrate
|
Resolution 2.30 Å R-free 0.276 |
| 6G3J MHC A02 Allele presenting MTSAIGILVP Deposited 2018-03-26 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K
|
Resolution 2.45 Å R-free 0.270 |
| 6G3J MHC A02 Allele presenting MTSAIGILVP Deposited 2018-03-26 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K
|
Resolution 2.45 Å R-free 0.270 |
| 6G3K MHC A02 Allele presenting MTSAIGILPV Deposited 2018-03-26 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K
|
Resolution 2.90 Å R-free 0.287 |
| 6G3K MHC A02 Allele presenting MTSAIGILPV Deposited 2018-03-26 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K
|
Resolution 2.90 Å R-free 0.287 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain I
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 10 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain R
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 11 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 12 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain Q
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 13 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 14 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 15 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain N
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 16 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 17 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain K
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 18 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain C
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 19 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain S
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain B
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 20 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain M
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain L
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain J
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 5 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain T
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 6 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain F
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 7 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain P
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 8 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain O
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6NCA HLA-A2 (A*02:01) bound to a peptide from the Epstein-Barr virus BRLF1 protein Deposited 2018-12-11 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 9 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain E
25–299（275 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 8.5；277 K；10.5% (w/v) PEG 4000, 35 mM Tris base/ HCl (pH 8.5), 70 mM Li2SO4
|
Resolution 3.30 Å R-free 0.303 |
| 6OPD Crystal Structure of ILNAMIVKI peptide bound to HLA-A2 Deposited 2019-04-24 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | ACT ACETATE ION × 3 GOL GLYCEROL × 4 MG MAGNESIUM ION × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；298 K；20% PEG8000, 100 mM MES, pH 6.5, 200 mM magnesium acetate
|
Resolution 1.79 Å R-free 0.204 |
| 6PTB Crystal Structure of ILNAMIAKI peptide bound to HLA-A2 Deposited 2019-07-15 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；15% v/v PEG3350, 100 mM MES
|
Resolution 2.15 Å R-free 0.232 |
| 6PTB Crystal Structure of ILNAMIAKI peptide bound to HLA-A2 Deposited 2019-07-15 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 6.5；277 K；15% v/v PEG3350, 100 mM MES
|
Resolution 2.15 Å R-free 0.232 |
| 6PTE Crystal Structure of ILNAMITKI peptide bound to HLA-A2 Deposited 2019-07-15 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | GOL GLYCEROL × 3 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；296 K；20% v/v PEG3350, 100 mM HEPES, pH 7.5
|
Resolution 1.90 Å R-free 0.185 |
| 6PTE Crystal Structure of ILNAMITKI peptide bound to HLA-A2 Deposited 2019-07-15 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain E
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | GOL GLYCEROL × 3 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；296 K；20% v/v PEG3350, 100 mM HEPES, pH 7.5
|
Resolution 1.90 Å R-free 0.185 |
| 6PTE Crystal Structure of ILNAMITKI peptide bound to HLA-A2 Deposited 2019-07-15 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain H
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | GOL GLYCEROL × 3 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；296 K；20% v/v PEG3350, 100 mM HEPES, pH 7.5
|
Resolution 1.90 Å R-free 0.185 |
| 6PTE Crystal Structure of ILNAMITKI peptide bound to HLA-A2 Deposited 2019-07-15 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain K
25–299（275 aa）
Fragment：UNP residues 25-299
|
Not recorded | GOL GLYCEROL × 3 NA SODIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, HANGING DROP；pH 7.5；296 K；20% v/v PEG3350, 100 mM HEPES, pH 7.5
|
Resolution 1.90 Å R-free 0.185 |
| 6Q3K Engineered Human HLA_A2 MHC Class I molecule in complex with NV9 peptide Deposited 2018-12-04 | Different construct Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
24–299（276 aa）
|
Not recorded | GOL GLYCEROL × 2 CO COBALT (II) ION × 7 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；5 mM cobalt chloride, 5 mM cadmium chloride, 5 mM magnesium chloride, 5 mM nickel chloride,
0.1 M HEPES pH 7.5, 12 % PEG 3350.
|
Resolution 1.50 Å R-free 0.200 |
| 6Q3S Engineered Human HLA_A2 MHC Class I molecule in complex with TCR and SV9 peptide Deposited 2018-12-04 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | GOL GLYCEROL × 1 ACT ACETATE ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.1 M ammonium acetate; 0.1 M bis-tris pH 5.5, 17 %(w/v) PEG 10.000
|
Resolution 2.50 Å R-free 0.273 |
| 6R2L NYBR1-A2-SLSKILDTV Deposited 2019-03-18 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Insufficient information Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | PEG DI(HYDROXYETHYL)ETHER × 1 EDO 1,2-ETHANEDIOL × 2 GOL GLYCEROL × 3 SO4 SULFATE ION × 8 EPE 4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 6；291 K；0.2 M NaCl, 0.1 M MES, 20% PEG 6000, pH 6.0 . Condition B07 from Molecular Dimensions PACT premier HT-96/FX-96, MD1-36
|
Resolution 2.30 Å R-free 0.265 |
| 6RP9 Crystal structure of the T-cell receptor NYE_S3 bound to HLA A2*01-SLLMWITQV Deposited 2019-05-14 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2 M ammonium sulphate, 15 % PEG8k, 0.1 M Tris pH7.5
|
Resolution 3.12 Å R-free 0.250 |
| 6RP9 Crystal structure of the T-cell receptor NYE_S3 bound to HLA A2*01-SLLMWITQV Deposited 2019-05-14 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2 M ammonium sulphate, 15 % PEG8k, 0.1 M Tris pH7.5
|
Resolution 3.12 Å R-free 0.250 |
| 6RPA Crystal structure of the T-cell receptor NYE_S2 bound to HLA A2*01-SLLMWITQV Deposited 2019-05-14 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.02 M sodium/potassium phosphate, 20 % PEG 3350
|
Resolution 2.56 Å R-free 0.293 |
| 6RPB Crystal structure of the T-cell receptor NYE_S1 bound to HLA A2*01-SLLMWITQV Deposited 2019-05-14 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2 M Ammonium sulfate, 25 %(w/v) PEG 4000, 0.1 M tri-Sodium citrate pH 5.6
|
Resolution 2.50 Å R-free 0.273 |
| 6RPB Crystal structure of the T-cell receptor NYE_S1 bound to HLA A2*01-SLLMWITQV Deposited 2019-05-14 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2 M Ammonium sulfate, 25 %(w/v) PEG 4000, 0.1 M tri-Sodium citrate pH 5.6
|
Resolution 2.50 Å R-free 0.273 |
| 6RPB Crystal structure of the T-cell receptor NYE_S1 bound to HLA A2*01-SLLMWITQV Deposited 2019-05-14 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain K
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2 M Ammonium sulfate, 25 %(w/v) PEG 4000, 0.1 M tri-Sodium citrate pH 5.6
|
Resolution 2.50 Å R-free 0.273 |
| 6RPB Crystal structure of the T-cell receptor NYE_S1 bound to HLA A2*01-SLLMWITQV Deposited 2019-05-14 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain P
25–300（276 aa）
|
Not recorded | No recorded non-water small molecule |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；293 K；0.2 M Ammonium sulfate, 25 %(w/v) PEG 4000, 0.1 M tri-Sodium citrate pH 5.6
|
Resolution 2.50 Å R-free 0.273 |
| 6RSY The complex between TCR a7b2 and human Class I MHC HLA-A0201-WT1 with the bound RMFPNAPYL peptide. Deposited 2019-05-22 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；297 K；7.5% PEG 8 K , 0.75 M NaCl , 50mM HEPES , pH 7.0
|
Resolution 2.95 Å R-free 0.291 |
| 6RSY The complex between TCR a7b2 and human Class I MHC HLA-A0201-WT1 with the bound RMFPNAPYL peptide. Deposited 2019-05-22 | Different oligomeric state Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 5 PDB declaration: pentameric |
Chain F
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；297 K；7.5% PEG 8 K , 0.75 M NaCl , 50mM HEPES , pH 7.0
|
Resolution 2.95 Å R-free 0.291 |
| 6SS7 Human Leukocyte Antigen Class I A02 Carrying LLWAGPMAV Deposited 2019-09-06 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–300（276 aa）
|
Not recorded | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 2 SO4 SULFATE ION × 5 GOL GLYCEROL × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M Sodium Cacodylate pH 6.0, 0.2 M Ammonium Sulphate, 25% PEG 4000. A2/LLW-7I crystals were grown in 0.1 M Mes pH 7.0, 0.2 M Ammonium Sulphate, 25% PEG 8000
|
Resolution 2.50 Å R-free 0.304 |
| 6SS7 Human Leukocyte Antigen Class I A02 Carrying LLWAGPMAV Deposited 2019-09-06 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | NA SODIUM ION × 1 EDO 1,2-ETHANEDIOL × 5 SO4 SULFATE ION × 5 GOL GLYCEROL × 5 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M Sodium Cacodylate pH 6.0, 0.2 M Ammonium Sulphate, 25% PEG 4000. A2/LLW-7I crystals were grown in 0.1 M Mes pH 7.0, 0.2 M Ammonium Sulphate, 25% PEG 8000
|
Resolution 2.50 Å R-free 0.304 |
| 6SS8 Human Leukocyte Antigen Class I A02 Carrying LLWNGPIAV Deposited 2019-09-06 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | GOL GLYCEROL × 3 EDO 1,2-ETHANEDIOL × 1 SO4 SULFATE ION × 6 PEG DI(HYDROXYETHYL)ETHER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M Mes pH 7.0, 0.2 M Amonium Sulphate, 25 % PEG 8000
|
Resolution 2.24 Å R-free 0.277 |
| 6SS8 Human Leukocyte Antigen Class I A02 Carrying LLWNGPIAV Deposited 2019-09-06 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–300（276 aa）
|
Not recorded | GOL GLYCEROL × 6 SO4 SULFATE ION × 5 PEG DI(HYDROXYETHYL)ETHER × 1 P4G 1-ETHOXY-2-(2-ETHOXYETHOXY)ETHANE × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；291 K；0.1 M Mes pH 7.0, 0.2 M Amonium Sulphate, 25 % PEG 8000
|
Resolution 2.24 Å R-free 0.277 |
| 6SSA Human Leukocyte Antigen Class I A02 Carrying LLWNGPMQV Deposited 2019-09-06 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 1 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain A
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 1 GOL GLYCEROL × 1 PEG DI(HYDROXYETHYL)ETHER × 2 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；291 K；0.1 M Sodium Cacodylate pH 6.5, 0.2 M Ammonium Sulphate, 20 % PEG 4000
|
Resolution 2.11 Å R-free 0.271 |
| 6SSA Human Leukocyte Antigen Class I A02 Carrying LLWNGPMQV Deposited 2019-09-06 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 2 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain D
25–300（276 aa）
|
Not recorded | GOL GLYCEROL × 2 PEG DI(HYDROXYETHYL)ETHER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；291 K；0.1 M Sodium Cacodylate pH 6.5, 0.2 M Ammonium Sulphate, 20 % PEG 4000
|
Resolution 2.11 Å R-free 0.271 |
| 6SSA Human Leukocyte Antigen Class I A02 Carrying LLWNGPMQV Deposited 2019-09-06 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 3 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain G
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 1 GOL GLYCEROL × 4 PEG DI(HYDROXYETHYL)ETHER × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；291 K；0.1 M Sodium Cacodylate pH 6.5, 0.2 M Ammonium Sulphate, 20 % PEG 4000
|
Resolution 2.11 Å R-free 0.271 |
| 6SSA Human Leukocyte Antigen Class I A02 Carrying LLWNGPMQV Deposited 2019-09-06 | Different ligand/ion Different experimental conditions Different structure-quality metrics | Assembly 4 Protein heterocomplex Heteromer；Protein × 3 PDB declaration: trimeric |
Chain J
25–300（276 aa）
|
Not recorded | EDO 1,2-ETHANEDIOL × 1 GOL GLYCEROL × 5 PEG DI(HYDROXYETHYL)ETHER × 1 CA CALCIUM ION × 1 |
X-RAY DIFFRACTION
X-ray crystallization conditions
VAPOR DIFFUSION, SITTING DROP；pH 7；291 K；0.1 M Sodium Cacodylate pH 6.5, 0.2 M Ammonium Sulphate, 20 % PEG 4000
|
Resolution 2.11 Å R-free 0.271 |
271 other PDB entries and 464 assemblies. Open the comparison page and filter oligomeric states
View Construct and Data Evidence
| UniProt name | 1A02_HUMAN |
| Isoform | — |
| PDB entities | 1 |
| Chains and sequence ranges | Author chain A； PDBConstruct 1–276； UniProt 25–300 Author chain D； PDBConstruct 1–276； UniProt 25–300 |
