6z9v

Human Class I Major Histocompatibility Complex, A02 allele, presenting IIGWMWIPV

Method: X-RAY DIFFRACTION

▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

MHC class I antigen

Homo sapiens

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein heterocomplex	Heteromer	Protein 3	Beta-2-microglobulin × 1 （P61769） ILE-ILE-GLY-TRP-MET-TRP-ILE-PRO-VAL × 1 1,2-ETHANEDIOL × 5 GLYCEROL × 1 SULFATE ION × 3 SODIUM ION × 1 1-ETHOXY-2-(2-ETHOXYETHOXY)ETHANE × 1 water × 3	Consistent with protein count
2	Protein heterocomplex	Heteromer	Protein 3	Beta-2-microglobulin × 1 （P61769） ILE-ILE-GLY-TRP-MET-TRP-ILE-PRO-VAL × 1 1,2-ETHANEDIOL × 5 GLYCEROL × 5 SULFATE ION × 1 1-ETHOXY-2-(2-ETHOXYETHOXY)ETHANE × 1 3,6,9,12,15,18,21-HEPTAOXATRICOSANE-1,23-DIOL × 1 CALCIUM ION × 1 water × 3	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	A0A5B8RNS7_HUMAN
Isoform	—
PDB entities	1
Chains and sequence ranges	Author chain A； PDBConstruct 1–276； UniProt 25–300 Author chain D； PDBConstruct 1–276； UniProt 25–300

Beta-2-microglobulin

Homo sapiens

UniProt P61769

State in the Current Structure

Assembly	Physical composition	Protein state	Molecular copy count	Associated components	Data consistency
1	Protein heterocomplex	Heteromer	Protein 3	MHC class I antigen × 1 （A0A5B8RNS7） ILE-ILE-GLY-TRP-MET-TRP-ILE-PRO-VAL × 1 1,2-ETHANEDIOL × 5 GLYCEROL × 1 SULFATE ION × 3 SODIUM ION × 1 1-ETHOXY-2-(2-ETHOXYETHOXY)ETHANE × 1 water × 3	Consistent with protein count
2	Protein heterocomplex	Heteromer	Protein 3	MHC class I antigen × 1 （A0A5B8RNS7） ILE-ILE-GLY-TRP-MET-TRP-ILE-PRO-VAL × 1 1,2-ETHANEDIOL × 5 GLYCEROL × 5 SULFATE ION × 1 1-ETHOXY-2-(2-ETHOXYETHOXY)ETHANE × 1 3,6,9,12,15,18,21-HEPTAOXATRICOSANE-1,23-DIOL × 1 CALCIUM ION × 1 water × 3	Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence

UniProt name	B2MG_HUMAN
Isoform	—
PDB entities	2
Chains and sequence ranges	Author chain B； PDBConstruct 2–100； UniProt 21–119 Author chain E； PDBConstruct 2–100； UniProt 21–119

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id	6z9v
Deposition date deposition_date	2020-06-04
Structure title title	Human Class I Major Histocompatibility Complex, A02 allele, presenting IIGWMWIPV
Keywords keywords	MHC I, IMMUNE SYSTEM; IMMUNE SYSTEM
Experimental Method method	X-RAY DIFFRACTION

▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

6z9v__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

6z9v__assembly_1__model_1 | I(q)

100 plotted points; both axes use logarithmic scales.

6z9v__assembly_1__model_1 | P(r) · Pending

P(r) will be calculated and displayed separately for the same assembly/model.

Rg（Guinier）	24.17 Å
Rg (electron density)	23.03 Å
Total Rg	23.90 Å
Atom count	3223
Residues	385
Excluded volume	56423 Å³
Maximum q	0.500 Å⁻¹

Assembly	Model	Structure unit	Oligomeric description	Status	CRYSOL	Actions
1	1	`6z9v__assembly_1__model_1`	trimeric （3）	Success	4.1.3-1-20251215 (887e7ef)	View Download
2	1	`6z9v__assembly_2__model_1`	trimeric （3）	Success	4.1.3-1-20251215 (887e7ef)	View Download

▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (11)

Entity 1 Entity 1 polymer

Description description	MHC class I antigen
Molecular weight formula_weight	31951.3 kDa
Source method src_method	man
Copy count entity_count	2

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	A,D
Atom count atom_count	7063

GSHSMRYFFTSVSRPGRGEPRFIAVGYVDDTQFVRFDSDAASQRMEPRAPWIEQEGPEYWDGETRKVKAHSQTHRVDLGTLRGYYNQSEAGSHTVQRMYGCDVGSDWRFLRGYHQYAYDGKDYIALKEDLRSWTAADMAAQTTKHKWEAAHVAEQLRAYLEGTCVEWLRRYLENGKETLQRTDAPKTHMTHHAVSDHEATLRCWALSFYPAEITLTWQRDGEDQTQDTELVETRPAGDGTFQKWAAVVVPSGQEQRYTCHVQHEGLPKPLTLRWEP

Source Source

Source organism organism	Homo sapiens
Common name common_name	Human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Escherichia coli

Entity 2 Entity 2 polymer

Description description	Beta-2-microglobulin
Molecular weight formula_weight	11879.4 kDa
Source method src_method	man
Copy count entity_count	2

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	B,E

MIQRTPKIQVYSRHPAENGKSNFLNCYVSGFHPSDIEVDLLKNGERIEKVEHSDLSFSKDWSFYLLYYTEFTPTEKDEYACRVNHVTLSQPKIVKWDRDM

Source Source

Source organism organism	Homo sapiens
Common name common_name	Human
NCBI taxonomy ID ncbi_taxonomy_id	9606
Host organism host_organism	Escherichia coli

Entity 3 Entity 3 polymer

Description description	ILE-ILE-GLY-TRP-MET-TRP-ILE-PRO-VAL
Molecular weight formula_weight	1114.4 kDa
Source method src_method	syn
Copy count entity_count	2

Polymer Polymer

Polymer type type	polypeptide(L)
Chain IDs strand_id	C,F

IIGWMWIPV

Entity 4 Entity 4 non-polymer

Description description	1,2-ETHANEDIOL
Molecular weight formula_weight	62.1 kDa
Source method src_method	syn
Copy count entity_count	10

Entity 5 Entity 5 non-polymer

Description description	GLYCEROL
Molecular weight formula_weight	92.1 kDa
Source method src_method	syn
Copy count entity_count	6

Entity 6 Entity 6 non-polymer

Description description	SULFATE ION
Molecular weight formula_weight	96.1 kDa
Source method src_method	syn
Copy count entity_count	4

Entity 7 Entity 7 non-polymer

Description description	SODIUM ION
Molecular weight formula_weight	23.0 kDa
Source method src_method	syn
Copy count entity_count	1

Entity 8 Entity 8 non-polymer

Description description	1-ETHOXY-2-(2-ETHOXYETHOXY)ETHANE
Molecular weight formula_weight	162.2 kDa
Source method src_method	syn
Copy count entity_count	2

Entity 9 Entity 9 non-polymer

Description description	3,6,9,12,15,18,21-HEPTAOXATRICOSANE-1,23-DIOL
Molecular weight formula_weight	370.4 kDa
Source method src_method	syn
Copy count entity_count	1

Entity 10 Entity 10 non-polymer

Description description	CALCIUM ION
Molecular weight formula_weight	40.1 kDa
Source method src_method	syn
Copy count entity_count	1

Entity 11 Entity 11 water

Description description	water
Molecular weight formula_weight	18.0 kDa
Source method src_method	nat
Copy count entity_count	491

▶

Unit-cell length a length_a	85.190 Å
Unit-cell length b length_b	85.190 Å
Unit-cell length c length_c	232.550 Å
Unit-cell angle α angle_alpha	90.00 °
Unit-cell angle β angle_beta	90.00 °
Unit-cell angle γ angle_gamma	120.00 °
Molecules per unit cell Z z_pdb	12

Space group space_group	P 32 1 2
Space-group number int_tables_number	153
Crystal system crystal_system	—

Resolution resolution	2.010 Å
Low-resolution limit resolution_low	73.780 Å
R factor r_factor	0.1778
R_work r_work	0.1758
R_free r_free	0.2164
