6wvd

Human JAGN1

Method: X-RAY DIFFRACTION
▼

1. Protein Identity and Related Structures Protein Identity & Related Structures

Green fluorescent protein, Protein jagunal homolog 1 chimera

Aequorea victoria

UniProt P42212

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Insufficient information Monomer Protein 1 (2R)-2,3-dihydroxypropyl (9Z)-octadec-9-enoate × 2 water × 1 Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence
UniProt name GFP_AEQVI
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A; PDBConstruct 1–142; UniProt 1–144 Author chain A; PDBConstruct 326–411; UniProt 146–231

Green fluorescent protein, Protein jagunal homolog 1 chimera

Aequorea victoria

UniProt Q8N5M9

State in the Current Structure

Assembly Physical composition Protein state Molecular copy count Associated components Data consistency
1 Insufficient information Monomer Protein 1 (2R)-2,3-dihydroxypropyl (9Z)-octadec-9-enoate × 2 water × 1 Consistent with protein count

Other States of the Same Protein in the Database

View Construct and Data Evidence
UniProt name JAGN1_HUMAN
Isoform —
PDB entities 1
Chains and sequence ranges Author chain A; PDBConstruct 143–325; UniProt 1–183

The page prioritizes protein identity, the current assembly, associated components, oligomeric state and cross-PDB links. Chain mapping and sequence ranges are retained as data evidence. Internal IDs, import timestamps and assembly operation expressions are maintenance fields and are not shown here.

▼

2. Structure Basics 2. Structure Basics

Entry ID entry_id6wvd
Deposition date deposition_date2020-05-05
Structure title titleHuman JAGN1
Keywords keywordsJAGN1, Protein jagunal homolog 1, MEMBRANE PROTEIN; MEMBRANE PROTEIN
Experimental Method methodX-RAY DIFFRACTION
▼

3. Official assembly/model SAXS Official SAXS Profiles

This page reads only the latest assembly calculations. Every curve maps to an explicit PDB entry, official biological assembly and coordinate model.

6wvd__assembly_1__model_1

Assembly 1 · Model 1 · CRYSOL 4.1.3-1-20251215 (887e7ef)

Download this curve (.dat)

6wvd__assembly_1__model_1 | I(q)

10-2 10-1 105 106 107 q (1/Angstrom) I(q)
100 plotted points; both axes use logarithmic scales.

6wvd__assembly_1__model_1 | P(r) · Pending

The new assembly/model P(r) has not been calculated yet This placeholder does not display legacy data r (Angstrom) P(r)
P(r) will be calculated and displayed separately for the same assembly/model.
Rg(Guinier)30.70 Å
Rg (electron density)31.03 Å
Total Rg31.37 Å
Atom count3229
Residues397
Excluded volume58083 ų
Maximum q0.500 Å⁻¹
Assembly Model Structure unit Oligomeric description Status CRYSOL Actions
1 1 6wvd__assembly_1__model_1 monomeric (1) Success 4.1.3-1-20251215 (887e7ef) View Download
▶

4. Crystallography and Experiment 4. Crystallography & Experiment

▶

5. Entities and Polymers Entities & Polymers (3)

▶

7. Citations (1)
